Reservoir Characteristics and Peat-Forming Environment of No. 8 Coal Seam in Benxi Formation, Yichuan Area, Southeastern Ordos Basin
-
摘要: 鄂尔多斯盆地东南缘的宜川地区本溪组8#煤岩广覆式发育，是深层煤层（岩）气勘探开发的主要目的层. 为落实8#煤层煤岩储层特征和聚煤环境，基于6口井的岩心资料，对煤岩成分、孔隙结构特征和元素地球化学特征开展试验分析. 8#煤岩显微组分以镜质组为主，占比为80.5%，工业分析为低含水（0.94%）、中‒低灰分（13.29%）、低挥发分，镜质体反射率平均2.99%，为高阶无烟煤. 煤岩孔隙类型以次生的有机质气孔占比最高，其次为屑间孔和胞腔孔，微裂隙发育大幅提升了煤岩基质的渗透性. 孔隙结构分析表明，8#煤岩微孔发育，孔体积占比为64.53%，提供了几乎全部吸附气的赋存空间；介孔不发育，宏孔和微裂隙较发育，为游离气提供了赋存空间. 8#煤岩主要聚煤沼泽类型为覆水森林沼泽和深水芦苇沼泽，温热潮湿的古气候有利于成煤植物的生长和繁育，封闭、还原的水体环境促进了凝胶化作用的进行，为优质煤岩的形成提供了良好的环境.Abstract: The No. 8 coal seam in the Benxi Formation of the Yichuan Area on the southeastern margin of the Ordos Basin is extensively developed, serving as the primary target layer for coalbed methane exploration and development. To clarify the reservoir characteristics and peat-forming environment of this coal seam, experimental analyses were conducted based on core data from five wells, focusing on coal composition, pore structure characteristics, and elemental geochemistry. The macerals of the No. 8 coal are predominantly vitrinite, accounting for 80.5%. Proximate analysis indicates low moisture (0.94%), medium-low ash (13.29%), and low volatile matter content. The average random vitrinite reflectance is 2.99%, classifying it as high-rank anthracite. Among pore types, secondary organic gas pores are the most abundant, followed by intergranular pores and cellular pores. Well-developed micro-fractures significantly enhance the permeability of the coal matrix. Pore structure analysis reveals that the No. 8 coal is rich in micropores, which contribute 64.53% of the total pore volume, providing nearly all the storage space for adsorbed gas. Mesopores are underdeveloped, while macropores and micro-fractures are relatively well-developed, offering storage space for free gas. The main types of peat-forming swamps for the No. 8 coal were flooded forest swamps and deep-water reed swamps. The warm, humid paleoclimate favored the growth and proliferation of peat-forming plants, and the closed, reducing water environment promoted gelification, providing favorable conditions for the formation of high-quality coal.
-
图 1 鄂尔多斯盆地构造分区与宜川地区地层综合柱状图
Fig. 1. Structural subdivisions of the Ordos Basin and stratigraphic column in Yichuan Area
图 2 研究区8#煤宏观煤岩类型照片（Y76-2井）
Fig. 2. Photos of the macroscopic coal and rock types of No. 8 coal in the study area(Well Y76-2)
图 4 研究区本溪组8#煤岩灰分产率随深度变化趋势
Fig. 4. Variation trend of ash yield with depth for the No. 8 coal seam in the Benxi Formation of the study area
图 5 鄂尔多斯盆地8#煤镜质体反射率等值线图
据长庆油田，2026，深层煤岩气勘探开发工作汇报
Fig. 5. Contour map of vitrinite reflectance for the No. 8 coal seam in the Ordos Basin
图 6 扫描电镜观察的研究区8#煤孔隙类型
a. 镜质体表面矿物晶间孔；b. 胞腔孔；c. 气孔群，部分被无机矿物充填；d. 微裂隙
Fig. 6. SEM-observed pore types in the No.8 coal seam of the study area
图 7 研究区8#煤微裂隙图像（YQ27井）
略显层理构造，主裂隙垂直于层理面发育，次裂隙与主裂隙近垂直，局部呈雁列式、阶梯状、不规则状，个别裂隙被矿物充填.气体晕痕明显
Fig. 7. Micro-fissure images of No.8 coal seam of the study area (Well YQ27)
图 8 研究区8#煤CO2吸附曲线
Fig. 8. CO2 adsorption curve of the No.8 coal seam in the study area
图 9 研究区本溪组8#煤比表面与孔体积随热演化程度变化曲线
Fig. 9. Curves of specific surface area and pore volume vs. thermal evolution degree for No. 8 coal seam in the Benxi Formation, study area
图 10 不同品质煤岩比表面积和孔体积变化曲线
Fig. 10. Curves of specific surface area and pore volume variation for different quality coal samples
图 11 研究区8#煤岩微孔孔径分布
Fig. 11. Micropore size distribution of No.8 coal seam in the study area
图 12 研究区8#煤N2吸附曲线
Fig. 12. N2 adsorption curve of the No.8 coal seam in the study area
图 13 研究区8#煤岩介孔孔径分布
Fig. 13. Mesopores size distribution of No.8 coal seam in the study area
图 14 研究区8#煤高压压汞曲线
Fig. 14. High-pressure mercury injection curve of No.8 coal seam in the study area
图 15 研究区8#煤全孔径拼接孔容容量分布
Fig. 15. Full pore size range integrated pore volume variation of No.8 coal seam in the study area
图 16 研究区8#煤稀土元素分布模式图
Fig. 16. Rare earth element distribution pattern diagram of No. 8 coal seam in the study area
图 17 研究区8#煤球粒陨石标准化后稀土元素配分模式图
Fig. 17. Chondrite-normalized rare earth element distribution pattern diagram of No. 8 coal seam samples in the study area
图 18 研究区8#煤古气候判别图
Fig. 18. Palaeoclimatic discrimination diagram for No. 8 coal seam in the study area
图 19 研究区8#煤古盐度剖面
Fig. 19. Palaeosalinity profile of the No. 8 coal seam in the study area
图 20 研究区8#煤氧化还原条件剖面
Fig. 20. Redox conditions profile of the No. 8 coal seam in the study area
图 21 研究区8#煤TPI-GI相图
Fig. 21. Phase diagram of TPI-GI of No. 8 coal seam in the study area
图 22 研究区本溪组8#煤勘探有利区预测图
Fig. 22. Prediction map of favorable areas for No. 8 coal seam exploration in the Benxi Formation of the study area
表 1 煤岩的宏观类型划分
Table 1. Macroscopic type classification for coal rocks
宏观煤
岩类型代码 分类指标 总体相对
光泽强度光亮成分含量(%) 光亮煤 BC 强 > 80 半亮煤 SBC 较强 > 50~80 半暗煤 SDC 较弱 > 20~50 暗淡煤 DC 弱 ≤20
下载: 导出CSV
表 2 研究区本溪组8#煤岩显微组分统计
Table 2. Statistics of macroscopic components for the No. 8 coal seam in the Benxi Formation of the study area
样品编号 镜质组含量
（%）惰质组含量
（%）黏土矿物含量
（%）硫化物类含量
（%）碳酸盐类含量
（%）镜惰比 Y156-2（1） 84.0 10.0 4.5 0.6 0.9 6.0 Y156-2（2） 85.2 10.0 3.8 0.4 0.6 4.8 Y156-2（3） 83.6 8.6 6.3 0.7 0.8 7.8 Y156-2（4） 85.6 7.6 5.4 0.6 0.8 6.8 Y156-2（5） 81.0 11.2 6.4 0.5 0.9 7.8 Y156-2（6） 87.6 6.0 5.0 0.6 0.8 6.4 Y156-2（7） 81.2 6.4 8.6 2.5 1.3 12.4 Y39-1（1） 85.2 9.0 4.6 0.5 0.7 5.8 Y39-1（2） 82.0 8.6 7.9 0.6 0.9 9.4 Y39-1（3） 81.6 10.6 6.3 0.6 0.9 7.8 Y39-1（4） 82.2 6.4 9.9 0.6 0.9 11.4 Y39-1（5） 81.0 11.0 6.3 0.8 0.9 8.0 Y39-1（6） 81.6 11.6 5.5 0.5 0.8 6.8 Y23-1（1） 81.0 12.0 5.2 1.0 0.8 7.0 Y23-1（2） 61.2 28.0 8.7 1.0 1.1 10.8 Y23-1（3） 87.2 5.8 4.3 2.2 0.5 7.0 Y23-1（4） 80.6 11.2 5.4 1.9 0.9 8.2 Y23-1（5） 81.0 11.6 5.8 0.6 1.0 7.4 Y23-1（6） 76.4 16.0 5.8 1.0 0.8 7.6 Y76-2（1） 78.0 14.4 5.8 0.8 1.0 7.6 Y76-2（2） 77.2 14.8 6.6 0.6 0.8 8.0 Y76-2（3） 86.4 7.6 4.6 0.6 0.8 6.0 Y76-2（4） 71.2 18.4 8.2 1.0 1.2 10.4 Y76-2（5） 76.4 17.6 4.2 0.8 1.0 6.0 Y56-3（1） 79.6 12.4 6.6 0.6 0.8 8.0 Y56-3（2） 83.6 10.0 4.8 0.8 0.8 6.4 Y56-3（3） 78.0 13.2 6.6 1.0 1.2 8.8 Y56-3（4） 74.0 18.0 6.2 0.8 1.0 8.0 Y56-3（5） 85.2 8.0 5.2 0.8 0.8 6.8 Y56-3（6） 76.0 10.4 10.4 1.4 1.8 13.6 平均值 80.5 11.5 6.2 0.9 0.9 8.0
下载: 导出CSV
表 3 研究区本溪组8#煤岩工业分析数据
Table 3. Proximate analysis data for the No. 8 coal seam in the Benxi Formation of the study area
样品编号 深度（m） 水分(%) 灰分(%) 挥发分(%) 固定碳(%) Ro(%) 空气干燥基 空气干燥基 空气干燥基 空气干燥基 Y156-2（1） 2 239.31 0.88 3.94 7.04 88.14 2.92 Y156-2（2） 2 239.88 0.93 4.83 6.51 87.73 2.94 Y156-2（3） 2 241.32 0.83 11.39 10.02 77.76 2.92 Y156-2（4） 2 241.67 0.91 4.27 7.18 87.64 2.99 Y156-2（5） 2 242.62 0.92 11.27 7.60 80.21 2.97 Y156-2（6） 2 243.42 0.86 4.32 7.07 87.75 3.03 Y156-2（7） 2 244.17 0.86 17.45 8.70 72.99 3.07 Y39-1（1） 2 342.07 1.47 10.48 7.32 80.73 3.03 Y39-1（2） 2 343.28 0.89 12.98 7.86 78.27 3.10 Y39-1（3） 2 344.64 1.16 10.13 7.22 81.49 3.10 Y39-1（4） 2 345.58 1.36 10.93 8.00 79.71 3.13 Y39-1（5） 2 346.88 1.34 10.92 6.90 80.84 3.13 Y39-1（6） 2 347.23 1.77 6.94 6.12 85.17 3.16 Y23-1（1） 2 099.60 0.91 23.48 8.57 67.04 2.94 Y23-1（2） 2 101.71 0.23 21.35 8.75 69.67 3.02 Y23-1（3） 2 102.12 1.43 12.43 6.99 79.15 2.96 Y23-1（4） 2 102.67 1.67 19.71 7.67 70.95 3.04 Y23-1（5） 2 104.87 0.99 32.75 9.13 57.13 3.04 Y23-1（6） 2 106.17 0.92 35.86 8.99 54.23 3.21 Y76-2（1） 2 097.27 0.55 2.43 6.82 90.20 2.80 Y76-2（2） 2 097.61 0.49 5.47 6.51 87.53 2.82 Y76-2（3） 2 098.69 0.83 7.09 7.88 84.20 2.81 Y76-2（4） 2 099.74 0.87 11.84 8.78 78.51 2.85 Y76-2（5） 2 100.35 0.59 20.19 9.17 70.05 2.90 Y56-3（1） 2 334.99 0.68 12.26 8.42 78.64 2.95 Y56-3（2） 2 336.92 0.94 17.27 7.96 73.83 2.86 Y56-3（3） 2 337.85 0.55 18.94 7.45 73.06 2.99 Y56-3（4） 2 338.75 0.77 10.17 7.24 81.82 3.01 Y56-3（5） 2 339.00 0.84 10.94 7.08 81.14 3.02 Y56-3（6） 2 340.67 0.83 16.76 7.43 74.98 2.90 平均值 0.94 13.29 7.75 78.02 2.99
下载: 导出CSV
表 4 研究区本溪组8#煤岩CO2吸附比表面积和孔体积
Table 4. CO2 adsorption specific surface area and pore volume of the No.8 coal seam in the Benxi Formation, study area
序号 样品编号 比表面积 孔体积 样品宏
观煤型Langmuir
（m2/g）DFT
PoreSize
（m2/g）Dubinin-
Astakhov
（m2/g）Horvath-Kawazoe（cm3/g） DFT
PoreSize
（cm3/g）Dubinin-
Astakhov（cm3/g）1 Y56-3（7） 183.341 6 156.913 0 166.985 8 0.042 8 0.045 5 0.064 8 半亮煤 2 Y76-2（6） 219.226 0 157.887 0 166.533 8 0.043 3 0.046 8 0.064 6 光亮煤 3 Y14-18X1（1） 161.037 8 187.910 0 178.326 1 0.049 5 0.052 2 0.067 4 半亮煤 4 Y14-18X1（2） 194.506 3 161.554 0 162.989 0 0.044 1 0.047 2 0.062 4 半亮煤
下载: 导出CSV
表 5 研究区本溪组8#煤岩N2吸附比表面积和孔体积
Table 5. N2 adsorption specific surface area and pore volume of the No.8 coal seam in the Benxi Formation, study area
序号 样品编号 比表面积
（BET法）(m²/g)微孔孔容
（t-plot法）(cm³/g)介孔孔容
（BJH法）(cm³/g)大孔孔容
（BJH法）(cm³/g)1 Y56-3（7） 2.0 0 0.001 852 0.001 028 2 Y76-2（6） 0.1 0.000 075 0.001 072 0.000 178 3 Y14-18X1（1） 4.5 0.000 236 0.004 747 0.000 476 4 Y14-18X1（2） 0.4 0.000 083 0.001 625 0.000 793
下载: 导出CSV
表 6 研究区本溪组8#煤主量元素分析数据
Table 6. Major element analysis data of No. 8 coal seam in the Benxi Formation of the study area
样品编号 深度(m) SiO2(%) TiO2(%) Al2O3(%) TFe2O3(%) MgO(%) CaO(%) Na2O(%) K2O(%) Y156-2（1） 2 239.31 52.10 1.12 25.49 3.64 0.56 15.97 0.56 0.56 Y156-2（2） 2 239.88 66.20 4.50 28.16 0.16 0.22 0.38 0.16 0.16 Y156-2（3） 2 241.32 44.21 0.78 30.30 15.08 0.65 7.93 0.39 0.52 Y156-2（4） 2 241.67 45.67 0.42 41.90 7.68 0.42 1.82 0.28 0.28 Y156-2（5） 2 242.62 50.83 2.52 44.19 0.94 0.41 0.23 0.18 0.67 Y156-2（6） 2 243.42 49.29 0.47 42.92 0.94 0.71 4.95 0.47 0.24 Y156-2（7） 2 244.17 48.37 2.48 43.76 0.25 0.35 4.16 0.15 0.45 Y39-1（1） 2 342.07 36.39 1.71 31.48 6.51 0.85 21.24 0.21 0.32 Y39-1（2） 2 343.28 40.96 0.49 36.02 0.85 0.92 15.61 0.21 0.42 Y39-1（3） 2 344.64 45.98 0.43 38.80 1.85 0.54 11.52 0.22 0.22 Y39-1（4） 2 345.58 49.48 0.57 44.72 0.38 0.57 3.62 0.19 0.19 Y39-1（5） 2 346.88 48.08 1.03 43.85 1.78 0.47 3.94 0.19 0.19 Y39-1（6） 2 347.23 34.79 0.42 32.50 24.40 0.73 5.71 0.21 0.31 Y23-1（1） 2 099.60 46.34 0.94 38.65 1.88 1.88 9.76 0.38 0.19 Y23-1（2） 2 101.71 51.71 2.54 26.54 0.29 1.85 16.68 0.20 0.20 Y23-1（3） 2 102.12 44.12 0.74 34.56 0.37 1.47 18.01 0.37 0.37 Y23-1（4） 2 102.67 51.70 0.82 36.61 3.27 1.40 4.80 0.70 0.70 Y23-1（5） 2 104.87 49.73 1.32 43.93 0.48 0.42 3.47 0.12 0.30 Y23-1（6） 2 106.17 50.40 4.15 43.83 0.12 0.35 0.81 0.12 0.17 Y76-2（1） 2 097.27 63.91 1.41 28.87 0.35 0.35 4.40 0.35 0.35 Y76-2（2） 2 097.61 53.46 0.45 38.93 0.79 0.79 4.43 0.68 0.45 Y76-2（3） 2 098.69 47.09 3.50 42.91 0.68 0.49 4.66 0.39 0.19 Y76-2（4） 2 099.74 45.60 0.28 42.19 6.11 0.57 3.27 0.28 0.28 Y76-2（5） 2 100.35 38.65 0.90 32.93 0.45 1.05 25.41 0.30 0.30 Y56-3（1） 2 334.99 51.06 0.56 42.68 1.45 0.56 3.24 0.11 0.34 Y56-3（2） 2 336.92 42.84 0.99 37.31 14.51 1.28 2.47 - 0.59 Y56-3（3） 2 337.85 39.49 0.59 34.63 20.58 0.49 3.84 0.11 0.27 Y56-3（4） 2 338.75 51.00 2.92 44.99 0.24 0.24 0.33 0.09 0.09 Y56-3（5） 2 339.00 36.48 0.69 31.55 19.33 0.37 10.99 0.05 0.37 Y56-3（6） 2 340.67 40.52 0.94 35.09 21.46 0.26 1.51 0.05 0.10 平均值 47.21 1.36 37.34 5.23 0.71 7.17 0.27 0.33
下载: 导出CSV
-
Chen, P. Y., Sun, D. S., Ding, P. X., et al., 1996. Atlas of Coal Petrology in China. China Coal Industry Publishing House, Beijing (in Chinese). Chen, S. D., Tang, D. Z., Hou, W., et al., 2023. Geological Particularity and Reservoir Engineering Response of Deep Coalbed Methane. Acta Petrolei Sinica, 44(11): 1993-2006 (in Chinese with English abstract). Deng, Z., Wang, H. Y., Jiang, Z. X., et al., 2024. Influence of Deep Coal Pore and Fracture Structure on Occurrence of Coalbed Methane: A Case Study of Daning- Jixian Block in Eastern Margin of Ordos Basin. Coal Science and Technology, 52(8): 106-123 (in Chinese with English abstract). Fan, L. Y., Shi, Y. H., Dong, G. D., et al., 2024. Geochemical Characteristics and Coal-Forming Environments of Deep Coal Rocks of Permian Shanxi Formation in Central and Eastern Ordos Basin. Natural Gas Industry, 44(10): 113-125 (in Chinese with English abstract). Huang, D. J., Xu, H., Hu, J. L., et al., 2025. Pore Development Patterns and Gas Control Effects of No. 8 Deep Coal Seam of Ordos Basin. Coal Science and Technology, 53(3): 115-123 (in Chinese with English abstract). Jiao, F. Z., Zhao, Q., Xiao, Y. H., et al., 2025. A Major Transformation from Coalbed Methane to Coal-Rock Gas Leading the "Coal-Rock Gas Revolution". Acta Petrolei Sinica, 46(12): 2211-2225 (in Chinese with English abstract). Johnson, R. C., Flores, R. M., 1998. Developmental Geology of Coalbed Methane from Shallow to Deep in Rocky Mountain Basins and in Cook Inlet-Matanuska Basin, Alaska, U. S. A. and Canada. International Journal of Coal Geology, 35(1-4): 241-282. https://doi.org/10.1016/S0166-5162(97)00016-5 Liu, H. L., Zou, C. N., Deng, Z., et al., 2026. Pore Characteristics and Coalbed Gas Reservoir Formation Characteristics of Coal Reservoir of No. 8 Coal Seam in Well Suide 1H, Ordos Basin. Earth Science, 51(1): 284-302 (in Chinese with English abstract). Liu, H. L., Zou, C. N., Yin, S., et al., 2024. Formation, Distribution, Sweet Spot Evaluation and Development Prospect of Coal-Measure Gas in China. Natural Gas Industry, 44(10): 1-21 (in Chinese with English abstract). Luo, P. Y., Zhu, S. Y., 2023. Theoretical and Technical Fundamentals of a 100 Billion-Cubic-Meter-Scale Large Industry of Coalbed Methane in China. Acta Petrolei Sinica, 44(11): 1755-1763 (in Chinese with English abstract). Ma, W. J., 2022. Accumulation Conditions and Favorable Exploration Areas Prediction of Lowrank Coalbed Methane in Member K1d2 of Huhehu Sag in Hailar Basin. Petroleum Geology & Oilfield Development in Daqing, 41(1): 33-40 (in Chinese with English abstract). Niu, X. B., Fan, L. Y., Yan, X. X., et al., 2024. Enrichment Conditions and Resource Potential of Coal-Rock Gas in Ordos Basin, NW China. Petroleum Exploration and Development, 51(5): 972-985 (in Chinese with English abstract). Peng, Z. X., Yu, X. H., Li, S. L., et al., 2023. Migration Patterns and Controlling Factors of Barrier of the Benxi Formation in Southeastern Ordos Basin. Journal of Palaeogeography, 25(6): 1330-1346 (in Chinese with English abstract). Qin, Y., 2023. Progress on Geological Research of Deep Coalbed Methane in China. Acta Petrolei Sinica, 44(11): 1791-1811 (in Chinese with English abstract). Qin, Y., Yuan, L., Hu, Q. T., et al., 2012. Status and Development Orientation of Coalbed Methane Exploration and Development Technology in China. Coal Science and Technology, 40(10): 1-6 (in Chinese with English abstract). Ren, Z. L., Qi, K., Li, J. B., et al., 2021. Thermodynamic Evolution and Hydrocarbon Accumulation in the Ordos Basin. Oil & Gas Geology, 42(5): 1030-1042 (in Chinese with English abstract). Shan, J. F., Wu, B. W., Jin, K., et al., 2022. Characteristics of Upper Paleozoic Reservoirs and Its Influence on Natural Gas Accumulation in Yichuan-Huanglong Area, Ordos Basin. Special Oil & Gas Reservoirs, 29(6): 29-38 (in Chinese with English abstract). Shi, J. T., Cao, J. T., Xu, F. Y., et al., 2024. A Calculation Model of Free Gas Saturation in Deep Coalbed Methane Reservoirs and Its Application. Coal Geology & Exploration, 52(2): 134-146 (in Chinese with English abstract). Xie, Y. G., Meng, S. Z., Wan, H., et al., 2015. Analysis on Geological Conditions of Multi Type Natural Gas Reservoir in Coal Measure Strata of Linxing Area. Coal Science and Technology, 43(9): 71-75, 143 (in Chinese with English abstract). Xu, F. Y., Hou, W., Xiong, X. Y., et al., 2023. The Status and Development Strategy of Coalbed Methane Industry in China. Petroleum Exploration and Development, 50(4): 669-682 (in Chinese with English abstract). Xu, F. Y., Wang, C. W., Xiong, X. Y., et al., 2022. Deep(Layer)Coalbed Methane Reservoir Forming Modes and Key Technical Countermeasures: Taking the Eastern Margin of Ordos Basin as an Example. China Offshore Oil and Gas, 34(4): 30-42 (in Chinese with English abstract). Xu, H., Tang, D. Z., Tao, S., et al., 2024. Differences in Geological Conditions of Deep and Shallow Coalbed Methane and Their Formation Mechanisms. Coal Geology & Exploration, 52(2): 33-39 (in Chinese with English abstract). Yang, H., Liu, C. L., Wang, F. L., et al., 2021. Paleoenvironment and Development Model of Source Rocks of Dongying Formation in Bozhong Sag. Lithologic Reservoirs, 33(6): 81-92 (in Chinese with English abstract). Zhang, J. F., Bi, C. Q., Tang, D. Z., et al., 2020. Research and Practice of Coalbed Methane Exploration and Development in China. Geological Publishing House, Beijing (in Chinese). Zhang, J. Y., Shi, X. W., Tian, C., et al., 2025. Multi-Scale Pore Structure of the Deep Coal-Rock Gas Reservoir in the Longtan Formation in the Central Sichuan Basin. Natural Gas Geoscience, 36(9): 1646-1660 (in Chinese with English abstract). Zhao, L. Y., Guo, Z. J., Han, S. J., et al., 2023. Coal Quality Characteristics and Sedimentary Environment Indication of the Longtan Formation in the Yina Area of Zhijin County, Guizhou Province. Geology and Exploration, 59(5): 974-984 (in Chinese with English abstract). Zhao, Z., Yang, W., Zhao, Z. Y., et al., 2024. Research Progresses in Geological Theory and Key Exploration Areas of Coal-Formed Gas in China. Petroleum Exploration and Development, 51(6): 1240-1253 (in Chinese with English abstract). 陈佩元, 孙达三, 丁丕训, 等, 1996. 中国煤岩图鉴. 北京: 煤炭工业出版社. 陈世达, 汤达祯, 侯伟, 等, 2023. 深部煤层气地质条件特殊性与储层工程响应. 石油学报, 44(11): 1993-2006. 邓泽, 王红岩, 姜振学, 等, 2024. 深部煤储层孔裂隙结构对煤层气赋存的影响: 以鄂尔多斯盆地东缘大宁‒吉县区块为例. 煤炭科学技术, 52(8): 106-123. 范立勇, 史云鹤, 董国栋, 等, 2024. 鄂尔多斯盆地中东部二叠系山西组深层煤岩地球化学特征及成煤环境. 天然气工业, 44(10): 113-125. 黄道军, 许浩, 虎建玲, 等, 2025. 鄂尔多斯盆地深部8号煤储层孔隙发育模式及其控气作用. 煤炭科学技术, 53(3): 115-123. 焦方正, 赵群, 肖宇航, 等, 2025. 煤层气到煤岩气的"蝶变"引领"煤岩气革命". 石油学报, 46(12): 2211-2225. 刘翰林, 邹才能, 邓泽, 等, 2026. 鄂尔多斯盆地绥德1H井8#煤储层孔隙特征及煤岩气成藏特征. 地球科学, 51(1): 284-302. doi: 10.3799/dqkx.2025.231 刘翰林, 邹才能, 尹帅, 等, 2024. 中国煤系气形成分布、甜点评价与展望. 天然气工业, 44(10): 1-21. 罗平亚, 朱苏阳, 2023. 中国建立千亿立方米级煤层气大产业的理论与技术基础. 石油学报, 44(11): 1755-1763. 马文娟, 2022. 海拉尔盆地呼和湖凹陷大二段低煤阶煤层气成藏条件及有利勘探区预测. 大庆石油地质与开发, 41(1): 33-40. 牛小兵, 范立勇, 闫小雄, 等, 2024. 鄂尔多斯盆地煤岩气富集条件及资源潜力. 石油勘探与开发, 51(5): 972-985. 彭子霄, 于兴河, 李顺利, 等, 2023. 鄂尔多斯盆地东南部本溪组障壁迁移样式及控制因素. 古地理学报, 25(6): 1330-1346. 秦勇, 2023. 中国深部煤层气地质研究进展. 石油学报, 44(11): 1791-1811. 秦勇, 袁亮, 胡千庭, 等, 2012. 我国煤层气勘探与开发技术现状及发展方向. 煤炭科学技术, 40(10): 1-6. 任战利, 祁凯, 李进步, 等, 2021. 鄂尔多斯盆地热动力演化史及其对油气成藏与富集的控制作用. 石油与天然气地质, 42(5): 1030-1042. 石军太, 曹敬添, 徐凤银, 等, 2024. 深部煤层气游离气饱和度计算模型及其应用. 煤田地质与勘探, 52(2): 134-146. 单俊峰, 吴炳伟, 金科, 等, 2022. 鄂尔多斯盆地宜川‒黄龙地区上古生界储层特征及其对天然气成藏的影响. 特种油气藏, 29(6): 29-38. 谢英刚, 孟尚志, 万欢, 等, 2015. 临兴地区煤系地层多类型天然气储层地质条件分析. 煤炭科学技术, 43(9): 71-75, 143. 徐凤银, 侯伟, 熊先钺, 等, 2023. 中国煤层气产业现状与发展战略. 石油勘探与开发, 50(4): 669-682. 徐凤银, 王成旺, 熊先钺, 等, 2022. 深部(层)煤层气成藏模式与关键技术对策——以鄂尔多斯盆地东缘为例. 中国海上油气, 34(4): 30-42. 许浩, 汤达祯, 陶树, 等, 2024. 深、浅部煤层气地质条件差异性及其形成机制. 煤田地质与勘探, 52(2): 33-39. 阳宏, 刘成林, 王飞龙, 等, 2021. 渤中凹陷东营组古沉积环境及烃源岩发育模式. 岩性油气藏, 33(6): 81-92. 张君峰, 毕彩芹, 汤达祯, 等, 2020. 中国煤层气勘探开发探索与实践. 北京: 地质出版社. 张景缘, 石学文, 田冲, 等, 2025. 川中地区二叠系龙潭组深层煤岩气储层多尺度孔隙结构表征. 天然气地球科学, 36(9): 1646-1660. 赵凌云, 郭志军, 韩思杰, 等, 2023. 贵州织金县以那地区龙潭组煤质特征及其沉积环境指示. 地质与勘探, 59(5): 974-984. 赵喆, 杨威, 赵振宇, 等, 2024. 中国煤成气地质理论研究进展与重点勘探领域. 石油勘探与开发, 51(6): 1240-1253. -
