Enhanced Formation Conditions of the Large-Scale Volcanic Reservoir in the BZ8-3S Large Volcanic Structure in Bozhong Sag, Bohai Bay Basin
-
摘要: 为解决如何在渤海湾盆地渤中凹陷中生界寻找规模型火山岩油气藏的难题，以BZ8-3S大型火山圈闭及该构造钻探的BZ8-3S-A高产火山岩探井为研究对象，详细研究了该构造火山岩岩性、岩相和储层特征，探讨了近烃源岩大型火山圈闭规模型火山岩储层的发育条件，并建立了储层发育模式. 研究表明，BZ8-3S构造由多个大中型酸性熔岩火山机构叠置构成，主要发育大套喷溢相上部亚相气孔流纹岩、下部亚相块状流纹岩、火山通道相隐爆角砾岩亚相流纹质隐爆角砾岩3种岩性岩相，形成高孔-低渗、中孔-低渗和低孔-低渗3种类型火山岩储层. 多喷发中心、富喷溢相上部亚相和火山通道相隐爆角砾岩亚相的大中型酸性熔岩火山机构是形成规模型火山岩储层的基础；风化作用促进了喷溢相上部亚相和隐爆角砾岩亚相溶蚀孔-缝的形成，改善了储层物性，是风化壳内有利储层形成的关键；构造作用改造喷溢相下部亚相块状熔岩，形成风化壳下部母岩中裂缝和溶蚀孔隙发育带，构成了风化壳-内幕双层储层结构. 以BZ8-3S为原型，建立了“以大中型多中心酸性熔岩火山机构及其发育的有利岩性、岩相为基础，风化和构造改造双控”的大型火山圈闭规模型储层发育模式.Abstract: In order to solve the problem of finding large-scale volcanic reservoirs in the Mesozoic of Bozhong Depression, Bohai Bay Basin, this paper takes BZ8-3S large volcanic trap and BZ8-3S-A high-yield volcanic exploration well drilled in this structure as the research object, and studies the lithology, lithofacies and reservoir characteristics of volcanic rocks in this structure in detail. The development conditions of the large volcanic trap model reservoir close to the source rock are discussed and the development model of the reservoir is established. The results show that the BZ8-3S structure is composed of several large and medium-sized acid lava volcanic structures and mainly develops three lithological lithofacies, namely porous rhyolite of the upper subfacies of the intermediate effusive facies, massive rhyolite of the lower subfacies and the crypto-explosive breccia subfacies of the volcanic vent facies, forming three types of volcanic reservoirs: high porosity and low permeability, medium porosity and low porosity and low permeability. The medium and large acid lavas with multiple eruption centres, rich upper subfacies of the effusive facies, as well as the upper subfacies of the effusive facies and the crypto-explosive breccia subfacies developed near the source facies of the volcanic mechanism are the basis for the formation of regular model volcanic rock reservoirs. Weathering promoted the formation of pores and fractures in the upper subfacies of the intermediate effusive facies and the crypto-explosive breccia subfacies, improved reservoir physical properties and was key to the formation of favourable reservoirs in the weathered crust. Tectonism transformed the massive lava of the lower subfacies of the effusive facies and formed the fracture and dissolution pore development zone in the parent rock of the lower part of the weathered crust, which formed the weathered crust-internal two-layer reservoir structure. Based on BZ8-3S, the reservoir development model of large-scale volcanic structure is established, which is based on the favourable lithology and lithofacies of large acid lava volcanic institutions and is controlled by weathering and tectonic transformation.
-
图 1 渤海湾盆地海域油区构造纲要和潜山地层综合柱状图
据Ye et al.（2021）加入中生界圈闭勘探成果修改；a. 渤海湾盆地海域油区构造纲要和中生界火山岩圈闭分布图；b. 渤中凹陷基底潜山地层综合柱状图
Fig. 1. Structural outline and comprehensive columnar diagram of buried hill strata in the Bohai Bay Basin
图 2 渤中凹陷中生界火山岩岩性、岩相分布图
Fig. 2. Lithology and distribution of lithofacies in Mesozoic volcanic rocks within the Bozhong Sag
图 3 BZ8-3S-A井火山岩岩性、岩相综合柱状图
Fig. 3. Comprehensive columnar diagram depicting lithology and lithofacies of volcanic rocks in well BZ8-3S-A
图 5 BZ8-3S-A井火山岩岩性特征
a. 4 938.5 m气孔流纹岩铸体薄片照片，单偏光；b. 5 064.0 m块状流纹岩铸体薄片照片，正交偏光；c.5 064.0 m块状流纹岩壁心照片；d. 5 001.0 m隐爆角砾岩壁心照片；e. 5 001.0 m隐爆角砾岩铸体薄片照片，正交偏光；f. 5 005.7 m火山角砾熔岩壁心照片；g. 4 993.7 m断层角砾岩壁心照片；h. 4 993.7 m断层角砾岩铸体薄片照片，单偏光
Fig. 5. Lithological characteristics of volcanic rocks in BZ8-3S-A well
图 6 BZ8-3S大型火山构造火山机构构成
a. BZ8-3S大型构造火山机构分布剖面图；b. BZ8-3S大型构造火山机构分布平面图
Fig. 6. Volcanic edifices of BZ8-3S represent a significant large-scale volcanic structure
图 7 BZ8-3S大型火山构造火山机构地质模型
Fig. 7. Geological model and volcanic mechanism of the BZ8-3S large volcanic structure
图 8 BZ8-3S-A井中生界火山岩孔隙度-渗透率交会图
Fig. 8. Crossplot analysis of porosity and permeability in the BZ8-3S-A well for Mesozoic volcanic rocks
图 9 BZ8-3S-A井火山岩储集空间类型和特征
a. 原生气孔和杏仁体内孔，4 945 m气孔流纹岩铸体薄片照片，单偏光；b. 基质溶蚀孔，4 945 m气孔流纹岩铸体薄片照片，单偏光；c. 晶内溶蚀孔，4 968 m块状流纹岩铸体薄片照片，单偏光；d.隐爆岩汁溶孔，5 006 m隐爆角砾岩铸体薄片照片，单偏光；e.脱玻化孔，4 968 m块状流纹岩扫描电镜照片，单偏光；f.隐爆岩汁脱玻化孔，4 941 m隐爆角砾岩铸体薄片照片，单偏光；g. 溶蚀扩大缝，4 937 m块状流纹岩铸体薄片照片，单偏光；h. 溶蚀缝，4 960 m块状流纹岩铸体薄片照片，单偏光；i. 隐爆缝，5 010 m隐爆角砾岩铸体薄片，单偏光；j. 网状构造缝，近断裂破碎带，5 094 m块状流纹岩铸体薄片照片，单偏光；k. 构造角砾溶孔，4 994 m构造角砾岩铸体薄片照片，单偏光；l. 充填裂缝，5 064 m块状流纹岩铸体薄片照片，单偏光
Fig. 9. Types and characteristics of reservoir space in the BZ8-3S-A well composed of volcanic rocks
图 10 BZ8-3S-A井不同类型储层的储集空间占比
Fig. 10. The proportion of reservoir space in different types of reservoirs within the BZ8-3S-A well
图 11 BZ8-3S-A井风化壳垂向发育模式图
Fig. 11. Vertical development model of weathering crust in well BZ8-3S-A
图 12 BZ8-3S-A井火山岩储层物性、有效储层发育率与火山岩相的关系
a.不同岩相火山岩储层孔隙度特征；b. 不同岩相火山岩有效储层发育率
Fig. 12. Correlation between physical properties of volcanic, effective reservoir development rate, and volcanic facies in well BZ8-3S-A
图 13 BZ8-3S大型火山构造规模型火山储层发育模式
Fig. 13. Development model of a large-scale volcanic reservoir within the extensive volcanic structure BZ8-3S
-
Cao, Y. C., Yuan, G. H., Wang, Y. Z., et al., 2022. Successive Formation of Secondary Pores via Feldspar Dissolution in Deeply Buried Feldspar-Rich Clastic Reservoirs in Typical Petroliferous Basins and Its Petroleum Geological Significance. Science China Earth Sciences, 65(9): 1673-1703. https://doi.org/10.1007/s11430-020-9931-9 Fu, M., Shan, X. L., Zhang, X. T., et al., 2022. Geodynamic Evolution of Lithospheric Removal of the North China Craton: Constraints from Late Mesozoic Volcanic Rocks in the Bohai Bay Basin, East China. Journal of Asian Earth Sciences, 236: 105330. https://doi.org/10.1016/j.jseaes.2022.105330 He, D. F., Cui, Y. Q., Zhang, Y. Y., et al., 2017. Structural Genetic Types of Paleoburied Hill in Jizhong Depression, Bohai Bay Basin. Acta Petrologica Sinica, 33(4): 1338-1356(in Chinese with English abstract). Hou, L. H., Luo, X., Wang, J. H., et al., 2013. Weathered Volcanic Crust and Its Petroleum Geologic Significance: a Case Study of the Carboniferous Volcanic Crust in Northern Xinjiang. Petroleum Exploration and Development, 40(3): 257-265, 274(in Chinese with English abstract). http://www.sciengine.com/doi/pdf/6AAF0C790CA54AC0A0179E2B28AAA9EC Hou, M. C., Cao, H. Y., Li, H. Y., et al., 2019. Characteristics and Controlling Factors of Deep Buried-Hill Reservoirs in the BZ19-6 Structural Belt, Bohai Sea Area. Natural Gas Industry, 39(1): 33-44(in Chinese with English abstract). Jiang, Y. L., Ye, T., Zhang, S. W., et al., 2015. Enrichment Characteristics and Main Controlling Factors of Hydrocarbon in Buried Hill of Bohai Bay Basin. Journal of China University of Petroleum (Edition of Natural Science), 39(3): 20-29(in Chinese with English abstract). doi: 10.3969/j.issn.1673-5005.2015.03.003 Li, H. Y., Niu, C. M., Xu, P., et al., 2021. Discovery of Bozhong 13-2 Archean Large Monoblock Volatile Buried Hill Oilfield and Its Oil and Gas Exploration Significance. Natural Gas Industry, 41(2): 19-26(in Chinese with English abstract). http://www.sciengine.com/doi/pdf/DAA33B0062B64F77BE0A50C279C0F67B Meng, F. C., Cao, Y. C., Cui, Y., et al., 2016. Genesis of Carboniferous Volcanic Reservoirs in Chepaizi Salient in Western Margin of Junggar Basin. Journal of China University of Petroleum (Edition of Natural Science), 40(5): 22-31(in Chinese with English abstract). doi: 10.3969/j.issn.1673-5005.2016.05.003 Shan, X. L., Wang, W., Zhang, X. T., et al., 2023. Geological Model and Construction Process of the Mesozoic Volcanic Edifices in Bozhong Sag, Bohai Sea. Oil & Gas Geology, 44(3): 675-688(in Chinese with English abstract). Schmidt, V., A, M. D., 1979. The Role of Secondary Porosity in the Course of Sandstone Diagenesis, vol. 26. SEPM Special Publication, 175-207. http://archives.datapages.com/data/meta/sepm_sp/SP26/The_Role_of_Secondary_Porosity_firstpage.pdf Shi, H. S., Niu, C. M., Hou, C. M., et al., 2021. Analysis of Hydrocarbon Accumulation Conditions of Double-Layered Archaeozoic Buried Hiland Major Discovery of Bozhong 13-2 Oil and Gasfield, Bohai Sea Area. China Petroleum Exploration, 26(2): 12-20(in Chinese with English abstract). doi: 10.3969/j.issn.1672-7703.2021.02.002 Sun, Y. T., Sun, C., Li, H., et al., 2016. Controlling Factors of Mesozoic Igneous Rock Reservoirs in Zhuangxi Area, Jiyang Depression, Shandong, China. Journal of Chengdu University of Technology (Science & Technology Edition), 43(3): 257-265(in Chinese with English abstract). doi: 10.3969/j.issn.1671-9727.2016.03.01 Tang, H. F., Tian, Z. W., Gao, Y. F., et al., 2022. Review of Volcanic Reservoir Geology in China. Earth-Science Reviews, 232: 104158. https://doi.org/10.1016/j.earscirev.2022.104158 Wang, C. J., Zhang, X. T., Xu, C. Q., et al., 2021. Development Characteristics and Main Controlling Factors of Mesozoic Volcanic Reservoirsin Northern Bozhong Sag. China Offshore Oil and Gas, 33(3): 48-57(in Chinese with English abstract). Wang, D. Y., Wang, Q. B., Liu, X. J., et al., 2019. Characteristics and Developing Patterns of Gneiss Buried Hill Weathering Crust Reservoir in the Sea Area of the Bohai Bay Basin. Acta Petrologica Sinica, 35(4): 1181-1193(in Chinese with English abstract). doi: 10.18654/1000-0569/2019.04.13 Wang, P., Chen, S. M., 2015. Cretaceous Volcanic Reservoirs and Their Exploration in the Songliao Basin, Northeast China. AAPG Bulletin, 99: 499-523. https://doi.org/10.1306/09041413095 Wang, P. J., Wu, H. Y., Pang, Y. M., et al., 2006. Volcanic Facies of the Songliao Basin Sequence, Model and the Quantitative Relationship with Porosity & Permeability of the Volcanic Reservoir. Journal of Jilin University(Earth Science Edition), (5): 805-812(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CCDZ200605023.htm Wang, P. J., Chi, Y. L., Liu, W. Z., et al., 2003. Volcanic Facies of the Songliao Basin: Classification, Characteristics and Reservoir Significance. Journal of Changchun University of Science and Technology, 33(4): 449-45 (in Chinese with English abstract). doi: 10.3969/j.issn.1671-5888.2003.04.011 Xu, C. G., Du, X. F., Liu, X. J., et al., 2020. Formation Mechanism of High-Quality Deep Buried-Hill Reservoir of Archaean Metamorphic Rocks and Its Significance in Petroleum Exploration in Bohai Sea Area. Oil & Gas Geology, 41(2): 235-247, 294 (in Chinese with English abstract). Xu, C. G., Yu, H. B., Wang, J., et al., 2019. Formation Conditions and Accumulation Characteristics of Bozhong 19-6 Large Condensate Gas Field in Offshore Bohai Bay Basin. Petroleum Exploration and Development, 46(1): 27-40(in Chinese with English abstract). doi: 10.1016/S1876-3804(19)30003-5 Xu, C. Q., Zhang, X. T., Wang, C. J., et al., 2022. Characteristics of Mesozoic Volcanic Rocks and Controlling Factors of High Quality Reservoirs in Bozhong Depression. Journal of Jilin University (Earth Science Edition), 52(4): 1027-1036(in Chinese with English abstract). Xue, Y. A., Li, H. Y., Xu P., et al., 2021. Recognition of Oil and Gas Accumulation of Mesozoic Covered Buried Hills in Bohai Sea Area and the Discovery of BZ 13-2 Oilfield. China Offshore Oil and Gas, 33(1): 13-22(in Chinese with English abstract). Ye, T., Chen, A. Q., Niu, C. M., et al., 2022. Effective Fractures Linked with Tectonic Reactivation and Multiple Genetic Fluids in the Ultradeep Paleozoic Carbonate Buried Hills of the Bozhong Sag, North China. Marine and Petroleum Geology, 140: 105642. https://doi.org/10.1016/j.marpetgeo.2022.105642 Ye, T., Chen, A. Q., Niu, C. M., et al., 2021. Structural, Petrophysical and Lithological Characterization of Crystalline Bedrock Buried-Hill Reservoirs: a Case Study of the Southern Jinzhou Oilfield in Offshore Bohai Bay Basin, North China. Journal of Petroleum Science and Engineering, 196: 107950. https://doi.org/10.1016/j.petrol.2020.107950 Yang, C., Chen, Q. H., Lv, H. B., et al., 2008. Late Paleozoic-Mesozoic Tectonic Evolution Features in Jiyang Depression. Acta Petrolei Sinica, 29(6): 859-864(in Chinese with English abstract). doi: 10.3321/j.issn:0253-2697.2008.06.013 Yi, J., Li, H. Y., Shan, X. L., et al., 2022. Division and Identification of Vertical Reservoir Units in Archaeozoic Metamorphic Buried Hill of Bozhong Sag, Bohai Bay Basin, East China. Petroleum Exploration and Development, 49(6): 1282-1294(in Chinese with English abstract). doi: 10.1016/S1876-3804(23)60349-0 Yi, J., Wang, P. J., Li, R. L., et al., 2014. Subaqueous Volcanic Eruptive Facies, Facies Model and Its Reservoir Significance in a Continental Lacustrine Basin: A Case from the Cretaceous in Chaganhua Area of Southern Songliao Basin, NE China. Journal of Jilin University (Earth Science Edition), 44 (3): 715-729 (in Chinese with English abstract). Yi, J., Wang, P. J., Shan, X. L., et al., 2020. Facies Variations in the Pyroclastic Density Currents(PDCS) Produced by the Millennium Eruption of the Changbaishan Tianchi Volcano, NE China. Acta Petrologica Sinica, 36(11): 3346-3362((in Chinese with English abstract) doi: 10.18654/1000-0569/2020.11.06 Yi, J., Wang, P. J., Tang, H. F., et al., 2015. Geological Property, Geological Connotation and Reservoir Significance of Volcano Stratigraphic Boundary: a Case Study of the Mesozoic & . Cenozoic Volcanic Rocks in Northeastern China. Acta Petrolei Sinica, 36(3): 324-336(in Chinese with English abstract). http://www.researchgate.net/publication/281765582_Geological_property_geological_connotation_and_reservoir_significance_of_volcanostratigraphic_boundary_A_case_study_of_the_Mesozoic_Cenozoic_volcanic_rocks_in_northeastern_China Yu, H. B., Wang, D. Y., Niu, C. M., et al., 2015. Characteristics and Formation Mechanisms of Buried Hill Carbonate Reservoirs in Bonan Low Uplift, Bohai Bay. Petroleum Geology & Experiment, 37(2): 150-156, 163(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/sysydz201502004 Zhang, Q. L., Ren, J. Y., Lu, J. B., et al., 2008. Hydrocarbon Enrichment and Favorable Exploration Areas in Mesozoic Buried Hill Reservoirs of Jiyang Depression. Special Oil & Gas Reservoirs, 15(2): 14-17, 106(in Chinese with English abstract). doi: 10.3969/j.issn.1006-6535.2008.02.004 Zhang, X. T, Zhang, L., Liu, X. J., 2023. Development Regularity of the Mesozoic Volcanic Reservoir in Bozhong Sag, Bohai BayBasin, China. Journal of Jilin niversity (Earth Science Edition), 53(1);1 -16(in Chinese with English abstract). Zhou, J. X., Yang, H. F., Guan, D. Y., et al, 2023. Discovery of BZ26-6 Metamorphic Rock Buried Hill Oilfield in Bohai Bay Basin and Understanding Innovation. China Offshore Oil and Gas, 35(4): 1-11(in Chinese with English abstract). Zhou, Q. J., Liu, Y. J., Wang, D. Y., et al., 2022. Mesozoic-Cenozoic Tectonic Evolution and Buried Hill Formation in Central Bohai Bay. Earth Science Frontiers, 29(5): 147-160(in Chinese with English abstract). Zhou, X. H., Zhang, R. C., Li, H. Y., et al., 2017. Major Controls on Natural Gas Accumulations in Deep-Buried Hills in Bozhong Depression, Bohai Bay Basin. Journal of China University of Petroleum (Edition of Natural Science), 41(1): 42-50 (in Chinese with English abstract). doi: 10.3969/j.issn.1673-5005.2017.01.005 Zhu, S. F., Jia, Y., Ma, L. C., et al., 2022. Characteristics, Quality-Controlling Factors and Sweet Spot Model of the Mesozoic Weathering Crust Reservoirs with Complex Lithologies in the Jiyang Depression, Bohai Bay Basin. Oil & Gas Geology, 43(3): 514-527 (in Chinese with English abstract). 何登发, 崔永谦, 张煜颖, 等, 2017. 渤海湾盆地冀中坳陷古潜山的构造成因类型. 岩石学报, 33(4): 1338-1356. 侯连华, 罗霞, 王京红, 等, 2013. 火山岩风化壳及油气地质意义——以新疆北部石炭系火山岩风化壳为例. 石油勘探与开发, 40(3): 257-265+274. 侯明才, 曹海洋, 李慧勇, 等, 2019. 渤海海域渤中19-6构造带深层潜山储层特征及其控制因素. 天然气工业, 39(1): 33-44. 蒋有录, 叶涛, 张善文, 等, 2015. 渤海湾盆地潜山油气富集特征与主控因素. 中国石油大学学报(自然科学版), 39(3): 20-29. 李慧勇, 牛成民, 许鹏, 等, 2021. 渤中13-2大型整装覆盖型潜山油气田的发现及其油气勘探意义. 天然气工业, 41(2): 19-26. 孟凡超, 操应长, 崔岩, 等, 2016. 准噶尔盆地西缘车排子凸起石炭系火山岩储层成因. 中国石油大学学报(自然科学版), 40(5): 22-31. 单玄龙, 王蔚, 张新涛, 等, 2023. 渤海海域渤中凹陷中生界火山机构地质模式及建造过程. 石油与天然气地质, 44(3): 675-688. 施和生, 牛成民, 侯明才, 等, 2021. 渤中13-2双层结构太古宇潜山成藏条件分析与勘探发现. 中国石油勘探, 26(2): 12-20. 孙耀庭, 孙超, 李辉, 等, 2016. 济阳拗陷桩西地区中生界火成岩储层控制因素. 成都理工大学学报(自然科学版), 43 (3): 257-265. 王晨杰, 张新涛, 徐春强, 等, 2021. 渤中凹陷北部中生界火山岩储层发育特征及主控因素. 中国海上油气, 33(3): 48-57. 王德英, 王清斌, 刘晓健, 等, 2019. 渤海湾盆地海域片麻岩潜山风化壳型储层特征及发育模式. 岩石学报, 35(4): 1181-1193. 王璞珺, 迟元林, 刘万洙, 等, 2003. 松辽盆地火山岩相: 类型、特征和储层意义. 吉林大学学报(地球科学版), (4): 449-456. 王璞珺, 吴河勇, 庞颜明, 等, 2006. 松辽盆地火山岩相: 相序、相模式与储层物性的定量关系. 吉林大学学报(地球科学版), (5): 805-812. 王艳忠, 操应长, 陈世悦等. 2007. 济阳坳陷中生界碎屑岩储层特征及其控制作用. 中国石油大学学报(自然科学版), 31 (5): 7-11+17. 徐春强, 张新涛, 王晨杰, 等, 2022. 渤中凹陷中生界火山岩特征及优质储层控制因素. 吉林大学学报(地球科学版), 52(4): 1027-1036. 徐长贵, 杜晓峰, 刘晓健, 等, 2020. 渤海海域太古界深埋变质岩潜山优质储集层形成机制与油气勘探意义. 石油与天然气地质, 41(2): 235-247+294. 徐长贵, 于海波, 王军, 等, 2019. 渤海海域渤中19-6大型凝析气田形成条件与成藏特征. 石油勘探与开发, 46(1): 25-38. 薛永安, 李慧勇, 许鹏, 等, 2021. 渤海海域中生界覆盖型潜山成藏认识与渤中13-2大油田发现. 中国海上油气, 33(1): 13-22. 杨超, 陈清华, 吕洪波, 等. 2008. 济阳坳陷晚古生代-中生代构造演化特点. 石油学报, 29(6): 859-864. 衣健, 李慧勇, 单玄龙, 等, 2022. 渤海湾盆地渤中凹陷太古宇变质岩潜山储集层垂向结构单元划分与识别. 石油勘探与开发, 49(6): 1107-1118. 衣健, 王璞珺, 李瑞磊, 等, 2014. 松辽盆地断陷层系地震火山地层学研究: 典型火山岩地震相与地质解释模式. 吉林大学学报(地球科学版), 44 (3): 715-729. 衣健, 王璞珺, 单玄龙, 等, 2020. 长白山天池火山千年大喷发火山碎屑流堆积相特征. 岩石学报, 36(11): 3346-3362. 衣健, 王璞珺, 唐华风, 等, 2015. 火山地层界面的地质属性、地质内涵和储层意义——以中国东北地区中生代-新生代火山岩为例. 石油学报, 36(3): 324-336. 于海波, 王德英, 牛成民, 等, 2015. 渤海海域渤南低凸起碳酸盐岩潜山储层特征及形成机制. 石油实验地质, 37(2): 150-156+163. 张青林, 任建业, 陆金波, 等, 2008. 济阳坳陷中生界古潜山油气富集规律及有利勘探区预测. 特种油气藏, 15(2): 14-17+106. 张新涛, 张藜, 刘晓健, 2023. 渤海湾盆地渤中凹陷中生界火山岩优质储层发育规律. 吉林大学学报(地球科学版), 53(1): 1-16. 周家雄, 杨海风, 官大勇, 等, 2023. 渤海湾盆地渤中26-6变质岩潜山大油田发现与认识创新. 中国海上油气, 35(4): 1-11. 周琦杰, 刘永江, 王德英, 等, 2022. 渤海湾中部中、新生代构造演化与潜山的形成. 地学前缘, 29(5): 147-160. 周心怀, 张如才, 李慧勇, 等, 2017. 渤海湾盆地渤中凹陷深埋古潜山天然气成藏主控因素探讨. 中国石油大学学报(自然科学版), 41(1): 42-50. 朱世发, 贾业, 马立驰, 等, 2022. 渤海湾盆地济阳坳陷中生界复杂岩性风化壳储层特征、质量控因与甜点模型. 石油与天然气地质, 43 (3): 514-527. -
