Tectonic Deformation and New Viewpoint on Age of the Biluoco Oil Shale Stratum in Qiangtang Basin
-
摘要: 受多期逆冲、伸展构造运动及泥页岩、膏岩等塑性变形影响，羌塘盆地毕洛错含油页岩地层（简称毕洛错地层）变形极为复杂，加之古生物化石时代和同位素年代学结果存在争议，严重制约了对地层岩性组合与时代归属的认识.针对毕洛错地层复杂的构造变形，开展了详细的构造观测与剖面测量，并根据逆冲-褶皱变形特征开展地层追索与对比，将毕洛错地层自下而上分出3段7类岩性组合.对下段砂岩与中段玄武岩分别开展锆石U-Pb同位素测试、锆石结构与成因分析，获得下段与中段最大沉积年龄分别为166 Ma和154 Ma.综合区域背景，认为毕洛错地层时代至少为中侏罗世巴通期至晚侏罗世提塘期，顶部可能为早白垩世贝里阿斯期.毕洛错含油页岩地层时代的确定，为羌塘盆地油气勘探、区域沉积构造演化和大洋缺氧等问题的研究提供了新依据.Abstract: Influenced by multi-phase thrusting,extensional tectonic movements,and the plastic deformation of mudstone,shale,and gypsum,the deformation of the Biluoco oil shale stratum (BLS) in the Qiangtang basin is extremely complex. Additionally,controversies surrounding paleontological fossil evidence and isotopic geochronology have severely constrained the understanding of the lithological assemblages and their temporal attribution. In response to the intricate structural deformation of BLS,this study conducted detailed structural observations and profile measurements. Based on the thrust-fold system,the stratum was traced and correlated,dividing into three segments with seven types of lithological assemblages from bottom to top. Zircon U-Pb isotopic testing,along with zircon structure and genetic analysis,was performed on the sandstone of the lower segment and the basalt of the middle segment,yielding maximum depositional ages of 166 Ma and 154 Ma,respectively. Integrating regional context,it is concluded that the age of BLS ranges at least from the Middle Jurassic Bathonian to the Late Jurassic Tithonian,with the top possibly extending to the Early Cretaceous Berriasian. The determination of the age for BLS provides new insights for hydrocarbon exploration in the Qiangtang basin,as well as for studies on sedimentary tectonic evolution and oceanic anoxic events.
-
图 1 羌塘盆地构造位置(a)、油页岩与主断裂分布(b)和早侏罗-新近纪地层单元划分(c)
图 1b中断层与岩浆岩为实际观测；图 1c中（1）和（4）据王剑等（2020）修改，（2）据王永胜等（2012）修改，（3）据Ma et al.（2017）修改
Fig. 1. Simplified geological map (a), distribution of oil shale and faults (b) and the Early Jurassic to Neogene stratigraphic framework (c) of Qiangtang basin
图 2 毕洛错地区地质图(a)和构造地质剖面图(b, c)
Fig. 2. Geological map (a) and structural profiles (b, c) of the Biluoco area
图 3 毕洛错地区构造变形特征
a.索日卡-董布拉宏观构造变形特征(镜向东); b.索日卡-毕洛错逆冲断层宏观构造变形特征(镜向北东); c.巴欧那一带逆冲断层和褶皱变形特征(镜向东); d.毕洛错地区东西向宏观构造变形特征(镜向北西); e.PM12厚层油页岩宏观特征；f. PM03厚层油页岩宏观特征; g.观测点G07处厚层油页岩特征; h.PM14厚层油页岩宏观特征; i.观测点G01处厚层油页岩特征; j.观测点G08泥岩夹泥灰岩特征: k.观测点G09石膏夹灰岩: (l) 观测点G10砂岩夹泥灰岩; m.董布拉逆冲断层; n.毕洛错逆冲断层及拖曳褶皱; o.PM14处毕洛错断层主断面; p.索日卡逆冲断层上盘灰岩发育断坪-断坪; q.巴欧纳2期砾岩及逆冲断层现象; r.巴欧纳山顶E内部小型双重叠瓦状逆冲断层; s.毕洛错逆冲断层破碎带，砾岩呈叠瓦状产出; t.巴欧纳背斜核部转折端; u.巴欧纳向斜核部; v.巴欧纳山顶灰岩、碎屑岩组成背斜; w.巴欧纳向斜核部灰岩内部发育双重叠瓦状逆冲断层; x.巴欧纳向斜核部灰岩发育多组走滑构造；y.灰岩夹层中的菊石化石点及毕洛错向斜
Fig. 3. The structural deformation characteristics of the Biluoco area
图 4 毕洛错地层岩性组合与剖面特征
i，j，l，m.据沈安江等（2023）修改；k为本文赴实物中心重新编录；o，n为本文实测并结合Xia et al.（2021）修编；其余为本文实测；井深单位：m
Fig. 4. Comparison of lithologic assemblages and profiles of the BLS
图 5 砂岩和玄武岩锆石成因划分及形态
Fig. 5. REE chondrite-normalized distribution pattern for sandstone and basalts of the BLS
表 1 毕洛错地层砂岩最年轻年龄
Table 1. The comparison of the youngest detrital zircon ages calculated by different methods of sandstone from the BLS
样号 有效测点数 YDZ YSG YPP YC1σ(2+)/颗粒数 YC2σ(3+)/颗粒数 22957 78 147.5+6.3/-12 146.92±5 168 168.0±2.3(n=6) 155.3±8.2(n=4) 15BL06 76 170.4+5.1/-7.8 172±3 174 174.6±3.4(n=4) 174.6±3.4(n =4) 15BL12 60 169.2+6.2/-14 171±3 170.8 171.7±5.1(n =3) 171.7±5.1(n =3) 注：YDZ.Isoplot计算的最年轻年龄; YSG.最年轻的单颗粒锆石; YPP.最年轻频谱图峰值年龄(Isoplot成图); YC1σ(2+)/两颗以上最年轻锆石在1σ误差下的加权平均年龄; YC2σ(3+)/3颗以上最年轻锆石在2σ误差下的加权平均年龄(Dickinson and Gehrels, 2009)，均使用Isoplot 4.15计算.15BL06和15BL12引自 Ma et al.(2017) ；单位：Ma.
下载: 导出CSV
-
Belousova, E. A., González Jiménez, J. M., Graham, I., et al., 2015. The Enigma of Crustal Zircons in Upper-Mantle Rocks: Clues from the Tumut Ophiolite, Southeast Australia. Geology, 43(2): 119-122. https://doi.org/10.1130/g36231.1 Bi, Z. W., Li, Z. M., Li, Q., et al., 2018. The Discovery of the Upper Jurassic to Lower Cretaceous Marine Strata on the Southwestern Margin of the Qiangtang Block. Sedimentary Geology and Tethyan Geology, 38(1): 1-10 (in Chinese with English abstract). Chen, L., Mattioli, E., Da, X. J., et al., 2019. Calcareous Nannofossils from the Jurassic Black Shales in the Qiangtang Basin, Northern Xizang (China): New Records of Stratigraphic Ages and Palaeoceanography. Newsletters on Stratigraphy, 52(1): 55-72. https://doi.org/10.1127/nos/2018/0464 Chen, L., Mattioli, E., Da, X. J., et al., 2023. Integrated Carbon-Isotope and Calcareous Nannofossil Stratigraphy in the Middle Jurassic of Qinghai-Xizang (China). Newsletters on Stratigraphy, 56(4): 405-421. https://doi.org/10.1127/nos/2023/0714 Cheng, J. B., Li, Y. L., He, H. Y., et al., 2021. Late Jurassic Nb-Enriched Basalts from the Bilong Co Area in the Southern Qiangtang Terrane, Central Tibet, and Their Implications. Geological Journal, 57(1): 358-379. https://doi.org/10.1002/gj.4302 Corfu, F., Hachar, J. M., Hoskin, P. W. O., et al., 2003. Atlas of Zircon Textures. Reviews in Mineralogy and Geochemistry, 53(1): 469-500. https://doi.org/10.2113/0530469 Dickinson, W. R., Gehrels, G. E., 2009. Use of U-Pb Ages of Detrital Zircons to Infer Maximum Depositional Ages of Strata: A Test against a Colorado Plateau Mesozoic Database. Earth and Planetary Science Letters, 288(1-2): 115-125. https://doi.org/10.1016/j.epsl.2009.09.013 Fu, X. G., Wang, J., Feng, X. L., et al., 2016. Early Jurassic Carbon-Isotope Excursion in the Qiangtang Basin (Tibet), the Eastern Tethys: Implications for the Toarcian Oceanic Anoxic Event. Chemical Geology, 442: 62-72. https://doi.org/10.1016/j.chemgeo.2016.09.007 Fu, X. G., Wang, J., Wen, H. G., et al., 2020. Carbon-Isotope Record and Paleoceanographic Changes Prior to the OAE 1a in the Eastern Tethys: Implication for the Accumulation of Organic-Rich Sediments. Marine and Petroleum Geology, 113: 104049. https://doi.org/10.1016/j.marpetgeo.2019.104049 Fu, X. G., Wang, J., Zeng, S. Q., et al., 2017. Continental Weathering and Palaeoclimatic Changes through the Onset of the Early Toarcian Oceanic Anoxic Event in the Qiangtang Basin, Eastern Tethys. Palaeogeography, Palaeoclimatology, Palaeoecology, 487: 241-250. https://doi.org/10.1016/j.palaeo.2017.09.005 Gao, Y., Wu, Z. H., Zuo, J. M., et al., 2024. Spatial-Temporal Activity of Quaternary Faults at Southern End of Nyalam-Coqen Rift, Southern Tibet. Earth Science, 49(7): 2552-2569(in Chinese with English abstract). Gehrels, G., Kapp, P., DeCelles, P., et al., 2011. Detrital Zircon Geochronology of Pre-Tertiary Strata in the Tibetan-Himalayan Orogen. Tectonics, 30(5): 2011TC002868. https://doi.org/10.1029/2011TC002868 Gong, J. H., Wang, Z. Q., Wang, D. S., et al., 2020. A Discussion on Genesis, Provenance and U-Pb Ages of the Zircons from Ultrabasic-Basic Rocks: A Case Study in Western Jiangnan Orogenic Belt. Geological Review, 66(6): 1536-1554(in Chinese with English abstract). He, H. Y., Li, Y. L., Ning, Z. J., et al., 2020. Transition from Oceanic Subduction to Continental Collision in Central Tibet: Evidence from the Cretaceous Magmatism in Qiangtang Block. International Geology Review, 64(4): 545-563. https://doi.org/10.1080/00206814.2020.1867912 Hoskin, P. W. O., 2005. Trace-Element Composition of Hydrothermal Zircon and the Alteration of Hadean Zircon from the Jack Hills, Australia. Geochimica et Cosmochimica Acta, 69(3): 637-648. https://doi.org/10.1016/j.gca.2004.07.006 Li, Y. L., He, J., Wang, C. S., et al., 2015. Cretaceous Volcanic Rocks in South Qiangtang Terrane: Products of Northward Subduction of the Bangong-Nujiang Ocean? Journal of Asian Earth Sciences, 104: 69-83. https://doi.org/10.1016/j.jseaes.2014.09.033 Lu, X. S., Gui, L. L., Chen, W. Y., et al., 2023. Improvement of In Situ LA-ICP-MS U-Pb Dating Method for Carbonate Minerals and Its Application in Petroleum Geology. Science China Earth Sciences, 66(12): 2914-2929. https://doi.org/10.1007/s11430-022-1072-2 Ma, A. L., Hu, X. M., Garzanti, E., et al., 2017. Sedimentary and Tectonic Evolution of the Southern Qiangtang Basin: Implications for the Lhasa-Qiangtang Collision Timing. Journal of Geophysical Research: Solid Earth, 122(7): 4790-4813. https://doi.org/10.1002/2017JB014211 Ma, A. L., Hu, X. M., Garzanti, E., et al., 2023. Paleogeographic and Tectonic Evolution of Mesozoic Qiangtang Basins (Tibet). Tectonophysics, 862: 229957. https://doi.org/10.1016/j.tecto.2023.229957 McDonough, W. F., Sun, S. S., 1995. The Composition of the Earth. Chemical Geology, 120(3-4): 223-253. https://doi.org/10.1016/0009-2541(94)00140-4 Sharman, G. R., Malkowski, M. A., 2020. Needles in a Haystack: Detrital Zircon U-Pb Ages and the Maximum Depositional Age of Modern Global Sediment. Earth-Science Reviews, 203: 103109. https://doi.org/10.1016/j.earscirev.2020.103109 Shen, A. J., Fu, X. D., Zhang, J. Y., et al., 2023. Characteristics and Discovery Significance of the Upper Triassic-Lower Jurassic Marine Shale Oil in Qiangtang Basin, NW China. Petroleum Exploration and Development, 50(5): 962-974(in Chinese with English abstract). Su, T. N., Zhang, W. Z., Zhang, S. Q., et al., 2007. Geologic Features of Gypsum Strata in the Middle Part of Buqu Formation, Biluocuo Area, Tibet. Jilin Geology, 26(2): 10-13 (in Chinese with English abstract). Wang, J., Fu, X. G., Du, A. D., et al., 2007. Organic Geochemistry and Re-Os Dating of Marine Oil Shale in Shenglihe Area, Northern Tibet, China. Marine Origin Petroleum Geology, 12(3): 21-26(in Chinese with English abstract). Wang, J., Fu, X. G., Tan, F. W., et al., 2020. Strategic Investigation of Oil and Gas Resources in Qiangtang Basin. Science Press, Beijing(in Chinese). Wang, L. C., Garzanti, E., Peng, H., et al., 2024. Discovery of the Callovian Oceanic Anoxic Event in the Qiangtang Basin, Eastern Tethys: Insights from In Situ Calcite U-Pb Dating. Palaeogeography, Palaeoclimatology Palaeoecology, 656(1-3): 112572. https://doi.org/10.1016/j.palaeo.2024.112572 Wang, Y. S., Zhang, S. Q., Xie, Y. H., 2012.1: 250 000 Regional Geological Survey Report of the Angdar Co Sheet, People's Republic of China. China University of Geosciences Press, Wuhan (in Chinese). Wang, Y. S., Zheng, C. Z., 2008. Gypsum Beds of the Early Jurassic Quse Formation in the Biloucuo Area of the Southern Qiangtang Basin, Northern Xizang. Journal of Stratigraphy, 32(3): 321-326 (in Chinese with English abstract). Wu, R. Z., Hu, C. Z., Wang, C. S., et al., 1985. The Stratigraphical System of Qangtang District in Northern Xizang (Tibet). Contribution to the Geology of the Qinghai-Xizang (Tibet) Plateau, 9: 1-32 (in Chinese). Wu, Y. B., Zheng, Y. F., 2004. Genesis of Zircon and Its Constraints on Interpretation of U-Pb Age. Chinese Science Bulletin, 49(15): 1554-1569. https://doi.org/10.1007/bf03184122 Wu, Z. H., Ji, C. J., Zhao, Z., et al., 2019a. Main Source Rock and Oil Resource Potential of the Bandaohu-Donghu Area in the Northern Qiangtang Basin. Acta Geologica Sinica, 93(7): 1738-1753 (in Chinese with English abstract). Wu, Z. H., Zhao, Z., Ji, C. J., et al., 2019b. Atlas of Nappe Structure and Its Effect to Petroliferous Sequence in Central Qiangtang Block, Northern Tibet. : China University of Geosciences Press, Wuhan(in Chinese). Wu, Z. H., Zhao, Z., Ji, C. J., et al., 2021. Geological Time of Marine Source Rocks in the Woruoshan Mountain and Its Adjacent Areas, Northern Qiangtang Depression. Acta Geologica Sinica, 95(2): 352-361 (in Chinese with English abstract). Xia, G. Q., Mansour, A., Gentzis, T., et al., 2021. Depositional Paleoenvironment and Source Rock Characterization across the Toarcian Oceanic Anoxic Event from the Eastern Tethys, Tibet, SW China. International Journal of Coal Geology, 243: 103780. https://doi.org/10.1016/j.coal.2021.103780 Xue, W. W., Ma, A. L., Hu, X. M., 2020. The Redefinition of the Jurassic-Cretaceous Lithostratigraphic Framework in the Qiangtang Basin, Xizang Plateau. Geological Review, 66(5): 1114-1129(in Chinese with English abstract). Yang, F., Han, H. W., Bian, T. Y., et al., 2024. Identification of Zircons of Different Origin in Complex Rock Mass and Its Implications for Zircon U-Pb Age: A Case Study from Zircon of Archean Basement in Liaohe Depression. Chinese Journal of Geology, 59(5): 1308-1325 (in Chinese with English abstract). Yi, H. S., Lin, J. H., Zhao, B., et al., 2003. New Biostratigraphic Data of the Qiangtang Area in the Northern Tibetan Plateau. Geological Review, 49(1): 59-65 (in Chinese with English abstract). Yin, J. R., 2021. A Revision and New Data on the Jurassic Ammonites from the Biluoco Area, Southern Qiangtang Block (North Tibet). Newsletters on Stratigraphy, 54(4): 1-19. https://doi.org/10.1127/nos/2021/0648 Yin, J. R., 2024. Comment on Zhang et al. New Age Constraints of the Bilong Co Oil Shale in the Qiangtang Basin, Northern Tibet: Evidence from In Situ U-Pb Dating and Palaeontology. Minerals 2024, 14, 246. Minerals, 14(8): 777. https://doi.org/10.3390/min14080777 Zhang, H. W., Wang, J., Mansour, A., et al., 2024. New Age Constraints of the Bilong Co Oil Shale in the Qiangtang Basin, Northern Tibet: Evidence from In Situ U-Pb Dating and Palaeontology. Minerals, 14(3): 246. https://doi.org/10.3390/min14030246 Zhang, K. X., Song, B. W., He, W. H., et al., 2025. Distribution and Evolution of the Tethyan OPS in the Central-Southern Qinghai-Xizang Region. Earth Science, 50(3): 1162-1200(in Chinese with English abstract). Zhang, L. L., Zhao, Z., Yang, Y. Z., et al., 2025. Fluid Inclusion Characteristics and the Hydrocarbon Accumulation Stages of the Middle Jurassic Buqu Formation in the Qiangtang Basin. Acta Geoscientica Sinica, 46(3): 683-693(in Chinese with English abstract). Zhao, Z., Wu, Z. H., Yang, Y. Z., et al., 2020. Establishing the Chronostratigraphic Framework of the Continental Red Beds in Central Qiangtang Basin: Constrained by Zircon U-Pb Ages. Geological Review, 66(5): 1155-1171 (in Chinese with English abstract). Zhao, Z., Wu, Z. H., Yu, J. Q., et al., 2019. Thrust Structures of the Nima-Rongma Area in the Qiangtang Block, Tibetan Plateau. Acta Geologica Sinica, 93(8): 1849-1866 (in Chinese with English abstract). Zhao, Z. Z., Li, Y. T., Ye, H. F., et al., 2001. Stratigraphy of the Tibetan Plateau. Science Press, Beijing(in Chinese). Zi, J. W., Rasmussen, B., Muhling, J. R., et al., 2022. In Situ U-Pb and Geochemical Evidence for Ancient Pb-Loss during Hydrothermal Alteration Producing Apparent Young Concordant Zircon Dates in Older Tuffs. Geochimica et Cosmochimica Acta, 320: 324-338. https://doi.org/10.1016/j.gca.2021.11.038 毕志伟, 李志敏, 李强, 等, 2018. 羌塘地块西南缘上侏罗统-下白垩统海相地层的发现. 沉积与特提斯地质, 38(1): 1-10. 高扬, 吴中海, 左嘉梦, 等, 2024. 藏南聂拉木-措勤裂谷南段第四纪正断层作用的时空特征. 地球科学, 49(7): 2552-2569. doi: 10.3799/dqkx.2023.009 宫江华, 王宗起, 王东升, 等, 2020. 对超基性-基性岩中锆石成因、来源及其U-Pb年龄的探讨: 以江南造山带西段为例. 地质论评, 66(6): 1536-1554. 沈安江, 付小东, 张建勇, 等, 2023. 羌塘盆地上三叠统-下侏罗统海相页岩油特征及发现意义. 石油勘探与开发, 50(5): 962-974. 苏铁牛, 张维忠, 张树岐, 等, 2007. 西藏比洛错一带布曲组中段膏盐地层的地质特征. 吉林地质, 26(2): 10-13. 王剑, 付修根, 杜安道, 等, 2007. 羌塘盆地胜利河海相油页岩地球化学特征及Re-Os定年. 海相油气地质, 12(3): 21-26. 王剑, 付修根, 谭富文, 等, 2020. 羌塘盆地油气资源战略调查. 北京: 科学出版社. 王永胜, 张树岐, 谢元和, 等. 2012. 中华人民共和国昂达尔错幅1: 25万区域地质调查报告. 武汉: 中国地质大学出版社. 王永胜, 郑春子, 2008. 藏北南羌塘盆地毕洛错地区下侏罗统曲色组石膏岩层. 地层学杂志, 32(3): 321-326. 吴瑞忠, 胡承祖, 王成善, 等, 1985. 藏北羌塘地区地层系统. 青藏高原地质文集, 9: 1-32. 吴珍汉, 季长军, 赵珍, 等, 2019a. 羌塘盆地半岛湖-东湖地区主力烃源岩及油气资源潜力. 地质学报, 93(7): 1738-1753. 吴珍汉, 赵珍, 季长军, 等. 2019b. 羌塘推覆构造与油气地质图集. 武汉: 中国地质大学出版社. 吴珍汉, 赵珍, 季长军, 等, 2021. 北羌塘凹陷沃若山及邻区海相烃源岩形成时代. 地质学报, 95(2): 352-361. 薛伟伟, 马安林, 胡修棉, 2020. 羌塘盆地侏罗系—白垩系岩石地层格架厘定. 地质论评, 66(5): 1114-1129. 杨飞, 韩宏伟, 边天一, 等, 2024. 复杂岩体中锆石的成因判识及其对锆石U-Pb年龄的影响: 以辽河坳陷太古宇基底中的锆石为例. 地质科学, 59(5): 1308-1325. 伊海生, 林金辉, 赵兵, 等, 2003. 藏北羌塘地区地层新资料. 地质论评, 49(1): 59-65. 张克信, 宋博文, 何卫红, 等, 2025. 青藏中-南部特提斯洋板块地层分布与演化. 地球科学, 50(3): 1162-1200. doi: 10.3799/dqkx.2024.147 张莉莉, 赵珍, 杨易卓, 等, 2025. 羌塘盆地中侏罗统布曲组包裹体特征及油气成藏期次研究. 地球学报, 46(3): 683-693. 赵珍, 吴珍汉, 杨易卓, 等, 2020. 羌塘中部陆相红层时代的U-Pb年龄约束. 地质论评, 66(5): 1155-1171. 赵珍, 吴珍汉, 于俊秋, 等, 2019. 西藏中部尼玛-荣玛地区逆冲推覆构造特征. 地质学报, 93(8): 1849-1866. 赵政璋, 李永铁, 叶和飞, 等, 2001. 青藏高原地层. 北京: 科学出版社. -
