Numerical Simulation on the Relationship between Seismic Moment of Lg Wave and Source of Underground Explosion
-
摘要: 针对地下爆炸当量估算问题，基于理论地震图仿真和Lg波谱反演方法，系统研究了不同场地中埋深、震源成分（ISO源、CLVD源、DC源及其组合）对源地震矩M0（source）与Lg波地震矩M0（Lg）关系的影响.通过定量标定M0（source）/M0（Lg）比值，结果表明两者比值具有显著的场地依赖性：朝鲜场地比值普遍高于0.2，而内华达场地低于0.2. CLVD和DC源等次生震源会显著降低朝鲜场地的Lg波激发效率（降幅可达50%），同时埋深增大会减弱P-S转换效应，导致比值进一步减小.（进一步的，结合震源模型建立了基于Lg波地震矩的当量估算方法，并以朝鲜第六次核试验数据为例进行了验证.Abstract: Regarding the estimation of yield of underground explosions, this study systematically investigates the influence of burial depth, source components(ISO, CLVD, DC, and their combinations), and site conditions on the relationship between the source seismic moment M0(source) and the Lg-wave seismic moment M0(Lg). Based on theoretical synthetic seismogram simulations and Lg-wave spectral inversion methods, we quantitatively calibrated the M0(source)/ M0(Lg) ratio for different test sites. The results reveal significant site dependence: the ratio generally exceeds 0.2 for the North Korean site but falls below 0.2 for the Nevada site. Secondary sources(e.g., CLVD and DC) reduce Lg-wave excitation efficiency in the North Korean site by up to 50%, while increased burial depth weakens P-S conversion effects, further decreasing the ratio. By integrating a seismic source model, we established a yield estimation method based on M0(Lg) and validated it using data from North Korea's sixth nuclear test.
-
Key words:
- source seismic moment /
- Lg wave /
- source model /
- yield estimation /
- synthetic seismogram
-
图 1 纯ISO、埋深0.26 km时，400~1 000 km震中距上的理论地震图
红色为截取的Lg波，速度窗口为3.0~3.6 km/s
Fig. 1. With pure ISO and a depth of 0.26 km, theoretical seismogram at epicentral distances of 400~1 000 km
图 2 不同埋深时Lg波频谱比值随频率的变化
星号表示观测值，直线为拟合结果
Fig. 2. The Lg wave spectrum ratio with frequency at different burial depths
图 3 纯ISO埋深0.26 km时反演得到的Lg波地震矩及视源拐角频率
直线表示源地震矩
Fig. 3. With pure ISO and a burial depth of 0.26 km, the Lg seismic moment and apparent source corner frequency obtained from inversion
图 4 ISO+CLVD源时，不同场地M0(Lg)/M0(exp)与FCLVD值及埋深关系
Fig. 4. Relationship between M0(Lg)/M0(exp) and FCLVD values and burial depth for different sites when using ISO+CLVD sources
图 5 ISO+DC源时，不同场地M0(Lg)/M0(exp)与FDC值及埋深关系
Fig. 5. Relationship between M0(Lg)/M0(exp) and FDC values and burial depth for different sites when using ISO+DC sources.
图 6 ISO+CLVD+DC源时，不同场地M0(Lg)/M0(exp)与K值及埋深关系
Fig. 6. Relationship between M0(Lg)/M0(exp) and FCLVD values and burial depth for different sites when using ISO+CLVD+DC sources
图 8 部分台站反演结果
黑色虚线为观测Lg波频谱，灰色为迭代曲线，红色为最优结果
Fig. 8. Inversion results of partial stations
图 10 朝鲜速度模型下，P/S幅值比随埋深变化
Fig. 10. P/S amplitude ratio versus burial depth under the North Korean velocity model
表 1 朝鲜和内华达场地速度模型（部分）
Table 1. velocity models for North Korea and Nevada sites(partial)
Layer（km） VS（km/s） VP（km/s） ρ（g/cm3） 朝鲜部分速度模型 1.0 3.09 5.35 2.57 8.0 3.35 5.81 2.66 20.0 3.62 6.27 2.78 ∞ 4.37 7.91 3.17 内华达部分速度模型 0.5 1.00 2.00 1.70 1.0 2.00 3.30 2.10 1.5 2.70 4.50 2.40 1.0 3.40 5.90 2.75 8.0 3.52 5.96 2.78 9.0 3.61 6.11 2.80 10.0 3.76 6.37 2.84
下载: 导出CSV
-
Adushkin, V. V., 2001. Yield Estimation for Semipalatinsk Underground Nuclear Explosions Using Seismic Surface-Wave Observations at Near-Regional Distances. Pure and Applied Geophysics, 158(11): 2217-2226. https://doi.org/10.1007/PL00001146 Chun, K. Y., West, G. F., Kokoski, R. J., et al., 1987. A Novel Technique for Measuring Lg Attenuation: Results from Eastern Canada between 1 to 10 Hz. Bulletin of the Seismological Society of America, 77(2): 398-419. https://doi.org/10.1785/bssa0770020398 Denny, M. D., Johnson, L. R., 1991. The Explosion Seismic Source Function: Models and Scaling Laws Reviewed. Explosion Source Phenomenology. American Geophysical Union, Washington, D. C., 1-24. https://doi.org/10.1029/gm065p0001 Ford, S. R., Dreger, D. S., Walter, W. R., 2009. Source Analysis of the Memorial Day Explosion, Kimchaek, North Korea. Geophysical Research Letters, 36(21): 2009GL040003. https://doi.org/10.1029/2009GL040003 He, J., Wu, Q. J., Li, Y. H., et al., 2017. Developments of Earthquake Lg-Wave Attenuation Study and Its Application in the Continental China. Progress in Geophysics, 32(2): 466-475(in Chinese with English abstract). Herrmann, R. B., 1995. Broadband Seismology and Small Regional Seismic Networks. Professional Paper. Jin, P., Xiao, W. G., Duan, K. M., 2004. Estimating Seismic Moments and Qlgusing Lg Spectra. Acta Seismologica Sinica, 26(S1): 21-30(in Chinese with English abstract). Jin, P., Xu, H. L., Ding, S. B., et al., 2023. Source Spectra of Pg and Lg Waves from North Korean Nuclear Tests Estimated Using a Nonmodel-Based Approach. Bulletin of the Seismological Society of America, 114(2): 1151-1166. https://doi.org/10.1785/0120230035 Jin, P., Zhu, H. F., Xu, X., et al., 2019. Seismic Spectral Ratios between North Korean Nuclear Tests: Implications for Their Seismic Sources. Journal of Geophysical Research: Solid Earth, 124(5): 4940-4958. https://doi.org/10.1029/2018JB016554 Liu, J., Li, L., Zahradník, J., et al., 2018. North Korea's 2017 Test and Its Nontectonic Aftershock. Geophysical Research Letters, 45(7): 3017-3025. https://doi.org/10.1002/2018GL077095 Lu, Y., Zhao, L. F., Pang, X. L., et al., 2024. Yield Estimation of North Korean Underground Nuclear Tests Using Lg-Wave Source Spectra. Frontiers in Earth Science, 12: 1386932. https://doi.org/10.3389/feart.2024.1386932 Marshall, P. D., Douglas, A., Hudson, J. A., 1971. Surface Waves from Underground Explosions. Nature, 234(5323): 8-9. https://doi.org/10.1038/234008a0 Mitchell, B. J., 1980. Frequency Dependence of Shear Wave Internal Friction in the Continental Crust of Eastern North America. Journal of Geophysical Research: Solid Earth, 85(B10): 5212-5218. https://doi.org/10.1029/JB085iB10p05212 Murphy, J. R., Barker, B. W., 2001. Application of Network-Averaged Teleseismic P-Wave Spectra to Seismic Yield Estimation of Underground Nuclear Explosions. Pure and Applied Geophysics, 158(11): 2123-2171. https://doi.org/10.1007/PL00001144 Murphy, J. R., Mueller, R. A., 1971. Seismic Characteristics of Underground Nuclear Detonations. Bulletin of the Seismological Society of America, 61(6): 1693-1704. https://doi.org/10.1785/bssa0610061693 Pasyanos, M. E., Myers, S. C., 2018. The Coupled Location/Depth/Yield Problem for North Korea's Declared Nuclear Tests. Seismological Research Letters, 89(6): 2059-2067. https://doi.org/10.1785/0220180109 Sereno, T. J. Jr, Bratt, S. R., Bache, T. C., 1988. Simultaneous Inversion of Regional Wave Spectra for Attenuation and Seismic Moment in Scandinavia. Journal of Geophysical Research: Solid Earth, 93(B3): 2019-2035. https://doi.org/10.1029/JB093iB03p02019 Stevens, J. L., 1986. Estimation of Scalar Moments from Explosion-Generated Surface Waves. Bulletin of the Seismological Society of America, 76(1): 123-151. https://doi.org/10.1785/bssa0760010123 Street, R. L., Herrmann, R. B., Nuttli, O. W., 1975. Spectral Characteristics of the Lg Wave Generated by Central United States Earthquakes. Geophysical Journal of the Royal Astronomical Society, 41(1): 51-63. https://doi.org/10.1111/j.1365-246X.1975.tb05484.x Wan, Y. G., 2024. Focal Mechanism Classification Based on Areal Strain of Horizontal Strain Rosette of Focal Mechanism and Characteristic Analysis of Overall Focal Mechanism of Earthquake Sequence. Earth Science, 49(7): 2675-2684(in Chinese with English abstract). Xie, J. K., 1993. Simultaneous Inversion for Source Spectrum and pathQusingLgwith Application to Three Semipalatinsk Explosions. Bulletin of the Seismological Society of America, 83(5): 1547-1562. https://doi.org/10.1785/bssa0830051547 Xie, J., 2002. Lg Q in the Eastern Tibetan Plateau. Bulletin of the Seismological Society of America, 92(2): 871-876. https://doi.org/10.1785/0120010154 Xie, J., Mitchell, B. J., 1990. Attenuation of Multiphase Surface Waves in the Basin and Range Province, Part Ⅰ: Lg and Lg Coda. Geophysical Journal International, 102(1): 121-137. https://doi.org/10.1111/j.1365-246X.1990.tb00535.x Xie, J., Nuttli, O. W., 1988. Interpretation of High-Frequency Coda at Large Distances: Stochastic Modelling and Method of Inversion. Geophysical Journal International, 95(3): 579-595. https://doi.org/10.1111/j.1365-246X.1988.tb06705.x Xu, H. L., Ni, S. D., Liu, W. X., et al., 2020. Focal Mechanisms of the 2017 North Korean Nuclear Test and Its Early Collapse Event. Geophysical Journal International, 220(2): 737-752. https://doi.org/10.1093/gji/ggz462 Xu, Z. S., Wen, X. T., Xi, N., et al., 2025. Aftershock Relocation and Intensity Distribution of the Dingri MS6.8 Earthquake in 2025. Earth Science, 50(5): 1759-1769(in Chinese with English abstract). Zhao, L. F., Xie, X. B., Wang, W. M., et al., 2012. Yield Estimation of the 25 may 2009 North Korean Nuclear Explosion. Bulletin of the Seismological Society of America, 102(2): 467-478. https://doi.org/10.1785/0120110163 Zhu, L. P., Ben-Zion, Y., 2013. Parametrization of General Seismic Potency and Moment Tensors for Source Inversion of Seismic Waveform Data. Geophysical Journal International, 194(2): 839-843. https://doi.org/10.1093/gji/ggt137 Zhu, L. P., Rivera, L. A., 2002. A Note on the Dynamic and Static Displacements from a Point Source in Multilayered Media. Geophysical Journal International, 148(3): 619-627. https://doi.org/10.1046/j.1365-246X.2002.01610.x 何静, 吴庆举, 李永华, 等, 2017. 天然地震Lg波衰减研究进展及其在中国大陆地区的应用. 地球物理学进展, 32(2): 466-475. 靳平, 肖卫国, 段克敏, 2004. 由Lg波振幅谱估算地震矩及Lg波Q值. 地震学报, 26(S1): 21-30. 万永革, 2024. 震源机制水平应变花面应变的地震震源机制分类方法及序列震源机制总体特征分析. 地球科学, 49(7): 2675-2684. doi: 10.3799/dqkx.2022.245 -
