Multi-Field Coupled Numerical Simulation of Porphyry Ore Formation Based on Simple Geometric Model
-
摘要:
斑岩型矿床在全球范围内广泛分布，其成矿机制具有重要的科研价值.成矿过程数值模拟方法是研究岩浆‒热液成矿系统的重要方法，该方法能够定量、连续分析成矿作用过程，为矿化/蚀变时空分布、成矿流体迁移‒演化等问题提供解答.本研究建立了斑岩型矿床简单几何模型，并基于该模型开展了成矿过程多物理场（热‒流‒化‒质）耦合数值模拟研究.结果表明，在成矿模拟研究中使用简单几何模型具有可行性，对深部找矿靶区预测、解释大型‒超大型斑岩型矿床成因具有一定的启示意义；该方法不仅可以用来计算矿化空间分布并实现深部找矿预测，还可以通过不同的矿化分布形式来反推成矿时期的构造环境，从而更深入地研究古成矿环境等问题；此外，简单模型具有计算量少、人为影响微弱、可信度高等特点，能够在一些特定的成矿理论问题研究中发挥重要作用.
Abstract:Porphyry deposits are widely distributed in the world, and their mineralization mechanisms are of significant scientific research value. Numerical simulation is an important approach to quantitatively and continuously analyze the formation of ore deposits, revealing the temporal-spatial distribution of mineralization/alteration and migration-evolution of ore-forming fluids. This study established a simple geometric model of porphyry deposits, and conducted multi-field coupled (heat-transfer, fluid-flow, chemical reaction, diffusion) numerical simulation of its formation. Results show that using simple geometric models in metallogenic simulation research is feasible, which has certain enlightening significance for searching for deep prospecting targets and explaining the genesis of large and ultra-large porphyry deposits. This method can not only be used to calculate the spatial distribution of mineralization and achieve deep prospecting prediction, but also to infer the tectonic environment during the mineralization period through different forms of mineralization distribution, thereby enabling a deeper study of issues such as the ancient mineralization environment. In addition, simple models are characterized by low computational cost, minimal human influence, and high credibility, so they can play an important role in the study of some specific metallogenic theoretical issues.
-
Key words:
- simple geometric model /
- porphyry deposit /
- ore formation /
- multi-field coupled /
- numerical simulation /
- big data
-
图 1 斑岩系统深部岩体、源区、上覆火山岩空间关系及成矿作用示意
图a据Sillitoe（2010）；b.本研究建立的简单地质模型；c.经过剖分的简单地质模型
Fig. 1. Generalized schematic diagram showing the spatial relationship between porphyry Cu stocks, underlying plutons, overlaying comagmatic volcanic rocks and the lithocap environment
图 2 模型内部空间降温过程
a.模型内部空间整体降温动态过程；b.模型内部空间400~550 ℃区间动态变化过程
Fig. 2. The temperature reduction within the model space
图 3 模型内部空间流体迁移方向（a）；成矿金属元素移动轨迹（b）
Fig. 3. The fluid migration directions (a) and migration trajectory (b) of ore-forming metals
图 4 0~30 000年间模型内部空间成矿金属元素迁移轨迹
Fig. 4. The migration trajectory of ore-forming metals from 0 to 30 000 years
图 5 双侧压力相等情况下的模型内部空间成矿金属元素沉淀成矿过程及其空间分布
Fig. 5. The mineralization and spatial distribution of ore-forming metals precipitated within the model space under conditions of bilateral pressure equilibrium
图 6 双侧压力不相等情况下的模型内部空间成矿金属元素沉淀成矿过程及其空间分布
Fig. 6. The mineralization and spatial distribution of ore-forming metals precipitated within the model space under conditions of unequal bilateral pressure
图 7 模型与模拟结果对比
a.本研究；b.安徽茶亭斑岩型铜矿床，据Hu et al.（2020）；c.安徽朱冲富钴矽卡岩型铁矿床，据Hu et al.（2026）
Fig. 7. Comparison of models and simulation results
表 1 本研究使用的岩石物性参数（据Hu et al., 2020）
Table 1. The rock properties parameters used in this study (from Hu et al., 2020)
参数类型 密度(kg/m3) 比热容(J/(kg‧K)) 孔隙度 渗透率(10‒13m2) 导热系数(W/(m‧K)) 数值 2 560 820 0.18 30 2.8
下载: 导出CSV
-
Carman, P. C., 1937. Fluid Flow Through Granular Beds. Transactions of the Institution of Chemical Engineers, 15: 150-166. https://doi.org/10.1016/S0263-8762(97)80003-2 Chen, W. L., Xiao, F., 2023. Advances in Numerical Modeling of Metallogenic Dynamics: A Review of Theories, Methods and Technologies. Bulletin of Geological Science and Technology, 42(3): 234-249 (in Chinese with English abstract). Cheng, Q. M., 2021. What Are Mathematical Geosciences and Its Frontiers? Earth Science Frontiers, 28(3): 6-25 (in Chinese with English abstract). Chi, G. X., Xue, C. J., 2011. Principles, Methods and Applications of Hydrodynamic Studies of Mineralization. Earth Science Frontiers, 18(5): 1-18 (in Chinese with English abstract). Cooke, D. R., Hollings, P., Walshe, J. L., 2005. Giant Porphyry Deposits: Characteristics, Distribution, and Tectonic Controls. Economic Geology, 100(5): 801-818. https://doi.org/10.2113/gsecongeo.100.5.801 Fournier, R. O., 1999. Hydrothermal Processes Related to Movement of Fluid from Plastic into Brittle Rock in the Magmatic-Epithermal Environment. Economic Geology, 94(8): 1193-1211. https://doi.org/10.2113/gsecongeo.94.8.1193 Grmela, M., 2012. Fluctuations in Extended Mass-Action-Law Dynamics. Physica D: Nonlinear Phenomena, 241(10): 976-986. https://doi.org/10.1016/j.physd.2012.02.008 Hobbs, B. E., Zhang, Y., Ord, A., et al., 2000. Application of Coupled Deformation, Fluid Flow, Thermal and Chemical Modelling to Predictive Mineral Exploration. Journal of Geochemical Exploration, 69: 505-509. https://doi.org/10.1016/S0375-6742(00)00099-6 Hou, Z. Q., Yang, Z. M., Wang, R., et al., 2020. Further Discussion on Porphyry Cu-Mo-Au Deposit Formation in Chinese Mainland. Earth Science Frontiers, 27(2): 20-44 (in Chinese with English abstract). Hu, B. Q., Wang, F. Z., Sun, Z. X., et al., 2003. The Pressure Gradient in the Lithosphere. Earth Science Frontiers, 10(3): 129-133 (in Chinese with English abstract). Hu, X. Y., Chen, R. Y., Liu, G. X., et al., 2024. Numerical Simulation-Based Targeting of the Au Mineralization within the Hongbu Altered Rock Type Gold Deposit, Eastern Shandong Peninsula, China. Journal of Geochemical Exploration, 265: 107557. https://doi.org/10.1016/j.gexplo.2024.107557 Hu, X. Y., Li, X. H., Yuan, F., et al., 2020. Numerical Modeling of Ore-Forming Processes within the Chating Cu-Au Porphyry-Type Deposit, China: Implications for the Longevity of Hydrothermal Systems and Potential Uses in Mineral Exploration. Ore Geology Reviews, 116: 103230. https://doi.org/10.1016/j.oregeorev.2019.103230 Hu, X. Y., Liang, X., Wang, F. Y., et al., 2026. Cooling Front Controls on Co Mineralization within Skarn-Type Co-Rich Fe Deposits: A Numerical Modeling Case Study of the Zhuchong Deposit, Anhui Province, China. Natural Resources Research, 35(1): 17-31. https://doi.org/10.1007/s11053-025-10573-z Lai, F., Zou, S. H., Xu, D. R., 2022. Silver Complexation in Chlorine- and Sulfur-Rich Hydrothermal Fluids: Insight from Ab Initio Molecular Dynamics Simulations. Chemical Geology, 589: 120684. https://doi.org/10.1016/j.chemgeo.2021.120684 Leng, S., Xia, Q. L., Li, T. F., et al., 2025. Geodynamic Simulation of the Pulang Porphyry Deposit in Southwest China: Implications for Ore Genesis and Exploration. Journal of Earth Science, 36(6): 2513-2525. https://doi.org/10.1007/s12583-022-1727-9 Li, X. H., Yuan, F., Zhang, M. M., et al., 2019. 3D Computational Simulation-Based Mineral Prospectivity Modeling for Exploration for Concealed Fe-Cu Skarn-Type Mineralization within the Yueshan Orefield, Anqing District, Anhui Province, China. Ore Geology Reviews, 105: 1-17. https://doi.org/10.1016/j.oregeorev.2018.12.003 Li, Z. H., Chi, G. X., Deng, T., et al., 2019. Controls of Reactivated Faults on the Unconformity-Related Uranium Deposits in the Athabasca Basin, Canada. Geotectonica et Metallogenia, 43(3): 518-527 (in Chinese with English abstract). Li, Z. H., Liu, M. Q., Gerya, T., 2015. Material Transportation and Fluid-Melt Activity in the Subduction Channel: Numerical Modeling. Scientia Sinica (Terrae), 45(7): 881-899 (in Chinese with English abstract). doi: 10.1360/zd-2015-45-7-881 Liu, L. M., Li, J. F., Zhou, R. C., et al., 2016. 3D Modeling of the Porphyry-Related Dawangding Gold Deposit in South China: Implications for Ore Genesis and Resources Evaluation. Journal of Geochemical Exploration, 164: 164-185. https://doi.org/10.1016/j.gexplo.2015.11.002 Mao, X. C., Duan X. M., Deng, H., et al., 2026. Intelligent 3D Prediction of Deep Mineral Resources: Theory, Methods, and Challenges. Earth Science, 51(3): 793-815 (in Chinese with English abstract). Mao, X. C., Ren, J., Liu, Z. K., et al., 2019. Three- Dimensional Prospectivity Modeling of the Jiaojia-Type Gold Deposit, Jiaodong Peninsula, Eastern China: A Case Study of the Dayingezhuang Deposit. Journal of Geochemical Exploration, 203: 27-44. https://doi.org/10.1016/j.gexplo.2019.04.002 Meinert, L. D., Dipple, G. M., Nicolescu, S., 2005. World Skarn Deposits. Economic Geology, (One Hundredth Anniversary Volume): 299-336. https://doi.org/10.5382/AV100.11 Mudd, G. M., Jowitt, S. M., 2018. Growing Global Copper Resources, Reserves and Production: Discovery Is not the Only Control on Supply. Economic Geology, 113(6): 1235-1267. https://doi.org/10.5382/econgeo.2018.4590 Ni, P., Chi, Z., Pan, J. Y., 2020. An Integrated Investigation of Ore-Forming Fluid Evolution in Porphyry and Epithermal Deposits and Their Implication on Exploration. Earth Science Frontiers, 27(2): 60-78 (in Chinese with English abstract). Ord, A., Hobbs, B. E., Lester, D. R., 2012. The Mechanics of Hydrothermal Systems: I. Ore Systems as Chemical Reactors. Ore Geology Reviews, 49: 1-44. https://doi.org/10.1016/j.oregeorev.2012.08.003 Qin, Y. Z., Liu, L. M., Wu, W. C., 2021. Machine Learning-Based 3D Modeling of Mineral Prospectivity Mapping in the Anqing Orefield, Eastern China. Natural Resources Research, 30(5): 3099-3120. https://doi.org/10.1007/s11053-021-09893-7 Shan, S. Q., Xie, G. Q., Liu, W. Y., et al., 2023. Hydrothermal Alteration and Sulfide Zoning Characteristics of the Čukaru Peki Super-Large Porphyry-Epithermal Copper-Gold Deposit in Western Tethys, Serbia and Its Implication for Exploration. Geotectonica et Metallogenia, 47(5): 1085-1109 (in Chinese with English abstract). Sillitoe, R. H., 2010. Porphyry Copper Systems. Economic Geology, 105(1): 3-41. https://doi.org/10.2113/gsecongeo.105.1.3 Sun, T., Li, H., Wu, K. X., et al., 2020. Data-Driven Predictive Modelling of Mineral Prospectivity Using Machine Learning and Deep Learning Methods: A Case Study from Southern Jiangxi Province, China. Minerals, 10(2): 102. https://doi.org/10.3390/min10020102 Wang, S. H., Pei, R. F., Zeng, X. H., et al., 2009. Metallogenic Series and Model of the Zijinshan Mining Field. Acta Geologica Sinica, 83(2): 145-157 (in Chinese with English abstract). Weis, P., Driesner, T., Heinrich, C. A., 2012. Porphyry-Copper Ore Shells Form at Stable Pressure-Temperature Fronts within Dynamic Fluid Plumes. Science, 338(6114): 1613-1616. https://doi.org/10.1126/science.1225009 Xiao, F., Chen, X. Y., Cheng, Q. M., 2024a. Combining Numerical Modeling and Machine Learning to Predict Mineral Prospectivity: A Case Study from the Fankou Pb-Zn Deposit, Southern China. Applied Geochemistry, 160: 105857. https://doi.org/10.1016/j.apgeochem.2023.105857 Xiao, F., Wang, K. Q., Cheng, Q. M., 2024b. Porphyry Magma Cooling and Crystallization Control of Mineralization: Insights from the Dynamic Numerical Modeling. Ore Geology Reviews, 166: 105956. https://doi.org/10.1016/j.oregeorev.2024.105956 Xiong, Y. H., Zuo, R. G., Miller, S. A., 2023. The Behavior of Hydrothermal Mineralization with Spatial Variations of Fluid Pressure. Journal of Geophysical Research: Solid Earth, 128(2): e2022JB025255. https://doi.org/10.1029/2022JB025255 Yao, Z. S., Mungall, J. E., 2022. Magnetite Layer Formation in the Bushveld Complex of South Africa. Nature Communications, 13: 416. https://doi.org/10.1038/s41467-022-28000-9 Zhao, C. B., Hobbs, B. E., Ord, A., 2018. Modeling of Mountain Topography Effects on Hydrothermal Pb-Zn Mineralization Patterns: Generic Model Approach. Journal of Geochemical Exploration, 190: 400-410. https://doi.org/10.1016/j.gexplo.2018.04.004 Zhao, C. B., Hobbs, B. E., Ord, A., 2022. Investigating Porosity Structure Effects on Hydrothermal Mineralization Patterns within Permeable Horizontal Layers of Fluid-Saturated Rocks: Semi-Analytical Approach through Generic Models. Ore Geology Reviews, 150: 105116. https://doi.org/10.1016/j.oregeorev.2022.105116 Zhong, J., Chen, Y. J., Chen, J., et al., 2011. Fluid Inclusion Study of the Luoboling Porphyry Cu-Mo Deposit in the Zijinshan Ore Field, Fujian Province. Acta Petrologica Sinica, 27(5): 1410-1424 (in Chinese with English abstract). Zhou, Y. Z., Chen, S., Zhang, Q., et al., 2018. Advances and Prospects of Big Data and Mathematical Geoscience. Acta Petrologica Sinica, 34(2): 255-263 (in Chinese with English abstract). Zou, Y. H., Liu, Y., Dai, T. G., et al., 2017. Finite Difference Modeling of Metallogenic Processes in the Hutouya Pb-Zn Deposit, Qinghai, China: Implications for Hydrothermal Mineralization. Ore Geology Reviews, 91: 463-476. https://doi.org/10.1016/j.oregeorev.2017.09.008 Zuo, R. G., Yang, F. F., Cheng, Q. M., et al., 2025. A Novel Data-Knowledge Dual-Driven Model Coupling Artificial Intelligence with a Mineral Systems Approach for Mineral Prospectivity Mapping. Geology, 53(3): 284-288. https://doi.org/10.1130/g52970.1 Zuo, R. G., 2025. Key Technology for Intelligent Mineral Prospectivity Mapping: Challenges and Solutions. Scientia Sinica (Terrae), 55(9): 3104-3119 (in Chinese with English abstract). doi: 10.1360/SSTe-2025-0096 陈伟林, 肖凡, 2023. 成矿动力学数值计算模拟研究进展: 理论、方法与技术. 地质科技通报, 42(3): 234-249. 成秋明, 2021. 什么是数学地球科学及其前沿领域? 地学前缘, 28(3): 6-25. 池国祥, 薛春纪, 2011. 成矿流体动力学的原理、研究方法及应用. 地学前缘, 18(5): 1-18. 侯增谦, 杨志明, 王瑞, 等, 2020. 再论中国大陆斑岩Cu-Mo-Au矿床成矿作用. 地学前缘, 27(2): 20-44. 胡宝群, 王方正, 孙占学, 等, 2003. 岩石圈中的地压梯度. 地学前缘, 10(3): 129-133. 李增华, 池国祥, 邓腾, 等, 2019. 活化断层对加拿大阿萨巴斯卡盆地不整合型铀矿的控制. 大地构造与成矿学, 43(3): 518-527. 李忠海, 刘明启, Gerya T., 2015. 俯冲隧道中物质运移和流体‒熔体活动的动力学数值模拟. 中国科学: 地球科学, 45(7): 881-899. 毛先成, 段新明, 邓浩, 等, 2026. 深部矿产三维智能预测理论、方法与挑战. 地球科学, 51(3): 793-815. doi: 10.3799/dqkx.2025.227 倪培, 迟哲, 潘君屹, 2020. 斑岩型和浅成低温热液型矿床成矿流体与找矿预测研究: 以华南若干典型矿床为例. 地学前缘, 27(2): 60-78. 单思齐, 谢桂青, 刘文元, 等, 2023. 特提斯西段塞尔维亚Čukaru Peki超大型斑岩‒浅成低温型铜金矿床的热液蚀变和硫化物分带特征及找矿方向. 大地构造与成矿学, 47(5): 1085-1109. 王少怀, 裴荣富, 曾宪辉, 等, 2009. 再论紫金山矿田成矿系列与成矿模式. 地质学报, 83(2): 145-157. 钟军, 陈衍景, 陈静, 等, 2011. 福建省紫金山矿田罗卜岭斑岩型铜钼矿床流体包裹体研究. 岩石学报, 27(5): 1410-1424. 周永章, 陈烁, 张旗, 等, 2018. 大数据与数学地球科学研究进展: 大数据与数学地球科学专题代序. 岩石学报, 34(2): 255-263. 左仁广, 2025. 智能矿产预测的技术挑战与解决方案. 中国科学: 地球科学, 55(9): 3104-3119. -
