Provenance and Tectonic Evolution of the Middle and Lower Jurassic Strata Constraints on the Uranium Mineralization in Southwest Margin of Ordos Basin
-
摘要: 鄂尔多斯盆地西南缘位于阿拉善地块、秦岭造山带与祁连造山带3个构造单元的交汇部位，给含铀岩系地层的物源体系和铀成矿作用研究带来一定困难.通过选取泾川研究区的直罗组和延安组砂岩进行碎屑锆石U-Pb测年和微量元素研究，分析结果显示：泾川地区直罗组砂岩的碎屑锆石年龄呈215~767 Ma和1 501~1 905 Ma；延安组砂岩的碎屑锆石年龄呈215~453 Ma、1 506~1 918 Ma和2 136~2 579 Ma.与源区同位素年代学对比认为直罗组和延安组砂岩的物源成分较为复杂，主要来自于阿拉善地块，其次来自于华北板块北缘和北祁连地区.从延安组到直罗组沉积期，祁连山和阿拉善陆块发生了快速隆升和剥蚀，为直罗组提供了物源，并且古生代和中生代侵入岩体提供物源的占比逐渐增大.研究西部靠近盆缘地区以中侏罗统砂岩层为找矿目的层，靠近盆内含矿层位逐渐变年轻.Abstract: The southwest margin of the Ordos basin is located at the intersection of the Alxa massif, the Qinling orogenic belt and the Qilian orogenic belt, which is challenging to the study of the provenance and uranium mineralization of the uranium bearing rock. This paper selects the Zhiluo Formation and Yan'an Formation sandstones in the Jingchuan area to conduct clastic zircon U-Pb dating and trace element research. The analysis results show that the clastic zircon ages of the Zhiluo Formation sandstones in Jingchuan area are 215-767 Ma and 1 501-1 905 Ma; The clastic zircon ages of Yan'an Formation sandstones are 215-453 Ma, 1 506-1 918 Ma and 2 136-2 579 Ma, respectively. Compared with the isotopic chronology of the source area, it is believed that the provenance components of the Zhiluo and Yan'an Formation sandstones are relatively complex, mainly from the Alxa block, followed by the northern margin of the North China plate and the North Qilian area. During the sedimentary period from Yan'an Formation to Zhiluo Formation, Qilian Mountain and Alxa landmass were rapidly uplifted and denuded, providing provenance for Zhiluo Formation, and the proportion of provenance provided by Paleozoic and Mesozoic intrusive rocks gradually increased. The study shows that the strata of middle Jurassic can be taken as the prospecting target strata in the west margin of basin, and the ore bearing strata near the basin gradually become younger.
-
Key words:
- Ordos basin /
- Jingchuan area /
- Middle and Lower Jurassic strata /
- U-Pb ages of detrital zircons /
- provenance /
- deposits /
- tectonics
-
图 1 鄂尔多斯盆地构造单元及研究区地质简图
Fig. 1. Geological diagram of the structural unit and study area of the Ordos basin
图 2 研究区深地孔钻孔柱状图及样品采集位置
Fig. 2. Histogram of deep hole drilling and sampling location in the study area
图 3 研究区中下侏罗统地层砂岩碎屑锆石CL图像
图中圆圈为测点位置，锆石上方为对应样品及测点号，锆石下方数值为锆石U-Pb年龄数值，单位为Ma
Fig. 3. CL image of the subordinate sandstone clastic zircon of Middle and Lower Jurassic strata in the study area
图 4 研究区砂岩碎屑锆石年龄与Th/U关系
Fig. 4. Relationship between sandstone clastic zircon age and Th/U in the study area
图 5 研究区锆石LA-ICP MS U-Pb年龄谐和图
Fig. 5. Study area zircon LA-ICP MS U-Pb age concordia diagram
图 6 研究区砂岩碎屑锆石样品年龄谱（a, b, c, d）
a.YDHSD01-2锆石年龄谱图；b. YDHSD01-4锆石年龄谱图；c. YDHSD01-6锆石年龄谱图；d. YDHSD01-8锆石年龄谱图
Fig. 6. Age spectrum of sandstone clastic zircon samples in the study area (a, b, c, d)
图 7 研究区砂岩碎屑锆石球粒陨石标准化稀土配分曲线（球粒陨石标准化值据Sun et al., 1989）
Fig. 7. Chondrite normalized REE patterns of the zircons of sandstone clastic zircon samples in the study area (chondrite normalized value after Sun et al., 1989)
图 8 研究区中侏罗统地层碎屑锆石微量元素岩性判别图解（底图根据Belousova et al., 2002修改）
Fig. 8. Lithological discriminant diagram of clastic zircon trace elements in the Zhiluo Formation of the Study Area (basemap modified according to Belousova et al., 2002)
图 9 泾川地区侏罗系下统样品岩石学特征
a.YDHSD01-2直罗组砂岩薄片镜下照片；b. YDHSD01-6延安组砂岩薄片镜下照片. Qrt. 石英；Pl. 斜长石；Bit. 黑云母
Fig. 9. Petrological characteristics of lower Jurassic samples in Jingchuan area
图 10 鄂尔多斯盆地直罗组下段沉积相图（据赵俊峰等，2008修改）
Fig. 10. Sedimentary facies distribution of lower member of Zhiluo Formation in Ordos basin
图 11 研究区砂岩碎屑锆石U-Pb年龄谱与周缘年龄谱对比图（N为统计数）
Fig. 11. Comparison chart of U-Pb age spectrum and peripheral age spectrum of sandstone clastic zircon in the study area (N is the statistic)
图 12 鄂尔多斯西南缘中下侏罗系统构造、物源及古地貌演化模式
Fig. 12. Structural, provenance and paleogeomorphic evolution model of Lower Jurassic in the southwest margin of Ordos basin
图 13 泾川地区砂岩型铀矿含氧含铀流体与含烃流体耦合成矿模式简图（据苗培森等，2020改）
Fig. 13. Schematic diagram of coupling mineralization model of oxygen bearing uranium fluid and hydrocarbon bearing fluid in the sandstone type uranium deposit (modified by Miao et al., 2020)
表 2 泾川及周边地区直罗组下段砂岩样品轻矿物对比
Table 2. Correlation of light minerals for the lower member of Zhiluo Formation around and in the Jingchuan area
地区 层位 石英(%) 长石(%) 岩屑(%) 杂基+胶结物(%) 成熟度Q1/(F1+R1) F1/R1 惠安堡 直罗组下段 60~65 1~2 15~25 5~10 0.79~2.4 0.06~0.08 环县 直罗组下段 88~90 0.5~1.0 0.5~1.0 5~8 45~88 1 泾川 直罗组下段 75~80 5~10 1~5 3~5 5.3~12.5 2~5 崇信 直罗组下段 60~65 1~2 10~15 10~20 3.8~5.5 0.10~0.13
下载: 导出CSV
-
Belousova, E., Griffin, W., O'Reilly, S. Y., et al., 2002. Igneous Zircon: Trace Element Composition as an Indicator of Source Rock Type. Contributions to Mineralogy and Petrology, 143(5): 602-622. https://doi.org/10.1007/s00410-002-0364-7 Chen, J. L., He, S. P., Wang, H. L., et al., 2006. Zircon LA-ICPMS U-Pb Age of Mafic Dykes in the Area between the Qinling and the Qilian Orogenic Belts and Its Geological Implications. Acta Petrologica et Mineralogica, 25(6): 455-462 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-6524.2006.06.001 Chen, J. L., Li, H. B., Wang, H. L., et al., 2007. LA-ICPMS Zircon U-Pb Dating of a Quartz Diorite Pluton from Wangjiacha, the Junction Area between the Qinling and Qilian Orogenic Belts and Its Tectonic Significance. Journal of Jilin University (Earth Science Edition), 37(3): 423-431 (in Chinese with English abstract) Duan, J. Y., Liu, P. J., Xia, D. X., 2002. The Preliminary Research on Tectonic Pattern and Tectonic Evolution of Mesoproterozoic-Paleozoic in North China Plate. Geoscience, 16(4): 331-338 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-8527.2002.04.001 Fan, H. R., Hu, F. F., Yang, K. F., et al., 2009. Geochronology Framework of Late Paleozoic Dioritic-Granitic Plutons in the Bayan Obo Area, Inner Mongolia, and Tectonic Significance. Acta Petrologica Sinica, 25(11): 2933-2938 (in Chinese with English abstract). Geng, Y. S., Wang, X. S., Shen, Q. H., et al., 2007. Chronology of the Precambrian Metamorphic Series in the Alxa Area, Inner Mongolia. Geology in China, 34(2): 251-261 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-3657.2007.02.006 Geng, Y. S., Zhou, X. W., 2010. Early Neoproterozoic Granite Events in Alax Area of Inner Mongolia and Their Geological Significance: Evidence from Geochronology. Acta Petrologica et Mineralogica, 29(6): 779-795 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-6524.2010.06.014 Geng, Y. S., Zhou, X. W., Wang, X. S., et al., 2009. Late-Paleoproterozoic Granite Events and Their Geological Significance in Helanshan Area, Inner Mongolia: Evidence from Geochronology. Acta Petrologica Sinica, 25(8): 1830-1842 (in Chinese with English abstract). Gong, J. H., Zhang, J. X., Yu, S. Y., 2013. Redefinition of the "Longshoushan Group" Outcropped in the Eastern Segment of Longshoushan on the Southern Margin of Alxa Block: Evidence from Detrital Zircon U-Pb Dating Results. Acta Petrologica et Mineralogica, 32(1): 1-22 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-6524.2013.01.001 Guo, P., Liu, C. Y., Han, P., et al., 2017. Geochronology of Detrital Zircon from the Lower-Middle Jurassic Strata in the Southwestern Ordos Basin, China, and Its Geological Significance. Geotectonica et Metallogenia, 41(5): 892-907 (in Chinese with English abstract). He, F., Xu, L. Q., Su, H. W., et al., 2004. Characteristics and Tectonic Setting of Middle-Permian A-Type Granites in Tianshuijing Area, West of Inner Mongolia. Northwestern Geology, 37(3): 7-14 (in Chinese with English abstract). doi: 10.3969/j.issn.1009-6248.2004.03.002 Huang, Z. G., 2016. Fission Track Constraints on Mesozoic Cenozoic Ascending Evolution of the Middle Northern Segment of the Luliang Mountains. Taiyuan University of Technology, Taiyuan (in Chinese with English abstract). Jiao, Y. Q., Wu, L. Q., Peng, Y. B., et al., 2015. Sedimentary-Tectonic Setting of the Deposition-Type Uranium Deposits Forming in the Paleo-Asian Tectonic Domain, North China. Earth Science Frontiers, 22(1): 189-205 (in Chinese with English abstract). Jiao, Y. Q., Wu, L. Q., Rong, H., et al., 2022. Sedimentation, Diagenesis and Uranium Mineralization: Innovative Discoveries and Cognitive Challenges in Study of Sandstone-Type Uranium Deposits in China. Earth Science, 47(10): 3580-3603 (in Chinese with English abstract). Jin, R. S., Teng, X. M., 2022. Large Scale Sandstone-Type Uranium Mineralization in Northern China. North China Geology, 45(1): 42-57 (in Chinese with English abstract). Li, J. Y., Zhang, J., Qu, J. F., 2012. Amalgamation of North China Craton with Alxa Block in the Late of Early Paleozoic: Evidengce from Sedmentary Sequences in the Niushou Mountain, Ningxia Hui Autonomous Region, NW China. Geological Review, 58(2): 208-214 (in Chinese with English abstract). doi: 10.3969/j.issn.0371-5736.2012.02.002 Li, K. Y., Li, W. H., Liu, Z., et al., 2016. Characteristics of Early Cretaceous Liupanshan Group Prototype Basin in Liupanshan Basin, Ningxia. Geological Bulletin of China, 35(S1): 383-389 (in Chinese with English abstract). Liu, C. F., 2010. Paleozoic Early Mesozoic Magmatic Rock Belt in Siziwangqi Area, Inner Mongolia and Its Tectonic Significance (Dissertation). China University of Geosciences, Beijing (in Chinese with English abstract). Liu, C. Y., Wang, J. Q., Zhang, D. D., et al., 2021. Genesis of Rich Hydrocarbon Resources and Their Occurrence and Accumulation Characteristics in the Ordos Basin. Oil & Gas Geology, 42(5): 1011-1029 (in Chinese with English abstract). Liu, S. P., Liu, X. F., 2002. Structural Types and Its Relation with Oil and Gas of Bayanhot Basin. Journal of Southwest Petroleum Institute, 24(3): 24-27, 4 (in Chinese with English abstract). Ludwig, K. R., 2009. Isoplot 3.71: A Geochronological Tool-Kit for Microsoft Excel. Berkeley Geochronology Center Special Publication, Berkeley. https://doi.org/10.13140/RG.2.1.3679.3440 Miao, P. S., Chen, Y., Cheng, Y. H., et al., 2020. New Deep Exploration Discoveries of Sandstone-Type Uranium Deposits in North China. Geotectonica et Metallogenia, 44(4): 563-575 (in Chinese with English abstract). Pei, X. Z., Li, Z. C., Li, R. B., et al., 2012. LA-ICP-MS U-Pb Ages of Detrital Zircons from Metamorphic Clastic Rocks of the Early Paleozoic Huluhe Group in the Eastern Segment of the Qilian Orogenic Belt: Source Area Characteristics and Definition of Sedimentary Age. Geological Frontier, 19 (5): 205-224 (in Chinese with English abstract). Ren, Y. S., Yang, X. Y., Miao, P. S., et al., 2022. Mineralogical and Geochemical Research on Pengyang Deposit: A Peculiar Eolian Sandstone-Hosted Uranium Deposit in the Southwest of Ordos Basin. Ore Geology Reviews, 141: 104571. https://doi.org/10.1016/j.oregeorev.2021.104571 Sun, S. S., Mcdonough, W. F., 1989. Chemical and Isotopic Systematics of Oceanic Basalts: Implications for Mantle Composition and Processes. Geological Society, London, Special Publications, 42(1): 313-345. doi: 10.1144/GSL.SP.1989.042.01.19 Wan, T. F., 2020. Discussion on the Liupanshan-Helanshan Collision Zone. Geotectonica et Metallogenia, 44(5): 845-851 (in Chinese with English abstract). Wan, Y. L., 2011. Study on Coupling Relationship between Provenance and Diagenesis of Yanchang Formation in the Southern Margin of Ordos Basin (Dissertation). Chengdu University of Technology, Chengdu (in Chinese with English abstract). Wang, G. Z., Liang, C. C., Nie, X. C., et al., 2016. Relation between Jurassic Palaeogeomorphology and Hydrocarbon Accumulation in Zhenjing. Special Oil & Gas Reservoirs, 23(4): 46-50, 153 (in Chinese with English abstract). Wang, M., Luo, J. L., Li, M., et al., 2013. Provenance and Tectonic Setting of Sandstone-Type Uranium Deposit in Dongsheng Area, Ordos Basin: Evidence from U-Pb Age and Hf Isotopes of Detrital Zircons. Acta Petrologica Sinica, 29(8): 2746-2758 (in Chinese with English abstract). Wang, S. D., 2014. Tectonic Uplift History of the Southern Margin of Liupan Mountain. Northwest University, Xi'an (in Chinese with English abstract). Wu, C. H., Sun, M., Li, H. M., et al., 2006. LA-ICP-MS U-Pb Zircon Ages of the Khondalites from the Wulashan and Jining High-Grade Terrain in Northern Margin of the North China Craton: Constraints on Sedimentary Age of the Khondalite. Acta Petrologica Sinica, 22(11): 2639-2654 (in Chinese with English abstract). Xia, X. P., Sun, M., Zhao, G. C., et al., 2006. U-Pb and Hf Isotopic Study of Detrital Zircons from the Wulashan Khondalites: Constraints on the Evolution of the Ordos Terrane, Western Block of the North China Craton. Earth and Planetary Science Letters, 241(3/4): 581-593. https://doi.org/10.1016/j.epsl.2005.11.024 Xu, X. Y., Wang, H. L., Chen, J. L., et al., 2008. Zircon U-Pb Dating and Petrogenesis of Xinglongshan Group Basic Volcanic Rocks at Eastern Segment of Middle Qilian Mts. Acta Petrologica Sinica, 24(4): 827-840 (in Chinese with English abstract). Yan, X. X., 2001. The Analysis of the Sediment Source and Reconstrucation of the Framework of the Depositional Environment in the Mesozoic Ordos Basin. Northwest University, Xi'an (in Chinese with English abstract). Yi, C., Han, X. Z., Li, X. D., et al., 2014. Study on Sandstone Petrologic Feature of the Zhiluo Formation and Its Controls on Uranium Mineralization in Northeastern Ordos Basin. Geological Journal of China Universities, 20(2): 185-197 (in Chinese with English abstract). Yu, R. A., Si, Q. H., Wang, S. B., et al., 2020a. Geochemical Characteristics of Sandstone and U-Pb Geochronology of Clastic Zircons of Zhiluo Formation in Shicaochun Area, Western Margin of Ordos Basin: Implications for Tectonic Setting and Provenance. Geotectonics and Metallogenesis, 44(4): 754-771 (in Chinese with English abstract). Yu, R. A., Zhu, Q., Wen, S. B., et al., 2020b. Tectonic Setting and Provenance Analysis of Zhiluo Formation Sandstone of Tarangaole Area in the Ordos Basin. Earth Science, 45(3): 829-843 (in Chinese with English abstract). Yu, R. G., Wang, S. B., Zhu, Q., et al., 2021. Zircon U-Pb Ages and Provenance Characteristics of the Zhiluo Formation Sandstones and the Formation Background of the Uranium Deposit in Huangling Area, Ordos Basin, China. China Geology, 4(4): 600-615. https://doi.org/10.31035/cg2021006 Zeng, Q. D., Liu, J. M., Xiao, W. J., et al., 2012. Mineralizing Types, Geological Characteristics and Geodynamic Background of Triassic Molybdenum Deposits in the Northern and Southern Margins of North China Craton. Acta Petrologica Sinica, 28(2): 357-371 (in Chinese with English abstract). Zhang, T. F., Cheng, X. Y., Wang, S. Y., et al., 2022. Middle Jurassic-Early Cretaceous Drastic Paleoenvironmental Changes in the Ordos Basin: Constraints on Sandstone-Type Uranium Mineralization. Ore Geology Reviews, 142: 104652. https://doi.org/10.1016/j.oregeorev.2021.104652 Zhao, H. G., Liu, C. Y., 2003. Approaches and Prospects of Provenance Analysis. Acta Sedimentologica Sinica, 21(3): 409-415 (in Chinese with English abstract). Zhao, H. L., Zang, Y. L., Li, J. G., et al., 2022. Preliminary Study on the Occurrence State of Uranium in the Lower Cretaceous Luohe Formation of Pengyang Uranium Deposit, Southwestern Ordos Basin. North China Geology, 45(4): 21-27 (in Chinese with English abstract). Zhao, J. F., Liu, C. Y., Zhao, J. S., et al., 2008. Sedimentary Facies and Its Evolution of Jurassic Zhiluo Formation in Ordos Basin. Journal of Northwest University (Natural Science Edition), 38(3): 480-486 (in Chinese with English abstract). Zhou, X., Zhang, Y., Yue, X. Y., 2014. Geochemical Characteristics and Its Tectonic Setting of Nanyinger Formation from Qilian Orogenic Belt. Xinjiang Geology, 32(2): 244-249 (in Chinese with English abstract). Zhu, Q., Si, Q. H., Li, J. G., et al., 2022. Two Genesis of Gray Sandstone and Their Uranium-Bearing Analysis of Lower Cretaceous Luohe Formation in Southwestern Ordos Basin. Earth Science (in Chinese with English abstract). 陈隽璐, 何世平, 王洪亮, 等, 2006. 秦岭祁连造山带接合部位基性岩墙的LA-ICP-MS锆石U-Pb年龄及地质意义. 岩石矿物学杂志, 25(6): 455-462. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW200606001.htm 陈隽璐, 李好斌, 王洪亮, 等, 2007. 秦祁结合部位王家岔石英闪长岩体锆石LA-ICPMS定年及地质意义. 吉林大学学报(地球科学版), 37(3): 423-431. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200703001.htm 段吉业, 刘鹏举, 夏德馨, 2002. 浅析华北板块中元古代‒古生代构造格局及其演化. 现代地质, 16(4): 331-338. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ200204000.htm 范宏瑞, 胡芳芳, 杨奎锋, 等, 2009. 内蒙古白云鄂博地区晚古生代闪长质‒花岗质岩石年代学框架及其地质意义. 岩石学报, 25(11): 2933-2938. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200911024.htm 耿元生, 王新社, 沈其韩, 等, 2007. 内蒙古阿拉善地区前寒武纪变质岩系形成时代的初步研究. 中国地质, 34(2): 251-261. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200702006.htm 耿元生, 周喜文, 2010. 阿拉善地区新元古代岩浆事件及其地质意义. 岩石矿物学杂志, 29(6): 779-795. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW201006014.htm 耿元生, 周喜文, 王新社, 等, 2009. 内蒙古贺兰山地区古元古代晚期的花岗岩浆事件及其地质意义: 同位素年代学的证据. 岩石学报, 25(8): 1830-1842. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB202401016.htm 宫江华, 张建新, 于胜尧, 2013. 阿拉善地块南缘龙首山东段"龙首山岩群" 的再厘定: 来自碎屑锆石U-Pb定年的证据. 岩石矿物学杂志, 32(1): 1-22. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW201301002.htm 郭佩, 刘池洋, 韩鹏, 等, 2017. 鄂尔多斯盆地西南缘下‒中侏罗统碎屑锆石U-Pb年代学及其地质意义. 大地构造与成矿学, 41(5): 892-907. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK201705008.htm 贺锋, 许立权, 苏宏伟, 等, 2004. 内蒙古西部甜水井地区中二叠世A型花岗岩. 西北地质, 37(3): 7-14. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDI200403002.htm 黄志刚, 2016. 吕梁山脉中北段中‒新生代降升演化的裂变径迹约束(博士学位论文). 太原: 太原理工大学. 焦养泉, 吴立群, 彭云彪, 等, 2015. 中国北方古亚洲构造域中沉积型铀矿形成发育的沉积‒构造背景综合分析. 地学前缘, 22(1): 189-205. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201501018.htm 焦养泉, 吴立群, 荣辉, 等, 2022. 沉积、成岩与铀成矿: 中国砂岩型铀矿研究的创新发现与认知挑战. 地球科学, 47(10): 3580-3603. doi: 10.3799/dqkx.2022.284?viewType=HTML 金若时, 滕雪明, 2022. 中国北方砂岩型铀矿大规模成矿作用. 华北地质, 45(1): 42-57. https://www.cnki.com.cn/Article/CJFDTOTAL-QHWJ202201003.htm 李锦轶, 张进, 曲军峰, 2012. 华北与阿拉善两个古陆在早古生代晚期拼合: 来自宁夏牛首山沉积岩系的证据. 地质论评, 58(2): 208-214. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201202005.htm 李克永, 李文厚, 刘哲, 等, 2016. 宁夏六盘山盆地早白垩世六盘山群原型盆地特征. 地质通报, 35(S1): 383-389. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2016Z1022.htm 柳长峰, 2010. 内蒙古四子王旗地区古生代‒早中生代岩浆岩带及其构造意义(博士学位论文). 北京: 中国地质大学. 刘池洋, 王建强, 张东东, 等, 2021. 鄂尔多斯盆地油气资源丰富的成因与赋存‒成藏特点. 石油与天然气地质, 42(5): 1011-1029. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202105002.htm 刘绍平, 刘学锋, 2002. 巴彦浩特盆地的构造类型. 西南石油学院学报, 24(3): 24-27, 4. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY200203006.htm 苗培森, 陈印, 程银行, 等, 2020. 中国北方砂岩型铀矿深部探测新发现及其意义. 大地构造与成矿学, 44(4): 563-575. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK202004002.htm 裴先治, 李佐臣, 李瑞保, 等, 2012. 祁连造山带东段早古生代葫芦河群变质碎屑岩中碎屑锆石LA-ICP-MSU-Pb年龄: 源区特征和沉积时代的限定. 地学前缘, 19(5): 205-224. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201205022.htm 万天丰, 2020. 论六盘山‒贺兰山碰撞带. 大地构造与成矿学, 5(4): 845-851. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK202005004.htm 万友利, 2011. 鄂尔多斯盆地南缘延长组物源与成岩耦合关系研究(硕士学位论文). 成都: 成都理工大学. 王国壮, 梁承春, 聂小创, 等, 2016. 镇泾地区侏罗纪古地貌与延安组成藏关系. 特种油气藏, 23(4): 46-50, 153. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201604010.htm 王盟, 罗静兰, 李杪, 等, 2013. 鄂尔多斯盆地东胜地区砂岩型铀矿源区及其构造背景分析: 来自碎屑锆石U-Pb年龄及Hf同位素的证据. 岩石学报, 29(8): 2746-2758. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB202308012.htm 王师迪, 2014. 六盘山西南缘构造隆升史(硕士学位论文). 西安: 西北大学. 吴昌华, 孙敏, 李惠民, 等, 2006. 乌拉山‒集宁孔兹岩锆石激光探针等离子质谱(LA-ICP-MS)年龄: 孔兹岩沉积时限的年代学研究. 岩石学报, 22(11): 2639-2654. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200611002.htm 徐学义, 王洪亮, 陈隽璐, 等, 2008. 中祁连东段兴隆山群基性火山岩锆石U-Pb定年及岩石成因研究. 岩石学报, 24(4): 827-840. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200804023.htm 闫小雄, 2001. 鄂尔多斯中生代盆地古物源分析与沉积环境格局恢复(硕士学位论文). 西安: 西北大学. 易超, 韩效忠, 李西得, 等, 2014. 鄂尔多斯盆地东北部直罗组砂岩岩石学特征与铀矿化关系研究. 高校地质学报, 20(2): 185-197. https://www.cnki.com.cn/Article/CJFDTOTAL-GXDX201402003.htm 俞礽安, 司庆红, 王善博, 等, 2020a. 鄂尔多斯盆地西缘石槽村地区直罗组砂岩地球化学特征和碎屑锆石U-Pb年代学特征: 对构造背景及物源的启示. 大地构造与成矿学, 44(4): 754-771. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK202004016.htm 俞礽安, 朱强, 文思博, 等, 2020b. 鄂尔多斯盆地塔然高勒地区直罗组砂岩源区构造背景与物源分析. 地球科学, 45(3): 829-843. doi: 10.3799/dqkx.2020.001?viewType=HTML 曾庆栋, 刘建明, 肖文交, 等, 2012. 华北克拉通南北缘三叠纪钼矿化类型、特征及地球动力学背景. 岩石学报, 28(2): 357-371. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201202002.htm 赵红格, 刘池洋, 2003. 物源分析方法及研究进展. 沉积学报, 21(3): 409-415. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200303006.htm 赵华雷, 臧永亮, 李建国, 等, 2022. 鄂尔多斯盆地西南部彭阳铀矿床下白垩统洛河组铀的赋存状态初探. 华北地质, 45(4): 21-27. https://www.cnki.com.cn/Article/CJFDTOTAL-QHWJ202204003.htm 赵俊峰, 刘池洋, 赵建设, 等, 2008. 鄂尔多斯盆地侏罗系直罗组沉积相及其演化. 西北大学学报(自然科学版), 38(3): 480-486. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ200803032.htm 周雄, 张贻, 岳相元, 2014. 祁连造山带上三叠统南营儿组地球化学特征及构造背景分析. 新疆地质, 32(2): 244-249. https://www.cnki.com.cn/Article/CJFDTOTAL-XJDI201402022.htm 朱强, 司庆红, 李建国, 等, 2022. 鄂尔多斯盆地西南部下白垩统洛河组灰色砂岩的两种成因及其含铀性. 地球科学, 1-27. doi: 10.3799/dqkx.2022.012?viewType=HTML -
