煤层气储层远井带应力动态变化定量表征

doi:10.3799/dqkx.2026.150

煤层气储层远井带应力动态变化定量表征

doi: 10.3799/dqkx.2026.150

1. 中国地质大学(武汉）资源学院, 湖北武汉 430074;
2. 新疆维吾尔自治区地质局煤田地质中心, 新疆乌鲁木齐 830099;
3. 中煤科工集团武汉设计研究院有限公司湖北武汉 430064;
4. 煤与煤层气共采全国重点实验室山西晋城 048000

基金项目:

国家自然科学基金项目(42072204)

山西省煤基低碳联合基金重点项目(U1910204)

煤与煤层气共采全国重点实验室开放基金项目(2024KF02)

新疆维吾尔自治区地质局科技创新团队项目(XJGBST202626)。

详细信息

作者简介:
李国庆(1980-),男,博士,副教授,主要从事非常规油气地质、矿井地质教学与科研。ORCID:0000-0002-3463-6715.E-mail:ligq@cug.edu.cn

中图分类号: P618、TE122
计量
- 文章访问数: 26
- HTML全文浏览量: 0
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-28
- 网络出版日期: 2026-06-29

A Preliminary Study on Quantitative Characterization of Stress Variation in the Far-Well Zone of Coalbed Methane Reservoirs

1. School of Earth Resources, China University of Geosciences(Wuhan), Wuhan 430074, China;
2. Coal Geology Center, Xinjiang Uygur Autonomous Region Bureau of Geology, Urumqi 830099, China;
3. Wuhan Design & Research Institute Co. Ltd. of China Coal Technology & Engineering Group, Wuhan 430064, China;
4. State Key Laboratory of Coal and CBM Co-Mining, Jincheng, Shanxi 048000, China

摘要

摘要: 应力是煤层气安全高效开发的关键影响因素之一，而目前针对煤层气储层应力大小、应力机制动态以及有效应力拐点定量表征的研究报道少见。应用弹性理论，基于单轴应变、垂向荷载不变假设，考虑甲烷解吸引起的弹性模量变化，建立远井带煤层气储层应力动态数学模型，推导水平有效主应力-储层压力曲线拐点处的储层压力解析解，探讨了远井带储层有效主应力大小及应力机制的变化规律。结果表明，远井带储层垂直有效主应力在排采过程中持续增加；水平有效主应力在排水阶段单调增加，在采气阶段先增加后减小；初始正断层应力机制始终保持不变，而初始走滑断层、初始逆断层应力机制分别有3种、6种可能的演化模式：(I排水阶段)走滑-(II产气阶段)走滑、走滑-(走滑-正)、(走滑-正)-正；逆-逆、逆-(逆-走滑)、逆-(逆-走滑-正)、(逆-走滑)-走滑、(逆-走滑)-(走滑-正)、(逆-走滑-正)-正。深部储层主应力差、渗透性随排采呈增大趋势；浅部逆断层应力机制储层可通过二次压裂改善其渗透性。研究认识可为储层稳定性分析、生产动态预测及开发方案优化提供借鉴。
- 煤层气 /
- 储层应力 /
- 应力机制 /
- 远井带 /
- 排采
Abstract: Stress is one of the key factors that influence the safe and efficient development of coalbed methane (CBM). However, there are currently limited reports on the variation of CBM reservoir stress magnitude and stress regime, and the quantitative characterization of the inflection point of effective stress. Applying elasticity theory, based on the assumption of uniaxial strain and considering the variations in elastic modulus caused by methane desorption, a mathematical model of stress variation of CBM reservoir far from the borehole was established, the analytical solution for reservoir pressure at the inflection point of the horizontal effective principal stress vs reservoir pressure curve was derived, and the variations in the magnitude and stress regime of the effective principal stress of reservoir far from a CBM well during reservoir pressure depletion were analyzed. The results indicate that, during reservoir pressure depletion, for the CBM reservoir where is affected by gas well drainage but not adjacent to the gas well, the vertical effective principal stress continues to rise; the horizontal effective principal stress rises monotonically during the dewatering only stage and first rises then declines during the gas production stage. During the reservoir pressure depletion, the initial normal faulting stress regime of the reservoir remains unchanged; there are three and six possible evolution modes for the initial strike-slip and reverse faulting stress regimes: from strike-slip (in the dewatering stage) to strike- slip (in the gas production stage), strike-slip-(strike-slip- normal), (strike slip-normal) to normal; reverse-reverse, reverse-(reverse-strike slip), reverse-(reverse-strike slip-normal), (reverse-strike slip)-strike slip, (reverse-strike slip) -(strike slip-normal), (reverse-strike slip-normal)-normal. For the deep CBM reservoir, with the depletion of reservoir, there is an increasing trend of principal stress difference and reservoir permeability; for the shallow reservoir in a reverse faulting stress regime, second hydraulic fracturing can be used to improve the reservoir permeability. The research outcomes can provide reference for reservoir stability analysis, production performance prediction, and development plan optimization.
- coalbed methane /
- reservoir stress /
- stress regime /
- far-well zone /
- drainage and production

HTML全文

参考文献(51)

[1]	Anderson, E. M.,1905. The Dynamics of Faulting. Transactions of the Edinburgh Geological Society,8:387-402.
[2]	Chang, C., Li, S., Tang, D.Z., et al.,2023. In-Situ Stress Calculation for Coal Reservoirs Based on Log Parameters: A Case Study of the Southern Yanchuan Block. Coal Geology and Exploration, 51(5):23-32 (in Chinese with English abstract).
[3]	Chen, S.D., Tang, D.Z., Tao, S., et al.,2017. In-Situ Stress Measurements and Stress Distribution Characteristics of Coal Reservoirs in Major Coalfields in China: Implication for Coalbed Methane (CBM) Development. International Journal of Coal Geology, 182:66-84.
[4]	Colmenares, L.B., Zoback, M.D.,2007. Hydraulic Fracturing and Wellbore Completion of Coalbed Methane Wells in the Powder River Basin, Wyoming: Implications for Water and Gas Production. AAPG Bulletin, 91(1):51-67.
[5]	Connell, L.D.,2009. Coupled Flow and Geomechanical Processes During Gas Production from Coal Seams. International Journal of Coal Geology, 79(1):18-28.
[6]	Espinoza, D.N., Pereira, J.M., Vandamm, M., et al.,2015. Desorption-Induced Shear Failure of Coal Bed Seams During Gas Depletion. International Journal of Coal Geology, 137:142-151.
[7]	Fan, L., Liu, S.,2018. Numerical Prediction of In-Situ Horizontal Stress Evolution in Coalbed Methane Reservoirs by Considering Both Poroelastic and Sorption Induced Strain Effects. International Journal of Rock Mechanics and Mining Sciences, 104:156-164.
[8]	Feng, R.M., Harpalani, S., Pandey, R.,2016. Laboratory Measurement of Stress-Dependent Coal Permeability using Pulse-Decay Technique and Flow Modeling with Gas Depletion. Fuel, 177:76-86.
[9]	Goulty, N. R.,2003. Reservoir Stress Path During Depletion of Norwegian Chalk Oilfields. Petroleum Geoscience, 9(3):233-241.
[10]	Guo, Y.B., Zhou, H.W., Rong, T.L., et al.,2018. Disturbance Characteristics of Deep Coal Mass Under the Mining Stress Path. Journal of China Coal Society,43(11):3072-3079. (in Chinese with English abstract).doi: 10.13225/j.cnki.jccs.2018.0207
[11]	Lu, M., Connell, L.D.,2016. Coal Failure During Primary and Enhanced Coalbed Methane Production - Theory and Approximate Analyses. International Journal of Coal Geology, 154-155:275-285.
[12]	Huang, F.S., Kang, Y.L., You, L.J., et al.,2017. Mechanisms and Control Methods of Depletion-Induced Shear Failure of Coalbed Seams. Journal of China Coal Society,42(7):1803-1810. (in Chinese with English abstract). doi: 10.13225/j.cnki.jccs.2016.1184.
[13]	Huang, J., Ghassemi, A.,2015. A Poroelastic Model for Evolution of Fractured Reservoirs During Gas Production. Journal of Petroleum Science and Engineering,135:626-644.
[14]	Jalili, S., Ahangari, K.,2017. Effects of Different Stress Regimes on Hydraulic Fracture Geometry: A Particle Flow Code Approach. Innovative Infrastructure Solutions,2(1): 1-6.
[15]	Ju, W., Jiang, B., Qin, Y., et al.,2020. Characteristics of Present-Day In-Situ Stress Field Under Multi-Seam Conditions: Implications for Coalbed Methane Development. Journal of China Coal Society,45(10):3492-3500 (in Chinese with English abstract).
[16]	Kang, H.P., Yi, B.D., Gao, F.Q., et al.,2019. Database and Characteristics of Underground In-Situ Stress Distribution in Chinese Coal Mines. Journal of China Coal Society, 44(1):23-33.
[17]	Li, G.Q., Yan, D.T., Zhuang, X.G., et al.,2019. Implications of the Pore Pressure and In-Situ Stress for the Coalbed Methane Exploration in the Southern Junggar Basin, China. Engineering Geology, 262:105305.
[18]	Liu, J.S., Ding, W.L., Gu, Y., et al.,2018. Methodology for Predicting Reservoir Breakdown Pressure and Fracture Opening Pressure in Low-Permeability Reservoirs Based on an In-Situ Stress Simulation. Engineering Geology, 246:222-232.
[19]	Meng, Z.P., Li, G.Q.,2013. Experimental Research on the Permeability of High-Rank Coal Under a Varying Stress and its Influencing Factors. Engineering Geology, 162:108-117.
[20]	Meng, Z.P., Tian, Y.D., Li, G.F.,2010. Characteristics of In-Situ Stress Field in Southern Qinshui Basin and Its Research Significance. Journal of China Coal Society, 35(6):975-981.
[21]	Meng, Z.P., Wang, Y.H., Zhang, K., et al.,2019. Analysis of Hydraulic Fracturing Cracks for Coal Reservoirs and In-Situ Stress Direction in Southern Qinshui Basin. Coal Science and Technology,47(10):216-222 (in Chinese with English abstract).
[22]	Moore,R.L., Loftin,D., Palmer,I.,2011. History Matching and Permeability Increases of Mature Coalbed Methane Wells in San Juan Basin.In: SPE Asia Pacific Oil and Gas Conference and Exhibition, Jakarta, Indonesia, 20-22 September 2011.Society of Petroleum Engineers, SPE 146931.
[23]	Palmer, I., Mansoori, J.,1998. How Permeability Depends on Stress and Pore Pressure in Coalbeds: A New Model. SPE Reservoir Evaluation and Engineering, 1(6): 539-544.
[24]	Pan, Z., Connell, L.D.,2011. Modelling of Anisotropic Coal Swelling and its Impact on Permeability Behaviour for Primary and Enhanced Coalbed Methane Recovery. International Journal of Coal Geology, 85:257-267.
[25]	Sampath K.H.S.M., Perera, M.S.A., Ranjith, P.G., et al.,2019. CO2Interaction Induced Mechanical Characteristics Alterations in Coal: A Review. International Journal of Coal Geology, 204:113-129.
[26]	Segall, P., Fitzgerald, S.D.,1998. A Note on Induced Stress Changes in Hydrocarbon and Geothermal Reservoirs. Tectonophysics, 289(1-3):117-128.
[27]	Shi, J. Q., Durucan, S.,2005. A Model for Changes in Coalbed Permeability During Primary and Enhanced Methane Recovery. SPE Reservoir Evaluation and Engineering, 8(4):291-299.
[28]	Tadayoni, M., Khalilbeyg, M., Bin, J.R.,2022. Fault and Fracture Reactivation Analysis by 4D Geomechanical Integrated Modelling in One of a Depleted Carbonate Oil Field, Southwest of Iran. Geomechanics and Geoengineering, 17(5):1536-1553. doi: 10.1080/17486025.2021.1955156.
[29]	Tavener, E., Flottmann, T., Brooke-Barnett, S.,2017. In-Situ Stress Distribution and Mechanical Stratigraphy in the Bowen and Surat Basins, Queensland, Australia. Geological Society, London, Special Publications,458(1):31-47.
[30]	Wang, W., Zhao, H.F., Ji, L., et al.,2025. Study on the Best Time of Refracturing for Hancheng Coal Seam. Safety in Coal Mines,56(1):26-33 (in Chinese with English abstract).
[31]	Wolhart,S.L., Berumen,S., Cipolla,C.L., et al.,2000. Use of Hydraulic Fracture Diagnostics to Optimize Fracturing Jobs in the Arcabuz-Culebra Field. In: SPE Rocky Mountain Region Low Permeability Reservoirs Symposium, Denver, CO, USA. Society of Petroleum Engineers, SPE 60314. doi: 10.2118/60314-MS.
[32]	Yang, D.S., Wang, W., Chen, W.Z., et al., 2017. Experimental Investigation on the Coupled Effect of Effective Stress and Gas Slippage on the Permeability of Shale. Scientific Reports, 7:44696.
[33]	Zhang, J.J., Hu, X.Y., Lian, P.Q., et al., 2025. In situ stress determination and its applications. The 59th U.S. Rock Mechanics/Geomechanics Symposium, Santa Fe, New Mexico, June 2025. doi: 10.56952/ARMA-2025-0245.
[34]	Zhang, P., Meng, Y., Liu, C.Y., et al.,2022. Stability Analysis of Fractured Coal Reservoirs Under Different Stress Mechanisms in Coalbed Methane Well Drainage. Coal Science and Technology,50(3):169-175 (in Chinese with English abstract).
[35]	Zhang, P., Meng, Y., Liu, C.Y., et al.,2023. In-situ Stress of Coal Reservoirs in the Zhengzhuang Area of the Southern Qinshui Basin and its Effects on Coalbed Methane Development, Energy Geoscience, 4(2):100144.
[36]	Zhang, P., Meng, Z.P., Jiang, S., et al.,2020. Characteristics of In-Situ Stress Distribution in Zhengzhuang Region, Southern Qinshui Basin, China and Its Stress Path During Depletion. Engineering Geology, 264:105413-105413.
[37]	Zhang, X.G., Ranjith, P.G., Lu, Y.Y., et al.,2019. Experimental Investigation of the Influence of CO2and Water Adsorption on Mechanics of Coal Under Confining Pressure. International Journal of Coal Geology, 209:117-129.
[38]	Zhang, X.G., Ranjith, P.G., Ranathunga, A.S., et al.,2019. Variation of Mechanical Properties of Bituminous Coal Under CO2and H2O Saturation. Journal of Natural Gas Science and Engineering, 61:158-168.
[39]	Zhao, Y.X., Lu, Z.G., Zhu, G.P., et al.,2018. Fault Reactive Induced by the Principal Stress Rotation for the Underground Coal Mining. Journal of China University of Mining&Technology,47(1):73-80 (in Chinese with English abstract).
[40]	Zoback, M.D.,2007. Reservoir Geomechanics. Cambridge: Cambridge University Press.
[41]	Zoback, M.D., Zinke, J.C.,2002. Production-Induced Normal Faulting in the Valhall and Ekofisk Oil fields. Pure and Applied Geophysics, 159:403-420.
[42]	常闯,李松,汤达祯,等,2023. 基于测井参数的煤储层地应力计算方法研究--以延川南区块为例.煤田地质与勘探,51(5):23-32.
[43]	郭依宝,周宏伟,荣腾龙,2018. 采动应力路径下深部煤体扰动特征.煤炭学报,43(11):3072-3079.
[44]	皇凡生,康毅力,游利军,等,2017. 排采降压诱发煤层剪切破坏机理与防控对策.煤炭学报,42(7):1803-1810.
[45]	鞠玮,姜波,秦勇,等,2020. 多煤层条件下现今地应力特征与煤层气开发.煤炭学报,45(10):3492-3500.
[46]	康红普,伊丙鼎,高富强,等,2019. 中国煤矿井下地应力数据库及地应力分布规律.煤炭学报,44(1):23-33.
[47]	孟召平,田永东,李国富,2010. 沁水盆地南部地应力场特征及其研究意义.煤炭学报,35(6):975-981.
[48]	孟召平,王宇恒,张昆,等,2019. 沁水盆地南部煤层水力压裂裂缝及地应力方向分析.煤炭科学技术, 47(10):216-222.
[49]	王伟, 赵海峰, 季亮, 等,2025. 韩城煤层重复压裂转向时机研究. 煤矿安全, 56(1):26-33.
[50]	章朋,孟雅,刘超英,等,2022.煤层气井排采中不同应力机制下含断裂煤储层稳定性分析.煤炭科学技术,50(03):169-175.DOI: 10.13199/j.cnki.cst.2021-0824.
[51]	赵毅鑫,卢志国,朱广沛,等,2018.考虑主应力偏转的采动诱发断层活化机理研究.中国矿业大学学报,47(01):73-80.DOI: 10.13247/j.cnki.jcumt.000794.
