Lithologic Constitution and Its Control on Reservoir Development on Penglai 9-1 Buried Hill, Bohai Sea Basin
-
摘要: PL9-1潜山油藏是渤海湾盆地储量最大的古潜山油气藏之一，探明储量过亿吨.该油藏发育于庙西北凸起鞍部的中生界花岗岩侵入体顶部.凸起端部变质岩中没有油气发现.油气的分布受岩性控制明显.综合岩心观察、薄片鉴定、X粉晶衍射以及常量元素分析等技术手段，通过对比不同岩石类型的矿物组成、储集空间类型及发育程度，探讨了岩性组成对储层发育的控制作用.研究表明，变质岩中裂缝和孔隙均不发育，不能形成有效储层.花岗岩主要储集空间类型为孔隙-裂缝型，总体具有从砂质风化带→砾质风化带→裂缝带→基岩带，储集空间组合类型从孔隙→孔隙+裂缝→裂缝→不太发育的微裂缝的变化特征.储层厚度大，成层性强，可形成有效的规模性储层.花岗岩与变质岩的矿物组成差异控制了研究区优质储层的发育.变质岩中长石含量极低，不能形成溶蚀孔隙，较高含量(30%~50%)的片状矿物使其在应力作用下易发生塑性变形，不易产生裂缝.花岗岩具有很高的长石含量和含量很低的片状矿物，不仅容易被风化并产生溶蚀孔隙，而且易于发生脆性变形形成裂缝.Abstract: A new oil field with a reserve of more than 100 million tons has been found in the Penglai 9-1 buried hill, consisting of Paleoproterozoic metamorphic rocks and Yanshan granites. The granites surrounded by Paleoproterozoic metamorphic rocks are distributed in central valley floor of the buried hill. The oil pool mainly accumulates in the reservoirs of granite weathered crust located in the valley floor of the buried hill. The granites can be classified into granodirorite and adamellite. Paleoproterozoic metamorphic rocks mainly consist of phyllite, schist, metasandstone, quartzite and mylonite. Although both metamorphic rocks and granites have experienced similar weathering and deformation, differences in mineral constitution, mechanical property and weathering ways between metamorphic rocks and granites result in alternative development of high quality reservoirs in the granites. The reservoirs in metamorphic rocks belong to porosity types and development of secondary porosity is quite limited, no effective reservoirs may be formed in the metamorphic rocks. The reservoirs in granites are characterized by development of porosity and fissure, high quality reservoirs mainly develop in the sandy, pebbly weathering zone and fissured zone, in which the reservoirs in fissured zone are the thickest. Except for intensity of hypergenic karstification and tectonic deformation, lithologic constitution and lithofacies of the granites play a controlling role in development of high quality reservoirs in granite weathered crust. The factors such as weathered intensity, deformation, lithologic constitution and lithofacies, etc. contribute to vertical zonation characteristics of weathered crust reservoir at the granite buried hill, the reservoir types changed from porosity to fissure from the top of the weathered crust to the bottom. The various secondary porosity and fissure are the most important reservoir spaces in buried hill granite reservoirs.
-
Key words:
- Penglai 9-1 oil field /
- metamorphic rock /
- granite /
- lithologic constitution /
- reservoir
-
图 1 研究区位置与地质要素
a.研究区位置; b.研究区岩性、油藏与井位分布
Fig. 1. Location and geological elements of the study area
图 4 PL9-1油藏典型岩石薄片镜下照片
a.花岗闪长岩及其斜长石中的环带构造; b.二长花岗岩; c.钾长花岗岩; d.绢云千枚岩; e.变质砂岩和变余砂状结构; f.云母石英片岩.Q.石英; Kfs.钾长石; Pl.斜长石; Bio.黑云母; Ser.绢云母; Epi.绿帘石
Fig. 4. Microscopic photographs of typical rock in reservoir of the PL9-1 oil field
图 5 潜山岩石的QAP图解
1.富石英花岗岩；2.碱长花岗岩；3a.花岗岩；3b.花岗岩(二长花岗岩)；4.花岗闪长岩；5.英云闪长岩、斜长花岗岩；6*.碱长石英正长岩；7*.石英正长岩；8*.石英二长岩；9*.石英二长闪长岩；10*.石英闪长岩、石英辉长岩、石英斜长岩
Fig. 5. QAP diagram of rocks from the buried hill
图 8 变质岩中的次生孔隙和裂缝
a.变质砂岩中的次生生溶孔；b.片岩中的次生溶孔；c.石英岩中的显微裂缝；d.斜长石蚀变形成的次生溶孔, 斜长石蚀变成高岭土和绢云母、蚀变强烈部位形成溶孔
Fig. 8. Secondary pores and fissures developing in the metamorphic rocks
图 9 各风化壳亚带储层孔隙度分布直方图
Fig. 9. Distribution histogram of reservoir porosity in different sub-zone of weathering crust
-
Chen, W.L., Zhou, W., 2012. Important Exploration Areas in Petaliferous Basins—The Basement Hydrocarbon Reservoirs. Journal of Southwest Petroleum University(Science & Technology Edition), 34(5): 17-24 (in Chinese with English abstract). http://www.researchgate.net/publication/289398874_Important_exploration_areas_in_petaliferous_basins_the_basement_hydrocarbon_reservoirs Chen, Z.H., Mu, Z.B., Sun, Y., 2009. Characteristics and Development Strategy of Fracture-Cavern Basement Oil Reservoir in White Tiger Field, Vietnam. Sino-Global Energy, 14(9): 45-49 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/zwny200909008 Chung-Hsiang, P., 1982. Prtroleum in Basement Rocks. AAPG Bulletin, 66: 1597-1643. Deng, Y.H., 2011. Control of the Neotectonism along Tancheng-Lujiang Fracture Zone on Hydrocarbon Accumulation in the Eastern Bohai Sea. China Offshore Oil and Gas (Geology), 15(5): 301-305 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZHSD200105000.htm Deng, Y.H., Peng, W.X., 2009. Discovering Large Buried-Hill Oil and Gas Fields of Migmatitic Granite on Jinzhou 25-1S in Bohai Sea. China Offshore Oil and Gas, 21(3): 145-156 (in Chinese with English abstract). http://search.cnki.net/down/default.aspx?filename=ZHSD200903000&dbcode=CJFD&year=2009&dflag=pdfdown Ge, Z.D., Wang, X.Z., Zhu, M., et al., 2011. Reservoir Characteristics of Archean Magmatic Rocks in Dongying Sag. Lithologic Reservoirs, 23(4): 48-52 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YANX201104011.htm Gong, Z.S., 2010. Continued Exploration of Granitic-Reservoir Hydrocarbon Accumulations in China Offshore Basins. China Offshore Oil and Gas, 22(4): 213-220 (in Chinese with English abstract). http://www.cqvip.com/QK/96273A/20104/35354589.html Hou, L.H., Wang, J.H., Zou, C.N., et al., 2011. Controlling Factors of Weathering Volcanic Reservoir: An Example from the Carboniferous Kalagang Formation in Santanghu Basin. Acta Geologica Sinica, 85(4): 559-566 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZXE201104012.htm Khridtoforova, N.N., Khristoforov, A.V., 2006. Fluid Migration and Location of Fractured Layers in the Crystalline Basement by Temperature Logging in the Volga Region, Russia. Journal of Geochemical Exploration, 89(1-3): 187-190. doi: 10.1016/j.gexplo.2005.11.074 Koning, T., 2003. Oil and Gas Production from Basement Reservoirs: Examples from Indonesia, USA and Venezuela. Geological Society of London, Special Publication, 214(1): 83-92. doi: 10.1144/GSL.SP.2003.214.01.05 Li, Y., Yue, D.L., Wu, S.H., 2005. Reservoir Spaces and Influence Factors on Lower Palaeozoic Reservoir in Zhuangxi Buried-Hill. Journal of Oil and Gas Technology, 27(5): 694-698 (in Chinese with English abstract). Ma, L., Liu, Q.X., Zhang, J.L., et al., 2006. A Discussion of Exploration Potentials of Basement Hydrocarbon Reservoir. Natural Gas Industry, 26(1): 8-11 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TRQG200601003.htm Pan, J.G., Hao, F., Zhang, H.Q., et al., 2007. Formation of Granite and Volcanic Rock Reservoirs and Their Accumulation Model. Natural Gas Geoscience, 18(3): 380-385 (in Chinese with English abstract). Plotnikova, I.N., 2006. Nonconventional Hydrocarbon Targets in the Crystalline Basement, and the Problem of the Recent Replenishment of Hydrocarbon Reserves. Jouranl of Geochemical Exploration, 89(1-3): 335-338. doi: 10.1016/j.gexplo.2005.12.012 Song, B.R., Hu, Y.J., Bian, S.Z., et al., 2011. Reservoir Characteristics of the Crystal Basement in the Xinglongtai Buried-Hill, Liaohe Depression. Acta Petrolei Sinica, 32(1): 77-82 (in Chinese with English abstract). http://www.researchgate.net/publication/286716820_Reservoir_characteristics_of_the_crystal_basement_in_the_Xinglongtai_buried-hill_Liaohe_Depression Tan, Z.J., Xiang, H., Liu, F.K., et al., 2006. Testing Techniques for Complex Reservoirs and Their Application in Bohai Sea. China Offshore Oil and Gas, 18(4): 223-228 (in Chinese with English abstract). Wang, Z.H., 2006. Comprehensive Evaluation for Facture-Cavity Reservoirs in Damintun Sag. Special Oil and Gas Reservoirs, 13(1): 30-31 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TZCZ200601010.htm Wu, Z.Y., Guo, J.H., Wu, D.S., 2011. Fractured Characteristics of Metamorphic Reservoirs in Low Buried-Hill in West of Jing'anpu, Damintun Depression. Oil & Gas Geology, 22(4): 322-325 (in Chinese with English abstract). Yang, F., Xu, S.Y., 2011. Global Distribution and Hydrocarbon Accumulation Pattern of Basement Reservoirs. Special Oil and Gas Reservoirs, 18(1): 7-12 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TZCZ201101003.htm Yu, Y.X., Zhou, X.H., Xu, C.G., et al., 2011. Characteristics and Formation Mechanisms of the Cenozoic Faults in the Bohai Sea Waters. Oil & Gas Geology, 32(2): 273-279 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT201102019.htm Zeng, X.P., Mao, L., Wang, Y.J., et al., 2010. Buried Hill Lithology Identification and Reservoir Quality Forecast in Bonan Low Uplift. Special Oil and Gas Reservoirs, 17(3): 27-30 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TZCZ201003006.htm Zhang, J.G., Wang, J.K., Qin, L.B., et al., 2007. Characteristics of Metamorphic Buried Hill Reservoir in Sude'erte of Beir Fault Depression in Hailar Basin. Acta Petrolei Sinica, 28(4): 21-25, 30 (in Chinese with English abstract). http://www.researchgate.net/publication/292010134_Characteristics_of_metamorphic_buried_hill_reservoir_in_Sude'erte_of_Beir_Fault_Depression_in_Hailar_Basin Zhang, P., Hu, M., He, B., et al., 2011. Analysis on Main Controlling Factors of Archaeozoic Base Rock Reservoir in Dongying Depression. Fault-Block Oil & Gas Field, 18(1): 18-21 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DKYT201101007.htm Zhao, H.L., Liu, Z.W., Li, J., et al., 2004. Petrologic Characteristics of Igneous Rock Reservoirs and Their Research Orientation. Oil & Gas Geology, 25(6): 609-613 (in Chinese with English abstract). http://www.researchgate.net/publication/303227273_Petrologic_characteristics_of_igneous_rock_reservoirs_and_their_research_orientation Zhao, L.M., 2007. Characteristics and Controlling Factors of Fracture in Buried Hill in Damintun Sag, Liaohe Basin. Geological Science and Technology Information, 26(4): 37-41 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZKQ200704007.htm Zhou, X.H., Yu, Y.X., Tang, L.J., et al., 2010. Cenozoic Offshore Basin Architecture and Division of Structural Elements in Bohai Sea. China Offshore Oil and Gas, 22(5): 285-289 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZHSD201005002.htm 陈文玲, 周文, 2012. 含油气盆地重要勘探领域——基岩油气藏. 西南石油大学学报(自然科学版), 34(5): 17-24. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201205002.htm 陈志海, 牟珍宝, 孙钰, 2009. 越南白虎油田缝洞型基岩油藏特征与开发对策. 中外能源, 14(9): 45-49. https://www.cnki.com.cn/Article/CJFDTOTAL-SYZW200909014.htm 邓运华, 2001. 郯庐断裂带新构造运动对渤海东部油气聚集的控制作用. 中国海上油气(地质), 15(5): 301-305. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD200105000.htm 邓运华, 彭文绪, 2009. 渤海锦州25-1S混合花岗岩潜山大油气田的发现. 中国海上油气, 21(3): 145-156. doi: 10.3969/j.issn.1673-1506.2009.03.001 葛志丹, 王兴志, 朱萌, 等, 2011. 东营凹陷太古界岩浆岩储层特征研究. 岩性油气藏, 23(4): 48-52. doi: 10.3969/j.issn.1673-8926.2011.04.009 龚再升, 2010. 继续勘探中国近海盆地花岗岩储层油气藏. 中国海上油气, 22(4): 213-220. doi: 10.3969/j.issn.1673-1506.2010.04.001 侯连华, 王京红, 邹才能, 等, 2011. 火山岩风化体储层控制因素研究——以三塘湖盆地石炭系卡拉岗组为例. 地质学报, 85(4): 559-566. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201104012.htm 李燕, 岳大力, 吴胜和, 2005. 桩西下古生界潜山油藏储集空间类型及其控制因素. 石油天然气学报, 27(5): 694-698. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX2005S5004.htm 马龙, 刘全新, 张景廉, 等, 2006. 论基岩油气藏的勘探前景. 天然气工业, 26(1): 8-11. doi: 10.3321/j.issn:1000-0976.2006.01.003 潘建国, 郝芳, 张虎权, 等, 2007. 花岗岩和火山岩油气藏的形成及其勘探潜力. 天然气地球科学, 18(3): 380-385. doi: 10.3969/j.issn.1672-1926.2007.03.013 宋柏荣, 胡英杰, 边少之, 等, 2011. 辽河坳陷兴隆台潜山结晶基岩油气储层特征. 石油学报, 32(1): 77-82. doi: 10.3969/j.issn.1001-8719.2011.01.013 谭忠健, 项华, 刘富奎, 等, 2006. 渤海复杂油气藏测试技术研究及应用效果. 中国海上油气, 18(4): 223-228. doi: 10.3969/j.issn.1673-1506.2006.04.002 王志红, 2006. 大民屯凹陷缝洞性储层综合评价方法研究. 特种油气藏, 13(1): 30-31. doi: 10.3969/j.issn.1006-6535.2006.01.008 吴智勇, 郭建华, 吴东胜, 2001. 大民屯陷静安堡西侧低潜山变质岩储层裂缝发育特征. 石油与天然气地质, 22(4): 322-325. doi: 10.3321/j.issn:0253-9985.2001.04.008 杨飞, 徐守余, 2011. 全球基岩油气藏分布及成藏规律. 特种油气藏, 18(1): 7-12. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201101003.htm 余一欣, 周心怀, 徐长贵, 等, 2011. 渤海海域新生代断裂发育特征及形成机制. 石油与天然气地质, 32(2): 273-279. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201102019.htm 曾选萍, 茆利, 王玉静, 等, 2010. 渤南低凸起潜山岩性识别及储集性能预测. 特种油气藏, 17(3): 27-30. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201003006.htm 张吉光, 王金奎, 秦龙卜, 等, 2007. 海拉尔盆地贝尔断陷苏德尔特变质岩潜山油藏特征. 石油学报, 28(4): 21-25, 30. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200704003.htm 张攀, 胡明, 何冰, 等, 2011. 东营凹陷太古界基岩储层主控因素分析. 断块油气田, 18(1): 18-21. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT201101007.htm 赵海玲, 刘振文, 李剑, 等, 2004. 火成岩油气储层的岩石学特征及研究方向. 石油与天然气地质, 25(6): 609-613. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200406001.htm 赵立旻, 2007. 大民屯凹陷古潜山裂缝特征及控制因素. 地质科技情报, 26(4): 37-41. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200704007.htm 周心怀, 余一欣, 汤良杰, 等, 2010. 渤海海域新生代盆地结构与构造单元划分. 中国海上油气, 22(5): 285-289. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD201005002.htm -
