Focal Mechanism Classification Based on Areal Strain of Horizontal Strain Rosette of Focal Mechanism and Characteristic Analysis of Overall Focal Mechanism of Earthquake Sequence
-
摘要: 地震震源机制分类对于地震动力学分析有重要作用.然而目前震源机制分类较为随意，并且存在不确定的类型，增加了后续进一步分析的困难.为解决此问题，引入地震震源机制水平应变花理论的面应变（As）作为震源机制类型划分的标准：正断型：-1≤ As < -0.7；正走滑型：-0.7≤ As < -0.3；走滑型：-0.3≤ As ≤0.3；逆走滑型：0.3 < As ≤0.7；逆断型：0.7 < As ≤1.由于震源机制水平应变花的面应变以震源引起的垂直变形量和水平变形量的比例来划分震源机制类型，避免了以3个轴倾伏角的多种组合进行划分的麻烦，并且解决了不确定型震源机制的问题.将这种划分方法表示在球面三角形的震源机制分类图中，发现震源机制的类型划分界限是对称的.另外，一条活动断层或地震带上地震的整体滑动行为对于地球动力学研究相当重要.假定活动断层或断裂带上发生的地震只有一个震源机制，即由释放较大矩张量的地震主导，而其他震源机制是由次级破裂或者误差导致的，则得出来的余震整体震源机制解在一定程度上可以反映断层破裂的性质.提出将余震震源机制采用标量地震矩加权平均的方法得到一条活动断层或地震带上的地震的整体震源机制，从而研究主震和余震的滑动行为差别的方法.将上述方法用于2021年玛多地震序列和2022年的门源地震序列中，得到了主震和序列中的其他地震滑动特性的差别，发现2022年的门源地震序列的余震整体震源机制与主震的震源机制几乎相同，而2021年玛多地震序列的余震总体震源机制和主震有一定的差别.该方法为一条断裂带或地震带的地震滑动以及地球动力学分析等提供了工具.Abstract: Classification of seismic focal mechanism plays an important role in earthquake dynamic analysis. However, focal mechanism classification is quite arbitrary at present, and the existence of the undefined type increases the difficulty of further analysis. To solve this problem, the authors introduce the areal strain (As) of seismic focal mechanism as the standard for the division of focal mechanism types: normal fault type with -1≤As < -0.7, normal strike-slip type with -0.7≤As < -0.3, strike-slip type with -0.3≤As≤0.3, reverse strike-slip type with 0.3 < As≤0.7, and reverse fault type with 0.7 < As≤1. Because the areal strain of horizontal strain rosette divides the focal mechanism according to the proportion of vertical and horizontal deformation caused by the source, the trouble of division by multiple combination of three axial plunge angles is avoided, and the problem of undefined type of focal mechanism is avoided. By presenting this partition strategy in spherical triangle diagram to show the focal mechanism classification, the type classification boundaries of focal mechanism are found to be symmetric. In addition, the overall sliding behavior of earthquake sequence on an active fault or seismic belt is quite important for geodynamic studies. Supposing that the earthquakes occur on a fault belt ruptured as the same focal mechanism, i.e. the released moment tensor dominated by the earthquakes with large moment tensor, and the other focal mechanisms are caused by observational errors, or secondary/minor fault rupture, then the overall focal mechanism can reflect the rupture property of the fault belt. This study proposes averaging the seismic moment tensor weighted by scalar seismic moment of the aftershocks to obtain the overall focal mechanism of earthquakes on an active fault or seismic belt, thus the difference of sliding behavior of the main shock and aftershocks can be analyzed. By adopting the above method in 2021 Qinghai Madoi earthquake sequence and 2022 Qinghai Menyuan earthquake sequence, the difference of slip properties between the main shock and other earthquakes is obtained. It is found that the overall focal mechanism of the 2022 Menyuan aftershocks is almost the same with that of the main shock, while the overall focal mechanism of the aftershocks in 2021 Madoi earthquake sequence has certain differences with that of the main shock. The method provides a tool for fault slip characteristics and geodynamic analysis in an active fault or seismic region.
-
图 2 三种典型类型震源机制的水平应变花表示
a.正断型（走向30°，倾角45°，滑动角‒90°）；b.走滑型（走向90°，倾角90°，滑动角0°）；c.逆断型（走向135°，倾角45°，滑动角90°）
Fig. 2. Horizontal strain rosettes of the 3 typical focal mechanisms
图 3 本研究的震源机制分类边界在球面三角形中的表示
三角形的3个边分别为震源机制P、T和B轴倾伏角的刻度，三角形中的点划线表示震源机制类型分类的界限.相对面应变（As）以图下方的色棒为标准采用背景颜色绘制.白线为网格线；SS.走滑型；NS.正走滑型；N.正断型；RS.逆走滑型；R.逆断型
Fig. 3. Focal mechanism classification boundaries of this study represented in spherical triangle diagram
图 4 2021年玛多地震序列的前震和余震震源机制分类及总体特征分析
a.前震和余震震源机制在球面三角形分类中的表示；余震用海滩球表示，其膨胀区颜色按照正断‒走滑‒逆冲逐渐由红色变为蓝色，主震和总体震源机制分别用’☆’和‘Δ’表示，其他表示与图 3相同.图b和图c主震震源机制和其他地震事件总体震源机制的比较.红色到蓝色表示压缩到膨胀的过渡；P、T、B分别表示压轴、张轴和中间轴
Fig. 4. Focal mechanism classification in 2021 Madoi earthquake sequence and its overall feature analysis
-
Amelung, F., King, G., 1997. Large-Scale Tectonic Deformation Inferred from Small Earthquakes. Nature, 386(6626): 702-705. https://doi.org/10.1038/386702a0 Cui, H. W., Wan, Y. G., Huang, J. C., et al., 2017. The Tectonic Stress Field in the Source of the New Britain Ms7.4 Earthquake of March 2015 and Adjacent Areas. Chinese Journal of Geophysics, 60(3): 985-998 (in Chinese with English abstract). Cui, H. W., Wan, Y. G., Wang, X. S., et al., 2021. Characteristic of Tectonic Stress Field in Source Region of 2018 Mw7.6 Palu Earthquake and Sulawesi Area. Earth Science, 46(7): 2657-2674 (in Chinese with English abstract). Du, Y., Zhang, Z. W., Ruan, X., et al., 2016. Earthquake Spatial Distribution and Stress-Field Characteristics before the Impoundment of the Dagangshan Reservoir. China Earthquake Engineering Journal, 38(S1): 36-43 (in Chinese with English abstract). Li P. E., Liao, L., Feng, J. Z., 2022. Relationship between Stress Evolution and Aftershocks after Changning M6.0 Earthquake in Sichuan on 17 June, 2019. Earth Science, 47(6): 2149-2164 (in Chinese with English abstract). Liu, J. R., Ren, Z. K., Min, W., et al., 2021. The Advance in Obtaining Fault Slip Rate of Strike Slip Fault—A Review. Earthquake Research Advances, 1(4): 100032. https://doi.org/10.1016/j.eqrea.2021.100032 Frohlich, C., 1992. Triangle Diagrams: Ternary Graphs to Display Similarity and Diversity of Earthquake Focal Mechanisms. Physics of the Earth and Planetary Interiors, 75(1-3): 193-198. https://doi.org/10.1016/0031-9201(92)90130-N Frohlich, C., 2001. Display and Quantitative Assessment of Distributions of Earthquake Focal Mechanisms. Geophysical Journal International, 144(2): 300-308. https://doi.org/10.1046/j.1365-246x.2001.00341.x Frohlich, C., Apperson, K. D., 1992. Earthquake Focal Mechanisms, Moment Tensors, and the Consistency of Seismic Activity near Plate Boundaries. Tectonics, 11(2): 279-296. https://doi.org/10.1029/91tc02888 Hanks, T. C., Kanamori, H., 1979. A Moment Magnitude Scale. Journal of Geophysical Research: Solid Earth, 84(B5): 2348-2350. https://doi.org/10.1029/jb084ib05p02348 Kaverina, A. N., Lander, A. V., Prozorov, A. G., 1996. Global Creepex Distribution and Its Relation to Earthquake-Source Geometry and Tectonic Origin. Geophysical Journal International, 125(1): 249-265. https://doi.org/10.1111/j.1365-246X.1996.tb06549.x Mallman, E. P., Parsons, T., 2008. A Global Search for Stress Shadows. Journal of Geophysical Research: Solid Earth, 113(B12): B12304. https://doi.org/10.1029/2007jb005336 Palano, M., Imprescia, P., Gresta, S., 2013. Current Stress and Strain-Rate Fields across the Dead Sea Fault System: Constraints from Seismological Data and GPS Observations. Earth and Planetary Science Letters, 369-370: 305-316. https://doi.org/10.1016/j.epsl.2013.03.043 Sheng, S. Z., Wan, Y. G., Huang, J. C., et al., 2015. Present Tectonic Stress Field in the Circum-Ordos Region Deduced from Composite Focal Mechanism Method. Chinese Journal of Geophysics, 58(2): 436-452 (in Chinese with English abstract). Wan, Y. G., 2016. Introduction to Seismology. Science Press, Beijing (in Chinese). Wan, Y. G., 2019. Determination of Center of Several Focal Mechanisms of the Same Earthquake. Chinese Journal of Geophysics, 62(12): 4718-4728 (in Chinese with English abstract). Wan, Y. G., 2020. Simulation on Relationship between Stress Regimes and Focal Mechanisms of Earthquakes. Chinese Journal of Geophysics, 63(6): 2281-2296 (in Chinese with English abstract). Wan, Y. G., Shen, Z. K., Sheng, S. Z., et al., 2009. The Influence of 2008 Wenchuan Earthquake on Surrounding Faults. Acta Seismologica Sinica, 31(2): 128-139 (in Chinese with English abstract). Wessel, P., Smith, W. H. F., 1998. New Improved Version of Generic Mapping Tools Released. EOS, Transactions American Geophysical Union, 79(47): 579. https://doi.org/10.1029/98eo00426 Xu, Y. C., Guo, X. Y., Feng, L. L., 2022. Relocation and Focal Mechanism Solutions of the Ms6.9 Menyuan Earthquake Sequence on January 8, 2022 in Qinghai Province. Acta Seismologica Sinica, 44(2): 195-210 (in Chinese with English abstract). Yang, Y. H., Zhang, X. M., Hua, Q., et al., 2021. Segmentation Characteristics of the Longmenshan Fault— Constrained from Dense Focal Mechanism Data. Chinese Journal of Geophysics, 64(4): 1181-1205 (in Chinese with English abstract). Yu, C. P., Vavryčuk, V., Adamová, P., et al., 2018. Moment Tensors of Induced Microearthquakes in the Geysers Geothermal Reservoir from Broadband Seismic Recordings: Implications for Faulting Regime, Stress Tensor, and Fluid Pressure. Journal of Geophysical Research: Solid Earth, 123(10): 8748-8766. https://doi.org/10.1029/2018jb016251 Zhang, J. Y., Wang, X., Chen, L., et al., 2022. Seismotectonics and Fault Geometries of the Qinghai Madoi Ms7.4 Earthquake Sequence: Insight from Aftershock Relocations and Focal Mechanism Solutions. Chinese Journal of Geophysics, 65(2): 552-562 (in Chinese with English abstract). Zhang, Z. W., Ruan, X., Wang, X. S., et al., 2015. Spatial-Temporal Evolution of Stress Fields in Sichuan Area before and after the 2008 Wenchuan and the 2013 Lushan Earthquake. Earthquake, 35(4): 136-146 (in Chinese with English abstract). Zheng, J. C., Wang, P., Li, D. M., et al., 2013. Tectonic Stress Field in Shandong Region Inferred from Small Earthquake Focal Mechanism Solutions. Acta Seismologica Sinica, 35(6): 773-784 (in Chinese with English abstract). Zoback, M. L., 1992. First- and Second-Order Patterns of Stress in the Lithosphere: The World Stress Map Project. Journal of Geophysical Research: Solid Earth, 97(B8): 11703-11728. https://doi.org/10.1029/92jb00132 崔华伟, 万永革, 黄骥超, 等, 2017.2015年3月新不列颠Ms7.4地震震源及邻区构造应力场特征. 地球物理学报, 60(3): 985-998. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201703014.htm 崔华伟, 万永革, 王晓山, 等, 2021.2018年帕卢Mw7.6地震震源及苏拉威西地区构造应力场特征. 地球科学, 46(7): 2657-2674. doi: 10.3799/dqkx.2020.243 杜瑶, 张致伟, 阮祥, 等, 2016. 大岗山水库蓄水前库区地震空间分布及应力场特征. 地震工程学报, 38(S1): 36-43. https://www.cnki.com.cn/Article/CJFDTOTAL-ZBDZ2016S1006.htm 李平恩, 廖力, 奉建州, 2022.2019年6月17日四川长宁6.0级地震震后应力演化与余震关系研究. 地球科学, 47(6): 2149-2164. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202206019.htm 盛书中, 万永革, 黄骥超, 等, 2015. 应用综合震源机制解法推断鄂尔多斯块体周缘现今地壳应力场的初步结果. 地球物理学报, 58(2): 436-452. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201502008.htm 万永革, 2016. 地震学导论. 北京: 科学出版社. 万永革, 2019. 同一地震多个震源机制中心解的确定. 地球物理学报, 62(12): 4718-4728. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201912018.htm 万永革, 2020. 震源机制与应力体系关系模拟研究. 地球物理学报, 63(6): 2281-2296. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX202006017.htm 万永革, 沈正康, 盛书中, 等, 2009.2008年汶川大地震对周围断层的影响. 地震学报, 31(2): 128-139. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXB200902002.htm 许英才, 郭祥云, 冯丽丽, 2022.2022年1月8日青海门源Ms6.9地震序列重定位和震源机制解研究. 地震学报, 44(2): 195-210. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXB202202002.htm 杨宜海, 张雪梅, 花茜, 等, 2021. 龙门山断裂带的分段性特征——来自密集震源机制解的约束. 地球物理学报, 64(4): 1181-1205. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX202104005.htm 张建勇, 王新, 陈凌, 等, 2022. 基于余震重定位和震源机制解研究青海玛多Ms7.4地震序列的发震构造和断裂形态. 地球物理学报, 65(2): 552-562. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX202202009.htm 张致伟, 阮祥, 王晓山, 等, 2015. 汶川、芦山地震前后四川地区应力场时空演化. 地震, 35(4): 136-146. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZN201504015.htm 郑建常, 王鹏, 李冬梅, 等, 2013. 使用小震震源机制解研究山东地区背景应力场. 地震学报, 35(6): 773-784. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXB201306001.htm -
