准噶尔盆地五彩湾凹陷基底火山岩储集性能及影响因素

余淳梅; 郑建平; 唐勇; 杨召; 齐雪峰

准噶尔盆地五彩湾凹陷基底火山岩储集性能及影响因素

1.
中国地质大学地球科学学院, 湖北武汉 430074
2.
新疆油田公司勘探开发研究院, 新疆克拉玛依 834000

基金项目:

国家自然科学基金项目 40273001

详细信息

作者简介:
余淳梅(1977-), 女, 助教, 从事岩石学、矿物学的教学及研究工作

中图分类号: P588.14
计量
- 文章访问数: 4124
- HTML全文浏览量: 1165
- PDF下载量: 14
- 被引次数: 0
出版历程
- 收稿日期: 2003-07-12
- 刊出日期: 2004-05-25

Reservoir Properties and Effect Factors on Volcanic Rocks of Basement beneath Wucaiwan Depression, Junggar Basin

1.
Faculty of Earth Sciences, China University of Geosciences, Wuhan 430074, China
2.
Research Institute of Exploration and Development, Xinjiang Oilfield Company, Karamay 834000, China

摘要

摘要: 含油气火山岩储层的研究为石油勘探开拓了更广阔的前景.利用岩心、薄片及成像测井(FMI)等手段对准噶尔盆地五彩湾凹陷基底火山岩储层的岩性特征、岩相分布、岩石物性(包括孔隙度和渗透率)进行了研究.该区含油气的火山岩主要为中石炭世巴山组(C₂b), 包括熔岩(安山岩和玄武岩)和火山碎屑岩.熔岩的平均孔隙度和渗透率分别为7.4 2 %和0.82× 10^-3 μm²; 火山角砾岩类的平均孔隙度和渗透率分别为9.84 %和0.33× 10^-3 μm₂.这些火山岩储集空间类型以次生孔、缝为主.与盆地内基底火山岩储集性能最好的腹部石西油田相比, 东部五彩湾凹陷的储集性能略差.火山喷发时的环境、火山岩的岩性岩相。
- 火山岩 /
- 基底古潜山 /
- 储集空间 /
- 准噶尔盆地
Abstract: The researches on oil- and gas-bearing volcanic rocks have largely developed the foreground of oil exploration. Types, facies distribution and physical properties (mainly porosity and permeability) of volcanic rock of the basement beneath the Wucaiwan depression, the eastern part of Junggar basin, are studied, based on the data of petrography and FMI. Oil- and gas-bearing volcanic rocks in this area belong to the Bashan group (C₂b). The rocks are mainly lava (including andesites and basalts) and pyroclastic ones. The average porosity and permeability are 7.42% and 0.82×10^-3 μm² in lavas, and are 9.84% and 0.33×10^-3 μm² in volcanic breccias respectively. The reservoir-spaces of the rocks are mainly composed of secondary pores and fissures. The reservoir property in the Wucaiwan area is slightly poorer than that of the basement beneath the Shixi oilfield, the center part of the basin, where there is the best reservoir property in volcanic rocks. The environment during the volcanic eruption, types and facies of the rocks, and subsequent modification play important roles on the reservoir properties of the basement rocks.
- volcanic rock /
- paleo-buried hill in basement /
- reservoir space /
- Junggar basin

HTML全文

图 1 五彩湾凹陷构造位置

Fig. 1. Structural map of Wucaiwan depression basement

下载: 全尺寸图片幻灯片

图 2 五彩湾凹陷基底火山岩岩石结构及孔隙特征

a.安山岩, 4×10（－）；b.玄武岩, 4×10（－）

Fig. 2. Characters of texture and pores in volcanic rocks from Wucaiwan depression basement

下载: 全尺寸图片幻灯片

图 3 准噶尔盆地五彩湾与腹部（陆梁）安山岩孔隙度（%）、渗透率（10^-3μm²）对比

Fig. 3. Comparison on porosity (%) and permeability (10^-3 μm²) of andesites between Luliang (Shixi) and Wucaiwan

下载: 全尺寸图片幻灯片

图 4 五彩湾凹陷不同火山岩孔隙度（%）、渗透率（10^-3 μm²）对比

Fig. 4. Comparison on porosity (%) and permeability (10^-3 μm²) in different volcanic rocks from Wucaiwan

下载: 全尺寸图片幻灯片

图 5 五彩湾凹陷基底火山岩岩相分布

[据李新兵（1997）内部报告修改]

下载: 全尺寸图片幻灯片

图 6 五彩湾凹陷基底火山岩中溶蚀孔与构造裂缝, 4× 10（-）

Fig. 6. Dissolved pore and structural fracture in volcanic rocks from Wucaiwan depression basement

下载: 全尺寸图片幻灯片

表 1 五彩湾与腹部陆梁区原生孔、缝统计对比

Table 1. Percent comparison on original pore and fracture between Wucaiwan and Luliang area

表 2 五彩湾火山岩储集空间类型、形成机理及主要分布

Table 2. Reservoir space types, genesis and distribution of volcanic rocks in Wucaiwan depression

参考文献(23)

Cai, Z.X., Chen, F.J., Jia, Z.Y., 2000. Types and tectonic evolution of Junggar basin. Earth Science Frontiers, 7(4): 431- 440(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DXQY200004018.htm
Guo, Q.J., Jiao, S.Q., Wan, Z.M., 1995. Petrology evaluation of volcanic rock reservoirs. Special Oil and Gas Reservoir, 2 (3): 6- 22(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TZCZ199503001.htm
Kuang, J., 1993. Terranes amalgamation and the forming of Junggar basin. Xinjiang Petroleum Geology, 14(2): 126- 131(in Chinese with English abstract).
Ma, Q., E, J.J., Li, W.H., et al., 2000. Reservoir evaluation of deep seated igneous rocks in Beipu region, Huanghua depression. Petroleum and Natural Gas Geology, 21(4): 337 - 344(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT200004012.htm
Prinon, J., 1995. Organic inclusions in salt. Part 2: Oil, gas and ammonium in inclusion from the carbon margin. Org. Geochem. , 23: 739- 750. doi: 10.1016/0146-6380(95)00057-L
Tao, K.Y., Yang, Z.L., Wang, L.B., et al., 1998. Oil-reservoir geological model of basalt in Minqiao, northern Jiangsu Province. Earth Science— Journal ofChina University of Geosciences, 23(3): 272- 276(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX803.011.htm
Wang, S.W., 1983. Petroleum geology of China. Petroleum Industry Press, Beijing, 300- 306(in Chinese).
Zhang, M.J., 2000. The characteristics of the Carboniferous traps in Junggar basin. Journal ofXinjiang Petroleum Institute, 12(1): 1- 5(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-XJSY200001000.htm
Zhang, M.J., Yang, P., 2000. The characteristic and analysis of reservoir-forming conditions of the Carboniferous oil and gas pools in Junggar basin. Journal ofXinjiang Petroleum Institute, 12(1): 8- 13(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-XJSY200002001.htm
Zhang, R.H., Xin, G.L., Liu, X.L., et al., 1994. Research and assessment of oil-gas potential of the Mesozoic era in the coastal of the Jiyang depression. Shandong Geology, 10 (1): 32- 39(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SDDI401.003.htm
Zhao, C.L., Meng, W.G., Jin, C.S., et al., 1999. Igneous rock and oil of Liaohe basin. Petroleum Industry Press, Beijing (in Chinese).
Zheng, J.P., Wang, F.Z., Cheng, Z.M., et al., 2000. Nature and evolution of amalgamated basement of Junggar basin, northwestern China: Sr-Nd isotope evidences of basement igneous rock. Earth Science— Journal ofChina University ofGeosciences, 25(2): 179- 185(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200002013.htm
蔡忠贤, 陈发景, 贾振远, 2000. 准噶尔盆地的类型和构造演化. 地学前缘, 7(4): 431- 440. doi: 10.3321/j.issn:1005-2321.2000.04.010
郭齐军, 焦守诠, 万智民, 1995. 火山岩储层的岩石学评价. 特种油气藏, 2(3): 6- 22. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ199503001.htm
况军, 1993. 地体拼贴与准噶尔盆地的形成. 新疆石油地质, 14(2): 126- 131. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSD199302002.htm
马乾, 鄂俊杰, 李文华, 等, 2000. 黄骅坳陷北堡地区深层火成岩储层评价. 石油与天然气地质, 21(4): 337- 344. doi: 10.3321/j.issn:0253-9985.2000.04.013
陶奎元, 杨祝良, 王力波, 等, 1998. 苏北闵桥玄武岩储油的地质模型. 地球科学——中国地质大学学报, 23(3): 272 - 276. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX803.011.htm
王尚文, 1983. 中国石油地质学. 北京: 石油工业出版社, 300 - 306.
张明洁, 2000. 准噶尔盆地石炭系圈闭特征. 新疆石油学院学报, 12(1): 1- 5. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSY200001000.htm
张明洁, 杨品, 2000. 准噶尔盆地石炭系(油)气藏特征及成藏条件分析. 新疆石油学院学报, 12(1): 8- 13. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSY200002001.htm
张日华, 信广林, 刘希林, 等, 1994. 济阳坳陷滨海地区中生界油气研究与评价. 山东地质, 10(1): 32- 39.
赵澄林, 孟卫工, 金春爽, 等, 1999. 辽河盆地火山岩与油气. 北京: 石油工业出版社.
郑建平, 王方正, 成中梅, 等, 2000. 拼合的准噶尔盆地基底: 基底火山岩Sr- Nd同位素证据. 地球科学——中国地质大学学报, 25(2): 179- 185. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200002013.htm
