Characteristics, Age, and Exploration Significance of Polymetallic Mineralized Skarns in the Super-Large Shizhushan Wollastonite Deposit in the Yichun-Xinyun Area of Jiangxi Province
-
摘要: 江西石竹山矿床（7 000万吨硅灰石）位于钦杭成矿带东段，是世界上最大的硅灰石矿床. 石竹山矿区中蒙山岩体与围岩碳酸盐岩地层接触带产出的矽卡岩中发育W-Sn-Cu-Mo多金属矿化现象，但其形成时代和成因研究较为薄弱. 基于石竹山矿床中多金属矿化矽卡岩的地质特征，通过对不同类型石榴子石开展原位微区U-Pb测年和主微量元素分析，以限定多金属矿化矽卡岩的形成年代，深化对矿床成因的认识，进一步指导找矿勘查. 矽卡岩中发育3种类型的石榴子石，分别为红棕色石榴子石（Grt-1），深棕色石榴子石（Grt-2）和黄绿色石榴子石（Grt-3），3种类型石榴子石均属于钙铁榴石-钙铝榴石固溶体系列，但Grt-1和Grt-2相对富铁而Grt-3相对富铝. Grt-2和Grt-3的U-Pb年龄分别为234.7±1.6 Ma和234.4±9.9 Ma，与矿区内广泛出露的蒙山岩体似斑状黑云母二长花岗岩的年龄一致. 研究表明，石竹山矿床硅灰石矿化和多金属矿化均发生于晚三叠世，二者均与蒙山岩体的岩浆活动具有密切的成因联系，除硅灰石外，石竹山矿区还具有较大的W-Sn-Cu-Mo多金属矿化潜力.Abstract: The Shizhushan deposit (70 millions tons of wollastonite) in Jiangxi is situated in the eastern section of the Qin-Hang metallogenic belt and is recognized as the largest wollastonite deposit in the world. Within this deposit, W-Sn-Cu-Mo polymetallic mineralization is present in the skarns located in the contact zone between the Mengshan granite and the surrounding carbonate rocks. However, research on the formation age and genesis of this mineralization is relatively limited. This paper conducts in situ U-Pb dating and trace element analyses of garnets from different generations to determine the age of formation of the polymetallic mineralized skarns. The findings aim to enhance the understanding of the deposit's genesis and provide further guidance for mineral exploration. Three types of garnets have developed in the skarn: the first type consists of reddish-brown garnet (Grt-1), the second type comprises dark-brown garnet (Grt-2), and the third type features yellowish-green garnet (Grt-3). All three types of garnet belong to the andradite to grossularite solid-solution series; however, Grt-1 and Grt-2 are relatively rich in iron, while Grt-3 is relatively rich in aluminum. The U-Pb ages of Grt-2 and Grt-3 are 234.7±1.6 Ma and 234.4±9.9 Ma, respectively, which align with the ages of the biotite monzogranite from the Mengshan complex, widely exposed in the mining area. This study indicates that both wollastonite mineralization and polymetallic mineralization in the Shizhushan deposit occurred during the Late Triassic and are closely associated with the intrusion of the Mengshan granite. In addition to wollastonite, the Shizhushan deposit also holds significant potential for W-Sn-Cu-Mo polymetallic mineralization.
-
图 1 （a）华南钦杭成矿带及邻区构造分区简图（据毛景文等，2011）；（b）石竹山地区地质图（王先广等，2019）
Fig. 1. (a) Geological map of the Qinghang Metallogenic Belt (after Mao et al., 2011); (b) Geological map of the Shizhushan area (Wang et al., 2019)
图 2 （a）蒙山地区石竹山硅灰石矿床矿区地质图；A-A’（b）与B-B’（c）勘探线剖面图（王先广等，2019）
Fig. 2. (a) Geological map of the Shizhushan wollastonite deposit, and representative cross sections (b, c) (Wang et al., 2019)
图 3 石竹山硅灰石矿床典型蚀变类型及矿物组合特征
a. 早矽卡岩阶段放射状硅灰石矿床，其中零星分布第一类型红棕色石榴子石（Grt-1）；b. 早矽卡岩阶段中Grt-1与辉钼矿；c. 石榴子石（Grt-1）-辉钼矿细脉穿插硅灰石矿石；d. 早矽卡岩阶段的硅灰石和石榴子石，其中第一类型红棕色石榴子石（Grt-1）主要分布在地层与岩体的接触带附近，而第二类型深棕色石榴子石（Grt-2）呈浸染状分布在硅灰石中；e.深棕色Grt-2围绕红棕色Grt-1生长；f. 第三类型黄绿色石榴子石（Grt-3）与方解石和斑铜矿紧密共生；矿物缩写：Bn.斑铜矿；Cal.方解石；Grt.石榴子石；Mo.辉钼矿；Wo.硅灰石
Fig. 3. Photographs showing typical alteration types and mineral assemblages of the Shizhushan wollastonite deposit
图 4 石竹山硅灰石矿床典型多金属矿化显微照片
a. 钨矿灯下，黄绿色荧光白钨矿与粗粒辉钼矿集合体紧密共生；b. 粗粒辉钼矿集合体；c. 辉钼矿与白钨矿和方解石共生；d. 冷阴极发光图像中，白钨矿包裹于Grt-1中；e. 黄铁矿与黄铜矿呈浸染状分布于矽卡岩中；f. 粗粒斑铜矿与Grt-3和石英紧密共生；矿物缩写：Bn. 斑铜矿；Cal. 方解石；Cpy. 黄铜矿；Grt. 石榴子石；Mo. 辉钼矿；Py. 黄铁矿；Sch. 白钨矿
Fig. 4. Typical photomicrographs showing the characteristics of the polymetallic mineralization in the Shizhushan wollastonite deposit
图 5 石竹山硅灰石矿床典型石榴子石矽卡岩TIMA图像
a.石榴子石矽卡岩薄片扫描图，揭示Grt-1和Grt-2的颜色区别；a1. 图a薄片的全片扫描BSE照片，揭示石榴子石矽卡岩的共生矿物组合；a2. Fe元素扫描图，指示Fe在Grt-1和Grt-2中的分布规律；b. 黄绿色石榴子石矽卡岩，其中含有大量发育环带的Grt-3和斑铜矿；b1. 图b对应石榴子石Fe元素面扫描图，指示石榴子石的震荡环带可能与Fe元素相关；b2. Grt-3钙铁榴石与透辉石、斑铜矿和方解石共生
Fig. 5. TIMA mineral maps of the granet skarns in the Shizhushan wollastonite deposit
图 6 石竹山硅灰石矿床典型石榴子石（a）三角分类图解（底图据Meinert et al., 2005）、Grt-1（b）、Grt-2（c）和Grt-3（d）稀土元素球粒陨石标准化配分曲线
Fig. 6. (a) Ternary diagram showing compositions of three types of garnets (after Meinert et al., 2005), Chondrite-normalized REE patterns of Grt-1 (b), Grt-2 (c), and Grt-3 (d)
-
Chen, C., Chen, S. B., Cheng, X. G., 2018. Geological Characteristics and Genesis of a Wollastonite Mineral Deposit in the Shizhushan-Zhangmuqiao, Mengshan Area of Jiangxi. Shanghai Land & Resources, 39(4): 19-24(in Chinese with English abstract). Chen, J., Halls, C., Stanley, C. J., 1992. Tin-Bearing Skarns of South China: Geological Setting and Mineralogy. Ore Geology Reviews, 7(3): 225-248. https://doi.org/10.1016/0169-1368(92)90006-7 Deng, X. D., Li, J. W., Luo, T., et al., 2017. Dating Magmatic and Hydrothermal Processes Using Andradite-Rich Garnet U-Pb Geochronometry. Contributions to Mineralogy and Petrology, 172(9): 71. https://doi.org/10.1007/s00410-017-1389-2 Huang, C., Wang, H., Yang, J. H., et al., 2019. SA01-a Proposed Zircon Reference Material for Microbeam U-Pb Age and Hf-O Isotopic Determination. Geostandards and Geoanalytical Research, 44(1): 103-123. https://doi.org/10.1111/ggr.12307 Jiang, S. Y., Zhao, K. D., Jiang, Y. H., et al., 2008. Characteristics and Genesis of Mesozoic A-Type Granites and Associated Mineral Deposits in the Southern Hunan and Northern Guangxi Provinces along the Shihang Belt, South China. Geological Journal of China Universities, 14(4): 496-509 (in Chinese with English abstract). Li, H. Y., Mao, J. W., Sun, Y. L., et al., 1996. Re-Os Isotopic Chronology of Molybdenites in the Shizhuyuan Polymetallic Tungsten Deposit, Southern Hunan. Geological Review, 42(3): 261-267(in Chinese with English abstract). Li, W. S., Ni, P., Wang, G. G., et al., 2020. A Possible Linkage between Highly Fractionated Granitoids and Associated W-Mineralization in the Mesozoic Yaogangxian Granitic Intrusion, Nanling Region, South China. Journal of Asian Earth Sciences, 193: 104314. https://doi.org/10.1016/j.jseaes.2020.104314 Li, W. S., Ni, P., Pan, J. Y., et al., 2021. Constraints on the Timing and Genetic Link of Scheelite- and Wolframite-Bearing Quartz Veins in the Chuankou W Ore Field, South China. Ore Geology Reviews, 133: 104122. https://doi.org/10.1016/j.oregeorev.2021.104122 Liu, Y. S., Hu, Z. C., Zong, K. Q., et al., 2010. Reappraisement and Refinement of Zircon U-Pb Isotope and Trace Element Analyses by LA-ICP-MS. Chinese Science Bulletin, 55(15): 1535-1546. https://doi.org/10.1007/s11434-010-3052-4 Lou, Y. L., Liu, X. H., Zeng, H., et al., 2024. Genesis of Xingfengshan Au-W Deposit in Central Hunan Province: Constraints from Hydrothermal Apatite U-Pb Dating and In Situ S Isotopes. Earth Science, 49(12): 4265-4277 (in Chinese with English abstract). Lu, Y. F., Ma, L. Y., Qu, W. J., et al., 2006. U-Pb and Re-Os Isotope Geochronology of Baoshan Cu-Mo Polymetallic Ore Deposit in Hunan Province. Acta Petrologica Sinica, 22(10): 2483-2492(in Chinese with English abstract). Ma, L. Y., Lu, Y. F., Qu, W. J., et al., 2007. Re-Os Isotopic Chronology of Molybdenites in Huangshaping Lead-Zinc Deposit, Southeast Hunan, and Its Geological Implications. Mineral Deposits, 26(4): 425-431(in Chinese with English abstract). Mao, J. W., Chen, M. H., Yuan, S. D., et al., 2011. Geological Characteristics of the Qinhang (or Shihang) Metallogenic Belt in South China and Spatial-Temporal Distribution Regularity of Mineral Deposits. Acta Geologica Sinica, 85(5): 636-658(in Chinese with English abstract). Meinert, L. D., Dipple, G. M., Nicolescu, S., 2005. World Skarn Deposits. In: Hedenquist, J. W., Thompson, J. F. H., Goldfarb, R. J., eds., Economic Geology 100th Anniversary Volume. Society of Economic Geologists, Colorado. Mezger, K., Hanson, G. N., Bohlen, S. R., 1989. U-Pb Systematics of Garnet: Dating the Growth of Garnet in the Late Archean Pikwitonei Granulite Domain at Cauchon and Natawahunan Lakes, Manitoba, Canada. Contributions to Mineralogy and Petrology, 101(2): 136-148. https://doi.org/10.1007/BF00375301 Qin, J. H., Wang, D. H., Li, C., et al., 2020. The Molybdenite Re-Os Isotope Chronology, in Situ Scheelite and Wolframite Trace Elements and Sr Isotope Characteristics of the Chuankou Tungsten Ore Field, South China. Ore Geology Reviews, 126: 103756. https://doi.org/10.1016/j.oregeorev.2020.103756 Sun, J. D., Li, H. L., Lu, F., et al., 2022. Geochemistry, Zircon U-Pb Ages, and Hf Isotopes of the Mengshan Rock Mass in Western Jiangxi Province and Their Geologic Implications. Geology and Exploration, 58(1): 96-106 (in Chinese with English abstract). Vermeesch, P., 2018. IsoplotR: a Free and Open Toolbox for Geochronology. Geoscience Frontiers, 9(5): 1479-1493. https://doi.org/10.1016/j.gsf.2018.04.001 Wang, X. G., Hu, Z. H., Yu, X., et al., 2019. Geological Characteristics and Prospecting Significance of the Shizhushan Superlarge Wollastonite Deposit in Mengshan, West Jiangxi Province. Acta Geoscientica Sinica, 40(2): 259-264 (in Chinese with English abstract). Wei, J., Ouyang, Y. P., Zou, J., et al., 2024. Genesis of the Mengshan Granitoid Complex in an Early Mesozoic Intracontinental Subduction Tectonic Setting in South China: Evidence from Zircon U-Pb-Hf Isotopes and Geochemical Composition. Minerals, 14(9): 854. https://doi.org/10.3390/min14090854 Wafforn, S., Seman, S., Kyle, J. R., et al., 2018. Andradite Garnet U-Pb Geochronology of the Big Gossan Skarn, Ertsberg-Grasberg Mining District, Indonesia. Economic Geology, 113(3): 769-778. https://doi.org/10.5382/econgeo.2018.4569 Xie, G. Q., Mao, J. W., Bagas, L., et al., 2018. Mineralogy and Titanite Geochronology of the Caojiaba W Deposit, Xiangzhong Metallogenic Province, Southern China: Implications for a Distal Reduced Skarn W Formation. Mineralium Deposita, 54(3): 459-472. https://doi.org/10.1007/s00126-018-0816-2 Xie, G. Q., Mao, J. W., Zhang, C. Q., et al., 2021. Triassic Deposits in South China: Geological Characteristics, Ore-Forming Mechanism and Ore Deposit Model. Earth Science Frontiers, 28(3): 252-270 (in Chinese with English abstract). Yang, M. G., Mei, Y. W., 1997. Characteristics of Geology and Mineralization in the Qinzhou-Hangzhou Paleoplate Juncture. Geology and Mineral Resources of South China, 3: 52-59 (in Chinese with English abstract). Yu, F., Shu, Q. H., Niu, X. D., et al., 2020. Composition of Garnet from the Xianghualing Skarn Sn Deposit, South China: Its Petrogenetic Significance and Exploration Potential. Minerals, 10(5): 456. https://doi.org/10.3390/min10050456 Zhang, P.H., Wang, X.G., Ding, F., et al. 2023. Characteristics and Geological Significance of Garnet in Shizhushan Wollastonite Deposit, Western Jiangxi Province. Acta Petrologica et Mineralogica, 42(4): 521-540 (in Chinese with English abstract). Zhang, X. B., Zhang, S. T., Chen, H. Y., et al., 2020. Application of Garnet U-Pb Dating in the Skarn Deposit: a Case Study of Gaoyishan W(-Cu) Deposit in Southeast Hubei Province. Earth Science, 45(3): 856-868 (in Chinese with English abstract). Zhao, P. L., Yuan, S. D., Mao, J. W., et al., 2016. Geochronological and Petrogeochemical Constraints on the Skarn Deposits in Tongshanling Ore District, Southern Hunan Province: Implications for Jurassic Cu and W Metallogenic Events in South China. Ore Geology Reviews, 78: 120-137. https://doi.org/10.1016/j.oregeorev.2016.03.004 Zhao, P. L., Yuan, S. D., Yuan, Y. B., 2018. Geochemical Characteristics of Garnet in the Huangshaping Polymetallic Deposit, Southern Hunan: Implications for the Genesis of Cu and W-Sn Mineralization. Acta Petrologica Sinica, 34(9): 2581-2597(in Chinese with English abstract). Zhao, W. W., Zhou, M. F., Dudka, S., 2023. In Situ U-Pb Dating of Garnet and Cassiterite from the Kanbauk W-Sn(-F) Skarn Deposit, Dawei Region, Southern Myanmar: New Insights on the Regional Sn-W Metallogeny in the Southeast Asian Tin Belt. Economic Geology, 118(5): 1219-1229. https://doi.org/10.5382/econgeo.5002 Zhong, Y. F., Ma, C. Q., She, Z. B., et al., 2011. U-Pb-Hf Isotope of Zircons, Geochemistry and Genesis of Mengshan Granitoids in Northwestern Jiangxi Province. Earth Science, 36(4): 703-720(in Chinese with English abstract). Zhou, J. H., Feng, C. Y., Li, D. X., 2017. Geochemistry of the Garnets in the Baiganhu W-Sn Orefield, NW China. Ore Geology Reviews, 82: 70-92. https://doi.org/10.1016/j.oregeorev.2016.11.019 陈铖, 陈四宝, 成绪光, 2018. 江西蒙山地区石竹山-樟木桥矿区硅灰石地质特征及成因探讨. 上海国土资源, 39(4): 19-24. 蒋少涌, 赵葵东, 姜耀辉, 等. 2008. 十杭带湘南-桂北段中生代A型花岗岩带成岩成矿特征及成因讨论. 高校地质学报, 14(4): 496-509. 李红艳, 毛景文, 孙亚利, 等. 1996. 柿竹园钨多金属矿床的Re-Os同位素等时线年龄研究. 地质论评, 42(3): 261-267. 娄元林, 刘贤红, 曾昊, 等, 2024. 湘中杏枫山金钨矿床成因: 热液磷灰石U-Pb定年和原位S同位素制约. 地球科学, 49(12): 4265-4277. 路远发, 马丽艳, 屈文俊, 等, 2006. 湖南宝山铜-钼多金属矿床成岩成矿的U-Pb和Re-Os同位素定年研究. 岩石学报, 22(10): 2483-2492. 马丽艳, 路远发, 屈文俊, 等, 2007. 湖南黄沙坪铅锌多金属矿床的Re-Os同位素等时线年龄及其地质意义. 矿床地质, 26(4): 425-431. 毛景文, 陈懋弘, 袁顺达, 等, 2011. 华南地区钦杭成矿带地质特征和矿床时空分布规律. 地质论评, 85(5): 636-658. 孙建东, 李海立, 陆凡, 等, 2022. 赣西蒙山岩体地球化学、锆石U-Pb年龄、Hf同位素特征及地质意义. 地质与勘探, 58(1): 96-106. 王先广, 胡正华, 余希, 等, 2019. 赣西蒙山地区石竹山超大型硅灰石矿床地质特征及找矿意义. 地球学报, 40(2): 259-264. 谢桂青, 毛景文, 张长青, 等, 2021. 华南地区三叠纪矿床地质特征、成矿规律和矿床模型. 地学前缘, 28(3): 252-270. 杨明桂, 梅勇文, 1997. 钦-杭古板块结合带与成矿带的主要特征. 华南地质与矿产, 3: 52-59. 张鹏浩, 王先广, 丁枫, 等, 2023. 赣西石竹山硅灰石矿床石榴子石特征及其地质意义. 岩石矿物学杂志, 42(4): 521-540. 张小波, 张世涛, 陈华勇, 等, 2020. 石榴子石U-Pb定年在矽卡岩矿床中的应用: 以鄂东南高椅山硅灰石(-铜)矿床为例. 地球科学, 45(3): 856-868. doi: 10.3799/dqkx.2019.061 赵盼捞, 袁顺达, 原垭斌, 2018. 湘南黄沙坪多金属矿床石榴子石地球化学特征及其对Cu与W-Sn复合成矿机理的指示. 岩石学报, 34(9): 2851-2597. 钟玉芳, 马昌前, 佘振兵, 等. 2011. 赣西北蒙山岩体的锆石U-Pb-Hf地球化学特征及成因. 地球科学, 36(4): 703-720. doi: 10.3799/dqkx.2011.071 -
