Research on the Shear Thickening Response Characteristics of Intelligent Plugging Drilling Fluid under Solid-Liquid Invasion Conditions
-
摘要: 钻井液漏失不仅损失大量钻井液还会导致孔壁失稳等事故.为明确实际钻井中存在的地层粘土矿物和水侵入对智能堵漏钻井液剪切增稠响应规律，选用纳米二氧化硅和聚乙二醇制备剪切增稠流体（STF），通过SEM、氮气吸脱附和比重瓶法表征纳米二氧化硅；通过挤压流动测试、稳态剪切测试表征STF增稠特性；设计伊利石、高岭石和蒙脱石侵入量0、1.8%、3.6%、5.4%和7.2%，水侵入量为0、2%、4%、6%和8%的试验. 结果表明高岭石和伊利石侵入会导致STF最大粘度下降79.8%和72.9%；而5.4%蒙脱石侵入导致STF增稠强度增大了56.4%. 8%水侵会显著稀释-抑制STF增稠特性，剪切增稠强度下降99.6%. 为剪切增稠型智能堵漏钻井液的应用提供了理论参考.Abstract: Drilling fluid loss results in significant material wastage and can lead to severe accidents such as borehole instability. To elucidate the effects of formation clay minerals and water intrusion on the shear thickening response of smart plugging drilling fluids, shear thickening fluids (STFs) were prepared using nano-silica and polyethylene glycol (PEG). The nano-silica was characterized by SEM, nitrogen adsorption-desorption and the balance bottle method.The STFs were characterized via squeeze flow and steady-state shear tests. Experiments were designed involving the intrusion of illite, kaolinite, and montmorillonite at concentrations of 0, 1.8%, 3.6%, 5.4%, and 7.2%, as well as water intrusion at 0, 2%, 4%, 6%, and 8%. The results indicate that the intrusion of kaolinite and illite reduced the maximum viscosity of the STF by 79.8% and 72.9%, respectively, due to the interlayer slippage effect. In contrast, the intrusion of 5.4% montmorillonite increased the thickening intensity of the STF by 56.4%. However, 8% water intrusion significantly diluted and inhibited the thickening characteristics of the STF, causing a 99.6% decrease in shear thickening intensity. This study provides a theoretical reference for the application of shear-thickening-based smart plugging drilling fluids.
-
Key words:
- smart materials /
- shear thickening fluid /
- plugging /
- rheology /
- clay minerals /
- drilling
-
图 4 300 nm、500 nm二氧化硅制备的STF稳态剪切流变曲线
Fig. 4. Steady-state shear rheological curves of STF prepared with 300 nm and 500 nm silica
图 5 不同挤压速度下STF法向应力与板间距关系
a. 300 nm二氧化硅；b. 500 nm二氧化硅
Fig. 5. Relationship between normal stress and gap distance of STF at different squeeze speeds
图 7 （a）不同纳米二氧化硅体积分数STF的流变曲线；（b）体积分数与流变参数的关系
Fig. 7. (a) Rheological curves of STF with different silica volume fractions; (b) Relationship between volume fraction and rheological parameters
图 8 （a）高岭石侵入的STF流变曲线；（b）高岭石侵入与流变参数的关系; （c）伊利石侵入的STF流变曲线；（d）伊利石侵入与流变参数的关系
Fig. 8. (a) Rheological curves of STF with kaolinite intrusion; (b) Relationship between kaolinite intrusion and rheological parameters; (c) Rheological curves of STF with illite intrusion; (d) Relationship between illite intrusion and rheological parameters
图 9 片状粘土矿物侵入后STF最大表观粘度下降机理示意图
Fig. 9. Schematic diagram of the reduction mechanism of maximum apparent viscosity of STF after flaky clay mineral intrusion
图 10 (a) 蒙脱石侵入的STF流变曲线；（b）蒙脱石侵入与流变参数的关系
Fig. 10. (a) Rheological curves of STF with montmorillonite intrusion; (b) Relationship between montmorillonite intrusion and rheological parameters
图 11 蒙脱石侵入的双重作用机制示意图
Fig. 11. Schematic diagram of the dual-action mechanism of montmorillonite intrusion
图 12 (a) 水侵入的STF流变曲线；（b）水侵入与流变参数的关系
Fig. 12. (a) Rheological curves of STF with water intrusion; (b) Relationship between water intrusion and rheological parameters
图 13 水侵对STF体系的“宏观稀释”与“微观润滑”作用机理图
Fig. 13. Mechanism diagram of "macroscopic dilution" and "microscopic lubrication" effects of water intrusion on the STF system
表 1 STF增稠特性影响因素试验参数表
Table 1. Experimental parameters of factors affecting the thickening characteristics of STF
自变量 纳米二氧化硅粒径（nm） 纳米二氧化硅体积分数（%） 伊利石侵入量（%） 高岭石侵入量（%） 蒙脱石侵入量（%） 水侵入量（%） 变量梯度 300 54 0.0 0.0 500 56 1.8 2.0 / 59 3.6 4.0 / 61 5.4 6.0 / / 7.2 8.0 测试方法 稳态剪切流变测试、挤压流动测试 稳态剪切流变测试
下载: 导出CSV
表 2 纳米二氧化硅颗粒表征参数
Table 2. Characterization parameters of nanosilica
纳米二氧化硅粒径 比表面积（m2/g） 颗粒密度（g/cm3） 300 nm 180 1.98 500 nm 170 1.82
下载: 导出CSV
-
Bai, Y. R., Sun, J. S., Lv, K. H., et al., 2019. Preparation and Application of Shear-Responsive Plugging. Gel. CN109825269(in Chinese). Bao, D., Qiu, Z. S., Qiu, W. Q., et al., 2019. Experiment on Properties of Lost Circulation Materials in High Temperature Formation. Acta Petrolei Sinica, 40(7): 846-857(in Chinese with English abstract). Brady, J. F., Bossis, G., 1985. The Rheology of Concentrated Suspensions of Spheres in Simple Shear Flow by Numerical Simulation. Journal of Fluid Mechanics, 155: 105-129. https://doi.org/10.1017/s0022112085001732 Chen, Q., He, Q. Y., Liu, M., etal., 2016. Mechanical Properties and Mechanism of Shear Thickening Fluid. Chinese Journal of Solid Mechanics, 37(6): 518-537(in Chinese). Cheng, X., McCoy, J. H., Israelachvili, J. N., et al., 2011. Imaging the Microscopic Structure of Shear Thinning and Thickening Colloidal Suspensions. Science, 333(6047): 1276-1279. https://doi.org/10.1126/science.1207032 Deng, Y. Y., Sun, P. H., Xia, Y., et al., 2024. Experimental Study on the Sealing Characteristics of Fractured Formation by Shear Thickening Fluid. Drilling Engineering, 51(5): 68-76(in Chinese with English abstract). Du, S. R., Liu, Y. Q., Fan, Y. Z., et al., 2022. Influence of the Dispersibility of Fumed Silica on the Steady-State Rheological Property of STF. New Chemical Materials, 50(4): 220-224(in Chinese with English abstract). Hao, Y. X., Yin, C., Li, Y. Z., et al., 2025. Evaluation of Fracturing Effect and Mechanism of Casing Deformation Weakening for Ultra-Long Section Fracturing. Earth Science, 50(12): 4751-4763(in Chinese with English abstract). Hu, C. F., Jiang, J. Y., Cai, J. C., et al., 2025. Research Progress on Aggregation Behavior Mechanism and Inhibition Methods of Nanomaterials Modified Polymers. Plastics Science and Technology, 53(11): 195-201(in Chinese with English abstract). Kang, Y. L., Zhang, J. Y., Xu, C. Y., et al., 2018. The Effect of Geometrical Morphology of Rigid Lost Circulation Materialon Its Retention Behavior in Fractures. Petroleum Drilling Techniques, 46(5): 26-34(in Chinese with English abstract). Lee, Y. S., Wagner, N. J., 2006. Rheological Properties and Small-Angle Neutron Scattering of a Shear Thickening, Nanoparticle Dispersion at High Shear Rates. Industrial & Engineering Chemistry Research, 45(21): 7015-7024. https://doi.org/10.1021/ie0512690 Li, G. R., Liu, Z. D., Zhang, J. H., et al., 2016. A Plugging Agent Containing Shape-Memory Alloy, CN201611203356.0(in Chinese). Li, W., Bai, Y. R., Li, Y. T., et al., 2021. Research and Application Progress of Drilling Fluid Lost Circulation Materials and Technical Countermeasures for Lost Circulation Control. Science Technology and Engineering, 21(12): 4733-4743(in Chinese with English abstract). Lin, J. M., Chen, Y., Min, S. N., et al., 2025. Effect of Nanowire Doping and Rheological Viscosity on Novel Design of Highly Concentrated Shear Thickening Fluid for Stabbing Resistant Composites. Composites Part B: Engineering, 303: 112601. https://doi.org/10.1016/j.compositesb.2025.112601 Liu, S., Zhao, C., Wen, Z. C., 2025. Impact Protection Performance of Kevlar Fabric Composites Impregnated with Modified Multiphase Shear Thickening Fluids. Thin-Walled Structures, 214: 113399. https://doi.org/10.1016/j.tws.2025.113399 Liu, Z. D., Li, H. B., Sun, T. F., et al., 2025. Plugging Performance of Shape Memory Foam Sealing Material with High Activation Temperature. Oilfield Chemistry, 42(3): 388-392(in Chinese with English abstract). Negi, A. S., Osuji, C. O., 2009. New Insights on Fumed Colloidal Rheology-Shear Thickening and Vorticity-Aligned Structures in Flocculating Dispersions. Rheologica Acta, 48(8): 871-881. https://doi.org/10.1007/s00397-008-0341-9 Serra, G. F., Oliveira, L., Gürgen, S., et al., 2024. Shear Thickening Fluid (STF) in Engineering Applications and the Potential of Cork in STF-Based Composites. Advances in Colloid and Interface Science, 327: 103157. https://doi.org/10.1016/j.cis.2024.103157 Sun, J. S., Bai, Y. R., Cheng, R. C., et al., 2021. Research Progress and Prospect of Plugging Technologies for Fractured Formation with Severe Lost Circulation. Petroleum Exploration and Development, 48(3): 732-743. https://doi.org/10.1016/S1876-3804(21)60059-9 Sun, J. S., Lei, S. F., Bai, Y. R., et al., 2020. Research Progress and Application Prospects of Smart Materials in Lost Circulation Control of Drilling Fluids. Journal of China University of Petroleum(Edition of Natural Science), 44(4): 100-110(in Chinese with English abstract). Sun, X. C., Li, Y. Q., Zhan, X. F., etal., 2014. Preparation and Properties of Shear Thickening Fluid. Journal of Textile Research, 35(8): 5-9(in Chinese with English abstract). Tan, Z. J., Deng, J. H., Zhang, X. Q., et al., 2023. Quantitative Characterization of Fractures under Volcanic Thermal Expansion Based on Thermal-Mechanical Coupling Analysis. Earth Science, 48(7): 2665-2677(in Chinese with English abstract). Tang, L. H., Wang, Y. L., Zhang, C. B., etal., 2022. Preparationand Evaluationof Thermosensitive Plugging Materials Basedon Shape Memory Polymers. Petroleum Drilling Techniques, 50(5): 70-75(in Chinese with English abstract). Yan, B. C., Jiang, G. C., Hu, W. J., et al., 2019. Study on High Temperature Delayed Crosslinking PAM Gel LCM. Drilling Fluid & Completion Fluid, 36(6): 679-682(in Chinese with English abstract). Yang, J. Y., Zhang, J. S., Wang, B. C., et al., 2025. Constitutive Modeling of Shear Thickening Fluid Using Continuum Mechanics. International Journal of Mechanical Sciences, 289: 110057. https://doi.org/10.1016/j.ijmecsci.2025.110057 Zarei, M., Aalaie, J., 2020. Application of Shear Thickening Fluids in Material Development. Journal of Materials Research and Technology, 9(5): 10411-10433. https://doi.org/10.1016/j.jmrt.2020.07.049 Zhao, C. Y., Gong, X. L., Wang, S., et al., 2020. Shear Stiffening Gels for Intelligent Anti-Impact Applications. Cell Reports Physical Science, 1(12): 100266. https://doi.org/10.1016/j.xcrp.2020.100266 Zhou, H., Tan, Z. H., 2021. Study on the Influence of Graphene on the Squeeze Flow Mechanical Properties of Shear Thickening Fluid. Materials Science and Technology, 29(01): 66-73(in Chinese with English abstract). 白英睿, 孙金声, 吕开河, 等, 2019. 剪切响应型凝胶堵漏剂及其制备方法与应用, CN109825269. 暴丹, 邱正松, 邱维清, 等, 2019. 高温地层钻井堵漏材料特性实验. 石油学报, 40(7): 846-857. 陈潜, 何倩云, 刘梅, 等, 2016. 剪切增稠液的力学性能与机理. 固体力学学报, 37(6): 518-537. 邓盈盈, 孙平贺, 夏余宏烨, 等, 2024. 剪切增稠流体对裂隙地层的封堵特性试验研究. 钻探工程, 51(5): 68-76. 杜苏睿, 刘亚青, 樊益泽, 等, 2022. 气相二氧化硅分散性对剪切增稠液体稳态流变学性能的影响. 化工新型材料, 50(4): 220-224. 郝越翔, 尹陈, 李宜真, 等, 2025. 页岩超长段压裂模式效果评价及套变弱化机制. 地球科学, 50(12): 4751-4763. doi: 10.3799/dqkx.2025.178 胡昌富, 蒋金云, 蔡建臣, 等, 2025. 纳米材料改性聚合物团聚行为机理及抑制方法研究进展. 塑料科技, 53(11): 195-201. 康毅力, 张敬逸, 许成元, 等, 2018. 刚性堵漏材料几何形态对其在裂缝中滞留行为的影响. 石油钻探技术, 46(5): 26-34. 李公让, 刘振东, 张敬辉, 等, 2016. 一种含有记忆金属的堵漏剂, CN201611203356.0 李伟, 白英睿, 李雨桐, 等, 2021. 钻井液堵漏材料研究及应用现状与堵漏技术对策. 科学技术与工程, 21(12): 4733-4743. 刘振东, 李海斌, 孙腾飞, 等, 2025. 高激活温度形状记忆发泡材料堵漏性能. 油田化学, 42(3): 388-392. 孙金声, 雷少飞, 白英睿, 等, 2020. 智能材料在钻井液堵漏领域研究进展和应用展望. 中国石油大学学报(自然科学版), 44(4): 100-110. 孙西超, 李艳清, 詹小芳, 等, 2014. 剪切黏稠液体的制备及其性能. 纺织学报, 35(8): 5-9. 谭忠健, 邓津辉, 张向前, 等, 2023. 基于热力耦合分析的火山热膨胀型裂缝定量表征. 地球科学, 48(7): 2665-2677. doi: 10.3799/dqkx.2022.110 汤龙皓, 王彦玲, 张传保, 等, 2022. 基于形状记忆聚合物的温敏型堵漏材料制备与评价. 石油钻探技术, 50(5): 70-75. 颜帮川, 蒋官澄, 胡文军, 等, 2019. 高温延迟交联聚丙烯酰胺凝胶堵漏剂的研究. 钻井液与完井液, 36(6): 679-682. 周浩, 谭柱华, 2021. 石墨烯对剪切增稠液挤压流动力学性能的影响. 材料科学与工艺, 29(1): 66-73. -
