Structural Characteristics and Favorable Target Prediction of Ultra-Deep Salt-Related Structures: A Case Study of the Madong Structural Belt
-
摘要: 塔里木盆地玛东构造带是世界上保存最好的早古生代褶皱-冲断带之一，由于构造的复杂性，其中寒武统盐相关构造特征和变形机理目前还存在较大的争议，这在一定程度上制约了该地区超深层盐下油气勘探.本研究基于二维地震资料厘定了盐相关构造样式，确定了其变形期次和演化序列，建立了构造演化与板块活动的响应关系，讨论了盐相关构造变形机理，预测了盐下油气有利区.玛东构造带中寒武统膏盐岩盐上多发育向腹陆方向冲断的破冲褶皱，盐下主要为剪切褶皱作用（含压扁褶皱作用）形成的基底卷入型冲起构造.主要变形期是奥陶纪末期和志留纪末期，受控于阿尔金-祁连地体和柴达木地块与塔里木板块的拼贴碰撞.中寒武统膏盐岩层是该地区反冲断层形成的最关键的驱动因素之一.剪切褶皱作用可以间接导致形成陡倾或直立的裂缝，“盐上破冲褶皱+盐下冲起构造”的组合是超深层盐下最有力的勘探目标.Abstract: Madong structural belt in the Tarim basin is one of the best-preserved Early Paleozoic fold-thrust belts in the world. However, significant controversy persists regarding the characteristics and deformation mechanisms of Middle Cambrian salt-related structures due to complicate structures, which has constrained ultra-deep hydrocarbon exploration in the region. This study delineated the styles of salt-related structures based on 2D seismic data, determined their deformation phases and evolutionary sequence, established the response relationship between structural evolution and plate activities, discussed the deformation mechanisms, and predicted favorable sub-salt hydrocarbon targets. In the Madong structural belt, the post-salt strata predominantly developed hinterland-vergent break-thrust folds, while the sub-salt strata were dominated by basement-involved pop-up structures formed through shear folding (including flattening folding). The main deformation periods occurred at the end of the Ordovician and the Silurian, controlled by the amalgamation and collision of the Altun-Qilian Terrane and the Qaidam Block with the Tarim Plate. The Middle Cambrian gypsum-salt layer is one of the most critical driving factors for the formation of back-thrust faults in the belt. Shear folding can indirectly lead to the development of steeply dipping or vertical fractures, and the assemblage of "post-salt break-thrust folds and sub-salt pop-up structures" represents the most favorable exploration target for ultra-deep sub-salt strata.
-
图 1 塔里木盆地构造概述及沉积地层层序
a.塔里木盆地周缘板块构造(据Chen et al., 2007和董云鹏等, 2022修改)及构造单元分区; b.塔里木盆地沉积地层层序及岩性(据Lin et al., 2012修改)
Fig. 1. Overview map and stratigraphic sequences of the Tarim basin
图 2 不同类型褶皱溢出面积随褶皱层高度变化规律
a.膝折褶皱；b.平行褶皱；c.相似褶皱；d.生长背斜
Fig. 2. Variation patterns of the excess area of different types of folds with respect to fold layer height
图 3 玛东-塘南褶皱冲断带中寒武统盐相关构造样式
蓝色为中寒武统
Fig. 3. Salt-related structural styles of the Middle Cambrian in the Madong-Tangnan fold-thrust belt
图 4 玛东‒塘南褶皱冲断带中寒武统顶、底面断裂分布
Fig. 4. Distribution of faults at the top (Tg6') and bottom (Tg7) of the Middle Cambrian gypsum-salt layer in the Madong-Tangnan fold-thrust belt
图 10 玛东构造带构造演化与板块活动的响应关系
a.塔里木板块东部及其周缘地区构造演化过程（据Chen et al.，2007修改）；b~e.玛东构造带中寒武统顶面活动断裂分布（底图为中寒武统顶面在不同时期的古地貌形态）.ATR：阿尔金裂谷，ATU：阿尔金隆起；AT：阿尔金，AT-QLT：阿尔金‒祁连地体，ENTS-JGR：东北天山‒准噶尔裂谷，ETMCMB：塔里木东部大陆边缘盆地，ENTS-JGO：东北天山‒准噶尔洋，ETMBAB：塔里木东部弧后盆地，ETMBAFB：塔里木东部弧后前陆盆地，ENTM：东北塔里木，IDP：印度板块，JGP：准噶尔板块，JSJO：金沙江洋，KQFB：库车前陆盆地，KL-QMP：昆仑‒柴达木板块，KMR：库满裂谷，LSB：拉萨地块，MTSA：中天山岛弧，NATO：北阿尔金洋，NTM：北塔里木，NTSO：北天山洋，NQTB：北羌塘地块，PSTS：古南天山，PNTS：古北天山，PNKLM：古北昆仑山，QDB：柴达木地块，SATO：南阿尔金洋，STSO：南天山洋，SKLT：南昆仑地体，SQTB：南羌塘地块，TMCD：塔里木克拉通内坳陷，TZ：塔中，TMP：塔里木板块，WTMCD：塔里木西部克拉通内坳陷，YLP：伊犁板块
Fig. 10. Response relationship between structural evolution of the Madong structural belt and plate activities
图 11 玛东构造带盐相关构造演化序列
Fig. 11. Evolutionary sequence of salt-related structures in the Madong structural belt
图 12 膏盐岩滑脱层对变形楔构造样式的影响
a.无膏盐岩滑脱面；b.有膏盐岩滑脱面
Fig. 12. Influence of gypsum-salt detachment layer on structural styles of the deformation wedge
图 13 无塑性层（a）和有塑性层（b）构造物理模拟实验结果
Fig. 13. Tectonophysical simulation experiment results without (a) and with (b) the plastic detachment layer
-
Anderson, E. M., 1951. The Dynamics of Faulting and Dyke Formation with Applications to Britain. Oliver and Boyd, Edinburgh. Biot, M. A., 1961. Theory of Folding of Stratified Viscoelastic Media and Its Implications in Tectonics and Orogenesis. Geological Society of America Bulletin, 72(11): 1595. https://doi.org/10.1130/0016-7606(1961)72[1595:tofosv]2.0.co;2 Bonini, M., 2007. Deformation Patterns and Structural Vergence in Brittle-Ductile Thrust Wedges: An Additional Analogue Modelling Perspective. Journal of Structural Geology, 29(1): 141-158. https://doi.org/10.1016/j.jsg.2006.06.012 Chen, S. P., Qi, J. F., Yu, F. S., et al., 2007. Deformation Characteristics in the Southern Margin of the Junggar Basin and Their Controlling Factors. Acta Geologica Sinica, 81(2): 151-157 (in Chinese with English abstract). Chen, S. P., Wan, H. C., Yuan, H. W., et al., 2022. Deformation Asymmetry in Foreland Thrust Belts and the Kinematic Direction of the Related Thrust Faults. Journal of Geomechanics, 28(2): 182-190 (in Chinese with English abstract). Chen, S. P., Wang, Y., Jin, Z. J., 2007. Controls of Tectonics on Both Sedimentary Sequences and Petroleum Systems in Tarim Basin, Northwest China. Petroleum Science, 4(2): 1-9. https://doi.org/10.1007/bf03187435 Chen, S. P., Yun, J. B., Liu, Z. N., et al., 2018. Recoil Fault and Its Formation Mechanism in the Northwest of Tangtang, Tarim Basin. Science and Technology Innovation Herald, 15(3): 127-131 (in Chinese with English abstract). Dong, Y. P., Hui, B., Sun, S. S., et al., 2022. Multiple Orogeny and Geodynamics from Proto-Tethys to Paleo-Tethys of the Central China Orogenic Belt. Acta Geologica Sinica, 96(10): 3426-3448 (in Chinese with English abstract). Fischer, M. P., Woodward, N. B., Mitchell, M. M., 1992. The Kinematics of Break-Thrust Folds. Journal of Structural Geology, 14(4): 451-460. https://doi.org/10.1016/0191-8141(92)90105-6 Fryklund, B., Stark, P., 2020. Super Basins-New Paradigm for Oil and Gas Supply. AAPG Bulletin, 104(12): 2507-2519. https://doi.org/10.1306/09182017314 Graveleau, F., Malavieille, J., Dominguez, S., 2012. Experimental Modelling of Orogenic Wedges: A Review. Tectonophysics, 538/539/540: 1-66. https://doi.org/10.1016/j.tecto.2012.01.027 Guo, Y., Tang, L. J., Yu, T. X., et al., 2016. Fault Features and Formation Mechanism of Madong Structural Belt in Tanggubasi Depression, Tarim Basin. Geotectonica et Metallogenia, 40(4): 643-653 (in Chinese with English abstract). https://doi.org/10.16539/j.ddgzyckx.2016.04.002 Han, J. F., Wu, G. H., Xiao, Z. Y., et al., 2020. Recognition of the Distribution of Cambrian Source Rocks and Its Significance for Exploration in Tarim Basin. Chinese Journal of Geology, 55(1): 17-29 (in Chinese with English abstract). Hao, J. B., Li, Y. K., Wang, C., et al., 2025. Structural Deformation Characteristics and Its Implications of Meso- to Neoproterozoic Sedimentary Strata in the Altyn Tagh Orogenic Belt. Earth Science, 50(9): 3679-3690 (in Chinese with English abstract). https://doi.org/10.3799/dqkx.2025.158 He, J., Wang, Y., Liu, S. L., et al., 2016. Characteristics of Fault Structure and Its Control on Hydrocarbon Accumulation in the Eastern Part of Southwestern Tarim Basin. Petroleum Geology & Experiment, 38(3): 326-332 (in Chinese with English abstract). https://doi.org/10.11781/sysydz201603326 Huang, S. Y., Chen, S. P., Xu, Z. P., et al., 2025. Middle Cambrian Paleo-Highlands and Their Controls on the Gypsum-Salt Rock Distribution in Tarim Basin. Geological Bulletin of China, 44(11): 2200-2219 (in Chinese with English abstract). https://doi.org/10.12097/gbc.2023.02.061 Li, H. W., Wang, J. J., Wu, G. H., et al., 2014. Features and Formation Mechanism of Middle Caledonian Faults in West of Tangguzibasi Depression, Tarim Basin. Journal of Central South University (Science and Technology), 45(12): 4331-4341 (in Chinese with English abstract). Li, S. Z., Zhao, S. J., Liu, X., et al., 2018. Closure of the Proto-Tethys Ocean and Early Paleozoic Amalgamation of Microcontinental Blocks in East Asia. Earth-Science Reviews, 186: 37-75. https://doi.org/10.1016/j.earscirev.2017.01.011 Li, W. P., Wang, Y., Qian, Y. X., et al., 2022. The First Discovery of the Ancient Hydrocarbon Source Rocks in the Altun Area, Southeast Margin of the Tarim Basin. Natural Gas Geoscience, 33(4): 533-547 (in Chinese with English abstract). Li, Y. J., Wen, L., Li, H. L., et al., 2016. The Madong Early Paleozoic Fold-Thrust Belt in Southern Tarim Basin. Journal of Asian Earth Sciences, 115: 247-256. https://doi.org/10.1016/j.jseaes.2015.10.007 Li, Y. P., Robinson, A. C., Gadoev, M., et al., 2020. Was the Pamir Salient Built along a Late Paleozoic Embayment on the Southern Asian Margin Earth and Planetary Science Letters, 550: 116554. https://doi.org/10.1016/j.epsl.2020.116554 Lin, C. S., Yang, H. J., Liu, J. Y., et al., 2012. Distribution and Erosion of the Paleozoic Tectonic Unconformities in the Tarim Basin, Northwest China: Significance for the Evolution of Paleo-Uplifts and Tectonic Geography during Deformation. Journal of Asian Earth Sciences, 46: 1-19. MacKay, M. E., 1995. Structural Variation and Landward Vergence at the Toe of the Oregon Accretionary Prism. Tectonics, 14(6): 1309-1320. https://doi.org/10.1029/95tc02320 Qi, J. F., Li, Y., Wu, C., et al., 2013. The Interpretation Models and Discussion on the Contractive Structure Deformation of Kuqa Depression, Tarim Basin. Geology in China, 40(1): 106-120 (in Chinese with English abstract). Shao, X. Z., Xu, S. B., Zhou, D. Y., 1997. Structural Feature of Earth Crust in Tarim Basin. Petroleum Exploration and Development, 24(2): 1-5, 96 (in Chinese with English abstract). Tian, Y. J., Tang, L. J., Yu, T. X., et al., 2017. Structural Style and Evolution of Fault-Related Folds in Yudong-Madong Structural Belt, Tarim Basin. Chinese Journal of Geology (Scientia Geologica Sinica), 52(1): 15-33 (in Chinese with English abstract). https://doi.org/10.12017/dzkx.2017.001 Wang, B., Wang, W., Zhu, L. C., et al., 2019. Fault-Related Fold and Its Application to Madong Fold and Thrust Belt. Geological Journal of China Universities, 25(2): 268-275 (in Chinese with English abstract). Wu, C. L., Wu, D., Mattinson, C., et al., 2019. Petrogenesis of Granitoids in the Wulan Area: Magmatic Activity and Tectonic Evolution in the North Qaidam, NW China. Gondwana Research, 67: 147-171. https://doi.org/10.1016/j.gr.2018.09.010 Wu, G. H., Deng, W., Huang, S. Y., et al., 2020. Tectonic-Paleogeographic Evolution in the Tarim Basin. Chinese Journal of Geology, 55(2): 305-321 (in Chinese with English abstract). Xu, S. D., Chen, S. P., Zhao, H. B., et al., 2024. Basin-Range Coupling Relationship and Prediction of Favorable Targets for Ultra-Deep Subsalt Exploration in the Tarim Basin, Northwest China. Journal of Asian Earth Sciences, 260: 105955. https://doi.org/10.1016/j.jseaes.2023.105955 Xu, Z. P., Chen, S. P., Luo, C. M., et al., 2023. Distribution and Sealing Capacity Evaluation of Gypsum-Salt Rocks in the Middle Cambrian in Tarim Basin. China Petroleum Exploration, 28(5): 54-67 (in Chinese with English abstract). Yamada, Y., McClay, K., 2003. Application of Geometric Models to Inverted Listric Fault Systems in Sandbox Experiments. Paper 1: 2D Hanging Wall Deformation and Section Restoration. Journal of Structural Geology, 25(9): 1551-1560. https://doi.org/10.1016/S0191-8141(02)00181-5 Yang, H. J., Chen, Y. Q., Pan, W. Q., et al., 2021. Study on Tectonic and Sedimentary Evolution during the Nanhua-Middle Cambrian and Its Significance for Subsalt Exploration, Tarim Basin. China Petroleum Exploration, 26(4): 84-98 (in Chinese with English abstract). Yang, H. J., Li, Y. J., Li, Y., et al., 2016. Madong Early Paleozoic Fold-Thrust Belt in the Southern Tarim Basin. Acta Petrologica Sinica, 32(3): 815-824 (in Chinese with English abstract). Yang, H. J., Wu, G. H., Kusky, T. M., et al., 2018. Paleoproterozoic Assembly of the North and South Tarim Terranes: New Insights from Deep Seismic Profiles and Precambrian Granite Cores. Precambrian Research, 305: 151-165. https://doi.org/10.1016/j.precamres.2017.11.015 Young, I. F., Ambrose, G. J., 2007. Petroleum Geology of the Southeastern Amadeus Basin: The Search for Sub-Salt Hydrocarbons. In: Proceedings of the Central Australian Basins Symposium, Alice Springs, 183-204. Yue, L. X., Xie, H. S., Liu, C. Q., et al., 2003. Origin of Low-Velocity Layer in the Lower Crust of Southwest Tarim: Limits of Velocity and Attenuation for Plagioclase Amphibolite. Geology-Geochemistry, 31(3): 13-19 (in Chinese with English abstract). Zhang, Y. G., Pan, W. Q., Zhu, B., et al., 2022. Recrystallization of Dolostones in the Cambrian Xiaoerbrak Formation, Tarim Basin and Possible Link to Reservoir Development. Marine and Petroleum Geology, 136: 105452. https://doi.org/10.1016/j.marpetgeo.2021.105452 Zhang, Z., Yang, X. Z., Hao, F., et al., 2024. Fluid Inclusion Characteristics and Hydrocarbon Accumulation Process in Lungu Area, Tarim Basin. Earth Science, 49(7): 2407-2419 (in Chinese with English abstract). https://doi.org/10.3799/dqkx.2022.494 Zhao, R. B., Lu, J. F., Yang, Z. E., et al., 2008. Deep-Shallow Structures in Tianshan Mountain and Basin-Mountain Coupling Relationship. Xinjiang Petroleum Geology, 29(3): 278-282 (in Chinese with English abstract). 陈书平, 漆家福, 于福生, 等, 2007. 准噶尔盆地南缘构造变形特征及其主控因素. 地质学报, 81(2): 151-157. 陈书平, 万华川, 袁浩伟, 等, 2022. 前陆冲断带非对称性变形与逆冲断层运动学指向. 地质力学学报, 28(2): 182-190. 陈书平, 云金表, 刘志娜, 等, 2018. 塔里木盆地塘西北反冲断层及其形成机制. 科技创新导报, 15(3): 127-131. 董云鹏, 惠博, 孙圣思, 等, 2022. 中国中央造山系原-古特提斯多阶段复合造山过程. 地质学报, 96(10): 3426-3448. 郭颖, 汤良杰, 余腾孝, 等, 2016. 塔里木盆地塘古巴斯坳陷玛东构造带断裂特征及成因探讨. 大地构造与成矿学, 40(4): 643-653. 韩剑发, 邬光辉, 肖中尧, 等, 2020. 塔里木盆地寒武系烃源岩分布的重新认识及其意义. 地质科学, 55(1): 17-29. 郝江波, 李宇科, 王超, 等, 2025. 阿尔金造山带中-新元古代沉积地层构造变形特征及其指示意义. 地球科学, 50(9): 3679-3690. doi: 10.3799/dqkx.2025.158 何娟, 王毅, 刘士林, 等, 2016. 塔里木盆地西南坳陷东部构造特征及对油气成藏的控制. 石油实验地质, 38(3): 326-332. 黄少英, 陈书平, 徐振平, 等, 2025. 塔里木盆地中寒武统古高地及对膏盐岩分布的控制. 地质通报, 44(11): 2200-2219. 李浩武, 王建君, 邬光辉, 等, 2014. 塔里木盆地塘古孜巴斯坳陷西部中加里东期断裂特征及形成机制. 中南大学学报(自然科学版), 45(12): 4331-4341. 李王鹏, 王毅, 钱一雄, 等, 2022. 塔里木盆地东南缘阿尔金地区首次发现古老烃源岩. 天然气地球科学, 33(4): 533-547. 漆家福, 李勇, 吴超, 等, 2013. 塔里木盆地库车坳陷收缩构造变形模型若干问题的讨论. 中国地质, 40(1): 106-120. 邵学钟, 徐树宝, 周东延, 1997. 塔里木盆地地壳结构特征. 石油勘探与开发, 24(2): 1-5, 96. 田亚杰, 汤良杰, 余腾孝, 等, 2017. 塔里木盆地玉东: 玛东构造带断层相关褶皱样式及演化. 地质科学, 52(1): 15-33. 王斌, 汪伟, 朱礼春, 等, 2019. 断层相关褶皱在塔里木盆地玛东地区的应用. 高校地质学报, 25(2): 268-275. 邬光辉, 邓卫, 黄少英, 等, 2020. 塔里木盆地构造-古地理演化. 地质科学, 55(2): 305-321. 徐振平, 陈书平, 罗彩明, 等, 2023. 塔里木盆地中寒武统膏盐岩分布及封闭性评价. 中国石油勘探, 28(5): 54-67. 杨海军, 陈永权, 潘文庆, 等, 2021. 塔里木盆地南华纪-中寒武世构造沉积演化及其盐下勘探选区意义. 中国石油勘探, 26(4): 84-98. 杨海军, 李曰俊, 李勇, 等, 2016. 塔里木盆地南部玛东早古生代褶皱-冲断带. 岩石学报, 32(3): 815-824. 岳兰秀, 谢鸿森, 刘丛强, 等, 2003. 塔里木西南缘下地壳低速层的成因: 斜长角闪岩的纵波速度和衰减的限制. 地质地球化学, 31(3): 13-19. 张泽, 杨宪彰, 郝芳, 等, 2024. 塔里木盆地轮古地区流体包裹体特征与油气成藏过程. 地球科学, 49(7): 2407-2419. 赵瑞斌, 卢静芳, 杨主恩, 等, 2008. 天山深浅构造特征及盆山耦合关系. 新疆石油地质, 29(3): 278-282. -
