基于光弹测试技术的颗粒柱坍塌启动细观行为分析

doi:10.3799/dqkx.2026.173

基于光弹测试技术的颗粒柱坍塌启动细观行为分析

doi: 10.3799/dqkx.2026.173

戴国威¹,
毛无卫^1,2,
黄雨^1,2,
郑虎^1,2, ,

1. 同济大学土木工程学院地质与水利工程系, 上海 200092;
2. 同济大学岩土及地下工程教育部重点实验室, 上海 200092

基金项目:

国家自然科学基金项目(42277156)。

详细信息

作者简介:
戴国威(1998-),男,博士研究生,主要从事颗粒物质力学、工程地质灾害等研究。E-mail:Daigw@tongji.edu.cn,ORCID:0000-0003-2477-7618

通讯作者:
郑虎(1986-),男,教授,博士生导师,主要从事地质灾害防治与岩土颗粒物质力学研究.E-mail:zhenghu@tongji.edu.cn,ORCID:0000-0002-9606-9947

中图分类号: P642.22
计量
- 文章访问数: 76
- HTML全文浏览量: 2
- PDF下载量: 8
- 被引次数: 0
出版历程
- 收稿日期: 2026-02-28
- 网络出版日期: 2026-06-29

Microscopic initiation behavior analysis of granular column collapse based on photoelastic technology

Guowei Dai¹,
Wuwei Mao^1,2,
Yu Huang^1,2,
Hu Zheng^{1,2
, ,}

1. Department of Geological and Hydraulic Engineering, College of Civil Engineering, Tongji University, Shanghai 200092, China;
2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai, 200092, China

摘要

摘要: 为揭示突发型滑坡启动过程的细观动力学机制，本研究基于光弹性测力技术与颗粒柱坍塌物理模型，实现了岩土颗粒材料在瞬态启动阶段颗粒位移与力链网络演化的同步系统观测。结果表明，滑坡启动过程中力链断裂重组与剪切带形成在时空上具有高度一致性。在形成稳定颗粒流之前，颗粒加速阶段与体系内部应力水平的快速衰减呈显著相关，表明应力释放是驱动滑坡突发启动的重要动力学机制。进一步分析发现，突发型滑坡启动过程中颗粒尺度动力学行为可划分为两种不同模式：一是滑动区内颗粒沿主滑移方向发生系统性位移；二是非滑动区内颗粒表现出不规则的非局域位移特征，该非局域运动主要受局部剪切扰动及力链传递过程控制。
- 颗粒启动 /
- 光弹性技术 /
- 力链网络 /
- 突发型滑坡
Abstract: To elucidate the mesoscopic mechanisms underlying the initiation of sudden-failure landslides, this study employs photoelastic experimental techniques combined with a granular column collapse model, to achieve simultaneous observation of granular displacement and force-chain network evolution during the transient initiation stage. The results reveal a strong spatiotemporal consistency between the evolution of the internal force-chain network and the formation of shear bands (failure line). Prior to the development of granular flow, particle acceleration is closely correlated with a reduction in the internal stress level of the system. At the particle scale, the initiation process can be characterized by two distinct dynamic patterns: systematic displacement within the sliding zone and irregular nonlocal displacement in the non-sliding zone, the latter being primarily driven by localized shear fluctuations and stress transmission within the granular assembly.
- granular initiation /
- photoelastic technology /
- force chain network /
- sudden-failure landslide

HTML全文

参考文献(40)

[1]	Bougouin, A., Lacaze, L., 2018. Granular Collapse in a Fluid: Different Flow Regimes for an Initially Dense-Packing.Physical Review Fluids, 3:064305. https://doi.org/10.1103/PhysRevFluids.3.064305
[2]	Chen, N.Sh., Zhou, W., Yang, Ch.L., et al., 2010. The Processes and Mechanism of Failure and Debris Flow Initiation for Gravel Soil with Different Clay Content.Geomorphology, 121:222-230. https://doi.org/10.1016/j.geomorph.2010.04.017
[3]	Courrech Du Pont, S., Gondret, P., Perrin, B., et al., 2003. Granular Avalanches in Fluids.Physical Review Letters, 90:044301. https://doi.org/10.1103/PhysRevLett.90.044301
[4]	Daniels, K.E., Kollmer, J.E., Puckett, J.G., 2017. Photoelastic Force Measurements in Granular Materials.Review of Scientific Instruments, 88:051808. https://doi.org/10.1063/1.4983049
[5]	Fazelpour, F., Tang, Z., Daniels, K.E., 2022. The Effect of Grain Shape and Material on the Nonlocal Rheology of Dense Granular Flows.Soft Matter, 18:1435-1442. https://doi.org/10.1039/D1SM01237A
[6]	Fern, E.J., De Lange, D.A., Zwanenburg, C., et al., 2017. Experimental and Numerical Investigations of Dyke Failures Involving Soft Materials.Engineering Geology, 219:130-139. https://doi.org/10.1016/j.enggeo.2016.07.006
[7]	Gou, H.X., Hu, W., Xu, Q., et al., 2023. Stick-Slip Nucleation and Failure in Uniform Glass Beads Detected by Acoustic Emissions in Ring-Shear Experiments: Implications for Identifying the Acoustic Emissions of Earthquake Foreshocks.Journal of Geophysical Research: Solid Earth, 128(8):e2023JB026612. https://doi.org/10.1029/2023JB026612
[8]	Howell, D., Behringer, R.P., Veje, C., 1999. Stress Fluctuations in a 2D Granular Couette Experiment: A Continuous Transition.Physical Review Letters, 82:5241-5244. https://doi.org/10.1103/PhysRevLett.82.5241
[9]	Hu, W., Chang, C.S., McSaveney, M., et al., 2020. A Weakening Rheology of Dry Granular Flows with Extensive Brittle Grain Damage in High-Speed Rotary Shear Experiments.Geophysical Research Letters, 47(11):e2020GL087763. https://doi.org/10.1029/2020GL087763
[10]	Jing, L., Yang, G.C., Kwok, C.Y., et al., 2018. Dynamics and Scaling Laws of Underwater Granular Collapse with Varying Aspect Ratios.Physical Review E, 98:042901. https://doi.org/10.1103/PhysRevE.98.042901
[11]	Johnson, B.C., Campbell, C.S., 2017. Drop Height and Volume Control the Mobility of Long-Runout Landslides on the Earth and Mars.Geophysical Research Letters, 44(24): 12091-12097. https://doi.org/10.1002/2017GL076113
[12]	Ladd, C.R., Reber, J.E., 2020. The Effect of a Liquid Phase on Force Distribution During Deformation in a Granular System.Journal of Geophysical Research: Solid Earth, 125(8): e2020JB019771. https://doi.org/10.1029/2020JB019771
[13]	Lee, C.H., Kuan, Y.H., 2021. Onset of Submerged Granular Collapse in Densely Packed Condition.Physics of Fluids, 33:121705. https://doi.org/10.1063/5.0072335
[14]	Li, Y., Hu, W., Xu, Q., et al., 2024. Velocity Profile Geometries and Granular Temperature Distributions in Very Dense Granular Flows.Geophysical Research Letters, 51(2):e2023GL104410. https://doi.org/10.1029/2023GL104410
[15]	Liu, A., Nagel, S., 1998. Jamming is not just cool anymore.Nature, 396: 21-22. https://doi.org/10.1038/23819
[16]	Majmudar, T.S., Behringer, R.P., 2005. Contact Force Measurements and Stress-Induced Anisotropy in Granular Materials.Nature, 435:1079-1082. https://doi.org/10.1038/nature03805
[17]	Rondon, L., Pouliquen, O., Aussillous, P., 2011. Granular Collapse in a Fluid: Role of the Initial Volume Fraction.Physics of Fluids, 23:073301. https://doi.org/10.1063/1.3594200
[18]	Shao, X.X., Zhang, H.Y., Tan, Y., 2018. Collapse Behavior and Microstructural Alteration of Remolded Loess under Graded Wetting Tests.Engineering Geology, 233:11-22. https://doi.org/10.1016/j.enggeo.2017.11.025
[19]	Tang, Z., Brzinski, T.A., Shearer, M., et al., 2018. Nonlocal Rheology of Dense Granular Flow in Annular Shear Experiments.Soft Matter, 14:3040-3048. https://doi.org/10.1039/C8SM00047F
[20]	Thomas, A. L., Tang, Z., et al., 2019. Force fluctuations at the transition from quasi-static to inertial granular flow.Soft Matter, 15:8532. https://doi.org/10.1039/c9sm01111k
[21]	Thomas, A. L., Vriend, N. M., 2019. Photoelastic study of dense granular free-surface flows.Physical review E, 100: 012902. https://doi.org/10.1103/PhysRevE.100.012902
[22]	Wang, D., Zheng, H., Yuan J., et al., 2020. Shear of Granular Materials Composed of Ellipses.Granular Matter, 22:5. https://doi.org/10.1007/s10035-019-0965-8
[23]	657. https://doi.org/10.1007/s12583-022-1713-2
[24]	154. https://doi.org/10.1007/s11440-022-01714-2
[25]	Yang, Q.Q., Su, Z.M., Cheng, Q.G., et al., 2019. High Mobility of Rock-Ice Avalanches: Insights from Small Flume Tests of Gravel-Ice Mixtures.Engineering Geology, 260:105260. https://doi.org/10.1016/j.enggeo.2019.105260
[26]	Yu, F.W., Su, L.J., 2021. Experimental Investigation of Mobility and Deposition Characteristics of Dry Granular Flow.Landslides, 18:1875-1887. https://doi.org/10.1007/s10346-020-01593-2
[27]	Zhang, X.M., Tahmasebi, P., 2022. Coupling Irregular Particles and Fluid: Complex Dynamics of Granular Flows.Computers and Geotechnics, 143:104624. https://doi.org/10.1016/j.compgeo.2021.104624
[28]	Zhao, Y.Q., Zheng, H., Wang, D., et al., 2019. Particle Scale Force Sensor Based on Intensity Gradient Method in Granular Photoelastic Experiments.New Journal of Physics, 21: 023009. https://doi.org/10.1088/1367-2630/ab05e7
[29]	Zheng, H., Dai, G.W., Bester, C.S., et al., 2023. Development of a Biaxial Apparatus for Jamming Profiles of Photoelastic Granular Media.Review of Scientific Instruments, 94(3):035110. https://doi.org/10.1063/5.0125720
[30]	Zheng, H., Wang, D., Behringer, R.P., 2019a. Experimental Study on Granular Biaxial Test Based on Photoelastic Technique.Engineering Geology, 260:105208. https://doi.org/10.1016/j.enggeo.2019.105208
[31]	Zheng, H., Wang, D., Tong, X.M., et al., 2019b. Granular Scale Responses in the Shear Band Region.Granular Matter, 21:107. https://doi.org/10.1007/s10035-019-0958-7
[32]	来志强,江恩慧,赵连军,等,2021.颗粒柱坍塌运动与堆积特性的研究综述.上海交通大学学报,55(04):421433.
[33]	孙其诚, 王光谦,2008. 静态堆积颗粒中的力链分布. 物理学报,57(8): 4667-4674.
[34]	唐辉明,葛云峰,张抒,等,2025.滑坡预测预报研究进展与挑战.中国科学基金,39(6):993-1005.
[35]	唐辉明,李长冬,胡伟,等,2022.重大滑坡启滑的物理机制是什么?.地球科学,47(10):3902-3903.
[36]	夏嘉诚,彭铭,景路,等,2025.粒径分布特征对水下颗粒柱坍塌过程影响.地球科学,50(10):3916-3928.
[37]	许强,汤明高,徐开祥,等,2008.滑坡时空演化规律及预警预报研究.岩石力学与工程学报,27(6):1104-1112.
[38]	许强,陈国庆,魏涛,等,2025.突发型滑坡形成过程中应力-滑动力-变形动态变化特征研究.岩石力学与工程学报,44(1):1-15.
[39]	郑虎,牛文清,毛无卫,等,2023.颗粒材料双轴压缩试验的光弹测试.同济大学学报(自然科学版),51(11):1719-1724.
[40]	朱武,张勤,朱建军,等,2022.特大滑坡实时监测预警与技术装备研发.岩土工程学报,44(7):1341-1350.
