Dynamic Evolution Laws of Free Gas and Adsorbed Gas in Deep Coal Reservoirs and Its Geological Controls: A Case Study of Daning-Jixian Block, Ordos Basin
-
摘要: 煤层气的赋存状态是影响深部煤层气资源评价和开发效益的关键因素之一.为了揭示深部煤储层中游离气‒吸附气的动态演化规律及其地质控制，从而深化对深部煤层气成藏过程的认识，本文以鄂尔多斯盆地大宁‒吉县区块太原组8号煤储层为研究对象，构建了游离气含量、吸附气含量、原位孔隙度以及含水饱和度的预测模型，结合煤层埋藏史、受热史、热演化史及储层压力演化过程的系统分析，探讨了煤层气成藏过程中气体赋存状态的动态演化规律.研究表明，该区煤层气成藏过程中游离气‒吸附气的动态演化可划分为4个阶段：（Ⅰ）晚二叠世至早侏罗世，煤层快速沉降阶段，吸附气含量不断增加，几乎不存在游离气；（Ⅱ）早侏罗世至早白垩世，煤层小幅升降阶段，游离气含量逐渐增加，吸附气含量呈现波动式变化；（Ⅲ）早白垩世至白垩纪中期，煤层二次快速沉降阶段，游离气含量先降低后升高，吸附气含量缓慢上升；（Ⅳ）白垩纪中期至今，煤层快速抬升阶段，游离气含量逐渐降低，吸附气含量持续上升.该研究成果可为深部煤层气资源的有利区优选和高效开发提供一定的理论借鉴.Abstract: The occurrence state of coalbed methane (CBM) is one of the key factors influencing the resource assessment and the development efficiency of deep CBM. In order to elucidate the dynamic evolution laws of free gas and adsorbed gas within deep coal reservoirs, as well as their geological controls, thereby deepening the understanding of deep CBM accumulation processes, this study focuses on the No. 8 coal seam of the Taiyuan Formation in the Daning-Jixian Block, Ordos Basin.Prediction models for free gas content, adsorbed gas content, in-situ porosity, and water saturation were established. These were integrated with a systematic reconstruction of the coal seam burial history, thermal history, thermal maturation, and reservoir pressure evolution, to investigate the dynamic evolution of gas occurrence states during CBM accumulation.The results indicate that the dynamic evolution of free and adsorbed gas during CBM accumulation in the study area can be classified into four stages: (Ⅰ) Late Permian-Early Jurassic: a period of rapid coal seam subsidence, accompanied by a sustained rise in adsorbed gas content and negligible free gas occurrence; (Ⅱ) Early Jurassic-Early Cretaceous: a stage of minor fluctuations in burial depth of coal seam, during which free gas content gradually increased, while adsorbed gas content exhibited oscillatory variations; (Ⅲ) Early Cretaceous-Middle Cretaceous: second rapid subsidence phase of coal seam, in which free gas content first decreases and then increases, with adsorbed gas content rising slowly; (Ⅳ) Middle Cretaceous-present: rapid uplift of coal seams, during which free gas content gradually decreases, while adsorbed gas content continues to increase.The findings of this study can provide a theoretical reference for favorable zone selection and efficient exploitation of deep CBM resources.
-
Key words:
- deep coalbed methane /
- adsorbed gas /
- free gas /
- dynamic evolution /
- Daning-Jixian /
- coalbed methane geology
-
图 1 鄂尔多斯盆地大宁‒吉县区块位置、含煤地层及构造特征（图d引自张雷等，2023）
Fig. 1. Location, coal-bearing strata, and structural characteristics of the Daning-Jixian Block in the Ordos Basin
图 2 煤样覆压孔隙度实验装置示意图
Fig. 2. Schematic diagram of the experimental apparatus for measuring overburden porosity of coal samples
图 3 研究区煤样归一化孔隙度与有效应力（a）以及储层压力（b）的关系
Fig. 3. Relationships between normalized porosity and effective stress (a) and reservoir pressure (b) for coal samples from the study area
图 4 研究区煤样归一化孔隙度实测值与预测值关系
Fig. 4. Relationship between measured and predicted normalized porosity for coal samples from the study area
图 5 鄂尔多斯盆地煤岩总孔体积（无应力加载条件下）与Ro, max关系
Fig. 5. Relationship between total pore volume (under no-stress loading) and Ro, max of coals in the Ordos Basin
图 6 Langmuir体积与Ro, max（a）以及温度（b）的关系
Fig. 6. Plots of Langmuir volume versus Ro, max (a) and temperature (b)
图 8 鄂尔多斯盆地煤样实测含水饱和度与Ro, max（a）以及氦测总孔隙度（b）的关系
Fig. 8. Plots of measured water saturation versus Ro, max (a) and helium-measured total porosity (b) of coal samples in the Ordos Basin
图 9 鄂尔多斯盆地煤样实测含水饱和度与预测含水饱和度的关系
Fig. 9. Relationship between measured and predicted water saturation for coal samples from the Ordos Basin
图 10 大宁‒吉县深部煤层气成藏过程以及吸附气‒游离气动态变化规律
a. 太原组8号煤层埋藏史、受热史和有机质成熟史；b. 8号煤层孔隙度、储层压力和静水压力演化史；c. 吸附气和游离气含量演化史及阶段划分
Fig. 10. Accumulation processes of deep CBM in the Daning-Jixian Block and dynamic variation laws of free gas and adsorbed gas
表 1 研究区煤样覆压孔隙度测试实验方案
Table 1. Experimental scheme for overburden porosity tests on coal samples in the study area
方案序号 有效应力、围压和储层压力设计方案 ① 保持有效应力5 MPa不变 围压（MPa） 6 9 12 15 20 储层压力（MPa） 1 4 7 10 15 ② 保持有效应力10 MPa不变 围压（MPa） 11 14 17 20 25 储层压力（MPa） 1 4 7 10 15 ③ 保持有效应力15 MPa不变 围压（MPa） 16 19 23 25 30 储层压力（MPa） 1 4 7 10 15
下载: 导出CSV
-
Aplin, A. C., Larter, S. R., Bigge, M. A., et al., 2000. PVTX History of the North Sea's Judy Oilfield. Journal of Geochemical Exploration, 69: 641-644. https://doi.org/10.1016/S0375-6742(00)00066-2 Bao, Y., Wei, C. T., Wang, C. Y., et al., 2012. Simulation of Geological Evolution History of the Upper Permian Coal Seam No. 8 in Shuigonghe Syncline, Zhina Coalfield, Guizhou. Coal Geology & Exploration, 40(6): 13-16, 23 (in Chinese with English abstract). Chen, S. D., Tang, D. Z., Hou, W., et al., 2023. Geological Particularity and Reservoir Engineering Response of Deep Coalbed Methane. Acta Petrolei Sinica, 44(11): 1993-2006 (in Chinese with English abstract). Deng, Z., Wang, H. Y., Jiang, Z. X., et al., 2024. Influence of Deep Coal Pore and Fracture Structure on Occurrence of Coalbed Methane: A Case Study of Daning- Jixian Block in Eastern Margin of Ordos Basin. Coal Science and Technology, 52(8): 106-123 (in Chinese with English abstract). Ding, R., Pang, X. Q., Jia, C. Z., et al., 2025. Methods, Principles and Case Study of Evaluating Deep Coalbed Methane Based on Whole Petroleum System Theory. Acta Petrolei Sinica, 46(3): 532-546 (in Chinese with English abstract). Fu, X. H., Qin, Y., Wei, C. T., 2007. Coalbed Methane Geology. China University of Mining and Technology Press, Xuzhou (in Chinese). Geng, M., Chen, H., Chen, Y. P., et al., 2018. Methods and Results of the Fourth Round National CBM Resources Evaluation. Coal Science and Technology, 46(6): 64-68 (in Chinese with English abstract). Guo, T., 2021. Occurrence and Gas Volume Prediction Model of Deep Coalbed Methane (Dissertation). China University of Mining and Technology, Xuzhou, 53-56 (in Chinese with English abstract). Guo, X. J., Zhi, D. M., Mao, X. J., et al., 2021. Discovery and Significance of Coal Measure Gas in Junggar Basin. China Petroleum Exploration, 26(6): 38-49 (in Chinese with English abstract). Huang, Z. W., Li, G. F., Yang, R. Y., et al., 2022. Review and Development Trends of Coalbed Methane Exploitation Technology in China. Journal of China Coal Society, 47(9): 3212-3238 (in Chinese with English abstract). Jin, Y., 2012. Research on Calculation Methods and Phase State Parameters of Gas Condensate Reservoir (Dissertation). Northeast Petroleum University, Daqing, 28-29 (in Chinese with English abstract). Li, R., Xiang, W. T., Xu, F. Y., et al., 2025. Value and Development Direction of Efficient Development of Coal-Measure Natural Gas in Energy Transition. Coal Science and Technology, 53(3): 60-72 (in Chinese with English abstract). Li, S., Qin, Y., Tang, D. Z., et al., 2023. A Comprehensive Review of Deep Coalbed Methane and Recent Developments in China. International Journal of Coal Geology, 279: 104369. https://doi.org/10.1016/j.coal.2023.104369 Li, Y., Xu, L. F., Liu, Y., et al., 2024. Occurrence Mechanism, Environment and Dynamic Evolution of Gas and Water in Deep Coal Seams. Coal Geology & Exploration, 52(2): 40-51 (in Chinese with English abstract). Lin, Y. X., Yu, Z. Y., Liu, D., 2021. Formation Mechanism and Model of Tight Sandstone Gas Reservoirs in the Linxing Area of Ordos Basin. Geology and Exploration, 57(1): 210-221 (in Chinese with English abstract). Mi, J. K., Xiao, X. M., Liu, D. H., et al., 2004. Utilizing Fluid Inclusion Information to Restore the Migration Process of the Gas-Water Interface in the Late Paleozoic Natural Gas Reservoirs of the Ordos Basin. Chinese Science Bulletin, 49(4): 396-400 (in Chinese). doi: 10.1007/BF02900324 Nie, Z. H., Xu, F. Y., Shi, X. S., et al., 2024. Outcomes and Implications of Pilot Tests for Deep Coalbed Methane Production on the Eastern Margin of the Ordos Basin. Coal Geology & Exploration, 52(2): 1-12 (in Chinese with English abstract). Qin, Y., 2023. Progress on Geological Research of Deep Coalbed Methane in China. Acta Petrolei Sinica, 44(11): 1791-1811 (in Chinese with English abstract). Qin, Y., Shen, J., Shi, R., 2022. Strategic Value and Choice on Construction of Large CMG Industry in China. Journal of China Coal Society, 47(1): 371-387 (in Chinese with English abstract). Ren, Z. L., Qi, K., Li, J. B., et al., 2021. Thermodynamic Evolution and Hydrocarbon Accumulation in the Ordos Basin. Oil & Gas Geology, 42(5): 1030-1042 (in Chinese with English abstract). Shen, J., Du, L., Qin, Y., et al., 2015. Three-Phase Gas Content Model of Deep Low-Rank Coals and Its Implication for CBM Exploration: A Case Study from the Jurassic Coal in the Junggar Basin. Natural Gas Industry, 35(3): 30-35 (in Chinese with English abstract). Shi, R., Bian, L. H., Zhang, W., et al., 2025. Prediction Model for Free Gas Content in Deep Coal Seams Based on Effective Porosity. Journal of China University of Mining & Technology, 54(1): 161-171 (in Chinese with English abstract). Sun, F. J., Zhou, G. X., Tian, W. G., et al., 2024. Definition, Connotation, Formation and Application of Coalbed Methane System: A Case Study on the Carboniferous-Permian Coal Seams in the Ordos Basin. Natural Gas Industry, 44(7): 42-53 (in Chinese with English abstract). Tang, S. H., Xi, Z. D., Zhang, S. H., et al., 2025. Occurrence Phase and Gas-Bearing Evolution of Deep Coalbed Methane. Coal Science and Technology, 53(3): 91-100 (in Chinese with English abstract). Tang, S. L., Tang, D. Z., Yang, J. S., et al., 2023. Pore Structure Characteristics and Gas Storage Potential of Deep Coal Pore Structure Characteristics and Gas Storage Potential of Deep Coal. Acta Petrolei Sinica, 44(11): 1854-1866, 1902 (in Chinese with English abstract). Wang, C. W., Zhen, H. B., Chen, G. J., et al., 2022. Assessment of Coal No. 8 Reservoir Features and Fracturability in Da'ning-Jixian Block Deep Part. Coal Geology of China, 34(2): 1-5 (in Chinese with English abstract). Xiong, X. Y., Yan, X., Xu, F. Y., et al., 2023. Analysis of Multi-Factor Coupling Control Mechanism, Desorption Law and Development Effect of Deep Coalbed Methane. Acta Petrolei Sinica, 44(11): 1812-1826, 1853 (in Chinese with English abstract). Xiong, X. Y., Zhen, H. B., Li, S. G., et al., 2024. Multi-Round Diverting Fracturing Technology and Its Application in Deep Coalbed Methane in the Daning-Jixian Block. Coal Geology & Exploration, 52(2): 147-160 (in Chinese with English abstract). Xu, F. Y., Wang, C. W., Xiong, X. Y., et al., 2022. Deep (Layer) Coalbed Methane Reservoir Forming Modes and Key Technical Countermeasures: Taking the Eastern Margin of Ordos Basin as an Example. China Offshore Oil and Gas, 34(4): 30-42 (in Chinese with English abstract). Xu, F. Y., Yan, X., Wang, F. L., et al., 2023. Development Strategy and Countermeasures of China's CBM Industry under the Goal of "Carbon Peak and Neutrality". Journal of Earth Science, 34(4): 975-984. https://doi.org/10.1007/s12583-022-1647-8 Xu, F. Y., Yan, X., Li, S. G., et al., 2023. Theoretical and Technological Difficulties and Countermeasures of Deep CBM Exploration and Development in the Eastern Edge of Ordos Basin. Coal Geology & Exploration, 51(1): 115-130 (in Chinese with English abstract). Xu, H., 2017. Occurrence Characteristics and Tectonic Controls of Coal Series Mineral Resources in Ordos Basin (Dissertation). China University of Mining and Technology (Beijing), Beijing, 14-15 (in Chinese with English abstract). Yang, H., Liu, X. S., Yan, X. X., 2015. The Relationship between Tectonic-Edimentary Evolution and Tight Sandstone Gas Reservoir since the Late Paleozoic in Ordos Basin. Earth Science Frontiers, 22(3): 174-183 (in Chinese with English abstract). Yang, Z. B., Li, C. L., Guo, Q. Z., et al., 2025. Distribution Patterns of Various Occurrence States of Deep Coalbed Methane in the Baijiahai Uplift, Junggar Basin, Xinjiang. Journal of China University of Mining & Technology, 54(1): 127-137 (in Chinese with English abstract). Yu, Z., 2011. Experimental Study on Density and Viscosity Characteristics of Supercritical Acid Natural Gas (Dissertation). China University of Petroleum (East China), Qingdao, 40-41 (in Chinese with English abstract). Zhang, L., Bian, L. H., Hou, W., et al., 2023. Pore Structure Characteristics and Exploration Significance of Deep Coal Reservoirs: A Case Study of Daning- Jixian Block in the Eastern Margin of Ordos Basin. Acta Petrolei Sinica, 44(11): 1867-1878 (in Chinese with English abstract). Zhang, X. R., Lai, F. P., Meng, Y., et al., 2024. Dynamic Production Characteristics of Deep Coalbed Methane: A Case Study of Daning-Jixian Block. Energy & Fuels, 38(10): 8700-8711. https://doi.org/10.1021/acs.energyfuels.4c01065 Zhang, X., Wang, L. L., Cai, S. Y., et al., 2024. Effects of Hydrocarbon Generation on the Occurrence of Organic Nanopores during Thermal Maturity of Organic Matters. Earth Science, 49(9): 3292-3305 (in Chinese with English abstract). Zhou, L. H., Xiong, X. Y., Li, Y., et al., 2025a. Revolutionary Breakthroughs and Key Theories and Technologies in Deep Coalbed Methane Development. Natural Gas Industry, 45(5): 17-30 (in Chinese with English abstract). Zhou, L. H., Yan, X., Xiong, X. Y., et al., 2025b. Characteristics of Occurrence and Distribution Rule of Deep Coalbed Methane in Supercritical State. Coal Science and Technology, 53(3): 73-90 (in Chinese with English abstract). 鲍园, 韦重韬, 王超勇, 等, 2012. 贵州织纳煤田水公河向斜上二叠统8煤层三史模拟. 煤田地质与勘探, 40(6): 13-16, 23. 陈世达, 汤达祯, 侯伟, 等, 2023. 深部煤层气地质条件特殊性与储层工程响应. 石油学报, 44(11): 1993-2006. 邓泽, 王红岩, 姜振学, 等, 2024. 深部煤储层孔裂隙结构对煤层气赋存的影响——以鄂尔多斯盆地东缘大宁‒吉县区块为例. 煤炭科学技术, 52(8): 106-123. 丁蓉, 庞雄奇, 贾承造, 等, 2025. 基于全油气系统理论评价深部煤层气的方法原理和研究实例. 石油学报, 46(3): 532-546. 傅雪海, 秦勇, 韦重韬, 2007. 煤层气地质学. 徐州: 中国矿业大学出版社, 11. 庚勐, 陈浩, 陈艳鹏, 等, 2018. 第4轮全国煤层气资源评价方法及结果. 煤炭科学技术, 46(6): 64-68. 郭涛, 2021. 深部煤层气赋存态及其含量预测模型(硕士学位论文). 徐州: 中国矿业大学, 53-56. 郭绪杰, 支东明, 毛新军, 等, 2021. 准噶尔盆地煤岩气的勘探发现及意义. 中国石油勘探, 26(6): 38-49. 黄中伟, 李国富, 杨睿月, 等, 2022. 我国煤层气开发技术现状与发展趋势. 煤炭学报, 47(9): 3212-3238. 靳烨, 2012. 凝析气藏相态实验及计算方法研究(硕士学位论文). 大庆: 东北石油大学, 28-29. 李瑞, 向雯婷, 徐凤银, 等, 2025. 煤系天然气高效开发在能源转型中的价值及发展方向. 煤炭科学技术, 53(3): 60-72. 李勇, 徐立富, 刘宇, 等, 2024. 深部煤层气水赋存机制、环境及动态演化. 煤田地质与勘探, 52(2): 40-51. 林玉祥, 余志勇, 刘冬, 2021. 临兴地区致密砂岩气藏形成机理与成藏模式. 地质与勘探, 57(1): 210-221. 米敬奎, 肖贤明, 刘德汉, 等, 2004. 利用流体包裹体信息恢复鄂尔多斯盆地晚古生代天然气气藏气水界面的迁移过程. 科学通报, 49(4): 396-400. 聂志宏, 徐凤银, 时小松, 等, 2024. 鄂尔多斯盆地东缘深部煤层气开发先导试验效果与启示. 煤田地质与勘探, 52(2): 1-12. 秦勇, 2023. 中国深部煤层气地质研究进展. 石油学报, 44(11): 1791-1811. 秦勇, 申建, 史锐, 2022. 中国煤系气大产业建设战略价值与战略选择. 煤炭学报, 47(1): 371-387. 任战利, 祁凯, 李进步, 等, 2021. 鄂尔多斯盆地热动力演化史及其对油气成藏与富集的控制作用. 石油与天然气地质, 42(5): 1030-1042. 申建, 杜磊, 秦勇, 等, 2015. 深部低阶煤三相态含气量建模及勘探启示——以准噶尔盆地侏罗纪煤层为例. 天然气工业, 35(3): 30-35. 史锐, 边利恒, 张伟, 等, 2025. 基于有效孔隙度的深部煤层游离气含量预测模型. 中国矿业大学学报, 54(1): 161-171. 孙粉锦, 周国晓, 田文广, 等, 2024. 煤层气系统的定义、内涵、形成及应用——以鄂尔多斯盆地石炭系‒二叠系煤层为例. 天然气工业, 44(7): 42-53. 唐书恒, 郗兆栋, 张松航, 等, 2025. 深部煤层气赋存相态与含气性演化. 煤炭科学技术, 53(3): 91-100. 唐淑玲, 汤达祯, 杨焦生, 等, 2023. 鄂尔多斯盆地大宁‒吉县区块深部煤储层孔隙结构特征及储气潜力. 石油学报, 44(11): 1854-1866, 1902. 王成旺, 甄怀宾, 陈高杰, 等, 2022. 大宁‒吉县区块深部8号煤储层特征及可压裂性评价. 中国煤炭地质, 34(2): 1-5. 熊先钺, 闫霞, 徐凤银, 等, 2023. 深部煤层气多要素耦合控制机理、解吸规律与开发效果剖析. 石油学报, 44(11): 1812-1826+1853. 熊先钺, 甄怀宾, 李曙光, 等, 2024. 大宁‒吉县区块深部煤层气多轮次转向压裂技术及应用. 煤田地质与勘探, 52(2): 147-160. 徐凤银, 王成旺, 熊先钺, 等, 2022. 深部(层)煤层气成藏模式与关键技术对策——以鄂尔多斯盆地东缘为例. 中国海上油气, 34(4): 30-42. 徐凤银, 闫霞, 李曙光, 等, 2023. 鄂尔多斯盆地东缘深部(层)煤层气勘探开发理论技术难点与对策. 煤田地质与勘探, 51(1): 115-130. 徐浩, 2017. 鄂尔多斯盆地煤系矿产资源赋存规律的构造控制研究(博士学位论文). 北京: 中国矿业大学(北京), 14-15. 杨华, 刘新社, 闫小雄, 2015. 鄂尔多斯盆地晚古生代以来构造‒沉积演化与致密砂岩气成藏. 地学前缘, 22(3): 174-183. 杨兆彪, 李存磊, 郭巧珍, 等, 2025. 新疆准噶尔盆地白家海凸起深部煤层气不同赋存态分配规律. 中国矿业大学学报, 54(1): 127-137. 于忠, 2011. 超临界酸性天然气密度粘度变化规律实验研究(硕士学位论文). 青岛: 中国石油大学(华东), 40-41. 张雷, 边利恒, 侯伟, 等, 2023. 深部煤储层孔隙结构特征及其勘探意义——以鄂尔多斯盆地东缘大宁‒吉县区块为例. 石油学报, 44(11): 1867-1878. 张旭, 王琳霖, 蔡苏阳, 等, 2024. 有机质生烃对纳米有机孔隙形成演化的影响. 地球科学, 49(9): 3292-3305. doi: 10.3799/dqkx.2023.093 周立宏, 熊先钺, 李勇, 等, 2025a. 深层煤层(岩)气革命性突破及关键理论与技术. 天然气工业, 45(5): 17-30. 周立宏, 闫霞, 熊先钺, 等, 2025b. 深部煤层气超临界状态下赋存特征及分配规律. 煤炭科学技术, 53(3): 73-90. -
