Study on Liquefaction and Excess Pore Pressure Development Characteristics of Fiber-Reinforced Calcareous Sand
-
摘要:
钙质砂地基液化是造成其上修建的防波堤、码头及机场跑道等关键基础设施地震损毁的主要原因.作为一种环境友好型土工材料，纤维加筋技术可显著提高钙质砂抗液化能力，在南海岛礁工程建设中展现出良好的应用前景.开展了一系列不排水循环单剪试验，研究纤维掺量Fc和循环应力比CSR对加筋钙质砂超静孔压、变形特性及抗液化强度的影响.在此基础上，提出了适用于纤维加筋钙质砂的新型超静孔压发展预测模型.研究表明：纤维掺量Fc的增加可明显减小钙质砂超静孔压和剪应变发展速率，提高其抗液化强度；随着CSR的增加，加筋效果逐渐减弱.纤维加筋可改变钙质砂在液化过程中的变形模式，有效抑制变形急剧增大现象的出现.此外，纤维加筋钙质砂超静孔压发展模式与硅质砂存在较大差异，相同循环振次比下钙质砂超静孔压累积速率更快，传统Seed模型难以准确刻画其超静孔压发展模式的变化特征.随着CSR的增加，其超静孔压发展模式由S型逐渐转变为双曲线型，而随着Fc的增加，发展模式则呈现相反的演变趋势.研究成果可为纤维加筋土技术在岛礁区基础设施抗液化处理中的应用提供重要的理论依据.
Abstract:Liquefaction of calcareous sand foundations is a major cause of seismic damage to critical infrastructure,including breakwaters,wharves,and airport runways. Fiber reinforcement,an environmentally friendly geotechnical materials,can effectively improve the liquefaction resistance of calcareous sand and exhibits great promise for island and reef engineering in the South China Sea. In this study,a series of undrained cyclic simple shear tests were conducted to examine the effects of fiber content (Fc) and cyclic stress ratio (CSR) on excess pore pressure,deformation,and liquefaction resistance of fiber-reinforced calcareous sand. A new prediction model for excess pore pressure development of fiber-reinforced calcareous sand was proposed based on the test results. The findings show that increasing Fc significantly reduces the accumulation rates of excess pore pressure and shear strain,thereby enhancing liquefaction resistance,whereas the reinforcement effect weakens as CSR rises. Fiber reinforcement also alters the deformation pattern of calcareous sand during liquefaction and effectively inhibits the occurrence of sharp increase in deformation. Furthermore,the excess pore pressure development in fiber-reinforced calcareous sand differs significantly from that in siliceous sand,and it presents a faster excess pore pressure accumulation rate under the same cyclic ratio,resulting in the traditional Seed model inadequate for accurately capturing its evolution. With increasing CSR,excess pore pressure development pattern shifts from S-shaped to hyperbolic,while higher Fc induces the opposite trend. These results provide important theoretical support for applying fiber reinforcement to liquefaction mitigation in island and reef infrastructures.
-
图 2 典型钙质砂颗粒电镜扫描图及级配曲线
a. 电镜扫描图；b. 级配曲线
Fig. 2. Scanning electron micrograph images of representative calcareous sand particles and grain size distribution curve
图 3 超静孔压与循环振次关系曲线
a.CSR=0.08；b.CSR=0.12
Fig. 3. Relationship curves of excess pore pressure and number of cycles
图 4 循环剪应变与循环振次关系曲线
a.CSR=0.08；b.CSR=0.12
Fig. 4. Relationship curves of cyclic shear strain and number of cycles
图 5 循环剪应力与剪应变变滞回关系曲线
Fig. 5. Hysteresis relationship curves of cyclic shear stress and cyclic shear strain
图 6 纤维加筋钙质砂抗液化强度曲线
Fig. 6. Liquefaction resistance of fiber-reinforced calcareous sand
图 7 参数A-Fc关系曲线(a)；CSR试验值与预测值对比(b)
Fig. 7. Relationship curves of parameter A-Fc (a); comparison between test values of CSR and predicted values (b)
图 9 孔压比-循环振次比关系曲线(a); 3种典型孔压比发展模式(b)
Fig. 9. Relationship curves of pore pressure ratio-number of cycle ratio (a); three typical pore pressure ratio development models (b)
图 10 孔压比-循环振次比关系曲线
a. Fc=0%；b. Fc=0.25%；c. Fc=0.75%；d. Fc=1%
Fig. 10. Relationship curves of pore pressure ratio-number of cycle ratio
图 11 实测孔压比-循环振次比关系与Seed模型预测趋势对比
a.CSR=0.07；b.CSR=0.08；c.CSR=0.10；d.CSR=0.12
Fig. 11. Comparison of the relationship between measured pore pressure ratio-number of cycle ratio with the Seed model prediction trend
图 12 试验数据与不同模型预测趋势对比
a. Fc=0%；b. Fc=0.25%
Fig. 12. Comparison of test data with predicted trends by different models
图 13 可决系数-纤维掺量关系曲线
Fig. 13. Relationship curves of determination coefficient-fiber content
图 14 模型参数-循环应力比关系曲线
a. 参数α；b. 参数β
Fig. 14. Relationship curves of model parameters-CSR
图 15 建立模型的预测趋势与既有研究试验数据对比
a.南沙珊瑚砂；b.MICP固化钙质砂
Fig. 15. Comparison of predictive trends using established model with the test data from existing research
表 1 不排水循环单剪试验工况
Table 1. Undrained cyclic simple shear test conditions
编号 纤维掺量Fc（%） 相对密实度Dr (%) 循环应力比CSR #1 0 50 0.07、0.08、0.10、0.12 #2 0.25 0.07、0.08、0.10、0.12 #3 0.50 0.07、0.08、0.10、0.12 #4 0.75 0.07、0.08、0.10、0.12 #5 1 0.07、0.08、0.10、0.12
下载: 导出CSV
-
Asadi, M. S., Asadi, M. B., Orense, R. P., et al., 2018. Undrained Cyclic Behavior of Reconstituted Natural Pumiceous Sands. Journal of Geotechnical and Geoenvironmental Engineering, 144(8): 04018045. https://doi.org/10.1061/(asce)gt.1943-5606.0001912 Bhattacharya, S., Hyodo, M., Goda, K., et al., 2011. Liquefaction of Soil in the Tokyo Bay Area from the 2011 Tohoku (Japan) Earthquake. Soil Dynamics and Earthquake Engineering, 31(11): 1618-1628. https://doi.org/10.1016/j.soildyn.2011.06.006 Chen, G. X., Li, J., Chen, J. X., et al., 2025. High-Precision Sub-Seafloor Velocity Building Based on Joint Tomography and Deep Learning on OBS Data in the South China Sea. Journal of Earth Science, 36(2): 830-834. https://doi.org/10.1007/s12583-025-0170-0 Chen, G. X., Ma, W. J., Qin, Y., et al., 2021. Liquefaction Susceptibility of Saturated Coral Sand Subjected to Various Patterns of Principal Stress Rotation. Journal of Geotechnical and Geoenvironmental Engineering, 147(9): 04021093. https://doi.org/10.1061/(asce)gt.1943-5606.0002590 Chen, G. X., Qin, Y., Ma, W. J., et al., 2024. Liquefaction Susceptibility and Deformation Characteristics of Saturated Coral Sandy Soils Subjected to Cyclic Loadings—A Critical Review. Earthquake Engineering and Engineering Vibration, 23(1): 261-296. https://doi.org/10.1007/s11803-024-2221-4 Eseller-Bayat, E., Yegian, M. K., Alshawabkeh, A., et al., 2013. Liquefaction Response of Partially Saturated Sands. II: Empirical Model. Journal of Geotechnical and Geoenvironmental Engineering, 139(6): 872-879. https://doi.org/10.1061/(asce)gt.1943-5606.0000816 Gao, R., Ye, J. H., 2019. Experimental Investigation on the Dynamic Characteristics of Calcareous Sand from the Reclaimed Coral Reef Islands in the South China Sea. Rock and Soil Mechanics, 40(10): 3897-3908, 3919 (in Chinese with English abstract). Ghadr, S., Samadzadeh, A., Bahadori, H., et al., 2020. Liquefaction Resistance of Fibre-Reinforced Silty Sands under Cyclic Loading. Geotextiles and Geomembranes, 48(6): 812-827. https://doi.org/10.1016/j.geotexmem.2020.07.002 Guo, S. Y., Cui, J., Wu, Y., et al., 2024. Dynamic Triaxial Tests of the Liquefaction Characteristics of Saturated Coral Sand. China Earthquake Engineering Journal, 46(1): 84-94(in Chinese with English abstract). Huang, Y., Jiang, X. M., 2010. Field-Observed Phenomena of Seismic Liquefaction and Subsidence during the 2008 Wenchuan Earthquake in China. Natural Hazards, 54(3): 839-850. https://doi.org/10.1007/s11069-010-9509-6 Kuhn, M. R., Renken, H. E., Mixsell, A. D., et al., 2014. Investigation of Cyclic Liquefaction with Discrete Element Simulations. Journal of Geotechnical and Geoenvironmental Engineering, 140(12): 04014075. https://doi.org/10.1061/(asce)gt.1943-5606.0001181 Lee, K. L., Albaisa, A., 1974. Earthquake Induced Settlements in Saturated Sands. Journal of the Geotechnical Engineering Division, 100(4): 387-406. https://doi.org/10.1061/ajgeb6.0000034 Li, W. Y., Huang, Y., 2023. Model Tests on the Effect of Dip Angles on Flow Behavior of Liquefied Sand. Journal of Earth Science, 34(2): 381-385. https://doi.org/10.1007/s12583-021-1498-8 Li, X., Liu, J. K., Nan, J. Y., 2022. Prediction of Dynamic Pore Water Pressure for Calcareous Sand Mixed with Fine-Grained Soil under Cyclic Loading. Soil Dynamics and Earthquake Engineering, 157: 107276. https://doi.org/10.1016/j.soildyn.2022.107276 Liu, H. L., Zhang, Y., Guo, W., et al., 2021. Study on Dynamic Pore Pressure Model of Calcareous Sand Strengthened by Microorganisms. Chinese Journal of Rock Mechanics and Engineering, 40(4): 790-801(in Chinese with English abstract). Liu, J., Wang, G. H., Kamai, T., et al., 2011. Static Liquefaction Behavior of Saturated Fiber-Reinforced Sand in Undrained Ring-Shear Tests. Geotextiles and Geomembranes, 29(5): 462-471. https://doi.org/10.1016/j.geotexmem.2011.03.002 Luo, Z. G., Ding, X. M., Ou, Q., et al., 2023. Experimental Study on Strength and Deformation Characteristics of Coral Sand Reinforced by Geogrid. Rock and Soil Mechanics, 44(4): 1053-1064(in Chinese with English abstract). Ma, W. J., Chen, G. X., Li, L., et al., 2019. Experimental Study on Liquefaction Characteristics of Saturated Coral Sand in Nansha Islands under Cyclic Loading. Chinese Journal of Geotechnical Engineering, 41(5): 981-988(in Chinese with English abstract). Qin, Y., Yang, Z. T., Du, X. Y., et al., 2024. An Energy-Based Model for the Generation of Excess Pore Water Pressure in Saturated Coral Sand. Marine Georesources & Geotechnology, 42(2): 193-204. https://doi.org/10.1080/1064119X.2023.2165992 Rasouli, H., Fatahi, B., 2022. Liquefaction and Post-Liquefaction Resistance of Sand Reinforced with Recycled Geofibre. Geotextiles and Geomembranes, 50(1): 69-81. https://doi.org/10.1016/j.geotexmem.2021.09.002 Rui, S. J., Guo, Z., Si, T. L., et al., 2020. Effect of Particle Shape on the Liquefaction Resistance of Calcareous Sands. Soil Dynamics and Earthquake Engineering, 137: 106302. https://doi.org/10.1016/j.soildyn.2020.106302 Salem, M., Elmamlouk, H., Agaiby, S., 2013. Static and Cyclic Behavior of North Coast Calcareous Sand in Egypt. Soil Dynamics and Earthquake Engineering, 55: 83-91. https://doi.org/10.1016/j.soildyn.2013.09.001 Saxena, S. K., Reddy, K. R., Avramidis, A. S., 1988. Liquefaction Resistance of Artificially Cemented Sand. Journal of Geotechnical Engineering, 114(12): 1395-1413. https://doi.org/10.1061/(asce)0733-9410(1988)114:12(1395) Shan, Y., Zhao, J. T., Tong, H. W., et al., 2022. Effects of Activated Carbon on Liquefaction Resistance of Calcareous Sand Treated with Microbially Induced Calcium Carbonate Precipitation. Soil Dynamics and Earthquake Engineering, 161: 107419. https://doi.org/10.1016/j.soildyn.2022.107419 Tomasello, G., Porcino, D. D., 2022. Influence of Sloping Ground Conditions on Cyclic Liquefaction Behavior of Sand under Simple Shear Loading. Soil Dynamics and Earthquake Engineering, 163: 107516. https://doi.org/10.1016/j.soildyn.2022.107516 Wang, D. L., Tang, C. S., Pan, X. H., et al., 2023. Coupling Effect of Fiber Reinforcement and MICP Stabilization on the Tensile Behavior of Calcareous Sand. Engineering Geology, 317: 107090. https://doi.org/10.1016/j.enggeo.2023.107090 Wang, L., Wang, Y. L., Yuan, X. M., et al., 2021. Experimental Study on Liquefaction Resistance of Hydraulic Fill Coralline Soils at Artificial Sites Based on Large-Scale Dynamic Triaxial Apparatus. Rock and Soil Mechanics, 42(10): 2819-2829(in Chinese with English abstract). Wang, X. Z., Jiao, Y. Y., Wang, R., et al., 2011. Engineering Characteristics of the Calcareous Sand in Nansha Islands, South China Sea. Engineering Geology, 120(1-4): 40-47. https://doi.org/10.1016/j.enggeo.2011.03.011 Wu, Y., Cui, J., Li, C., et al., 2022. Experimental Study on the Influence of Fine Particle Content on the Maximum Dynamic Shear Modulus of Coral Sand Filled by Island Reef. Chinese Journal of Rock Mechanics and Engineering, 41(1): 205-216(in Chinese with English abstract). Wu, Y., Wu, Y. H., Ma, L. J., et al., 2024. Experimental Study on Dynamic Characteristics of Calcareous Sand-Gravel Mixtures from Islands in the South China Sea. Chinese Journal of Geotechnical Engineering, 46(1): 63-71(in Chinese with English abstract). Xiao, P., Liu, H. L., Stuedlein, A. W., et al., 2019. Effect of Relative Density and Biocementation on Cyclic Response of Calcareous Sand. Canadian Geotechnical Journal, 56(12): 1849-1862. https://doi.org/10.1139/cgj-2018-0573 Xiao, P., Liu, H. L., Xiao, Y., et al., 2018. Liquefaction Resistance of Bio-Cemented Calcareous Sand. Soil Dynamics and Earthquake Engineering, 107: 9-19. https://doi.org/10.1016/j.soildyn.2018.01.008 Ye, B., Cheng, Z. R., Liu, C., et al., 2017. Liquefaction Resistance of Sand Reinforced with Randomly Distributed Polypropylene Fibres. Geosynthetics International, 24(6): 625-636. https://doi.org/10.1680/jgein.17.00029 Yu, H. Z., Wang, R., Zhao, W. G., et al., 2006. Experimental Research on Development Pattern of Pore Water Pressure of Carbonate Sand under Wave Loads. Journal of Wuhan University of Technology, 28(11): 86-89(in Chinese with English abstract). Yuan, X. M., Zhang, W. B., Duan, Z. G., et al., 2019. Analysis of Seismic Liquefaction Characteristics of Coral Soil Engineering Site. Chinese Journal of Rock Mechanics and Engineering, 38(S2): 3799-3811(in Chinese with English abstract). Zhang, X. L., Chen, Y. M., Liu, H. L., et al., 2020. Performance Evaluation of a MICP-Treated Calcareous Sandy Foundation Using Shake Table Tests. Soil Dynamics and Earthquake Engineering, 129: 105959. https://doi.org/10.1016/j.soildyn.2019.105959 Zhou, L., Chen, J. F., Peng, M., et al., 2022. Liquefaction Behavior of Fiber-Reinforced Calcareous Sands in Unidirectional and Multidirectional Simple Shear Tests. Geotextiles and Geomembranes, 50(4): 794-806. https://doi.org/10.1016/j.geotexmem.2022.04.003 Zhou, L., Chen, J. F., Zhu, Y., 2025. Development Model of Excess Pore Pressure for Geogrid Reinforced Coral Sand Based on Strain Characteristics. Earth Science, 50(10): 3905-3915(in Chinese with English abstract). Zhou, L., Chen, J. F., Zhu, Y., et al., 2024. Liquefaction and Post-Liquefaction Behaviors of Unreinforced and Geogrid Reinforced Calcareous Sand. Geotextiles and Geomembranes, 52(3): 286-303. https://doi.org/10.1016/j.geotexmem.2023.11.002 高冉, 叶剑红, 2019. 中国南海吹填岛礁钙质砂动力特性试验研究. 岩土力学, 40(10): 3897-3908, 3919. 郭舒洋, 崔杰, 吴杨, 等, 2024. 饱和珊瑚砂液化特性动三轴试验研究. 地震工程学报, 46(1): 84-94. 刘汉龙, 张宇, 郭伟, 等, 2021. 微生物加固钙质砂动孔压模型研究. 岩石力学与工程学报, 40(4): 790-801. 骆赵刚, 丁选明, 欧强, 等, 2023. 土工格栅加筋珊瑚砂的强度及变形特性试验研究. 岩土力学, 44(4): 1053-1064. 马维嘉, 陈国兴, 李磊, 等, 2019. 循环荷载下饱和南沙珊瑚砂的液化特性试验研究. 岩土工程学报, 41(5): 981-988. 王鸾, 汪云龙, 袁晓铭, 等, 2021. 人工场地吹填珊瑚土抗液化强度大粒径动三轴试验研究. 岩土力学, 42(10): 2819-2829. 吴杨, 崔杰, 李晨, 等, 2022. 细粒含量对岛礁吹填珊瑚砂最大动剪切模量影响的试验研究. 岩石力学与工程学报, 41(1): 205-216. 吴杨, 吴毅航, 马林建, 等, 2024. 南海岛礁珊瑚砂砾混合料动力特性试验研究. 岩土工程学报, 46(1): 63-71. 虞海珍, 汪稔, 赵文光, 等, 2006. 波浪荷载下钙质砂孔压增长特性的试验研究. 武汉理工大学学报, 28(11): 86-89. 袁晓铭, 张文彬, 段志刚, 等, 2019. 珊瑚土工程场地地震液化特征解析. 岩石力学与工程学报, (增刊2): 3799-3811. 周林, 陈建峰, 朱艳, 2025. 基于应变特性的土工格栅加筋珊瑚砂超静孔压发展模型. 地球科学, 50(10): 3905-3915. doi: 10.3799/dqkx.2025.097 -
