A Cloud-Edge-End Collaborative Architecture for Intelligent Operation and Maintenance of High-End Drilling Equipment
-
摘要: 为提升深部钻探成套装备在极端工况下的安全可靠运行，面向集成自动化、数字化、多源传感与高可靠性设计的高端钻探装备，构建了“云-边-端”分布式协同的智能运维体系架构，提出钻探装备、数据采集、智能运维与数字孪生4层模块总体框架，设计基于MQTT与Kafka的数据流程，建立主题层级分类与消息体结构定义的数据建模策略，并采用边缘特征上报与云端按需采集机制以适应低带宽、高时延、间歇连接的网络条件. 该架构可支撑多源数据接入、跨井场统一部署与远程可视化交互，满足状态监测、故障诊断与预测性维护需求，为高端钻探装备智能运维平台设计与实现提供体系化参考.Abstract: To improve the safe and reliable operation of deep drilling equipment under extreme working conditions, this study focuses on high-end drilling equipment that integrates automated execution, digital control, multi-source sensing, and high-reliability design. A cloud-edge-end collaborative intelligent operation and maintenance (O&M) architecture is developed. The proposed architecture consists of four modules, namely the drilling equipment module, the data acquisition module, the intelligent O&M module, and the digital twin module. A data workflow based on MQTT and Kafka is designed. A data modeling strategy is established through hierarchical topic classification and message schema specification. An edge-side feature reporting mechanism and a cloud-side on-demand data acquisition mechanism are further introduced to cope with network conditions characterized by low bandwidth, high latency, and intermittent connectivity. The architecture supports multi-source data access, unified deployment across multiple drilling sites, and remote visualization and interaction. It meets the requirements of equipment condition monitoring, fault diagnosis, and predictive maintenance, and provides a systematic reference for the design and implementation of intelligent O&M platforms for high-end drilling equipment.
-
图 1 高端钻探装备智能运维系统功能框架图
Fig. 1. Functional architecture of the intelligent operation and maintenance system for high-end drilling equipment
图 2 高端钻探装备智能运维系统总体结构图
Fig. 2. Overall architecture of the intelligent operation and maintenance system for high-end drilling equipment
图 3 高端钻探装备智能运维分层解耦“代理-消费”模型
Fig. 3. Layered and decoupled "broker-consumer" model for intelligent operation and maintenance system of high-end drilling equipment
图 5 MQTT消息携带JSON格式的数据示例图
Fig. 5. Example of an MQTT message carrying JSON-formatted data
图 6 智能运维模块云边端协同架构
Fig. 6. Cloud-edge-end collaborative architecture of the intelligent operation and maintenance module
表 1 数据建模的示例主题表
Table 1. Example MQTT topics for data modeling
主题 示例Topic 含义 QoS 钻井参数数据 drilling/GOM/RIG01/sensor/001/wob
drilling/GOM/RIG01/sensor/002/torque钻压
扭矩QoS 1
QoS 1井下测量数据 measurement/SC/RIG03/sensor/101/pressure
measurement/SC/RIG03/sensor/102/temperature环空压力
井底温度QoS 2
QoS 2循环系统数据 mud/GOM/RIG01/sensor/201/flowrate
mud/GOM/RIG01/sensor/202/density泥浆流量
泥浆密度QoS 0
QoS 1设备控制与执行类数据 control/SC/RIG03/pump/302/start
control/SC/RIG03/pump/302/stop泵启指令
泵停指令QoS 2
QoS 2安全报警类数据 alarm/GOM/RIG02/sensor/402/overpressure
alarm/GOM/RIG02/sensor/403/fire超压报警
火警报警QoS 2
QoS 2环境监测数据 environment/SC/RIG03/sensor/502/humidity
environment/SC/RIG03/sensor/503/wind湿度
风速QoS 0
QoS 0系统与网络运行数据 system/GOM/RIG01/controller/001/status
system/GOM/RIG01/logger/001/log系统运行状态
系统运行日志QoS 1
QoS 0
下载: 导出CSV
-
Bala, A., Rashid, R. Z. J. A., Ismail, I., et al., 2024. Artificial Intelligence and Edge Computing for Machine Maintenance: Review. Artificial Intelligence Review, 57(5): 119. https://doi.org/10.1007/s10462-024-10748-9 Carvalho, T. P., Soares, F. A. A. M. N., Vita, R., et al., 2019. A Systematic Literature Review of Machine Learning Methods Applied to Predictive Maintenance. Computers & Industrial Engineering, 137: 106024. https://doi.org/10.1016/j.cie.2019.106024 Cheng, X., Chaw, J. K., Goh, K. M., et al., 2022. Systematic Literature Review on Visual Analytics of Predictive Maintenance in the Manufacturing Industry. Sensors, 22(17): 6321. https://doi.org/10.3390/s22176321 Christou, I. T., Kefalakis, N., Zalonis, A., et al., 2020. End-to-End Industrial IoT Platform for Actionable Predictive Maintenance. IFAC-PapersOnLine, 53(3): 173-178. https://doi.org/10.1016/j.ifacol.2020.11.028 Cui, S. L., He, M. W., Chen, J. H., et al., 2025. Construction Method of Fault Knowledge Graph for Coal Mine Electromechanical Equipment Oriented to Standard Operating Process. Industry and Mine Automation, 51(S1): 50-54, 60 (in Chinese with English abstract). Eugster, P. T., Felber, P. A., Guerraoui, R., et al., 2003. The many Faces of Publish/subscribe. ACM Computing Surveys, 35(2): 114-131. https://doi.org/10.1145/857076. 857078 doi: 10.1145/857076.857078 Gawde, S., Patil, S., Kumar, S., et al., 2024. Explainable Predictive Maintenance of Rotating Machines Using LIME, SHAP, PDP, ICE. IEEE Access, 12: 29345-29361. https://doi.org/10.1109/access.2024.3367110 Guo, B., Liu, S. C., Liu, Y., et al., 2023. AIoT: The Concept, Architecture and Key Technologies. Chinese Journal of Computers, 46(11): 2259-2278 (in Chinese with English abstract). Khaldy, M. A. A., Nabot, A., Al-Qerem, A., et al., 2025. Adaptive Conflict Resolution for IoT Transactions: A Reinforcement Learning-Based Hybrid Validation Protocol. Scientific Reports, 15(1): 25589. https://doi.org/10.1038/s41598-025-09698-1 Liu, Y. S., Zhang, J. W., Huang, H. C., 2024. Key Technologies and Development Direction for Deep and Ultra-Deep Drilling and Completion in China. Acta Petrolei Sinica, 45(1): 312-324 (in Chinese with English abstract). Lu, Z. Z., Zhu, X. K., Du, X. G., et al., 2024. Development and Prospect of Deep-Sea Environmental Noise Monitoring Technology. Earth Science, 49(6): 2120-2130 (in Chinese with English abstract). Lv, H. Z., Chen, D., Fan, B., et al., 2018. Standardization Progress and Case Analysis Of Edge Computing. Journal of Computer Research and Development, 55(3): 487-511 (in Chinese with English abstract). Pagano, D., 2023. A Predictive Maintenance Model Using Long Short-Term Memory Neural Networks and Bayesian Inference. Decision Analytics Journal, 6(7): 100174. https://doi.org/10.1016/j.dajour.2023.100174 Peng, M., Wang, Y., Ma, C. Y., et al., 2025. Review of Risk Assessment and Prevention for Valley Landslide Disaster Chains. Earth Science, 50(10): 3723-3760 (in Chinese with English abstract). Pech, M., Vrchota, J., Bednář, J., 2021. Predictive Maintenance and Intelligent Sensors in Smart Factory: Review. Sensors, 21(4): 1470. https://doi.org/10.3390/s21041470 Ren, J. W., Cheng, Y., Zhang, Y. F., et al., 2024. A Digital Twin-Enhanced Collaborative Maintenance Paradigm for Aero-Engine Fleet. Frontiers of Engineering Management, 11(2): 356-361. https://doi.org/10.1007/s42524-024-0299-z Resende, P. T. V., Haddad, D. B., Weyrich, M., et al., 2021. TIP4.0: Industrial Internet of Things Platform for Predictive Maintenance. Sensors, 21(14): 4676. https://doi.org/10.3390/s21144676 Sathupadi, K., Achar, S., Bhaskaran, S. V., et al., 2024. Edge-Cloud Synergy for AI-Enhanced Sensor Network Data: A Real-Time Predictive Maintenance Framework. Sensors, 24(24): 7918. https://doi.org/10.3390/s24247918 Tang, Z. Y., Xiong, M. W., Yang, M. Q., et al., 2013. Real-Time Research and Redundancy Design of Hydropower Station Monitoring System. Power System Communications, 34(1): 62-65 (in Chinese with English abstract). Tao, F., Sun, X. M., Cheng, J. F., et al., 2024. MakeTwin: A Reference Architecture for Digital Twin Software Platform. Chinese Journal of Aeronautics, 37(1): 1-18. https://doi.org/10.1016/j.cja.2023.05.002 Wang, H. G., Huang, H. C., Bi, W. X., et al., 2022. Deep and Ultra-Deep Oil and Gas Well Drilling Technologies: Progress and Prospect. Natural Gas Industry B, 9(2): 141-157. https://doi.org/10.1016/j.ngib.2021.08.019 Zhang, X. R., Ji, L., Fan, Z. M., et al., 2022. Research on the Next Power Distribution IoT Operation and Maintenance Technology Based on Cloud-Edge Collaboration. Integrated Smart Energy, 44(12): 25-32 (in Chinese with English abstract). Zhang, K., Leng, S. P., He, Y. J., et al., 2018. Mobile Edge Computing and Networking for Green and Low-Latency Internet of Things. IEEE Communications Magazine, 56(5): 39-45. https://doi.org/10.1109/mcom.2018.1700882 Zhang, M., Feng, K., Jiang, Z. N., 2014. A Mechanical Fault Early Warning Methodology Based on Dynamic Self-Learning Threshold and Trend Filtering Techniques. Journal of Vibration and Shock, 33(24): 8-14 (in Chinese with English abstract). Zhong, D., Xia, Z. L., Zhu, Y. A., et al., 2023. Overview of Predictive Maintenance Based on Digital Twin Technology. Heliyon, 9(4): e14534. https://doi.org/10.1016/j.heliyon.2023.e14534 Zonta, T., da Costa, C. A., da Rosa Righi, R., et al., 2020. Predictive Maintenance in the Industry 4.0: A Systematic Literature Review. Computers & Industrial Engineering, 150(6): 106889. https://doi.org/10.1016/j.cie.2020.106889 Zhu, L., Wu, Z. L., Huang, S. Y., 2023. Assessment Method of Distribution Network Health Level Based on Multivariate Information. Frontiers in Energy Research, 11: 1178631. https://doi.org/10.3389/fenrg.2023.1178631 崔石磊, 何明伟, 陈建华, 等, 2025. 面向标准作业流程的煤矿机电设备故障知识图谱构建方法. 工矿自动化, 51(S1): 50-54+60. 郭斌, 刘思聪, 刘琰, 等, 2023. 智能物联网: 概念、体系架构与关键技术. 计算机学报, 46(11): 2259-2278. 刘岩生, 张佳伟, 黄洪春, 2024. 中国深层—超深层钻完井关键技术及发展方向. 石油学报, 45(1): 312-324. 陆哲哲, 朱心科, 杜新光, 等, 2024. 深海环境噪声监测技术发展现状与展望. 地球科学, 49(6): 2120-2130. doi: 10.3799/dqkx.2023.162 吕华章, 陈丹, 范斌, 等, 2018. 边缘计算标准化进展与案例分析. 计算机研究与发展, 55(3): 487-511. 彭铭, 王悦, 马晨议, 等, 2025. 河谷滑坡灾害链风险评估及防控研究进展. 地球科学, 50(10): 3723-3760. doi: 10.3799/dqkx.2025.142 汤震宇, 熊慕文, 杨梅强, 等, 2013. 水电监控系统的冗余设计和实时性研究. 电力系统通信, 34(1): 62-65. 张晓瑞, 纪陵, 范仲鸣, 等, 2022. 基于云边融合的新一代配电物联运维技术研究. 综合智慧能源, 44(12): 25-32. 张明, 冯坤, 江志农, 2014. 基于动态自学习阈值和趋势滤波的机械故障智能预警方法. 振动与冲击, 33(24): 8-14. -
