Simulation of Nitrate Hydrologic Residence Time in a Hierarchical Groundwater Flow System of Sandy Basin and Implications from Management
-
摘要:
以小型砂质盆地为例，基于二维Tóth模型探究了硝酸盐在多级次地下水流系统中的水文遗留时间特征.随着入渗强度增大，水流系统从单一区域系统、嵌套系统向单一局部水流系统转化，盆地硝酸盐平均水文遗留时间递减，但较长遗留时间（250~500 a）占比始终最大.排泄区硝酸盐浓度受相邻局部水流系统主导，其发育深度越大，水文遗留时间越长.若不削减输入，排泄区硝酸盐浓度经2~8 a稳定后无法下降，立即停输比逐步停输使硝酸盐提前4~6 a恢复本底值.控制地下水硝酸盐污染需优先管控相邻局部水流系统硝酸盐输入，或通过调控补给强度改变局部水流系统的发育深度，但快速削减地下水硝酸盐输入量无法显著改善管控措施对水质改善的滞后性.
Abstract:This study investigates the nitrate hydrologic residence time (NHRT) in a sandy, hierarchical groundwater flow system based on a 2D Tóth basin. Results show that with increasing groundwater recharge intensity, groundwater flow system evolves from a single regional system to nested systems, and finally to a single local flow system. The mean NHRT within the basin decreases across five distinct flow system patterns, but the proportion of longer-duration NHRT (250-500 a) remains dominant. Nitrate concentrations in discharge zones were primarily governed by adjacent local flow systems. A greater development depth of the local system prolongs NHRT in the discharge zone. Under nitrate input control scenarios, the baseline simulation (no input reduction) shows that concentrations in discharge zones stabilized within 2-8 years and then failed to decline. Compared to a gradual cessation, an immediate cessation of nitrate input accelerates recovery to background levels by only 4-6 years. The findings suggest that effective control of groundwater nitrate pollution requires either prioritizing input reduction in recharge areas of adjacent local flow systems or altering their development depth by regulating recharge intensity. Nevertheless, rapid cuts in nitrate loading do not substantially mitigate the inherent time lag of water quality response to remediation measures.
-
图 1 地下水流系统概念模型及硝酸盐水文遗留时间(NHRT)计算方法示意
度量线示意了局部、中间系统流线上标圈硝酸盐质点的水文遗留时间及区域系统流线上标圈地下水质点的滞留时间；右侧为排泄区NHRT的计算方法示意图
Fig. 1. Schematic of the conceptual groundwater flow system and the method for calculating nitrate hydrologic residence time (NHRT)
图 2 输入强度管控情景中地下水硝酸盐输入浓度变化
Fig. 2. Nitrate recharge concentrations to groundwater under three input-intensity control scenarios
图 3 不同水流系统模式盆地流场及氧化还原带分布
A.地下水流场分布；B.硝酸盐浓度分布；a.单一区域水流系统（R）；b.局部-区域二级嵌套水流系统（2L+R）；c.局部-中间-区域三级嵌套水流系统（6L+M+R）；d.局部-中间二级嵌套水流系统（6L+M）；e.单一局部水流系统（6L）；图中数字表示局部水流系统的编号
Fig. 3. Flow field and distribution of redox zones in the basin under different flow patterns
图 4 不同水流系统模式下的硝酸盐水文遗留时间分布
A.空间分布特性；B.硝酸盐水文遗留时间及地下水滞留时间归一化频率直方图；a.单一区域水流系统（R）；b.局部-区域二级嵌套水流系统（2L+R）；c.局部-中间-区域三级嵌套水流系统（6L+M+R）；d.局部-中间二级嵌套水流系统（6L+M）；e.单一局部水流系统（6L）
Fig. 4. Distribution of NHRT under different flow patterns
图 5 不同输入位置下排泄区硝酸盐的穿透曲线
A.仅RZ1输入；B.仅RZ2输入；C.仅RZ3输入；a.单一区域水流系统（R）；b.局部-区域二级嵌套水流系统（2L+R）；c.局部-中间-区域三级嵌套水流系统（6L+M+R）；d.局部-中间二级嵌套水流系统（6L+M）；e.单一局部水流系统（6L）
Fig. 5. Nitrate breakthrough curves in the discharge zone for different input locations
图 6 不同输入强度下排泄区硝酸盐的穿透曲线
A.情景ⅰ“保持现状”；B.情景ⅱ“逐步停止”；C.情景ⅲ“立即停止”；a.单一区域水流系统（R）；b.局部-区域二级嵌套水流系统（2L+R）；c.局部-中间-区域三级嵌套水流系统（6L+I+R）；d.局部-中间二级嵌套水流系统（6L+I）；e.单一局部水流系统（6L）
Fig. 6. Nitrate breakthrough curves in the discharge zone for different input intensities
表 1 模型几何尺寸、水文地质与溶质运移相关参数取值
Table 1. Parameter values for model geometry, hydrogeology and solute transport
参数类别 参数 取值 几何尺寸 盆地宽度L 3 600 m 最低排泄点高程h0 250 m 区域和局部起伏振幅hR、hL 25 m 局部起伏频率k 6 水文物理参数 渗透系数K 0.25 m/d(Domenico and Schwartz, 1997) 孔隙度θ 0.40(Allard and World Health Organization, 1992) 耦合长度尺度l 0.01 m(年庚乾等, 2020) 地球化学参数 初始浓度C0 0 mg/L 纵向弥散度aL 40 m(蒋小伟等, 2012; Gelhar et al., 1992) 横向弥散度aT 4 m(蒋小伟等, 2012; Gelhar et al., 1992) 分子扩散系数D* 1.16×10-9 m2/s(蒋小伟等, 2012) 溶解氧一级反应动力学常数kDO 0.04 a-1 (McMahon et al., 2008) 硝酸盐一级反应动力学常数$ k_{\mathrm{N}{\mathrm{O}}_{3}} $ 0.02 a-1 (McMahon et al., 2008)
下载: 导出CSV
表 2 各水流系统模式的入渗强度比设置
Table 2. Settings of infiltration intensity ratios for different flow patterns
下载: 导出CSV
表 3 各工况中硝酸盐输入的时空条件
Table 3. Spatiotemporal conditions of nitrate input in the simulation cases
工况 硝酸盐输入位置 硝酸盐输入时间序列$ C_{\mathrm{N}{\mathrm{O}}_{3}, \text{watertable}} $ (t) Case-Ⅰ不同水流系统模式中的硝酸盐水文遗留时间(tNHRT)分布特征 上边界均匀输入(RZ1+RZ2+RZ3) 恒定值100 mg/L Case-Ⅱ不同输入位置下的排泄区硝酸盐水文遗留时间(tNHRT')特征 分别在RZ1/RZ2/RZ3输入 100 mg/L，溶质运移稳定后(85 a)降至0 Case-Ⅲ不同管控强度下的排泄区硝酸盐水文遗留时间(tNHRT')特征 上边界均匀输入(RZ1+RZ2+RZ3) 保持现状/逐步停止/立即停止
下载: 导出CSV
表 4 不同水流系统模式下地下水平均滞留时间和硝酸盐平均水文遗留时间
Table 4. Mean groundwater residence time and mean nitrate hydrologic residence time across different flow patterns
下载: 导出CSV
-
Allard, M., World Health Organization, 1992. GEMS/WATER Operational Guide. Report GEMS/W. 92.1. National Water Research Institute, Burlington. Chen, D. J., Hu, M. P., Dahlgren, R. A., 2014. A Dynamic Watershed Model for Determining the Effects of Transient Storage on Nitrogen Export to Rivers. Water Resources Research, 50(10): 7714-7730. https://doi.org/10.1002/2014wr015852 Chen, D. J., Shen, H., Hu, M. P., et al., 2018. Legacy Nutrient Dynamics at the Watershed Scale: Principles, Modeling, and Implications. Advances in Agronomy. Elsevier, Amsterdam, 237-313. https://doi.org/10.1016/bs.agron.2018.01.005 Domenico, P. A., Schwartz, F. W., 1997. Physical and Chemical Hydrogeology. John Wiley Sons, New York. Erler, D. V., Shepherd, B. O., Linsley, B. K., et al., 2018. Coral Skeletons Record Increasing Agriculture-Related Groundwater Nitrogen Inputs to a South Pacific Reef over the Past Century. Geophysical Research Letters, 45(16): 8370-8378. https://doi.org/10.1029/2018gl078656 Gao, J. B., Wang, S. M., Li, Z. Q., et al., 2021. High Nitrate Accumulation in the Vadose Zone after Land-Use Change from Croplands to Orchards. Environmental Science Technology, 55(9): 5782-5790. https://doi.org/10.1021/acs.est.0c06730 Gelhar, L. W., Welty, C., Rehfeldt, K. R., 1992. A Critical Review of Data on Field-Scale Dispersion in Aquifers. Water Resources Research, 28(7): 1955-1974. https://doi.org/10.1029/92wr00607 Goode, D. J., 1996. Direct Simulation of Groundwater Age. Water Resources Research, 32(2): 289-296. https://doi.org/10.1029/95wr03401 Green, C. T., Jurgens, B. C., Zhang, Y., et al., 2016. Regional Oxygen Reduction and Denitrification Rates in Groundwater from Multi-Model Residence Time Distributions, San Joaquin Valley, USA. Journal of Hydrology, 543: 155-166. https://doi.org/10.1016/j.jhydrol.2016.05.018 Gu, B. J., Ge, Y., Chang, S. X., et al., 2013. Nitrate in Groundwater of China: Sources and Driving Forces. Global Environmental Change, 23(5): 1112-1121. https://doi.org/10.1016/j.gloenvcha.2013.05.004 Hu, M. P., 2019. Quantitative Study on Lag Effect of Watershed Non-Point Source Nitrogen Pollution (Disserattion). Zhejiang University, Hangzhou (in Chinese with English abstract). Jiang, X. W., Wan, L., Wang, X. S., et al., 2012. Distribution of Groundwater Age in Drainage Basins. Hydrogeology Engineering Geology, 39(4): 1-6(in Chinese with English abstract). Jiang, X. W., Wang, X. S., Wan, L., et al., 2011. An Analytical Study on Stagnation Points in Nested Flow Systems in Basins with Depth-Decaying Hydraulic Conductivity. Water Resources Research, 47: 2010WR009346. https://doi.org/10.1029/2010wr009346 Kolbe, T., de Dreuzy, J. R., Abbott, B. W., et al., 2019. Stratification of Reactivity Determines Nitrate Removal in Groundwater. Proceedings of the National Academy of Sciences of the United States of America, 116(7): 2494-2499. https://doi.org/10.1073/pnas.1816892116 Korom, S. F., 1992. Natural Denitrification in the Saturated Zone: A Review. Water Resources Research, 28(6): 1657-1668. https://doi.org/10.1029/92wr00252 Liang, X., Quan, D. J., Jin, M. G., et al., 2013. Numerical Simulation of Groundwater Flow Patterns Using Flux as Upper Boundary. Hydrological Processes, 27(24): 3475-3483. https://doi.org/10.1002/hyp.9477 Liu, C., Gong, X. L., Liang, Y., et al., 2025. Characteristics of Seasonal Changes in Organic Matter of Groundwater in Binhai, Jiangsu Province and Its Impact on Nitrogen Transport and Transformation. Earth Science, 50(6): 2400-2415(in Chinese with English abstract). Liu, H. W., Luan, H. A., Zhang, Y. T., et al., 2024. Research Progress on the Occurrence Characteristics of Nitrogen and Phosphorus Leaching in Dryland Farmland. Chinese Journal of Eco-Agriculture, 32(9): 1520-1533 (in Chinese with English abstract) Liu, Y. Y., Liu, C. X., Nelson, W. C., et al., 2017. Effect of Water Chemistry and Hydrodynamics on Nitrogen Transformation Activity and Microbial Community Functional Potential in Hyporheic Zone Sediment Columns. Environmental Science Technology, 51(9): 4877-4886. https://doi.org/10.1021/acs.est.6b05018 McMahon, P. B., Böhlke, J. K., Kauffman, L. J., et al., 2008. Source and Transport Controls on the Movement of Nitrate to Public Supply Wells in Selected Principal Aquifers of the United States. Water Resources Research, 44(4): 2007WR006252. https://doi.org/10.1029/2007wr006252. Nian, G. Q., Chen, Z. H., Zhang, L. F., et al., 2020. Treatment of Two Boundary Conditions for Rainfall Infiltration in Slope and Its Application. Rock and Soil Mechanics, 41(12): 4105-4115 (in Chinese with English abstract). Peterson, M. E., Curtin, D., Thomas, S., et al., 2013. Denitrification in Vadose Zone Material Amended with Dissolved Organic Matter from Topsoil and Subsoil. Soil Biology and Biochemistry, 61: 96-104. https://doi.org/10.1016/j.soilbio.2013.02.010. Puckett, L. J., Tesoriero, A. J., Dubrovsky, N. M., 2011. Nitrogen Contamination of Surficial Aquifers—A Growing Legacy. Environmental Science Technology, 45(3): 839-844. https://doi.org/10.1021/es1038358. Quan, D. J., 2012. Analysis of Two-Dimension Groundwater Flow Patterns and Transformation Rules (Dissertation). China University of Geosciences (Wuhan), Wuhan(in Chinese with English abstract). Spalding, R. F., Exner, M. E., 1993. Occurrence of Nitrate in Groundwater: A Review. Journal of Environmental Quality, 22(3): 392-402. https://doi.org/10.2134/jeq1993.00472425002200030002x. Sun, R., 2018. Numerical Simulation of Coastal Nutrient Input Processes Using Transport-Reaction Numerical Model (Dissertation). China University of Geosciences (Beijing), Beijing (in Chinese with English abstract). Tang, J. H., 2023. Effects of Nitrogen Reduction Combined with Urease/Nitrification Inhibitors on Nitrogen Loss and Nitrogen Use Efficiency in Purple Soil-Wheat System (Dissertation). Sichuan Agricultural University, Chengdu (in Chinese with English abstract). Tóth, J., 1963. A Theoretical Analysis of Groundwater Flow in Small Drainage Basins. Journal of Geophysical Research, 68(16): 4795-4812. https://doi.org/10.1029/jz068i016p04795. Van Meter, K. J., Basu, N. B., 2017. Time Lags in Watershed-Scale Nutrient Transport: An Exploration of Dominant Controls. Environmental Research Letters, 12(8): 084017. https://doi.org/10.1088/1748-9326/aa7bf4 Wang, J. L., Jin, M. G., Jia, B. J., et al., 2022. Numerical Investigation of Residence Time Distribution for the Characterization of Groundwater Flow System in Three Dimensions. Journal of Earth Science, 33(6): 1583-1600. https://doi.org/10.1007/s12583-022-1623-3 Wang, J. Q., Ma, R., Sun, Z. Y., 2019. Reactive Transport and Model of Nitrogen Pollutants in the Surface Water-Ground Water Interaction Zones: A Review. Geological Science and Technology Information, 38(4): 270-280 (in Chinese with English abstract). Wang, J. Z., 2015. A Methodological Study on the Identification of Hierarchically Nested Groundwater Flow Systems in Drainage Basins (Dissertation). China University of Geosciences (Beijing), Beijing(in Chinese with English abstract). Wang, Y. A., Zhao, R. C., Ding, L., et al., 2025. Karst Trough Control of Solute Transport Processes at Two Karst Groundwater Flow Systems, Western Hubei, Central China. Journal of Earth Science, 36(4): 1731-1741. https://doi.org/10.1007/s12583-022-1665-6 Wei, R. C., Tang, S. M., Wu, C. S., et al., 2020. Redox Zoning of Shallow Groundwater in Dongting Lake Region. China Environmental Science, 40(4): 1715-1722 (in Chinese with English abstract) Wentworth, C. K., 1922. A Scale of Grade and Class Terms for Clastic Sediments. The Journal of Geology, 30(5): 377-392. https://doi.org/10.1086/622910. Zhang, J., 2021. Hierarchically Nested Groundwater Flow System and Hydrological and Ecological Effects in the Northern Ordos Basin (Dissertation). Chang'an University, Xi'an(in Chinese with English abstract). Zhang, X. L., Jiao, J. J., 2023. Numerical Modelling Study on Non-Steady-State Groundwater Flow Systems in Response to Changing Rainfall. Bulletin of Geological Science and Technology, 42(4): 154-161, 169 (in Chinese with English abstract). 胡敏鹏, 2019. 流域非点源氮污染的滞后效应定量研究(博士学位论文). 杭州: 浙江大学. 蒋小伟, 万力, 王旭升, 等, 2012. 盆地地下水年龄空间分布规律. 水文地质工程地质, 39(4): 1-6. 刘晨, 龚绪龙, 梁莹, 等, 2025. 江苏滨海地下水有机质季节变化特征及对氮迁移转化影响. 地球科学, 50(6): 2400-2415. doi: 10.3799/dqkx.2025.053 刘瀚文, 栾好安, 张亦涛, 等, 2024. 旱地农田氮磷淋溶发生特征研究进展. 中国生态农业学报(中英文), 32(9): 1520-1533. 年庚乾, 陈忠辉, 张凌凡, 等, 2020. 边坡降雨入渗问题中两种边界条件的处理及应用. 岩土力学, 41(12): 4105-4115. 权董杰, 2012. 二维盆地地下水流模式与转化规律分析(硕士学位论文). 武汉: 中国地质大学(武汉). 孙锐, 2018. 利用运移—反应数值模型模拟海岸带营养盐输入过程(硕士学位论文). 北京: 中国地质大学(北京). 唐俊辉, 2023. 氮肥减量配施脲酶/硝化抑制剂对紫色土—小麦系统氮损失及利用效率的影响研究(硕士学位论文). 成都: 四川农业大学. 王佳琪, 马瑞, 孙自永, 2019. 地表水与地下水相互作用带中氮素污染物的反应迁移机理及模型研究进展. 地质科技情报, 38(4): 270-280. 王俊智, 2015. 盆地多级次地下水流系统识别方法研究(博士学位论文). 北京: 中国地质大学(北京). 危润初, 唐仕明, 吴长山, 等, 2020. 洞庭湖区浅层地下水氧化还原分带规律. 中国环境科学, 40(4): 1715-1722. 张俊, 2021. 鄂尔多斯高原多级嵌套地下水流系统形成演化及水文生态效应(博士学位论文). 西安: 长安大学. 张萧琅, 焦赳赳, 2023. 非稳态地下水流系统响应降雨变化的数值模型研究. 地质科技通报, 42(4): 154-161, 169. -
