Influence of Porous Aquifer Heterogeneity on Contaminant Transport, Transformation and Remediation
-
摘要: 孔隙含水层非均质性是制约污染场地地下水修复的核心因素.阐述了结构与氧化还原两种非均质性的概念，深入分析了两种非均质性对污染物和修复剂迁移转化的影响机制.结构非均质主要影响污染物迁移和修复剂传输扩散过程，含水介质渗透性差异通常导致低渗区成为修复剂难以入渗的修复盲区，在修复后期因反向扩散出现污染物浓度反弹.以氧化还原容量差异表征的氧化还原非均质性，主要通过参与电子转移过程影响污染物转化和修复剂消耗，因此选择修复技术和设计参数时需特别考虑氧化还原容量的影响.最后针对非均质含水层修复中的关键挑战，在总结应对措施的基础上提出了未来的研究方向.Abstract: Porous aquifer heterogeneity is a fundamental factor constraining the efficiency of groundwater remediation at contaminated sites. This study clarified the concepts of structural heterogeneity and redox heterogeneity, and systematically analyzed the mechanisms of heterogeneity governing the transport and transformation of contaminants and remediation reagents.Structural heterogeneity primarily controls contaminant transport and the delivery and dispersion of remediation reagents. Permeability difference within aquifers commonly results in remediation blind zones in low-permeability regions as amendment penetration is limited. This may lead to contaminant rebound during the later stage of remediation due to back diffusion. Redox heterogeneity, characterized by spatial variations in redox capacity, mainly influenced contaminant transformation and remediation reagent consumption through its involvement in electron transfer processes. Consequently, the effects of redox capacity must be explicitly considered in the selection of remediation technologies and the design of operational parameters. Finally, key challenges associated with the remediation of heterogeneous aquifers are identified, and future research directions are proposed based on a synthesis of existing mitigation strategies.
-
Key words:
- aquifer heterogeneity /
- aquifer structure /
- redox reaction /
- contaminant /
- groundwater remediation /
- hydrogeology
-
图 1 含水层结构与氧化还原非均质性示意
Fig. 1. Schematic diagram of aquifer structure and redox heterogeneity
图 2 含水层结构非均质性对地下水流和污染物分配的影响
Fig. 2. Effect of aquifer heterogeneity on groundwater flow and contaminant distribution
图 3 含水层主要氧化还原电对和污染物的电位范围
Fig. 3. Redox potential ranges of dominant redox couples in aquifer
图 4 场地含水层非均质对污染物自然衰减(a)和原位修复(b)的影响
Fig. 4. Influence of aquifer heterogeneity on contaminant natural attenuation (a) and in-situ remediation (b) at field site
表 1 非均质含水层修复措施的建议
Table 1. Recommendations for heterogenous aquifer remediation measures
修复阶段 结构非均质 氧化还原非均质 场地调查 地质调查 联用钻孔、物探等技术，提高岩性界面的表征精度 结合钻孔和地下水样品的氧化还原性质、结构非均质表征结果，预测与增加含水层氧化还原非均质性的刻画 污染物调查 增加低渗区污染物富集量与释放周期的评估 增加氧化还原非均质性对污染物自然衰减过程中时空演化影响的定量识别 场地修复技术 清挖、高压旋喷增渗；
阻隔/控制污染源，强化自然衰减、原位化学/生物修复高还原容量区域对应还原型修复技术，反之选择氧化型修复技术；
增加高氧化/还原容量的修复剂注入量与注入频次修复效果评估 监测低渗区中污染物浓度
下载: 导出CSV
-
Aeppli, M., Babey, T., Engel, M., et al., 2022. Export of Organic Carbon from Reduced Fine-Grained Zones Governs Biogeochemical Reactivity in a Simulated Aquifer. Environmental Science Technology, 56(4): 2738-2746. https://doi.org/10.1021/acs.est.1c04664 Ahmad, M., Teel, A. L., Watts, R. J., 2013. Mechanism of Persulfate Activation by Phenols. Environmental Science Technology, 47(11): 5864-5871. https://doi.org/10.1021/es400728c Apte, A., Tare, V., Bose, P., 2006. Extent of Oxidation of Cr(Ⅲ) to Cr(Ⅵ) under Various Conditions Pertaining to Natural Environment. Journal of Hazardous Materials, 128(2-3): 16-174. https://doi.org/10.1016/j.jhazmat.2005.07.057 Aranguren-Díaz, Y., Galán-Freyle, N. J., Guerra, A., et al., 2024. Aquifers and Groundwater: Challenges and Opportunities in Water Resource Management in Colombia. Water, 16(5): 685. https://doi.org/10.3390/w16050685 Ayral-Cinar, D., Demond, A. H., 2017. Effective Diffusion Coefficients of DNAPL Waste Components in Saturated Low Permeability Soil Materials. Journal of Contaminant Hydrology, 207: 1-7. https://doi.org/10.1016/j.jconhyd.2017.09.008 Bakker, M., Bot, B., 2025. The Effective Vertical Anisotropy of Layered Aquifers. Groundwater, 63(1): 68-75. https://doi.org/10.1111/gwat.13432 Bolhari, A., Sale, T., 2023. Processes Governing Treatment of Contaminants in Low Permeability Zones. Science of the Total Environment, 879: 163010. https://doi.org/10.1016/j.scitotenv.2023.163010 Cherry, J. A., Freeze, R. A., 1979. Groundwater. Prentice Hall, Englewood Cliffs, New Jersey, 30-31. Dagan, G., 1982. Stochastic Modeling of Groundwater Flow by Unconditional and Conditional Probabilities: 1. Conditional Simulation and the Direct Problem. Water Resources Research, 18(4): 813-833. https://doi.org/10.1029/WR018i004p00813 Davis, E., 2023. In Situ Thermal Remediation. United States Environmental Protection Agency, Washington, D.C., 3-15. Dong, H. Y., Xu, Q. H., Lian, L. S., et al., 2021. Degradation of Organic Contaminants in the Fe(Ⅱ)/Peroxymonosulfate Process under Acidic Conditions: The Overlooked Rapid Oxidation Stage. Environmental Science Technology, 55(22): 15390-15399. https://doi.org/10.1021/acs.est.1c04563 EPA, U., 1994. How to Evaluate Alternative Cleanup Technologies for Underground Storage Tank Sites: A Guide for Corrective Action Plan Reviewers. Environmental Protection Agency, Washington, D.C., U.S.A., 14. Filippini, M., Parker, B. L., Dinelli, E., et al., 2020. Assessing Aquitard Integrity in a Complex Aquifer-Aquitard System Contaminated by Chlorinated Hydrocarbons. Water Research, 171: 115388. https://doi.org/10.1016/j.watres.2019.115388 Fjordbøge, A. S., Riis, C., Christensen, A. G., et al., 2012. ZVI-Clay Remediation of a Chlorinated Solvent Source Zone, Skuldelev, Denmark: 1. Site Description and Contaminant Source Mass Reduction. Journal of Contaminant Hydrology, 140-141: 56-66. https://doi.org/10.1016/j.jconhyd.2012.08.007 Guo, Z. L., Ma, R., Zhang, Y., et al., 2021. Contaminant Transport in Heterogeneous Aquifers: A Critical Review of Mechanisms and Numerical Methods of Non-Fickian Dispersion. Science China: Earth Sciences, 51(11): 1817-1836 (in Chinese). Henry, B., 2010. Loading Rates and Impacts of Substrate Delivery for Enhanced Anaerobic Bioremediation. Environmental Security Technology Certification Program, Arlington, Virginia, 41. Herfort, M., 2000. Reactive Transport of Organic Compounds within a Heterogeneous Porous Aquifer. Institut und Museum für Geologie und Paläontologie der Universität Tübingen. Hoving, A. L., Sander, M., Bruggeman, C., et al., 2017. Redox Properties of Clay-Rich Sediments as Assessed by Mediated Electrochemical Analysis: Separating Pyrite, Siderite and Structural Fe in Clay Minerals. Chemical Geology, 457: 149-161. https://doi.org/10.1016/j.chemgeo.2017.03.022 ITRC, 2007. In Situ Bioremediation of Chlorinated Ethene DNAPL Source Zones: Case Studies. Interstate Technology Regulatory Council (ITRC), Washington, D.C., U.S.A., 51. ITRC, 2011. Permeable Reactive Barrier: Technology Update. Interstate Technology Regulatory Council (ITRC), Washington, D.C., U.S.A., 99. Janot, N., Lezama Pacheco, J. S., Pham, D. Q., et al., 2015. Physico-Chemical Heterogeneity of Organic-Rich Sediments in the Rifle Aquifer, CO: Impact on Uranium Biogeochemistry. Environmental Science Technology, 50(1): 46-53. https://doi.org/10.1021/acs.est.5b03208 Jiang, L. Q., Sun, R. L., Liang, X., 2021. Predicting Groundwater Flow and Transport in Heterogeneous Aquifer Sandbox Using Different Parameter Estimation Methods. Earth Science, 46(11): 4150-4160 (in Chinese with English abstract). Joe-Wong, C., Brown, G. E. Jr, Maher, K., 2017. Kinetics and Products of Chromium(Ⅵ) Reduction by Iron(Ⅱ/Ⅲ)-Bearing Clay Minerals. Environmental Science Technology, 51(17): 9817-9825. https://doi.org/10.1021/acs.est.7b02934 Kessler, T. C., Comunian, A., Oriani, F., et al., 2013. Modeling Fine-Scale Geological Heterogeneity—Examples of Sand Lenses in Tills. Groundwater, 51(5): 692-705. https://doi.org/10.1111/j.1745-6584.2012.01015.x Kwon, S. C., Kim, J. Y., Yoon, S. M., et al., 2012. Treatment Characteristic of 1, 4-Dioxane by Ozone-Based Advanced Oxidation Processes. Journal of Industrial and Engineering Chemistry, 18(6): 1951-1955. https://doi.org/10.1016/j.jiec.2012.05.010 Li, F. L., Ni, P., Guo, H. M., et al., 2015. Characteristics of Aquifer Sediments in Songnen Plain and Their Influences on Distribution of Arsenic Occurrence Modes. Journal of Earth Sciences and Environment, 37(1): 101-110 (in Chinese with English abstract). Liu, R. X., Yang, X. R., Xie, J. Y., et al., 2021. Experimental Investigation on the Effects of Ethanol-Enhanced Steam Injection Remediation in Nitrobenzene-Contaminated Heterogeneous Aquifers. Applied Sciences, 11(24): 12029. https://doi.org/10.3390/app112412029 Lu, Y. X., Chen, R., Zhao, W. J., et al., 2025. Accurate and Simple Determination of Sediment Redox Capacity by a Modified Chemical Probe Method: Implications to Contaminant Remediation. Water Research, 284: 124014. https://doi.org/10.1016/j.watres.2025.124014 Ludwig, R. D., Su, C. M., Lee, T. R., et al., 2007. In Situ Chemical Reduction of Cr(Ⅵ) in Groundwater Using a Combination of Ferrous Sulfate and Sodium Dithionite: A Field Investigation. Environmental Science Technology, 41(15): 5299-5305. https://doi.org/10.1021/es070025z Martin, E. J., Mumford, K. G., Kueper, B. H., 2016. Electrical Resistance Heating of Clay Layers in Water-Saturated Sand. Groundwater Monitoring Remediation, 36(1): 54-61. https://doi.org/10.1111/gwmr.12146 Moyo, F., Tandlich, R., Wilhelmi, B., et al., 2014. Sorption of Hydrophobic Organic Compounds on Natural Sorbents and Organoclays from Aqueous and Non-Aqueous Solutions: A Mini-Review. International Journal of Environmental Research and Public Health, 11(5): 5020-5048. https://doi.org/10.3390/ijerph110505020. Muller, K. A., Johnson, C. D., Bagwell, C. E., et al., 2021. Methods for Delivery and Distribution of Amendments for Subsurface Remediation: A Critical Review. Groundwater Monitoring Remediation, 41(1): 46-75. https://doi.org/10.1111/gwmr.12418 Mumford, K. G., Martin, E. J., Kueper, B. H., 2021. Removal of Trichloroethene from Thin Clay Lenses by Electrical Resistance Heating: Laboratory Experiments and the Effects of Gas Saturation. Journal of Contaminant Hydrology, 243: 103892. https://doi.org/10.1016/j.jconhyd.2021.103892 Paul, L., Herrmann, S., Bender Koch, C., et al., 2013. Inhibition of Microbial Trichloroethylene Dechorination by Fe (Ⅲ) Reduction Depends on Fe Mineralogy: A Batch Study Using the Bioaugmentation Culture KB-1. Water Research, 47(7): 2543-2554. https://doi.org/10.1016/j.watres.2013.02.029 Rehfeldt, K. R., Boggs, J. M., Gelhar, L. W., 1992. Field Study of Dispersion in a Heterogeneous Aquifer: 3. Geostatistical Analysis of Hydraulic Conductivity. Water Resources Research, 28(12): 3309-3324. https://doi.org/10.1029/92WR01758 Riddle, A. D., Arihood, L. D., Naylor, S., et al., 2025. Hydrogeologic Mapping and Three-Dimensional Geologic Modeling of Glacial Deposits in a Multicounty Area of Southeastern Michigan, Northeastern Indiana, and Northwestern Ohio. 2025-5008. United States Geologic Survey, Reston, Virginia, U. S. A., 47. Roehl, K. E., Czurda, K., 1998. Diffusion and Solid Speciation of Cd and Pb in Clay Liners. Applied Clay Science, 12(5): 387-402. https://doi.org/10.1016/S0169-1317(97)00022-7 Salowsky, H., Schäfer, W., Schneider, A. L., et al., 2021. Beneficial Effects of Dynamic Groundwater Flow and Redox Conditions on Natural Attenuation of Mono-, Poly-, and NSO-Heterocyclic Hydrocarbons. Journal of Contaminant Hydrology, 243: 103883. https://doi.org/10.1016/j.jconhyd.2021.103883 Scheibe, T., Yabusaki, S., 1998. Scaling of Flow and Transport Behavior in Heterogeneous Groundwater Systems. Advances in Water Resources, 22(3): 223-238. https://doi.org/10.1016/S0309-1708(98)00014-1 Shi, C. W., Tong, M., Cai, Q. Z., et al., 2023. Electrokinetic-Enhanced Bioremediation of Trichloroethylene-Contaminated Low-Permeability Soils: Mechanistic Insight from Spatio-Temporal Variations of Indigenous Microbial Community and Biodehalogenation Activity. Environmental Science Technology, 57(12): 5046-5055. https://doi.org/10.1021/acs.est.3c00278 Starr, R. C., Cherry, J. A., 1994. In Situ Remediation of Contaminated Ground Water: The Funnel-and-Gate System. Groundwater, 32(3): 465-476. https://doi.org/10.1111/j.1745-6584.1994.tb00664.x Sudicky, E. A., 1986. A Natural Gradient Experiment on Solute Transport in a Sand Aquifer: Spatial Variability of Hydraulic Conductivity and Its Role in the Dispersion Process. Water Resources Research, 22(13): 2069-2082. https://doi.org/10.1029/WR22i013p02069 Tatti, F., Papini, M. P., Sappa, G., et al., 2018. Contaminant Back-Diffusion from Low-Permeability Layers as Affected by Groundwater Velocity: A Laboratory Investigation by Box Model and Image Analysis. Science of the Total Environment, 622-623: 164-171. https://doi.org/10.1016/j.scitotenv.2017.11.347 Wang, H., Cai, Q. Z., Cao, Z. X., et al., 2025. Interfacial Electron Transfer from Low-Permeability Lenses to Transmissive Zones Enhanced by Dissolved Iron. Water Research, 287: 124426. https://doi.org/10.1016/j.watres.2025.124426 Wang, H., Zhu, Y. H., Lu, Y. X., et al., 2024a. Reduction Capacity in the Transmissive Zones Fueled by the Embedded Low-Permeability Lenses: Implications for Contaminant Transformation in Heterogeneous Aquifers. Water Research, 260: 121955. https://doi.org/10.1016/j.watres.2024.121955 Wang, P., Li, J., An, P., et al., 2024b. Understanding the Dilemmas and Breakdown of the Reactive Migration Ofin Situgroundwater Injection Reagents from an Environmental Geology Perspective. Critical Reviews in Environmental Science and Technology, 54(9): 747-770. https://doi.org/10.1080/10643389.2023.2277649 Woessner, W. W., Poeter, E. P., 2020. Hydrogeologic Properties of Earth Materials and Principles of Groundwater Flow. The Groundwater Project, Guelph, Ontario, Canada, 58-62. https://doi.org/10.21083/978-1-7770541-2-0 Xiao, D. C., Brantley, S. L., Li, L., 2021. Vertical Connectivity Regulates Water Transit Time and Chemical Weathering at the Hillslope Scale. Water Resources Research, 57(8): e2020WR029207. https://doi.org/10.1029/2020WR029207 Xie, J. Y., Qin, X. M., Yang, X. R., et al., 2025. New Insights into the Remediation Agent Transport across the Interface and Contaminant Removal in Heterogeneous Aquifer with Lens. Journal of Environmental Chemical Engineering, 13(4): 117283. https://doi.org/10.1016/j.jece.2025.117283 Yuan, S. H., Zhang, P., Kang, X. Y., et al., 2024. Aquifer Heterogeneity and Contamination Remediation. Earth Science, 49(1): 375-378 (in Chinese with English abstract). Zhang, H. C., Weber, E. J., 2009. Elucidating the Role of Electron Shuttles in Reductive Transformations in Anaerobic Sediments. Environmental Science Technology, 43(4): 1042-1048. https://doi.org/10.1021/es8017072 Zhang, J., Liu, T. G., Dong, J. Q., et al., 2020. The Impact of Aquifer Layered Heterogeneity on Groundwater Flow System. Geology in China, 47(6): 1715-1725 (in Chinese with English abstract). Zhang, J., Lu, S. F., Li, J. Q., et al., 2017. Adsorption Properties of Hydrocarbons (n-Decane, Methyl Cyclohexane and Toluene) on Clay Minerals: An Experimental Study. Energies, 10(10): 1586. https://doi.org/10.3390/en10101586 Zhang, P., Chu, C. H., Bu, X. C., et al., 2025. Production and Significance of Reactive Oxygen Species in the Subsurface. Earth-Science Reviews, 270: 105230. https://doi.org/10.1016/j.earscirev.2025.105230 Zhang, Y. T., Tong, M., Lu, Y. X., et al., 2024. Directional Long-Distance Electron Transfer from Reduced to Oxidized Zones in the Subsurface. Nature Communications, 15: 6576. https://doi.org/10.1038/s41467-024-50974-x Zheng, Y. S., Lu, Y. X., Yuan, S. H., 2024. Contaminant Degradation by •OH during Sediment Oxygenation: Effect of Abundant Solid Matrix in Aquifer. Journal of Hazardous Materials, 465: 133322. https://doi.org/10.1016/j.jhazmat.2023.133322 郭芷琳, 马瑞, 张勇, 等, 2021. 地下水污染物在高度非均质介质中的迁移过程: 机理与数值模拟综述. 中国科学: 地球科学, 51(11): 1817-1836. 蒋立群, 孙蓉琳, 梁杏, 2021. 含水层非均质性不同刻画方法对地下水流和溶质运移预测的影响. 地球科学, 46(11): 4150-4160. 李付兰, 倪萍, 郭华明, 等, 2015. 松嫩平原含水层沉积物特征及其对砷赋存态分布的影响. 地球科学与环境学报, 37(1): 101-110. 袁松虎, 张鹏, 康学远, 等, 2024. 含水层非均质性与污染修复. 地球科学, 49(1): 375-378. 张俊, 刘天罡, 董佳秋, 等, 2020. 含水层层状非均质对地下水流系统的影响. 中国地质, 47(6): 1715-1725. -
