Formation and Evolution Process of Baoyunting Granite Buried Hill in the East China Sea Basin: Constraints from Zircon U-Pb Isotopic Geochronology and Petrogeochemistry
-
摘要: 目前对于东海盆地宝云亭地区已钻遇花岗岩的形成时代、岩石成分、成因机制及其潜山演化历史仍缺乏深入的认识.通过宝云亭潜山两口关键探井中钻遇的花岗岩开展锆石U-Pb年代学与岩石地球化学的综合研究，确定宝云亭花岗岩的成因及其深部地球动力学背景，进而揭示宝云亭花岗岩潜山形成与演化过程.锆石LA-ICP-MS U-Pb同位素测年结果揭示，宝云亭潜山花岗岩的结晶年龄为106.9~108.8 Ma，花岗岩上部火山碎屑岩的形成时代为35.9~41.3 Ma.宝云亭花岗岩体主要由花岗岩和花岗闪长岩组成，总体具有与高Sr/Y花岗岩或者埃达克质岩石类似的成分特征.综合岩石学和地球化学研究数据，可以确定宝云亭花岗岩的成因应该与早白垩世时期增厚下地壳范围内玄武质岩石的部分熔融有关.综合本文及区域上已有的多学科研究成果，可以判断宝云亭花岗岩体应该形成于早白垩世末期古太平洋板块俯冲回撤的构造背景中，并且东海盆地宝云亭花岗岩潜山的形成与演化至少经历了岩体形成期、岩体隆升与剥蚀期、岩体沉降期三个不同阶段.Abstract: Current understanding remains limited regarding the formation age, petrological composition, genetic mechanisms, and tectonic evolution of the granite encountered in the Baoyunting buried hill within the East China Sea basin. This study presents an integrated zircon U-Pb geochronological and petrogeochemical investigation on granites from two key exploration wells in the Baoyunting area. The objectives are to determine the petrogenesis and deep-seated geodynamic setting of these granites, and to further unravel their formation and evolution processes. Zircon LA-ICP-MS U-Pb dating reveals crystallization ages of 106.9-108.8 Ma for the Baoyunting granites, while the overlying pyroclastic rocks yield younger ages of 35.9-41.3 Ma. The granitic pluton primarily comprises granite and granodiorite, exhibiting geochemical affinities to high-Sr/Y granites or adakitic rocks. Combined petrological and geochemical evidence suggests that the Baoyunting granites originated from partial melting of basaltic rocks within a thickened lower crust during the Early Cretaceous. Integrating the results with regional multidisciplinary data, it proposes that these granites formed in a tectonic setting associated with the Paleo-Pacific Plate slab rollback during the late Early Cretaceous. The evolution of the Baoyunting granite buried hill involved three distinct stages: (1) pluton emplacement, (2) uplift-denudation, and (3) subsidence.
-
Key words:
- granite buried hill /
- zircon U-Pb geochronology /
- petrogenesis /
- Baoyunting /
- East China Sea basin /
- geochemistry
-
图 1 东海盆地构造单元(a)、西湖凹陷构造单元(b)、宝云亭潜山地震剖面(c)及其示意图(d)
Fig. 1. Tectonic map of the East China Sea basin (a), tectonic map of the Xihu sag (b), seismic profile across the Baoyunting buried hill (c), and its schematic diagram (d)
图 2 宝云亭花岗岩潜山已钻遇火山岩和花岗岩手标本和显微镜下照片
a.A2井钻遇的花岗岩手标本照片；b.A7井钻遇的上覆火山岩层，火山岩层中可见花岗岩角砾；c.A2井花岗岩的正交偏光镜下照片；d.A2井花岗岩的正交偏光镜下照片；e.已钻遇火山岩的正交偏光镜下照片；f.花岗岩角砾的正交偏光镜下照片；Af.碱性长石；Bt.黑云母；Pl.斜长石；Qz.石英
Fig. 2. Hand specimens and photomicrographs of volcanic rocks and granites drilled in the Baoyunting granite buried hill
图 3 宝云亭潜山A2和A7井中钻遇花岗岩与凝灰岩的锆石U-Pb年龄谐和图以及代表性锆石颗粒CL图像
Fig. 3. Zircon U-Pb concordia diagrams for the granite and tuff encountered in Wells A2 and A7 of the Baoyunting buried hill, and cathodoluminescence (CL) images of representative zircon grains
图 4 宝云亭潜山中岩石样品的(Na2O+K2O)-SiO2(a)、K2O-SiO2(b)、A/NK-A/CNK(c)、Sr/Y-Y图解(d)
a.底图据Middlemost（1994）；b.底图据Peccerillo and Taylor（1976）；c.底图据Maniar and Piccoli（1989）；d.底图据Castillo（2012）
Fig. 4. (Na2O + K2O)-SiO2 (a), K2O-SiO2 (b), A/NK-A/CNK (c), and Sr/Y-Y (d) diagrams for rock samples from the Baoyunting buried hill
图 5 宝云亭潜山中岩石样品的稀土元素球粒陨石标准化分布（a）和微量元素原始地幔标准化蛛网图（b）
球粒陨石标准化值据Taylor and McLennan（1985）；原始地幔标准化值据Sun and McDonough（1989）
Fig. 5. Chondrite-normalized rare earth element (REE) distribution pattern (a) and primitive mantle-normalized trace element spider diagram (b) for rock samples from the Baoyunting buried hill
图 6 宝云亭花岗岩样品的锆石εHf(t)-年龄（Ma）协变图
东海盆地已钻遇的侏罗纪花岗岩（MYF-1井）Hf同位素数据据Yuan et al.（2018）；华夏地块古元古代地壳演化与中元古代地壳演化趋势及其范围据贺振宇等（2015）
Fig. 6. Zircon εHf(t) vs. age (Ma) covariation diagram for granite samples from the Baoyunting buried hill
图 7 宝云亭潜山岩样品molar K2O/Na2O-molar Ca/(MgO+FeOt) (a)、molar K2O/Na2O-ASI (b)、MgO-SiO2 (c)和Mg#- SiO2(d)图解
a.底图据Kaygusuz et al.（2008）；b.底图据Pearce et al.（1984）；c.底图据Wang et al.（2005）；d.底图据Rapp et al.（1999）
Fig. 7. Molar K2O/Na2O vs. molar Ca/(MgO+FeOₜ) (a), molar K2O/Na2O vs. ASI (b), MgO vs. SiO2 (c), and Mg# vs. SiO2 (d) diagrams for rock samples from the Baoyunting buried hill
-
Arculus, R. J., Lapierre, H., Jaillard, E., 1999. Geochemical Window into Subduction and Accretion Processes: Raspas Metamorphic Complex, Ecuador. Geology, 27(6): 547. https://doi.org/10.1130/0091-7613(1999)027<0547:GWISAA>2.3.CO;2 doi: 10.1130/0091-7613(1999)027<0547:GWISAA>2.3.CO;2 Castillo, P. R., 2012. Adakite Petrogenesis. Lithos, 134: 304-316. https://doi.org/10.1016/j.lithos.2011.09.013 Chapman, J. B., Ducea, M. N., DeCelles, P. G., et al., 2015. Tracking Changes in Crustal Thickness during Orogenic Evolution with Sr/Y: An Example from the North American Cordillera. Geology, 43(10): 919-922. https://doi.org/10.1130/G36996.1 Defant, M. J., Drummond, M. S., 1990. Derivation of Some Modern Arc Magmas by Melting of Young Subducted Lithosphere. Nature, 347(6294): 662-665. https://doi.org/10.1038/347662a0 Defant, M. J., Kepezhinskas, P., 2001. Evidence Suggests Slab Melting in Arc Magmas. EOS, Transactions American Geophysical Union, 82(6): 65-69. https://doi.org/10.1029/01EO00038 Guo, Z., Gao, S. L., Wang, J. Q., et al., 2015. U-Pb Dating of the Zircon from Cenozoic Basement Rock and Its Tectonic Significance in the Lishui Sag of the East China Sea Shelf Basin. Marine Science Bulletin, 34(6): 675-687 (in Chinese with English abstract). He, Z. Y., Sun, L. X., Mao, L. J., et al., 2015. Zircon U-Pb and Hf Isotopic Study of Gneiss and Granodiorite from the Southern Beishan Orogenic Collage: Mesoproterozoic Magmatism and Crustal Growth. Chinese Science Bulletin, 60(4): 389-399 (in Chinese). doi: 10.1360/N972014-00898 Hu, F. Y., Ducea, M. N., Liu, S. W., et al., 2017. Quantifying Crustal Thickness in Continental Collisional Belts: Global Perspective and a Geologic Application. Scientific Reports, 7: 7058. https://doi.org/10.1038/s41598-017-07849-7 Huang, X. S., Zhang, T., Tang, X. J., et al., 2024. Biostratigraphic Division, Sedimentary Environment and Paleoclimate of Pinghu Formation and Huagang Formation in Central Anticline Belt, Xihu Sag, East China Sea Basin. Journal of Stratigraphy, 48(4): 440-452 (in Chinese with English abstract). Kaygusuz, A., Siebel, W., Şen, C., et al., 2008. Petrochemistry and Petrology of I-Type Granitoids in an Arc Setting: The Composite Torul Pluton, Eastern Pontides, NE Turkey. International Journal of Earth Sciences, 97(4): 739-764. https://doi.org/10.1007/s00531-007-0188-9 Li, L. Z., Guo, G., Qi, P., et al., 2023. Prediction of Favorable Reservoir in Granite Weathering-Crust Buried-Hill Type-A Case Study of the Baoyunting Area on Pinghu Slope. Marine Geology & Quaternary Geology, 43(2): 160-169 (in Chinese with English abstract). Li, S. Z., Cao, X. Z., Wang, G. Z., et al., 2019. Meso- Cenozoic Tectonic Evolution and Plate Reconstruction of the Pacific Plate. Journal of Geomechanics, 25(5): 642-677 (in Chinese with English abstract). Li, S. Z., Suo, Y. H., Li, X. Y., et al., 2019. Mesozoic Tectono-Magmatic Response in the East Asian Ocean-Continent Connection Zone to Subduction of the Paleo-Pacific Plate. Earth-Science Reviews, 192: 91-137. https://doi.org/10.1016/j.earscirev.2019.03.003 Li, W., Liu, Y. Q., Dong, Y. P., et al., 2013. The Geochemical Characteristics, Geochronology and Tectonic Significance of the Carboniferous Volcanic Rocks of the Santanghu Area in Northeastern Xinjiang, China. Science China Earth Sciences, 56(8): 1318-1333. https://doi.org/10.1007/s11430-012-4483-3 Liu, B., Wu, L., Ma, C. Q., et al., 2025. Volcanic- Intrusive Connections and Crystal-Melt Segregation in the Dulan Tilted Crustal Section: Insights from Accessory Mineral Evolution. Chemical Geology, 672: 122517. https://doi.org/10.1016/j.chemgeo.2024.122517 Liu, B., Xu, Y., Ma, C. Q., et al., 2023. Petrogenesis and Geodynamic Setting of the Ningduo Peraluminous Granites from the North Qiangtang Terrane. Earth Science, 48(9): 3296-3311 (in Chinese with English abstract). Liu, J. S., Xu, H. Z., Jiang, Y. M., et al., 2020. Mesozoic and Cenozoic Basin Structure and Tectonic Evolution in the East China Sea Basin. Acta Geologica Sinica, 94(3): 675-691 (in Chinese with English abstract). Liu, Y. S., Hu, Z. C., Zong, K. Q., et al., 2010. Reappraisement and Refinement of Zircon U-Pb Isotope and Trace Element Analyses by LA-ICP-MS. Chinese Science Bulletin, 55(15): 1535-1546. https://doi.org/10.1007/s11434-010-3052-4 Liu, Y. S., Zong, K. Q., Kelemen, P. B., et al., 2008. Geochemistry and Magmatic History of Eclogites and Ultramafic Rocks from the Chinese Continental Scientific Drill Hole: Subduction and Ultrahigh-Pressure Metamorphism of Lower Crustal Cumulates. Chemical Geology, 247(1-2): 133-153. https://doi.org/10.1016/j.chemgeo.2007.10.016 MacPherson, C. G., Dreher, S. T., Thirlwall, M. F., 2006. Adakites without Slab Melting: High Pressure Differentiation of Island Arc Magma, Mindanao, the Philippines. Earth and Planetary Science Letters, 243(3/4): 581-593. https://doi.org/10.1016/j.epsl.2005.12.034 Maniar, P. D., Piccoli, P. M., 1989. Tectonic Discrimination of Granitoids. Geological Society of America Bulletin, 101(5): 635-643. https://doi.org/10.1130/0016-7606(1989)101<0635:TDOG>2.3.CO;2 doi: 10.1130/0016-7606(1989)101<0635:TDOG>2.3.CO;2 Middlemost, E. A. K., 1994. Naming Materials in the Magma/Igneous Rock System. Earth-Science Reviews, 37(3-4): 215-224. https://doi.org/10.1016/0012-8252(94)90029-9 Miller, C. F., McDowell, S. M., Mapes, R. W., 2003. Hot and Cold Granites Implications of Zircon Saturation Temperatures and Preservation of Inheritance. Geology, 31(6): 529. https://doi.org/10.1130/0091-7613(2003)031<0529:HACGIO>2.0.CO;2 doi: 10.1130/0091-7613(2003)031<0529:HACGIO>2.0.CO;2 Moreira, H., Buzenchi, A., Hawkesworth, C. J., et al., 2023. Plumbing the Depths of Magma Crystallization Using 176Lu/177Hf in Zircon as a Pressure Proxy. Geology, 51(3): 233-237. https://doi.org/10.1130/G50659.1 Müller, R. D., Seton, M., Zahirovic, S., et al., 2016. Ocean Basin Evolution and Global-Scale Plate Reorganization Events since Pangea Breakup. Annual Review of Earth and Planetary Sciences, 44: 107-138. https://doi.org/10.1146/annurev-earth-060115-012211 Pearce, J. A., Harris, N. B. W., Tindle, A. G., 1984. Trace Element Discrimination Diagrams for the Tectonic Interpretation of Granitic Rocks. Journal of Petrology, 25(4): 956-983. https://doi.org/10.1093/petrology/25.4.956 Peccerillo, A., Taylor, S. R., 1976. Geochemistry of Eocene Calc-Alkaline Volcanic Rocks from the Kastamonu Area, Northern Turkey. Contributions to Mineralogy and Petrology, 58(1): 63-81. https://doi.org/10.1007/BF00384745 Profeta, L., Ducea, M. N., Chapman, J. B., et al., 2016. Quantifying Crustal Thickness over Time in Magmatic Arcs. Scientific Reports, 5: 17786. https://doi.org/10.1038/srep17786 Rapp, R. P., Shimizu, N., Norman, M. D., et al., 1999. Reaction between Slab-Derived Melts and Peridotite in the Mantle Wedge: Experimental Constraints at 3.8 GPa. Chemical Geology, 160(4): 335-356. https://doi.org/10.1016/S0009-2541(99)00106-0 Streck, M. J., Leeman, W. P., Chesley, J., 2007. High-Magnesian Andesite from Mount Shasta: A Product of Magma Mixing and Contamination, not a Primitive Mantle Melt. Geology, 35(4): 351. https://doi.org/10.1130/G23286A.1 Sun, S. S., McDonough, W. F., 1989. Chemical and Isotopic Systematics of Oceanic Basalts: Implications for Mantle Composition and Processes. Geological Society, London, Special Publications, 42(1): 313-345. https://doi.org/10.1144/gsl.sp.1989.042.01.19 Taylor, S. R., McLennan, S. M., 1985. The Continental Crust: Its Composition and Evolution. Blackwell Scientific Publications, Oxford, 312. https://doi.org/10.1017/S0016756800032167 Valer'evna, D., Wang, P. C., Li, S. Z., et al., 2017. Meso-Cenozoic Evolution of Earth Surface System under the East Asian Tectonic Superconvergence. Marine Geology & Quaternary Geology, 37(4): 33-64. Wang, Y. J., Fan, W. M., Peng, T. P., et al., 2005. Elemental and Sr-Nd Isotopic Systematics of the Early Mesozoic Volcanic Sequence in Southern Jiangxi Province, South China: Petrogenesis and Tectonic Implications. International Journal of Earth Sciences, 94(1): 53-65. https://doi.org/10.1007/s00531-004-0441-4 Watson, E. B., Harrison, T. M., 1983. Zircon Saturation Revisited: Temperature and Composition Effects in a Variety of Crustal Magma Types. Earth and Planetary Science Letters, 64(2): 295-304. https://doi.org/10.1016/0012-821X(83)90211-X Xie, Y. H., Gao, Y. D., 2020. Recent Domestic Exploration Progress and Direction of CNOOC. China Petroleum Exploration, 25(1): 20-30 (in Chinese with English abstract). Xu, C. G., Yang, H. F., Xu, W., et al., 2025. New Fields and Resource Potential of Tight Oil and Gas and Shale Oil Exploration in the Bohai Sea Area. Acta Petrolei Sinica, 46(1): 173-190, 264 (in Chinese with English abstract). Xu, C. H., Zhang, L., Shi, H. S., et al., 2017. Tracing an Early Jurassic Magmatic Arc from South to East China Seas: Early Jurassic Magmatic Arc in SE China. Tectonics, 36(3): 466-492. https://doi.org/10.1002/2016tc004446 Yogodzinski, G. M., Kelemen, P. B., 1998. Slab Melting in the Aleutians: Implications of an Ion Probe Study of Clinopyroxene in Primitive Adakite and Basalt. Earth and Planetary Science Letters, 158(1/2): 53-65. https://doi.org/10.1016/S0012-821X(98)00041-7 Yuan, W., Yang, Z. Y., Zhao, X. X., et al., 2018. Early Jurassic Granitoids from Deep Drill Holes in the East China Sea Basin: Implications for the Initiation of Palaeo-Pacific Tectono-Magmatic Cycle. International Geology Review, 60(7): 813-824. https://doi.org/10.1080/00206814.2017.1351312 Zhang, G. H., Zhang, J. P., 2015. A Discussion on the Tectonic Inversion and Its Genetic Mechanism in the East China Sea Shelf Basin. Earth Science Frontiers, 22(1): 260-270 (in Chinese with English abstract). Zhou, X. H., Gao, S. L., Gao, W. Z., et al., 2019. Formation and Distribution of Marine-Continental Transitional Lithologic Reservoirs in Pingbei Slope Belt, Xihu Sag, East China Sea Shelf Basin. China Petroleum Exploration, 24(2): 153-164 (in Chinese with English abstract). Zhu, W. L., Zhong, K., Fu, X. W., et al., 2019. The Formation and Evolution of the East China Sea Shelf Basin: A New View. Earth-Science Reviews, 190: 89-111. https://doi.org/10.1016/j.earscirev.2018.12.009 郭真, 高顺莉, 王建强, 等, 2015. 东海丽水凹陷新生代基底岩体锆石U-Pb年龄及其构造意义. 海洋通报, 34(6): 675-687. 贺振宇, 孙立新, 毛玲娟, 等, 2015. 北山造山带南部片麻岩和花岗闪长岩的锆石U-Pb定年和Hf同位素: 中元古代的岩浆作用与地壳生长. 科学通报, 60(4): 389-399. 黄晓松, 张涛, 唐贤君, 等, 2024. 东海盆地西湖凹陷中央背斜带平湖组、花港组生物地层厘定及其沉积环境、古气候探讨. 地层学杂志, 48(4): 440-452. 李林致, 郭刚, 祁鹏, 等, 2023. 风化壳型花岗岩潜山有效储层预测: 以平湖斜坡宝云亭地区为例. 海洋地质与第四纪地质, 43(2): 160-169. 李三忠, 曹现志, 王光增, 等, 2019. 太平洋板块中‒新生代构造演化及板块重建. 地质力学学报, 25(5): 642-677. 刘彬, 徐雨, 马昌前, 等, 2023. 北羌塘宁多地区三叠纪过铝质花岗岩的成因及其地球动力学背景. 地球科学, 48(9): 3296-3311. doi: 10.3799/dqkx.2022.191 刘金水, 许怀智, 蒋一鸣, 等, 2020. 东海盆地中、新生代盆架结构与构造演化. 地质学报, 94(3): 675-691. 谢玉洪, 高阳东, 2020. 中国海油近期国内勘探进展与勘探方向. 中国石油勘探, 25(1): 20-30. 徐长贵, 杨海风, 徐伟, 等, 2025. 渤海海域致密油气及页岩油勘探新领域及资源潜力. 石油学报, 46(1): 173-190, 264. 张国华, 张建培, 2015. 东海陆架盆地构造反转特征及成因机制探讨. 地学前缘, 22(1): 260-270. 周心怀, 高顺莉, 高伟中, 等, 2019. 东海陆架盆地西湖凹陷平北斜坡带海陆过渡型岩性油气藏形成与分布预测. 中国石油勘探, 24(2): 153-164. -
