Analysis of Fault-Moho Characteristics and Prediction of Hydrocarbon-Rich Sags in Bohai Bay Basin Based on Gravity Data
-
摘要: 渤海湾盆地作为叠置在古生代华北克拉通坳陷之上的新生代陆内裂谷盆地，处于三大构造域交接中心，其含油气性与地壳结构密切相关. 基于渤海湾盆地的重力数据，系统分析了盆地断裂体系、基底与莫霍面分布特征，并通过主成分分析（PCA）对59个凹陷的油气富集潜力进行定量评价.研究表明，盆地断裂具有多向发育、分级控制、深浅耦合特征，其形成受“地幔热伸展‒板块边界走滑”双动力源协同驱动；莫霍面与基底呈显著镜像响应关系，海域莫霍面平均深度（33.5 km）显著浅于陆域（42.1 km），结晶地壳厚度呈现“陆域厚（36.7 km）、海域薄（25.3 km）”的空间分异特征；渤中凹陷作为盆地内地幔隆起与地壳拉伸减薄的核心区域，油气富集潜力综合评分达1.00，位列所有凹陷之首.依据油气富集综合评分，将59个凹陷划分为四类勘探靶区，其中Ⅰ-Ⅲ类凹陷（含渤中、东营、饶阳、惠民等27个凹陷）为油气勘探有利区域，Ⅳ类凹陷（32个）因深部构造活动微弱、成藏条件受限，勘探价值较低. 本研究成果不仅揭示了渤海湾盆地深部地壳结构与油气富集的关联机制，更为该盆地及全球同类陆内裂谷盆地的油气资源精准勘探提供了重要的深部地质依据与技术支撑.Abstract: As a Cenozoic intracontinental rift basin superimposed on the Paleozoic North China Craton depression, the Bohai Bay basin is located at the junction center of three major tectonic domains, where its hydrocarbon potential is closely related to the crustal structure. Based on the gravity data of the Bohai Bay basin, this study systematically analyzes the fault system of basin, basement characteristics, and Moho discontinuity distribution, and quantitatively evaluates the oil and gas enrichment potential of 59 sags using Principal Component Analysis (PCA). The results show that the faults of basin are characterized by multi-directional development, hierarchical control, and deep-shallow coupling, with their formation synergistically driven by the dual dynamic sources of "mantle thermal extension and plate boundary strike-slip movement". The Moho discontinuity exhibits a significant mirror response relationship with the basement: the average depth of the Moho in the marine area (33.5 km) is significantly shallower than that in the continental area (42.1 km), and the crystalline crust thickness shows a spatial differentiation feature of "thicker in the continental area (36.7 km) and thinner in the marine area (25.3 km)". As the core area of mantle uplift and crustal stretching-thinning in the basin, the Bozhong sag achieved a comprehensive score of 1.00 for oil and gas enrichment potential, ranking first among all sags. According to the comprehensive enrichment score, the 59 sags were classified into four types of exploration targets. Among them, Type Ⅰ-Ⅲ sags (including 27 sags such as Bozhong, Dongying, Raoyang, and Huimin) are favorable for oil and gas exploration, while Type Ⅳ sags (32 sags) have low exploration value due to weak deep tectonic activity and limited reservoir-forming conditions. The findings of this study not only reveal the correlation mechanism between deep crustal structure and oil-gas enrichment in the Bohai Bay basin but also provide important deep geological basis and technical support for the precise exploration of oil and gas resources in this basin and similar intracontinental rift basins worldwide.
-
Key words:
- Bohai Bay basin /
- fault /
- Moho characteristics /
- crustal characteristics /
- hydrocarbon-rich sag /
- tectonics /
- petroleum geology
-
图 1 渤海湾盆地地形高程及构造单元
Fig. 1. Topographic elevation and structural units of the Bohai Bay basin
图 2 渤海湾盆地及邻域布格重力异常
Fig. 2. Bouguer gravity anomalies in the Bohai Bay basin and its adjacent areas
图 3 渤海湾盆地断裂识别结果
a.凹陷级断裂识别；b.渤海湾盆地断裂体系
Fig. 3. Fault identification results of the Bohai Bay basin
图 4 渤海湾盆地沉积层结构特征
a.沉积层底面（基底）深度；b.沉积层厚度
Fig. 4. Structural characteristics of the sedimentary layer in the Bohai Bay basin
图 9 莫霍面及地壳拉张因子
a.莫霍面拉张因子；b.地壳拉张因子
Fig. 9. Moho stretching factor and crustal stretching factor
图 10 各凹陷内部莫霍面深度及地壳厚度的统计结果
a.各凹陷内部莫霍面深度的统计结果；b.各凹陷内部地壳厚度的统计结果
Fig. 10. Statistical results of Moho depth and crustal thickness inside each sag
图 11 渤海湾盆地海域凹陷莫霍面最小值统计对比
Fig. 11. Statistical comparison of Moho minimum values in offshore sags of the Bohai Bay basin
图 12 各凹陷内部莫霍面及地壳拉张因子的统计结果
a.各凹陷内部莫霍面拉张因子的统计结果；b.各凹陷内部地壳拉张因子的统计结果
Fig. 12. Statistical results of the Moho stretching factor and crustal stretching factor inside each sag
-
Cai, M. K., Wang, W. Y., Zhang, Y. M., et al., 2025. The Influence of Faults and the Moho Interface on the Differential Hydrocarbon Accumulation between Marine and Terrestrial Areas in the Bohai Bay Basin. Acta Geologica Sinica, 99(5): 1554-1575 (in Chinese with English abstract). Cai, M. K., Zhang, G. C., Wang, W. Y., et al., 2024. Study on Crustal Thickness and the Prediction of Prolific Depressions: The Bohai Basin as an Example. Acta Oceanologica Sinica, 43(4): 92-104. https://doi.org/10.1007/s13131-024-2339-2 Chen, G. X., Zhang, M. H., Zhang, S., 2019. Constraint Interface Inversion with Variable Density Model Used in the Study of Deep Structure of Bohai. Progress in Geophysics, 34(6): 2406-2413 (in Chinese with English abstract). Cox, A., Engebretson, D., 1985. Change in Motion of Pacific Plate at 5 Myr BP. Nature, 313(6002): 472-474. https://doi.org/10.1038/313472a0 Deng, X. F., Li, H. Q., Gao, R., 2023. Depth Migration of Crustal-Scale Seismic Reflection Profiles: A Case Study in the Bohai Bay Basin. Frontiers in Earth Science, 11: 1145095. https://doi.org/10.3389/feart.2023.1145095 Guan, D. L., Ke, X. P., Wang, Y., 2016. Basement Structures of East and South China Seas and Adjacent Regions from Gravity Inversion. Journal of Asian Earth Sciences, 117: 242-255. https://doi.org/10.1016/j.jseaes.2015.12.017 Hao, T. Y., You, Q. Y., Liu, L. H., et al., 2013. Joint Land-Sea Seismic Survey and Research on the Deep Structures of the Bohai Sea Areas. Acta Oceanologica Sinica, 32(12): 13-24. https://doi.org/10.1007/s13131-013-0383-4 Hu, Z. W., Xu, C. G., Wang, D. Y., et al., 2019. Superimposed Characteristics and Genetic Mechanism of Strike-Slip Faults in the Bohai Sea, China. Petroleum Exploration and Development, 46(2): 265-279 (in Chinese with English abstract). doi: 10.1016/S1876-3804(19)60007-8 Li, C., Chen, S. Y., Pu, X. G., et al., 2024. Stratigraphic Subdivision and Correlation of the Mesozoic in the Bohai Bay Basin. Earth Science, 49(3): 1119-1143 (in Chinese with English abstract). Li, S. Z., Suo, Y. H., Dai, L. M., et al., 2010. Development of the Bohai Bay Basin and Destruction of the North China Craton. Earth Science Frontiers, 17(4): 64-89 (in Chinese with English abstract). Li, Z. H., Zheng, Y. P., Zhi, P. Y., et al., 2015. The New Progress of Deep Seismic Survey and Crustal Structure in Southeast of Bohai Sea-Based on the Data Processing and Analysis of OBS2013 Line. Progress in Geophysics, 30(3): 1402-1409 (in Chinese with English abstract). Li, Z. W., Xu, Y., Hao, T. Y., et al., 2006. Seismic Tomography and Velocity Structure in the Crust and Upper Mantle around Bohai Sea Area. Chinese Journal of Geophysics, 49(3): 698-706 (in Chinese with English abstract). doi: 10.1002/cjg2.884 Liang, J. T., Wang, H. L., Bai, Y., et al., 2016. Cenozoic Tectonic Evolution of the Bohai Bay Basin and Its Coupling Relationship with Pacific Plate Subduction. Journal of Asian Earth Sciences, 127: 257-266. https://doi.org/10.1016/j.jseaes.2016.06.012 Liang, W., Li, J. C., Xu, X. Y., et al., 2020. A High-Resolution Earth's Gravity Field Model SGG-UGM-2 from GOCE, GRACE, Satellite Altimetry, and EGM2008. Engineering, 6(8): 860-878. https://doi.org/10.1016/j.eng.2020.05.008. Lu, Z. X., Jiang, X. Q., Bai, Y., et al., 1999. Structural Characteristics of Crust and Upper Mantle and Inhomogeneity of the Medium in Jiaoliao and Bohai Regions. North China Earthguake Sciences, 17(2): 43-51 (in Chinese with English abstract). Maruyama, S., Isozaki, Y., Kimura, G., et al., 1997. Paleogeographic Maps of the Japanese Islands: Plate Tectonic Synthesis from 750 Ma to the Present. Island Arc, 6(1): 121-142. https://doi.org/10.1111/j.1440-1738.1997.tb00043.x Mi, L. J., Zhang, G. C., Liu, Z. F., et al., 2023. Discussion on the Development Mechanism of Lacustrine High-Quality Source Rocks in Oil-Rich Sags in Offshore China. Acta Petrolei Sinica, 44(3): 405-419, 509 (in Chinese with English abstract). Shao, X. Z., Zhang, J. R., Yin, X. H., 1999. Oilgas Exploration and Study of Deep Crustal Structure. Petroleum Exploration and Development, 26(2): 11-14 (in Chinese with English abstract). Suo, Y. H., Li, S. Z., Yu, S., et al., 2014. Cenozoic Tectonic Jumping and Implications for Hydrocarbon Accumulation in Basins in the East Asia Continental Margin. Journal of Asian Earth Sciences, 88: 28-40. https://doi.org/10.1016/j.jseaes.2014.02.019 Teng, J. W., Wang, Q. S., Liu, Y. L., et al., 1983. The Characteristics of Geophysical Field and the Distribution and Formation of Oil-and Gas-Bearing Basin in Eastern China. Chinese Journal of Geophysics, 26(4): 319-330 (in Chinese with English abstract). Vasanthi, A., Santosh, M., 2021. Overview of Regional Gravity Field Computation Models and Application of a Novel Method in Imaging the Lithospheric Architecture and Destruction of the North China Craton. Earth-Science Reviews, 215: 103548. https://doi.org/10.1016/j.earscirev.2021.103548 Xia, Q. L., Xu, C. G., 2016. New Geological Understandings and Major Hydrocarbon Discoveries in the Complex Fault Zone of Bohai Sea. Acta Petrolei Sinica, 37(S1): 22-33 (in Chinese with English abstract). Xue, Y. A., Hu, A. W., Wan, L., et al., 2025. Accumulation Process and Phase Control Factors of Large Natural Gas Reservoirs in the Oil-Prone Bohai Bay Basin, East China. Earth Science, 50(2): 377-387 (in Chinese with English abstract). Xue, Y. A., Lyu, D. Y., Hu, Z. W., et al., 2021. Tectonic Development of Subtle Faults and Exploration in Mature Areas in Bohai Sea, East China. Petroleum Exploration and Development, 48(2): 269-285 (in Chinese with English abstract). doi: 10.1016/S1876-3804(21)60022-8 Xue, Y. A., Wang, F. L., Tang, G. M., et al., 2020. Geological Condition and Exploration Prospect of Shale Oil and Gas in the Bohai Sea. Oil & Gas Geology, 41(4): 696-709 (in Chinese with English abstract). Yang, K. J., Qi, J. F., Yu, Y. X., et al., 2016. Fault-Related Folds in Bohai Bay and Its Significance of Hydrocarbon Accumulation. Oil Geophysical Prospecting, 51(3): 625-636, 420 (in Chinese with English abstract). Yang, S. Y., Jiang, F. J., Wen, S. Y., 2024. Statistical Characteristics and Prediction Model of Oil and Gas Resource Abundance in Key Basins in China. China Petroleum Exploration, 29(3): 170-180 (in Chinese with English abstract). Ye, T., Niu, C. M., Wang, D. Y., et al., 2022. Mesozoic Tectonic Evolution of the Southwestern Bohai Sea and Its Dynamic Mechanism: Implications for the Destruction of the North China Craton. Earth Science Frontiers, 29(5): 133-146 (in Chinese with English abstract). Yu, B., Liu, J. L., Yang, G. L., et al., 2021. Hydrocarbon Generation Characteristics and Signification of Source Rock in Different Oil-Rich Depressions in the Eastern Part of the Bohai Sea. Bulletin of Geological Science and Technology, 40(4): 104-114, 130 (in Chinese with English abstract). Yuan, X. J., Qiao, H. S., 2002. Exploration of Subtle Reservoir in Prolific Depression of Bohai Bay Basin. Oil & Gas Geology, 23(2): 130-133 (in Chinese with English abstract). Zhang, F. F., Meng, X. J., Han, B., et al., 2019. Gravity-Magnetic Anomalies of Liaodong Bay and Their Tectonic Implications. Marine Geology & Quaternary Geology, 39(3): 104-112 (in Chinese with English abstract). Zhang, G. C., 2000. Tectonic Framework and Prolific Hydrocarbon Depressions in Bohai Bay. China Offshore Oil and Gas (Geology), 14(2): 93-99 (in Chinese with English abstract). Zhang, G. C., Liang, J. S., Xu, J. Y., et al., 2013. An Evaluation Method of Potential Hydrocarbon-Rich Sags and Their Source Rock Identification Offshore China. China Offshore Oil and Gas, 25(1): 13-19, 102 (in Chinese with English abstract). Zhang, G. C., Tong, D. J., Chen, K., et al., 2024. Tectonic Evolution and Source Rocks Development of the Super Oil-Rich Bohai Bay Basin, East China. Petroleum Exploration and Development, 51(5): 1165-1182 (in Chinese with English abstract). doi: 10.1016/S1876-3804(25)60533-7 Zhang, W. Z., 1997. Major Nonmarine Oilfields of China. Petroleum Industry Press, Beijing (in Chinese). Zhang, Y. M., Wang, W. Y., Li, L. Z., et al., 2023. Influence of the Moho Surface Distribution on the Oil and Gas Basins in China Seas and Adjacent Areas. Acta Oceanologica Sinica, 42(3): 167-188. https://doi.org/10.1007/s13131-022-2136-8 Zhu, R. X., Xu, Y. G., Zhu, G., et al., 2012. Destruction of the North China Craton. Science China Earth Sciences, 55(10): 1565-1587 (in Chinese). doi: 10.1007/s11430-012-4516-y Zhu, W. L., Mi, L. J., Gong, Z. S., et al., 2009. Oil and Gas Reservoir Formation and Exploration in the Bohai Sea Region. Science Press, Beijing (in Chinese). 蔡梦轲, 王万银, 张义蜜, 等, 2025. 渤海湾盆地断裂与莫霍面对油气富集海陆差异性的影响. 地质学报, 99(5): 1554-1575. 陈光希, 张明华, 张盛, 2019. 约束变密度界面反演法在渤海深部结构研究中的应用. 地球物理学进展, 34(6): 2406-2413. 胡志伟, 徐长贵, 王德英, 等, 2019. 渤海海域走滑断裂叠合特征与成因机制. 石油勘探与开发, 46(2): 254-267. 李晨, 陈世悦, 蒲秀刚, 等, 2024. 渤海湾盆地中生代地层划分与对比. 地球科学, 49(3): 1119-1143. doi: 10.3799/dqkx.2022.220 李三忠, 索艳慧, 戴黎明, 等, 2010. 渤海湾盆地形成与华北克拉通破坏. 地学前缘, 17(4): 64-89. 李祖辉, 郑彦鹏, 支鹏遥, 等, 2015. 渤海东南部深地震探测与地壳结构研究新进展: OBS2013剖面数据处理分析. 地球物理学进展, 30(3): 1402-1409. 李志伟, 胥颐, 郝天珧, 等, 2006. 环渤海地区的地震层析成像与地壳上地幔结构. 地球物理学报, 49(3): 797-804. 卢造勋, 蒋秀琴, 白云, 等, 1999. 胶辽渤海地区地壳上地幔结构特征与介质的横向非均匀性. 华北地震科学, 17(2): 43-51. 米立军, 张功成, 刘志峰, 等, 2023. 中国近海富油凹陷湖相优质烃源岩发育机制. 石油学报, 44(3): 405-419, 509. 邵学钟, 张家茹, 殷秀华, 1999. 油气勘探与地壳深部构造研究. 石油勘探与开发, 26(2): 11-14. 滕吉文, 王谦身, 刘元龙, 等, 1983. 中国东部地区的地球物理场特征与含油气盆地的分布和形成. 地球物理学报, 26(4): 319-330. 夏庆龙, 徐长贵, 2016. 渤海海域复杂断裂带地质认识创新与油气重大发现. 石油学报, 37(S1): 22-33. 薛永安, 胡安文, 万琳, 等, 2025. 渤海湾油型盆地深层大型气藏成藏过程与相态控制因素. 地球科学, 50(2): 377-387. doi: 10.3799/dqkx.2024.013 薛永安, 吕丁友, 胡志伟, 等, 2021. 渤海海域隐性断层构造发育特征与成熟区勘探实践. 石油勘探与开发, 48(2): 233-246. 薛永安, 王飞龙, 汤国民, 等, 2020. 渤海海域页岩油气地质条件与勘探前景. 石油与天然气地质, 41(4): 696-709. 杨克基, 漆家福, 余一欣, 等, 2016. 渤海湾地区断层相关褶皱及其油气地质意义. 石油地球物理勘探, 51(3): 625-636, 420. 杨舒越, 姜福杰, 温思远, 2024. 中国重点盆地油气资源丰度统计特征及预测模型建立. 中国石油勘探, 29(3): 170-180. 叶涛, 牛成民, 王德英, 等, 2022. 渤海西南海域中生代构造演化、动力学机制及其对华北克拉通破坏的启示. 地学前缘, 29(5): 133-146. 于彪, 刘建良, 杨贵丽, 等, 2021. 渤海海域东部不同富油凹陷烃源岩生烃特征差异及意义. 地质科技通报, 40(4): 104-114, 130. 袁选俊, 谯汉生, 2002. 渤海湾盆地富油气凹陷隐蔽油气藏勘探. 石油与天然气地质, 23(2): 130-133. 张菲菲, 孟祥君, 韩波, 等, 2019. 辽东湾地区重、磁异常特征及其区域构造分析. 海洋地质与第四纪地质, 39(3): 104-112. 张功成, 2000. 渤海海域构造格局与富生烃凹陷分布. 中国海上油气地质, 12(2): 93-99. 张功成, 梁建设, 徐建永, 等, 2013. 中国近海潜在富烃凹陷评价方法与烃源岩识别. 中国海上油气, 25(1): 13-19, 102. 张功成, 佟殿君, 陈凯, 等, 2024. 渤海湾超级油盆构造演化及其烃源岩发育. 石油勘探与开发, 51(5): 1008-1023. 张文昭, 1997. 中国陆相大油田. 北京: 石油工业出版社. 朱日祥, 徐义刚, 朱光, 等, 2012. 华北克拉通破坏. 中国科学: 地球科学, 42(8): 1135-1159. 朱伟林, 米立军, 龚再升, 等, 2009. 渤海海域油气成藏与勘探. 北京: 科学出版社. -
