Mechanisms and Predictive Modeling of Ball-Valve Actuating force in Pressure-Preserved Coring Tools
-
摘要: 保压取心钻具对深海资源评价与开发至关重要，其密封球阀的关闭性能直接决定原位岩心样品获取成败. 针对球阀驱动力受多因素耦合影响、精确量化困难的问题，本文融合试验与机器学习展开驱动力多因素定量预测研究. 通过全面析因试验，获取温度、密封圈类型及润滑剂粘度等多水平工况下的驱动力数据，系统分析各因素主效应及交互效应. 结果表明，润滑剂粘度是首要影响因素，且与温度存在强烈耦合作用. 基于此，结合数据增强技术并采用梯度提升回归算法构建多因素预测模型，模型R2值达0.99以上. 量化评估显示关键特征重要性排序与试验分析趋势一致，验证了方法有效性. 研究结果可为深海保压取心钻具球阀密封系统优化设计和材料选型提供可靠依据.Abstract: Pressure-Preserved Coring Tools are critical to deep-sea resource assessment and development, and the closure performance of their sealing ball valve directly determines the success of acquiring in situ core samples. Addressing the difficulty of accurately quantifying the ball-valve actuating force under multi-variable interaction effects, this study integrates experiments with machine learning to achieve quantitative prediction across multiple factors. Through comprehensive factorial experiments, we obtain driving-force data under multi-level operating conditions involving temperature, seal-ring type, and lubricant viscosity, and systematically analyze main effects and interactions. The results indicate that lubricant viscosity is the primary influencing factor, exhibiting strong coupling with temperature. Building on these findings, we employ data-augmentation techniques and a gradient boosting regressor to construct a multi-factor prediction model. The model attains an R2 exceeding 0.99, and quantitative feature-importance analysis yields a ranking consistent with experimental trends, validating the effectiveness of the approach. The results provide a reliable basis for the optimized design and materials selection of sealing systems in deep-sea Pressure-Preserved Coring Tools.
-
图 2 保压取心钻具密封阀主要结构
a. 转轴偏置球阀；b. 齿轮-齿条球阀（卢春华等，2023）；c. 翻板密封阀
Fig. 2. Main structure of the ball valve of the pressure-preserved coring tool
图 3 保压取心钻具工况对比
a. 球阀翻转到位获取了水合物保压岩心；b. 球阀翻转密封失败
Fig. 3. Comparison of operating conditions forpressure-preserved coring tool
图 4 密封球阀运动过程力学分析
a.球阀完全开启；b. 球阀闭合阶段；c. 球阀完全闭合
Fig. 4. Mechanical analysis of the sealing ball valve's motion process
图 10 润滑剂粘度与温度的交互效应
Fig. 10. Interaction effect between lubricant viscosity and temperature
图 11 润滑剂粘度与密封圈类型的交互效应
Fig. 11. Interaction effect between lubricant viscosity and seal type
图 16 驱动力三维预测曲面
a.NBR驱动力预测曲面；b.PTFE驱动力预测曲面
Fig. 16. Actuating force 3D response surface plot
表 1 试验因素与水平
Table 1. Experimental factors and levels
因素代号 因素名称 水平1 水平2 水平3 水平4 A 温度(℃) 20 10 4 0 B 密封圈类型 NBR PTFE - - C 运动粘度(cSt) 0 (无润滑) 45 220 -
下载: 导出CSV
表 2 预测模型设定参数值
Table 2. Setting parameter values of prediction model
超参数 最优值 树的数量 100 收缩系数 0.1 最大深度 3 随机种子 42
下载: 导出CSV
表 3 地温12.5 ℃条件下的球阀工程参数建议
Table 3. Recommended engineering parameters for ball valves under 12.5 ℃ ground temperature conditions
序号 密封圈类型 润滑剂粘度(cSt) 预测驱动力(N) 建议 1 PTFE 43.1 126.9 性能最优方案 2 NBR 29.8 155.8 NBR的最优选择
下载: 导出CSV
-
Abegg, F., Hohnberg, H. J., Pape, T., et al., 2008. Development and Application of Pressure-Core-Sampling Systems for the Investigation of Gas- and Gas-Hydrate-Bearing Sediments. Deep Sea Research Part I: Oceanographic Research Papers, 55(11): 1590-1599. https://doi.org/10.1016/j.dsr.2008.06.006 Abid, K., Spagnoli, G., Teodoriu, C., et al., 2015. Review of Pressure Coring Systems for Offshore Gas Hydrates Research. Underwater Technology, 33(1): 19-30. https://doi.org/10.3723/ut.33.019 Al-besharah, J. M., Salman, O. A., Akashah, S. A., 1987. Viscosity of Crude Oil Blends. Industrial & Engineering Chemistry Research, 26(12): 2445-2449. https://doi.org/10.1021/ie00072a010 Cui, B. L., Lin, Z., Zhu, Z. C., et al., 2017. Influence of Opening and Closing Process of Ball Valve on External Performance and Internal Flow Characteristics. Experimental Thermal and Fluid Science, 80: 193-202. https://doi.org/10.1016/j.expthermflusci.2016.08.022 Dugan, B., Germaine, J. T., 2008. Near-Seafloor Overpressure in the Deepwater Mississippi Canyon, Northern Gulf of Mexico. Geophysical Research Letters, 35(2): L02304. https://doi.org/10.1029/2007gl032275 Fan, Q., Zhu, Z., Pang, W., et al., 2024. Reservoir Characteristics and Exploration Implications of Gas Hydrate-Rich Areas in the Qiongdongnan Basin. Earth Science, 49(4): 1421-1430 (in Chinese with English abstract). Gao, M., Song, J., Cui, P., et al., 2024. In-situ Pressure-Retaining Coring and Gas-Retaining Technology and Its Preliminary Application in Deep Coal Seams. Coal Science and Technology, 52(4): 143-154 (in Chinese with English abstract). Guo, D., Chen, L., Zhou, Z. Y., et al., 2023. Development of a Pressure Coring System for the Investigation of Deep Underground Exploration. International Journal of Mining Science and Technology, 33(11): 1351-1364. https://doi.org/10.1016/j.ijmst.2023.10.001 Han, Z. L., Li, X. Y., Zhao, M., et al., 2024. Analysis of Working Dynamics of Ball Valve with Pressure Core Sampler. Drilling Engineering, 51(6): 32-38 (in Chinese with English abstract). Itoh, S., Fukuzawa, K., Hamamoto, Y., et al., 2009. Temperature Dependence of Viscoelasticity of PFPE Lubricant Confined in Nanometer-Sized Gaps. STLE/ASME 2008 International Joint Tribology Conference, October 20-22, 2008, Miami, Florida, USA. 697-699. https://doi.org/10.1115/IJTC2008-71169 Kubo, Y., Mizuguchi, Y., Inagaki, F., et al., 2014. A New Hybrid Pressure-Coring System for the Drilling Vessel Chikyu. Scientific Drilling, 17: 37-43. https://doi.org/10.5194/sd-17-37-2014 Li, Q. P., Zhou, S. W., Zhao, J. F., et al., 2022. Research Status and Prospects of Natural Gas Hydrate Exploitation Technology. Chinese Journal of Engineering Science, 24(3): 214 (in Chinese with English abstract). doi: 10.15302/J-SSCAE-2022.03.022 Liu, G. P., Jiang, S. Q., Jin, Y. P., et al., 2025. Mechanism of Low-Disturbance and High-Pressure-Retaining Sampling of Seafloor Sediments at 10 000-Meter Depth and Its Laboratory Experiment and On-Site Sea Trials. International Journal of Mining Science and Technology, 35(11): 1871-1884. https://doi.org/10.1016/j.ijmst.2025.06.001 Lu, Q. P., Qin, R. L., Yu, Y. J., et al., 2024. The Design and Application of a New Wireline Pressure Coring System for the Guangzhou Marine Geological Survey Methane Hydrate Expedition in the South China Sea. Applied Sciences, 14(15): 6753. https://doi.org/10.3390/app14156753 Lu, C. H., Zhang, T., Xu, J., et al., 2023. Development and Experiment of Pressure Core Sampler for Marine Natural Gas Hydrates. Drilling Engineering, 50(6): 18-26 (in Chinese with English abstract). Santamarina, J. C., Dai, S., Jang, J., et al., 2012. Pressure Core Characterization Tools for Hydrate-Bearing Sediments. Scientific Drilling, 14: 44-48. https://doi.org/10.5194/sd-14-44-2012 Schultheiss, P. J., Francis, T. J. G., Holland, M., et al., 2006. Pressure Coring, Logging and Subsampling with the HYACINTH System. Geological Society, London, Special Publications, 267(1): 151-163. https://doi.org/10.1144/gsl.sp.2006.267.01.11 Schultheiss, P., Holland, M., Humphrey, G., 2009. Wireline Coring and Analysis under Pressure: Recent Use and Future Developments of the HYACINTH System. Scientific Drilling, 7: 44-50. https://doi.org/10.5194/sd-7-44-2009 Tommasi, P., Avalle, A., Budillon, F., et al., 2019. Evaluation of Disturbance Induced on Soft Offshore Sediments by Two Types of Gravity Piston Coring Techniques. Marine Geology, 417: 106005. https://doi.org/10.1016/j.margeo.2019.106005 Wan, C. Y., Zhang, H. E., Li, L., et al., 2024. Current Status and Techniques of Equipment for Depressurization Exploitation of Marine Natural Gas Hydrate. China Petroleum Machinery, 52(10): 83-90 (in Chinese with English abstract). Wang, J. L., Sun, Y., Qian, D. L., et al., 2022. Scheme Design and Performance Analysis of Thin-Walled Pressure-Retaining Coring Tools for Seafloor Drills in the Deep-Sea Operating Environment. Journal of Petroleum Science and Engineering, 208: 109790. https://doi.org/10.1016/j.petrol.2021.109790 Wang, T. Y., Li, J. N., Zhang, Y. W., et al., 2023. Sealing Performance Analysis and Structure Optimization of Pressure-Preserved Controller for Pressure-Preserved Coring in Deep Coal Mine. Coal Geology & Exploration, 51(8): 88-97 (in Chinese with English abstract). Wang, W. Z., Huang, P., 2004. Study on the Lubrication State of Frictional Pairs with Different Surface Roughness Based on Stribeck Curves. Tribology, 24(3): 254-257(in Chinese with English abstract). Wu, N. H., Xie, H. P., Chen, L., et al., 2020. Sealing Form and Failure Mechanism of Deep in Situ Rock Core Pressure-Maintaining Controller. Geofluids, 2020: 8892720. https://doi.org/10.1155/2020/8892720 Xie, H. P., Cui, P. F., Shang, D. L., et al., 2023. Research Advances on the In-situ Pressure-Preserved Coring and Gas Parameter Determination for Deep Coal Seams. Coal Geology & Exploration, 51(8): 1-12 (in Chinese with English abstract). Yamamoto, K., 2015. Overview and Introduction: Pressure Core-Sampling and Analyses in the 2012-2013 MH21 Offshore Test of Gas Production from Methane Hydrates in the Eastern Nankai Trough. Marine and Petroleum Geology, 66: 296-309. https://doi.org/10.1016/j.marpetgeo.2015.02.024 Yang, L. W., Su, Y., Luo, J., et al., 2020. Development of GW-CP194-80A Pressure-Retaining Coring Tool. Natural Gas Industry, 40(4): 91-96 (in Chinese with English abstract). Zhang, X. H., Ji, H., Yu, T., et al., 2025. Water-Lubricated Frictional Behaviour Enhanced by Small Quantity of Secondary Lubricating Medium of Thordon Material. Tribology, 45(4): 571-581(in Chinese with English abstract). Zhao, Y., Liu, H., Cai, J., et al., 2023. Development and Application of TKP194-80 Pressure-Retaining Coring Tool. Exploration Engineering, 50(4): 77-83(in Chinese with English abstract). Zhu, H. Y., Liu, Q., Deng, J. G., et al., 2011. Pressure and Temperature Preservation Techniques for Gas-Hydrate-Bearing Sediments Sampling. Energy, 36(7): 4542-4551. https://doi.org/10.1016/j.energy.2011.03.053 樊奇, 朱振宇, 庞维新, 等, 2024. 琼东南盆地水合物富集区储层特征及勘探启示. 地球科学, 49(4): 1421-1430. 高明忠, 宋杰, 崔鹏飞, 等, 2024. 深部煤层原位保压保瓦斯取心技术装备及初步应用. 煤炭科学技术, 52(4): 143-154. 韩泽龙, 李小洋, 赵明, 等, 2024. 保压取心钻具球阀工作动力学分析. 钻探工程, 51(6): 32-38. 李清平, 周守为, 赵佳飞, 等, 2022. 天然气水合物开采技术研究现状与展望. 中国工程科学, 24(3): 214-224. 卢春华, 张涛, 徐俊, 等, 2023. 海域天然气水合物保压取心钻具的研制与试验. 钻探工程, 50(6): 18-26. 万春燕, 张贺恩, 李磊, 等, 2024. 海洋天然气水合物降压开采装备现状与技术探讨. 石油机械, 52(10): 83-90. 王天宇, 李佳南, 张益玮, 等, 2023. 深部煤矿保压取心保压控制器密封性能分析与结构优化. 煤田地质与勘探, 51(8): 88-97. 王慰祖, 黄平, 2004. 不同表面粗糙度的摩擦副润滑状态的Stribeck曲线研究. 摩擦学学报, 24(3): 254-257. 谢和平, 崔鹏飞, 尚德磊, 等, 2023. 深部煤层原位保压取心技术原理与瓦斯参数测定研究进展. 煤田地质与勘探, 51(8): 1-12. 杨立文, 苏洋, 罗军, 等, 2020. GW-CP194-80A型保压取心工具的研制. 天然气工业, 40(4): 91-96. 张晓寒, 季浩, 禹涛, 等, 2024. 赛龙材料微量第二润滑介质增强水润滑摩擦学特性研究. 摩擦学学报, 45(4): 571-581. 赵义, 刘海龙, 蔡家品, 等, 2023. TKP194-80型密闭保压取心工具的研制与应用. 钻探工程, 50(4): 77-83. -
