Experimental Methodology for Modeling Disaster Chain of Near-Dam Landslide-Generated Waves and Resultant Dam Breach
-
摘要:
近坝库岸滑坡引发的涌浪灾害链具有突发性、链生性、强破坏性等特点，对水工建筑物及下游安全构成严重威胁.通过开展滑坡涌浪溃坝一体化物理模型试验，系统记录涌浪演进、坝体冲蚀及溃决过程的关键数据，揭示了土石坝在涌浪作用下的溃决机制.基于水槽试验数据，建立基于有限体积法的三维精细化数值模型，耦合滑体运动、水流动力与坝料冲蚀模块，验证了数值方法的可靠性.开展多因素数值分析，揭示了滑坡体积、滑落高度、坝体几何形态及滑坡位置等因素对溃坝过程的影响.研究结果表明，在溃坝场景下，涌浪冲击显著加速坝体侵蚀，导致洪峰流量增大、溃决时间提前，呈现出明显的灾害放大效应.研究为近坝库区地质灾害链的风险识别与评估提供了理论依据与模拟方法支撑.
Abstract:The disaster chain initiated by near-dam reservoir landslides, characterized by its abrupt onset, cascading nature, and severe destructive potential, poses a significant threat to hydraulic structures and downstream safety. This study presents integrated physical model tests simulating landslide-generated impulse waves and subsequent dam breaching. Key data on wave evolution, dam erosion, and the breach process were systematically recorded, revealing the failure mechanisms of earth-rock dams subjected to wave impact. Leveraging the experimental data, a refined three-dimensional numerical model was developed using the Finite Volume Method. This model couples modules for landslide motion, hydrodynamics, and dam material erosion. The reliability of the numerical model was validated against the experimental results. A parametric study was then conducted to investigate the influence of key factors, including landslide volume, fall height, dam geometry, and landslide location, on the breaching process. The results demonstrate that wave impact significantly accelerates dam erosion, leading to an increased peak discharge and an advanced breach timeline, highlighting a clear disaster amplification effect. This study provides both a theoretical foundation and an advanced simulation methodology for the risk identification and assessment of cascading geological hazards in near-dam reservoir areas.
-
图 1 滑坡涌浪溃坝试验装置
Fig. 1. Experimental setup of dam breaching under landslide-generated wave
图 6 滑坡涌浪溃坝灾害链数值模拟过程
Fig. 6. Variation diagram of surge propagation vector in the reservoir area
图 7 物理试验与数值模拟溃决流量及坝前水位数据对比
Fig. 7. Comparison of breach flow and upstream water level between physical experiment and numerical simulation
图 8 各影响因素下数值试验结果
Fig. 8. Discharge process of earth-rock dam breach under various influencing factors
图 10 滑坡涌浪作用下与常规漫顶溃坝流量过程对比
Fig. 10. Comparison of breach flow process between landslide-generated wave and conventional overtopping failure
表 1 物理模型试验缩尺设计参数
Table 1. Design parameters for the scaled model test
物理模型 滑体 坝体 体积(m3) 滑体厚度(m) 距坝址距离(m) 坝高(m) 顶宽(m) 上游坡角tanβ1 下游坡角tanβ2 原型 33 000 000 70.0~780.0 3 000.0 295.0 20.00 0.667 0.500 模型试验 0.003 0.8 1.2 0.4 0.03 0.667 0.667
下载: 导出CSV
表 2 物理模型试验与数值模拟中材料特性
Table 2. Material properties in the physical experiment and numerical simulations
试验 滑体 坝体 密度(kg/m3) 表面摩擦系数 比重(kg/m3) 体积分数(%) 颗粒粒组(mm) 物理试验 2 200 - 2 650 64 0~0.5, 0.5~1, 1~2, 2~4, 4~10 数值模拟 0.007 试验 坝体 各粒组比例(%) 推移质系数 夹带系数 临界希尔兹数 内摩擦角(°) 物理试验 15, 15, 15, 20, 35 - - 0.035, 0.04, 0.045, 0.05, 0.055 30, 32, 35, 38, 42 数值模拟 9, 8, 7, 6, 5 0.02
下载: 导出CSV
表 3 数值试验工况设置
Table 3. Settings of numerical test conditions
试验 Hs (m) Vs(m3) Wd (m) Ds (m) tan(β) 1 1.4 0.004 0.05 1.5 0.667 2 0.008 3 0.012 4 0.016 5 0.6 0.004 0.05 1.5 0.667 6 1 7 1.4 8 1.8 9 1.4 0.004 0 1.5 0.667 10 0.05 11 0.10 12 0.15 13 0.20 14 1.4 0.004 0.05 1.5 1 15 0.667 16 0.500 17 0.400 18 0.330 19 1.4 0.004 0.05 1.2 0.667 20 1.5 21 1.8 22 2.1
下载: 导出CSV
-
Chen, S. Z., Xu, W. Y., Shi, A. C., et al., 2023. Review of Hazard Chain of Landslide Surge for High Dams and Large Reservoirs. Advances in Science and Technology of Water Resources, 43(3): 83-93 (in Chinese with English abstract). Du, Z. H., Chen, X., Pan, H. Y., et al., 2025. Research Advances on Landslide-Induced Surge and Dam-Break Cascading Disasters near Dams. China Water Resources, (3): 50-57 (in Chinese with English abstract). Du, Z. H., Zhou, J. W., Zhang, S. C., et al., 2025. Experimental Analysis on Breaching Mechanism of Earth-Rock Dam Induced by Landslide Generated Waves. Engineering Geology, 346: 107913. https://doi.org/10.1016/j.enggeo.2025.107913 Evers, F. M., Heller, V., Fuchs, H., et al., 2019. Landslide-Generated Impulse Waves in Reservoirs: Basics and Computation (2nd Edition). VAW-Mitteilung, 254. Ghirotti, M., Stead, D., 2013. Vaiont Landslide, Italy. Springer, Netherlands. Guo, W. L., Zhu, J. G., Wen, Y. F., 2016. Unified Description for Four Grading Scale Methods for Coarse Aggregate. Chinese Journal of Geotechnical Engineering, 38(8): 1473-1480 (in Chinese with English abstract). Heller, V., Ruffini, G., 2023. A Critical Review about Generic Subaerial Landslide-Tsunami Experiments and Options for a Needed Step Change. Earth-Science Reviews, 242: 104459. https://doi.org/10.1016/j.earscirev.2023.104459 Hu, Y. X., Li, H. B., Li, C. J., et al., 2022. Quantitative Evaluation in Classification and Amplitude of Near-Field Landslide Generated Wave Induced by Granular Debris. Ocean Engineering, 261: 112142. https://doi.org/10.1016/j.oceaneng.2022.112142 Huang, B. L., Yin, Y. P., Li, R. J., et al., 2025. Research Progress and Challenges of Landslide-Induced Impulse Wave Prevention and Control Engineering Measures. Journal of Engineering Geology, 33(1): 159-170 (in Chinese with English abstract). Li, S., Peng, M., Shi, Z. M., et al., 2025. Simulation and Analysis of Cascading Hazard Based on Fluid-Soil Coupled SPH Method. Earth Science, 50(10): 3967-3981 (in Chinese with English abstract). Mastbergen, D. R., Van Den Berg, J. H., 2003. Breaching in Fine Sands and the Generation of Sustained Turbidity Currents in Submarine Canyons. Sedimentology, 50(4): 625-637. https://doi.org/10.1046/j.1365-3091.2003.00554.x Meyer-Peter, E., Muller, R., 1948. Formulas for Bed-Load Transport. In Process of Congress IAHR, 6(2): 39-64. Mei, S. Y., Zhong, Q. M., Chen, S. S., et al., 2023. Numerical Simulation of Breach Hydrograph and Morphology Evolution during Landslide Dam Breaching. Earth Science, 48(4): 1634-1648 (in Chinese with English abstract). Peng, M., Jiang, Q. L., Zhang, Q. Z., et al., 2019. Stability Analysis of Landslide Dams under Surge Action Based on Large-Scale Flume Experiments. Engineering Geology, 259: 105191. https://doi.org/10.1016/j.enggeo.2019.105191 Peng, M., Ma, C. Y., Chen, H. X., et al., 2021. Experimental Study on Breaching Mechanisms of Landslide Dams Composed of Different Materials under Surge Waves. Engineering Geology, 291: 106242. https://doi.org/10.1016/j.enggeo.2021.106242 Peng, M., Wang, Y., Ma, C. Y., et al., 2025. Review of Risk Assessment and Prevention for Valley Landslide Disaster Chains. Earth Science, 50(10): 3723-3760 (in Chinese with English abstract). Peng, M., Zhao, Q. X., Li, S., et al., 2025. Two-Phase SPH Simulation of Granular Landslide-Tsunamis Processes Considering Dynamic Seepage. Earth Science, 50(10): 3795-3808 (in Chinese with English abstract). Pourshahbaz, H., Abbasi, S., Pandey, M., et al., 2022. Morphology and Hydrodynamics Numerical Simulation around Groynes. ISH Journal of Hydraulic Engineering, 28(1): 53-61. https://doi.org/10.1080/09715010.2020.1830000 PRC Ministry of Water Resources, 2012a. Regulations for River Model Test (SL 99-2012). China Water and Power Press, Beijing (in Chinese). PRC Ministry of Water Resources, 2012b. Test Regulation for Normal Hydraulic Model (SL 155-2012). China Water and Power Press, Beijing (in Chinese). PRC Ministry of Water Resources, 2019. Regulation for Simulation of Landslide Generated Waves (SL/T 165-2019). China Water and Power Press, Beijing (in Chinese). Qi, B., Du, Z. H., Zhang, S. C., 2023. Study on the Construction of Early Warning System for Reservoir Flood Discharge in China. Hydraulic and Civil Engineering (Technology Ⅷ), 43: 783-790. https://doi.org/10.3233/atde230797 Rauter, M., Hoße, L., Mulligan, R. P., et al., 2021. Numerical Simulation of Impulse Wave Generation by Idealized Landslides with OpenFOAM. Coastal Engineering, 165: 103815. https://doi.org/10.1016/j.coastaleng.2020.103815 Sabeti, R., Heidarzadeh, M., 2022. Numerical Simulations of Water Waves Generated by Subaerial Granular and Solid-Block Landslides: Validation, Comparison, and Predictive Equations. Ocean Engineering, 266(3): 112853. https://doi.org/10.1016/j.oceaneng.2022.112853 Samma, H., Khosrojerdi, A., Rostam-Abadi, M., et al., 2020. Numerical Simulation of Scour and Flow Field over Movable Bed Induced by a Submerged Wall Jet. Journal of Hydroinformatics, 22(2): 385-401. https://doi.org/10.2166/hydro.2020.091 Sattar, A., Cook, K. L., Rai, S. K., et al., 2025. The Sikkim Flood of October 2023: Drivers, Causes, and Impacts of a Multihazard Cascade. Science, 387(6740): eads2659. https://doi.org/10.1126/science.ads2659 Semenza, E., Ghirotti, M., 2000. History of the 1963 Vaiont Slide: The Importance of Geological Factors. Bulletin of Engineering Geology and the Environment, 59(2): 87-97. https://doi.org/10.1007/s100640000067 Singh, A., Anand, V., Durga Rao, K. H. V., et al., 2025. Unveiling the Catastrophic Landslide-Induced Flash Flood in Teesta River, Sikkim: Insight from South Lhonak Glacial Lake. Landslides, 22(3): 837-855. https://doi.org/10.1007/s10346-024-02378-7 Su, Z. Y., Kang, X., Ding, X. C., et al., 2026. SPH-DEM Modeling of Rainfall-Induced Slope Failure in Partially Saturated Soil-Rock Mixture. Computers and Geotechnics, 189: 107635. https://doi.org/10.1016/j.compgeo.2025.107635 Su, Z. Y., Wang, S., Li, D. Q., et al., 2024. SPH–DEM Modeling Overtopping Failure of Earthfill Dams. Acta Geotechnica, 19(2): 953-970. https://doi.org/10.1007/s11440-024-02258-3 Tang, C. L., Hu, J. C., Lin, M. L., et al., 2009. The Tsaoling Landslide Triggered by the Chi-Chi Earthquake, Taiwan: Insights from a Discrete Element Simulation. Engineering Geology, 106(1-2): 1-19. https://doi.org/10.1016/j.enggeo.2009.02.011 Wang, W., Chen, G. Q., Zhang, Y. B., et al., 2017. Dynamic Simulation of Landslide Dam Behavior Considering Kinematic Characteristics Using a Coupled DDA-SPH Method. Engineering Analysis with Boundary Elements, 80: 172-183. https://doi.org/10.1016/j.enganabound.2017.02.016 Zhong, Q. M., Wang, L., Chen, S. S., et al., 2021. Breaches of Embankment and Landslide Dams-State of the Art Review. Earth-Science Reviews, 216: 103597. https://doi.org/10.1016/j.earscirev.2021.103597 陈世壮, 徐卫亚, 石安池, 等, 2023. 高坝大库滑坡涌浪灾害链研究综述. 水利水电科技进展, 43(3): 83-93. 杜镇瀚, 陈祥, 潘洪月, 等, 2025. 近坝库岸滑坡涌浪-溃坝链生灾害研究进展. 中国水利(3): 50-57. 郭万里, 朱俊高, 温彦锋, 2016. 对粗粒料4种级配缩尺方法的统一解释. 岩土工程学报, 38(8): 1473-1480. 黄波林, 殷跃平, 李仁江, 等, 2025. 滑坡涌浪综合防控工程措施研究进展与挑战. 工程地质学报, 33(1): 159-170. 李爽, 彭铭, 石振明, 等, 2025. 基于水土耦合SPH方法的滑坡-堵江-成坝灾害链全过程动力演化模拟. 地球科学, 50(10): 3967-3981. doi: 10.3799/dqkx.2025.112 梅胜尧, 钟启明, 陈生水, 等, 2023. 堰塞体溃决流量与溃口形态演化数值模拟. 地球科学, 48(4): 1634-1648. doi: 10.3799/dqkx.2022.360 彭铭, 王悦, 马晨议, 等, 2025a. 河谷滑坡灾害链风险评估及防控研究进展. 地球科学, 50(10): 3723-3760. doi: 10.3799/dqkx.2025.142 彭铭, 赵庆新, 李爽, 等, 2025b. 考虑动态渗流的散粒体滑坡-涌浪过程两相SPH模拟. 地球科学, 50(10): 3795-3808. doi: 10.3799/dqkx.2025.100 中华人民共和国水利部, 2012a. 河工模型试验规程(SL 99-2012). 北京: 中国水利水电出版社. 中华人民共和国水利部, 2012b. 水工(常规)模型试验规程(SL 155-2012). 北京: 中国水利水电出版社. 中华人民共和国水利部, 2019. 滑坡涌浪模拟技术规程(SL/T 165-2019). 北京: 中国水利水电出版社. -
