Explanation of Faulted Structure in Yitong Basin Using Three-Directional Small Subdomain Filtering
-
摘要: 关于伊通盆地的断裂系统, 前人主要研究了边界断裂和盆地内的2号断裂的性质.为了精细地解译盆地内其他断裂的基本性质, 利用重力场小子域滤波及三方向小子域滤波技术圈定了14条断裂的平面位置, 给出了伊通盆地平面断裂构造格架并描述了主要断裂的重力场特征.在与其他地球物理资料(4条地震剖面和4条电阻率断面) 的对比分析中, 除证实了已有的断裂外, 还验证了利用三方向小子域滤波技术最新发现的一些断裂, 证明了该方法技术的有效性.阐述了14条断裂的基本性质, 重点研究了盆地内中央断裂的存在性和基本性质.指出中央断裂是与盆地东南缘和西北缘两条断裂同期形成的主要控盆构造; 2号断裂向西与西拉木伦断裂相连, 盆地南部(2号断裂以南) 基底与华北板块有关, 北部则属于东北微陆块复合基底.Abstract: The predecessors mainly researched properties of boundary faults and secondary fault of the faulted system in Yitong basin.In order to explain the characteristics of other faults in this basin, the paper obtains the locations of 14 faults, rebuilds faulted structure pattern curve of this basin and describes the charateristics of gravity field of main faults using the techniques of small subdomain filtering and three-directional small subdomain filtering.The comparison with other physical geography data (4 seismic profiles and 4 electrical resistivity sections) proves that the new found faults by the three-directional small subdomain filtering are existent and ensures that the techniques used in this paper are valid.In the paper, we expatiate on the characteristics of 14 faults and mainly study the existence and property of mid-faults.The mid-faults with boundary faults of this basin are main faulted structure that controls the whole basin and formed in geologic epoch.The secondary faulted structure joints Xilamulun faulted structure and the basal of the south part of this basin (the south of the secondary fault) is related to Huabei plate, while the north of it is compound basal of Dongbei small plates.
-
图 1 伊通盆地构造简图(王永春, 2001; 李献甫等, 2002; 李本才等, 2003)
①莫里青凹陷; ②马鞍山断阶带; ③尖山隆起带; ④大南凹陷; ⑤五星构造带; ⑥梁家构造带; ⑦新安堡凹陷; ⑧万昌构造带; ⑨太平凹陷; ⑩孤店斜坡带; (1) 辽东河断裂; (2) 2号断裂; (3) 第二松花江断裂
Fig. 1. Geological structural map of the Yitong basin
图 6 利用地震剖面确定的断裂(断面位置见图 5)
a.Z1线地震剖面; b.Z2线地震剖面; c.Z3线地震剖面; d.Z4线地震剖面
Fig. 6. Location of faulted structures based on seismic profile
图 7 利用CEMP剖面二维反演电阻率断面图确定的断裂(断面位置见图 5)
a.D1线电阻率断面; b.D2线电阻率断面; c.D3线电阻率断面; d.D4线电阻率断面
Fig. 7. Location of faulted structures based on electrical resistivity sections inversed by CEMP profile
-
Chen, F. J., Zhao, H. L., Chen, Z. N., et al., 1996. Structural characteristics and geodynamic setting of Mesozoic andCenozoic extensional basins in eastern China. EarthScience—Journal of China University of Geosciences, 21 (4): 357-365 (in Chinese with English abstract). Dong, H. M., 2002. The property and evolution of boundary faults of Yitong graben. Journal of Geomechanics, 8 (1): 35-42 (in Chinese with English abstract). Hu, G. S., 2003. Digital signal processing. Tsinghua Univer-sity Press, Beijing, 363-375 (in Chinese). Li, B. C., Liu, H. Y., Du, H. X., et al., 2003. The petroleumsystemand accumulation in Yitong basin. China Petro-leum Exploration, 8 (3): 38-44 (in Chinese with Eng-lish abstract). Li, X. F., Chen, Q. M., Zhang, X. H., et al., 2002. The Yitonggraben: The structural features and evolution of a strike-slip fault basin. Petroleum Geology & Experiment, 24 (1): 19-24 (in Chinese with English abstract). Rao, K. R., Yip, P., 1990. Discrete cosine transfrom: Algo-rithms, advantages and applications. Academic Press, New York. Sun, D. Y., Wu, F. Y., Zhang, Y. B., et al., 2004. The finalclosing ti me of the west Lamulun River-Changchun-Yanji plate suture zone: Evidence from the Dayushangranitic pluton, Jilin Province. Journal of Jilin Univer-sity (Earth Science Edition), 34 (2): 174-181 (in Chi-nese with English abstract). Sun, X. M., Long, S. X., Zhang, M. S., et al., 2006. Discov-ery and ti ming of major thrustbelt in Jiamusi-Yitongfault zone. Oil & Gas Geology, 27 (5): 637-643 (inChinese with English abstract). Wan, T. F., 1995. Evolution of Tancheng-Lujiang fault zoneand paleostress fields. Earth Science—Journal of Chi-na University of Geosciences, 20 (5): 526-534 (in Chi-nese with English abstract). Wang, Y. C., 2001. The petroleum system and hydrocarbon accumulation in Yitong graben. Petroleum Industry Press, Beijing, 14-16 (in Chinese). Yang, G. Y., 1995. A newtechnique for potential-field data pro-cessing: Small subdomain filtering. Oil Geophysical Prospec-ting, 30 (2): 240-244 (in Chinese with English abstract). Zhang, F. X., Meng, L. S., Zhang, F. Q., et al., 2006. A newmethod for spectral analysis of the potential field andconversion of derivative of gravity-anomalies: Cosinetransform.Chinese J. Geophys., 49 (1): 244-248 (inChinese with English abstract). Zhang, F. X., Zhang, F. Q., Meng, L. S., et al., 2005. Usingcosine transformfor forward modeling and inversion ofgravitational anomaly on densityinterface. Oil Geophys-ical Prospecting, 40 (5): 598-602 (in Chinese withEnglish abstract). Zhang, F. X., Zhang, F. Q., Liu, C., et al., 2007a. Atechnique for elaborate explanation of faulted structures: Three-direc-tional small subdomain filtering. Chinese J. Geophys., 50 (5): 1543-1550 (in Chinese with English abstract). Zhang, F. X., Zhang, F. Q., Meng, L. S., et al., 2007b. Mag-netic potential spectrumanalysis and calculating methodof magnetic anomaly derivatives based on discrete cosinetransform. Chinese J. Geophys., 50 (1): 297-304 (inChinese with English abstract). 陈发景, 赵海玲, 陈昭年, 等, 1996. 中国东部中、新生代伸展盆地构造特征及地球动力学背景. 地球科学——中国地质大学学报, 21 (4): 357-365. 董亨茂, 2002. 伊通地堑边界断裂的性质与演化. 地质力学学报, 8 (1): 35-42. doi: 10.3969/j.issn.1006-6616.2002.01.004 胡广书, 2003. 数字信号处理. 北京: 清华大学出版社, 363-375. https://cdmd.cnki.com.cn/Article/CDMD-11412-2005066063.htm 李本才, 刘鸿友, 杜怀旭, 等, 2003. 伊通盆地含油气系统与油气藏. 中国石油勘探, 8 (3): 38-44. doi: 10.3969/j.issn.1672-7703.2003.03.008 李献甫, 陈全茂, 张学海, 等, 2002. 伊通地堑——走滑断陷盆地的构造特征及演化. 石油实验地质, 24 (1): 19-24. doi: 10.3969/j.issn.1001-6112.2002.01.003 孙德有, 吴福元, 张艳斌, 等, 2004. 西拉木伦河-长春-延吉板块缝合带的最后闭合时间——来自吉林大玉山花岗岩体的证据. 吉林大学学报(地球科学版), 34 (2): 174-181. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200402003.htm 孙晓猛, 龙胜祥, 张梅生, 等, 2006. 佳木斯-伊通断裂带大型逆冲构造带的发现及形成时代. 石油与天然气地质, 27 (5): 637-643. doi: 10.3321/j.issn:0253-9985.2006.05.008 万天丰, 1995. 郯庐断裂带的演化与古应力场. 地球科学——中国地质大学学报, 20 (5): 526-534. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX505.008.htm 王永春, 2001. 伊通地堑含油气系统与油气藏. 北京: 石油工业出版社, 14-16. 杨高印, 1995. 位场数据处理的一项新技术——小子域滤波法. 石油地球物理勘探, 30 (2): 240-244. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ199502011.htm 张凤旭, 孟令顺, 张凤琴, 等, 2006. 重力位谱分析及重力异常导数换算新方法——余弦变换. 地球物理学报, 49 (1): 244-248. doi: 10.3321/j.issn:0001-5733.2006.01.031 张凤旭, 张凤琴, 孟令顺, 等, 2005. 基于余弦变换的密度界面重力异常正反演研究. 石油地球物理勘探, 45 (5): 598-602. doi: 10.3321/j.issn:1000-7210.2005.05.021 张凤旭, 张凤琴, 刘财, 等, 2007a. 断裂构造精细解释技术——三方向小子域滤波. 地球物理学报, 50 (5): 1543-1550. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX200705030.htm 张凤旭, 张凤琴, 孟令顺, 等, 2007b. 基于离散余弦变换的磁位谱分析及磁异常导数计算方法. 地球物理学报, 50 (1): 297-304. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX200701036.htm
