Main Controlling Factors and Accumulation Models of Upper Paleozoic Coalbed Methane in Huanghua Depression
-
摘要: 黄骅坳陷构造格局复杂，上古生界煤层埋深、热演化程度和保存条件空间差异明显，煤层气富集规律及成藏类型尚不明确，制约了区域煤层气勘探开发部署.以研究区太原组、山西组主力含煤地层为对象，综合煤厚展布、煤岩煤质、镜质体反射率（Ro）平面分布、典型井埋藏-热演化史、构造演化及岩浆活动资料，分析沉积、构造深埋和岩浆作用对煤层气成藏的控制.太原组煤层厚度和横向连续性整体优于山西组，王官屯-乌马营和孔店-埕海地区为主要聚煤区；构造深埋作用导致区域性高成熟度及保存条件分异，多期构造反转则造成气藏调整，岩浆热事件不仅导致浅埋或构造高部位出现异常高熟，还能叠加改造深埋煤系.研究区煤层气富集受埋藏增温、构造调整和岩浆热改造共同控制，可划分为浅埋岩浆作用、构造深埋作用、多期构造反转作用和深埋岩浆作用4类成藏模式.本研究成果可为黄骅坳陷上古生界煤层气有利区优选与勘探潜力评价提供理论支撑.Abstract: The Huanghua Depression is characterized by complex structural units. The Upper Paleozoic coal seams show marked spatial variations in burial depth, thermal maturity, and preservation conditions, and the enrichment patterns and accumulation types of coalbed methane remain unclear. This study integrated coal-thickness distribution, coal petrographic and coal-quality characteristics, plane distribution of vitrinite reflectance (Ro), burial-thermal evolution histories of typical wells, tectonic evolution, and borehole evidence of magmatic rocks to analyze the controls of sedimentation, tectonic deep burial, and magmatism on coalbed methane accumulation. The coal thickness and lateral continuity of the Taiyuan Formation are generally better than those of the Shanxi Formation, and the Wangguantun-Wumaying and Kongdian-Chenghai areas are the main coal-accumulation zones. Tectonic deep burial resulted in regional high maturity and differentiation of preservation conditions; multi-stage tectonic inversion caused reservoir adjustment; and magmatic thermal events led to abnormally high maturity in shallow-burial areas or structural highs, and could further modify deeply buried coal measures. Coalbed methane enrichment in the study area is jointly controlled by burial heating, tectonic adjustment, and magmatic thermal modification. Four accumulation models are identified: shallow-burial magmatic model, tectonic deep-burial model, multi-stage tectonic inversion model, and deep-burial magmatic model. This study provides a theoretical basis for favorable area selection and exploration potential evaluation of Upper Paleozoic CBM in the Huanghua Depression.
-
图 1 黄骅坳陷构造位置及上古生界地层综合柱状图（据刘海涛等，2026）
Fig. 1. Tectonic location of the Huanghua Depression and composite stratigraphic column of the Upper Paleozoic
图 2 黄骅坳陷山西组（a）和太原组（b）煤层厚度平面分布图
Fig. 2. Plane distribution of coal thickness in the Shanxi (a) and Taiyuan (b) formations of the Huanghua Depression
图 3 煤中显微组分类型及赋存样式
a.GT1H井，3 642 m，结构镜质体；b.GT1H井，3 650 m，均质镜质体；c.GT1H井，3 710 m，基质镜质体和碎屑镜质体；d.GT1H井，3 642 m，碎屑惰质体；e.GT1H井，3 710 m，碎屑惰质体；f.GT1H井，3 650 m，半丝质体；g.GT1H井，3 642 m，角质体；h.GT1H井，3 710 m，树脂体；i.GT1H井，3 711 m，孢子体
Fig. 3. Maceral types and occurrence patterns of Upper Paleozoic coals in the Huanghua Depression
图 4 黄骅坳陷上古生界煤储层孔隙结构扫描电镜特征
a.有机质、高岭石黏土及有机质孔隙；b.有机质、有机质孔隙及孔隙中充填的高岭石黏土、石英等矿物；c.有机质、有机质孔隙、有机质裂缝及孔缝中充填的高岭石黏土和方解石；d.有机质、有机质裂缝及裂缝中充填的高岭石黏土；e.碎屑颗粒、有机质、黏土矿物及微孔缝；f.碎屑颗粒、黏土矿物、有机质及微孔缝
Fig. 4. Scanning electron microscope characteristics of pore-fracture structures in Upper Paleozoic coal reservoirs of the Huanghua Depression
图 7 黄骅坳陷上古生界典型井埋藏‒热演化史模拟图
a.黄骅坳陷南部WS1井；b.黄骅坳陷北部HG1井
Fig. 7. Burial-thermal evolution histories of typical Upper Paleozoic wells in the Huanghua Depression
图 8 黄骅坳陷大港探区石炭‒二叠系Ro平面分布图
Fig. 8. Plane distribution map of Carboniferous-Permian Ro in Dagang exploration area of Huanghua Depression
图 9 黄骅坳陷上古生界煤系Ro与埋深关系
Fig. 9. Relationship between vitrinite reflectance and burial depth of Upper Paleozoic coal-bearing strata in the Huanghua Depression
图 10 黄骅坳陷上古生界煤层气成藏模式图
a.浅埋岩浆作用型；b.构造深埋作用型；c.多期构造反转作用型；d.深埋岩浆作用型；e.综合成藏模式
Fig. 10. Coalbed methane accumulation models of the Upper Paleozoic in the Huanghua Depression
表 1 黄骅坳陷上古生界煤岩煤质参数特征
Table 1. Characteristics of coal quality parameters of Upper Paleozoic coal rock in Huanghua Depression
层位 样品数 Mad(%) Ⅴad(%) Aad(%) FCad(%) 镜质组(%) 惰质组(%) 壳质组(%) Ro(%) 山西组 10 0.58 18.86 17.09 63.47 66.12 26.48 7.39 0.55~3.73 太原组 10 1.05 20.03 21.21 57.71 73.62 18.32 8.06 0.86~1.21
下载: 导出CSV
表 2 黄骅坳陷上古生界煤储层孔隙结构
Table 2. Pore-structure parameters of Upper Paleozoic coal reservoirs in the Huanghua Depression
层位 低温N2吸附 低温CO2吸附 比表面积
(m2/g)孔体积
(cm3/g)平均孔径
（nm）比表面积
(m2/g)孔体积
(cm3/g)平均孔径
（nm）山西组 2.95 0.016 07 18.77 57.52 0.017 08 0.62 太原组 3.50 0.031 02 42.11 40.20 0.011 72 0.61
下载: 导出CSV
-
Bo, S. S., Zhang, J. N., Han, G. M., et al., 2022. Differential Evolution of South and North Structure in Huanghua Depression. Bulletin of Science and Technology, 38(1): 20-25 (in Chinese with English abstract). Chang, J., Chen, S. Y., Wang, Q., et al., 2021. Sedimentary Sequence and Coal Accumulation Model of Barrier Coastal System under the Background of Epicontinental Sea: A Case Study of Late Paleozoic Taiyuan Formation in Bohai Bay Area. Coal Geology & Exploration, 49(4): 123-133 (in Chinese with English abstract). Cheng, Q. M., 2017. Sedimentary Characteristics and Evolution of Upper Paleozoic in Huanghua Depression (Dissertation). China University of Petroleum (East China), Qingdao (in Chinese with English abstract). Gong, X., Wang, Y. B., Yu, Y., 2022. Geochemical Characteristics and Hydrocarbon Generation Characteristics of Upper Paleozoic Coal Measures Source Rocks in Huanghua Depression, Bohai Bay Basin: Case Study of Dagang Exploration Area. Natural Gas Geoscience, 33(6): 1013-1024 (in Chinese with English abstract). He, J., Wang, B. H., Lu, Z. L., 2023. Experimental Study on the Effect of Magma Intrusion and Temperature on the Pore Structure of Coal. Energy, 284: 128688. https://doi.org/10.1016/j.energy.2023.128688 Hou, Z. S., 2020. Research on Sequence, Sedimentology and Favorable Reservoir of Carboniferous-Permian in Huanghua Depression (Dissertation). China University of Petroleum (East China), Qingdao (in Chinese with English abstract). Hu, H. J., Jiang, Y. L., Liu, J. D., et al., 2018. Gas Generation Evolution and Potential Analysis of Carboniferous-Permian Coal-Measured Source Rocks in Dongpu Depression. Earth Science, 43(2): 610-621 (in Chinese with English abstract). Jin, F. M., Wang, X., Li, H. J., et al., 2019. Formation of the Primary Petroleum Reservoir in Wumaying Inner Buried-Hill of Huanghua Depression, Bohai Bay Basin, China. Petroleum Exploration and Development, 46(3): 521-529 (in Chinese with English abstract). Li, S. Z., Suo, Y. H., Zhou, L. H., et al., 2011. Pull-Apart Basins within the North China Craton: Structural Pattern and Evolution of Huanghua Depression in Bohai Bay Basin. Journal of Jilin University (Earth Science Edition), 41(5): 1362-1379 (in Chinese with English abstract). Li, W., Wu, Z. P., Liu, H., 2009. Mesozoic and Cenozoic Basin Evolution and Coal-Derived Gas Accumulation of Upper Paleozoic in the Area of Bohai Bay Basin. Petroleum Geology and Recovery Efficiency, 16(1): 13-16 (in Chinese with English abstract). Liu, H. T., Shen, C. B., Yu, H. T., et al., 2026. Special Geological Conditions, Genetic Types, and Significance of Petroleum Exploration in Low Exploration Degree Depressions of Bohai Bay Basin. Earth Science, 51(5): 1619-1635 (in Chinese with English abstract). Liu, N., Qiu, N. S., Chang, J., et al., 2017. Hydrocarbon Migration and Accumulation of the Suqiao Buried-Hill Zone in Wen'an Slope, Jizhong Subbasin, Bohai Bay Basin, China. Marine and Petroleum Geology, 86: 512-525. https://doi.org/10.1016/j.marpetgeo.2017.05.040. Liu, Q. Y., Zhang, R., Wang, M., et al., 2017. Physical Properties of Coal from Different Depths. Journal of China Coal Society, 42(8): 2101-2109 (in Chinese with English abstract). Pu, X. G., Dong, X. Y., Chai, G. Q., et al., 2024. Accumulation Conditions and Exploration Orientation of Coal Measure Gas in the Upper Paleozoic in Huanghua Depression. China Petroleum Exploration, 29(4): 60-70 (in Chinese with English abstract). Ren, J. Y., Liao, Q. J., Lu, G. C., et al., 2010. Deformation Framework and Evolution of the Huanghua Depression, Bohai Gulf. Geotectonica et Metallogenia, 34(4): 461-472 (in Chinese with English abstract). Wang, X., Li, Z., Zhu, R. F., et al., 2023. Study on Hydrocarbon Generation Characteristics of Carboniferous-Permian Coal-Measure Source Rocks in Huanghua Depression, Bohai Bay Basin. Special Oil & Gas Reservoirs, 30(4): 19-27 (in Chinese with English abstract). Wu, C. P., 2018. Study on Carboniferous-Permian Sequence Stratigraphy and Sedimentary Facies in South-Central Huanghua Depression (Dissertation). Northeast Petroleum University, Daqing (in Chinese with English abstract). Wu, C. R., 1992. Magmatic Thermal Metamorphism of Coal. Coal Geology & Exploration, (4): 24-30 (in Chinese). Wu, Y. P., Fu, L. X., Yang, C. Y., et al., 2002. Influence of Mesozoic Tectonic Evolution on Hydrocarbon Accumulation in Buried Hill in Huanghua Depression. Acta Petrolei Sinica, 23(2): 16-21 (in Chinese with English abstract). Xu, J. J., Jin, Q., Cheng, F. Q., et al., 2017. Advances and Crucial Issues on Secondary Hydrocarbon Generation of the Carboniferous-Permian Coal-Measure Source Rocks in Bohai Bay Basin. Petroleum Geology and Recovery Efficiency, 24(1): 43-49, 91 (in Chinese with English abstract). Yan, D. T., 2025. Comment: Hydrocarbon Accumulation Conditions and Enrichment Model in Deep Depression of Huanghua Depression. Bulletin of Geological Science and Technology, 44(3): 1 (in Chinese). Yang, R. Z., Liu, H. T., Li, H. J., et al., 2022. Accumulation Mechanism and Model of Coal Measure Derived Oil and Gas in the Deep Reservoir of Huanghua Depression, Bohai Bay Basin. Natural Gas Geoscience, 33(7): 1074-1090 (in Chinese with English abstract). Yu, Z. J., Jin, C., Tang, X., et al., 2024. Influence of Magma Intrusion and Contact Distance on Thermal Effects of Low-Temperature Oxidation Processes in Coal. Journal of China Coal Society, 49(12): 4873-4882 (in Chinese with English abstract). Zhai, M. G., 2019. Tectonic Evolution of North China Craton. Journal of Geomechanics, 25(5): 722-745 (in Chinese with English abstract). Zhang, J. N., Fu, L. X., Zhou, J. S., et al., 2019a. Macroscopic Distribution Characteristics and Evolution Process of Buried Hill in the Huanghua Depression, Bohai Bay Basin. Acta Geologica Sinica, 93(3): 585-596 (in Chinese with English abstract). Zhang, J. N., Zhou, J. S., Fu, L. X., et al., 2019b. Geological Characteristics and Process of Natural Gas Accumulation in Gangbei Buried Hill. Journal of China University of Mining & Technology, 48(5): 1078-1089 (in Chinese with English abstract). Zhang, J. N., Zhou, J. S., Xiao, D. Q., et al., 2019c. Control of the Mesozoic Tectonic Movement on the Hydrocarbon Generation and Evolution of Upper Paleozoic Coal-Measure Source Rocks in the Huanghua Depression, Bohai Bay Basin. Natural Gas Industry, 39(9): 1-10 (in Chinese with English abstract). Zhao, C. Y., Li, Y. X., Wang, J. F., et al., 2019. Genetic Types and Exploration Potential of Natural Gas in Bohai Bay Basin. Natural Gas Geoscience, 30(6): 783-789 (in Chinese with English abstract). Zhao, G. C., 2009. Metamorphic Evolution of Main Structural Units in North China Craton Basement and Discussion on Some Problems. Acta Petrologica Sinica, 25(8): 1772-1792 (in Chinese with English abstract). Zhou, L. H., Hua, S. J., Sun, C. N., et al., 2017. Geochemical Characteristics and Secondary Hydrocarbon Generation of Coal-Measure Source Rocks in Upper Paleozoic of Dagang Oilfield. Oil & Gas Geology, 38(6): 1043-1051 (in Chinese with English abstract). Zhu, Y. M., Qin, Y., Wang, M., et al., 2006. Tectonic Control on the Hydrocarbon-Generation Evolution of Permo-Carboniferous Coal in Huanghua Depression. Journal of China University of Mining & Technology, 35(3): 283-287 (in Chinese with English abstract). 薄尚尚, 张津宁, 韩国猛, 等, 2022. 黄骅坳陷南、北构造差异演化研究. 科技通报, 38(1): 20-25. 常嘉, 陈世悦, 王琼, 等, 2021. 陆表海背景下障壁海岸体系沉积层序及聚煤模式——以渤海湾地区晚古生代太原组为例. 煤田地质与勘探, 49(4): 123-133. 程秋萌, 2017. 黄骅坳陷上古生界沉积特征及沉积演化(硕士学位论文). 青岛: 中国石油大学(华东). 龚训, 王延斌, 于赟, 2022. 渤海湾盆地黄骅坳陷上古生界煤系烃源岩地球化学特征及生烃特性: 以大港探区为例. 天然气地球科学, 33(6): 1013-1024. 侯中帅, 2020. 黄骅坳陷石炭-二叠系层序、沉积及有利储层研究(博士学位论文). 青岛: 中国石油大学(华东). 胡洪瑾, 蒋有录, 刘景东, 等, 2018. 东濮凹陷石炭-二叠系煤系烃源岩生气演化及潜力分析. 地球科学, 43(2): 610-621. doi: 10.3799/dqkx.2017.604 金凤鸣, 王鑫, 李宏军, 等, 2019. 渤海湾盆地黄骅坳陷乌马营潜山内幕原生油气藏形成特征. 石油勘探与开发, 46(3): 521-529. 李三忠, 索艳慧, 周立宏, 等, 2011. 华北克拉通内部的拉分盆地: 渤海湾盆地黄骅坳陷结构构造与演化. 吉林大学学报(地球科学版), 41(5): 1362-1379. 李伟, 吴智平, 刘华, 2009. 中、新生代渤海湾盆地区演化与上古生界煤成气成藏. 油气地质与采收率, 16(1): 13-16. 刘海涛, 沈传波, 于海涛, 等, 2026. 渤海湾盆地低勘探程度凹陷特殊地质条件、成因类型及油气勘探意义. 地球科学, 51(5): 1619-1635. doi: 10.3799/dqkx.2026.169 刘倩颖, 张茹, 王满, 等, 2017. 不同赋存深度煤的物性特征. 煤炭学报, 42(8): 2101-2109. 蒲秀刚, 董雄英, 柴公权, 等, 2024. 黄骅坳陷上古生界煤岩气成藏条件与勘探方向. 中国石油勘探, 29(4): 60-70. 任建业, 廖前进, 卢刚臣, 等, 2010. 黄骅坳陷构造变形格局与演化过程分析. 大地构造与成矿学, 34(4): 461-472. 王鑫, 李政, 朱日房, 等, 2023. 渤海湾盆地黄骅坳陷石炭系-二叠系煤系烃源岩生烃特征研究. 特种油气藏, 30(4): 19-27. 吴成璞, 2018. 黄骅坳陷中南部石炭-二叠系层序地层学与沉积相研究(硕士学位论文). 大庆: 东北石油大学. 吴传荣, 1992. 煤的岩浆热变质作用. 煤田地质与勘探, (4): 24-30. 吴永平, 付立新, 杨池银, 等, 2002. 黄骅坳陷中生代构造演化对潜山油气成藏的影响. 石油学报, 23(2): 16-21. 徐进军, 金强, 程付启, 等, 2017. 渤海湾盆地石炭系-二叠系煤系烃源岩二次生烃研究进展与关键问题. 油气地质与采收率, 24(1): 43-49, 91. 严德天, 2025. 评论: 黄骅坳陷深凹区油气成藏条件与富集模式. 地质科技通报, 44(3): 1. 杨润泽, 刘海涛, 李宏军, 等, 2022. 渤海湾盆地黄骅坳陷深部煤系地层油气成藏机理与模式. 天然气地球科学, 33(7): 1074-1090. 于志金, 晋策, 汤旭, 等, 2024. 岩浆侵入与接触距离对煤低温氧化过程热效应的影响. 煤炭学报, 49(12): 4873-4882. 翟明国, 2019. 华北克拉通构造演化. 地质力学学报, 25(5): 722-745. 张津宁, 付立新, 周建生, 等, 2019a. 渤海湾盆地黄骅坳陷古潜山的宏观展布特征与演化过程. 地质学报, 93(3): 585-596. 张津宁, 周建生, 付立新, 等, 2019b. 港北潜山内幕天然气成藏地质特征与成藏过程. 中国矿业大学学报, 48(5): 1078-1089. 张津宁, 周建生, 肖敦清, 等, 2019c. 黄骅坳陷中生代构造运动对上古生界煤系烃源岩生烃演化的控制. 天然气工业, 39(9): 1-10. 赵国春, 2009. 华北克拉通基底主要构造单元变质作用演化及其若干问题讨论. 岩石学报, 25(8): 1772-1792. 赵长毅, 李永新, 王居峰, 等, 2019. 渤海湾盆地天然气成因类型与勘探潜力分析. 天然气地球科学, 30(6): 783-789. 周立宏, 滑双君, 孙超囡, 等, 2017. 大港油田上古生界煤系烃源岩地球化学特征与二次成烃. 石油与天然气地质, 38(6): 1043-1051. 朱炎铭, 秦勇, 王猛, 等, 2006. 黄骅坳陷石炭-二叠纪煤成烃演化的构造控制. 中国矿业大学学报, 35(3): 283-287. -
