The Discovery of Earliest Middle Triassic C-Type Adakite from Langshan Area, Inner Mongolia and Its Tectonic Implications
-
摘要: 狼山构造带位于索伦缝合带南西,华北北缘及中亚造山带南缘的结合位置,是研究中亚造山带晚古生代-早中生代构造-岩浆演化及地球动力学背景的重要场所.在该地区新识别出中三叠世早期具有埃达克岩特征的扎拉山岩体,该岩体岩石类型主要为花岗闪长岩及二长花岗岩,LA-ICP-MS锆石U-Pb定年结果显示该岩体的形成时代介于244.9±1.2 Ma~244.1±2.3 Ma.地球化学特征表明,该岩体具有较高的SiO2(68.77%~72.58%)、Al2O3(14.48%~16.28%)、Sr(287×10-6~455×10-6,平均值413×10-6)含量及Sr/Y比值(46.07~95.50),较低的Y(4.07×10-6~8.01×10-6)、Yb(0.43×10-6~0.78×10-6)、Cr(5.18×10-6~8.92×10-6)、Ni(1.34×10-6~7.71×10-6)含量及Mg#值(35.54~41.64),Na2O/K2O比值为0.86~1.19,重稀土元素强烈亏损,轻重稀土元素分馏明显(26.45 <(La/Yb)N < 56.13),铕异常较弱(0.82 < δEu < 1.02),具有C型埃达克岩特征.锆石Hf同位素分析结果显示εHf(t)值介于2.5~8.9,对应的二阶模式年龄TDM2介于707~1 115 Ma,表明其源区主要为年轻地壳.结合区域地质背景,结果表明内蒙古狼山地区中三叠世早期具有C型埃达克岩特征的扎拉山岩体应为古亚洲洋闭合之后,西伯利亚板块与华北板块碰撞造山阶段的产物,为加厚的下地壳部分熔融形成.Abstract: The Langshan structural belt is located in southwest of the Solonker suture zone and as well as the junction between the northern margin of the North China Craton and southern of Central Asian orogenic belt, which is an ideal workplace to study on tectonic-magmatic evolution and geodynamics background from Late Paleozoic to Early Mesozoic. An earliest Middle Triassic pluton with Adakite characteristics was discovered in this study and was called as Zhalashan pluton. The main rock types of Zhalashan Pluton are granodiorite and monzogranite. LA-ICP-MS zircon U-Pb ages yield the formation time of Zhalashan pluton between 244.9±1.2 Ma and 244.1±2.3 Ma. Geochemical characteristics show that the Zhalashan granites are typical C-type adakite with high SiO2(68.77%-72.58%), Al2O3(14.48%-16.28%), Sr(287×10-6-455×10-6, 413×10-6 on average) content and high Sr/Y ratio (46.07-95.50), low Y(4.07×10-6-8.01×10-6), Yb(0.43×10-6-0.78×10-6), Cr(5.18×10-6-8.92×10-6), Ni(1.34×10-6-7.71×10-6) content and low Mg#(35.54-41.64), Na2O/K2O ratio between 0.86 and 1.19. In addition, it exhibits significant fractionation between LREE and HREE[26.45 < (La/Yb)N < 56.13] and is depleted in HREE with slight Eu anomaly (0.82 < δEu < 1.02). Zircon Hf isotopic data displays that εHf(t) values vary from 2.5~8.9, Hf model ages TDM2 vary from 707-1 115 Ma, indicating a juvenile crustal material. Together with regional geological background, the authors hold that the Zhalashan pluton resulted from collision between Siberia Craton and North China Craton after the closure of the Paleo-Asian Ocean which is the product of partial melting of the thickened lower crust.
-
Key words:
- Langshan area /
- earliest Middle Triassic /
- adakite /
- thickened crust /
- closure of the Paleo-Asian Ocean /
- petrology
-
图 1 狼山及相邻地区不同尺度区域地质简图
a.中亚造山带构造纲要图,据Şengör et al.(1993)、Jahn et al.(2004)修改;b.华北北缘晚古生代-早中生代侵入岩分布图,据Shi et al.(2014)修改;c.狼山地区地质简图,据Liu et al.(2016),以及中国地质调查局天津地质调查中心, 2016, 内蒙古1:5万查干呼舒庙幅、楚鲁庙幅、潮格幅、哈尔木格台幅、那仁宝力格公社幅、居力格台幅区域地质矿产调查报告修改.1.中-新元古代变质沉积岩;2.新元古代变质沉积岩;3.晚古生代沉积岩及火山岩;4.中-新生代沉积岩;5.中元古代变质侵入岩;6.早古生代侵入岩;7.晚古生代镁铁质侵入岩;8.晚古生代中-酸性侵入岩;9.早中生代花岗岩;10.获各琦断裂;11.其他断裂;12.韧性剪切带;13.扎拉山岩体地质简图位置;14.前人锆石U-Pb年龄采样点;15.本文锆石U-Pb年龄采样点
Fig. 1. Different scale geological maps in Langshan and adjacent area
图 6 扎拉山岩体岩石判别图解
a.SiO2-K2O图解,转引自(Maitre, 1989);b.A/CNK-A/NK图解,转引自Maniar and Piccoli(1989),乌和尔图花岗岩数据王文龙等(2017),下文图解相同
Fig. 6. Granitiods discrimination diagrams of the Zhalashan pluton
图 7 扎拉山岩体岩石稀土元素球粒陨石标准化配分图(a)及微量元素原始地幔蛛网图(b)
Fig. 7. Chondrite-normalized REE parterns (a) and primitive-mantle normalized trace element spider diagram (b) for Zhalashan pluton
图 8 扎拉山岩体埃达克岩判别图解
图a据Defant and Drummond(1990);图b据Martin(1986)
Fig. 8. Adakite discrimination diagram of Zhalashan pluton
图 9 扎拉山岩体花岗闪长岩εHf(t)-t图解
样品TW3306-1数据引自乌和尔图岩体,据王文龙等(2017)
Fig. 9. εHf(t)-t diagrams of Zhalashan granodiorite
图 11 扎拉山岩体SiO2-MgO(a)及SiO2-Cr图解(b)
Fig. 11. SiO2-MgO (a) and SiO2-Cr (b) diagrams of Zhalashan pluton
-
Castillo, P.R., 2012.Adakite Petrogenesis.Lithos, 134-135:304-316. https://doi.org/10.1016/j.lithos.2011.09.013 Cawood, P.A., Kröner, A., Collins, W.J., et al., 2009.Accretionary Orogens through Earth History.Geological Society, London, Special Publications, 318(1):1-36.https://doi.org/10.1144/sp318.1 doi: 10.1144/SP318.1 Chen, C.Y., Gao, Y.F., Wu, H.B., et al., 2016.Zircon U-Pb Chronology of Volcanic Rocks in the Hailaer Basin, NE China and Its Geological Implications.Earth Science, 41(8):1259-1274 (in Chinese with English abstract).https://doi.org/10.3799/dqkx.2016.104 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201608002 Chen, Y.P., Wei, C.J., Zhang, J.R., et al., 2015.Metamorphism and Zircon U-Pb Dating of Garnet Amphibolite in the Baoyintu Group, Inner Mongolia.Chinese Science Bulletin, 60(19):1698-1707.https://doi.org/10.1007/s11434-015-0890-0 http://www.cqvip.com/QK/86894X/201519/666357555.html Chiaradia, M., 2009.Adakite-Like Magmas from Fractional Crystallization and Melting-Assimilation of Mafic Lower Crust (Eocene Macuchi Arc, Western Cordillera, Ecuador).Chemical Geology, 265(3-4):468-487. https://doi.org/10.1016/j.chemgeo.2009.05.014 Chiaradia, M., 2015.Crustal Thickness Control on Sr/Y Signatures of Recent Arc Magmas:An Earth Scale Perspective.Scientific Reports, 5(1):8115. https://doi.org/10.1038/srep08115 Defant, M.J., Drummond, M.S., 1990.Derivation of Some Modern Arc Magmas by Melting of Young Subducted Lithosphere.Nature, 347(6294):662-665. https://doi.org/10.1038/347662a0 Gao, S., Rudnick, R.L., Yuan, H.L., et al., 2004.Recycling Lower Continental Crust in the North China Craton.Nature, 432(7019):892-897. https://doi.org/10.1038/nature03162 Ge, X.Y., Li, X.H., Chen, Z.G., et al., 2002.Geochemistry and Petrogenesis of Jurassic High Sr/Low Y Granitoids in Eastern China:Constrains on Crustal Thickness.Chinese Science Bulletin, 47(6):474-480 (in Chinese). http://www.onacademic.com/detail/journal_1000034848941010_4962.html Geng, J.Z., Li, H.K., Zhang, J., et al., 2011.Zircon Hf Isotope Analysis by Means of LA-MC-ICP-MS.Geological Bulletin of China, 30(10):1508-1513 (in Chinese with English Abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz201110004 Gong, W.B., Hu, J.M., Wu, S.J., et al., 2017.Deformation Characteristics, Timing and Significance of the Lang Shan Sinistral Strike-Slip Ductile Shear Zone in Inner Mongolia.Earth Science Fronitiers, 24(3):263-275 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201703024 Guo, S., Teng, X.J., Liu, Y., et al., 2017.Geochemistry, Chronology and Hf Isotope Features of the Permain Intermediate-Basic Volcanic Rocks in Wulanaobao Area, Urad Houqi, Inner Mongolia and Its Geological Significance.Journal of Geomechanics, 23(3):397-410 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlxxb201703007 Hu, J.M., Gong, W.B., Wu, S.J., et al., 2014.LA-ICP-MS Zircon U-Pb Dating of the Langshan Group in the Northeast Margin of the Alxa Block, with Tectonic Implications.Precambrian Research, 255:756-770. https://doi.org/10.1016/j.precamres.2014.08.013 Jahn, B.M., Windley, B., Natal'in, B., et al., 2004.Phanerozoic Continental Growth in Central Asia.Journal of Asian Earth Sciences, 23(5):599-603.https://doi.org/10.1016/s1367-9120(03)00124-x doi: 10.1016/S1367-9120(03)00124-X Jian, P., Liu, D.Y., Kröner, A., et al., 2010.Evolution of a Permian Intraoceanic Arc-Trench System in the Solonker Suture Zone, Central Asian Orogenic Belt, China and Mongolia.Lithos, 118(1-2):169-190. https://doi.org/10.1016/j.lithos.2010.04.014 Kay, R.W., Kay, S.M., 1993.Delamination and Delamination Magmatism.Tectonophysics, 219(1-3):177-189.https://doi.org/10.1016/0040-1951(93)90295-u doi: 10.1016/0040-1951(93)90295-U Kay, S.M., Ramos, V.A., Marquez, M., 1993.Evidence in Cerro Pampa Volcanic Rocks for Slab-Melting Prior to Ridge-Trench Collision in Southern South America.The Journal of Geology, 101(6):703-714.https://doi.org/10.1086/648269 http://www.jstor.org/stable/30065151 Li, S., Chung, S.L., Wilde, S.A., et al., 2017.Early-Middle Triassic High Sr/Y Granitoids in the Southern Central Asian Orogenic Belt:Implications for Ocean Closure in Accretionary Orogens.Journal of Geophysical Research:Solid Earth, 122(3):2291-2309.https://doi.org/10.1002/2017jb014006 doi: 10.1002/2017JB014006/pdf Li, S., Wang, T., Wilde, S.A., et al., 2012.Geochronology, Petrogenesis and Tectonic Implications of Triassic Granitoids from Beishan, NW China.Lithos, 134-135:123-145. https://doi.org/10.1016/j.lithos.2011.12.005 Li, S., Wilde, S.A., Wang, T., et al., 2016.Latest Early Permian Granitic Magmatism in Southern Inner Mongolia, China:Implications for the Tectonic Evolution of the Southeastern Central Asian Orogenic Belt.Gondwana Research, 29(1):168-180. https://doi.org/10.1016/j.gr.2014.11.006 Li, S.C., Zhang, L.Y., Li, P.C., et al., 2017.Discovery and Tectonic Implications of Early Triassic O-Type Adakite in Middle of Great Xing'an Range.Earth Science, 42(12):2117-2128 (in Chinese with English Abstract).https://doi.org/10.3799/dqkx.2017.136 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201712002 Liu, C.F., Wu, C., Zhu, Y., et al., 2015.Late Paleozoic-Early Mesozoic Magmatic History of Central Inner Mongolia, China: Implications for the Tectonic Evolution of the Xingmeng Orogenic Belt, the Southeastern Segment of the Central Asian Orogenic Belt.Journal of Asian Earth Sciences, Online.https: //doi.org/10.1016/j.jseaes.2015.09.011 Liu, C.H., Zhao, G.C., Liu, F.L., et al., 2017.Late Precambrian Tectonic Affinity of the Alxa Block and the North China Craton: Evidence from Zircon U-Pb Dating and Lu-Hf Isotopes of the Langshan Group.Precambrian Research, Online.https: //doi.org/10.1016/j.precamres.2017.10.019 Liu, J., Xi, A.H., Ge, Y.H., et al., 2015.LA-ICP-MS Zircon U-Pb Ages and Petrogenesis of Granodiorite in Mengguyingzi, Chifeng, Inner Mongolia.Geological Bulletin of China, 34(2):437-446 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD2015Z1020.htm Liu, J.F., Chi, X.G., Zhao, Z., et al., 2013.Zircon U-Pb Age and Petrogenetic Discussion on Jianshetun Adakite in Balinyouqi, Inner Mongolia.Acta Petrologica Sinica, 29(3):827-839 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201303007 Liu, M., Zhang, D., Xiong, G.Q., et al., 2016.Zircon U-Pb Age, Hf Isotope and Geochemistry of Carboniferous Intrusions from the Langshan Area, Inner Mongolia:Petrogenesis and Tectonic Implications.Journal of Asian Earth Sciences, 120:139-158. https://doi.org/10.1016/j.jseaes.2016.01.005 Liu, Y.S, Gao, S., Hu, Z.C., et al., 2010.Continental and Oceanic Crust Recycling-Induced Melt-Peridotite Interactions in the Trans-North China Orogen:U-Pb Dating, Hf Isotopes and Trace Elements in Zircons from Mantle Xenoliths.Journal of Petrology, 51(1-2):537-571. https://doi.org/10.1093/petrology/egp082 Ludwig, K., 2003.Isoplot/Ex, A Geochronological Toolkit for Microsoft Excel.version 3.00.Berkeley Geochronology Centre, Berkeley. Ma, S.W., Liu, C.F., Xu, Z.Q., et al., 2017.Geochronology, Geochemistry and Tectonic Significance of the Early Carboniferous Gabbro and Diorite Plutons in West Ujimqin, Inner Mongolia.Journal of Earth Science, 28(2):249-264. https://doi.org/10.1007/s12583-016-0912-2 Maitre, R.W.L., 1989.A Classification of Igneous Rocks and Glossary of Terms:Recommendations of the International Union of Geological Sciences Subcommission on the Systematics of Igneous Rocks.Blackwell Scientific, Oxford. Maniar, P.D., Piccoli, P.M., 1989.Tectonic Discrimination of Granitoids.Geological Society of America Bulletin, 101(5):635-643.https://doi.org/10.1130/0016-7606(1989)101<0635:tdog>2.3.co; 2 doi: 10.1130/0016-7606(1989)101<0635:TDOG>2.3.CO;2 Martin, H., 1986.Effect of Steeper Archean Geothermal Gradient on Geochemistry of Subduction-Zone Magmas.Geology, 14(9):753.https://doi.org/10.1130/0091-7613(1986)14<753:eosagg>2.0.co; 2 doi: 10.1130/0091-7613(1986)14<753:EOSAGG>2.0.CO;2 Rapp, R.P., Watson, E.B., 1995.Dehydration Melting of Metabasalt at 8-32 kbar:Implications for Continental Growth and Crust-Mantle Recycling.Journal of Petrology, 36(4):891-931. https://doi.org/10.1093/petrology/36.4.891 Şengör, A.M.C., Natal'in, B.A., Burtman, V.S., 1993.Evolution of the Altaid Tectonic Collage and Palaeozoic Crustal Growth in Eurasia.Nature, 364(6435):299-307.https://doi.org/10.1038/364299a0 doi: 10.1038-364299a0/ Shi, X.J., Wang, T., Zhang, L., et al., 2014.Timing, Petrogenesis and Tectonic Setting of the Late Paleozoic Gabbro-Granodiorite-Granite Intrusions in the Shalazhashan of Northern Alxa:Constraints on the Southernmost Boundary of the Central Asian Orogenic Belt.Lithos, 208-209:158-177. https://doi.org/10.1016/j.lithos.2014.08.024 Sisson, T.W., 1994.Hornblende-Melt Trace-Element Partitioning Measured by Ion Microprobe.Chemical Geology, 117(1-4):331-344.https://doi.org/10.1016/0009-2541(94)90135-x doi: 10.1016/0009-2541(94)90135-X Sun, S.S., McDonough, W.F., 1989.Chemical and Isotopic Systematics of Oceanic Basalts:Implications for Mantle Composition and Processes.Geological Society, London, Special Publications, 42(1):313-345.https://doi.org/10.1144/gsl.sp.1989.042.01.19 doi: 10.1144/GSL.SP.1989.042.01.19 Sylvester, P.J., 1989.Post-Collisional Alkaline Granites.The Journal of Geology, 97(3):261-280. https://doi.org/10.1086/629302 Wang, Q., Wyman, D.A., Xu, J.F., et al., 2007.Partial Melting of Thickened or Delaminated Lower Crust in the Middle of Eastern China:Implications for Cu-Au Mineralization.The Journal of Geology, 115(2):149-161. https://doi.org/10.1086/510643 Wang, Q., Xu, J.F., Jian, P., et al., 2006.Petrogenesis of Adakitic Porphyries in an Extensional Tectonic Setting, Dexing, South China:Implications for the Genesis of Porphyry Copper Mineralization.Journal of Petrology, 47(1):119-144. https://doi.org/10.1093/petrology/egi070 Wang, T.Y., Wang, J.R., Wang, S.Z., et al., 1992.Discovery of the Engeer Wusu Ophiolitic Mélange Belt in Northern Alashan and Its Tectonic Significance.Journal of Lanzhou University (Natural Sciences), 28(2):194-196 (in Chinese with English abstract). Wang, W.L., Teng, X.J., Liu, Y., et al., 2017.Zircon U-Pb Chronology and Geochemical Characteristics of the Wuheertu Granite Mass in Langshan, Inner Mongolia.Journal of Geomechanics, 23(3):382-396 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlxxb201703006 Wang, Z.Z., Han, B.F., Feng, L.X., et al., 2015a.Geochronology, Geochemistry and Origins of the Paleozoic-Triassic Plutons in the Langshan Area, Western Inner Mongolia, China.Journal of Asian Earth Sciences, 97:337-351. https://doi.org/10.1016/j.jseaes.2014.08.005 Wang, Z.J., Xu, W.L., Pei, F.P., et al., 2015b.Geochronology and Geochemistry of Middle Permian-Middle Triassic Intrusive Rocks from Central-Eastern Jilin Province, NE China:Constraints on the Tectonic Evolution of the Eastern Segment of the Paleo-Asian Ocean.Lithos, 238:13-25. https://doi.org/10.1016/j.lithos.2015.09.019 Wang, Z.Z., Han, B.F., Feng, L.X., et al., 2016.Tectonic Attribution of the Langshan Area in Western Inner Mongolia and Implications for the Neoarchean-Paleoproterozoic Evolution of the Western North China Craton:Evidence from LA-ICP-MS Zircon U-Pb Dating of the Langshan Basement.Lithos, 261:278-295. https://doi.org/10.1016/j.lithos.2016.03.005 Wilde, S.A., 2015.Final Amalgamation of the Central Asian Orogenic Belt in NE China:Paleo-Asian Ocean Closure Versus Paleo-Pacific Plate Subduction-A Review of the Evidence.Tectonophysics, 662:345-362. https://doi.org/10.1016/j.tecto.2015.05.006 Xiong, X.L., Liu, X.C., Zhu, Z.M., et al., 2011.Adakitic Rocks and Destruction of the North China Craton:Evidence from Experimental Petrology and Geochemistry.Science in China (Series D), 41(5):654-667 (in Chinese). http://www.cqvip.com/QK/60111X/201106/37557801.html Yang, G., Xiao, L., Wang, G.C., et al., 2015.Geochronology, Geochemistry and Petrogenesis of Bieluagaxi Granodioritic Pluton in Western Junggar.Earth Science, 40(5):810-823 (in Chinese with English abstract).https://doi.org/10.37pp/dqkx.2015.043 http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX201505004.htm Yang, H., Ge, W.C., Zhao, G.C., et al., 2015.Early Permian-Late Triassic Granitic Magmatism in the Jiamusi-Khanka Massif, Eastern Segment of the Central Asian Orogenic Belt and Its Implications.Gondwana Research, 27(4):1509-1533. https://doi.org/10.1016/j.gr.2014.01.011 Zeng, L.S., Gao, L.E., Xie, K.J., et al., 2011.Mid-Eocene High Sr/Y Granites in the Northern Himalayan Gneiss Domes:Melting Thickened Lower Continental Crust.Earth and Planetary Science Letters, 303(3-4):251-266. https://doi.org/10.1016/j.epsl.2011.01.005 Zhang, Q., Wang, Y., Liu, W., et al., 2002.Adakite:Its Characteristic and Implications.Geological Bulletin of China, 21(7):431-435 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201002023 Zhang, S.H., Zhao, Y., Liu, J.M., et al., 2010.Geochronology, Geochemistry and Tectonic Setting of the Late Paleozoic-Early Mesozoic Magmatism in the Northern Margin of the North China Block:A Preliminary Review.Acta Petrologica et Mineralogica, 29(6):824-842 (in Chinese with English abstract). http://cn.bing.com/academic/profile?id=363389243769f700672abad14356aea2&encoded=0&v=paper_preview&mkt=zh-cn Zhang, S.H., Zhao, Y., Liu, J.M., et al., 2016.Different Sources Involved in Generation of Continental Arc Volcanism:The Carboniferous-Permian Volcanic Rocks in the Northern Margin of the North China Block.Lithos, 240-243:382-401. https://doi.org/10.1016/j.lithos.2015.11.027 Zhang, S.H., Zhao, Y., Ye, H., et al., 2012.Early Mesozoic Alkaline Complexes in the Northern North China Craton:Implications for Cratonic Lithospheric Destruction.Lithos, 155:1-18. https://doi.org/10.1016/j.lithos.2012.08.009 Zhang, S.H., Zhao, Y., Ye, H., et al., 2014.Origin and Evolution of the Bainaimiao Arc Belt:Implications for Crustal Growth in the Southern Central Asian Orogenic Belt.Geological Society of America Bulletin, 126(9-10):1275-1300.https://doi.org/10.1130/b31042.1 doi: 10.1130/B31042.1 Zhang, W., Jian, P., Liu, D.Y., et al., 2010.Geochemistry, Geochronology and Hf Isotopic Compositions of Triassic Granodioritediorite and Shoshonite from the Damaoqi Area, Central Inner Mongolia, China.Geological Bulletin of China, 29(7):821-832 (in Chinese with English abstract). Zhao, X.C., Zhou, W.X., Fu, D., et al., 2018.Isotope Chronology and Geochemistry of the Lower Carboniferous Granite in Xilinhot, Inner Mongolia, China.Journal of Earth Science, 29(2):280-294. https://doi.org/10.1007/s12583-017-0942-2 陈崇阳, 高有峰, 吴海波, 等, 2016.海拉尔盆地火山岩的锆石U-Pb年龄及其地质意义.地球科学, 41(8):1259-1274. http://earth-science.net/WebPage/Article.aspx?id=3336 葛小月, 李献华, 陈志刚, 等, 2002.中国东部燕山期高Sr低Y型中酸性火成岩的地球化学特征及成因:对中国东部地壳厚度的制约.科学通报, 47(6):474-480. doi: 10.3321/j.issn:0023-074X.2002.06.018 耿建珍, 李怀坤, 张健, 等, 2011.锆石Hf同位素组成的LA-MC-ICP-MS测定.地质通报, 30(10):1508-1513. doi: 10.3969/j.issn.1671-2552.2011.10.004 公王斌, 胡健民, 吴素娟, 等, 2017.内蒙古狼山左行走滑韧性剪切带变形特征、时间及意义.地学前缘, 24(3):263-275. http://d.old.wanfangdata.com.cn/Periodical/dxqy201703024 郭硕, 滕学建, 刘洋, 等, 2017.内蒙古乌拉特后旗乌兰敖包地区二叠纪中-基性火山岩地球化学、年代学、Hf同位素特征及其地质意义.地质力学学报, 23(3):397-410. doi: 10.3969/j.issn.1006-6616.2017.03.007 李世超, 张凌宇, 李鹏川, 等, 2017.大兴安岭中段早三叠世O型埃达克岩的发现及其大地构造意义.地球科学, 42(12):2117-2128. http://earth-science.net/WebPage/Article.aspx?id=3709 刘珏, 郗爱华, 葛玉辉, 等, 2015.内蒙古赤峰地区蒙古营子花岗闪长岩LA-ICP-MS锆石U-Pb年龄及成因.地质通报, 34(2):437-446. doi: 10.3969/j.issn.1671-2552.2015.02.020 刘建峰, 迟效国, 赵芝, 等, 2013.内蒙古巴林右旗建设屯埃达克岩锆石U-Pb年龄及成因讨论.岩石学报, 29(3):827-839. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201303007 王廷印, 王金荣, 王士政, 等, 1992.阿拉善北部恩格尔乌苏蛇绿混杂岩带的发现及其构造意义.兰州大学学报(自科版), 28(2):194-196. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000002075353 王文龙, 滕学建, 刘洋, 等, 2017.内蒙古狼山乌和尔图花岗岩岩体锆石U-Pb年代学及地球化学特征.地质力学学报, 23(3):382-396. doi: 10.3969/j.issn.1006-6616.2017.03.006 熊小林, 刘星成, 朱志敏, 等, 2011.华北埃达克质岩与克拉通破坏:实验岩石学和地球化学依据.中国科学(D辑), 41(5):654-667. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201105005.htm 杨钢, 肖龙, 王国灿, 等, 2015.西准噶尔别鲁阿嘎希花岗闪长岩年代学、地球化学特征及岩石成因.地球科学, 40(5):810-823. http://earth-science.net/WebPage/Article.aspx?id=3090 张旗, 王焰, 刘伟, 等, 2002.埃达克岩的特征及其意义.地质通报, 21(7):431-435. doi: 10.3969/j.issn.1671-2552.2002.07.012 张拴宏, 赵越, 刘建民, 等, 2010.华北地块北缘晚古生代——早中生代岩浆活动期次、特征及构造背景.岩石矿物学杂志, 29(6):824-842. doi: 10.3969/j.issn.1000-6524.2010.06.017 张维, 简平, 刘敦一, 等, 2010.内蒙古中部达茂旗地区三叠纪花岗岩和钾玄岩的地球化学、年代学和Hf同位素特征.地质通报, 29(7):821-832. http://d.old.wanfangdata.com.cn/Periodical/zgqydz201006004 -
