New Insights into Reservoirs Heterogeneous Genesis of Favorable Facies in Pinghu Formation, Xihu Depression
-
摘要: 河流-潮汐双向水流沉积环境中，水体方向、动力、化学属性变化频繁，储层矿物基础、成岩过程复杂多变、物性非均质性强，一直是制约其勘探开发的难点.以中国东海西湖凹陷平湖组为例，针对河流-潮汐背景中潮道和水下分流河道两种高能沉积微相，通过岩心观察、孔渗测试、光镜等方法，从物质基础、物性规律、主控因素3个方面开展研究.结果表明：（1）潮道中上部物性好，孔隙度平均18%、渗透率平均120 mD（1 mD≈10-3 μm2），而潮道底部致密，孔隙度平均4%、渗透率平均0.05 mD；呈现非均质性的主要原因是碳酸盐胶结导致底部致密；（2）水下分流河道上部物性好，孔隙度平均5%、渗透率平均70 mD，而水下分流河道底部致密，孔隙度平均1%、渗透率平均0.01 mD；呈现非均质性的主要原因是高岭石充填导致底部致密.上述研究明确了西湖凹陷平湖组2种优势微相的非均质性成因，对深化河流-潮汐背景下储层非均质性规律及成因机制具有重要的理论指导意义；技术方法、研究成果可应用于东海盆地低渗砂岩储层油气勘探，对于中国近海、国外区块的深层碎屑岩储层油气勘探亦具有重要推广借鉴意义.Abstract: Flow direction, dynamic and chemical properties change frequently in fluvial and tidal sedimentary environment, the reservoir mineral foundation and diagenetic process are complex and changeable, and the physical property is strong heterogeneity, which has always been the difficulty restricting its exploration and development. In this paper, Pinghu Formation in Xihu Depression of East Sea, China was taken as an example. Material basis, materiality pattern and main controlling factors were investigated in two high-energy sedimentary microphases, namely tidal channel and submerged divergent river channel. Methods include core observation, pore penetration test, light microscopy, isotope and inclusions. The results show follows. (1) The upper/middle part of tidal channel possessed good physical properties with an average porosity of 18% and permeability of 120 mD, while the bottom of tidal channel was dense with an average porosity of 4% and permeability of 0.05 mD. The main reason for the inhomogeneity is that the bottom is dense due to carbonate cementation. (2) The upper part of submerged diversion channel had good physical properties with an average porosity of 5% and permeability of 70 mD, while the bottom of submerged diversion channel was dense with an average porosity of 1% and permeability of 0.05 mD. The main reason for the inhomogeneity is that the bottom is dense due to kaolinite filling. The above analysis has important theoretical guiding significance to deepen the law and formation mechanism of reservoir heterogeneity under fluvial and tidal background. The technical methods and research results can be applied to the oil and gas exploration of low permeability sandstone reservoirs in the East China Sea basin, and have important reference significance for the oil and gas exploration of deep clastic reservoirs in offshore China and foreign blocks.
-
Key words:
- offshore /
- deep-buried /
- non-homogeneous /
- carbonate /
- kaolinite /
- petroleum geology
-
图 2 西湖凹陷平湖组潮道
a. 潮道孔隙度与渗透率相关性统计图; b.水下分流河道孔隙度与渗透率相关性统计图.1 mD≈10-3 μm2
Fig. 2. Physical properties of Pinghu Formation in Xihu sag
图 3 潮道微相岩心柱状图及典型沉积构造特征(A1井)
a. 3 445.57 m，褐色泥质薄层；b. 3 442.40 m，潮束构造；c. 3 443.55 m，羽状交错层理；d. 3 445.27 m，脉状层理；e.3 441.72 m，变形层理、泥砾；f. 3 440.62 m，双黏土层
Fig. 3. Core histogram and typical sedimentary structure of tidal channel (Well A1)
图 4 研究区水下分流河道微相储层岩心柱状图(A3井)
a. 4 202.75 m，岩性截变面、冲刷面；b. 变形构造；c. 4 207.60 m，泄水构造；d. 4 206.70 m，植物碎片；e. 4 201.70 m，截变接触、低角度交错；f. 4 201.40 m，楔状交错层理
Fig. 4. Core histogram of underwater distributary channel (Well A3)
图 5 研究区潮道微相储层孔渗性随深度的变化规律
a. A1井，3 439.19~3 447.38 m；b.A2井，潮道底部0.50 m
Fig. 5. Variation of porosity and permeability of tidal channel
图 6 研究区水下分流河道微相储层孔渗性随深度的变化规律
A3井, 4 191.27~4 202.87 m
Fig. 6. Variation of porosity and permeability of underwater distributary channel
图 7 潮道碳酸盐胶结物与孔隙度相关性统计图(a)和碳酸盐胶结物与渗透率相关性统计图(b)
Fig. 7. Correlation between carbonate cement and porosity (a) and correlation between carbonate cement and permeability (b) in tidal channel
图 8 潮道微相储层矿物组成特征及孔隙类型
Fig. 8. Mineral composition characteristics and pore types of tidal channel
图 9 高岭石与孔隙度(a)和渗透率(b)相关性统计
高岭石含量据A3井薄片统计
Fig. 9. Correlation statistics of kaolinite with porosity (a) and permeability (b)
-
Cao, Y. C., Yuan, G. H., Li, X. Y., et al., 2013. Types and Characteristics of Anomalously High Porosity Zones in Paleogene Mid-Deep Buried Reservoirs in the Northern Slope, Dongying Sag. Acta Petrolei Sinica, 34(4): 683-691(in Chinese with English abstract). Feng, J. R., Gao, Z. Y., Cui, J. G., et al., 2016. The Exploration Status and Research Advances of Deep and Ultra-Deep Clastic Reservoirs. Advances in Earth Science, 31(7): 718-736(in Chinese with English abstract). Gao, W. Z., Yang, C. H., Zhao, H., 2015. Reservoir Formation and Modification Controlled by Thermal Events in the Xihu Sag, East China Sea Basin. Petroleum Geology and Experiment, 37(5): 548-554(in Chinese with English abstract). Gong, L., Gao, X. Z., Qu, F. T., et al., 2023. Reservoir Quality and Controlling Mechanism of the Upper Paleogene Fine-Grained Sandstones in Lacustrine Basin in the Hinterlands of Northern Qaidam Basin, NW China. Journal of Earth Science, 34(3): 806-823. https://doi.org/10.1007/s12583-022-1701-6 Gu, H. R., Jia, J. Y., Ye, J. R., 2002. Characteristics of Oil and Gas Bearing System in Xihu Lake Depression in the East China Sea. Oil & Gas Geology, 23(3): 295-297, 306(in Chinese with English abstract). Hu, M. Y., Shen, J., Hu, D., 2013. Reservoir Characteristics and Its Main Controlling Factors of the Pinghu Formation in Pinghu Structural Belt, Xihu Depression. Oil & Gas Geology, 34(2): 185-191(in Chinese with English abstract). Hu, W. R., Bao, J. W., Hu, B., 2013. Trend and Progress in Global Oil and Gas Exploration. Petroleum Exploration and Development, 40(4): 409-413(in Chinese with English abstract). Jiang, H. J., Hu, M. Y., Hu, Z. G., et al., 2011. Sedimentary Environment of Paleogene in Xihu Sag: Microfossil as the Main Foundation. Lithologic Reservoirs, 23(1): 74-78 (in Chinese with English abstract). doi: 10.3969/j.issn.1673-8926.2011.01.013 Jiang, P., Wang, Z. Z., Zou, M. S., et al., 2021. Development Characteristics of Carbonate Cement and Its Influence on Reservoir Quality in Sandstones from Zhuhai Formation in Wenchang A Depression. Earth Science, 46(2): 600-620(in Chinese with English abstract). Liu, J. S., Cao, B., Xu, Z. X., et al., 2012. Sedimentary Facies and the Characteristics of Tight Sandstone Reservoirs of Huagang Formation in Xihu Depression, East China Sea Basin. Journal of Chengdu University of Technology (Science & Technology Edition), 39(2): 130-136(in Chinese with English abstract). doi: 10.3969/j.issn.1671-9727.2012.02.003 Morad, S., Ketzer, J. M., De Ros, L. F., 2000. Spatial and Temporal of Diagenetic Alterations in Siliciclastic Rocks: Implications for Mass Transfer in Sedimentary Basins. Sedimentology, 47: 95-120. doi: 10.1046/j.1365-3091.2000.00007.x Pan, R., Zhu, X. M., Wang, X. X., et al., 2014. Advancement on Formation Mechanism of Deep Effective Clastic Reservoir. Lithologic Reservoirs, 26(4): 73-80(in Chinese with English abstract). doi: 10.3969/j.issn.1673-8926.2014.04.011 Sun, L. D., Zou, C. N., Zhu, R. K., et al., 2013. Formation, Distribution and Potential of Deep Hydrocarbon Resources in China. Petroleum Exploration and Development, 40(6): 641-649(in Chinese with English abstract). Tong, X. G., Zhang, G. Y., Wang, Z. M., et al., 2014. Distribution and Potential of Global Oil and Gas Resources. Earth Science Frontiers, 21(3): 1-9(in Chinese with English abstract). Wu, K. Q., Xie, X. J., Liao, J. H., et al., 2023. The Rules of Reservoir Characteristics and Dissolution of Paleogene Clastic Rocks in Offshore China. Earth Science, 48(2): 385-397(in Chinese with English abstract). Wu, J. P., Zhang, L., Wan, L. F., et al., 2017. Provenance Analysis of Pinghu Formation in Xihu Sag. China Petroleum Exploration, 22(2): 50-57(in Chinese with English abstract). doi: 10.3969/j.issn.1672-7703.2017.02.006 Xie, X. J., Xiong, L. Q., Chen, Y., et al., 2021. Low Permeability Reservoir Characteristics and Controlling Factors of "Sweet Points" of Pinghu Formation in Xihu Sag. Science Technology and Engineering, 21(30): 12890-12900(in Chinese with English abstract). doi: 10.3969/j.issn.1671-1815.2021.30.014 Yang, H. J., Li, Y., Tang, Y. G., et al., 2019. Discovery of Kelasu Subsalt Deep Large Gas Field, Tarim Basin. Xinjiang Petroleum Geology, 40(1): 12-20(in Chinese with English abstract). Yang, W. X., Gui, L. L., Zhou, H., et al., 2023. Diagenesis and Accumulation Process of Silurian Sandstone Reservoir in Keping Area, Northwest Tarim Basin. Earth Science, 48(11): 4103-4116(in Chinese with English abstract). Yu, S., 2020. Depositional Genesis Analysis of Source Rock in Pinghu Formation of Western Slope, Xihu Depression. Earth Science, 45(5): 1722-1736(in Chinese with English abstract). Yu, X. H., Li, S. L., 2009. The Development and Hotspot Problems of Clastic Petroleum Reservoir Sedimentology. Acta Sedimentologica Sinica, 27(5): 880-895(in Chinese with English abstract). Zhang, G. C., Tian, B., Xie, X. J., et al., 2019. A Full-Life-Cycle Research Methodology of Deep High-Quality Clastic Rock Reservoir. Acta Petrolei Sinica, 40(S2): 13-28(in Chinese with English abstract). Zhang, K. X., Bai, G. P., Cao, B. F., et al., 2016. Geological Features of Siliciclastic Reservoirs in Deep Petroleum Accumulations. Chinese Journal of Engineering, 38(1): 1-10(in Chinese with English abstract). Zhang, L., Shu, Z. g., He, S., et al., 2021. Reservoir Characteristics and Differential Evolution Process of Xujiahe Formation in Jiannan Area, East Sichuan. Earth Science, 46(9): 3139-3156(in Chinese with English abstract). Zhong, D. K., Zhu, X. M., Wang, H. J., 2008. Reservoir Characteristics and Formation Mechanism of Deep High-Quality Clastic Rocks in China. Science in China (Ser. D), 38(S1): 11-18(in Chinese). Zhou, X. H., Gao, S. L., Gao, W. Z., et al., 2019. Formation and Distribution of Marine-Continental Transitional Lithologic Reservoirs in Pingbei Slope Belt, Xihu Sag, East China Sea Shelf Basin. China Petroleum Exploration, 24(2): 153-164(in Chinese with English abstract). 操应长, 远光辉, 李晓艳, 等, 2013. 东营凹陷北带古近系中深层异常高孔带类型及特征. 石油学报, 34(4): 683-691. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201304008.htm 冯佳睿, 高志勇, 崔京钢, 等, 2016. 深层、超深层碎屑岩储层勘探现状与研究进展. 地球科学进展, 31(7): 718-736. https://www.cnki.com.cn/Article/CJFDTOTAL-DXJZ201607009.htm 高伟中, 杨彩虹, 赵洪, 2015. 东海盆地西湖凹陷热事件对储层的改造及其机理探讨. 石油实验地质, 37(5): 548-554. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD201505005.htm 顾惠荣, 贾健谊, 叶加仁, 2002. 东海西湖凹陷含油气系统特征. 石油与天然气地质, 23(3): 295-297, 306. doi: 10.3321/j.issn:0253-9985.2002.03.021 胡明毅, 沈娇, 胡蝶, 2013. 西湖凹陷平湖构造带平湖组砂岩储层特征及其主控因素. 石油与天然气地质, 34(2): 185-191. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201302009.htm 胡文瑞, 鲍敬伟, 胡滨, 2013. 全球油气勘探进展与趋势. 石油勘探与开发, 40(4): 409-413. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201304002.htm 蒋海军, 胡明毅, 胡忠贵, 等, 2011. 西湖凹陷古近系沉积环境分析: 以微体古生物化石为主要依据. 岩性油气藏, 23(1): 74-78. doi: 10.3969/j.issn.1673-8926.2011.01.013 姜平, 王珍珍, 邹明生, 等, 2021. 文昌A凹陷珠海组砂岩碳酸盐胶结物发育特征及其对储层质量的影响. 地球科学, 46(2): 600-620. doi: 10.3799/dqkx.2020.075 刘金水, 曹冰, 徐志星, 等, 2012. 西湖凹陷某构造花港组沉积相及致密砂岩储层特征. 成都理工大学学报(自然科学版), 39(2): 130-136. doi: 10.3969/j.issn.1671-9727.2012.02.003 潘荣, 朱筱敏, 王星星, 等, 2014. 深层有效碎屑岩储层形成机理研究进展. 岩性油气藏, 26(4): 73-80. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX201404014.htm 孙龙德, 邹才能, 朱如凯, 等, 2013. 中国深层油气形成、分布与潜力分析. 石油勘探与开发, 40(6): 641-649. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201306001.htm 童晓光, 张光亚, 王兆明, 等, 2014. 全球油气资源潜力与分布. 地学前缘, 21(3): 1-9. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201403002.htm 吴嘉鹏, 张兰, 万丽芬, 等, 2017. 西湖凹陷平湖组物源分析. 中国石油勘探, 22(2): 50-57. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201702006.htm 吴克强, 谢晓军, 廖计华, 等, 2023. 中国近海古近纪碎屑岩储层特征与溶蚀作用规律. 地球科学, 48(2): 385-397. doi: 10.3799/dqkx.2022.151 谢晓军, 熊连桥, 陈莹, 等, 2021. 西湖凹陷平湖组低渗储层特征及"甜点" 主控因素分析. 科学技术与工程, 21(30): 12890-12900. https://www.cnki.com.cn/Article/CJFDTOTAL-KXJS202406006.htm 杨海军, 李勇, 唐雁刚, 等, 2019. 塔里木盆地克拉苏盐下深层大气田的发现. 新疆石油地质, 40(1): 12-20. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSD201901003.htm 杨文霞, 桂丽黎, 周慧, 等, 2023. 塔里木盆地柯坪地区志留系砂岩储层成岩与成藏过程. 地球科学, 48(11): 4103-4116. doi: 10.3799/dqkx.2023.004 于水, 2020. 西湖凹陷西斜坡平湖组烃源岩沉积成因分析. 地球科学, 45(5): 1722-1736. doi: 10.3799/dqkx.2019.188 于兴河, 李胜利, 2009. 碎屑岩系油气储层沉积学的发展历程与热点问题思考. 沉积学报, 27(5): 880-895. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200905013.htm 张功成, 田兵, 谢晓军, 等, 2019. 深层优质碎屑岩储层全生命周期分析方法论. 石油学报, 40(增刊2): 13-28. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB2019S2004.htm 张凯逊, 白国平, 曹斌风, 等, 2016. 深层碎屑岩含油气储层发育特征. 工程科学学报, 38(1): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-BJKD201601001.htm 张莉, 舒志国, 何生, 等, 2021. 川东建南地区须家河组储层特征及其差异演化过程. 地球科学, 46(9): 3139-3156. doi: 10.3799/dqkx.2020.302 钟大康, 朱筱敏, 王红军, 2008. 中国深层优质碎屑岩储层特征与形成机理分析. 中国科学(D辑), 38(S1): 11-18. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1002.htm 周心怀, 高顺莉, 高伟中, 等, 2019. 东海陆架盆地西湖凹陷平北斜坡带海陆过渡型岩性油气藏形成与分布预测. 中国石油勘探, 24(2): 153-164. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201902003.htm -
