Forming Conditions and Failure Mechanism of Clustered High-Position Ancient Landslides in Linka Township, Basu County, Tibet Autonomous Region, China
-
摘要:
藏东南地处青藏高原东南缘，板块构造活跃、地形起伏剧烈，大型高位古滑坡密集分布.为进一步揭示藏东南大型高位古滑坡的孕灾机制，以八宿县林卡乡为研究区，通过高分辨率遥感影像解译，识别和厘定古滑坡边界，建立林卡乡古滑坡编目数据集；基于GIS空间分析和数据统计，查明林卡乡古滑坡群的空间分布特征与主控孕灾因子；通过现场调查、无人机航拍和地球物理勘探，揭示典型大型高位古滑坡的形成机制.结果表明，八宿县林卡乡境内共发育51处高位古滑坡，其中50处为大型滑坡，古滑坡聚集分布于深切河谷的谷坡之上.岩性和地形起伏度是控制该区域古滑坡分布的关键因素，砂板岩地层和起伏度介于1 000~1 600 m的陡峻地形对古滑坡的发育最有利.对林卡乡孜嘎村附近4处大型高位古滑坡的调查分析表明，其均为弯曲倾倒-拉裂滑移型破坏.由于林卡乡境内砂板岩地层普遍具有中-陡倾的薄-中厚层状结构，为典型的易倾倒岩体，且已探明古滑坡的主滑方向多与区域地层的优势倾向一致或相反，符合弯曲倾倒所致滑坡的典型运动特征，推测岩层长期的弯曲倾倒变形是造成林卡乡古滑坡群聚发育的重要因素，倾倒岩体的拉裂滑移是区域内古滑坡的主要破坏机制.
Abstract:Southeast Tibet, located at the southeastern margin of the Qinghai-Tibet Plateau, is characterized by active plate tectonics and intense topographic relief, making it a high-incidence area for large high-position landslides. To investigate the forming mechanisms of large high-position landslides in Southeast Tibet, ancient landslides in Linka Township, Basu County, were identified through remote sensing interpretation to establish a landslide inventory. GIS-based spatial analysis and statistical methods were then applied to characterize their spatial distribution and determine the dominant controlling factors. Finally, four representative high-position ancient landslides near Ziga Village were selected for field investigation to further examine their forming mechanisms. Remote sensing interpretation identifies 51 high-position ancient landslides, all located on deeply incised valley flanks, primarily concentrated along the slopes of the Nujiang and Waqu rivers. Statistical analysis reveals that lithology and topographic relief are the primary environmental controls on their distribution. Ancient landslides are most likely to develop in sandstone-slate strata and in areas with relief between 1 000 and 1 600 m. Field investigations of four typical ancient landslides near Ziga Village in Linka Township reveal that they all developed in fragmented rock masses induced by long-term flexural toppling. The widespread occurrence of moderately to steeply dipping, layered, weakly metamorphosed sandstone and slate—typical topple-prone rock masses—in the landslide areas of Linka Township, combined with the sliding directions of ancient landslides generally aligning with or opposing the dominant bedding orientation, suggests that toppling was likely a widespread pre-existing failure mechanism prior to the formation of these ancient landslides.
-
图 1 研究区地质与地貌条件概况
a. 八宿县区域地质背景（修改自Wang et al.，2023；张培震等，2003）；b. 八宿县遥感影像（修改自二十一世纪空间技术应用股份有限公司，世纪空间卫星影像图（2024版）（GS（2024）1614号），
https://www.21at.com.cn ）；c. 八宿县典型地形剖面（基于ALOS 12.5 m数字高程模型）Fig. 1. Overview of geological and geomorphic conditions of the study area
图 2 典型古滑坡几何形态特征
遥感影像来源：二十一世纪空间技术应用股份有限公司，世纪空间卫星影像图（2024版）（GS（2024）1614号），
https://www.21at.com.cn Fig. 2. Morphological characteristics of typical ancient landslides
图 3 林卡乡古滑坡空间分布特征与几何特征统计
a. 古滑坡分布与Kernel密度统计图；b. 古滑坡数量-面积统计；c. 古滑坡面积-长度关系统计；d. 古滑坡面积-高度统计；e. 古滑坡面积-高长比H/L统计
Fig. 3. Spatial distribution and geometric characteristics statistics of ancient landslides in Linka Township
图 4 环境因子空间分布特征
a. 高程；b. 坡度；c. 坡向；d. 地形起伏度；e. 地表粗糙度TRI；f. 剖面曲率；g. 平面曲率；h. 地形位置指数TPI；i. 距断层距离；j. 岩性
Fig. 4. Spatial distribution of environmental factors
图 6 古滑坡分布主控条件因子统计
Fig. 6. Statistics on primary controlling factors of ancient landslide distribution
图 7 林卡乡孜嘎村及邻区地质地貌条件
修改自中国地质调查局，2019，全国1∶200 000数字地质图（公开版）空间数据库（V1），
http://dcc.ngac.org.cn/geologicalData/rest/geologicalData/geologicalDataDetail/7d7ac63df9805f39a92591d105b7b0f2 Fig. 7. Geological and geomorphic conditions of Ziga Village in Linka Township and adjacent areas
图 8 孜嘎村后山滑坡平剖面图与典型变形破坏特征
a. 平面图；b. 剖面图；c. 滑坡后壁特征；d. 滑坡堆积体前缘特征；e. 堆积体前缘岩性分界；f. 堆积体侧壁岩性分界；g. 滑坡右侧岩体弯曲倾倒特征；h. 滑坡右侧河谷河流阶地特征
Fig. 8. Plan view and longitudinal section of Ziga Village backhill landslide with typical failure characteristics
图 9 孜嘎村瓦曲河右岸滑坡平剖面图与典型变形破坏特征
a. 平面图；b. 剖面图；c. 滑坡后壁特征；d. 滑坡堆积体特征；e. 堆积体右侧岩体露头特征
Fig. 9. Plan view and longitudinal section of Ziga Village north-bank landslide with typical failure characteristics
图 10 孜嘎村西侧滑坡典型特征
a. 西侧1#滑坡全貌；b. 西侧1#滑坡滑源区遥感影像；c. 西侧1#滑坡堆积区沉积的紫红色砂岩块体；d. 西侧2#滑坡全貌；e. 西侧2#滑坡滑源区遥感影像；f. 西侧2#滑坡源区岩体露头特征
Fig. 10. Typical failure characteristics of landslides on the west side of Ziga Village
图 11 林卡乡古滑坡主滑方向与域内岩层倾向关系统计
a. 古滑坡主滑方向玫瑰花图；b. 古滑坡分布区岩层倾向玫瑰花图（数据来自中国地质调查局，2019，全国1∶200 000数字地质图（公开版）空间数据库（V1），
http://dcc.ngac.org.cn/geologicalData/rest/geologicalData/geologicalDataDetail/7d7ac63df9805f39a92591d105b7b0f2 ）Fig. 11. Relationship between main slip directions of ancient landslides and bedding dip directions in Linka Township
图 12 倾倒岩体的拉裂-滑移破坏过程物理模拟（修改自宁奕冰等，2021）
Fig. 12. Physical simulation of the toppling failure process
-
Dai, F. C., Deng, J. H., 2020. Development Characteristics of Landslide Hazards in Three-Rivers Basin of Southeast Tibetan Plateau. Advanced Engineering Sciences, 52(5): 3-15 (in Chinese with English abstract). Dou, J., Xiang, Z. L., Xu, Q., et al., 2023. Application and Development Trend of Machine Learning in Landslide Intelligent Disaster Prevention and Mitigation. Earth Science, 48(5): 1657-1674 (in Chinese with English abstract). Dou, J., Xing, K., Wang, L. Z., et al., 2025. Air-Space-Ground Synergistic Observations for Rapid Post-Seismic Disaster Assessment of 2025 Ms6.8 Xigazê Earthquake, Xizang. Journal of Earth Science, 36(4): 1605-1622. https://doi.org/10.1007/s12583-025-0160-2 Evans, J. D., 1996. Straightforward Statistics for the Behavioral Sciences. Brooks/Cole Publishing, Pacific Grove. Feng, C. J., Chen, Q. C., Li, G. Q., et al., 2014. In-Situ Stress Measurement in Lijiang-Jianchuan Area and Tentative Discussion on the Seismic Hazards on the Southeastern Margin of the Tibetan Plateau. Geological Bulletin of China, 33(4): 524-534 (in Chinese with English abstract). Guo, Y. H., Dou, J., Xiang, Z. L., et al., 2024. Susceptibility Evaluation of Wenchuan Coseismic Landslides by Gradient Boosting Decision Tree and Random Forest Based on Optimal Negative Sample Sampling Strategies. Bulletin of Geological Science and Technology, 43(3): 251-265 (in Chinese with English abstract). He, K., Wang, Y. F., Cheng, Q. G., et al., 2024. Research on the Substrate Entrainment Dynamics of Rock Avalanches: State-of-the-Art. Journal of Engineering Geology, 32(3): 904-917 (in Chinese with English abstract). Hsü, K. J., 1975. Catastrophic Debris Streams (Sturzstroms) Generated by Rockfalls. Geological Society of America Bulletin, 86(1): 129-140. https://doi.org/10.1130/0016-7606(1975)86<129:CDSSGB>2.0.CO;2 doi: 10.1130/0016-7606(1975)86<129:CDSSGB>2.0.CO;2 Huang, D., Ma, H., Huang, R. Q., 2022. Deep-Seated Toppling Deformations of Rock Slopes in Western China. Landslides, 19(4): 809-827. https://doi.org/10.1007/s10346-021-01829-9 Huang, R. Q., Wang, Y. S., Wang, S. T., et al., 2011. High Geo-Stress Distribution and High Geo-Stress Concentration Area Models for Eastern Margin of Qinghai-Tibet Plateau. Science China Technological Sciences, 54(1): 154-166. https://doi.org/10.1007/s11431-011-4652-1 Hungr, O., Leroueil, S., Picarelli, L., 2014. The Varnes Classification of Landslide Types, an Update. Landslides, 11(2): 167-194. https://doi.org/10.1007/s10346-013-0436-y Larsen, I. J., Montgomery, D. R., Korup, O., 2010. Landslide Erosion Controlled by Hillslope Material. Nature Geoscience, 3(4): 247-251. https://doi.org/10.1038/ngeo776 Li, B., Gao, Y., Zhuang, Y., et al., 2025. Characteristics and Cascading Effects of the Blatten Avalanche in the Swiss Alps. Earth Science, 50(12): 4950-4969(in Chinese with English abstract). Lin, Q. W., Cheng, Q. G., Li, K., et al., 2023. Review on Fragmentation-Related Dynamics of Rock Avalanches. Journal of Engineering Geology, 31(3): 815-829 (in Chinese with English abstract). Liu, J. C., Wang, W. P., Gao, Y., et al., 2024. Study on the Unstable Characteristics of High-Level Landslide in Zelongnong Gou, Xizang under Severe Earthquakes. The Chinese Journal of Geological Hazard and Control, 35(6): 15-23 (in Chinese with English abstract). Long, X. Y., Hu, Y. X., Gan, B. R., et al., 2024. Numerical Simulation of the Mass Movement Process of the 2018 Sedongpu Glacial Debris Flow by Using the Fluid-Solid Coupling Method. Journal of Earth Science, 35(2): 583-596. https://doi.org/10.1007/s12583-022-1625-1 Ma, S. Y., Shao, X. Y., Xu, C., et al., 2024. Distribution Pattern, Geometric Characteristics and Tectonic Significance of Landslides Triggered by the Strike-Slip Faulting 2022 Ms 6.8 Luding Earthquake. Geomorphology, 453: 109138. https://doi.org/10.1016/j.geomorph.2024.109138 Ning, Y. B., Tang, H. M., Zhang, B. C., et al., 2021. Evolution Process and Failure Mechanism of a Deep-Seated Toppling Slope in the Lancang River Basin. Chinese Journal of Rock Mechanics and Engineering, 40(11): 2199-2213 (in Chinese with English abstract). Pánek, T., Břežný, M., Havenith, H. B., et al., 2024. Landslides and Growing Folds: A Lesson from the Kura Fold- and -Thrust Belt (Azerbaijan, Georgia). Geomorphology, 449: 109059. https://doi.org/10.1016/j.geomorph.2024.109059 Pang, J. F., Ding, X. Z., Han, K. Y., et al., 2017. The National 1∶1 000 000 Geological Map Spatial Database. Geology in China, 44(S1): 8-18, 125-138(in Chinese). Shi, A. W., Cheng, Q. G., Wang, Y. F., et al., 2024. State of the Art on Fluidized Geomorphology of Rock Avalanche. Journal of Engineering Geology, 32(3): 978-995 (in Chinese with English abstract). Shugar, D. H., Jacquemart, M., Shean, D., et al., 2021. A Massive Rock and Ice Avalanche Caused the 2021 Disaster at Chamoli, Indian Himalaya. Science, 373(6552): 300-306. https://doi.org/10.1126/science.abh4455 Smith, J. V., 2015. Self-Stabilization of Toppling and Hillside Creep in Layered Rocks. Engineering Geology, 196: 139-149. https://doi.org/10.1016/j.enggeo.2015.07.008 Wang, Y. F., Chen, P. H., Qian, J. Z., et al., 2025. Geomorphic and Geologic Controls on Large-Scale Landslides in the Himalayan Region of China. Landslides, 22(5): 1725-1741. https://doi.org/10.1007/s10346-024-02447-x Wang, Y. F., Cheng, Q. G., Lin, Q. W., et al., 2023. Rock Avalanches in the Tibetan Plateau of China. In: Alcántara-Ayala, I., et al., Progress in Landslide Research and Technology, Volume 2 Issue 2, 2023. Springer Nature Switzerland, Cham: 55-111. https://doi.org/10.1007/978-3-031-44296-4_2 Wang, Y. F., Cheng, Q. G., Lin, Q. W., et al., 2025. Research on Rock Avalanches in Tibetan Plateau: From Field Observations to Dynamic Mechanisms. Earth Science, 50(10): 4071-4095 (in Chinese with English abstract). Wang, Y. F., Ming, J., Feng, Z. Y., et al., 2022. Research on the Fluidized Propagation and Frictional Heating Effect of the Luanshibao Rock Avalanche. Chinese Journal of Rock Mechanics and Engineering, 41(S2): 3174-3188 (in Chinese with English abstract). Xing, K., Li, H., Zhang, L. L., et al., 2025. Analysis of Surface Rupture and Seismic Damage Characteristics of 2025 Dingri Ms6.8 Earthquake in Xizang. Safety and Environmental Engineering, 32(2): 20-30 (in Chinese with English abstract). Xu, Q., Zheng, G., Li, W. L., et al., 2018. Study on Successive Landslide Damming Events of Jinsha River in Baige Village on Octorber 11 and November 3, 2018. Journal of Engineering Geology, 26(6): 1534-1551 (in Chinese with English abstract). Yin, Y. P., 2000. Study on the Characteristics and Disaster Mitigation of the Gigantic Landslide on the Yigong Expressway in Bomi, Tibet. Hydrogeology & Engineering Geology, 27(4): 8-11 (in Chinese with English abstract). Yin, Y. P., Gao, S. H., 2024. Research on High-Altitude and Long-Runout Rockslides: Review and Prospects. The Chinese Journal of Geological Hazard and Control, 35(1): 1-18 (in Chinese with English abstract). Yin, Y. P., Wang, W. P., Zhang, N., et al., 2017. Long Runout Geological Disaster Initiated by the Ridge-Top Rockslide in a Strong Earthquake Area: A Case Study of the Xinmo Landslide in Maoxian County, Sichuan Province. Geology in China, 44(5): 827-841 (in Chinese with English abstract). Zhang, B. C., Ning, Y. B., Tang, H. M., et al., 2023. Study on the Evolutionary Process of Interbedded Anti-Inclined Slope Block-Flexure Toppling in the Upper Yalong River. Bulletin of Engineering Geology and the Environment, 82(7): 240. https://doi.org/10.1007/s10064-023-03223-2 Zhang, P. Z., Deng, Q. D., Zhang, G. M., et al., 2003. Active Tectonic Blocks and Strong Earthquakes in the Continent of China. Scientia Sinica (Terrae), 33(S1): 12-20 (in Chinese). Zhang, Y. S., Ren, S. S., Li, J. Q., et al., 2023. Prone Sliding Geo-Structure and High-Position Initiating Mechanism of Duolasi Landslide in Nu River Tectonic Mélange Belt. Earth Science, 48(12): 4668-4679 (in Chinese with English abstract). Zheng, D. F., Li, Y. Y., Yan, C. L., et al., 2025. Landslide Susceptibility Assessment Using AutoML-SHAP Method in the Southern Foothills of Changbai Mountain, China. Landslides, 22(6): 1855-1875. https://doi.org/10.1007/s10346-025-02462-6 戴福初, 邓建辉, 2020. 青藏高原东南三江流域滑坡灾害发育特征. 工程科学与技术, 52(5): 3-15. 窦杰, 向子林, 许强, 等, 2023. 机器学习在滑坡智能防灾减灾中的应用与发展趋势. 地球科学, 48(5): 1657-1674. 丰成君, 陈群策, 李国歧, 等, 2014. 青藏高原东南缘丽江-剑川地区地应力测量与地震危险性. 地质通报, 33(4): 524-534. 郭衍昊, 窦杰, 向子林, 等, 2024. 基于优化负样本采样策略的梯度提升决策树与随机森林的汶川同震滑坡易发性评价. 地质科技通报, 43(3): 251-265. 何可, 王玉峰, 程谦恭, 等, 2024. 高速远程滑坡底部裹挟机理研究现状及展望. 工程地质学报, 32(3): 904-917. 李滨, 高杨, 庄宇, 等, 2025. 瑞士瓦莱州Blatten高位远程崩滑碎屑流成灾特征与级联放大效应. 地球科学, 50(12): 4950-4969. doi: 10.3799/dqkx.2025.239 林棋文, 程谦恭, 李坤, 等, 2023. 高速远程滑坡碎屑化运动机理研究综述. 工程地质学报, 31(3): 815-829. 刘俊辰, 王文沛, 高杨, 等, 2024. 强震条件下西藏则隆弄沟高位滑坡失稳特征研究. 中国地质灾害与防治学报, 35(6): 15-23. 宁奕冰, 唐辉明, 张勃成, 等, 2021. 澜沧江深层倾倒体演化过程及失稳机制研究. 岩石力学与工程学报, 40(11): 2199-2213. 庞健峰, 丁孝忠, 韩坤英, 等, 2017. 1∶100万中华人民共和国数字地质图空间数据库. 中国地质, 44(增刊1): 8-18, 125-138. 史安文, 程谦恭, 王玉峰, 等, 2024. 高速远程滑坡流态化地貌研究综述. 工程地质学报, 32(3): 978-995. 王玉峰, 明杰, 冯止依, 等, 2022. 乱石包高速远程滑坡流态化运动模式及摩擦热效应研究. 岩石力学与工程学报, 41(增刊2): 3174-3188. 王玉峰, 程谦恭, 林棋文, 等, 2025. 青藏高原高速远程滑坡研究: 从地质现象到动力学机理. 地球科学, 50(10): 4071-4095. doi: 10.3799/dqkx.2025.207 邢珂, 黎昊, 张乐乐, 等, 2025.2025年西藏定日MS6.8地震地表破裂与震害特征分析. 安全与环境工程, 32(2): 20-30. 许强, 郑光, 李为乐, 等, 2018.2018年10月和11月金沙江白格两次滑坡-堰塞堵江事件分析研究. 工程地质学报, 26(6): 1534-1551. 殷跃平, 2000. 西藏波密易贡高速巨型滑坡特征及减灾研究. 水文地质工程地质, 27(4): 8-11. 殷跃平, 高少华, 2024. 高位远程地质灾害研究: 回顾与展望. 中国地质灾害与防治学报, 35(1): 1-18. 殷跃平, 王文沛, 张楠, 等, 2017. 强震区高位滑坡远程灾害特征研究: 以四川茂县新磨滑坡为例. 中国地质, 44(5): 827-841. 张培震, 邓起东, 张国民, 等, 2003. 中国大陆的强震活动与活动地块. 中国科学(D辑: 地球科学), 33(增刊1): 12-20. 张永双, 任三绍, 李金秋, 等, 2023. 怒江构造混杂岩带多拉寺滑坡的易滑地质结构及高位启滑运动机制. 地球科学, 48(12): 4668-4679. doi: 10.3799/dqkx.2023.017 -
