Stratigraphic Framework and Timing Constraints of Early Triassic Nanzhang-Yuan'an Fauna
-
摘要:
海生爬行动物在早三叠世生物复苏过程中遍布在古特提斯洋和西泛大洋，南漳‒远安动物群是早三叠世最早的海生爬行动物群落之一.然而，该动物群的具体生存时代以及所赋存的嘉陵江组地层的沉积时代都还不够明确.在湖北南漳‒远安一带针对南漳‒远安动物群赋存地层开展岩石地层和同位素年代学研究.南漳‒远安动物群产于嘉陵江组二段上部的纹层状灰岩中，并获得SHRIMP Ⅱ U-Pb年龄247.8±1.2 Ma.建立了南漳‒远安地区嘉陵江组上部地层对比格架，证明南漳‒远安动物群生存在早三叠世Spathian晚期.
Abstract:The main marine reptiles spread over the eastern Paleotethys and western Panthalassa Ocean during the biotic recovery in the Early Triassic. The Nanzhang-Yuan'an fauna is one of the earliest marine reptiles in the Early Triassic. However, the specific survival time of this fauna and the fossil-bearing Jialingjiang Formation is still not well defined. Here, it conducted litho-stratigraphy and isotopic dating on the Nanzhang-Yuan'an fauna in the Nanzhang-Yuan'an area of Hubei Province. The fauna is documented in the laminated limestone of the upper Jialingjiang Formation, with a SHRIMP Ⅱ U-Pb age of 247.8±1.2 Ma. The stratigraphic framework for the upper part of the Jialingjiang Formation was established, proving that the Nanzhang-Yuan'an fauna lived in the late Spathian stage of the Early Triassic.
-
Key words:
- Early Triassic /
- Nanzhang-Yuan'an fauna /
- marine reptile /
- SHRIMP Ⅱ /
- stratigraphic correlation /
- geobiology
-
图 1 南漳‒远安动物群古地理位置、地质简图和和剖面位置
a.华南早三叠世奥伦尼克期古地理图，改自Feng et al.（2015）；b.南漳‒远安地区地质简图和研究剖面位置
Fig. 1. The paleogeography, simplified geological map and study locations of the Nanzhang-Yuan'an fauna
图 2 鄂西南漳‒远安地区嘉陵江组二段上部至三段下部地层对比图
Fig. 2. Lithostratigraphic correlation of representative sections in Nanzhang-Yuan'an area
图 3 南漳‒远安地区嘉陵江组野外典型照片
a.张家湾剖面单元C中纹层状灰岩；b.西流坪剖面单元C中包卷层理；c.落星村地区单元C与单元D接触关系，单元D底部为火山灰；d.西流坪剖面单元C与单元E接触关系；e.大石板剖面单元A与单元E接触关系；f.巡检剖面单元E中岩溶角砾岩
Fig. 3. Field photos of the Jialingjiang Formation in Nanzhang-Yuan'an area
图 4 南漳‒远安地区嘉陵江组第三段底部火山灰区域对比
Fig. 4. Volcanic ash beds at lowermost Member Ⅲ of the Jialingjiang Formation in Nanzhang-Yuan'an area
图 5 张家湾剖面火山灰及锆石颗粒阴极发光图像
a.张家湾剖面火山灰层；b.锆石阴极发光图像
Fig. 5. The tuff and СL images of zircons in the Zhangjiawan Section
表 1 张家湾剖面火山灰锆石SHRIMP U-Pb年龄测定结果
Table 1. SHRIMP U-Pb isotopic data for zircons from volcanic ash at the Zhangjiawan Section
Spot no. 206Pbc(%) U (10‒6) Th (10‒6) 232Th/238U 206Pb*(10‒6) 206Pb*/238U（%） σ 207Pb*/235U（%） σ 207Pb*/206Pb*（%） σ 206Pb/238U(Ma) Error corr. 1.1 2.41 278 74 0.28 9.40 0.038 93 1.10 0.280 0 3.9 0.052 2 3.8 246.2±2.9 0.279 2.1 0.70 470 121 0.27 16.1 0.039 57 0.70 0.282 7 2.3 0.051 8 2.2 250.2±1.9 0.301 3.1 1.21 318 80 0.26 10.8 0.038 98 0.84 0.271 6 3.2 0.050 5 3.1 246.5±2.2 0.265 4.1 1.93 313 79 0.26 10.7 0.039 44 1.30 0.285 0 3.9 0.052 4 3.7 249.4±3.3 0.325 5.1 0.84 544 178 0.34 18.6 0.039 70 0.65 0.281 8 2.1 0.051 5 2.0 251.0±1.7 0.309 6.1 3.05 471 149 0.33 16.1 0.039 24 0.68 0.296 7 2.3 0.054 8 2.2 248.1±1.8 0.296 7.1 1.06 303 93 0.32 10.2 0.038 78 0.85 0.280 8 2.9 0.052 5 2.8 245.2±2.2 0.291 8.1 1.32 419 114 0.28 14.3 0.039 45 0.73 0.273 3 2.4 0.050 2 2.3 249.4±1.9 0.299 9.1 1.95 301 76 0.26 10.4 0.039 77 0.86 0.292 3 2.9 0.053 3 2.8 251.4±2.3 0.294 10.1 1.44 421 89 0.22 14.6 0.040 21 0.72 0.274 5 2.7 0.049 5 2.6 254.2±1.9 0.271 11.1 0.91 549 174 0.33 18.9 0.039 76 0.87 0.259 6 2.2 0.047 4 2.0 251.3±2.3 0.394 12.1 1.37 478 122 0.26 16.1 0.038 97 0.66 0.275 0 2.9 0.051 2 2.8 246.5±1.7 0.232 注：误差为1σ，Pbc和Pb*分别为普通Pb和放射成因Pb，用204Pb测量值来矫正普通Pb.
下载: 导出CSV
-
Benton, M. J., Wu, F. X., 2022. Triassic Revolution. Frontiers in Earth Science, 10: 899541. https://doi.org/10.3389/feart.2022.899541 Benton, M. J., Zhang, Q. Y., Hu, S. X., et al., 2013. Exceptional Vertebrate Biotas from the Triassic of China, and the Expansion of Marine Ecosystems after the Permo-Triassic Mass Extinction. Earth-Science Reviews, 125: 199-243. https://doi.org/10.1016/j.earscirev.2013.05.014 Chen, C., Chen, X. H., Cheng, L., et al., 2016. Nanzhang-Yuan'an Fauna, Hubei Province and Its Significance for Biotic Recovery. Acta Geologica Sinica, 90(3): 409-420 (in Chinese with English abstract). Chen, Z. Q., Benton, M. J., 2012. The Timing and Pattern of Biotic Recovery Following the End-Permian Mass Extinction. Nature Geoscience, 5(6): 375-383. https://doi.org/10.1038/ngeo1475 Cheng, L., Moon, B. C., Yan, C. B., et al., 2022. The Oldest Record of Saurosphargiformes (Diapsida) from South China could Fill an Ecological Gap in the Early Triassic Biotic Recovery. Peer J, 10: e13569. https://doi.org/10.7717/peerj.13569 Cheng, L., Motani, R., Jiang, D. Y., et al., 2019. Early Triassic Marine Reptile Representing the Oldest Record of Unusually Small Eyes in Reptiles Indicating Non-Visual Prey Detection. Scientific Reports, 9(1): 152. https://doi.org/10.1038/s41598-018-37754-6 Cheng, L., Yan, C. B., Chen, X. H., et al., 2015. Characteristics and Significance of Nanzhang/Yuanan Fauna, Hubei Province. Geology in China, 42(2): 676-684 (in Chinese with English abstract). Fang, Z. C., Cheng, L., Yan, C. B., 2020. A Review on the Early Triassic Nanzhang-Yuanan Fauna of Hubei Province, South China. South China Geology, 36(1): 80-86 (in Chinese with English abstract). Fang, Z. C., Li, J. L., Yan, C. B., et al., 2023. First Filter Feeding in the Early Triassic: Cranial Morphological Convergence between Hupehsuchus and Baleen Whales. BMC Ecology and Evolution, 23(1): 36. https://doi.org/10.1186/s12862-023-02143-9 Feng, Z. Z., Bao, Z. D., Zheng, X. J., et al., 2015. There was no "Great Bank of Guizhou" in the Early Triassic in Guizhou Province, South China. Journal of Palaeogeography, 4(1): 99-108. https://doi.org/10.3724/SP.J.1261.2015.00070 Grãdinaru, E., Kozur, H., Nicora, A., et al., 2006. The Chiosella timorensis Lineage and Correlation of the Ammonoids and Conodonts around the Base of the Anisian in the GSSP Candidate at Desli Caira (North Dobrogea, Romania). Albertiana, 34: 34-39. Grãdinaru, E., Orchard, M. J., Nicora, A., et al., 2007. The Global Boundary Stratotype Section and Point (GSSP) for the Base of the Anisian Stage: Deşli Caira Hill, North Dobrogea, Romania. Albertiana, 36: 54-67. Lehrmann, D., Payne, J., Enos, P., et al., 2005. Field Excursion 2: Permian-Triassic Boundary and a Lower-Middle Triassic Boundary Sequence on the Great Bank of Guizhou, Nanpanjiang Basin, Southern Guizhou Province. Albertiana, 33: 169-186. Lehrmann, D. J., Stepchinski, L., Altiner, D., et al., 2015. An Integrated Biostratigraphy (Conodonts and Foraminifers) and Chronostratigraphy (Paleomagnetic Reversals, Magnetic Susceptibility, Elemental Chemistry, Carbon Isotopes and Geochronology) for the Permian-Upper Triassic Strata of Guandao Section, Nanpanjiang Basin, South China. Journal of Asian Earth Sciences, 108: 117-135. https://doi.org/10.1016/j.jseaes.2015.04.030 Li, J. L., Liu, J., Li, C., et al., 2002. The Horizon and Age of the Marine Reptiles from Hubei Province, China. Vertebrata Pala Siatica, 40(3): 241-244 (in Chinese with English abstract). Liang, D., Tong, J. N., Zhao, L. S., 2011. Lower Triassic Smithian-Spathian Boundary at West Pingdingshan Section in Chaohu, Anhui Province. Science China Earth Sciences, 54(3): 372-379. https://doi.org/10.1007/s11430-010-4145-2 Liu, Q. L., Cheng, L., Stubbs, T. L., et al., 2023. Rapid Neck Elongation in Sauropterygia (Reptilia: Diapsida) Revealed by a New Basal Pachypleurosaur from the Lower Triassic of China. BMC Ecology and Evolution, 23(1): 44. https://doi.org/10.1186/s12862-023-02150-w Motani, R., 2009. The Evolution of Marine Reptiles. Evolution: Education and Outreach, 2(2): 224-235. https://doi.org/10.1007/s12052-009-0139-y Ovtcharova, M., Goudemand, N., Hammer, Ø., et al., 2015. Developing a Strategy for Accurate Definition of a Geological Boundary through Radio-Isotopic and Biochronological Dating: The Early-Middle Triassic Boundary (South China). Earth-Science Reviews, 146: 65-76. https://doi.org/10.1016/j.earscirev.2015.03.006 Tong, J. N., Chu, D. L., Liang, L., et al., 2019. Triassic Integrative Stratigraphy and Timescale of China. Science China Earth Sciences, 62(1): 189-222. https://doi.org/10.1007/s11430-018-9278-0 Wang, Z. H., Cao, Y. Y., 1981. Early Triassic Conodonts from Lichuan, Western Hubei. Acta Palaeontologica Sinica, 20(4): 363-375, 401-403 (in Chinese with English abstract). Wu, K., Zou, Y. R., Li, H. J., et al., 2023. A Unique Early Triassic (Spathian) Conodont Community from the Nanzhang-Yuan'an Fauna, Hubei Province, South China. Geological Journal, 58(10): 3879-3898. https://doi.org/10.1002/gj.4815 Yan, C. B., Li, J. L., Cheng, L., et al., 2021. Strata Characteristics of the Early Triassic Nanzhang-Yuan'an Fauna in Western Hubei Province. Earth Science, 46(1): 122-135 (in Chinese with English abstract). Yang, C., Fang, Z. C., Cheng, L., et al., 2022. Limbs' Characteristics of Hupehsuchus nanchangensis Young, 1972 (Diapsida: Hupehsuchia) from the Early Triassic of Hubei Province. South China Geology, 38(1): 174-187 (in Chinese with English abstract). Zhao, J. K., Chen, Z. C., Liang, X. L., 1962. Triassic in China. Science Press, Beijing (in Chinese). Zhao, L. S., Chen, Y. L., Chen, Z. Q., et al., 2013. Uppermost Permian to Lower Triassic Conodont Zonation from Three Gorges Area, South China. Palaios, 28(8): 523-540. https://doi.org/10.2110/palo.2012.p12-107r Zhao, L. S., Orchard, M. J., Tong, J. N., et al., 2007. Lower Triassic Conodont Sequence in Chaohu, Anhui Province, China and Its Global Correlation. Palaeogeography, Palaeoclimatology, Palaeoecology, 252(1-2): 24-38. https://doi.org/10.1016/j.palaeo.2006.11.032 Zhao, L. S., Tong, J. N., Sun, Z. M., et al., 2008. A Detailed Lower Triassic Conodont Biostratigraphy and Its Implications for the GSSP Candidate of the Induan-Olenekian Boundary in Chaohu, Anhui Province. Progress in Natural Science, 18(1): 79-90. https://doi.org/10.1016/j.pnsc.2007.07.001 Zheng, L. D., Yao, J. X., Tong, Y. B., et al., 2010. Zircon U-Pb Dating for the Boundary of Olenekian-Anisian at Wangmo, Guizhou Province. Acta Geologica Sinica, 84(8): 1112-1117 (in Chinese with English abstract). 陈粲, 陈孝红, 程龙, 等, 2016. 湖北南漳‒远安动物群及其生物复苏意义. 地质学报, 90(3): 409-420. 程龙, 阎春波, 陈孝红, 等, 2015. 湖北省南漳/远安动物群特征及其意义初探. 中国地质, 42(2): 676-684. 方子晨, 程龙, 阎春波, 2020. 早三叠世南漳‒远安动物群研究进展. 华南地质与矿产, 36(1): 80-86. 李锦玲, 刘俊, 李淳, 等, 2002. 湖北三叠纪海生爬行动物的层位及时代. 古脊椎动物学报, 40(3): 241-244. 王志浩, 曹延岳, 1981. 湖北利川早三叠世牙形刺. 古生物学报, 20(4): 363-375, 401-403. 阎春波, 李姜丽, 程龙, 等, 2021. 鄂西早三叠世南漳‒远安动物群地层分布特征. 地球科学, 46(1): 122-135. doi: 10.3799/dqkx.2020.023 杨晨, 方子晨, 程龙, 等, 2022. 早三叠世南漳湖北鳄(双孔类: 湖北鳄目)的四肢特征. 华南地质, 38(1): 174-187. 赵金科, 陈震楚, 梁希洛, 1962. 中国的三叠系. 北京: 科学出版社. 郑连弟, 姚建新, 仝亚博, 等, 2010. 贵州南部地区安尼阶底界锆石SHRIMP年龄结果. 地质学报, 84(8): 1112-1117. -
