Caprock Type and Sealing Mechanism of Quaternary Ultra Shallow Large Gas Reservoir in Deep Water Area of Qiongdongnan Basin, China
-
摘要: 盖层是决定油气能否成藏的重要因素，目前盖层研究多关注中深层固结岩石的封盖能力，而围绕浅层疏松未固结盖层的研究较少，对于深水浅埋地层中的盖层评价则更为少见.基于琼东南盆地深水区三维地震解释、三轴应力实验、测井评价、圆锥触探试验等研究成果，明确了L36区第四系乐东组浅埋气藏盖层的发育类型及封堵能力，总结了研究区盖层封盖机理.结果表明：（1）深水区乐东组发育深海泥、块体流、含水合物地层3类盖层，三者均可起到有效封盖作用；（2）综合地震‒地质解释及实验成果，明确了3类盖层封盖能力从小到大依次为深海泥、块体流、含水合物地层，其中深海泥在海底埋深200 m处可封盖59 m天然气，为研究区主要目的层盖层封堵下限.（3）深水浅埋盖层封堵机理占主导作用的是毛细管封闭、水力封闭，低温高压环境下饱和盐水封堵机制发挥了特色性增封作用.以上认识得到近两年钻探的验证，这不仅为琼东南盆地乐东组的后续勘探开发提供了理论依据，也可为其他深水浅埋地区的天然气勘探提供有益借鉴.Abstract: Caprock plays an important role in determining whether hydrocarbon accumulation is available. Previous studies of caprock mainly focus on the sealing ability of medium-deep consolidated rock, while less attention is paid to the shallow unconsolidated caprock, and the evaluation of caprock of shallow buried formations in deep water area is rare. Based on the research results of seismic interpretation, uniaxial stress test, logging evaluation, and cone penetration test in the deep water area of Qiongdongnan Basin, the development type and sealing ability of the caprock for the gas reservoir of the Ledong Formation in the L36 area are studied in this paper. The results show that: (1) There are three types of caprock (deep-sea mud, mass transport deposits, and hydrate-bearing strata) in the deep water area of the Ledong Formation, which could all have the effective sealing effect. (2) Based on the seismic and geological interpretation and experimental results, it is clear that the sealing capacity increases in the order of deep-sea mud, mass transport deposits, and hydrate-bearing strata; and the deep-sea mud can seal 59 m hydrocarbon at 200 m below seafloor, which is the threshold of sealing ability for the main target layer in the study area. (3) The capillary sealing and hydraulic sealing plays a dominant role in the sealing mechanism of shallow buried caprock in the deep water area, under low temperature and high pressure environment, the saturated salt water sealing mechanism plays a characteristic role in increasing sealing capacity. The above results have been verified by drilling in the past two years, which not only provides a theoretical basis for the follow-up exploration and development of the Ledong Formation in Qiongdongnan Basin, but also can provide a useful reference for the natural gas exploration in other shallow buried areas in the deep water area.
-
Key words:
- Qiongdongnan Basin /
- deep water area /
- Quaternary /
- ultra shallow gas reservoir /
- caprock type /
- sealing mechanism /
- petroleum geology
-
图 1 琼东南盆地构造区划（a）、地层综合柱状图（b）
Fig. 1. Structural division (a) and stratigraphic comprehensive histogram (b) of Qiongdongnan Basin
图 4 琼东南盆地西北方向块体流地震剖面及弧长属性
Fig. 4. Seismic profile and arc length attribute of MTDs from northwest direction in Qiongdongnan Basin
图 5 琼东南盆地西南方向块体流地震剖面（a）及振幅属性（b）
Fig. 5. Seismic profile (a) and amplitude attribute (b) of MTDs from southwest direction in Qiongdongnan Basin
图 6 L36-1a井乐三段泥岩盖层排替压力与盖层孔隙度、埋深、泥岩厚度的关系
Fig. 6. The relationship between the displacement pressure of mudstone caprock and the porosity, buried depth and mudstone thickness of the third member of Ledong Formation in Well L36-1a
图 7 基于CPT原位测试分析含水合物地层封盖能力
Fig. 7. Analysis of sealing ability of hydrate-bearing strata based on CPT in-situ test
图 8 毛细管失效（a）与水力破裂（b）模式
Fig. 8. Patterns of capillary failure (a) and hydraulic fracture (b)
图 9 琼东南地区深水浅埋盖层封盖机理
Fig. 9. Sealing mechanism of deep-water shallow-buried caprock in Qiongdongnan area
图 10 不同温度条件下盖层表面张力（a）、变温‒变压条件下天然气密度（b）
Fig. 10. Caprock surface tension (a) under different temperature conditions, natural gas density (b) under variable temperature and pressure conditions
图 11 深水井LS17-2（a）、浅水井DF-X（b）海底埋深30 m圆锥静力触探实验对比
Fig. 11. Deep water Well LS17-2 (a), shallow water Well DF-X (b) seabed buried depth of 30 m cone static cone penetration test comparison
表 1 L36-1a井盖层排替压力及其可封堵最大气柱高度
Table 1. The displacement pressure of Well L36-1a caprock and the maximum height of gas column that can be sealed
顶深(m) 底深(m) 厚度(m) 孔隙度（%） 排替压力（MPa） 可封最大气柱高度（m） 1 770 1 782 12 22 0.9 116 1 795 1 822 27 20 1.1 144 1 827 1 829 2 15 1.9 246 1 843 1 858 15 25 0.7 84 1 860 1 874 14 20.5 1.1 136 1 878 1 889 11 20 1.1 144 1 894 1 896 2 20 1.1 144 1 897 1 899 2 25 0.7 84 1 914 1 921 7 17 1.6 198 1 924 1 943 19 16 1.7 221 1 948 1 992 44 18 1.4 178 2 011 2 053 42 19 1.3 160
下载: 导出CSV
表 2 块体流与深海泥测井参数(Sun and Alves, 2020)
Table 2. Logging parameters of MTDs and deepsea mud (Sun and Alves, 2020)
测井参数 块体流 深海泥 体积密度(g/cm3) 1.8 1.7 孔隙度(%) 42 50 电阻率(Ω·m) 2 1.5 声波时差(µs/ft) 160 177 含水饱和度(wt%) 22 25
下载: 导出CSV
-
Algar, S., Milton, C., Upshall, H., et al., 2011. Mass-Transport Deposits of the Deepwater Northwestern Borneo Margin—Characterization from Seismic-Reflection, Borehole, and Core Data with Implications for Hydrocarbon Exploration and Exploitation. In: Shipp, R. C., Weimer, P., Posamentier, H. W., eds., Mass-Transport Deposits in Deepwater Settings. SEPM (Society for Sedimentary Geology), Tulsa, 351-366. https://doi.org/10.2110/sepmsp.096.351 Amy, L. A., 2019. A Review of Producing Fields Inferred to have Upslope Stratigraphically Trapped Turbidite Reservoirs: Trapping Styles (Pure and Combined), Pinch-out Formation, and Depositional Setting. Bulletin of the American Association of Petroleum Geologists, 103(12): 2861-2889. https://doi.org/10.1306/02251917408 Baur, F., Scheirer, A. H., Peters, K. E., 2018. Past, Present, and Future of Basin and Petroleum System Modeling. AAPG Bulletin, 102(4): 549-561. https://doi.org/10.1306/08281717049 Bhatnagar, P., Verma, S., Bianco, R., 2019. Characterization of Mass Transport Deposits Using Seismic Attributes: Upper Leonard Formation, Permian Basin. Interpretation, 7(4): SK19-SK32. https://doi.org/10.1190/int-2019-0036.1 Bull, S., Cartwright, J., Huuse, M., 2009. A Review of Kinematic Indicators from Mass-Transport Complexes Using 3D Seismic Data. Marine and Petroleum Geology, 26(7): 1132-1151. https://doi.org/10.1016/j.marpetgeo.2008.09.011 Byerlee, J., 1978. Friction of Rocks. Pure and Applied Geophysics, 116: 615-626. https://doi.org/10.1007/BF00876528 Cardona, S., Kobayashi, H., Wood, L., et al., 2022. Assessing the Sealing Quality of Submarine Mass Transport Complexes and Deposits. Marine and Petroleum Geology, 143: 105748. https://doi.org/10.1016/j.marpetgeo.2022.105748 Cardona, S., Wood, L. J., Day-Stirrat, R. J., et al., 2016. Fabric Development and Pore-Throat Reduction in a Mass-Transport Deposit in the Jubilee Gas Field, Eastern Gulf of Mexico: Consequences for the Sealing Capacity of MTDs. In: Lamarche, G., Mountjoy, J., Bull, S., et al., eds., Advances in Natural and Technological Hazards Research. Springer International Publishing, Cham, 27-37. https://doi.org/10.1007/978-3-319-20979-1_3 Cartwright, J., Huuse, M., Aplin, A., 2007. Seal Bypass Systems. AAPG Bulletin, 91: 1141-1166. https://doi.org/10.1306/04090705181 Castillo, D. A., Bishop, D. J., Donaldson, I., et al., 2000. Trap Integrity in the Lam in Aria High-Nancar Trough Region, Timor Sea: Prediction of Fault Seal Failure Using well-Constrained Stress Tensors and Fault Surfaces Interpreted from 3D Seismic. The APPEA Journal, 40(1): 151. https://doi.org/10.1071/aj99009 Downey, M. W., 1984. Evaluating Seals for Hydrocarbon Accumulations. AAPG Bulletin, 68: 1752-1763. https://doi.org/10.1306/ad461994-16f7-11d7-8645000102c1865d Fryer, R. C., Jobe, Z. R., 2019. Quantification of the Bed-Scale Architecture of Submarine Depositional Environments. The Depositional Record, 5(2): 192-211. https://doi.org/10.1002/dep2.70 Godo, T. J., 2006. Identification of Stratigraphic Traps with Subtle Seismic Amplitude Effects in Miocene Channel/Levee Sand Systems, NE Gulf of Mexico. Geological Society, London, Special Publications, 254(1): 127-151. https://doi.org/10.1144/gsl.sp.2006.254.01.07 Jackson, A., Stright, L., Hubbard, S. M., et al., 2019. Static Connectivity of Stacked Deep-Water Channel Elements Constrained by High-Resolution Digital Outcrop Models. AAPG Bulletin, 103(12): 2943-2973. https://doi.org/10.1306/03061917346 Jia, R., 2018. Integrity of Caprock in Yingqiong Basin and Its Relationship with Natural Gas Accumulation (Dissertation). Northeast Petroleum University, Daqing (in Chinese with English abstract). Jiang, Y. L., 1998. Discussion on the Relationship between the Thickness of Caprock and the Height of Hydrocarbon Column Covered by It. Natural Gas Industry, 18(2): 20-23 (in Chinese with English abstract). doi: 10.3321/j.issn:1000-0976.1998.02.007 Johnson, R. C., Birdwell, J., Brownfield, M., et al., 2015. Mass-Movement Deposits in the Lacustrine Eocene Green River Formation, Piceance Basin, Western Colorado. U. S. Geological Survey, Reston, Virginia. https://doi.org/10.3133/ofr20151044 . RestonKessler, F., Jong, J., 2018. Hydrocarbon Retention in Clastic Reservoirs of NW Borneo-Examples of Hydrocarbon Trap, Reservoir, Seal and Implications on Hydrocarbon Column Length. Berita Sedimentologi, 40: 6-44. Li, F. J., 1982. Discussion on the Problem of Wellbore Stability. Oil Drilling & Production Technology, (7): 1-8 (in Chinese). Li, J., Yan, Q. T., Zhang, Y., et al., 2007. Particularity of Sealing Mechanism of Quaternary Biogas Caprock in Sanhu Area of Qaidam Basin. Scientia Sinica Terrae, 37(S2): 36-42 (in Chinese). Liu, Q. H., Li, Z. Y., Chen, H. H., et al., 2024. Current Geological Issues and Future Perspectives in Deep-Time Source-to-Sink Systems of Continental Rift Basins. Journal of Earth Science, 35(5): 1758-1764. https://doi.org/10.1007/s12583-024-0028-x Meckel, L. D., 2011. Reservoir Characteristics and Classification of Sand-Prone Submarine Mass-Transport Deposits. In: Shipp, R. C., Weimer, P., Posamentier, H. W., eds., Mass-Transport Deposits in Deepwater Settings. SEPM (Society for Sedimentary Geology), Tulsa, 423-452. https://doi.org/10.2110/sepmsp.096.423 Pei, J. X., Song, P., Guo, M. G., et al., 2023. Sedimentary Evolution and Hydrocarbon Exploration Prospect of the Quaternary Central Canyon System in the Qiongdongnan Basin. Earth Science, 48(2): 451-464 (in Chinese with English abstract). Rayeva, N., Kosnazarova, N., Arykbayeva, Z., et al., 2014. Petroleum Systems Modeling and Exploration Risk Assessment for the Eastern Margin of the Precaspian Basin (Russian) In: SPE Annual Caspian Technical Conference and Exhibition. Society of Petroleum Engineers, Astana. https://doi.org/10.2118/172332-ru Rudolph, K. W., Goulding, F. J., 2017. Benchmarking Exploration Predictions and Performance Using 20+ Yr of Drilling Results: One Company's Experience. AAPG Bulletin, 101(2): 161-176. https://doi.org/10.1306/06281616060 Schmatz, J., Vrolijk, P. J., Urai, J. L., 2010. Clay Smear in Normal Fault Zones-The Effect of Multilayers and Clay Cementation in Water-Saturated Model Experiments. Journal of Structural Geology, 32(11): 1834-1849. https://doi.org/10.1016/j.jsg.2009.12.006 Sha, Z. B., Liang, J. Q., Zhang, G. X., et al., 2015. A Seepage Gas Hydrate System in Northern South China Sea: Seismic and Well Log Interpretations. Marine Geology, 366: 69-78. https://doi.org/10.1016/j.margeo.2015.04.006 Shanmugam, G., Shrivastava, S. K., Das, B., 2009. Sandy Debrites and Tidalites of Pliocene Reservoir Sands in Upper-Slope Canyon Environments, Offshore Krishna-Godavari Basin (India): Implications. Journal of Sedimentary Research, 79(9): 736-756. https://doi.org/10.2110/jsr.2009.076 Sun, Q. L., Alves, T. M., 2020. Petrophysics of Fine-Grained Mass-Transport Deposits: A Critical Review. Journal of Asian Earth Sciences, 192: 104291. https://doi.org/10.1016/j.jseaes.2020.104291 Tänavsuu-Milkeviciene, K., Sarg, J. F., 2012. Evolution of an Organic-Rich Lake Basin-Stratigraphy, Climate and Tectonics: Piceance Creek Basin, Eocene Green River Formation. Sedimentology, 59(6): 1735-1768. https://doi.org/10.1111/j.1365-3091.2012.01324.x Wang, Y., Pei, J. X., Liu, Y., 2016. Caprock Sealing Mechanism of High-Temperature and Overpressure Gas Reservoirs in the Dongfang Block, Yinggehai Basin, South China. Geology and Minerals Resources South China, 32(4): 397-405 (in Chinese with English abstract). Watts, N. L., 1987. Theoretical Aspects of Cap-Rock and Fault Seals for Single- and Two-Phase Hydrocarbon Columns. Marine and Petroleum Geology, 4(4): 274-307. https://doi.org/10.1016/0264-8172(87)90008-0 Welbon, A. I. F., Brockbank, P. J., Brunsden, D., et al., 2007. Characterizing and Producing from Reservoirs in Landslides: Challenges and Opportunities. Geological Society, London, Special Publications, 292(1): 49-74. https://doi.org/10.1144/sp292.3 Xie, Y. H., 2019. Quantitative Evaluation of Sealing Capacity of High Temperature and Pressure Caprocks in Yinggehai Basin. Earth Science, 44(8): 2579-2589 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX201908001.htm Yang, J. X., Davies, R. J., Huuse, M., 2013. Gas Migration below Gas Hydrates Controlled by Mass Transport Complexes, Offshore Mauritania. Marine and Petroleum Geology, 48: 366-378. https://doi.org/10.1016/j.marpetgeo.2013.09.003 Zou, C. N., Yang, Z., Zhang, G. S., et al., 2023. Theory, Technology and Practice of Unconventional Petroleum Geology. Journal of Earth Science, 34(4): 951-965. https://doi.org/10.1007/s12583-023-2000-8 贾茹, 2018. 莺琼盆地盖层完整性及与天然气成藏(博士学位论文). 大庆: 东北石油大学. 蒋有录, 1998. 油气藏盖层厚度与所封盖烃柱高度关系问题探讨. 天然气工业, 18(2): 20-23. doi: 10.3321/j.issn:1000-0976.1998.02.007 李凤九, 1982. 井壁稳定问题的探讨. 石油钻采工艺, (7): 1-8. 李剑, 严启团, 张英, 等, 2007. 柴达木盆地三湖地区第四系生物气盖层封闭机理的特殊性. 中国科学: 地球科学, 37(S2): 36-42. 裴健翔, 宋鹏, 郭明刚, 等, 2023. 琼东南盆地第四纪中央峡谷体系沉积演化与油气前景. 地球科学, 48(2): 451-464. doi: 10.3799/dqkx.2022.487 汪洋, 裴健翔, 刘亿, 2016. 莺歌海盆地东方区高温超压气藏盖层封盖机制. 华南地质与矿产, 32(4): 397-405. doi: 10.3969/j.issn.1007-3701.2016.04.010 谢玉洪, 2019. 莺歌海盆地高温高压盖层封盖能力定量评价. 地球科学, 44(8): 2579-2589. doi: 10.3799/dqkx.2019.095 -
