Quantitative Characterization of Log Facies and Depositional Model of Mixed Siliciclastic-Carbonate Rocks Based on Fisher Discriminant: A Case Study on Daluhu Oilfield, Bohai Bay Basin
-
摘要: 针对渤海湾盆地大芦湖油田西部沙四纯上亚段及沙三下亚段混积岩储层岩性复杂、非均质性强导致的岩相识别困难与沉积规律认识不足，本研究综合利用钻录井、测井及地震资料，在构建等时地层格架的基础上，应用Fisher判别分析进行混积岩测井相定量表征，并综合揭示了混积岩沉积演化规律.结果表明：（1）基于Fisher判别分析，优选自然伽马（GR）、声波时差（AC）、体积密度（DEN）和补偿中子孔隙度（CNL）测井曲线，分序列建立砂‒泥和灰‒泥系统岩性定量识别模型，有效解决了灰岩与砂岩测井响应重叠问题，显著提升了岩性识别精度，砂‒泥系统验证集岩性识别正确率为79.5%，粉砂岩预测精度为95%；灰‒泥系统回判总正确率达84.5%.（2）沙四纯上亚段高位体系域发育浅湖‒半深湖相，岩性为灰质页岩与泥岩互层，受古水深和盐度的控制，有机质呈中西部富集和东南部局部发育的格局，集中在0.8%~1.9%；沙三下亚段低位和湖扩体系域以半深湖相为主，有机质北部和南部富集，TOC含量集中在0.9%~2.3%；沙三下亚段HST发育辫状河三角洲‒半深湖复合沉积体系，盆地边缘发育三角洲前缘粉砂岩相，致有机质保存条件变差，洼陷中心以半深湖相沉积为主，富有机质泥质页岩占优.（3）建立四类岩相垂向和平面组合模式：垂向组合为厚层砂夹薄泥型、厚层泥夹薄砂型、厚层灰质页岩夹薄泥型和厚层泥夹薄灰质页岩型.平面上，混积岩沉积体系西部及西南部陡岸发育辫状河三角洲与近岸水下扇复合体，低位和高位体系域坡折带之下的斜坡带和湖盆中发育滑塌成因浊积岩体，东部及东北部缓坡区发育半深湖和深湖环境中灰质为主的沉积相，泥质页岩和灰质页岩相向湖盆中心迁移.本研究为湖相混积岩测井相预测提供了定量化理论依据，为富含有机质烃源岩预测、细粒储层类型预测、沉积规律以及油气勘探研究提供指导.Abstract: The lithological complexity and strong heterogeneity of the mixed siliciclastic and carbonate reservoirs result in difficulties in lithofacies identification and insufficient understanding of depositional patterns in the upper Shahejie 4 Member and lower Shahejie 3 Member in the western Daluhu oilfield, Bohai Bay basin. Integrating drilling, logging, and seismic data, Fisher discriminant analysis was applied for quantitative characterization of mixed siliciclastic and carbonate lithofacies from well logs, and the depositional evolution of mixed sediments was comprehensively revealed, on the basis of a chronostratigraphic framework. The results are as follows. (1) Based on Fisher discriminant analysis, quantitative lithology identification models for sand-mudstone and limestone-mudstone systems were established within subsequences using optimally selected natural gamma ray (GR), Sonic transit time (AC), density (DEN) and compensated neutron (CNL) logging curves, effectively addressing the problem of overlapping log responses between limestone and sandstone and significantly improving lithology identification accuracy. For the sand-mudstone system, the lithology identification accuracy in the validation set was 79.5%, with a siltstone prediction accuracy of 95%; for the limestone-mudstone system, the overall back-prediction accuracy reached 84.5%. (2) The highstand systems tract (HST) of the upper Shahejie 4 Member is dominated by shallow-lake to semi-deep-lake facies, consisting of interbedded calcareous shale and mudstone. Controlled by paleo-water depth and salinity, organic matter is enriched in the central-western and locally in the southeastern parts, with contents mainly between 0.8%-1.9%. The lowstand and lake-expansion systems tracts of the lower Shahejie 3 Member are dominated by semi-deep-lake facies, with organic matter enriched in the northern and southern areas and TOC content concentrated at 0.9%-2.3%. The HST of the lower Shahejie 3 Member developed a braided-river delta-semi-deep lake composite depositional system, with delta-front siltstone facies developed along the basin margins, resulting in poorer organic matter preservation, whereas the sag center was dominated by semi-deep lacustrine deposits, with organic-rich argillaceous shale being predominant. (3) Four types of vertical lithofacies association models were established: thick-bedded sandstone interbedded with thin mudstone, thick-bedded mudstone interbedded with thin sandstone, thick-bedded calcareous shale interbedded with thin mudstone, and thick-bedded mudstone interbedded with thin calcareous shale. In plan view, the mixed siliciclastic-carbonate depositional system is characterized by braided-river delta and nearshore subaqueous fan complexes along the western and southwestern steep margins. Slump-induced turbidite bodies developed in the slope zones and lake basin below the slope-break belts of the lowstand and highst and systems tracts. In the eastern and northeastern gentle-slope areas, calcareous-dominated sedimentary facies developed in semi-deep to deep lacustrine environments, while muddy shale and calcareous shale facies shifted toward the basin center. This study provides a quantitative theoretical basis for lacustrine mixed lithofacies prediction from well logs, offering guidance for organic-rich source rock and reservoir prediction, depositional pattern analysis, and oil and gas exploration.
-
图 1 研究区渤海湾盆地大芦湖油田西部位置示意(Wang et al., 2017; Lu et al., 2020; 林中凯等, 2023)
Fig. 1. Schematic diagram of location of study area-western Daluhu oilfield in the Bohai Bay basin (Wang et al., 2017; Lu et al., 2020; Lin et al., 2023)
图 2 关键层序界面测井-地震响应特征
a. FJF179井综合柱状图; b. FJF179井地震剖面响应
Fig. 2. Logging-seismic response characteristics of key sequence boundaries
图 3 依据FJF-Y1井建立TOC预测模型
a.沙三下亚段测井幅度差与实测TOC值的关系；b. 沙四纯上亚段测井幅度差与实测TOC值的关系；c. 沙三下亚段和沙四纯上亚段实测和预测TOC测井综合柱状图
Fig. 3. TOC prediction model established according to well FJF-Y1
图 4 依据矿物组分岩相划分方案
Fig. 4. Ternary diagram of lithofacies classification based on mineral components
图 5 五类岩相与不同测井曲线关系交会图
Fig. 5. Crossplot of the relationship between 5 lithofacies and different logging curves
图 8 GQF-X184井和ZLG-X86井Fisher判别模型预测岩性与岩心岩性对比
Fig. 8. Comparison between lithologies predicted by the Fisher discriminant model and core-derived lithologies in wells GQF-X184 and ZLG-X86
图 9 岩相连井剖面
a. GQF-X190-GQF172-ZLG-X86-ZLG92;b. ZLG-X98-ZLG88-ZLG898-ZLG897
Fig. 9. Lithofacies correlation profile
图 11 研究区各体系域沉积相展布模式
a. 沙四纯上亚段HST岩相分布; b. 沙三下亚段LST+EST岩相分布; c. 沙三下亚段HST岩相分布
Fig. 11. Spatial distribution patterns of depositional facies in the study area by systems tract
表 1 砂‒泥系统训练集各岩性回判准确率统计
Table 1. Statistics of the accuracy of lithological inversion in sand-mud system training set
分区 岩性 泥质页岩 粉（细）砂岩 总计 项目 计数 概率(%) 计数 概率(%) 计数 概率(%) 正确 86 97.7 31 96.9 117 97.5 错误 2 2.3 1 3.1 3 2.5 总计 88 100 32 100 120 100
下载: 导出CSV
-
Abouelresh, M. O., Slatt, R. M., 2012. Lithofacies and Sequence Stratigraphy of the Barnett Shale in East-Central Fort Worth Basin, Texas. AAPG Bulletin, 96(1): 1-22. https://doi.org/10.1306/04261110116 Aghchelou, M., Nabi-Bidhendi, M., Shahvar, M. B., 2012. Lithofacies Estimation by Multi-Resolution Graph-Based Clustering of Petrophysical Well Logs: Case Study of South Pars Gas Field of Iran. Nigeria Annual International Conference and Exhibition, Lagos. Society of Petroleum Engineers, Richardson, SPE 162991-MS. https://doi.org/10.2118/162991-ms Dong, S. Q., Wang, Z. Z., Zeng, L. B., 2016. Lithology Identification Using Kernel Fisher Discriminant Analysis with Well Logs. Journal of Petroleum Science and Engineering, 143: 95-102. https://doi.org/10.1016/j.petrol.2016.02.017 Dong, S. Q., Zeng, L. B., Du, X. Y., et al., 2022. Lithofacies Identification in Carbonate Reservoirs by Multiple Kernel Fisher Discriminant Analysis Using Conventional Well Logs: A Case Study in a Oilfield, Zagros Basin, Iraq. Journal of Petroleum Science and Engineering, 210: 110081. https://doi.org/10.1016/j.petrol.2021.110081 Duan, Y. J., Xie, J., Li, B. C., et al., 2020. Lithology Identification and Reservoir Characteristics of the Mixed Siliciclastic-Carbonate Rocks of the Lower Third Member of the Shahejie Formation in the South of the Laizhouwan Sag, Bohai Bay Basin, China. Carbonates and Evaporites, 35(2): 55. https://doi.org/10.1007/s13146-020-00583-8 Feng, C., Dai, L. M., Liu, X. J., et al., 2020. Logging Classification and Recognition of Lacustrine Mixed Sedimentary Reservoirs in First and Second Members of Shahejie Formation in Bohai Sea. Earth Science, 45(10): 3677-3692 (in Chinese with English abstract). Gao, B., Hao, F., Xu, S., et al., 2025. Oil Content and Its Occurrence State of Lower Member of Shahejie Formation Shale in Dongying Sag. Earth Science, 50(6): 2199-2208 (in Chinese with English abstract). Guo, J. N., Shan, X. L., Hao, G. L., 2019. Identification of Basement Lithology in Central Uplift Zone of Songliao Basin by Fisher Discriminant Analysis. Journal of Heilongjiang University of Science and Technology, 29(1): 60-65 (in Chinese with English abstract). Jiang, S., Wang, H., Guo, T., et al., 2022. Geomorphology of Gravity Flow Deposits in the Gentle Slope Zone of Intra-Basinal High in the Liaodong Bay Depression, Bohai Bay Basin and Its Controlling Factors. Oil & Gas Geology, 43(4): 823-832 (in Chinese with English abstract). Jiang, S., Wang, H., Weimer, P., 2008. Sequence Stratigraphy Characteristics and Sedimentary Elements in Deepwater. Earth Science, 33(6): 825-833 (in Chinese with English abstract). Kvale, E. P., Bowie, C. M., Flenthrope, C., et al., 2020. Facies Variability within a Mixed Carbonate-Siliciclastic Sea-Floor Fan (Upper Wolfcamp Formation, Permian, Delaware Basin, New Mexico). AAPG Bulletin, 104(3): 525-563. https://doi.org/10.1306/06121917225 Li, C. C., Hong, X. E., Han, D. L., et al., 2023. Identification Method of Lithology by Logging in Favorable Reservoir of Lacustrine Mixed Rock—A Case Study of the Small Layer 2 of the Upper Part of the Member 3 of Shahejie Formation in Dawangzhuang Oilfield. Petroleum Geology and Engineering, 37(4): 37-44 (in Chinese with English abstract). Li, G. X., Liu, G. Q., Hou, Y. T., et al., 2021. Optimization Method of Favorable Lithofacies and Fracturing Parameter for Continental Shale Oil. Acta Petrolei Sinica, 42(11): 1405-1416 (in Chinese with English abstract). Lin, Z. K., Zhang, S. L., Li, C. H., et al., 2023. Types of Shale Lithofacies Assemblage and Its Significance for Shale Oil Exploration: A Case Study of Shahejie Formation in Boxing Sag. Petroleum Reservoir Evaluation and Development, 13(1): 39-51 (in Chinese with English abstract). Liu, H. M., 2022. Geological Particularity and Exploration Practice of Paleogene Shale Oil in Jiyang Depression: A Case Study of the Upper Submember of Member 4 to the Lower Submember of Member 3 of Shahejie Formation. Acta Petrolei Sinica, 43(5): 581-594 (in Chinese with English abstract). Lu, Y., Liu, K. Y., Xu, S. Y., et al., 2020. Identifying Flow Units by FA-Assisted SSOM—An Example from the Eocene Basin-Floor-Fan Turbidite Reservoirs in the Daluhu Oilfield, Dongying Depression, Bohai Bay Basin, China. Journal of Petroleum Science and Engineering, 186: 106695. https://doi.org/10.1016/j.petrol.2019.106695 Luo, H., Lai, F. Q., Dong, Z., et al., 2018. A Lithology Identification Method for Continental Shale Oil Reservoir Based on BP Neural Network. Journal of Geophysics and Engineering, 15(3): 895. https://doi.org/10.1088/1742-2140/aaa4db Mao, Z. Q., Xia, Y., Gao, G., et al., 2020. Characteristics and Identification of Lacustrine Sedimentary Lithology in Lower Es3 Strata of Boxing Subsag. Journal of Xi'an Shiyou University (Natural Science Edition), 35(5): 14-23 (in Chinese with English abstract). Pan, J., Liu, X. L., Li, H., et al., 2023. Characteristics and Distribution of Lithofacies Assemblages of the Permian Lucaogou Formation in the Eastern Slope of Fukang Sag. Acta Sedimentologica Sinica, 41(5): 1366-1379 (in Chinese with English abstract). Passey, Q. R., Creaney, S., Kulla, J. B., et al., 1990. A Practical Model for Organic Richness from Porosity and Resistivity Logs. AAPG Bulletin, 74(12): 1777-1794. https://doi.org/10.1306/0c9b25c9-1710-11d7-8645000102c1865d. Song, Z. J., Xiao, D. S., Wei, Y. B., et al., 2023. The Research on Complex Lithology Identification Based on Well Logs: A Case Study of Lower 1st Member of the Shahejie Formation in Raoyang Sag. Energies, 16(4): 1748. https://doi.org/10.3390/en16041748 Wang, J., Cao, Y. C., Liu, K. Y., et al., 2017. Identification of Sedimentary-Diagenetic Facies and Reservoir Porosity and Permeability Prediction: An Example from the Eocene Beach-Bar Sandstone in the Dongying Depression, China. Marine and Petroleum Geology, 82: 69-84. https://doi.org/10.1016/j.marpetgeo.2017.02.004 Wang, L., Lü, Q. Q., Zhang, Y., et al., 2025. Lithofacies Characteristics and Distribution Patterns of Deep Water Gravity Flow Deposits in the Chang 7 Oil Member in the Southwest Ordos Basin. Acta Sedimentologica Sinica, 43(1): 154-168 (in Chinese with English abstract). Wang, M., Yang, J. L., Wang, X., et al., 2023. Identification of Shale Lithofacies by Well Logs Based on Random Forest Algorithm. Earth Science, 48(1): 130-142 (in Chinese with English abstract). Wang, Y., Liu, L. F., Meng, J. H., et al., 2014. Depositional Environment of Es4u and Es3l Shales Based on Biomarkers from the Boxing Sag of Dongying Depression, East China. Acta Geologica Sinica (English Edition), 88(5): 1556-1564. https://doi.org/10.1111/1755-6724.12318 Wang, Y. S., Gao, Y., Li, J. L., et al., 2025. New Exploration Fields and Resource Potential of Paleogene Clastic Tight Oil in Jiyang Depression, Bohai Bay Basin. Acta Petrolei Sinica, 46(1): 118-136 (in Chinese with English abstract). Xu, C. G., Zhou, J. X., Yang, H. F., et al., 2024. New Fields, New Types and Resource Potentials of Oil-Gas Exploration in Bohai Sea. Acta Petrolei Sinica, 45(1): 163-182 (in Chinese with English abstract). Ye, M. S., Xie, X. N., Du, X. B., et al., 2025. Characteristics and Formation Mechanism of Heterogeneity in "Compositional Mixing" Reservoirs: An Example from the First-Second Member of the Palaeogene Shahejie Formation, Bohai Sea. Acta Sedimentologica Sinica, 43(2): 635-652 (in Chinese with English abstract). Zhao, H., Wang, H. L., Liu, H. M., et al., 2022. Application of Fisher Discriminant Method in the Facies Division of Lake Facies-Taking the Third Member of Shahejie Formation in Dongying Sag as an Example. Energy Sources, Part A: Recovery, Utilization, and Environmental Effects, 44(2): 4977-4990. https://doi.org/10.1080/15567036.2019.1656680 Zou, C. N., Feng, Y. L., Yang, Z., et al., 2023. Fine-Grained Gravity Flow Sedimentation and Its Influence on Development of Shale Oil Sweet Spot Intervals in Lacustrine Basins in China. Petroleum Exploration and Development, 50(5): 883-897 (in Chinese with English abstract). 冯冲, 代黎明, 刘晓健, 等, 2020. 渤海海域沙一二段湖相混积岩储层测井分类与识别. 地球科学, 45(10): 3677-3692. doi: 10.3799/dqkx.2020.129 高波, 郝芳, 徐尚, 等, 2025. 东营凹陷沙三下亚段页岩含油性及赋存特征. 地球科学, 50(6): 2199-2208. doi: 10.3799/dqkx.2025.026 郭剑南, 单玄龙, 郝国丽, 2019. 松辽盆地中央隆起带基底岩性识别的Fisher判别分析法. 黑龙江科技大学学报, 29(1): 60-65. 蒋恕, 王浩, 郭涛, 等, 2022. 渤海湾盆地辽东湾坳陷盆中隆起缓坡带重力流沉积形态及其控制因素. 石油与天然气地质, 43(4): 823-832. 蒋恕, 王华, Weimer, P., 2008. 深水沉积层序特点及构成要素. 地球科学, 33(6): 825-833. http://www.earth-science.net/article/id/1774 李楚楚, 洪秀娥, 韩登林, 等, 2023. 湖相混积岩有利储层岩性测井识别方法: 以大王庄油田沙三上亚段为例. 石油地质与工程, 37(4): 37-44. 李国欣, 刘国强, 侯雨庭, 等, 2021. 陆相页岩油有利岩相优选与压裂参数优化方法. 石油学报, 42(11): 1405-1416. 林中凯, 张少龙, 李传华, 等, 2023. 湖相页岩油地层岩相组合类型划分及其油气勘探意义: 以博兴洼陷沙河街组为例. 油气藏评价与开发, 13(1): 39-51. 刘惠民, 2022. 济阳坳陷古近系页岩油地质特殊性及勘探实践: 以沙河街组四段上亚段—沙河街组三段下亚段为例. 石油学报, 43(5): 581-594. 毛振强, 夏宇, 高刚, 等, 2020. 博兴洼陷沙三下段湖相沉积岩性特征及识别. 西安石油大学学报(自然科学版), 35(5): 14-23. 潘进, 刘新龙, 李辉, 等, 2023. 阜东斜坡芦草沟组岩相组合特征及展布规律. 沉积学报, 41(5): 1366-1379. 王林, 吕奇奇, 张严, 等, 2025. 鄂尔多斯盆地西南部长7油层组深水重力流沉积岩相特征及分布模式. 沉积学报, 43(1): 154-168. 王民, 杨金路, 王鑫, 等, 2023. 基于随机森林算法的泥页岩岩相测井识别. 地球科学, 48(1): 130-142. doi: 10.3799/dqkx.2022.181 王永诗, 高阳, 李军亮, 等, 2025. 渤海湾盆地济阳坳陷古近系碎屑岩致密油勘探新领域及资源潜力. 石油学报, 46(1): 118-136. 徐长贵, 周家雄, 杨海风, 等, 2024. 渤海海域油气勘探新领域、新类型及资源潜力. 石油学报, 45(1): 163-182. 叶茂松, 解习农, 杜学斌, 等, 2025. "组分混合"沉积的储层非均质性及形成机理: 以渤海海域古近系沙河街组一、二段为例. 沉积学报, 43(2): 635-652. 邹才能, 冯有良, 杨智, 等, 2023. 中国湖盆细粒重力流沉积作用及其对页岩油"甜点段"发育的影响. 石油勘探与开发, 50(5): 883-897. -
