Mechanisms of High-Speed Long-Distance Landslides under Synergistic Effects of Glacial Meltwater and Rainfall
-
摘要:
高速远程滑坡灾变模式复杂，诱发因素多样，其启滑机制及动力学演变阶段的判定是研究的重点与难点.以易贡高速远程滑坡为例，融合静力学反演与动力学模拟，揭示了冰川融水与降雨共同作用下的滑坡触发机制与运动特性.基于遥感影像、环剪试验与数字高程模型，采用极限平衡法标定关键参数（孔压系数），并在滑移路径预设松散堆积层，实现了剪切液化与铲刮效应的定量表征.结果表明，降雨与冰川融水显著增加孔隙水压力，降低抗剪强度，诱发滑坡失稳；运动过程中剪切液化与铲刮效应使滑体速度提升了32.1%，规模扩大了28.3%.模拟结果与实际工况吻合良好，为类似灾害风险防控提供了科学依据与方法.
Abstract:High-speed long-distance landslides exhibit complex disaster patterns and diverse triggering factors, making the determination of their initiation mechanisms and dynamic evolution stages a key research focus and challenge. This study takes the Yigong high-speed long-distance landslide as an example and integrates static inversion with dynamic simulation to reveal the triggering mechanism and movement characteristics of the landslide under the combined influence of glacial meltwater and rainfall. Based on remote sensing images, ring shear tests, and digital elevation models, key parameters (pore pressure coefficient) were calibrated using the limit equilibrium method, and a loose accumulation layer was preset along the sliding path to quantitatively characterize shear liquefaction and the scraping effect. The results show that rainfall and glacial meltwater significantly increase pore water pressure and reduce shear strength, leading to landslide instability. Furthermore, shear liquefaction and the scraping effect during motion increased the sliding speed by 32.1% and expanded the landslide scale by 28.3%. The simulation results agree well with actual conditions, providing a scientific basis and methodology for risk prevention and control of similar geological disasters.
-
图 1 2000年5月4日（滑坡发生25 d后）获得的陆地卫星-7号图像（Delaney and Evans, 2015）
Fig. 1. Landsat-7 image obtained on May 4, 2000 (25 days after the landslide occurrence)(Delaney and Evans, 2015)
图 2 易贡滑坡典型剖面的Geo-Slope计算结果
a.滑坡条分模型；b.自重最大块体与自重最小块体的静力学分析
Fig. 2. Geo-Slope calculation results for a typical profile of the Yigong landslide
图 3 集成滑坡模拟模型的操作流程及本构模型原理（Dang et al., 2019）
Fig. 3. The operation flowchart and constitutive model principle of the integrated landslide simulation model (Dang et al., 2019)
图 4 高精度环剪仪及设计原理（Setiawan et al., 2018）
a.仪表箱；b.主控单元作为控制、监控箱；c.计算机系统；d.减压系统；e.孔隙压力供应系统；f.设计原理
Fig. 4. High precision ring shear apparatus (Setiawan et al., 2018)
图 5 由高精度环剪仪不排水剪切产生的典型有效应力路径（Tan et al., 2020）
Fig. 5. Typical effective stress path generated by the high precision ring shear apparatus (Tan et al., 2020)
图 6 集成滑坡模拟模型模拟结果
Fig. 6. The simulation results of the integrated landslide simulation model
图 8 结果对比
a. 滑坡前沿速度剖面；b. 滑坡堆积体厚度剖面. 黄色曲线据Zhou et al.（2020）；绿色曲线据Delaney and Evans（2015）；红色曲线据本文，其中，实线表示考虑了剪切液化与铲刮效应，虚线表示未考虑剪切液化与铲刮效应）；Delaney and Evans（2015）展示的地形剖面图以黑色表示，估计的源区用虚线棕色标出
Fig. 8. Result comparison
图 9 易贡滑坡A-A'剖面机理
Zhou et al.（2016）；Dai et al.（2021）；万佳威等（2021）
Fig. 9. Mechanism of the A-A' profile of the Yigong landslide
图 10 1998—2000年易贡3、4月份温度与降雨情况
Zhou et al.（2016）；Guo et al.（2023）
Fig. 10. Temperature and rainfall conditions in Yigong during March and April from 1998 to 2000
表 1 极限平衡法滑体参数
Table 1. Parameters of the sliding mass in the limit equilibrium method
参数 取值 单位重量（U） 18.45 kN/m3 粘聚力（c） 13 kPa 摩擦角（φ） 36.2°
下载: 导出CSV
表 2 有效路径图中符号及缩写的意义
Table 2. The meaning of symbols and abbreviations in the effective stress path
符号或缩写 意义 $ {\sigma }_{0} $ 初始法向应力 $ {\tau }_{0} $ 初始剪切应力 $ {\sigma }_{\mathit{S}\mathit{S}} $ 稳定状态下的法向应力 $ {\tau }_{SS} $ 稳定状态下的剪切应力 cp 稳定状态下的黏聚力 $ I({\sigma }_{0}, {\tau }_{0}) $ 初始状态点，表示土体在初始条件下的应力状态 $ SS $ 稳定状态点，表示土体在长时间剪切后达到的稳定状态 $ F $ 破坏点，表示土体在剪切过程中达到的破坏状态 FLP 破坏线（红色），表示极限破坏点的应力路径 FLM 稳定线（蓝色），表示稳定状态下的应力路径 $ {\varphi }_{\alpha \left(ss\right)} $ 稳定摩擦角线（绿色），表示稳定状态下的摩擦角 $ {\varphi }_{p} $ 破坏摩擦角（红色），表示破坏状态下的摩擦角 $ {\varphi }_{m} $ 稳定摩擦角（蓝色），表示稳定状态下的摩擦角
下载: 导出CSV
表 3 LS-RAPID模型中使用的参数
Table 3. Parameters used in the LS-RAPID model
参数 取值 来源 侧压比 0.4 文献 滑坡体内摩擦系数 0.35 文献 运动过程中的摩擦系数 0.732 试验 稳态剪切阻力 56 kPa 试验 孔隙压力产生率 0.2 文献 峰值摩擦系数 0.65 文献 峰值粘聚力 100 kPa 文献 剪切位移/强度折减开始时 10.5 mm 试验 剪切位移/稳态开始时 5 000 mm 试验 岩土体的总单位重量 18.45 kN/m3 试验
下载: 导出CSV
-
Cai, Z. Y., Liu, E. L., Chen, N. S., et al., 2022. Numerical Analysis of the Initiation and Sliding Process of the Yigong Landslide Using a Continuous-Discontinuous Method. Environmental Earth Sciences, 81(5): 150. https://doi.org/10.1007/s12665-022-10279-y Cui, P., Chen, R., Xiang, L. Z., et al., 2014. Risk Analysis of Mountain Hazards in Tibetan Plateau under Global Warming. Progressus Inquisitiones DE Mutatione Climatis, 10(2): 103-109 (in Chinese with English abstract). Dai, Z. L., Wang, F. W., Cheng, Q. G., et al., 2019. A Giant Historical Landslide on the Eastern Margin of the Tibetan Plateau. Bulletin of Engineering Geology and the Environment, 78(3): 2055-2068. https://doi.org/10.1007/s10064-017-1226-x Dai, Z. L., Xu, K., Wang, F. W., et al., 2021. Numerical Investigation on the Kinetic Characteristics of the Yigong Debris Flow in Tibet, China. Water, 13(8): 1076. https://doi.org/10.3390/w13081076 Dang, K., Sassa, K., Konagai, K., et al., 2019. Recent Rainfall-Induced Rapid and Long-Traveling Landslide on 17 May 2016 in Aranayaka, Kagelle District, Sri Lanka. Landslides, 16(1): 155-164. https://doi.org/10.1007/s10346-018-1089-7 Delaney, K. B., Evans, S. G., 2015. The 2000 Yigong Landslide (Tibetan Plateau), Rockslide-Dammed Lake and Outburst Flood: Review, Remote Sensing Analysis, and Process Modelling. Geomorphology, 246: 377-393. https://doi.org/10.1016/j.geomorph.2015.06.020 Du, Y., Zhang, H. D., Xie, M. W., et al., 2024. A Possible Mechanism of High-Speed and Long-Distance Rockslides. Journal of Earth Science, 35(6): 2158-2162. https://doi.org/10.1007/s12583-024-2025-5 Ekström, G., Stark, C. P., 2013. Simple Scaling of Catastrophic Landslide Dynamics. Science, 339(6126): 1416-1419. https://doi.org/10.1126/science.1232887. Evans, S. G., Delaney, K. B., 2010. Characterization of the 2000 Yigong Zangbo River (Tibet) Landslide Dam and Impoundment by Remote Sensing. Natural and Artificial Rockslide Dams. Springer Berlin Heidelberg, Berlin, Heidelberg: 543-559. https://doi.org/10.1007/978-3-642-04764-0_22 Gao, H. Y., Gao, Y., Li, B., et al., 2023. The Dynamic Simulation and Potential Hazards Analysis of the Yigong Landslide in Tibet, China. Remote Sensing, 15(5): 1322. https://doi.org/10.3390/rs15051322 Gao, Y., Li, B., Gao, H. Y., et al., 2020. Progress and Issues in the Research of Impact and Scraping Effect of High-Elevation and Long-Runout Landslide. Journal of Geomechanics, 26(4): 510-519 (in Chinese with English abstract). Guo, C. B., Wu, R. A., Zhong, N., et al., 2024. Large Landslides along Active Tectonic Zones of Eastern Tibetan Plateau: Background and Mechanism of Landslide Formation. Earth Science, 49(12): 4635-4658 (in Chinese with English abstract). Guo, C. B., Yuan, H., Wu, R. A., et al., 2023. Research Review and Prospects of the 2000 Giant Yigong Long-Runout Landslide: Volume, Formation Mechanism and Recurrence Period, Tibetan Plateau, China. Frontiers in Earth Science, 10: 1017611. https://doi.org/10.3389/feart.2022.1017611 Ho, C. Y. J., Zhang, Z., Tan, Y. J., 2025. Analysing Dynamics of the 2000 Yigong Landslide in the Tibetan Plateau Using Seismic Observations. Landslides, 22(8): 2701-2713. https://doi.org/10.1007/s10346-025-02525-8 Hu, M. J., Pan, H. L., Zhu, C. Q., et al., 2015. High-Speed Ring Shear Tests to Study the Motion and Acceleration Processes of the Yingong Landslide. Journal of Mountain Science, 12(6): 1534-1541. https://doi.org/10.1007/s11629-014-3059-4 Hu, M. J., Wang, F. W., Cheng, Q. G., 2009. Formation of Tremendous Yigong Landslide Based on High-Speed Shear Tests. Chinese Journal of Geotechnical Engineering, 31(10): 1602-1606 (in Chinese with English abstract). Li, J. P., Jiang, S. H., Huang, F. M., et al., 2024. Investigation of Large Deformation Failure Characteristics of Slopes under Rainfalls Considering Spatial Variability of Hydraulic Conductivity. Journal of Basic Science and Engineering, 32(1): 72-84 (in Chinese with English abstract). Liu, W., He, S. M., 2018. Dynamic Simulation of a Mountain Disaster Chain: Landslides, Barrier Lakes, and Outburst Floods. Natural Hazards, 90(2): 757-775. https://doi.org/10.1007/s11069-017-3073-2 Lü, J. T., Wang, Z. H., Zhou, C. H., 2003. Discussion on the Occurrence of Yigong Landslide in Tibet. Earth Science, 28(1): 107-110 (in Chinese with English abstract). Niu, B., Feng, C., Cong, J. Y., et al., 2023. Analysis of Disaster Area of Three-Dimensional High-Speed Remote Landslide Based on CDEM Particle Flow. Chinese Journal of Rock Mechanics and Engineering, 42(S2): 4018-4027 (in Chinese with English abstract). Ren, J. W., Shan, X. J., Shen, J., et al., 2001. Geological Characteristics and Kinematics of the Rock Fall-Landslide in Yi'ong, Southeastern Tibet. Geological Review, 47(6): 642-647, 4 (in Chinese with English abstract). Sassa, K., 1989. Special Lecture: Geotechnical Model for the Motion of Landslides. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 26(2): 88. https://doi.org/10.1016/0148-9062(89)90311-2 Sassa, K., Fukuoka, H., Wang, G. H., et al., 2004. Undrained Dynamic-Loading Ring-Shear Apparatus and Its Application to Landslide Dynamics. Landslides, 1(1): 7-19. https://doi.org/10.1007/s10346-003-0004-y Sassa, K., He, B., Miyagi, T., et al., 2012. A Hypothesis of the Senoumi Submarine Megaslide in Suruga Bay in Japan—Based on the Undrained Dynamic-Loading Ring Shear Tests and Computer Simulation. Landslides, 9(4): 439-455. https://doi.org/10.1007/s10346-012-0356-2 Setiawan, H., Sassa, K., Dang, K., et al., 2018. TXT-Tool 3.081-1.6: Manual for the Undrained Dynamic-Loading Ring-Shear Apparatus. Landslide Dynamics: ISDR-ICL Landslide Interactive Teaching Tools. Springer International Publishing, Cham: 321-350. https://doi.org/10.1007/978-3-319-57777-7_18 Shang, Y. J., Yang, Z. F., Li, L. H., et al., 2003. A Super-Large Landslide in Tibet in 2000: Background, Occurrence, Disaster, and Origin. Geomorphology, 54(3-4): 225-243. https://doi.org/10.1016/S0169-555X(02)00358-6 Tan, Q. W., Sassa, K., Dang, K., et al., 2020. Estimation of the Past and Future Landslide Hazards in the Neighboring Slopes of the 2016 Aranayake Landslide, Sri Lanka. Landslides, 17(7): 1727-1738. https://doi.org/10.1007/s10346-020-01419-1 Wan, J. W., Chu, H. L., Li, B., et al., 2021. Characteristics, Types, Main Causes and Development of High-Position Geohazard Chains along the Jiali Fault Zone, Tibet, China. The Chinese Journal of Geological Hazard and Control, 32(3): 51-60 (in Chinese with English abstract). Wang, L., Chen, Z. Y., Wang, N. X., et al., 2016. Modeling Lateral Enlargement in Dam Breaches Using Slope Stability Analysis Based on Circular Slip Mode. Engineering Geology, 209: 70-81. https://doi.org/10.1016/j.enggeo.2016.04.027 Wang, Z., Zhao, C. Y., Liu, X. J., et al., 2021. Evolution Analysis and Deformation Monitoring of Yigong Landslide in Tibet with Optical Remote Sensing and InSAR. Geomatics and Information Science of Wuhan University, 46(10): 1569-1578 (in Chinese with English abstract). Wang, Z. H., 2008. A Thunder at the Beginning of the 21st Century—The Giant Yigong Landslide. The Tenth International Symposium on Landslides and Engineered Slopes, Xi'an, 1068-1075. Wu, Y. M., Yang, Z. H., 2024. A Depth-Averaged SPH-FV Landslide Dynamic Model for Evaluating Hazard Zones. Computers and Geotechnics, 169: 106210. https://doi.org/10.1016/j.compgeo.2024.106210 Yang, C., Zhao, J. J., Wang, S. Y., et al., 2024. MatDEM-Based Investigation of Shovel-Scraping Effect on Yigong Landslide. Journal of Chengdu University of Technology (Science & Technology Edition), 51(3): 477-488 (in Chinese with English abstract). Yin, Y. P., 2003. Investigation on "5.11" Landslide Disaster of Sansui-Kaili Expressway in Guizhou Province. The Chinese Journal of Geological Hazard and Control, 14(3): 138-138, 143 (in Chinese with English abstract). Yu, S., Chen, Z. Y., et al., 2021. A New Measurement Method of the Erodibility of Soil. Geotechnical Testing Journal, 44(1): 3-14. https://doi.org/10.1520/gtj20180005 Yuan, H., Guo, C. B., Wu, R. A., et al., 2023. Research Progress and Prospects of the Giant Yigong Long Run-out Landslide, Tibetan Plateau, China. Geological Bulletin of China, 42(10): 1757-1773 (in Chinese with English abstract). Zhong, Y., Li, Y. Y., Yin, K. L., et al., 2023. Failure Mechanism of Thick Colluvium Landslide Triggered by Heavy Rainfall Based on Model Test. Earth Science, 48(10): 3912-3924 (in Chinese with English abstract). Zhou, G. G. D., Roque, P. J. C., Xie, Y. X., et al., 2020. Numerical Study on the Evolution Process of a Geohazards Chain Resulting from the Yigong Landslide. Landslides, 17(11): 2563-2576. https://doi.org/10.1007/s10346-020-01448-w Zhou, J. W., Cui, P., Hao, M. H., 2016. Comprehensive Analyses of the Initiation and Entrainment Processes of the 2000 Yigong Catastrophic Landslide in Tibet, China. Landslides, 13(1): 39-54. https://doi.org/10.1007/s10346-014-0553-2 Zhuang, Y., Yin, Y. P., Xing, A. G., et al., 2020. Combined Numerical Investigation of the Yigong Rock Slide-Debris Avalanche and Subsequent Dam-Break Flood Propagation in Tibet, China. Landslides, 17(9): 2217-2229. https://doi.org/10.1007/s10346-020-01449-9 Zou, C. B., Jansen, J. D., Carling, P. A., et al., 2023. Triggers for Multiple Glacier Detachments from a Low-Angle Valley Glacier in the Amney Machen Range, Eastern Tibetan Plateau. Geomorphology, 440: 108867. https://doi.org/10.1016/j.geomorph.2023.108867 崔鹏, 陈容, 向灵芝, 等, 2014. 气候变暖背景下青藏高原山地灾害及其风险分析. 气候变化研究进展, 10(2): 103-109. 高杨, 李滨, 高浩源, 等, 2020. 高位远程滑坡冲击铲刮效应研究进展及问题. 地质力学学报, 26(4): 510-519. 郭长宝, 吴瑞安, 钟宁, 等, 2024. 青藏高原东部活动构造带大型滑坡成灾背景与灾变机制. 地球科学, 49(12): 4635-4658. doi: 10.3799/dqkx.2024.124 胡明鉴, 汪发武, 程谦恭, 2009. 基于高速环剪试验易贡巨型滑坡形成原因试验探索. 岩土工程学报, 31(10): 1602-1606. 李剑平, 蒋水华, 黄发明, 等, 2024. 考虑渗透系数空间变异性的降雨作用下边坡大变形破坏特征. 应用基础与工程科学学报, 32(1): 72-84. 吕杰堂, 王治华, 周成虎, 2003. 西藏易贡大滑坡成因探讨. 地球科学, 28(1): 107-110. http://www.earth-science.net/article/id/1222 牛犇, 冯春, 丛俊余, 等, 2023. 基于CDEM颗粒流的三维高速远程滑坡成灾范围分析. 岩石力学与工程学报, 42(增刊2): 4018-4027. 任金卫, 单新建, 沈军, 等, 2001. 西藏易贡崩塌—滑坡—泥石流的地质地貌与运动学特征. 地质论评, 47(6): 642-647, 4. 万佳威, 褚宏亮, 李滨, 等, 2021. 西藏嘉黎断裂带沿线高位链式地质灾害发育特征分析. 中国地质灾害与防治学报, 32(3): 51-60. 王哲, 赵超英, 刘晓杰, 等, 2021. 西藏易贡滑坡演化光学遥感分析与InSAR形变监测. 武汉大学学报(信息科学版), 46(10): 1569-1578. 杨畅, 赵建军, 王寿宇, 等, 2024. 基于MatDEM的易贡滑坡铲刮效应研究. 成都理工大学学报(自然科学版), 51(3): 477-488. 殷跃平, 2003. 贵州省三穗-凯里高速公路"5.11"滑坡灾害调查. 中国地质灾害与防治学报, 14(3): 138-138, 143. 袁浩, 郭长宝, 吴瑞安, 等, 2023. 西藏易贡高位远程滑坡研究进展与展望. 地质通报, 42(10): 1757-1773. 钟源, 李远耀, 殷坤龙, 等, 2023. 基于物理模型试验的厚层堆积层滑坡强降雨触发机制. 地球科学, 48(10): 3912-3924. doi: 10.3799/dqkx.2021.248 -
