Slope Reliability Analysis Considering Degradation and Spatial Variability of Subsidence Zone Parameters
-
摘要: 消落带上土体因反复干湿循环导致抗剪强度参数退化，且参数存在空间变异性，二者均是影响边坡稳定性的关键因素，而现有研究多仅考虑其一. 为此，提出同时考虑这两种因素的边坡稳定可靠度分析新方法. 其中，使用Karhunen⁃Loève法模拟参数随机场，利用切片逆回归法进行降维，进而构建基于增强鲸鱼优化算法的极端梯度提升代理模型. 以三峡库区白水河滑坡为例进行分析，探讨了消落带抗剪强度参数退化和空间变异性对滑坡失效概率的影响. 结果表明：所提出方法能极大提高计算效率并准确估算滑坡失效概率（Pf）；滑坡Pf随消落带参数退化次数增加而增大，在第四次后趋于平稳；当不考虑水位变化时，饱和渗透系数空间变异性对可靠度结果影响较小，而有效内摩擦角的空间变异性对安全系数分布影响高于有效粘聚力.Abstract: The soil on the ablation zone is degraded in shear strength parameters due to repeated wet and dry cycles, and there is spatial variability in the parameters, both of which are key factors affecting slope stability, while most of the existing studies only consider one of them. For this reason, a new method for analyzing the stability and reliability of slopes that considers both factors is proposed. In this, a parameter random field is simulated using the Karhunen⁃Loève method, and dimensionality reduction is performed using sliced inverse regression, which in turn leads to the construction of an extreme gradient boosting surrogate model based on the augmented whale optimization algorithm. The Three Gorges Reservoir Area Baishuihe landslide is analyzed as an example to explore the effects of degradation of shear strength parameters and spatial variability of the ablation zone on the probability of landslide failure. The results show that: the proposed method can greatly improve the computational efficiency and accurately estimate the probability of landslide failure (Pf); landslide Pf increases with the number of degradation times of the parameters of the fallout zone and tends to stabilize after the fourth time; the spatial variability of saturated permeability coefficients has a small effect on the reliability results when water level changes are not taken into account, while the spatial variability of the effective internal friction angle has a higher effect on the distribution of the factor of safety than that of the effective cohesive force.
-
图 13 FS和Pf随退化次数的变化
a. 平均FS; b. Pf
Fig. 13. Variation of FS and Pf with the number of degradations
图 15 考虑不同参数空间变异性下的FS和Pf的变化情况
Fig. 15. Variation of FS and Pf considering spatial variability of different parameters
图 16 考虑不同参数空间变异性下的FS直方图和拟合曲线
a. c'；b. φ'；c. 不考虑参数空间变异性；d. c'，φ'，ks
Fig. 16. Considering FS histograms and fitted curves under different parameter spatial variability
表 1 土体参数随退化次数的取值
Table 1. Values of soil parameters with the number of degradations
Di c' φ' 0 18.32 19.31 1 15.58 18.33 2 13.21 17.66 3 10.15 16.78 4 8.71 16.39 5 8.27 16.14 6 7.84 15.74 7 7.40 15.46
下载: 导出CSV
表 2 滑坡土体参数统计信息
Table 2. Statistical data of landslide soil parameters
分析 参数 均值(滑坡体) 均值(地基) 变异系数(滑坡体) 分布类型 稳定 c′ 18.32 kPa 190 kPa 0.3 对数正态 φ′ 19.31° 30.4° 0.2 γ 20.7 kN/m 25.6 kN/m3 - 确定性 渗流 θs 0.43 m3/m3 - - θr 0.02 m3/m3 - - a 50 kPa n 1.45 ks 0.43 m/d 0.01 m/d 0.6 对数正态
下载: 导出CSV
表 3 不同退化次数下白水河滑坡的安全系数
Table 3. FS in the Baishuihe landslide under different numbers of degradations
Di FS 0 1.167 1 1.119 2 1.082 3 1.024 4 0.997 5 0.985 6 0.969 7 0.956
下载: 导出CSV
-
Andreea, C., 2016. Unsaturated Slope Stability and Seepage Analysis of a Dam. Energy Procedia, 85: 93-98. https://doi.org/10.1016/j.egypro.2015.12.278 Deng, H. F., Xiao, Y., Fang, J. C., et al., 2017. Shear Strength Degradation and Slope Stability of Soils at Hydro-Fluctuation Belt of River Bank Slope during Drying-Wetting Cycle. Rock and Soil Mechanics, 38(9): 2629-2638(in Chinese with English abstract). Deng, Z. P., Pan, M., Niu, J. T., et al., 2021. Slope Reliability Analysis in Spatially Variable Soils Using Sliced Inverse Regression: Based Multivariate Adaptive Regression Spline. Bulletin of Engineering Geology and the Environment, 80(9): 7213-7226. https://doi.org/10.1007/s10064-021-02353-9 Deng, Z. P., Zhong, M., Pan, M., et al., 2024a. Slope Reliability Analysis Considering Parameter Spatial Variability and Based on Efficient Agent Model. Chinese Journal of Geotechnical Engineering, 46(2): 273-281(in Chinese with English abstract). Deng, Z. P., Zhong, M., Pan, M., et al., 2024b. Reliability Evaluation of Slopes Considering Spatial Variability of Soil Parameters Based on Efficient Surrogate Model. ASCE-ASME Journal of Risk and Uncertainty in Engineering Systems, Part A: Civil Engineering, 10: 04023057. https://doi.org/10.1061/ajrua6.rueng-1172 Deng, Z. P., Zou, Y., Pan, M., et al., 2025. Time-Varying Reliability Analysis of Unsaturated Reservoir Bank Slopes under Water Level Landing Considering Multi-Parameter Spatial Variability. Chinese Journal of Geotechnical Engineering, 47(7): 1410-1421(in Chinese with English abstract). Deng, Z. P., Zou, Y., Pan, M., et al., 2024. Reliability Analysis of Unsaturated Earth and Rock Dam Slopes Considering Multi-Parameter Spatial Variability. Journal of Basic Science and Engineering, 32(4): 1108-1123(in Chinese with English abstract). Fredlund, D. G., Morgenstern, N. R., Widger, R. A., 1978. The Shear Strength of Unsaturated Soils. Canadian Geotechnical Journal, 15(3): 313-321. https://doi.org/10.1139/t78-029 Gu, X., Wang, L., Ou, Q., et al., 2023. Efficient Stochastic Analysis of Unsaturated Slopes Subjected to Various Rainfall Intensities and Patterns. Geoscience Frontiers, 14(1): 101490. https://doi.org/10.1016/j.gsf.2022.101490 Guardiani, C., Soranzo, E., Wu, W., 2022. Time-Dependent Reliability Analysis of Unsaturated Slopes under Rapid Drawdown with Intelligent Surrogate Models. Acta Geotechnica, 17(4): 1071-1096. https://doi.org/10.1007/s11440-021-01364-w Huang, F. M., Liu, K. J., Jiang, S. H., et al., 2025. Optimization Method of Conditioning Factors Selection and Combination for Landslide Susceptibility Prediction. Journal of Rock Mechanics and Geotechnical Engineering, 17(2): 722-746. https://doi.org/10.1016/j.jrmge.2024.04.029 Jiang, S. H., Xiong, W., Zhu, G. Y., et al., 2024. Probabilitic Analysis of Reservoir Landslides Considering the Spatial Variation of Seepage Parameters under the Conditions of Rainstorm and Sudden Drop of Water Level. Earth Science, 49(5): 1679-1691(in Chinese with English abstract). Jing, J., Hou, J. M., Sun, W., et al., 2022. Study on Influencing Factors of Unsaturated Loess Slope Stability under Dry-Wet Cycle Conditions. Journal of Hydrology, 612: 128187. https://doi.org/10.1016/j.jhydrol.2022.128187 Li, D. Q., Jiang, S. H., Zhou, C. B., et al., 2013. A Non-intrusive Stochastic Finite Element Method for Slope Reliability Analysis Considering Spatial Variability of Parameters. Chinese Journal of Geotechnical Engineering, 35(8): 1413-1422(in Chinese with English abstract). Li, D. X., Li, L., Cheng, Y., et al., 2022. Reservoir Slope Reliability Analysis under Water Level Drawdown Considering Spatial Variability and Degradation of Soil Properties. Computers and Geotechnics, 151: 104947. https://doi.org/10.1016/j.compgeo.2022.104947 Liu, X., Li, D. Q., Cao, Z. J., et al., 2020. Adaptive Monte Carlo Simulation Method for System Reliability Analysis of Slope Stability Based on Limit Equilibrium Methods. Engineering Geology, 264: 105384. https://doi.org/10.1016/j.enggeo.2019.105384 Luo, S. L., Huang, D., Peng, J. B., et al., 2024. Insights into Reservoir-Triggered Landslides Development and Its Influence Factors in the Three Gorges Reservoir Area, China. Journal of Earth Science, 35(6): 1979-1997. https://doi.org/10.1007/s12583-024-0024-1 Ma, G. T., Rezania, M., Mousavi Nezhad, M., et al., 2022. Uncertainty Quantification of Landslide Runout Motion Considering Soil Interdependent Anisotropy and Fabric Orientation. Landslides, 19(5): 1231-1247. https://doi.org/10.1007/s10346-021-01795-2 Nadimi-Shahraki, M. H., Zamani, H., Mirjalili, S., 2022. Enhanced Whale Optimization Algorithm for Medical Feature Selection: a COVID-19 Case Study. Computers in Biology and Medicine, 148: 105858. https://doi.org/10.1016/j.compbiomed.2022.105858 Pan, M., Jiang, S. H., Liu, X., et al., 2024. Sequential Probabilistic back Analyses of Spatially Varying Soil Parameters and Slope Reliability Prediction under Rainfall. Engineering Geology, 328: 107372. https://doi.org/10.1016/j.enggeo.2023.107372 Peng, X., Li, D. Q., Cao, Z. J., et al., 2016. Reliability Design Method for Rocky Slopes Based on Monte Carlo Simulation. Chinese Journal of Rock Mechanics and Engineering, 35(A02): 3794-3804(in Chinese with English abstract). Phoon, K. K., Huang, S. P., Quek, S. T., 2002. Implementation of Karhunen-Loeve Expansion for Simulation Using a Wavelet-Galerkin Scheme. Probabilistic Engineering Mechanics, 17(3): 293-303. https://doi.org/10.1016/s0266-8920(02)00013-9 Phoon, K. K., Kulhawy, F. H., 1999. Characterization of Geotechnical Variability. Canadian Geotechnical Journal, 36(4): 612-624. https://doi.org/10.1139/t99-038 Richards, L. A., 1931. Capillary Conduction of Liquids through Porous Mediums. Physics, 1(5): 318-333. https://doi.org/10.1063/1.1745010 van Genuchten, M. T., 1980. A Closed-Form Equation for Predicting the Hydraulic Conductivity of Unsaturated Soils. Soil Science Society of America Journal, 44(5): 892-898. https://doi.org/10.2136/sssaj1980.03615995004400050002x Wang, H., Wang, Y. J., Jin, F. J., 2024. Stability of Expansive Soil Slopes under Wetting-Drying Cycles Based on the Discrete Element Method. Water, 16(6): 861. https://doi.org/10.3390/w16060861 Wang, W. D., Wang, P. C., Zhang, Z. H., 2022. Study on Gravel Soil Strength Degradation and Its Influence on the Slope Stability in Reservoir Bank Fluctuating Zone. Engineering Failure Analysis, 134: 105980. https://doi.org/10.1016/j.engfailanal.2021.105980 Wang, X. G., Zhan, H. B., Wang, J. D., et al., 2019. On the Mechanical Damage to Tailings Sands Subjected to Dry-Wet Cycles. Bulletin of Engineering Geology and the Environment, 78(6): 4647-4657. https://doi.org/10.1007/s10064-018-1427-y Yang, X. F., Chen, D. X., Liu, Y., 2022. Fissure Evolution and Slope Stability of Granite Residual Soil under Dry and Wet Cycles. Journal of Xiamen University (Natural Science), 61(4): 591-599(in Chinese with English abstract). Yin, Y. P., Wang, L. Q., Zhang, W. G., et al., 2022. Research on the Collapse Process of a Thick-Layer Dangerous Rock on the Reservoir Bank. Bulletin of Engineering Geology and the Environment, 81(3): 109. https://doi.org/10.1007/s10064-022-02618-x Zeng, X. W., Pan, M, Deng, Z. P., et al., 2025. Probabilistic Analysis of Slope Stability under Random Rainfall Considering Spatial Variability of Parameters. Journal of Civil and Environmental Engineering, 1-12[2025-07-04]. https://kns-cnki-net.webvpn.nit.edu.cn/kcms/detail/50.1218.TU.20250506.1015.004.html (in Chinese with English abstract).Zhang, J., Luo, C., Wu, C. G., et al., 2025. System Reliability Analysis of Soil-Nailed Slopes. Engineering Failure Analysis, 176: 109613. https://doi.org/10.1016/j.engfailanal.2025.109613 Zhang, Q. Q., Zhang, H. B., Wang, L. G., et al., 2024a. Effect of Structural Characteristics on the Stability of Multi-Weak Rock Slopes Considering the Spatial Variability of Geotechnical Parameters. Scientific Reports, 14: 30618. https://doi.org/10.1038/s41598-024-82296-9 Zhang, W. G., Li, H. R., Han, L., et al., 2022. Slope Stability Prediction Using Ensemble Learning Techniques: a Case Study in Yunyang County, Chongqing, China. Journal of Rock Mechanics and Geotechnical Engineering, 14(4): 1089-1099. https://doi.org/10.1016/j.jrmge.2021.12.011 Zhang, W. G., Ran, B., Gu, X., et al., 2024b. Efficient Reliability Analysis of Unsaturated Slope Stability under Rapid Drawdown Using XGBoost-Based Surrogate Model. Soils and Foundations, 64(6): 101539. https://doi.org/10.1016/j.sandf.2024.101539 Zhang, W. G., Ran, B, Gu, X., et al., 2025. Analysis of Bank Slope Stability Reliability of Heishuihe under the Combined Effect of Reservoir Level Change and Rainfall. Journal of Civil and Environmental Engineering, 1-10[2025-07-04]. https://kns-cnki-net.webvpn.nit.edu.cn/kcms/detail/50.1218.TU.20241031.1256.002.html (in Chinese with English abstract).Zhang, W. G., Wu, C. Z., Tang, L. B., et al., 2023. Efficient Time-Variant Reliability Analysis of Bazimen Landslide in the Three Gorges Reservoir Area Using XGBoost and LightGBM Algorithms. Gondwana Research, 123: 41-53. https://doi.org/10.1016/j.gr.2022.10.004 Zhong, Z. X., Hu, B., Li, J., et al., 2025. Impact of Rainfall Dry-Wet Cycles on Slope Deformation and Landslide Prediction in Open-Pit Mines: a Case Study of Mohuandang Landslide, Emeishan, China. Results in Engineering, 26: 105011. https://doi.org/10.1016/j.rineng.2025.105011 邓华锋, 肖瑶, 方景成, 等, 2017. 干湿循环作用下岸坡消落带土体抗剪强度劣化规律及其对岸坡稳定性影响研究. 岩土力学, 38(9): 2629-2638. 邓志平, 钟敏, 潘敏, 等, 2024a. 考虑参数空间变异性和基于高效代理模型的边坡可靠度分析. 岩土工程学报, 46(02): 273-281. 邓志平, 邹艺, 潘敏, 等, 2024b. 考虑多参数空间变异性的非饱和土石坝坝坡可靠度分. 应用基础与工程科学学报, 32(4): 1108-1123. 邓志平, 邹艺, 潘敏, 等, 2025. 水位降落下考虑多参数空间变异性的非饱和库岸边坡时变可靠度分析. 岩土工程学报, 47(7): 1410-1421. 蒋水华, 熊威, 朱光源, 等, 2024. 暴雨及水位骤降条件下渗流参数空间变异的水库滑坡概率分析. 地球科学, 49(5): 1679-1691. doi: 10.3799/dqkx.2022.361 李典庆, 蒋水华, 周创兵, 等, 2013. 考虑参数空间变异性的边坡可靠度分析非侵入式随机有限元法. 岩土工程学报, 35(8): 1413-1422. 彭兴, 李典庆, 曹子君, 等, 2016. 基于蒙特卡洛模拟的岩质边坡可靠度设计方法. 岩石力学与工程学报, 35(A02): 3794-3804. 杨雪菲, 陈东霞, 刘越, 2022. 干湿循环下花岗岩残积土裂隙演化及边坡稳定. 厦门大学学报(自然科学版), 61(4): 591-599. 曾祥薇, 潘敏, 邓志平, 等, 2025. 随机降雨下考虑参数空间变异性的边坡稳定概率分析. 土木与环境工程学报(中英文), 1-12[2025-07-04]. https://kns-cnki-net.webvpn.nit.edu.cn/kcms/detail/50.1218.TU.20250506.1015.004.html 仉文岗, 冉博, 顾鑫, 等, 2025. 库水位变化和降雨联合作用下黑水河岸坡稳定可靠度分析. 土木与环境工程学报(中英文), 1-10[2025-07-04]. https://kns-cnki-net.webvpn.nit.edu.cn/kcms/detail/50.1218.TU.20241031.1256.002.html -
