Characteristics of Oil Reservoiring and Its Relationship with Pressure Evolution of Shahejie Formation in Pucheng Area
-
摘要: 目前对濮城地区沙河街组一至四段的成藏整体研究仍存在空白.利用流体包裹体系统分析方法，结合原油实测数据对东濮凹陷濮城地区沙河街组的成藏特征进行研究.结果表明总体上多套烃源岩联合供烃控制着濮城地区沙河街组原油成熟度的垂向分布，压力演化作为成藏的驱动因素与各期成藏耦合完好.濮城地区沙河街组原油存在三期成藏：第一期约30.9~25.3 Ma；第二期约22.3~14.8 Ma；第三期约3.2~1.4 Ma.垂向上巨厚的烃源岩同一时期生成不同成熟度的原油，此外，同一层位烃源岩随时间推移依次生成低熟、成熟、高熟油，使得濮城地区沙河街组各段均存在不同成熟度原油同期成藏的特征.古压力模拟结果表明第一期成藏为超压驱动，第二期成藏为泄压驱动，第三期成藏兼具前两期的特点.Abstract: The whole Shahejie Formation has not been treated as one target for reservoiring research. So in this study, fluid inclusion systematic analysis conducted on samples from Shahejie Formation in Pucheng area, Dongpu depression, combined with the crude oil data, indicates that the vertical distribution of oil maturity is under control of petroleum generation of multiple sets of source rocks. The pressure evolution process considered to be a driving factor was in agreement with the reservoiring stages. Three reservoiring stages were identified in Pucheng area: the first was from 30.9-25.3 Ma, the second was from 22.3-14.8 Ma, the third was from 3.2-1.4 Ma. The source rocks with huge vertical thickness produced crude oil with different maturities at the same time. Moreover, different maturities of oil were generated from the same set of source rock over time, which made the Shahejie Formation in Pucheng area had characteristics of simultaneous reservoiring of crude oil with different maturity. The results of paleopressure simulation show that the first stage was driven by overpressure, the second stage was driven by pressure relief and the third stage had the combined features of the former two stages.
-
图 1 东濮凹陷北部濮城地区构造位置图及研究井位图
Fig. 1. Structural location of Pucheng area in the northern Dongpu depression and that of studied wells
图 2 濮城地区沙河街组油包裹体λmax和QF535关系
Fig. 2. Relationship between peak wave length (λmax) and QF535 of micro-beam fluorescent spectrum of single oil inclusion in the Shahejie Formation in Pucheng area
图 3 东濮凹陷濮城地区典型油包裹体显微照片
a，b.濮3-227井，Esh21，埋深2 447.00 m，硬石膏晶粒中橙色荧光油包裹体；c，d.濮6-65井，Esh41，埋深3 764.07 m，穿石英颗粒裂纹中黄色荧光油包裹体；e，f.濮6-65井，Esh41，埋深3 665.10 m，穿石英颗粒裂纹中绿色荧光和蓝色荧光油包裹体；g，h.濮3-227井，Esh21，埋深2 447.00 m，穿石英颗粒裂纹中蓝色荧光油包裹体
Fig. 3. Typical micrographs showing fluid inclusions in Pucheng area of Dongpu depression
图 4 濮城地区沙河街组不同深度包裹体均一温度分布直方图
a.埋深2 447 m，b.埋深2 868~2 870 m，c.埋深3 568~3 666 m，d.埋深3 372 m，e.埋深3 038~3 092 m.其中，橙色荧光油包裹体及其同期盐水包裹体为硬石膏胶结物中，黄色、绿色、蓝色荧光油包裹体及其同期盐水包裹体均为穿颗粒裂纹中
Fig. 4. Homogenization temperature of fluid inclusions of different depths in Shahejie Formation in Pucheng area
图 6 濮城地区埋藏史及沙河街组油气充注时间确定
Fig. 6. Burial history and definition of oil charging time of the Shahejie Formation in Pucheng area
图 5 油包裹体激光共聚焦沿z轴切片及三维重建
1~6.沿z轴30张切片中的6张；a.透射光下的油包裹体平面形态；b.三维重建后的油包裹体空间形态
Fig. 5. Laser confocal cutting slides along z-axis and 3D reconstruction of oil inclusion
表 1 各类油包裹体λmax与QF535的相应范围
Table 1. Corresponding ranges of λmax and QF535 of each type of oil inclusions
荧光颜色 橙色 黄色 绿色 蓝色 λmax(nm) 612~617 563~580 528~550 477~495 QF535 1.96~2.25 1.78~1.97 0.91~1.62 0.81~0.93
下载: 导出CSV
表 2 濮城地区沙河街组油包裹体最小捕获压力模拟
Table 2. Simulation of the lowest trapping pressure of oil inclusions in Shahejie Formation in Pucheng area
井号 今埋深(m) 捕获年龄(Ma) λmax(nm) Thoil(℃) Thaqu(℃) 气/液比 捕获压力(MPa) 压力系数 P6-65 3 665.10 27.3 549 96.3 111.3 7.89 25.19 1.14 P6-65 3 666.00 27.9 522 97.4 105.4 9.32 25.08 1.19 P63 3 371.93 14.8 542 115.4 134.2 10.19 30.25 1.21 P77 3 646.88 1.6 548 112.4 128.9 14.93 35.68 1.15 P77 3 622.00 1.4 523 118.4 132.7 14.87 34.85 1.12 P6-65 2 868.08 26.7 617 73.2 80.3 4.99 16.69 1.21 P6-65 2 870.08 27.0 581 67.5 75.1 10.39 16.02 1.17 P6-65 2 870.08 27.0 549 70.4 75.1 4.67 14.9 1.09 P6-65 3 038.00 26.2 555 90.1 94.5 10.57 26.02 1.42 P6-65 3 038.00 26.3 554 94.5 95.2 8.63 20.66 1.38 P6-65 3 091.54 30.3 552 43 67.6 1.3 15.05 1.50 P6-65 3 092.44 30.9 556 46 63.6 1.5 11.15 1.06 P6-65 3 092.44 22.3 555 97.4 100.3 15.23 30.09 1.43 P3-227 2 447.00 2.0 580 99.3 124.8 11.44 35.9 1.13
下载: 导出CSV
-
Chen H.H., Dong W.L., Zhang S.L., et al.2002.Application of Fluid Inclusion in Palaeopressure Modelling Research.Oil & Gas Geology, 23(3):207-211(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz200203002 Chen H.H., Zhang Q.M., Shi J.X..1997.Evidence of Fluid Inclusion of Movements of Hydrocarbon Bearing Fluids in Qiongdongnan Basin.Science in China(Ser.D), 27(4):343-348(in Chinese). http://www.cnki.com.cn/Article/CJFDTotal-JDXG199706012.htm Chen S.P., Zou Y.X., Han X., et al.2015.Relationship Between the Formation and Development of Fault Propagation Folds and Oil and Gas in Pucheng Dongpu Depression.Oil Geophysical Prospecting, 50(3):536-541(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYDQ201503026.htm Feng Z.D., Cheng X.S., Fu X.L., et al.2014.Neotectonic Movements in the Dongpu Depression and Their Controls on Hydrocarbon Accumulation in Shallow Reservoirs.Sedimentary Geology and Tethyan Geology, 34(1):8-13(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yxgdl201401002 Goldstein R.H., Reynolds T.J..1994.Systematics of Fluid Inclusions in Diagenetic Minerals.SEM Short Course 31.Society of Sedimentary Geology (SEPM), Tulsa. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cc7cd5e8d83b8bce0a651028054d6e0c Jiang Y.L., Fang L., Tan Y.M., et al.2015.Differences and Main Controlling Factors of Accumulation Periods in Dongpu Sag, Bohai Bay Basin.Geological Review, 61(6):1321-1331(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201506011 Li C.Q., Chen H.H., Liu H.M..2010.Identification of Hydrocarbon Charging Events by Using Micro-Beam Fluorescence Spectra of Petroleum Inclusions.Earth Science, 35(4):657-662(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201004016 Liu D.H., Xiao X.M., Cheng P., et al.2016.Study of Genetic Evolution of Oil Inclusion and Density of Surface Oil by Measurement of Fluorescence Lifetime of Crude Oil and Oil Inclusion.Science China:Earth Sciences, 46(12):1626-1632(in Chinese). http://www.cnki.com.cn/Article/CJFDTotal-JDXG201701009.htm Ping H.W., Chen H.H., Song G.Q., et al.2012.Accumulation History of the Deeply Buried Condensate Reservoir in Minfeng Sag of the Northern Dongying Depression and Its Exploration Significance.Acta Petrolei Sinica, 33(6):970-977(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201206007 Shan X.Q., Li J., Hu G.Y., et al.2007.Analysis and Calculation of Hydrocarbon Accumulation History and Paleocurrent Potential by Studying Fluid Inclusions:An Example from the Upper Paleozoic in Yulin, Ordos Basin.Oil & Gas Geology, 28(2):159-165(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT200702008.htm Su A., Chen H.H., Wu Y., et al.2017.Characteristics, Genesis and Geological Significance of Natural Hydrocarbon Immiscible Inclusions in Sandstone Reservoirs.Acta Petrolei Sinica, 38(7):763-776(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201707005 Sun B., Jiang Y.L., Shi X.H., et al.2013.Pressure Evolution and Formation Mechanism of Overpressure in Dongpu Depression, Bohaiwan Basin.Journal of China University of Petroleum(Edition of Natural Science), 37(2):28-35(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydxxb201302005 Wang J.P., Huang Z.G., Zhang Y.X., et al.2018.Lithological Characteristics and Macroscopic Distribution Rule of High-Quality Hydrocarbon Source Rocks in Dongpu Depression.Fault-Block Oil & Gas Field, 25(5):549-554(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dkyqt201805001 Wang Q.R., Chen H.H., Zhao Y.T., et al.2018.Differences of Hydrocarbon Accumulation Periods in Silurian of Tazhong Northern Slope, Tarim Basin.Earth Science, 43(2):577-593(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201802018 Wu Y., Chen H.H., Zhao Y.T., et al.2017.Evidences and Controlling Factors of Hydrocarbon Charging in the Late Silurian in the North Slope of the Tazhong Uplift, Tarim Basin.Oil & Gas Geology, 38(2):292-301(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201702011 Xu C.Q., Jiang Y.L., Cheng Q., et al.2010.Study on the Formation Stages of Oil-Gas Reservoirs in Puwei Subsag, Dongpu Sag.Journal of Earth Sciences and Environment, 32(3):257-262(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xagcxyxb201003007 Xu T.W., Zhang H.A., Li J.D., et al.2019.Characters of Hydrocarbon Generation and Accumulation of Salt-Lake Facies in Dongpu Sag, Bohai Bay Basin.Oil & Gas Geology, 40(2):248-261(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201902005 Xue G.G., Gao J.Z..2014.The Formation Mechanism of Abnormal High Pressure Reservoirs in Dongpu Sag, Bohai Bay Basin.Xinjiang Petroleum Geology, 35(2):149-152(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xjsydz201402004 Yu H.B., Cheng X.S., Qi J.F., et al.2018.Effects of Paleogene Faulting on the Subsag Evolution and Hydrocarbon Generation in Dongpu Sag.Petroleum Geology and Recovery Efficiency, 25(6):24-31(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yqdzycsl201806004 Zhang X.J..2016.Fluorescence Spectra Analyzing Method and Its Application in the Oil Inclusions of the Tight Reservoirs.Petroleum Geology and Oilfield Development in Daqing, 35(3):49-53(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqsydzykf201603009 Zuo Y.H., Tang S.L., Zhang W., et al.2017.Cenozoic Thermal History of the Dongpu Sag, Bohai Bay Basin.Earth Science Frontiers, 24(3):149-156(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DZKT201603023.htm 陈红汉, 董伟良, 张树林, 等.2002.流体包裹体在古压力模拟研究中的应用.石油与天然气地质, 23(3):207-211. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz200203002 陈红汉, 张启明, 施继锡.1997.琼东南盆地含烃热流体活动的流体包裹体证据.中国科学(D辑), 27(4):343-348. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700269976 陈书平, 邹宇轩, 韩煦, 等.2015.东濮凹陷濮城断展褶皱形成演化及与油气关系.石油地球物理勘探, 50(3):536-541. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydqwlkt201503022 冯阵东, 程秀申, 付晓龙, 等.2014.东濮凹陷构造演化对浅层油气成藏的影响.沉积与特提斯地质, 34(1):8-13. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yxgdl201401002 蒋有录, 房磊, 谈玉明, 等.2015.渤海湾盆地东濮凹陷不同区带油气成藏期差异性及主控因素.地质论评, 61(6):1321-1331. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201506011 李纯泉, 陈红汉, 刘惠民.2010.利用油包裹体微束荧光光谱判识油气充注期次.地球科学, 35(4):657-662. doi: 10.3799/dqkx.2010.080 刘德汉, 肖贤明, 程鹏, 等.2016.应用原油和石油包裹体荧光寿命研究石油包裹体的成因演化和对应地面原油的密度.中国科学:地球科学, 46(12):1626-1632. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkx-cd201612005 平宏伟, 陈红汉, 宋国奇, 等.2012.东营凹陷北带民丰洼陷深层凝析油藏成藏史及其勘探意义.石油学报, 33(6):970-977. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201206007 单秀琴, 李剑, 胡国艺, 等.2007.利用流体包裹体分析和计算油气的充注史和古流体势.石油与天然气地质, 28(2):159-165. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz200702005 苏奥, 陈红汉, 吴悠, 等.2017.砂岩储层烃类不混溶包裹体特征、成因及地质意义.石油学报, 38(7):763-776. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201707005 孙波, 蒋有录, 石小虎, 等.2013.渤海湾盆地东濮凹陷压力演化与超压形成机制.中国石油大学学报(自然科学版), 37(2):28-35. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydxxb201302005 王金萍, 黄泽贵, 张云献, 等.2018.东濮凹陷优质烃源岩的岩性特征及宏观展布规律.断块油气田, 25(5):549-554. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dkyqt201805001 王倩茹, 陈红汉, 赵玉涛, 等.2018.塔中北坡顺托果勒地区志留系油气成藏期差异性分析.地球科学, 43(2):577-593. doi: 10.3799/dqkx.2018.026 吴悠, 陈红汉, 赵玉涛, 等.2017.塔中地区北坡志留系晚期油气充注证据及控制因素.石油与天然气地质, 38(2):292-301. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201702011 徐春强, 蒋有录, 程奇, 等.2010.东濮凹陷濮卫洼陷油气成藏期分析.地球科学与环境学报, 32(3):257-262. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xagcxyxb201003007 徐田武, 张洪安, 李继东, 等.2019.渤海湾盆地东濮凹陷盐湖相成烃成藏特征.石油与天然气地质, 40(2):248-261. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201902005 薛国刚, 高渐珍.2014.东濮凹陷异常高压油气藏形成机理.新疆石油地质, 35(2):149-152. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xjsydz201402004 余海波, 程秀申, 漆家福, 等.2018.东濮凹陷古近纪断层活动性对洼陷演化及生烃的影响.油气地质与采收率, 25(6):24-31. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yqdzycsl201806004 张学军.2016.致密储层油包裹体荧光光谱分析方法及其应用.大庆石油地质与开发, 35(3):49-53. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqsydzykf201603009 左银辉, 唐世林, 张旺, 等.2017.东濮凹陷新生代构造——热历史研究.地学前缘, 24(3):149-156. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201703013 -
