Runout Simulation and Disaster Amplification of Dehenglong Paleolandslide-Dammed Lake-Outburst Flood Chain in the Upper Yellow River
-
摘要:
位于青藏高原东北缘的黄河上游峡谷段发育了大量巨型古滑坡-堰塞湖-溃决洪水灾害链，厘清其运动演化过程对防控此类灾害链具有重要意义.在野外调查基础上，通过构建深度平均滑坡-堵河运动学模型与考虑颗粒物运移及物理侵蚀沉积机制的溃决洪水动力学耦合模型，以其中典型的德恒隆巨型滑坡灾害链为例开展模拟研究，系统分析了滑坡堵河-堰塞湖蓄水-溃决洪水的完整运动学过程.结果表明：德恒隆滑坡体积达35亿m3，峰值平均速度约44.5 m/s，总滑移时长约120 s，形成堰塞坝高达234 m，堵塞黄河形成面积约280 km2、库容约232.3亿m3的巨型堰塞湖；堰塞坝溃决过程持续约100 h，洪峰流量达23.8万m3/s，洪水沿黄河河道波及下游900 km流域，最高洪水位达158 m.相比于滑坡本身的运动距离，本次巨型滑坡-堵河-溃坝洪水灾害链波及了上下游约1 000 km河道范围内的广大区域，具有显著的灾害放大效应.研究成果可为黄河流域滑坡灾害链的风险评估与防灾决策提供科学依据.
Abstract:The upper Yellow River canyon on the northeastern margin of the Tibetan Plateau has developed numerous giant paleo-landslide-dammed lake-outburst flood disaster chains. Understanding their kinematic evolution is crucial for mitigating such cascading hazards. Based on field investigations, this study constructs a depth-averaged landslide damming kinematic model and a coupled outburst flood dynamics model incorporating sediment transport and physical erosion/deposition mechanisms, using the typical Dehenglong giant landslide disaster chain as a case study. The simulation systematically analyzes the entire kinematic process, including landslide damming, lake formation, and dam breaching. The results indicate that the Dehenglong landslide had a volume of 3.50 billion m3, reached a peak average velocity of 44.5 m/s, and had a total sliding duration of 120 s. This formed a 234 m-high dam that blocked the Yellow River, creating a giant dammed lake with an area of 280 km2 and a storage capacity of 23.23 billion m3. The dam breach lasted 100 h, with a peak discharge of 238 300 m3/s. The resulting flood propagated 900 km downstream along the Yellow River, reaching a maximum water level of 158 m. Compared to the landslide movement distance itself, this giant landslide-damming-outburst flood disaster chain affected a vast area spanning approximately 1 000 km of the river channel, exhibiting a significant disaster amplification effect. The findings of this study provide a scientific basis for risk assessment and disaster prevention decision-making regarding landslide disaster chains along the Yellow River Basin.
-
Key words:
- depth-averaged model /
- giant landslide /
- disaster chain /
- full-process simulation /
- engineering geology
-
图 1 滑坡地理位置(a)、区域地质图(b)及地质剖面图(c)
Fig. 1. Geographical location (a), regional geological map (b), and geological cross-section of the landslide (c)
图 2 德恒隆滑坡区卫星影像(a)和滑坡全景图(b)
Fig. 2. Satellite imagery of the Dehenglong landslide area (a); panoramic view of the landslide (b)
图 3 不同摩擦系数和粘聚力条件下的滑坡堆积体厚度分布
蓝点为河道参考点；黑点为坝体最低点；虚线为实际滑坡主体范围
Fig. 3. Distribution of landslide deposit thickness under varying friction coefficients and cohesion conditions
图 5 堰塞湖面积与坝高关系曲线(a); 堰塞湖体积与坝高关系曲线(b)
Fig. 5. Relationship between landslide-dam lake area and dam height (a); relationship between landslide-dam lake volume and dam height (b)
图 7 堰塞坝溃决程度-时间曲线(a)；侵蚀速率-时间曲线(b)
Fig. 7. Temporal evolution of landslide-dam breach extent (a); erosion rate-time relationship(b)
图 9 德恒隆滑坡坝溃决洪水最大水深（不计黄河基础水深）及监测分布
Fig. 9. Maximum floodwater depth and monitoring distribution during the Dehenglong landslide-dam breach
表 1 物理力学参数
Table 1. Physical and mechanical parameters
摩擦系数μ 粘聚力(kPa) 密度(kg/m3) 0.12 20 2 490
下载: 导出CSV
表 2 溃决洪水模拟参数
Table 2. Simulation parameters of collapse flood
n α β φs φd ρs (kg/m3) e 0.038 1.00 0.10 0.577 0.462 2 490 0.32
下载: 导出CSV
表 3 溃口流量估计参数
Table 3. Crash flow estimation parameters
Hd (m) V1 (m3) g (m/s2) a 234 23 230×106 9.81 1.236
下载: 导出CSV
-
Bai, S. B., Cui, P., Ge, Y. G., 2021. 10Be and 26Al Exposure Dating Study of the Dehenglong Giant Landslide in the Upper Reaches of the Yellow River. In Proceedings of the 2021 Chinese Geoscience Union Meeting (Volume 37), 97-100 (in Chinese). Dai, X. J., Yin, Y. P., Xing, A. G., 2019. Simulation and Dynamic Analysis of Yigong Rockslide-Debris Avalanche-Dam Breaking Disaster Chain. The Chinese Journal of Geological Hazard and Control, 30(5): 1-8 (in Chinese with English abstract). Duan, Y. X., Zhang, T. F., 2022. The Effects of Interaction on Landslide Stability. Statistics and Application, 11(6): 1313-1317 (in Chinese with English abstract). doi: 10.12677/SA.2022.116136 Fan, X. M., Yang, F., Siva Subramanian, S., et al., 2020. Prediction of a Multi-Hazard Chain by an Integrated Numerical Simulation Approach: The Baige Landslide, Jinsha River, China. Landslides, 17(1): 147-164. https://doi.org/10.1007/s10346-019-01313-5 Guo, X. H., 2017. Relationship between Landslide-Dammed Lakes with the Evolution of Upper Stream of The Yellow River from Longyang Gorge to Liujia Gorge on Northeast Margin of Tibet Plateau (Dissertation). Chang'an University, Xi'an (in Chinese with English abstract). Guo, X. H., Lu, Y. D., Li, X. L., et al., 2015. Event of Block up of Upper Yellow River by Dehenglong-Suozi Landslides. Journal of Jilin University (Earth Science Edition), 45(6): 1789-1797(in Chinese with English abstract). Ji, Y. Q., 2024. Tectonic Geomorphology and Genetic Mechanism of Giant Landslides from Lagan Gorge to Liujia Gorge in the Upper Reaches of the Yellow River (Dissertation). Chang'an University, Xi'an (in Chinese with English abstract). Jia, K. C., Zhuang, J. Q., Zhan, J. W., et al., 2023. Reconstruction of the Dynamic Process of the Holocene Gelongbu Landslide-Blocking-Flood Geological Disaster Chain Based on Numerical Simulation. Earth Science, 48(9): 3402-3419 (in Chinese with English abstract). Jin, Z., Yu, X., Li, Z. H., et al., 2024. Scientific Investigation on the Entire Yellow River Basin: Understanding and Reflections. China Water Resources, (23): 7-11, 6 (in Chinese with English abstract). Lan, H. X., Peng, J. B., Zhu, Y. B., et al., 2022. Research on Geological and Surfacial Processes and Major Disaster Effects in the Yellow River Basin. Scientia Sinica (Terrae), 52(2): 199-221 (in Chinese). doi: 10.1360/SSTe-2021-0115 Li, J., Su, A. J., 2018. Numerical Simulation of Dam-Break Flood for Tangjiashan Landslide Dam. Water Resources and Power, 36(8): 56-59, 147 (in Chinese with English abstract). Li, S., Peng, M., Gao, L., et al., 2024. A 3D SPH Framework for Simulating Landslide Dam Breaches by Coupling Erosion and Side Slope Failure. Computers and Geotechnics, 175: 106699. https://doi.org/10.1016/j.compgeo.2024.106699 Li, S., Peng, M., Shi, Z. M., et al., 2025. Simulation and Analysis of Cascading Hazard Based on Fluid-Soil Coupled SPH Method. Earth Science, 50(10): 3967-3981 (in Chinese with English abstract). Li, X. L., Guo, X. H., Li, W. H., 2011. Mechanism of Giant Landslides from Longyangxia Valley to Liujiaxia Valley along Upper Yellow River. Journal of Engineering Geology, 19(4): 516-529 (in Chinese with English abstract). Li, Y. C., Guo, S. F., Zheng, B. W., et al., 2025. Analysis of Ancient Rongcharong Landslide Dam Failure Events in the Suwalong Reach of the Upper Reaches of the Jinsha River. Journal of Earth Science, 36(5): 2005-2022. https://doi.org/10.1007/s12583-024-0052-x Liu, W., He, S. M., 2020. Numerical Simulation of the Evolution Process of Disaster Chain Induced by Potential Landslide in Woda of Jinsha River Basin. Advanced Engineering Sciences, 52(2): 38-46 (in Chinese with English abstract). Ma, C. Y., Peng, M., Yang, J. T., et al., 2025. A Breaching Model for Landslide Dams Involving Size-Selective Erosion and Breach Evolution. Engineering Geology, 355: 108235. https://doi.org/10.1016/j.enggeo.2025.108235 Mei, S. Y., Zhong, Q. M., Chen, S. S., et al., 2023. Numerical Simulation of Breach Hydrograph and Morphology Evolution during Landslide Dam Breaching. Earth Science, 48(4): 1634-1648 (in Chinese with English abstract). Peng, J. B., Ma, R. Y., Lu, Q. Z., et al., 2004. Geological Hazards Effects of Uplift of Qinghai-Tibet Plateau. Advance in Earth Sciences, 19(3): 457-466 (in Chinese with English abstract). Peng, J. B., Wang, F. Y., Xu, J. S., 2025. Basin Layered Structure and Urban Geological Safety. Earth Science, 50(8): 3117-3131 (in Chinese with English abstract). Peng, M., Zhang, L. M., 2012. Breaching Parameters of Landslide Dams. Landslides, 9(1): 13-31. https://doi.org/10.1007/s10346-011-0271-y Wang, H. M., Luan, J. K., Ma, N., 2024. Hydrodynamic Modelling of Flash Flood Processes in the Typical Regions in the Upper Yellow River Basin. Journal of Beijing Normal University (Natural Science), 60(4): 519-528 (in Chinese with English abstract). Xia, X. L., Jarsve, K. T., Dijkstra, T., et al., 2023. An Integrated Hydrodynamic Model for Runoff-Generated Debris Flows with Novel Formulation of Bed Erosion and Deposition. Engineering Geology, 326: 107310. https://doi.org/10.1016/j.enggeo.2023.107310 Xia, X. L., Liang, Q. H., 2018. A New Depth-Averaged Model for Flow-Like Landslides over Complex Terrains with Curvatures and Steep Slopes. Engineering Geology, 234: 174-191. https://doi.org/10.1016/j.enggeo.2018.01.011 Yang, Z. W., Wu, B. B., Liu, W. M., et al., 2025. Progress in Erosion Mechanism and Geomorphological Effects of High-Energy Outburst Floods. Earth Science, 50(2): 718-736 (in Chinese with English abstract). Yin, Z. Q., Wei, G., Qin, X. G., et al., 2021. Research Progress on Landslides and Dammed Lakes in the Upper Reaches of the Yellow River, Northeastern Tibetan Plateau. Earth Science Frontiers, 28(2): 46-57 (in Chinese with English abstract). Zhou, M. J., Shi, Z. M., Peng, C., et al., 2024. Two-Phase Modelling of Erosion and Deposition Process during Overtopping Failure of Landslide Dams Using GPU-Accelerated ED-SPH. Computers and Geotechnics, 166: 105944. https://doi.org/10.1016/j.compgeo.2023.105944 Zhu, Q. Y., Jiang, N., Chen, Q., et al., 2023. DEM-SPH Simulation for the Formation and Breaching of a Landslide-Dammed Lake Triggered by the 2022 Lushan Earthquake. Landslides, 20(9): 1925-1941. https://doi.org/10.1007/s10346-023-02096-6 白世彪, 崔鹏, 葛永刚, 2021. 黄河上游德恒隆巨型滑坡10Be和26Al暴露年代研究. 见: 2021年中国地球科学联合学术年会论文集(三十七), 97-100. 戴兴建, 殷跃平, 邢爱国, 2019. 易贡滑坡-碎屑流-堰塞坝溃坝链生灾害全过程模拟与动态特征分析. 中国地质灾害与防治学报, 30(5): 1-8. 段颖星, 张天芳, 2022. 交互效应对滑坡稳定性的影响. 统计学与应用, 11(6): 1313-1317. 郭小花, 2018. 龙羊峡-刘家峡河段巨型滑坡堵河事件与黄河演化之间的关系(博士学位论文). 西安: 长安大学. 郭小花, 卢玉东, 李小林, 等, 2015. 黄河上游德恒隆-锁子滑坡堵塞黄河事件. 吉林大学学报(地球科学版), 45(6): 1789-1797. 纪一奇, 2024. 黄河上游拉干峡至刘家峡段构造地貌及巨型滑坡成因机理研究(博士学位论文). 西安: 长安大学. 贾珂程, 庄建琦, 占洁伟, 等, 2023. 基于数值模拟的戈龙布滑坡-堵江-溃决洪水地质灾害链动力学过程重建. 地球科学, 48(9): 3402-3419. doi: 10.3799/dqkx.2021.124 金钊, 余欣, 李振洪, 等, 2024. 黄河全流域科学考察的几点认识和思考. 中国水利(23): 7-11, 6. 兰恒星, 彭建兵, 祝艳波, 等, 2022. 黄河流域地质地表过程与重大灾害效应研究与展望. 中国科学: 地球科学, 52(2): 199-221. 李敬, 苏爱军, 2018. 唐家山滑坡坝溃坝洪水数值模型研究. 水电能源科学, 36(8): 56-59, 147. 李爽, 彭铭, 石振明, 等, 2025. 基于水土耦合SPH方法的滑坡-堵江-成坝灾害链全过程动力演化模拟. 地球科学, 50(10): 3967-3981. doi: 10.3799/dqkx.2025.112 李小林, 郭小花, 李万花, 2011. 黄河上游龙羊峡-刘家峡河段巨型滑坡形成机理分析. 工程地质学报, 19(4): 516-529. 刘威, 何思明, 2020. 金沙江沃达潜在滑坡诱发灾害链成灾过程数值模拟. 工程科学与技术, 52(2): 38-46. 梅胜尧, 钟启明, 陈生水, 等, 2023. 堰塞体溃决流量与溃口形态演化数值模拟. 地球科学, 48(4): 1634-1648. 彭建兵, 马润勇, 卢全中, 等, 2004. 青藏高原隆升的地质灾害效应. 地球科学进展, 19(3): 457-466. 彭建兵, 王飞永, 徐继山, 2025. 盆地圈层结构与城市地质安全. 地球科学, 50(8): 3117-3131. doi: 10.3799/dqkx.2025.093 王慧敏, 栾金凯, 马宁, 2024. 基于水动力模型的黄河上游典型地区暴雨洪水过程模拟. 北京师范大学学报(自然科学版), 60(4): 519-528. 杨泽文, 吴兵兵, 刘维明, 等, 2025. 高能溃决洪水侵蚀机理与地貌效应研究进展. 地球科学, 50(2): 718-736. doi: 10.3799/dqkx.2024.009 殷志强, 魏刚, 秦小光, 等, 2021. 青藏高原东北缘黄河上游滑坡与堰塞湖研究进展. 地学前缘, 28(2): 46-57. -
