Large Deformation Analysis of 3D Soil-Rock Mixture Slopes Using SPH-DEM Method
-
摘要:
自然界中的大多数边坡由土体与块石混合构成，一旦发生大变形破坏，可能严重威胁周围人民生命安全及基础设施建设运维.针对土石混合体边坡研究中存在的精细化建模及块石与土体耦合计算难题，建立了一种三维土石混合体边坡高保真建模技术，并提出了基于SPH-DEM耦合的三维土石混合体边坡大变形模拟方法，进一步分析了块石对边坡大变形冲击过程的影响，并预测了青海省浪加滑坡体再次滑动后冲击大坝附属建筑物动力过程，结果表明：块石含量和位置分布显著影响滑坡冲击过程，块石含量越高，冲击力时程曲线的差异性越显著，若块石与建筑物直接碰撞，峰值冲击力较不考虑块石时提高约30%.浪加滑坡再次滑动后前缘最大运动距离达108 m，启闭房、施工营地所受峰值冲击力分别高达自身重力的20倍和4倍，极易被滑坡体冲毁.该研究成果可为土石混合体滑坡的灾害预测和危险性分析提供参考依据.
Abstract:Most natural slopes are composed of soil-rock mixtures, whose large deformation and failure pose severe threats to human safety and infrastructure. To overcome the challenges in high-fidelity modeling and coupled soil-rock mixture interaction analysis, this study develops a high-fidelity 3D modeling technique for soil-rock mixture slopes and proposes an SPH-DEM coupling method to simulate the large deformations. It further analyzes the impact of boulders on the deformation and failure process of the slope and predict the variation of the impact on dam appurtenant structures after the reactivation of the Langjia landslide in Qinghai Province. The results reveal that boulders within the landslide body significantly increasing the landslide velocity, and the content and position of the boulders affect the impact process. Higher boulder content leads to a more pronounced difference in the impact force time-history curve. When boulders collide directly with buildings, the peak impact force increases by about 30% compared to scenarios without boulders. After reactivation, the maximum movement distance of the front edge of the Langjia landslide in Qinghai Province reaches 108 m, with peak impact forces on the intake and construction camp structures reaching 20 times and 4 times their own weight, respectively, making them highly vulnerable to destruction by the landslide. The findings of this study provide valuable insights for disaster prediction and risk analysis of soil-rock mixture landslides.
-
Key words:
- soil-rock mixture slope /
- large deformation /
- refined modeling /
- impact process /
- SPH-DEM method /
- engineering geology
-
图 1 采用扫描仪建立的块石几何轮廓及实体模型
Fig. 1. Geometric profile and solid model of block stone established using scanner
图 6 块石含量为0%的土石混合体边坡运动过程
Fig. 6. Motion process of soil-rock mixture slope with 0% block content
图 7 块石含量为15%的土石混合体边坡运动过程
Fig. 7. Motion process of soil-rock mixture slope with 15% block content
图 10 土石混合体边坡大变形峰值冲击力箱型图
Fig. 10. Box plot of the peak impact force of soil-rock mixture landslide
图 11 土石混合体边坡中块石运动过程（俯视图）
Fig. 11. Movement process of the rocks in the soil-rock mixture slope (top view)
图 12 滑坡体与周围建筑物布置及数值模型
Fig. 12. Layout of the landslide, buildings, and the corresponding numerical model
表 1 块石相关参数
Table 1. Relevant parameters of block stones
序号 块石密度（kg/m3） 块石体积（m3） 1 2 714.27 2.01 2 2 768.21 1.79 3 2 818.20 1.67 4 2 781.98 1.42 5 2 725.37 1.96 6 2 751.22 2.01 7 2 780.48 1.88 8 2 809.44 1.98 9 2 786.14 2.00 10 2 727.79 1.69 11 2 702.48 1.60 12 2 696.91 1.63 13 2 776.73 1.74 14 2 704.51 1.80 15 2 768.69 1.92 16 2 696.17 2.06 17 2 742.33 2.31 18 2 786.14 2.00
下载: 导出CSV
表 2 土体、块石及房屋建筑物材料参数
Table 2. Material parameters for soil, rocks and building
材料 参数 数值 土体 密度（kg/m3） 2 000 弹性模量(MPa) 10 泊松比 0.3 峰值粘聚力(Pa) 10 000 残余粘聚力(Pa) 0 粘聚力软化系数 5 峰值摩擦角(°) 21.3 残余摩擦角(°) 21.3 摩擦角软化系数 0 块石 密度(kg/m3) 2 731.7 弹性模量(GPa) 30 泊松比 0.3 碰撞恢复系数 0.5 动摩擦系数 0.35 建筑物 密度(kg/m3) 2 400 弹性模量(GPa) 10 泊松比 0.3 碰撞恢复系数 0.50 动摩擦系数 0.35
下载: 导出CSV
表 3 滑坡体中随机块石数据
Table 3. Data of random block stones in landslides
工况 含量(%) 小粒径块石 大粒径块石 实际含量(%) 个数 总体积(m3) 个数 总体积(m3) 1 0 0 0 0 0 0 2 5 14 25 191.07 8 117 684.14 5.010 3 10 18 33 483.09 17 251 832.58 10.005
下载: 导出CSV
表 4 数值模拟中滑坡体材料参数
Table 4. Material parameters of the landslide for the numerical simulation
参数 取值 密度(kg/m3) 2 100 弹性模量(MPa) 50 泊松比 0.3 峰值粘聚力(Pa) 7 500 残余粘聚力(Pa) 3 750 粘聚力软化系数 5 峰值摩擦角(°) 16.09 残余摩擦角(°) 16.09 摩擦角软化系数 0 剪胀角(°) 0
下载: 导出CSV
-
Abioga, A., Rachmansyah, A., Zaika, Y., 2025. Rainfall-Induced Slope Stability on Soil-Rock Mixture. Rekayasa Sipil, 19(1): 83-96. https://doi.org/10.21776/ub.rekayasasipil.2025.019.01.11 Bian, H. G., Wang, S., Ma, H. S., et al., 2024. Stability of Soil-Rock Mixture Slopes Based on Random Field Theory. Bulletin of Geological Science and Technology, 43(6): 162-170 (in Chinese with English abstract). Bui, H. H., Fukagawa, R., Sako, K., et al., 2011. Slope Stability Analysis and Discontinuous Slope Failure Simulation by Elasto-Plastic Smoothed Particle Hydrodynamics (SPH). Géotechnique, 61(7): 565-574. https://doi.org/10.1680/geot.9.p.046 Canelas, R. B., Domínguez, J. M., Crespo, A. J. C., et al., 2017. Resolved Simulation of a Granular-Fluid Flow with a Coupled SPH-DCDEM Model. Journal of Hydraulic Engineering, 143(9): 0601701. https://doi.org/10.1061/(asce)hy.1943-7900.0001331 Chau, K. T., Wong, R. H. C., Wu, J. J., 2002. Coefficient of Restitution and Rotational Motions of Rockfall Impacts. International Journal of Rock Mechanics and Mining Sciences, 39(1): 69-77. https://doi.org/10.1016/s1365-1609(02)00016-3 Fang, H. J., Li, D. Q., Wang, S., et al., 2024. Hypoplastic Modeling Post-Failure Behavior of Sandy Slope with Porosity Spatial Variability. Computers and Geotechnics, 173: 106470. https://doi.org/10.1016/j.compgeo.2024.106470 Hu, Y. Y., Lu, Y., Zheng, Y. W., 2025. Numerical Study on Seepage-Induced Instability of Soil-Rock Mixture Slopes Using CFD-DEM Coupling Method. Computers and Geotechnics, 183: 107206. https://doi.org/10.1016/j.compgeo.2025.107206 Kang, X., Wang, S., et al., 2025. Mechanical Behaviour and Shear Localisation of Gravel Soils: Experimental Study and Numerical Modelling. Géotechnique, 76(1): 56-71. https://doi.org/10.1680/jgeot.24.01238 Li, S., Peng, M., Shi, Z. M., et al., 2025. Simulation and Analysis of Cascading Hazard Based on Fluid-Soil Coupled SPH Method. Earth Science, 50(10): 3967-3981 (in Chinese with English abstract). Liu, S. Q., Wang, H. L., Xu, W. Y., et al., 2020. Numerical Investigation of the Influence of Rock Characteristics on the Soil-Rock Mixture (SRM) Slopes Stability. KSCE Journal of Civil Engineering, 24(11): 3247-3256. https://doi.org/10.1007/s12205-020-0034-1 Peng, M., Zhao, Q. X., Li, S., et al., 2025. Two-Phase SPH Simulation of Granular Landslide-Tsunamis Processes Considering Dynamic Seepage. Earth Science, 50(10): 3795-3808 (in Chinese with English abstract). Peng, X. Y., Yu, P. C., Zhu, H., et al., 2023. Proposal of a Coupled DDA-SPH Method Incorporating a New Contact Algorithm for Soil-Structure Interaction Simulations in Geotechnical Hazards. Computers and Geotechnics, 164: 105849. https://doi.org/10.1016/j.compgeo.2023.105849 Su, Z. Y., Kang, X., Ding, X. C., et al., 2026. SPH-DEM Modeling of Rainfall-Induced Slope Failure in Partially Saturated Soil-Rock Mixture. Computers and Geotechnics, 189: 107635. https://doi.org/10.1016/j.compgeo.2025.107635 Su, Z. Y., Xiang, Y., Li, D. Q., et al., 2024. SPH-DEM Modeling of Cable-Controlled ROVs: Underwater Mobility and Path Planning. Ocean Engineering, 292: 1166. https://doi.org/10.1016/j.oceaneng.20.116623 Sun, H. F., Ju, Y., Wang, X. F., et al., 2014. Review of the Study on Deformation, Failure and the Mesomechanisms of Rock-Soil Mixture(RSM). Scientia Sinica (Technologica), 44(2): 172-181 (in Chinese). doi: 10.1360/092013-198 Wang, S., Wu, W., Cui, D. S., 2022. On Mechanical Behaviour of Clastic Soils: Numerical Simulations and Constitutive Modelling. Géotechnique, 72(8): 706-721. https://doi.org/10.1680/jgeot.20.p.184 Wendland, H., 1995. Piecewise Polynomial, Positive Definite and Compactly Supported Radial Functions of Minimal Degree. Advances in Computational Mathematics, 4(1): 389-396. https://doi.org/10.1007/BF02123482 Xu, W. J., Hu, L. M., Gao, W., 2016. Random Generation of the Meso-Structure of a Soil-Rock Mixture and Its Application in the Study of the Mechanical Behavior in a Landslide Dam. International Journal of Rock Mechanics and Mining Sciences, 86: 166-178. https://doi.org/10.1016/j.ijrmms.2016.04.007 Yang, Y. T., Liu, F., Wu, W. A., 2022. Assessing Slope Stability with an Improved 3D Numerical Manifold Method. Rock Mechanics and Rock Engineering, 55(10): 6409-6423. https://doi.org/10.1007/s00603-022-02993-7 Zhang, R. H., Zhang, L. K., Cui, X. C., 2023. Triaxial Numerical Simulation and Macro-Micro Deformation Analysis of Soil-Rock Mixture. Water Resources and Power, 41(7): 171-174, 31 (in Chinese with English abstract). Zhao, L. H., Huang, D. L., Zhang, S. H., et al., 2021. A New Method for Constructing Finite Difference Model of Soil-Rock Mixture Slope and Its Stability Analysis. International Journal of Rock Mechanics and Mining Sciences, 138: 104605. https://doi.org/10.1016/j.ijrmms.2020.104605 Zhu, C. W., Peng, C., Wu, W., 2022. Lagrangian Meshfree Particle Method (SPH) Based Simulation for Granular Flow in a Rotating Drum with Regularized μ(I) Elastoplastic Model. Powder Technology, 408: 117699. https://doi.org/10.1016/j.powtec.20.117699 边宏光, 王顺, 马海善, 等, 2024. 基于随机场理论的土石混合体边坡稳定性. 地质科技通报, 43(6): 162-170. 李爽, 彭铭, 石振明, 等, 2025. 基于水土耦合SPH方法的滑坡-堵江-成坝灾害链全过程动力演化模拟. 地球科学, 50(10): 3967-3981. 彭铭, 赵庆新, 李爽, 等, 2025. 考虑动态渗流的散粒体滑坡-涌浪过程两相SPH模拟. 地球科学, 50(10): 3795-3808. doi: 10.3799/dqkx.2025.100 孙华飞, 鞠杨, 王晓斐, 等, 2014. 土石混合体变形破坏及细观机理研究的进展. 中国科学: 技术科学, 44(2): 172-181. 张润涵, 张凌凯, 崔熙灿, 2023. 土石混合体的三轴数值模拟及宏细观变形分析. 水电能源科学, 41(7): 171-174, 31. -
