Danxia Red Caused by Surface Iron Coating: Study on the Occurrence State of Iron in Typical Danxia Strata in Southern China
-
摘要: 丹霞地貌在我国南方地区广泛发育，其红色的特征是主要的地貌判别标志之一. 前人的研究成果显示丹霞的红色成因与地层中的铁有关，但是对于铁的赋存状态并未进行深入研究. 通过对采自广东省丹霞山及江西省龙虎山两个典型丹霞地貌区的样品进行矿物组成、地球化学及铁的赋存状态研究，结果表明：（1）广东丹霞山及江西龙虎山丹霞地层样品的岩性主要为砾岩与砂岩，主要的矿物组成是石英与长石，含有少量的粘土及铁氧化物，岩体致密坚硬，固结程度高，多为铁质胶结.（2）地球化学分析显示，二者的SiO2的含量最高，Al2O3次之，TFe2O3与FeO的含量较低，铁氧化物主要是赤铁矿，它是极高效的显色剂，通过高效的地球化学过程，以最显色的矿物形式，富集在了颗粒表面.（3）穆斯堡尔谱分析显示二者地层中铁均以氧化物铁及粘土铁的形式赋存，其中三价铁离子远高于二价铁离子的含量. 综合来看，铁在丹霞地层中的含量较低，但是以铁氧化物的形式吸附和沉淀在石英、长石等矿物的表面，以及粘土矿物的表面和层间，形成极薄的赤铁矿包膜，致使地层呈现红色.Abstract: Danxia landform is widely developed in southern China, and its red feature is one of the main distinguishing marks of landform. Previous research results have shown that the red color of Danxia landforms is related to iron in the strata, but no in-depth study has been conducted on the state of iron occurrence. In this paper, the mineral composition, geochemistry and iron occurrence of samples from Danxia Mountain in Guangdong Province and Longhu Mountain in Jiangxi Province are studied. The results show that: (1)The Danxia landform stratigraphic samples in Guangdong Province and Longhu Mountain in Jiangxi Province show that the main mineral composition is quartz and feldspar, containing a small amount of clay and iron oxides, with a high degree of consolidation, and some layers contain gravel. (2) Geochemical analysis shows that the content of SiO2 in both is the highest, followed by Al2O3. The content of TFe2O3 (0.81%~1.63%) and FeO (0.08%~0.16%) is lower, indicating that the content of iron minerals is not the main factor causing redness. (3)The iron in the Danxia Formation of Danxia Mountain in Guangdong and Longhu Mountain in Jiangxi mainly exists in the form of clay iron and oxide iron, among which trivalent iron ions (oxides-Fe3+: 41.3% and 44.3%, clay-Fe3+: 49.7% and 47.6%) are much higher than the content of divalent iron ions (clay-Fe2+: 9.0% and 8.1%). All indicate that the content of iron in the Danxia Formation is relatively low, but it may be in the form of an iron oxide coating that exists on the surface of minerals such as quartz and feldspar, causing the formation to appearred.
-
图 1 广东丹霞山及江西龙虎山丹霞地层手标本及岩石样品单偏光镜下照片
a. 广东丹霞山丹霞地层暗红色砾岩；b. 广东丹霞山丹霞地层暗红色粗砂岩；c. 江西龙虎山丹霞地层暗红色中粗粒砂岩；d. 广东丹霞山样品单偏光下照片；e. 江西龙虎山样品单偏光下照片
Fig. 1. Photographs of hand specimens and rock samples of Danxia strata in Danxia Mountain, Guangdong Province and Longhu Mountain, Jiangxi Province under partially polarized light
图 2 南方典型丹霞地层矿物组合XRD分析结果
Qz. 石英；Cy. 粘土类矿物；Fp. 长石；Io. 铁氧化物；Sf. 硫化物
Fig. 2. Mineral association of typical Danxia Formation in southern China
图 3 南方典型丹霞地层穆斯堡尔谱图
Fig. 3. Mossbauer spectrum of typical Danxia strata in southern China
表 1 南方典型丹霞地层地球化学成分（%）
Table 1. The typical Danxia strata chemical composition in southern China (%)
序号 样品名称 样品性质 SiO2 TiO2 Al2O3 TFe2O3 MnO MgO CaO Na2O K2O P2O5 LOI FeO SUM 1 sg01 砾岩 85.61 0.11 7.86 0.81 0.01 0.70 0.05 0.10 2.21 0.02 2.19 0.08 99.66 2 sg02 砂岩 73.22 0.14 13.82 1.63 0.03 1.45 0.40 0.60 5.40 0.02 2.81 0.16 99.53 3 yt01 砂岩 80.75 0.26 6.72 1.18 0.04 0.40 3.89 1.25 1.61 0.02 3.97 0.12 100.10 注：全铁=FeO+Fe2O3；sg01和sg02为广东丹霞山早白垩世丹霞组地层样品；yt01为江西龙虎山晚白垩世赣州群丹霞地层样品；FeO的含量采用化学滴定法测定.
下载: 导出CSV
表 2 南方典型丹霞地层样品化学指标
Table 2. The Typical Danxia strata samples chemical indicators in southern China
样品号 样品类型 颜色 氧化还原指标 CIA风化指数 sg01 粗砾岩 暗红色 10.13 0.75 sg02 粗砂岩 暗红色 10.19 0.65 yt01 粗砂岩 暗红色 9.83 0.53 注：氧化还原指标：TFe2O3/FeO；化学风化指标CIA={(Al2O3)/[(A12O3)+(CaO*)+(Na2O)+(K2O)]}×100%，表达式中主成分均以摩尔分数表示，CaO*指硅酸盐中的CaO，即全岩中的CaO扣除掉化学沉积的CaO的摩尔分数，CIA实际反映了含铝硅酸盐矿物尤其是长石风化成粘土矿物的程度，CIA值越高，指示硅酸盐矿物中Na、K和Ca矿物从母岩中淋失越多，化学风化越强.由于实验过程中很难精确地分离纯化沉积物样品中的硅酸盐矿物，本文采用McLennan提出的校正方法，即根据自然界硅酸盐矿物中Na和Ca的平均组成，依据沉积物样品中的CaO/Na2O的摩尔比值来计算CIA：如果比值> 1, 以Na2O的摩尔含量代替CaO含量；而若比值< 1，则直接以CaO摩尔含量来计算CIA.
下载: 导出CSV
表 3 南方典型丹霞地层样品穆斯堡尔谱拟合参数结果及铁的赋存状态
Table 3. The result of fitting parameters of Mossbauer spectrum and the occurrence state of iron in typical Danxia formation samples in southern China
样品号 化学种 相对含量（%） IS（mm/s） QS(mm/s) HW(mm/s) H/T sg01 clay-Fe2+ 9.00±0.21 1.079±0.005 2.217±0.010 0.099±0.003 clay-Fe3+ 49.70±0.29 0.292±0.003 0.754±0.005 0.099±0.003 oxides-Fe3+ 41.30±0.32 0.361±0.001 -0.095±0.001 0.099±0.003 45.3±0.14 yt01 clay-Fe2+ 8.10±0.38 1.337±0.008 2.039±0.002 0.169±0.006 clay-Fe3+ 47.60±0.50 0.296±0.003 0.676±0.006 0.169±0.006 oxides-Fe3+ 44.30±0.54 0.351±0.005 -0.102±0.001 0.169±0.006 50.39±0.24
下载: 导出CSV
-
An, L. H., Y, L., H, D., et al., 2019. Photoelectric Conversion on Earth's Surface via Widespread Fe- and Mn-Mineral Coatings. Proceedings of the National Academy of Sciences of the United States of America, 116(20): 9741-9746. https://doi.org/10.1073/pnas.1902473116 Cai, T. S., 2017. Research of the Particularity of Danxia Landform's Development Stage in Southern China(Dissertation). Nanjing University, Nanjing(in Chinese with English abstract). Chen, H. X., 2009. Research of Paleoenvironment and Paleoclimate of Cretaceous in Ya'an Area of Western Sichuan Basin(Dissertation). Chengdu University of Technology, Chengdu(in Chinese with English abstract). Chen, L. Q., Li, P. C., Guo, F. S., et al., 2019. Facies Analysis and Paleoclimate Implications of the Late Cretaceous Danxia Formation in the Danxia Basin, Northern Guangdong Province, South China. Acta Sedimentologica Sinica, 37(1): 17-29(in Chinese with English abstract). Dang, M. Z., et al., 2018. Substitution of Al for Fe in Hematite: A Mössbauer Study. American Mineralogist, 103(5): 799-806. Ding, H. W., Wang, S. Y., Yin, Z., et al., 2014. Geologic Origins of Danxia and Colorful Hills of Zhangye and Comparison with Danxia Landform in Southern China. Arid Land Geography, 37(3): 419-428(in Chinese with English abstract). Dyar, M. D., Agresti, D. G., Schaefer, M. W., et al., 2006. Mössbauer Spectroscopy of Earth and Planetary Materials. Annual Review of Earth and Planetary Sciences, 34: 83-125. https://doi.org/10.1146/annurev.earth. 34. 031405. 125049 doi: 10.1146/annurev.earth.34.031405.125049 Fu, Q., Zhang, G. F., Zhang, K., et al., 2025. Quantitative Representation and Influencing Factors to Landscape Maturity of Danxia Landscape: a Case Study in Mount Danxiashan, Guangdong Province. Earth Science, 50(2): 782-797(in Chinese with English abstract). Guo, F. S., Chen, L. Q., Yan, Z. B., et al., 2020. Definition, Classification, and Danxianization of Danxia Landscapes. Acta Geologica Sinica, 94(2): 361-374(in Chinese with English abstract). Guo, F. S., Jiang, Y. B., Hu, Z. H., et al., 2011. Evolution and Genesis System Features of Danxia Lanform in Longhushan World Geopark. Journal of Mountain Science, 29(2): 195-201(in Chinese with English abstract). Guo, H. T., Xu, Y. X., Qin, K. Z., 2014. Mussbauer Spectra Characteristics of Eight Sulfate Minerals in Oxidization Zone of Hongshan Hs-Epithermal Cu-Au Deposit, Eastern Tianshan, NW China, and Their Geological Significance. Geology and Exploration, 50(3): 486-493(in Chinese with English abstract). Gütlich, P., et al., 2011. Mössbauer Spectroscopy: Applications in Chemistry, Biology, and Nanotechnology. Wiley, Hoboken. Huang, J., Chen, Z. J., Qi, D. L., 2015. Study on Distribution of Danxia Landform in China(First). Mountain Research, 33(4): 385-396(in Chinese with English abstract). Ji, J. P., 2017. Controlling Factors of Color Change in Zhangye Colored Hills and Its Paleoclimatic Significance(Dissertation). Fujian Normal University, Fuzhou(in Chinese with English abstract). Jiang, F. W., Liu, F. J., Huang, B. H., 2017. Characteristics of Geological Disasters of Danxia Landform in Longhushan World Geopark. Journal of East China University of Technology (Social Science), 36(2): 121-125(in Chinese with English abstract). Jiang, Y. B., Guo, F. S., Li, G. R., et al., 2024. Study on the Evoluation of Danxia Landform in Jiangxi Province and Its Structural Factors. Geological Review, 70(1): 44-58(in Chinese with English abstract). Jiang, Z., et al., 2019. Surface Modification-Induced Bhf Reduction in Nanoscale Hematite. Geochemical Transactions, 20(1): 1-10. doi: 10.1186/s12932-019-0061-3 Liu, F. J., 2020. Sedimentary Environment and Geomorphologic Evolution of Danxia Landscape Layer from Danxiashan, Guangdong Province(Dissertation). Chengdu University of Technology, Chengdu(in Chinese with English abstract). Liu, Q., et al., 2020. Iron Speciation in Clay Minerals by Mössbauer Spectroscopy. Clays and Clay Minerals, 68(2), 102-115. Ma, X. X., Wang, H. L., Zhang, Z. W., et al., 2014. Distribution Characteristics of Iron Species in Three Faults along the Eastern Margin of the Tibetan Plateau, China. Bulletin of Mineralogy, Petrology and Geochemistry, 33(3): 348-354(in Chinese with English abstract). Michel, F. M., Ehm, L., Antao, S. M., et al., 2010. The Structure of Ferrihydrite, a Nanocrystalline Material. ChemInform, 38(40): 200740005. https://doi.org/10.1002/chin.200740005 Peng, H., 2000. A Survey of the Danxia Landform Research in China. Scientia Geographica Sinica, 20(3): 203-211(in Chinese with English abstract). Peng, H., 2020. The Basic Questions on Danxia Landform. China Danxia. Springer, Singapore, 3-21. https://doi.org/10.1007/978-981-13-5959-0_1 Peng, H., 2002. Research on the Formation Mechanism of Danxia Landform. Journal of Sun Yat sen University (Natural Science Edition), 41(3): 87-91. Rancourt, D. G., Ping, J. Y., 1991. Voigt-Based Methods for Arbitrary-Shape Static Hyperfine Parameter Distributions in Mössbauer Spectroscopy. Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms, 58(1): 85-97. https://doi.org/10.1016/0168-583x(91)95681-3 Shi, Y. X., 2023. Sedimentary Characteristics and Geochemistry of Late Cretaceous Red Beds in Danxia Basin(Dissertation). East China Institute of Technology, Fuzhou(in Chinese with English abstract). Shu, L., Faure, M., Wang, B., Zhou, X., et al., 2019. Cretaceous Tectonic Evolution of South China: A Preliminary Synthesis. Earth-Science Reviews, 196: 102872. doi: 10.1016/j.earscirev.2019.05.016 Song, C. H., Bai, J. F., Zhao, Y. D., et al., 2005. The Color of Lacustrine Sediments Recorded Climatic Changes from 13 to 4.5 Myr in Linxia Basin. Acta Sedimentologica Sinica, 23(3): 507-513(in Chinese with English abstract). Wang, J. M., Yan, B. H., Wu, S., et al., 2012. Climate Changes Recorded by Colors of the Miocene Sediments in Northeast Qaidam Basin. Gansu Geology, 21(1): 6-11(in Chinese with English abstract). Wang, Q. X., Ping, X. Q., Zheng, J. P., et al., 2023. Mineral Ferric Iron Contents of Peridotite Xenoliths by M? ssbauer Spectroscopy: Oxygen Fugacity Applications. Earth Science, 48(3): 1217-1231(in Chinese with English abstract). Wang, S. J., Zeng, F. G., Huang, X. Z., et al., 1998. The Mssbauer Effect of Clay Minerals in Oil Basin and Its Application: Taking Tertiary System of Qaidam Basin as an Example. Acta Sedimentologica Sinica, 16(2): 109-112(in Chinese with English abstract). Ye, Z. Y., Lu, J. B., Li, S. N., et al., 2021. Preliminary-Discussion on Red Bed Hematite Genetic Mode in Danxia Basin, Northern Guangdong. Coal Geology of China, 33(S1): 61-64(in Chinese with English abstract). Zhang, F. L., Yi, F., Chen, Y. L., et al., 1997. Determination of the Optimum Thickneseof an Absorber in Mossbauer Spectroscopy. Journal of Wuhan University (Natural Science Edition), (3): 348-352(in Chinese with English abstract). Zheng, G. D., 2008. Iron Speciation by Mssbauer Spectroscopy and Its Implications in Various Studies on the Earth Surface Processes. Bulletin of Mineralogy, Petrology and Geochemistry, 27(2): 161-168(in Chinese with English abstract). Zheng, G. D., Fu, B. H., Duan, Y., et al., 2004. Iron Speciation Related to Color of Jurassic Sedimentary Rocks in Turpan Basin, Northwest China. Journal of Radioanalytical and Nuclear Chemistry, 261(2): 421-427. https://doi.org/10.1023/B:JRNC.0000034880.20577.fb Zhou, X. J., 2003. A Study on North-South Differences of the Danxia Landform Pattern and Its Tourism Values in China. Journal of Mountain Research, 21(2): 180-186(in Chinese with English abstract). Zhou, H., et al., 2022. Diagenetic Iron Oxide Cements in Red Beds. Sedimentary Geology, 428: 106075. Zhu, Z. J., Huang, B. H., Guo, F. S., et al., 2012. Cretaceous Braided River Facies Sediments and Danxia Landform Development Characteristics in Longhushan World Geopark, Jiangxi. Acta Geoscientica Sinica, 33(3): 379-387(in Chinese with English abstract). 蔡天赦, 2017. 中国南方丹霞地貌发育阶段特殊性研究(硕士学位论文). 南京: 南京大学. 陈海霞, 2009. 川西雅安地区白垩纪古环境古气候研究. 成都: 成都理工大学. 陈留勤, 李鹏程, 郭福生, 等, 2019. 粤北丹霞盆地晚白垩世丹霞组沉积相及古气候意义. 沉积学报, 37(1): 17-29. 丁宏伟, 王世宇, 尹政, 等, 2014. 张掖丹霞暨彩色丘陵地质成因及与南方丹霞地貌之对比. 干旱区地理, 37(3): 419-428. 傅强, 章桂芳, 张珂, 等, 2025. 丹霞地貌发育程度的定量指示及影响因素: 以广东丹霞山为例. 地球科学, 50(2): 782-797. doi: 10.3799/dqkx.2023.050 郭福生, 陈留勤, 严兆彬, 等, 2020. 丹霞地貌定义、分类及丹霞作用研究. 地质学报, 94(2): 361-374. 郭福生, 姜勇彪, 胡中华, 等, 2014. 龙虎山世界地质公园丹霞地貌成景系统特征及其演化. 山地学报, 29(2): 195-201. 郭海棠, 许英霞, 秦克章, 2014. 东疆红山Cu-Au矿床氧化带硫酸盐矿物穆斯堡尔谱特征及其意义. 地质与勘探, 50(3): 486-493. 黄进, 陈致均, 齐德利, 2015. 中国丹霞地貌分布(上). 山地学报, 33(4): 385-396. 吉金平, 2017. 张掖彩色丘陵颜色变化的控制因素及其古气候意义(硕士学位论文). 福州: 福建师范大学. 姜伏伟, 刘富军, 黄宝华, 2017. 龙虎山世界地质公园丹霞地貌地质灾害特征研究. 东华理工大学学报(社会科学版), 36(2): 121-125. 姜勇彪, 郭福生, 黎广荣, 等, 2024. 江西丹霞地貌演化阶段与分布及其构造控制探讨. 地质论评, 70(1): 44-58. 刘富军, 2020. 广东丹霞山丹霞地貌成景地层沉积环境与地貌演化(博士学位论文). 成都: 成都理工大学. 马向贤, 王华林, 张志武, 等, 2014. 青藏高原东缘3条断裂带断层泥铁元素化学种的分布特征. 矿物岩石地球化学通报, 33(3): 348-354. 彭华, 2000. 中国丹霞地貌研究进展. 地理科学, 20(3): 203-211. 彭华, 2002. 丹霞地貌形成机制研究. 中山大学学报(自然科学版), 41(3): 87-91. 史月欣, 2023. 丹霞盆地晚白垩世红层沉积特征及地球化学研究(硕士学位论文). 东华理工大学, 抚州. 宋春晖, 白晋锋, 赵彦德, 等, 2005. 临夏盆地13~4.4Ma湖相沉积物颜色记录的气候变化探讨. 沉积学报, 23(3): 507-513. 王杰民, 闫宝华, 吴松, 等, 2012. 柴达木盆地东北部中新世沉积物色度记录的气候变化. 甘肃地质, 21(1): 6-11. 王秋霞, 平先权, 郑建平, 等, 2023. 穆斯堡尔光谱仪在揭示地幔氧逸度研究中的应用. 地球科学, 48(3): 1217-1231. 王随继, 曾凡刚, 黄杏珍, 等, 1998. 含油气盆地中粘土矿物的穆斯堡尔效应及应用: 以柴达木盆地第三系为例. 沉积学报, 16(2): 109-112. 叶泽宇, 陆金波, 李世念, 等, 2021. 粤北丹霞盆地红层赤铁矿成因模式初步探讨. 中国煤炭地质, 33(S1): 61-64. 张富良, 易凡, 陈义龙, 等, 1997. 穆斯堡尔谱学中样品最佳厚度的确定. 武汉大学学报(自然科学版), (3): 348-352. 郑国东, 2008. 基于穆斯堡尔谱技术的铁化学种及其在相关表生地球科学研究中的应用. 矿物岩石地球化学通报, 27(2): 161-168. 周学军, 2003. 中国丹霞地貌的南北差异及其旅游价值. 山地学报, 21(2): 180-186. 朱志军, 黄宝华, 郭福生, 等, 2012. 江西龙虎山世界地质公园白垩系辫状河相沉积及其丹霞地貌发育特征. 地球学报, 33(3): 379-387 -
