The Hydrocarbon Generation Characteristics of the Upper Paleozoic Coaly Bearing Source Rocks and Its Main Controlling Factors in the North of the Jizhong Depression
-
摘要: 冀中坳陷位于渤海湾盆地西部，其古生界石炭‒二叠系煤系烃源岩具有很大的资源潜力，已在苏桥‒文安地区发现了与石炭‒二叠系煤系烃源岩有关的油气藏.但是目前对冀中坳陷古生界不同层段煤系烃源岩的生烃特征及其发育的主控因素认识不清，影响了下一步油气勘探决策.在前人研究基础上，对冀中坳陷东北部石炭‒二叠系煤系烃源岩有机地化特征进行分析，并挑选太原组和山西组煤样进行高温高压生烃动力学热模拟实验研究，探讨煤系源岩的生烃潜力和生烃机理，总结其发育的主控因素.研究结果表明，研究区内煤系烃源岩有机丰度高，具有较好的生烃潜力；太原组煤系烃源岩的有机质类型以Ⅱ2型和Ⅱ1型为主，山西组煤系烃源岩以Ⅱ2型和Ⅲ型为主，多处于成熟阶段；太原组煤的生油气能力强于山西组，但山西组煤生气的活化能更低，更容易生成气；煤系烃源岩发育受沉积环境、古气候与古植物因素的控制，太原组煤主要形成于瀉湖泥炭沼泽成煤环境，山西组煤主要形成于三角洲平原泥炭沼成煤环境.综合以上研究建立了研究区的聚煤模式.该成果对该区的油气资源潜力评价具有重要的参考作用.Abstract: Jizhong depression is located in the west of Bohai Bay basin. Its Carboniferous-Permian coaly source rocks have great resource potential, of which related oil and gas reservoirs have been explored in Suqiao-Wen'an area in the depression. However, the hydrocarbon generation characteristics and petroleum resource potential of the coaly source rocks still remain unclear in the Jizhong depression, which seriously affects the oil and gas exploration. On the basis of previous research, in this paper it makes a detailed analysis of organic geochemical characteristics of the Carboniferous-Permian coaly source rocks. The hydrocarbon generation potential and mechanism of selected coaly source rocks from Taiyuan Formation and Shanxi Formation are also explored by the experiment of high temperature and high pressure hydrocarbon generation kinetics. The research shows that the organic abundance of coal source rocks in the study area is high, indicating good hydrocarbon generation potential. The organic matter types of Taiyuan Formation are mainly type II2 and type II1, and the organic matter types of Shanxi Formation are mainly type II2 and type III, which are mostly in the mature stage.The oil and gas generation capacity of Taiyuan Formation is stronger than that of Shanxi Formation, but the activation energy of coal in Shanxi Formation is lower and it is easier to generate gas. The development of coal-bearing source rocks is controlled by sedimentary environment, paleoclimate and paleoplant factors. The coal of Taiyuan Formation is mainly formed in the coal-forming environment of lagoon peat swamp, and the coal of Shanxi Formation is mainly formed in the coal-forming environment of delta plain peat swamp. On this basis, a coal accumulation model suitable for the study area has been established. This study plays an important supporting role in the evaluation of oil and gas resource potential in the study area.
-
图 2 研究区构造演化剖面图（据尘福艳等，2012有所修改）
Fig. 2. Structural evolution profile of the study area (modified after Chen, 2012)
图 3 胜1井太原组上段煤岩显微组分荧光照片
Fig. 3. Fluorescence photos of macerals in upper Taiyuan Formation of Sheng 1 well
图 4 冀中坳陷东北部煤系烃源岩TOC与S1+S2关系
Fig. 4. Relationship between TOC and S1+S2 of coal- measure source rocks in northeastern Jizhong depression
图 5 冀中坳陷东北部煤系烃源岩氢指数与Tmax关系
a.暗色泥岩；b.炭质泥岩；c.煤岩
Fig. 5. The relationship between hydrogen index and Tmax of coal source rocks in the northeastern Jizhong depression
图 6 冀中坳陷东北部煤系烃源岩与深度和侵入岩关系
a.全区Ro统计；b.苏8井Ro分布
Fig. 6. The relationship between coal-measure source rocks and depth and intrusive rocks in the northeastern Jizhong depression
图 7 太原组煤热解实验气态烃产率
a.甲烷产率；b. 乙烷产率；c.丙烷产率；d. 总气态烃产率
Fig. 7. Gaseous hydrocarbon yield of Taiyuan Formation coal pyrolysis experiment
图 8 山西组煤热解实验气态烃产率
a.甲烷产率；b. 乙烷产率；c.丙烷产率；d. 总气态烃产率
Fig. 8. Gaseous hydrocarbon yield of Shanxi Formation coal pyrolysis experiment
图 11 太原组和山西组煤的气态烃转化率
Fig. 11. Gaseous hydrocarbon conversion rate of different groups of coal
图 12 太原组和山西组沉积相平面图和煤岩厚度分布
a.太原组下沉积相图；b. 山西组沉积相图；c.太原组下煤岩厚度；d.山西组煤岩厚度
Fig. 12. Sedimentary facies plan and coal rock thickness distribution map of Taiyuan Formation and Shanxi Formation
图 13 冀中凹陷东北部不同层位煤岩生烃潜力直方图
Fig. 13. Histogram of hydrocarbon generation potential of coal rock in different layers in the northeastern Jizhong depression
图 14 冀中坳陷东北部煤系烃源岩沉积环境模式（据常嘉，2019修改）
Fig. 14. Sedimentary environment model of coal-measure source rocks in northeastern Jizhong depression (modified after Chang, 2019)
表 1 冀中坳陷东北部煤系烃源岩显微组分平均含量
Table 1. Average contents of macerals of coal-measure source rocks in northeastern Jizhong depression
地层 岩石类型 镜质组（%） 惰质组（%） 壳质组+腐泥组（%） 山西组 煤 46.70（15） 25.53（15） 27.77（15） 炭质泥岩 49.23（2） 46.70（2） 4.08（2） 暗色泥岩 77.90（2） 17.45（2） 4.20（2） 太原组上段 煤 59.01（9） 11.12（9） 29.88（9） 炭质泥岩 67.22（3） 4.59（3） 28.19（3） 暗色泥岩 74.33（1） 18.35（1） 7.33（1） 太原组下段 煤 46.57（5） 30.77（5） 22.66（5） 炭质泥岩 51.15（5） 19.97（5） 28.87（5） 暗色泥岩 75.40（1） 15.30（1） 9.30（1） 注：平均值（样品数）.
下载: 导出CSV
表 2 冀中凹陷东北部烃源岩有机碳含量（TOC）统计
Table 2. Statistics of total organic carbon (TOC) content of source rocks in northeastern Jizhong depression
有机质丰度 层位 山西组 太原组上段 太原组下段 岩石类型 TOC（%） 暗色泥岩 0.06~9.92 0.22~9.85 0.11~9.88 2.22（183） 3.02（115） 3.94（118） 炭质泥岩 10.11~39.8 10.19~38.56 10.05~39.50 20.63（32） 18.54（35） 20.99（50） 煤 40.70~88.61 42.95~82.72 40.03~91.08 56.65（29） 67.17（24） 58.03（29） 注：最小值~最大值；平均值（样品数）.
下载: 导出CSV
表 3 冀中凹陷东北部烃源岩生烃潜力（S1+S2）统计
Table 3. Statistics of hydrocarbon generation potential (S1+S2) of source rocks in northeastern Jizhong depression
有机质丰度 层位 山西组 太原组上段 太原组下段 岩石类型 S1+S2（mg/g） 暗色泥岩 0.02~46.89
3.6（103）0.14~19.89
3.69（57）0.13~47.92
3.33（72）炭质泥岩 0.9~107.67
43.61（23）0.74~86.65
23.21（25）0.44~105.66
35.28（43）煤 0.52~198.43
92.94（24）42.3~273.28
98.12（17）40.35~209.22
89.17（23）注：最小值~最大值；平均值（样品数）
下载: 导出CSV
表 4 实验样品地化参数
Table 4. Geochemical parameters of experimental samples
井位 层位 岩性 TOC S1 S2 Tmax（℃） Ro（%） HI （%） （mg/g） （mg/g） （mg/g·TOC） 埕古2 山西组 煤 75.46 3.87 148.6 443 0.72 196.9 胜1 太原组 60.98 6.76 140.7 430 0.67 230.8
下载: 导出CSV
表 5 冀中凹陷东北部不同层位煤系源岩厚度
Table 5. The thickness of coal source rock in different layers in the northeastern Jizhong depression
层位 岩石类型 厚度（m） 厚值中心 主要沉积环境 山西组 暗色泥岩 20~100 文安斜坡、里坦凹陷 三角洲平原分流间湾 炭质泥岩 2~20 文安斜坡、大城凸起 煤 3~27 文安斜坡、大城凹陷 三角洲平原泥炭沼泽 太原组上段 暗色泥岩 10~80 文安斜坡、武清凹陷 瀉湖、潮坪 炭质泥岩 5~45 文安斜坡、里坦凹陷 煤 2~20 文安斜坡、武清凹陷 瀉湖泥炭沼泽 太原组下段 暗色泥岩 10~80 文安斜坡、武清凹陷 瀉湖、潮坪 炭质泥岩 5~35 文安斜坡、大城凸起 煤 2~40 文安斜坡、大城凸起 瀉湖泥炭沼泽
下载: 导出CSV
-
Chang, J., 2019. Sedimentary Environment and Source Rock Characteristics of the Late Paleozoic Coal-Bearing Strata in the Bohai Bay Basin Region (Dissertation). China University of Petroleum (East China), Qingdao, 51-53 (in Chinese with English abstract). Chen, F. Y., Ding, W. L., Qian, Z., et al., 2013. Control Factors of Burial-Hydrocarbon Generation History of Carboniferous-Permian Source Rocks in Jizhong Depression. Fault-Block Oil & Gas Field, 20(2): 145-149 (in Chinese with English abstract). Chen, F. Y., Liang, H. B., Ding, W. L., et al., 2012. Carboniferous-Permian Sedimentary Facies Characteristics and Paleoenvironmental Reconstruction in Northeast Jizhong Depression. Geology in China, 39(4): 939-946 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-3657.2012.04.009 Chen, F. Y., Yang, C., Tan, F. R., et al., 2019. Application of Trace Element Analysis in Sedimentary Media Environment Differentiation-A Case Study of Permo- Carboniferous in Northeastern Part of Central Hebei Depression. Coal Geology of China, 31(6): 15-22 (in Chinese with English abstract). doi: 10.3969/j.issn.1674-1803.2019.06.04 Dai, J. X., Qin, S. F., Tao, S. Z., et al., 2005. Developing Trends of Natural Gas Industry and the Significant Progress on Natural Gas Geological Theories in China. Natural Gas Geoscience, 16(2): 127-142 (in Chinese with English abstract). doi: 10.3969/j.issn.1672-1926.2005.02.001 Deng, S. H., Lu, Y. Z., Zhao, Y., et al., 2017. The Jurassic Palaeoclimate Regionalization and Evolution of China. Earth Science Frontiers, 24(1): 106-142 (in Chinese with English abstract). Feng, Z. D., Cheng, X. S., Wang, S. L., et al., 2013. Hydrocarbon Generation Potential of the Upper Paleozoic Coal Measure Source Rocks in the Luxi Area, Western Shandong, China. Natural Gas Industry, 33(2): 17-21 (in Chinese with English abstract). Guo, P., 2020. Geochemical Characteristics and Hydrocarbon Generation Evolution of Upper Paleozoic Coal Measures in Jizhong Depression, Bohai Bay Basin. Natural Gas Geoscience, 31(9): 1306-1315 (in Chinese with English abstract). Huang, W. K., 2019. Hydrocarbon Generation Kinetics and Geochemical Characteristics of Coaly Source Rocks in the Kuqa Depression (Dissertation). University of Chinese Academy of Sciences (Guangzhou Institute of Geochemistry, Chinese Academy of Sciences), Guangzhou (in Chinese with English abstract). Jia, C. Z., Zhang, Y. F., Zhao, X., 2014. Prospects of and Challenges to Natural Gas Industry Development in China. Natural Gas Industry, 34(2): 8-18 (in Chinese with English abstract). Li, E. T., Pan, C. C., Yu, S., et al., 2013. Hydrocarbon Generation from Coal, Extracted Coal and Bitumen Rich Coal in Confined Pyrolysis Experiments. Organic Geochemistry, 64: 58-75. https://doi.org/10.1016/j.orggeochem.2013.09.004 Li, E. T., Pan, C. C., Yu, S., et al., 2016. Interaction of Coal and Oil in Confined Pyrolysis Experiments: Insight from the Yields and Carbon Isotopes of Gas and Liquid Hydrocarbons. Marine and Petroleum Geology, 69: 13-37. https://doi.org/10.1016/j.marpetgeo.2015.10.006 Li, R. X., Li, Y. Z., Gao, Y. W., 2007. Catagenesis of Organic Matter of Oil Source Rocks in Upper Paleozoic Coal Formation of the Bohai Gulf Basin (Eastern China). Russian Geology and Geophysics, 48(5): 415-421. https://doi.org/10.1016/j.rgg.2007.05.001 Liao, Q. J., Yu, X. M., He, Y. M., et al., 2003. The Characteristics and Resource Potential of Coal-Bearing Formations in Upper Paleozoic in Dagang Oilfield. Natural Gas Geoscience, 14(4): 250-253 (in Chinese with English abstract). Liu, J. Z., Tang, Y. C., 1998. An Example of Predicting Methane Production by Kerogen Hydrocarbon Generation Kinetics Method. Chinese Science Bulletin, 43(10): 1187-1191 (in Chinese with English abstract). Lü, X. Y., Jiang, Y. L., Jiang, W. Y., et al., 2019. Genetic Types and Source of Meso-Paleozoic Crude Oil in the Huanghua Sub-Basin. Journal of China University of Mining & Technology, 48(6): 1290-1300 (in Chinese with English abstract). Pan, C. C., Geng, A. S., Zhong, N. N., et al., 2010a. Kerogen Pyrolysis in the Presence and Absence of Water and Minerals: Steranes and Triterpenoids. Fuel, 89(2): 336-345. https://doi.org/10.1016/j.fuel.2009.06.032 Pan, C. C., Jiang, L. L., Liu, J. Z., et al., 2010b. The Effects of Calcite and Montmorillonite on Oil Cracking in Confined Pyrolysis Experiments. Organic Geochemistry, 41(7): 611-626. https://doi.org/10.1016/j.orggeochem.2010.04.011 Qian, Z., Zhang, S. H., Liang, H. B., et al., 2015. Hydrocarbon Evaluation of Carboniferous-Permian Source Rocks in Northeast Jizhong Depression. Journal of Jilin University (Earth Science Edition), 45(5): 1332-1341 (in Chinese with English abstract). Tang, Y., Perry, J. K., Jenden, P. D., et al., 2000. Mathematical Modeling of Stable Carbon Isotope Ratios in Natural Gases. Geochimica et Cosmochimica Acta, 64(15): 2673-2687. https://doi.org/10.1016/s0016-7037(00)00377-x Wang, F. Y., Fu, J. M., Liu, D. H., et al., 1993. Detection and Significance of Ultramicro Lipid in Vitrinite of Coal and Source Rocks. Chinese Science Bulletin, 38(2): 151-154 (in Chinese with English abstract). Wang, Y. Z., 2020. Carboniferous-Permian Coal-Derived Gas Resource Potential Analysis and Favorable Area Prediction in the Northeast of Jizhong Depression (Dissertation). China University of Geosciences (Beijing), Beijing, 23-25 (in Chinese with English abstract). Xin, C. L., Wang, L. H., Ji, J. J., et al., 2019. Geological Age and Palaeogeographical Study of the Yaojie Flora in Gansu Province. Acta Geologica Sinica, 93(2): 302-316 (in Chinese with English abstract). Xiong, Y. Q., Geng, A. S., Liu, J. Z., et al., 2002. Kinetic Simulating Experiment Combined with GC-IRMS Analysis: Application to Identification of Effective Gas Source Rock. Geochimica, 31(1): 21-25 (in Chinese with English abstract). Yang, C. Y., Yu, X. M., Liu, Y., et al., 2014. Geological Conditions of Coal-Derived Gas Accumulation and Exploitation Prospect in the Carboniferous-Permian Covered Area from South Central of Huanghua Depression in Bohai Bay Basin. Natural Gas Geoscience, 25(1): 23-32 (in Chinese with English abstract). Zeng, L. F., 2020. Petroleum Generation Kinetics of Jurassic Coaly Source Rocks in Junggar Basin (Dissertation). University of Chinese Academy of Sciences (Guangzhou Institute of Geochemistry, Chinese Academy of Sciences), Guangzhou, 58-62 (in Chinese with English abstract). Zhang, S. H., Liang, H. B., Tang, S. H., et al., 2014. Simulation of the Thermal and Maturity History of Carboniferous-Permian Source Rock in the Northeast of Jizhong Depression. Geological Journal of China Universities, 20(3): 454-463 (in Chinese with English abstract). Zhao, C. Y., Li, Y. X., Wang, J. F., et al., 2019. Genetic Types and Exploration Potential of Natural Gas in Bohai Bay Basin. Natural Gas Geoscience, 30(6): 783-789 (in Chinese with English abstract). Zhou, L. H., Hua, S. J., Sun, C. N., et al., 2017. Geochemical Characteristics and Secondary Hydrocarbon Generation of Coal-Measure Source Rocks in Upper Paleozoic of Dagang Oilfield. Oil & Gas Geology, 38(6): 1043-1051 (in Chinese with English abstract). 常嘉, 2019. 渤海湾盆地晚古生代含煤地层沉积环境与烃源岩特征研究(硕士学位论文). 青岛: 中国石油大学(华东), 51-53. 尘福艳, 丁文龙, 钱铮, 等, 2013. 冀中坳陷石炭‒二叠系烃源岩埋藏‒生烃史控制因素. 断块油气田, 20(2): 145-149. 尘福艳, 梁宏斌, 丁文龙, 等, 2012. 冀中坳陷东北部石炭‒二叠系沉积相特征及古环境再造. 中国地质, 39(4): 939-946. 尘福艳, 杨创, 谭富荣, 等, 2019. 微量元素分析在判别沉积介质环境中的应用——以冀中坳陷东北部石炭‒二叠系为例. 中国煤炭地质, 31(6): 15-22. 戴金星, 秦胜飞, 陶士振, 等, 2005. 中国天然气工业发展趋势和天然气地学理论重要进展. 天然气地球科学, 16(2): 127-142. 邓胜徽, 卢远征, 赵怡, 等, 2017. 中国侏罗纪古气候分区与演变. 地学前缘, 24(1): 106-142. 冯阵东, 程秀申, 王生朗, 等, 2013. 鲁西地区上古生界煤系烃源岩生烃潜力. 天然气工业, 33(2): 17-21. 郭萍, 2020. 渤海湾盆地冀中坳陷上古生界煤系烃源岩地球化学特征与生烃演化. 天然气地球科学, 31(9): 1306-1315. 黄文魁, 2019. 库车坳陷煤系烃源岩生烃动力学和地球化学特征研究(博士学位论文). 广州: 中国科学院大学(中国科学院广州地球化学研究所). 贾承造, 张永峰, 赵霞, 2014. 中国天然气工业发展前景与挑战. 天然气工业, 34(2): 8-18. 廖前进, 于学敏, 何咏梅, 等, 2003. 大港探区上古生界煤系烃源岩特征及资源潜力. 天然气地球科学, 14(4): 250-253. 刘金钟, 唐永春, 1998. 用干酪根生烃动力学方法预测甲烷生成量之一例. 科学通报, 43(10): 1187-1191. 吕雪莹, 蒋有录, 姜文亚, 等, 2019. 黄骅坳陷中‒古生界原油成因类型与来源. 中国矿业大学学报, 48(6): 1290-1300. 钱铮, 张松航, 梁宏斌, 等, 2015. 冀中坳陷东北部石炭‒二叠系烃源岩生烃潜力评价. 吉林大学学报(地球科学版), 45(5): 1332-1341. 王飞宇, 傅家谟, 刘德汉, 等, 1993. 煤和烃源岩镜质体中超微类脂体检出及意义. 科学通报, 38(2): 151-154. 王永臻, 2020. 冀中坳陷东北部石炭‒二叠系煤成气资源潜力分析及有利区预测(博士学位论文). 北京: 中国地质大学(北京), 23-25. 辛存林, 王露菡, 季健健, 等, 2019. 甘肃窑街植物群的地质时代及古地理区系研究. 地质学报, 93(2): 302-316. 熊永强, 耿安松, 刘金钟, 等, 2002. 生烃动力学模拟实验结合GC-IRMS测定在有效气源岩判识中的应用. 地球化学, 31(1): 21-25. 杨池银, 于学敏, 刘岩, 等, 2014. 渤海湾盆地黄骅坳陷中南部煤系发育区煤成气形成条件及勘探前景. 天然气地球科学, 25(1): 23-32. 曾立飞, 2020. 准噶尔盆地侏罗系煤系烃源岩生烃动力学研究(博士学位论文). 广州: 中国科学院大学(中国科学院广州地球化学研究所), 58-62. 张松航, 梁宏斌, 唐书恒, 等, 2014. 冀中坳陷东北部石炭‒二叠系烃源岩热史及成熟史模拟. 高校地质学报, 20(3): 454-463. 赵长毅, 李永新, 王居峰, 等, 2019. 渤海湾盆地天然气成因类型与勘探潜力分析. 天然气地球科学, 30(6): 783-789. 周立宏, 滑双君, 孙超囡, 等, 2017. 大港油田上古生界煤系烃源岩地球化学特征与二次成烃. 石油与天然气地质, 38(6): 1043-1051. -
