Development Characteristics and Controlling Factors of Natural Fractures in Chang 7 Shale Oil Reservoir, Longdong Area, Ordos Basin
-
摘要: 鄂尔多斯盆地陇东地区长7页岩油储层天然裂缝类型多样，裂缝是影响页岩油富集和产能的关键因素.为了指导该地区的勘探开发，综合利用野外露头、岩心、薄片、成像测井等资料，分析天然裂缝的成因类型和发育特征.研究区的天然裂缝按照成因可分为构造裂缝、成岩裂缝和异常高压裂缝三大类，其中构造裂缝主要包括高角度剪切裂缝、低角度剪切裂缝和张裂缝；成岩裂缝以层理缝为主，发育少量缝合线；异常高压裂缝发育较少.在此基础上进一步研究影响裂缝发育的控制因素，研究表明构造裂缝主要受到岩性、岩石力学层厚度和构造应力场的控制，层理缝的发育程度与有机碳含量和纹层有关，异常高压裂缝主要受异常高压的影响.Abstract: There are various types of natural fractures in Chang 7 shale oil reservoir in Longdong area, Ordos Basin, which are the key factors affecting shale oil enrichment and productivity. In order to guide the exploration and development of this area, the genetic types and development characteristics of natural fractures were analyzed by comprehensively utilizing various data of outcrops, cores, thin sections and imaging logging. Natural fractures in the study area can be divided into three types according to their origin, including tectonic fractures, diagenetic fractures and abnormal high pressure fractures. The tectonic fractures mainly include high-angle shear fractures, low-angle shear fractures and tensile fractures. Diagenetic fractures are mainly bedding fractures with a few sutures. Abnormal high pressure fractures are less developed. On this basis, the controlling factors affecting fracture development are further studied. The results show that tectonic fractures are mainly controlled by lithology, rock mechanical layer thickness and tectonic stress field. The development degree of bedding fractures is related to organic carbon content and lamina, and abnormal high pressure fractures are mainly affected by abnormal high pressure.
-
Key words:
- shale oil /
- natural fracture /
- development characteristic /
- controlling factor /
- Ordos Basin /
- petroleum geology
-
图 1 鄂尔多斯盆地构造区划及延长组综合柱状图
a.据付金华等（2020）修改；b.据冯雪等（2021）修改
Fig. 1. Tectonic division of Ordos Basin and stratigraphic column of Yanchang Formation
图 2 鄂尔多斯盆地长7段野外露头裂缝发育特征
a.构造裂缝与层面垂直或高角度相交；b. 两组构造裂缝，平面上相互切割成棋盘状
Fig. 2. Fracture development characteristics of Chang 7 Member outcrop in Ordos Basin
图 3 鄂尔多斯盆地长7段岩心裂缝发育特征
a. Z40井，直立剪切缝，缝面含油，1 405.8 m；b. Z107井，高角度剪切缝被方解石全充填，1 164.4 m；c. G347井，滑脱裂缝，见镜面和擦痕，2 407.75 m；d. G347井，张裂缝被方解石全充填，2 423.8 m；e. YY1井，层理缝，228.07 m；f. L211井，层理缝面见碳质，2 378.8 m；g. W336井，异常高压缝，1 957.9 m；h. YY1井，缝合线，219.84 m
Fig. 3. Fracture development characteristics of Chang 7 Member core in Ordos Basin
图 4 鄂尔多斯盆地长7段薄片裂缝发育特征
a. L211井，低角度剪切裂缝，2 371.5 m；b. Z8井，两组构造裂缝相互切割，1 277.5 m；c. Z8井，剪切裂缝穿过矿物颗粒，1 279.9 m；d. Z8井，层理缝绕过矿物颗粒，1 124.5 m；e. M53井，层理缝中见油迹，2 370.1 m；f. Z70井，1 659.9 m，异常高压缝早期被充填，后期重新裂开
Fig. 4. Fracture development characteristics of Chang 7 Member thin sections in Ordos Basin
图 5 鄂尔多斯盆地长7段裂缝走向玫瑰花图（N=161）
Fig. 5. Rose diagram of fracture strike in Chang 7 Member of Ordos Basin(N=161)
图 6 鄂尔多斯盆地长7段不同井裂缝倾角和高度频率分布直方图（N=184）
Fig. 6. Histograms of fracture dip angle and height frequency distribution of different wells in Chang 7 Member, Ordos Basin (N=184)
图 7 鄂尔多斯盆地Z40井长7段成像测井裂缝解释图
Fig. 7. Imaging logging fracture interpretation in Chang 7 Member of Well Z40 in Ordos Basin
图 8 鄂尔多斯盆地长7段不同岩性构造裂缝线密度频率分布直方图（N=66）
Fig. 8. Histogram of linear density frequency distribution of structural fractures in different lithologies of Chang 7 Member, Ordos Basin (N=66)
图 9 鄂尔多斯盆地野外露头长7段层内剪切裂缝间距与岩石力学层厚度关系（N=12）
Fig. 9. Relationship between in-layer shear fracture and rock mechanical layer thickness in Chang 7 Member of outcrop in Ordos Basin(N=12)
图 10 鄂尔多斯盆地不同时期构造应力场与裂缝走向关系
Fig. 10. Relationship between tectonic stress field and fracture strike in different periods in Ordos Basin
图 11 鄂尔多斯盆地长73泥岩层理缝线密度与有机碳含量关系（N=16）
Fig. 11. Relationship between bedding fracture linear density and organic carbon content of Chang 73 mudstone in Ordos Basin (N=16)
图 12 鄂尔多斯盆地长7段不同纹层类型
a. G347井，2 425.91 m；b.L211井，2 369.65 m
Fig. 12. Different laminate types in Chang 7 Member of Ordos Basin
-
Dewhurst, D. N., Siggins, A. F., Sarout, J., et al., 2011. Geomechanical and Ultrasonic Characterization of a Norwegian Sea Shale. Geophysics, 76(3): WA101-WA111. https://doi.org/10.1190/1.3569599 Ding, W. L., Wang, X. H., Hu, Q. J., et al., 2015. Progress in Tight Sandstone Reservoir Fractures Research. Advances in Earth Science, 30(7): 737-750 (in Chinese with English abstract). Feng, X., Gao, S. L., Liu, Y. T., et al., 2021. Characteristics of Delta Front Progradation Structure of Yanchang Formation in Longdong Area, Ordos Basin. Lithologic Reservoirs, 33(6): 48-58 (in Chinese with English abstract). Feng, Y. W., Chen, Y., Zhao, Z. Y., et al., 2021. Migration of Natural Gas Controlled by Faults of Majiagou Formation in Central Ordos Basin: Evidence from Fluid Inclusions. Earth Science, 46(10): 3601-3614 (in Chinese with English abstract). doi: 10.1007/s12182-020-00522-1?utm_source=TrendMD Fu, J. H., Li, S. X., Niu, X. B., et al., 2020. Geological Characteristics and Exploration of Shale Oil in Chang 7 Member of Triassic Yanchang Formation, Ordos Basin, NW China. Petroleum Exploration and Development, 47(5): 870-883 (in Chinese with English abstract). Fu, S. T., Jin, Z. J., Fu, J. H., et al., 2021. Transformation of Understanding from Tight Oil to Shale Oil in the Member 7 of Yanchang Formation in Ordos Basin and Its Significance of Exploration and Development. Acta Petrolei Sinica, 42(5): 561-569 (in Chinese with English abstract). Gong, L., Fu, X. F., Wang, Z. S., et al., 2019. A New Approach for Characterization and Prediction of Natural Fracture Occurrence in Tight Oil Sandstones with Intense Anisotropy. AAPG Bulletin, 103(6): 1383-1400. https://doi. org/10.1306/12131818054 doi: 10.1306/12131818054 He, Z. J., Liu, B. J., Wang, P., 2011. Genesis of Bedding Fractures and Its Influences on Reservoirs in Jurassic, Yongjin Area, Junggar Basin. Petroleum Geology and Recovery Efficiency, 18(1): 15-17, 112 (in Chinese with English abstract). Jin, Z. J., Bai, Z. R., Gao, B., et al., 2019. Has China Ushered in the Shale Oil and Gas Revolution? Oil & Gas Geology, 40(3): 451-458 (in Chinese with English abstract). Jin, Z. J., Zhu, R. K., Liang, X. P., et al., 2021. Several Issues Worthy of Attention in Current Lacustrine Shale Oil Exploration and Development. Petroleum Exploration and Development, 48(6): 1276-1287 (in Chinese with English abstract). Jiu, B., Huang, W. H., Wang, Y. T., et al., 2018. Effect of Coal-Measure Tight Sandstone Cementation on Reservoir Physical Property in the South of Ordos Basin. Journal of China Coal Society, 43(9): 2543-2552 (in Chinese with English abstract). Jiu, K., Ding, W. L., Huang, W. H., et al., 2013. Fractures of Lacustrine Shale Reservoirs, the Zhanhua Depression in the Bohai Bay Basin, Eastern China. Marine and Petroleum Geology, 48: 113-123. https://doi.org/10.1016/j.marpetgeo.2013.08.009 Ju, W., Niu, X. B., Feng, S. B., et al., 2020. The Present-Day In-Situ Stress State and Fracture Effectiveness Evaluation in Shale Oil Reservoir: A Case Study of the Yanchang Formation Chang 7 Oil-Bearing Layer in the Ordos Basin. Journal of China University of Mining & Technology, 49(5): 931-940 (in Chinese with English abstract). Li, C. H., Zhao, L., Liu, B., et al., 2021. Research Status and Development Trend of Fractures in Carbonate Reservoir. Bulletin of Geological Science and Technology, 40(4): 31-48 (in Chinese with English abstract). Li, C. S., Zhang, W. X., Lei, Y., et al., 2021. Characteristics and Controlling Factors of Oil Accumulation in Chang 9 Member in Longdong Area, Ordos Basin. Earth Science, 46(10): 3560-3574 (in Chinese with English abstract). Li, M. W., Jin, Z. J., Dong, M. Z., et al., 2020. Advances in the Basic Study of Lacustrine Shale Evolution and Shale Oil Accumulation. Petroleum Geology & Experiment, 42(4): 489-505 (in Chinese with English abstract). Li, Y. L., Lu, S. L., Xia, D. L., et al., 2022. Development Characteristics and Main Controlling Factors of Natural Fractures in Shale Series of the Seventh Member of the Yanchang Formation, Southern Ordos Basin. Chinese Journal of Geology (Scientia Geologica Sinica), 57(1): 73-87 (in Chinese with English abstract). Liu, D. D., Zhang, C., Luo, Q., et al., 2017. Development Characteristics and Controlling Factors of Natural Fractures in Permian Lucaogou Formation Tight Reservoir in Jimsar Sag, Junggar Basin. China Petroleum Exploration, 22(4): 36-47 (in Chinese with English abstract). doi: 10.3969/j.issn.1672-7703.2017.04.004 Liu, G. P., Zeng, L. B., Sun, G. Q., et al., 2020. Natural Fractures in Tight Gas Volcanic Reservoirs and Their Influences on Production in the Xujiaweizi Depression, Songliao Basin, China. AAPG Bulletin, 104(10): 2099-2123. https://doi.org/10.1306/05122017169 Liu, G. P., Zeng, L. B., Zhu, R. K., et al., 2021. Effective Fractures and Their Contribution to the Reservoirs in Deep Tight Sandstones in the Kuqa Depression, Tarim Basin, China. Marine and Petroleum Geology, 124: 104824. https://doi.org/10.1016/j.marpetgeo.2020.104824 Liu, H. L., Qiu, Z., Xu, L. M., et al., 2021. Distribution of Shallow Water Delta Sand Bodies and the Genesis of Thick Layer Sand Bodies of the Triassic Yanchang Formation, Longdong Area, Ordos Basin. Petroleum Exploration and Development, 48(1): 106-117 (in Chinese with English abstract). Liu, Q. Y., Li, P., Jin, Z. J., et al., 2022. Organic-Rich Formation and Hydrocarbon Enrichment of Lacustrine Shale Strata: A Case Study of Chang 7 Member. Scientia Sinica Terrae, 52(2): 270-290 (in Chinese). doi: 10.1360/SSTe-2021-0081 Luo, Q., Wei, H. Y., Liu, D. D., et al., 2017. Research Significance, Advances and Trends on the Role of Bedding Fracture in Tight Oil Accumulation. Petroleum Geology & Experiment, 39(1): 1-7 (in Chinese with English abstract). Lü, W. Y., Zeng, L. B., Chen, S. Q., et al., 2021. Characterization Methods of Multi-Scale Natural Fractures in Tight and Low-Permeability Sandstone Reservoirs. Geological Review, 67(2): 543-556 (in Chinese with English abstract). Lü, W. Y., Zeng, L. B., Zhou, S. B., et al., 2020. Microfracture Characteristics and Its Controlling Factors in the Tight Oil Sandstones in the Southwest Ordos Basin: Case Study of the Eighth Member of the Yanchang Formation in Honghe Oilfield. Natural Gas Geoscience, 31(1): 37-46 (in Chinese with English abstract). Tian, H., Zeng, L. B., Xu, X., et al., 2020. Characteristics of Natural Fractures in Marine Shale in Fuling Area, Sichuan Basin, and Their Influence on Shale Gas. Oil & Gas Geology, 41(3): 474-483 (in Chinese with English abstract). Wang, R. Y., Ding, W. L., Gong, D. J., et al., 2016. Development Characteristics and Major Controlling Factors of Shale Fractures in the Lower Cambrian Niutitang Formation, Southeastern Chongqing-Northern Guizhou Area. Acta Petrolei Sinica, 37(7): 832-845, 877 (in Chinese with English abstract). Wang, X. H., Wang, R. Y., Ding, W. L., et al., 2017. Development Characteristics and Dominant Factors of Fractures and Their Significance for Shale Reservoirs: A Case Study from ∈1b2 in the Cen'gong Block, Southern China. Journal of Petroleum Science and Engineering, 159: 988-999. https://doi.org/10.1016/j.petrol.2017.08.007 Xu, C., Shan, Y. F., Zhang, Z. H., et al., 2015. Behavior of Propagating Fracture at Bedding Interface in Layered Rocks. Engineering Geology, 197: 33-41. https://doi.org/10.1016/j.enggeo.2015.08.010 Yang, L., Jin, Z. J., 2019. Global Shale Oil Development and Prospects. China Petroleum Exploration, 24(5): 553-559 (in Chinese with English abstract). Zeng, L. B., Gao, C. Y., Qi, J. F., et al., 2008. The Distribution Rule and Seepage Effect of the Fractures in the Ultra-Low Permeability Sandstone Reservoir in East Gansu Province, Ordos Basin.Scientia Sinica Terrae, (S1): 41-47 (in Chinese). Zeng, L. B., Li, X. Y., 2009. Fractures in Sandstone Reservoirs with Ultra-Low Permeability: A Case Study of the Upper Triassic Yanchang Formation in the Ordos Basin, China. AAPG Bulletin, 93(4): 461-477. https://doi.org/10.1306/09240808047 Zeng, L. B., Lü, P., Qu, X. F., et al., 2020. Multi-Scale Fractures in Tight Sandstone Reservoirs with Low Permeability and Geological Conditions of Their Development. Oil & Gas Geology, 41(3): 449-454 (in Chinese with English abstract). Zeng, L. B., Lü, W. Y., Li, J., et al., 2016. Natural Fractures and Their Influence on Shale Gas Enrichment in Sichuan Basin, China. Journal of Natural Gas Science and Engineering, 30: 1-9. https://doi.org/10.1016/j.jngse.2015.11.048 Zeng, L. B., Lü, W. Y., Xu, X., et al., 2022. Development Characteristics, Formation Mechanism and Hydrocarbon Significance of Bedding Fractures in Typical Tight Sandstone and Shale. Acta Petrolei Sinica, 43(2): 180-191 (in Chinese with English abstract). Zeng, L. B., Qi, J. F., Wang, Y. X., 2007. Origin Type of Tectonic Fractures and Geological Conditions in Low-Permeability Reservoirs. Acta Petrolei Sinica, 28(4): 52-56 (in Chinese with English abstract). Zeng, L. B., Su, H., Tang, X. M., et al., 2013. Fractured Tight Sandstone Oil and Gas Reservoirs: A New Play Type in the Dongpu Depression, Bohai Bay Basin, China. AAPG Bulletin, 97(3): 363-377. https://doi.org/10.1306/09121212057 Zeng, L. B., Xiao, S. R., 1999. Fractures in the Mudstone of Tight Reservoirs. Petroleum Geology & Experiment, 21(3): 266-269 (in Chinese with English abstract). doi: 10.3969/j.issn.1001-6112.1999.03.015 Zhang, X. M., Shi, W. Z., Hu, Q. H., et al., 2020. Developmental Characteristics and Controlling Factors of Natural Fractures in the Lower Paleozoic Marine Shales of the Upper Yangtze Platform, Southern China. Journal of Natural Gas Science and Engineering, 76: 103191. https://doi.org/10.1016/j.jngse.2020.103191 Zhang, Y. Y., He, Z. L., Jiang, S., et al., 2019. Fracture Types in the Lower Cambrian Shale and Their Effect on Shale Gas Accumulation, Upper Yangtze. Marine and Petroleum Geology, 99: 282-291. https://doi.org/10.1016/j.marpetgeo.2018.10.030 Zhang, Y. Z., Zeng, L. B., Luo, Q., et al., 2018. Research on the Types and Genetic Mechanisms of Tight Reservoir in the Lucaogou Formation in Jimusar Sag, Junggar Basin. Natural Gas Geoscience, 29(2): 211-225 (in Chinese with English abstract). 丁文龙, 王兴华, 胡秋嘉, 等, 2015. 致密砂岩储层裂缝研究进展. 地球科学进展, 30(7): 737-750. https://www.cnki.com.cn/Article/CJFDTOTAL-DXJZ201507001.htm 冯雪, 高胜利, 刘永涛, 等, 2021. 鄂尔多斯盆地陇东地区延长组三角洲前缘前积结构特征. 岩性油气藏, 33(6): 48-58. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX202106006.htm 冯艳伟, 陈勇, 赵振宇, 等, 2021. 鄂尔多斯盆地中部地区马家沟组断裂控制天然气运移方向的流体包裹体证据. 地球科学, 46(10): 3601-3614. doi: 10.3799/dqkx.2020.384 付金华, 李士祥, 牛小兵, 等, 2020. 鄂尔多斯盆地三叠系长7段页岩油地质特征与勘探实践. 石油勘探与开发, 47(5): 870-883. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202005005.htm 付锁堂, 金之钧, 付金华, 等, 2021. 鄂尔多斯盆地延长组7段从致密油到页岩油认识的转变及勘探开发意义. 石油学报, 42(5): 561-569. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202105001.htm 贺振建, 刘宝军, 王朴, 2011. 准噶尔盆地永进地区侏罗系层理缝成因及其对储层的影响. 油气地质与采收率, 18(1): 15-17, 112. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201101004.htm 金之钧, 白振瑞, 高波, 等, 2019. 中国迎来页岩油气革命了吗? 石油与天然气地质, 40(3): 451-458. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201903002.htm 金之钧, 朱如凯, 梁新平, 等, 2021. 当前陆相页岩油勘探开发值得关注的几个问题. 石油勘探与开发, 48(6): 1276-1287. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202106021.htm 久博, 黄文辉, 王雅婷, 等, 2018. 鄂尔多斯盆地南部煤系致密砂岩胶结作用对储层物性的影响. 煤炭学报, 43(9): 2543-2552. https://www.cnki.com.cn/Article/CJFDTOTAL-MTXB201809022.htm 鞠玮, 牛小兵, 冯胜斌, 等, 2020. 页岩油储层现今地应力场与裂缝有效性评价——以鄂尔多斯盆地延长组长7油层组为例. 中国矿业大学学报, 49(5): 931-940. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKD202005013.htm 李长海, 赵伦, 刘波, 等, 2021. 碳酸盐岩裂缝研究进展及发展趋势. 地质科技通报, 40(4): 31-48. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ202104004.htm 李程善, 张文选, 雷宇, 等, 2021. 鄂尔多斯盆地陇东地区长9油层组砂体成因与油气差异分布. 地球科学, 46(10): 3560-3574. doi: 10.3799/dqkx.2021.007 黎茂稳, 金之钧, 董明哲, 等, 2020. 陆相页岩形成演化与页岩油富集机理研究进展. 石油实验地质, 42(4): 489-505. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD202004004.htm 李彦录, 陆诗磊, 夏东领, 等, 2022. 鄂尔多斯盆地南部延长组长7油组页岩层系天然裂缝发育特征及主控因素. 地质科学, 57(1): 73-87. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX202201004.htm 刘冬冬, 张晨, 罗群, 等, 2017. 准噶尔盆地吉木萨尔凹陷芦草沟组致密储层裂缝发育特征及控制因素. 中国石油勘探, 22(4): 36-47. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201704004.htm 刘翰林, 邱振, 徐黎明, 等, 2021. 鄂尔多斯盆地陇东地区三叠系延长组浅水三角洲砂体特征及厚层砂体成因. 石油勘探与开发, 48(1): 106-117. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202101011.htm 刘全有, 李鹏, 金之钧, 等, 2022. 湖相泥页岩层系富有机质形成与烃类富集——以长7为例. 中国科学: 地球科学, 52(2): 270-290. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK202202006.htm 罗群, 魏浩元, 刘冬冬, 等, 2017. 层理缝在致密油成藏富集中的意义、研究进展及其趋势. 石油实验地质, 39(1): 1-7. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD201701002.htm 吕文雅, 曾联波, 陈双全, 等, 2021. 致密低渗透砂岩储层多尺度天然裂缝表征方法. 地质论评, 67(2): 543-556. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP202102024.htm 吕文雅, 曾联波, 周思宾, 等, 2020. 鄂尔多斯盆地西南部致密砂岩储层微观裂缝特征及控制因素——以红河油田长8储层为例. 天然气地球科学, 31(1): 37-46. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX202001004.htm 田鹤, 曾联波, 徐翔, 等, 2020. 四川盆地涪陵地区海相页岩天然裂缝特征及对页岩气的影响. 石油与天然气地质, 41(3): 474-483. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202003005.htm 王濡岳, 丁文龙, 龚大建, 等, 2016. 渝东南‒黔北地区下寒武统牛蹄塘组页岩裂缝发育特征与主控因素. 石油学报, 37(7): 832-845, 877. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201607002.htm 杨雷, 金之钧, 2019. 全球页岩油发展及展望. 中国石油勘探, 24(5): 553-559. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201905002.htm 曾联波, 高春宇, 漆家福, 等, 2008. 鄂尔多斯盆地陇东地区特低渗透砂岩储层裂缝分布规律及其渗流作用. 中国科学: 地球科学, (S1): 41-47. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1005.htm 曾联波, 吕鹏, 屈雪峰, 等, 2020. 致密低渗透储层多尺度裂缝及其形成地质条件. 石油与天然气地质, 41(3): 449-454. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202003002.htm 曾联波, 吕文雅, 徐翔, 等, 2022. 典型致密砂岩与页岩层理缝的发育特征、形成机理及油气意义. 石油学报, 43(2): 180-191. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202202002.htm 曾联波, 漆家福, 王永秀, 2007. 低渗透储层构造裂缝的成因类型及其形成地质条件. 石油学报, 28(4): 52-56. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200704009.htm 曾联波, 肖淑蓉, 1999. 低渗透储集层中的泥岩裂缝储集体. 石油实验地质, 21(3): 266-269. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD199903014.htm 张云钊, 曾联波, 罗群, 等, 2018. 准噶尔盆地吉木萨尔凹陷芦草沟组致密储层裂缝特征和成因机制. 天然气地球科学, 29(2): 211-225. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201802007.htm -
