Tectonic Transition of the Late-Mesozoic Yellow Sea and Adjacent Region and Its Tectonic Framework of the Proto-Basin
-
摘要: 古太平洋板块的俯冲、回卷(rollback)及俯冲方向的转变对中国黄海及邻近地区盆地的发育有着重要的影响.综合利用野外剖面、钻井岩心和地震剖面等,对比分析不同盆地间沉积充填历史,识别出不同时期应力场方向的变化和主要构造变形样式,对主要断裂进行界定,为关键时间节点提供证据,并恢复了侏罗纪-白垩纪的构造演化过程.结果表明:(1)在古太平洋板块俯冲作用背景下,受郯庐断裂带F1和朝鲜半岛西部断裂带F2两个主控断裂带共同的控制作用,盆地经历了多期“伸展”和“挤压”的构造应力场的转变,性质各不相同;(2)构造演化可划分为6个阶段:莱阳期近南北向拉伸,发育被动裂谷;125±1 Ma阶段,热隆挤压造成轻微构造反转,形成隆起区的角度不整合;青山期近东西向滑脱伸展形成主动裂谷性质的火山弧盆;87.5±2.5 Ma挤压阶段,经历了大规模左旋走滑,形成区域角度不整合;王氏期热沉降,形成带走滑拉分性质的大面积坳陷;50±5 Ma挤压阶段,主要在F1、F2断裂经历右旋走滑;(3)估算了挤压阶段的走滑量,对伸展阶段的伸展率、沉降率进行了计算.首次恢复了中国黄海及邻近地区晚中生代挤压构造幕演化之前的构造格局和盆地原型,并解释了古太平洋板块俯冲作用对黄海及邻区构造格局演变的影响.Abstract: The subduction, rollbacking and the direction of the subduction of the Paleo-Pacific Plate had a significant influence on the development of the basins in the Yellow Sea and its adjacent areas. According to the drilling core data of the field profile and marine seismic profile, the sedimentation between different basins is compared and analyzed, and the changes of the stress field direction and main tectonic deformation framework in different periods are identified. Meanwhile, the main faults are defined, critical time nodes have provided evidence, and the research area's tectonic transition from the Jurassic to the Cretaceous is restored. The results indicate that: (1) Under the background of the subduction of the paleo-pacific plate, the basin has undergone multiple stages of 'extension' and 'compression' structural stress fields and under the joint control of the two main fault zones of the Tanlu fault zone F1 and the western Korean Peninsula fault zone F2. (2) During Laiyang period, passive rift was developed due to the stretching from south to north; At 125±1 Ma stage, thermal uplift extrusion caused slight tectonic inversion and formed angular unconformity in the uplift area; The volcanic arc basin with active rift was formed during the Qingshan period; At the extrusion stage of 87.5±2.5 Ma, large-scale sinistral strike-slip occurred and regional angular unconformity was formed; The thermal subsidence in Wang stage formed a large area depression with the nature of take-away slip and pull-apart; At the extrusion stage of 50±5 Ma, dextral strike-slip occurred mainly at F1 and F2 faults. (3) In this paper, the strike-slip amount in the extrusion stage is estimated, and the elongation and settlement rate in the extension stage are calculated. It is the first time to reconstruct the tectonic framework and basin prototype before the evolution of the Late Mesozoic compressive tectonic episode in the Yellow Sea and adjacent areas of China, and to explain the influence of the subduction of the Paleo-Pacific plate on the evolution of the tectonic framework in the Yellow Sea and adjacent areas.
-
图 3 航磁ΔT化极异常分区(据杨金玉,2010修改)
Fig. 3. Anomaly zoning of aeromagnetic ΔT pole (modifed from Yang, 2010)
图 4 布格重力异常分区(据杨金玉,2010修改)
Fig. 4. Aeromagnetic anomaly zone (modifed from Yang, 2010)
图 5 中国黄海及邻近地区构造层划分及应力场方向(据张岳桥等,2004修改)
Fig. 5. Stress direction and structural layer division in the Yellow Sea and adjacent areas of China (modifed from Zhang et al., 2004)
图 6 过灵科1井-背来石构造剖面及灵山岛野外照片
a. 灵山岛地区过灵科1井青山期-莱阳期近南北向地层剖面图;b. 灵山岛地质简图(修改自周瑶琪等,2017);c. 为灵山岛地区野外照片;c-1. 为125±1 Ma时期形成的节理照片,地质锤把手所指方向为N,最大主应力方向为近东西近E-W,与125±1 Ma时期应力方向为近东西向相吻合;c-2. 为87.5±2.5 Ma时期形成的北西向逆冲断裂(f1),此断层是87.5±2.5 Ma时期形成北东向走滑断层F7的派生断层;c-3. 青山群和莱阳群的界限,不整合界面上下的地层角度相差大约10°.青山期岩性为火成岩;莱阳群为砂岩,其中扇三角洲沉积相中的褶皱反映出125±1 Ma时期近E-W向挤压应力场;d. 灵科1井的岩心,分别过灵科1井的3条断裂破碎带f3(上下厚度约5 m)、f4(上下厚度约10 m)、f5(上下厚度约5 m)
Fig. 6. The geological section from Well Lingke 1 to Beilaishi and Field photos of Lingshan Island
图 7 崂山地区垭口-八仙墩-部分海域地层剖面图(露头剖面部分据Wang et al., 2016修改)
Fig. 7. Stratigraphic section of Laoshan Mountain to Yakou-Baxiandun area-apart of sea (Outcrop profile section is modifed from Wang et al., 2016)
图 8 灵科1井莱阳群/青山群地层序列图(据周腾飞等,2022)
Fig. 8. Stratigraphic sequence diagram of Lingke 1 Well Laiyang Group/Qingshan Group(revised by Zhou et al., 2022)
图 9 西太平洋区域位置图以及白垩纪古太平洋板块(由现今太平洋板块上热点海隆年龄标定)自NWW至NNW向位移-时间图(据Andrew A. Stepashko, 2017, 私人通讯)
Fig. 9. Location map of the Western Pacific Region and Cretaceous Pacific plate displacement from NWW to NNW (Dated from the current hotspot on the Pacific plate)-time map (revised by Andrew A. Stepashko, 2017, Private communications)
表 1 黄海及邻区主要走滑断裂走滑量及走滑速率
Table 1. Strike-slip quantities and rates of the main strike-slip faults in the Yellow Sea and adjacent areas
走滑时间 断裂带 走滑量(km) 走滑速度(km/Ma) 走滑时间 断裂带 走滑量
(km)走滑速度(km/Ma) 87.5±2.5 Ma
左旋F1 550 110 50±5 Ma
右旋F1 300 30 F2 560 112 F2 350 35 F3 40 8 F3 0(?) 0(?) F4 50 10 F4 0(?) 0(?) F5 34 6.8 F5 0(?) 0(?) F6 40 8 F6 0(?) 0(?) F7 30 6 F7 0(?) 0(?) F8 230 46 F8 0(?) 0(?) F9 100 20 F9 0(?) 0(?) F10 50 10 F10 0(?) 0(?) F11 100 20 F11 0(?) 0(?) F12 60 12 F12 0(?) 0(?) 表 2 黄海及邻区不同盆地伸展率及沉降速率
Table 2. Extensional rates and settlement rates of different basins in the Yellow Sea and adjacent areas
盆地名称 伸展率(%) 沉降速率(m/Ma) 莱阳期 青山期 王氏期 莱阳期 青山期 王氏期 SN EW SN 日青威盆地 20 3 8 200 38 78 胶莱盆地 15 2 6 150 27 61 南黄海南部盆地 10 1 4 98 12 41 北黄海盆地 10 2 0 87 21 0 -
Cheng, Y.J., Wu, Z.P., Liu, X.Y., et al., 2022. Study on Late Jurassic to Early Cretaceous Magnetic Stratigraphy in Well Lingke 1, Lingshan Island, Riqingwei Basin, Eastern China. Scientia Sinica (Terrae), 52(5): 903-919(in Chinese with English abstract). doi: 10.1360/N072021-0143 Ding, L., Maksatbek, S., Cai, F.L., et al., 2017. The Time Limit, Closure Mode and Process of Initial Collision between India and Eurasia. Scientia Sinica (Terrae), 47(3): 293-309(in Chinese with English abstract). doi: 10.1360/N072016-00244 Fu, P.Y., 2013. Geochronology and Petrogenesis of the Early Cretaceous Volcanic Rocks in the Yi-Shu Fault Zone(Dissertation). Hefei University of Technology, Hefei (in Chinese with English abstract). Han, R., Ree, J. H., Cho, D. L., et al., 2006. Shrimp U-Pb Zircon Ages of Pyroclastic Rocks in the Bansong Group, Taebaeksan Basin, South Korea and Their Implication for the Mesozoic Tectonics. Gondwana Research, 9(1-2): 106-117. https://doi.org/10.1016/j.gr.2005.06.006 Kuang, Y.S., Pang, C.J., Hong, L.B., et al., 2012. Geochronology and Geochemistry of the Late Cretaceous Basalts in the Jiaolai Basin: Constraints on Lithospheric Thinning and Accretion beneath North China Craton. Geotectonica et Metallogenia, 36(4): 559-571(in Chinese with English abstract). doi: 10.3969/j.issn.1001-1552.2012.04.010 Kusky, T. M., Windley, B. F., Wang, L., et al., 2014. Flat Slab Subduction, Trench Suction, and Craton Destruction: Comparison of the North China, Wyoming, and Brazilian Cratons. Tectonophysics, 630: 208-221. https://doi.org/10.1016/j.tecto.2014.05.028 Li, S. Z., Jahn, B. M., Zhao, S. J., et al., 2017. Triassic Southeastward Subduction of North China Block to South China Block: Insights from New Geological, Geophysical and Geochemical Data. Earth-Science Reviews, 166: 270-285. https://doi.org/10.1016/j.earscirev.2017.01.009 Li, S.Z., Suo, Y.H., Li, X.Y., et al., 2018. Mesozoic Plate Subduction in West Pacific and Tectono-Magmatic Response in the East Asian Ocean-Continent Connection Zone. Chinese Science Bulletin, 63(16): 1550-1593(in Chinese with English abstract). doi: 10.1360/N972017-01113 Li, S.Z., Zhang, G.W., Zhou, L.H., et al., 2011. The Opposite Meso-Cenozoic Intracontinental Deformations under the Superconvergence: Rifting and Extension in the North China Craton and Shortening and Thrusting in the South China Craton. Earth Science Frontiers, 18(3): 79-107(in Chinese with English abstract). Li, Z.Q., Yang, B., Han, Z.J., et al., 2022. Tectonic-Thermal Evolution of Meso-Cenozoic Rift Basin in the South Yellow Sea, offshore Eastern China: Implications for Basin-Forming Mechanism and Thermal Evolution of Source Rocks. Earth Science, 47(5): 1652-1668 (in Chinese with English abstract). Liang, R.C., Han, G.Z., Zheng, Y.P., et al., 2001. Gravity and Magnetic Field and Geological Structure Characteristics in the South Yellow Sea. Cinese Science Bulletin, 46(S1): 59-67(in Chinese with English abstract). doi: 10.1360/csb2001-46-S1-59 Liang, Z., Zhou, Y. Q., van Loon, A. J. T., 2018. Soft-Sediment Deformation Structures Induced by Rapid Sedimentation in Early Cretaceous Turbidites, Lingshan Island, Eastern China. Canadian Journal of Earth Sciences, 55(2): 118-129. https://doi.org/10.1139/cjes-2017-0106 Ling, Y.Y., Zhang, J.J., Liu, K., et al., 2017. Geochemistry, Geochronology, and Tectonic Setting of Early Cretaceous Volcanic Rocks in the Northern Segment of the Tan-Lu Fault Region, Northeast China. Journal of Asian Earth Sciences, 144: 303-322. https://doi.org/10.1016/j.jseaes.2016.12.025 Liu, F. F., Zhou, Y. Q., 2019. Nd Isotopic and Model Age Study of the Shandong Province, North China Craton: Implications for Correlation with South Korea. Journal of Earth Science, 30(5): 938-951. https://doi.org/10.1007/s12583-019-1213-1 Liu, F. F., Zhou, Y. Q., Zhang, Z. K., et al., 2019. Detrital Zircon U-Pb Geochronology of Early Cretaceous Sedimentary Rocks in Dingzi Bay and Taolin Area from the Sulu Orogen: Provenances and Tectonic Implications. Geological Journal, 54(4): 2693-2715. https://doi.org/10.1002/gj.3364 Liu, F.F., 2019. Tectonic Framework and Evolution Study of Eastern Shandong Offshore Ri-Qing-Wei Basin(Dissertation). China University of Petroleum, Qingdao(in Chinese with English abstract). Liu, F.F., Zhou, Y.Q., Xu, H., et al., 2016. Origin of the Lingshan Island and Geotectonic Significance. Marine Geology Frontiers, 32(3): 33-40(in Chinese with English abstract). Liu, Y.Q., Kuang, H.W., Peng, N., et al., 2011. Sedimentary Facies of Dinosaur Trackways and Bonebeds in the Cretaceous Jiaolai Basin, Eastern Shandong, China, and Their Paleogeographical Implications. Earth Science Frontiers, 18(4): 9-24(in Chinese with English abstract). http://www.researchgate.net/publication/285505140_Sedimentary_facies_of_dinosaur_trackways_and_bonebeds_in_the_Cretaceous_Jiaolai_Basin_eastern_Shandong_China_and_their_paleogeographical_implications Lü, H.B., Wang, J., Zhang, H.C., 2011. Discovery of the Late Mesozoic Slump Beds in Lingshan Island, Shandong, and a Pilot Research on the Regional Tectonics. Acta Geologica Sinica, 85(6): 938-946(in Chinese with English abstract). Ma, Q., Zhou, Y., Mu, H., et al., 2022. Geochemistry of the Laiyang Group from Outcrops and Lingke-1 Core on Lingshan Island, Shandong Province, Eastern China: Implications for Provenance, Tectonic Setting and Palaeo-Environment. Geological Magazine, 159(1), 37-54. https://doi: 10.1017/S0016756821000819 Ma, Z.J., Chai, F.M., Wang, W., et al., 2022. Petrogenesis of Pingtaishan Compound Massif in the Eastern Tianshan, NW China, and Its Implications on Late Paleozoic Ridge Subduction. Earth Science, 47(9): 3210-3228 (in Chinese wtih English abstract). Mao, X.P., Wu, C.L., Yuan, Y.B., 1998. Physical Balanced Cross Sections for Geological Structure. Earth Science, 23(2): 167-170(in Chinese with English abstract). doi: 10.3321/j.issn:1000-2383.1998.02.013 Qi, J.F., Yang, Q., Wang, Z.Y., et al., 2001. Some Problems about Compiling Tectonic Evolution Sections of Basin. Geological Review, 47(4): 388-392(in Chinese with English abstract). doi: 10.3321/j.issn:0371-5736.2001.04.009 Qiu, J.S., Liu, L., Li, Y.L., 2012. Geochronology and Geochemistry of Potassic and Sodic Volcanic Rocks in Tangtou Basin, Shandong Province: Implications for Lithospheric Thinning beneath the North China Craton. Acta Petrologica Sinica, 28(4): 1044-1056(in Chinese with English abstract). Qiu, J.S., Xu, X.S., Luo, Q.H., 2001. 40Ar-39Ar Dating of Potassium-Rich Volcanic Rocks and Lamprophyres in Western Shandong and Tracing of Their Source Regions. Chinese Science Bulletin, 46(18): 1500-1508(in Chinese with English abstract). doi: 10.1360/csb2001-46-18-1500 Ren, J.S., Niu, B.G., Wang, J., et al., 2013.1∶5 Million International Geological Map of Asia. Acta Geoscientica Sinica, 34(1): 24-30, 129(in Chinese with English abstract). Ren, J.Y., Pang, X., Lei, C., et al., 2015. Ocean and Continent Transition in Passive Continental Margins and Analysis of Lithospheric Extension and Breakup Process: Implication for Research of the Deepwater Basins in the Continental Margins of South China Sea. Earth Science Frontiers, 22(1): 102-114(in Chinese with English abstract). Ren, J.Y., Xie, X.N., 1996. Continental Rifting and Basin Development System. Geological Science and Technology Information, 15(4): 26-32(in Chinese with English abstract). Tang, X.J., Zhang, S.L., Shan, R., 2018. Discussion on Mesozoic Plate Boundary in East China-Korean Peninsula: A Revised Model of Plate Indentation. Marine Geology & Quaternary Geology, 38(2): 79-87(in Chinese with English abstract). Wang, A.D., Zhou, Y.Q., Zhang, Z.K., et al., 2014. Characteristics and Significance of Underwater Non-Tectonic Cracks in Laiyang Group of Lingshan Island, Shandong Province. Acta Geoscientica Sinica, 35(3): 321-328(in Chinese with English abstract). Wang, J., Chang, S. C., Lin, P., et al. , 2016. Evidence of Early Cretaceous Transpression in the Sulu Orogenic Belt, Eastern China. Tectonophysics, 687: 44-55. https://doi.10.1016/j.tecto.2016.09.005 doi: 10.1016/j.tecto.2016.09.005 Wu, F.Y., 2005. Nature and Significance of the Early Cretaceous Giant Igneous Event in Eastern China. Earth and Planetary Science Letters, 233(1-2): 103-119. https://doi.org/10.1016/j.epsl.2005.02.019 Xia, G.Q., Yi, H.S., Zhao, X.X., et al., 2012. Quantitative Study on Paleoelevation of Eastern China Plateau in Late Mesozoic. Chinese Science Bulletin, 57(23): 2220-2230(in Chinese with English abstract). doi: 10.1360/csb2012-57-23-2220 Xie, X.N., Ren, J.Y., Lei, C., 2012. Reviews and Prospects of Depositional Basin Dynamics. Geological Science and Technology Information, 31(5): 76-84(in Chinese with English abstract). Yang, J.Y., 2010. Research on the Tectonic Relation between the South Yellow Sea Basin and Its Adjacent Area and Distribution Characteristic and Tectonic Evolution of the Mesozoic-Paleozoic Marine Strata (Dissertation). Zhejiang University, Hangzhou (in Chinese with English abstract). Zhang, L. M., Wang, C.S., Ke, C., et al., 2016. High Elevation of Jiaolai Basin during the Late Cretaceous: Implication for the Coastal Mountains along the East Asian Margin. Earth and Planetary Science Letters, 456: 112-123. https://doi.org/10.1016/j.epsl.2016.09.034 Zhang, L. X., Liu, P. H., Wang, Y. L., et al., 2021. Depositional Timing and Provenance Characteristics of the Cretaceous in Sishan Formation in the Shewopo Area, Jiaolai Basin: New Evidence from Detrital Zircon U-Pb Dating and REE Composition. Earth Science, 46(3): 1119-1132 (in Chinese wtih English abstract). Zhang, Q., Jin, W.J., Wang, Y.L., et al., 2007. Discussion of North Boundary of the East China Plateau during Late Mesozoic Era. Acta Petrologica Sinica, 23(4): 689-700(in Chinese with English abstract). Zhang, Q., Qian, Q., Wang, E.Q., et al., 2001. An East China Plateau in Mid-Late Yanshanian Period: Implication from Adakites. Chinese Journal of Geology, 36(2): 248-255(in Chinese with English abstract). doi: 10.3321/j.issn:0563-5020.2001.02.014 Zhang, Y.B., Wu, F.Y., Yang, Z.H., et al., 2016. Petrogenesis and Geological Implications of Phanerozoic Granitoids at Northern Korean Peninsula. Acta Petrologica Sinica, 32(10): 3098-3122(in Chinese with English abstract). Zhang, Y.Q., Zhao, Y., Dong, S.W., et al., 2004. Tectonic Evolution Stages of the Early Cretaceous Rift Basins in Eastern China and Adjacent Areas and Their Geodynamic Background. Earth Science Frontiers, 11(3): 123-133(in Chinese with English abstract). Zhang, Z. K., Zhou, Y. Q., Zhou, T. F., et al., 2020. Geochemistry of Siltstones of the Early Cretaceous Laiyang Group in Taolin Area, Shandong Province, Eastern China: Implications for Provenance, Source Weathering, Palaeo-Environment, and Tectonic Setting. Geological Journal, 55(1): 133-146. https://doi.org/10.1002/gj.3400 Zhang, Y. Q., Dong, S. W., Shi, W., 2003. Cretaceous Deformation History of the Middle Tan-Lu Fault Zone in Shandong Province, Eastern China. Tectonophysics, 363(3-4): 243-258. https://doi.org/10.1016/S0040-1951(03)00039-8 Zhou, T. F., Zhou, Y. Q., Nina Søager, et al., 2022. Late Mesozoic Rifting and Its Deep Dynamic Mechanisms in the Central Sulu Orogenic Belt: Records from Lingshan Island. Science China: Earth Sciences, 52(10): 2002-2022 (in Chinese with English abstract). Zhou, Y.Q., Gu, Y.J., Zhou, T.F., et al., 2019. Sedimentary Strata and Organic Matter Features of the Cretaceous Laiyang Group in Eastern Shandong Province. Oil & Gas Geology, 40(1): 109-122(in Chinese with English abstract). Zhou, Y.Q., Zhang, Z.K., Liang, W.D., et al., 2015. Late Mesozoic Tectono-Magmatic Activities and Prototype Basin Restoration in Eastern Shandong Province, China. Earth Science Frontiers, 22(1): 137-156(in Chinese with English abstract). Zhou, Y.Q., Zhou, T.F., Ma, C.Q., et al., 2018. Transcrustal Magmatic System of Early Cretaceous (Qingshan Stage) in Eastern Shandong and the Basin Formation Related to "Thermal Upwelling-Detachment". Earth Science, 43(10): 3373-3390(in Chinese with English abstract). Zhou, Y.Q., Zhou, T.F., Zhang, Z.K., et al., 2017. Characteristics and Formation Mechanism of Soft-Sediment Deformation Structures Related to Volcanic Earthquakes of the Lower Cretaceous Qingshan Group in Lingshan Island, Shandong Province. Journal of Palaeogeography, 19(4): 567-582(in Chinese with English abstract). Zhu, G., Liu, C., Gu, C.C., et al., 2018. Oceanic Plate Subduction History in the Western Pacific Ocean: Constraint from Late Mesozoic Evolution of the Tan-Lu Fault Zone. Scientia Sinica (Terrae), 48(4): 415-435(in Chinese with English abstract). doi: 10.1360/N072017-00213 Zhu, G., Wang, Y., Wang, W., et al., 2017. An Accreted Micro-Continent in the North of the Dabie Orogen, East China: Evidence from Detrital Zircon Dating. Tectonophysics, 698: 47-64. https://doi.org/10.1016/j.tecto.2017.01.004 程燕君, 吴智平, 刘晓宇, 等, 2022. 中国东部日青威盆地灵山岛灵科1井晚侏罗世至早白垩世磁性地层研究. 中国科学: 地球科学, 52(5): 903-919. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK202205014.htm 丁林, Satybaev MAKSATBEK, 蔡福龙, 等, 2017. 印度与欧亚大陆初始碰撞时限、封闭方式和过程. 中国科学: 地球科学, 47(3): 293-309. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201703003.htm 傅朋远, 2013. 沂沭断裂带早白垩世火山岩年代学及其成因研究(硕士学位论文). 合肥: 合肥工业大学. 解习农, 任建业, 雷超, 2012. 盆地动力学研究综述及展望. 地质科技情报, 31(5): 76-84. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201205012.htm 匡永生, 庞崇进, 洪路兵, 等, 2012. 胶莱盆地晚白垩世玄武岩的年代学和地球化学特征及其对华北岩石圈减薄-增生的制约. 大地构造与成矿学, 36(4): 559-571. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK201204012.htm 李三忠, 索艳慧, 李玺瑶, 等, 2018. 西太平洋中生代板块俯冲过程与东亚洋陆过渡带构造-岩浆响应. 科学通报, 63(16): 1550-1593. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201816006.htm 李三忠, 张国伟, 周立宏, 等, 2011. 中、新生代超级汇聚背景下的陆内差异变形: 华北伸展裂解和华南挤压逆冲. 地学前缘, 18(3): 79-107. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201103012.htm 李志强, 杨波, 韩自军, 等, 2021. 南黄海中-新生代裂谷盆地构造-热演化: 对成盆机制和烃源岩热演化的指示. 地球科学, 47(5): 1652-1668. doi: 10.3799/dqkx.2021.152 梁瑞才, 韩国忠, 郑彦鹏, 等, 2001. 南黄海重磁场与地质构造特征. 科学通报, 46(增刊1): 59-67. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB2001S1009.htm 刘菲菲, 2019. 山东东部近海日青威盆地的构造格局与演化研究(博士学位论文). 青岛: 中国石油大学(华东). 刘菲菲, 周瑶琪, 许红, 等, 2016. 灵山岛成因特征、类型及其地质构造意义. 海洋地质前沿, 32(3): 33-40. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDT201603005.htm 柳永清, 旷红伟, 彭楠, 等, 2011. 山东胶莱盆地白垩纪恐龙足迹与骨骼化石埋藏沉积相与古地理环境. 地学前缘, 18(4): 9-24. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201104001.htm 吕洪波, 王俊, 张海春, 2011. 山东灵山岛晚中生代滑塌沉积层的发现及区域构造意义初探. 地质学报, 85(6): 938-946. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201106002.htm 马志杰, 柴凤梅, 王雯, 等, 2022. 东天山平台山复式岩体岩石成因及其对晚古生代洋脊俯冲的启示. 地球科学, 47(9): 3210-3228. doi: 10.3799/dqkx.2021.213 毛小平, 吴冲龙, 袁艳斌, 1998. 地质构造的物理平衡剖面法. 地球科学, 23(2): 167-170. http://www.earth-science.net/article/id/612 漆家福, 杨桥, 王子煜, 等, 2001. 关于编制盆地构造演化剖面的几个问题的讨论. 地质论评, 47(4): 388-392. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP200104010.htm 邱检生, 刘亮, 李友连, 2012. 山东汤头盆地钾质及钠质火山岩的年代学与地球化学: 对华北克拉通岩石圈减薄的启示. 岩石学报, 28(4): 1044-1056. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201204004.htm 邱检生, 徐夕生, 罗清华, 2001. 鲁西富钾火山岩和煌斑岩的40Ar-39Ar定年及源区示踪. 科学通报, 46(18): 1500-1508. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200118001.htm 任纪舜, 牛宝贵, 王军, 等, 2013.1: 500万国际亚洲地质图. 地球学报, 34(1): 24-30, 129. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201301004.htm 任建业, 解习农, 1996. 大陆裂陷作用及盆地发育系统. 地质科技情报, 15(4): 26-32. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ604.006.htm 任建业, 庞雄, 雷超, 等, 2015. 被动陆缘洋陆转换带和岩石圈伸展破裂过程分析及其对南海陆缘深水盆地研究的启示. 地学前缘, 22(1): 102-114. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201501011.htm 唐贤君, 张绍亮, 单蕊, 2018. 中国东部-朝鲜半岛中生代板块结合带划分: 对嵌入模式的新认识. 海洋地质与第四纪地质, 38(2): 79-87. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201802008.htm 王安东, 周瑶琪, 张振凯, 等, 2014. 山东灵山岛莱阳群水下非构造裂缝特征及意义. 地球学报, 35(3): 321-328. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201403009.htm 夏国清, 伊海生, 赵西西, 等, 2012. 晚中生代中国东部高原古高程定量研究. 科学通报, 57(23): 2220-2230. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201223012.htm 杨金玉, 2010. 南黄海盆地与周边构造关系及海相中、古生界分布特征与构造演化研究(博士学位论文). 杭州: 浙江大学. 张连祥, 刘平华, 王义龙, 等, 2021. 胶莱盆地蛇窝泊地区白垩纪林寺山组沉积时代与物源特征: 来自碎屑锆石U-Pb测年与稀土元素组成的新证据. 地球科学, 46(3): 1119-1132. doi: 10.3799/dqkx.2020.403 张旗, 金惟俊, 王元龙, 等, 2007. 晚中生代中国东部高原北界探讨. 岩石学报, 23(4): 689-700. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200704002.htm 张旗, 钱青, 王二七, 等, 2001. 燕山中晚期的中国东部高原: 埃达克岩的启示. 地质科学, 36(2): 248-255. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX200102015.htm 张艳斌, 吴福元, 杨正赫, 等, 2016. 朝鲜半岛北部显生宙花岗岩成因研究及地质意义. 岩石学报, 32(10): 3098-3122. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201610013.htm 张岳桥, 赵越, 董树文, 等, 2004. 中国东部及邻区早白垩世裂陷盆地构造演化阶段. 地学前缘, 11(3): 123-133. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200403017.htm 周腾飞, 周瑶琪, Nina Søager, 等. 2022. 苏鲁造山带中部晚中生代裂谷作用与深部动力机制: 来自灵山岛的记录. 中国科学: 地球科学, 52(10): 2002-2022. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK202210008.htm 周瑶琪, 辜洋建, 周腾飞, 等, 2019. 山东东部白垩系莱阳群沉积地层与有机质特征. 石油与天然气地质, 40(1): 109-122. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201901012.htm 周瑶琪, 张振凯, 梁文栋, 等, 2015. 山东东部晚中生代构造-岩浆活动及原型盆地恢复. 地学前缘, 22(1): 137-156. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201501014.htm 周瑶琪, 周腾飞, 马昌前, 等, 2018. 山东东部早白垩世青山期穿地壳岩浆系统与热隆滑脱成盆. 地球科学, 43(10): 3373-3390. doi: 10.3799/dqkx.2018.998 周瑶琪, 周腾飞, 张振凯, 等, 2017. 山东省灵山岛下白垩统青山群火山地震软沉积物变形构造特征及成因机制. 古地理学报, 19(4): 567-582. https://www.cnki.com.cn/Article/CJFDTOTAL-GDLX201704001.htm 朱光, 刘程, 顾承串, 等, 2018. 郯庐断裂带晚中生代演化对西太平洋俯冲历史的指示. 中国科学: 地球科学, 48(4): 415-435. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201804003.htm
