Interactive Mode between Surface Water and Groundwater in Complex Karst Mining Areas under Influence of Mining Activities
-
摘要:
为研究采矿活动影响下的复杂岩溶矿区地表水-地下水相互作用模式.借助水化学及同位素技术、示踪实验、数值模拟等方法，发现天然条件下，地下水以大气降水补给为主，沿分水岭向牛栏江排泄.开采干扰下（1950—2010年），浅层开采对区域地下水流动系统影响有限，仅引起局部水位下降，改变局部径流方向.干扰强化条件下（2010年后）第一时期（2010—2025年）呈现“浅部弱自然循环-深部强人工排泄”的特征，浅部含水层与牛栏江弱连通，深部地下水向巷道排泄；第二时期（2025年后）以持续扩展的降落漏斗为特征，预测往后第5、10、20年的水位下降约64 m、103 m、120 m.综上所述，矿区岩溶地表水-地下水交互受控于矿区岩溶水文地质结构与采矿活动.研究成果可为会泽铅锌矿区制定科学有效的防排水方案提供理论依据.
Abstract:The Huize lead-zinc mine is located in the karst plateau of northeastern Yunnan. Long term mining has formed a complex underground mining tunnel system below the local minimum erosion benchmark level of the Niulanjiang River. The interaction between karst surface water and groundwater in the mining area is extremely complex under the influence of mining activities. In this article it uses hydrochemical and isotopic techniques, tracer experiments, numerical simulations, and other methods to deeply explore the interaction process between surface water and groundwater in mining areas. The following conclusions are drawn. Under natural conditions, groundwater is mainly supplied by atmospheric precipitation and discharged along the watershed to the Niulanjiang River. Under the disturbance of mining (1950—2010), shallow mining had limited impact on the regional groundwater flow system, only causing a local water level drop and changing the direction of local runoff. Under the conditions of intensified interference (after 2010), the first period (2010—2025) presents the characteristics of "weak natural circulation in the shallow part and strong artificial discharge in the deep part". The shallow aquifer is weakly connected to the Niulanjiang River, and the deep groundwater is discharged into the tunnel. The second period (after 2025) is characterized by a continuously expanding descending funnel, and it is predicted that the water level will decrease by about 64 m, 103 m, and 120 m in the 5th, 10th, and 20th years. In summary, the interaction between karst surface water and groundwater in mining areas is controlled by the hydrogeological structure of karst and mining activities. The research results provide theoretical basis for the development of scientific and effective waterproofing and drainage plans in the Huize lead-zinc mining area.
-
图 3 研究区地下水系统三维结构模型
Fig. 3. Three dimensional structural model of groundwater system in the study area
图 4 地下水三维数值模型校验
a.模型含水层观测点分布；b.观测孔拟合对比
Fig. 4. Verification of groundwater three-dimensional numerical model
图 5 天然地表水-地下水交互作用模式
Fig. 5. The interaction mode between surface water and groundwater under natural conditions
图 6 人工干扰下地表水-地下水交互作用模式
Fig. 6. The interaction mode between surface water and groundwater under artificial interference conditions
图 7 矿区水化学piper三线图
a.枯水期; b.丰水期；数值单位为%
Fig. 7. Piper diagrams of water chemistry in the study area
图 8 研究区地表水、地下水中δD与δ18O关系
Fig. 8. The relationship between δD and δ18O of surface water and groundwater in the study area
图 9 示踪试验点位(a)及监测结果(b)
a. 示踪试验监测点位置示意；b. 示踪试验监测点电导率变化曲线
Fig. 9. Tracer test points(a) and monitoring results (b)
图 10 干扰强化条件下第一时期地表水-地下水交互作用模式
Fig. 10. The interaction mode between surface water and groundwater under enhanced interference conditions in the first period
图 11 干扰强化条件下第二时期地表水-地下水交互作用模式
Fig. 11. The interaction mode between surface water and groundwater under enhanced interference conditions in the second period
图 12 干扰强化条件下第一时期矿区地下水渗流场
a.模型表层地下水流向；b.模型第三层渗流场
Fig. 12. Groundwater seepage field of the mining area during the first period under enhanced interference conditions
图 13 干扰强化条件下第二时期矿区地下水渗流场
a.深部开采5年后; b.深部开采10年后; c.深部开采20年后
Fig. 13. Groundwater seepage field of the mining area during the second period under enhanced interference conditions
表 1 地下水三维数值模型参数
Table 1. Parameters of groundwater three-dimensional numerical model
分区 Kxy(m/d) Kz(m/d) Ss(1/m) Sy P1q+m 0.6 0.35 0.06 0.000 6 Z2dn+Z2d 0.02 0.01 0.002 0.000 02 C2w+C1b+C1d +D3zg 0.65 0.325 0.065 0.000 65 P1l+C3m 0.005 0.002 5 0.000 5 0.000 005 D2h + ∈1q 0.005 0.003 0.000 5 0.000 005 P2β 0.4 0.2 0.04 0.000 4
下载: 导出CSV
-
Bakalowicz, M., 2015. Karst and Karst Groundwater Resources in the Mediterranean. Environmental Earth Sciences, 74(1): 5-14. https://doi.org/10.1007/s12665-015-4239-4 Cao, Y., 2009. Groundwater Circulation Patterns of Typical Lake Area in Northern Ordos Cretaceous Basin (Dissertation). Jilin University, Changchun(in Chinese with English abstract). Chen, S. L., Liu, M. Z., 2011. Status and Advances in the Coupled Model between Surface Water and Groundwater. Journal of Beihing City University, (2): 87-93(in Chinese with English abstract). Hu, Z. Q., 2019. The 30 Years' Land Reclamation and Ecological Restoration in China: Review, Rethinking and Prospect. Coal Science and Technology, 47(1): 25-35 (in Chinese with English abstract). Kang, F. X., Sui, H. B., Zheng, T. T., et al., 2024. Formation Mechanism of Cold Springs and Hot Springs in Karst Groundwater Systems in North China: A Study of Baotu Spring. Earth Science, 49(8): 2862-2878 (in Chinese with English abstract). Li, B. Z., 2001. The Hydrogeological Condition of Huize Pb-Zn Mining Area and the Prediction of Water Discharge of Qilinchang Deposit (Dissertation). Kunming University of Technology, Kunming(in Chinese with English abstract). Li, L., Qin, D. J., Sun, J., et al., 2019. Impacts of Yongding River on the Xishan Karst Aquifer and Yuquan Spring in Beijing, China. Journal of Engineering Geology, 27(1): 162-169 (in Chinese with English abstract). Liu, F., Wang, S., Wang, L. S., et al., 2019. Coupling Hydrochemistry and Stable Isotopes to Identify the Major Factors Affecting Groundwater Geochemical Evolution in the Heilongdong Spring Basin, North China. Journal of Geochemical Exploration, 205: 106352. https://doi.org/10.1016/j.gexplo.2019.106352 Ma, R., Dong, Q. M., Sun, Z. Y., et al., 2013. Using Heat to Trace and Model the Surface Water-Groundwater Interactions: A Review. Geological Science and Technology Information, 32(2): 131-137 (in Chinese with English abstract). Mao, X. H., 2024. Research on the Impact and Prevention Measures of Coal Mining on Groundwater Environment. Water Conservancy Science and Technology and Economy, 30(3): 107-111, 117 (in Chinese with English abstract). Pan, G. Y., Xuan, J. S., Yue, B. X., et al., 2007. The Large Dewatering Test and Tracing Experiment Based on GSM Water Level Remote Sensing System. Journal of Henan Polytechnic University (Natural Science), 26(2): 152-155 (in Chinese with English abstract). Qiao, Y., 2025. Study on the Impact of Deep Mining in Huize Lead-Zinc Mining Area on the Karst Groundwater System (Dissertation). Chengdu University of Technology, Chengdu (in Chinese with English abstract). Shang, H. M., Cui, Q. G., Yu, J. Q., et al., 2025. Risk Analysis of Water Inrush in a Tunnel Project in a Karst Mountain Area. Modern Tunnelling Technology, 62(1): 48-55 (in Chinese with English abstract). Sun, F. Q., 2010. Research on Groundwater Circulation and Environment Effect of Dusitu River in Ordos Basin (Dissertation). Chang'an University, Xi'an(in Chinese with English abstract). Sun, H. Y., Sun, X. M., Wei, X. F., et al., 2022. Formation Mechanism of Metasilicate Mineral Water in Chengde, Hebei Province: Evidence from Rock Weathering and Water-Rock Interaction. Geology in China, 49(4): 1088-1113 (in Chinese with English abstract). Peng, T. R., Huang, C. C., Chen, C. T., et al., 2016. Using Stable Hydrogen and Oxygen Isotopes to Reveal Monsoonal and Related Hydrological Effects on Meteoric Water in the Western Pacific Monsoon Region: A Case Study of the Ilan Region, Northeastern Taiwan. Journal of Asian Earth Sciences, 128: 105-115. https://doi.org/10.1016/j.jseaes.2016.06.024 Wen, H. H., 2013. Study on Circulation Pattern and Numerical Modeling of Groundwater Flow in Leizhou Peninsula (Dissertation). China University of Geosciences, Wuhan(in Chinese with English abstract). Yang, B., Luo, Z. Q., Wang, Y. W., et al., 2013. Analysis and Prediction of Mine Groundwater Flow Field Based on Visual Modflow. Mining and Metallurgical Engineering, 33(4): 11-15, 21 (in Chinese with English abstract). Yang, R. Q., 2022. Study on Surface Water Groundwater Interaction in Ecologically Fragile Area under the Influence of Coal Mining (Dissertation). Liaoning Technical University, Fuxin(in Chinese with English abstract). Yu, Q., Zhang, Y., Dong, T., et al., 2023. Effect of Surface Water-Groundwater Interaction on Arsenic Transport in Shallow Groundwater of Jianghan Plain. Earth Science, 48(9): 3420-3431 (in Chinese with English abstract). Zhang, Y. P., Yan, K. T., Chen, C., 2024. Hydrochemical and Multi-Isotope Analysis of Nitrogen Sources and Transformation Processes in the Wetland-Groundwater System of Honghu Lake. Earth Science, 49(11): 3946-3959 (in Chinese with English abstract). Zheng, J., Chen, L. W., Zhang, J., et al., 2025. Study on Hydraulic Connections between Water-Inrush Aquifers Based on Bayesian Discriminant Analysis and Inverse Hydrogeochemical Simulation. Journal of Hefei University of Technology (Natural Science), 48(2): 203-211(in Chinese with English abstract). 曹阳, 2009. 鄂尔多斯白垩系盆地北部典型湖淖地区地下水循环模式研究(硕士学位论文). 长春: 吉林大学. 陈税琳, 刘明柱, 2011. 地表水-地下水相互作用模型研究现状及进展, 北京城市学院学报, (2): 87-93. 胡振琪, 2019. 我国土地复垦与生态修复30年: 回顾、反思与展望. 煤炭科学技术, 47(1): 25-35. 康凤新, 隋海波, 郑婷婷, 等, 2024. 岩溶地下水系统冷泉和热泉的形成机制: 以趵突泉群为例. 地球科学, 49(8): 2862-2878. doi: 10.3799/dqkx.2023.051 李保珠, 2001. 会泽铅锌矿区水文地质条件及麒麟厂深部矿坑涌水量预测(硕士学位论文). 昆明: 昆明理工大学. 李露, 秦大军, 孙杰, 等, 2019. 永定河对北京西山岩溶水和玉泉山泉的影响. 工程地质学报, 27(1): 162-169. 马瑞, 董启明, 孙自永, 等, 2013. 地表水与地下水相互作用的温度示踪与模拟研究进展. 地质科技情报, 32(2): 131-137. 毛学红, 2024. 煤矿开采对地下水环境的影响及防治措施研究. 水利科技与经济, 30(3): 107-111, 117. 潘国营, 轩吉善, 岳保祥, 等, 2007. 基于GSM水位遥测系统的大型放水与示踪联合试验. 河南理工大学学报(自然科学版), 26(2): 152-155. 乔宇, 2025. 云南会泽铅锌矿深部开采对岩溶地下水系统影响研究(硕士学位论文). 成都: 成都理工大学. 尚海敏, 崔庆国, 于进庆, 等, 2025. 岩溶山区某隧道工程突涌水风险分析. 现代隧道技术, 62(1): 48-55. 孙芳强, 2010. 鄂尔多斯盆地都思兔河流域地下水循环及生态环境效应研究(博士学位论文). 西安: 长安大学. 孙厚云, 孙晓明, 卫晓锋, 等, 2022. 河北承德偏硅酸矿泉水成因模式: 岩石风化与水岩作用证据. 中国地质, 49(4): 1088-1113. 温汉辉, 2013. 雷州半岛地下水循环规律及合理开发利用研究(博士学位论文). 武汉: 中国地质大学. 杨彪, 罗周全, 王益伟, 等, 2013. 基于Visual Modflow的矿山地下水流场分析及预测. 矿冶工程, 33(4): 11-15, 21. 杨瑞琪, 2022. 采煤影响下的生态脆弱区地表水-地下水相互作用研究(硕士学位论文). 阜新: 辽宁工程技术大学. 余倩, 张宇, 董听, 等, 2023. 地表水-地下水相互作用对砷在浅层地下水系统中运移的影响. 地球科学, 48(9): 3420-3431. doi: 10.3799/dqkx.2022.146 张彦鹏, 严克涛, 陈晨, 2024. 洪湖湿地-地下水系统中氮来源与转化过程的水化学和多同位素解析. 地球科学, 49(11): 3946-3959. doi: 10.3799/dqkx.2024.093 郑剑, 陈陆望, 张杰, 等, 2025. 贝叶斯突水水源判别与反向水文地球化学模拟的含水层水力分析. 合肥工业大学学报(自然科学版), 48(2): 203-211. -
