Evolution of Basin-Range Pattern in Southwest Margin of Yangtze Block during Late Triassic to Early Jurassic: Evidence of Detrital Zircon U-Pb Geochronology from Chuxiong Basin
-
摘要: 印支期扬子西南缘沉积盆地大地构造性质及盆山格局演化过程长期存在较大分歧. 对楚雄盆地西侧祥云剖面上三叠统-下侏罗统砂岩样品进行碎屑锆石U-Pb定年和碎屑物源分析. 结果显示，上三叠统云南驿组和罗家大山组碎屑物源主要来自上扬子地区的中-下三叠统和二叠系，而上三叠统白土田组和下侏罗统冯家河组碎屑物源主要来自松潘-甘孜地体和康滇古陆. 结合沉积环境演变和区域地质背景，认为在晚三叠世早期，区域内造山作用相对较弱，楚雄盆地碎屑物源供给不足，为欠补偿盆地；晚三叠世晚期-早侏罗世，虽然楚雄盆地的构造演化受哀牢山造山带逆冲推覆作用的控制，但是楚雄盆地的沉积充填过程主要受控于快速崛起的松潘-甘孜造山带.Abstract: There exist divergent views about the Indosinian tectonic nature of basin and the evolution of basin-range pattern in the southwest margin of the Yangtze block. Detrital zircon U-Pb dating and detrital provenance analysis of sandstone samples from the Upper Triassic-Lower Jurassic of Xiangyun Section in the western Chuxiong basin were carried out. The results show that the detrital sources of the Upper Triassic Yunnanyi Formation and Luojiadashan Formation are mainly from the Middle-Lower Triassic and Permian in the Upper Yangtze region. The detrital sources of the Upper Triassic Baitutian Formation and the Lower Jurassic Fengjiahe Formation are mainly from the Songpan-Ganzi terrane and Kangdian ancient land.Combined with the sedimentary environment evolution and regional geological setting, it is considered that the orogeny is relatively weak during the earlier Late Triassic, and Chuxiong basin is an underfilled basin, whose clastic source supply is insufficient. From the later Late Triassic to Early Jurassic, the tectonic evolution of Chuxiong basin was controlled by the thrust nappe of Ailaoshan orogenic belt, but the sedimentary filling process of Chuxiong basin was mainly controlled by the rapid rise of Songpan-Ganzi orogenic belt.
-
图 1 上扬子及邻区地质简图
AMLS. 阿尼玛卿-勉略缝合带；ALS. 哀牢山缝合带；BNS. 班公湖-怒江缝合带；BST.保山地体；GLS.甘孜-理塘缝合带；JS.金沙江缝合带；LST.兰坪-思茅地体；LT.拉萨地体；NCB.华北陆块；QT.羌塘地体；SDS.商丹缝合带；SGT.松潘-甘孜地体；YD.义敦地体
Fig. 1. Simplified geological map of the Upper Yangtze Block and adjacent areas
图 2 楚雄盆地及邻区地质简图
Fig. 2. Simplified geological maps of Chuxiong basin and adjacent regions
图 3 楚雄盆地祥云剖面上三叠统-下侏罗统综合柱状图
Fig. 3. The Upper Triassic-Lower Jurassic profile of Xiangyun section in Chuxiong basin
图 4 楚雄盆地上三叠统-下侏罗统碎屑锆石和潜在物源区锆石年龄KDE图和200~300 Ma年龄直方图
a~d. 分别为本文XY06、XY07、XY05、XY04样品碎屑锆石KDE图；e. TT指上扬子地区中三叠统火山灰夹层获得的锆石年龄（Yan et al.，2019；李宸等，2020；刘建清等，2021）；f. PCT指上扬子地区中、晚二叠世碎屑岩和火山灰（包括峨眉山玄武岩及沉积岩中的火山灰夹层）的锆石年龄（He et al.，2007；Zhonget al.，2014；Huang et al.，2016；Huang et al.，2018）；g. SG指松潘-甘孜地区下、中三叠统碎屑锆石年龄（Weislogel et al.，2006，2010；Enkelmann et al.，2007；Ding et al.，2013）；h.YD指义敦地体南部下、中三叠统碎屑锆石年龄（Wang et al.，2013）；i. ALS指哀牢山地区志留系和泥盆系碎屑锆石年龄（Xia et al.，2016）；j. KD指康滇古陆地区前二叠纪地层锆石年龄（Zhou et al.，2006；Sun et al.，2009；Wang et al.，2012）
Fig. 4. KDE plot and 200-300 Ma age histograms of detrital zircons from the Upper Triassic-Lower Jurassic in Chuxiong basin and potential provenance area
图 5 楚雄盆地上三叠统-下侏罗统碎屑锆石年龄和潜在物源区锆石年龄MDS图
距离越近的年龄数，其亲缘关系越强；实线代表亲缘关系较强，虚线代表亲缘关系较弱
Fig. 5. MDS plot of the Upper Triassic-Lower Jurassic detrital zircon age in Chuxiong basin and potential provenance area
-
Chen, G.W., Wu, Y.Z., 1999. The Formation and Evolution of Chuxiong Back-Arc Foreland Basin. Yunnan Geology, 18(4): 392-397(in Chinese with English abstract). Deng, F., Jia, D., Luo, L., et al., 2008. The Contrast between Provenances of Songpan-Garze and Western Sichuan Foreland Basin in the Late Triassic: Clues to the Tectonics and Palaeogeography. Geological Review, 54(4): 561-573(in Chinese with English abstract). doi: 10.3321/j.issn:0371-5736.2008.04.017 Dickinson, W. R., Beard, L. S., Brakenridge, G. R., et al., 1983. Provenance of North American Phanerozoic Sandstones in Relation to Tectonic Setting. Geological Society of America Bulletin, 94(2): 222. https://doi.org/10.1130/0016-7606(1983)94222:ponaps>2.0.co;2 doi: 10.1130/0016-7606(1983)94222:ponaps>2.0.co;2 Ding, L., Yang, D., Cai, F. L., et al., 2013. Provenance Analysis of the Mesozoic Hoh-Xil-Songpan-Ganzi Turbidites in Northern Tibet: Implications for the Tectonic Evolution of the Eastern Paleo-Tethys Ocean. Tectonics, 32(1): 34-48. https://doi.org/10.1002/tect.20013 Enkelmann, E., Weislogel, A., Ratschbacher, L., et al., 2007. How was the Triassic Songpan-Ganzi Basin Filled? A Provenance Study. Tectonics, 26(4): TC4007. https://doi.org/10.1029/2006tc002078 Gan, W. J., Molnar, P., Zhang, P. Z., et al., 2022. Initiation of Clockwise Rotation and Eastward Transport of Southeastern Tibet Inferred from Deflected Fault Traces and GPS Observations. GSA Bulletin, 134(5/6): 1129-1142. https://doi.org/10.1130/b36069.1 Gong, X.D., Tang, Y., Qin, Y.D., et al., 2020. Late Triassic Collision of Jinshajiang Suture Belt: Geochronological, Geochemical and Hf Isotope Evidences from Quartz Monzonite in Gonjo Area. Earth Science, 45(8): 2905-2919(in Chinese with English abstract). Griffin, W.L., Powell, W.J., Pearson, N.J., et al., 2008. GLITTER: Data Reduction Software for Laser Ablation ICP-MS. In: Sylvester, P., ed., Laser Ablation-IPS-MS in the Earth Sciences, Current Practices and Outstanding Issues. Mineralogical Association of Canada, 40: 308-311. Guo, P., Li, C.Z., 2013. A Summary of the Nature of Chuxiong Basin. Ground Water, 35(5): 194-196(in Chinese). doi: 10.3969/j.issn.1004-1184.2013.05.073 He, B., Xu, Y. G., Huang, X. L., et al., 2007. Age and Duration of the Emeishan Flood Volcanism, SW China: Geochemistry and SHRIMP Zircon U-Pb Dating of Silicic Ignimbrites, Post-Volcanic Xuanwei Formation and Clay Tuff at the Chaotian Section. Earth and Planetary Sciences Letters, 255(3-4): 306-323. https://doi.org/10.1016/j.epsl.2006.12.021 Hu, X.M., Xue, W.W., Lai, W., et al., 2021. Sedimentary Basins in Orogenic Belt and Continental Geodynamics. Acta Geologica Sinica, 95(1): 139-158(in Chinese with English abstract). Huang, H., Cawood, P. A., Hou, M. C., et al., 2018. Provenance of Late Permian Volcanic Ash Beds in South China: Implications for the Age of Emeishan Volcanism and Its Linkage to Climate Cooling. Lithos, 314/315: 293-306. https://doi.org/10.1016/j.lithos.2018.06.009 Huang, H., Cawood, P.A., Hou, M.C., et al., 2016. Silicic Ash Beds Bracket Emeishan Large Igneous Province to < 1 M. y. at ~ 260 Ma. Lithos, 264: 17-27. https://doi.org/10.1016/j.lithos.2016.08.013 Jackson, S. E., Pearson, N. J., Griffin, W. L., et al., 2004. The Application of Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry to In Situ U-Pb Zircon Geochronology. Chemical Geology, 211(1-2): 47-69. https://doi.org/10.1016/j.chemgeo.2004.06.017 Jiang, L., Deng, B., Liu, S.G., et al., 2018. Differential Uplift and Fragmentation of Upper Yangtze Basin in Cenozoic. Earth Science, 43(6): 1872-1886(in Chinese with English abstract). Li, C., Lang, X.H., Deng, Y.L., et al., 2020. Geochronological and Geochemical Characteristics of the Claystone (Mung Bean Rock) at the Bottom of the Leikoupo Formation in the Emeishan Area, Sichuan Basin, China. Bulletin of Mineralogy, Petrology and Geochemistry, 39(4): 810-825(in Chinese with English abstract). Li, S. H., Advokaat, E. L., van Hinsbergen, D. J. J., et al., 2017. Paleomagnetic Constraints on the Mesozoic-Cenozoic Paleolatitudinal and Rotational History of Indochina and South China: Review and Updated Kinematic Reconstruction. Earth-Science Reviews, 171: 58-77. https://doi.org/10.1016/j.earscirev.2017.05.007 Liu, J.Q., He, L., Chen, F.L., et al., 2021. Studies on the Chronology and Geochemistry of the Green Pisolites at the Bottom of the Middle Triassic Guanling Formation in Yanjin Area, Northeastern Yunnan Province. Acta Petrologica Sinica, 37(7): 2245-2255(in Chinese with English abstract). doi: 10.18654/1000-0569/2021.07.16 Sun, W. H., Zhou, M. F., Gao, J. F., et al., 2009. Detrital Zircon U-Pb Geochronological and Lu-Hf Isotopic Constraints on the Precambrian Magmatic and Crustal Evolution of the Western Yangtze Block, SW China. Precambrian Research, 172(1/2): 99-126. Tan, F.W., Yin, F.G., Xu, X.S., et al., 2004. Relationship of Tectonics to Sedimentary Evolution of Chuxiong Foreland Basin. Geotectonica et Metallogenia, 28(3): 345-352(in Chinese with English abstract). doi: 10.3969/j.issn.1001-1552.2004.03.016 Tapponnier, P., Lacassin, R., Leloup, P. H., et al., 1990. The Ailao Shan/Red River Metamorphic Belt: Tertiary Left-Lateral Shear between Indochina and South China. Nature, 343(6257): 431-437. https://doi.org/10.1038/343431a0 Vermeesch, P., Resentini, A., Garzanti, E, 2016. An R Package for Statistical Provenance Analysis. Sedimentary Geology, 336: 14-25. https://doi.org/10.1016/j.sedgeo.2016.01.009 Wang, B. Q., Wang, W., Chen, W. T., et al., 2013. Constraints of Detrital Zircon U-Pb Ages and Hf Isotopes on the Provenance of the Triassic Yidun Group and Tectonic Evolution of the Yidun Terrane, Eastern Tibet. Sedimentary Geology, 289: 74-98. https://doi.org/10.1016/j.sedgeo.2013.02.005 Wang, L. J., Yu, J. H., Griffin, W. L., et al., 2012. Early Crustal Evolution in the Western Yangtze Block: Evidence from U-Pb and Lu-Hf Isotopes on Detrital Zircons from Sedimentary Rocks. Precambrian Research, 222/223: 368-385. https://doi.org/10.1016/j.precamres.2011.08.001 Weislogel, A. L., Graham, S. A., Chang, E. Z., et al., 2006. Detrital Zircon Provenance of the Late Triassic Songpan-Ganzi Complex: Sedimentary Record of Collision of the North and South China Blocks. Geology, 34(2): 97. https://doi.org/10.1130/g21929.1 Weislogel, A. L., Graham, S. A., Chang, E. Z., et al., 2010. Detrital Zircon Provenance from Three Turbidite Depocenters of the Middle-Upper Triassic Songpan-Ganzi Complex, Central China: Record of Collisional Tectonics, Erosional Exhumation, and Sediment Production. Geological Society of America Bulletin, 122(11-12): 2041-2062. https://doi.org/10.1130/b26606.1 Wiedenbeck, M., Hanchar, J. M., Peck, W. H., et al., 2004. Further Characterisation of the 91500 Zircon Crystal. Geostandards and Geoanalytical Research, 28(1): 9-39. https://doi.org/10.1111/j.1751-908x.2004.tb01041.x Wu, G.Y., Takao, Y., 1993. Late Triassic Sedimentary. Gravity Flow Deposits in Central Yunnan and Their Geological Significances. Geotectonica et Metallogenia, 17(4): 305-313(in Chinese with English abstract). Xia, X. P., Nie, X. S., Lai, C. K., et al., 2016. Where was the Ailaoshan Ocean and When did It Open: A Perspective Based on Detrital Zircon U-Pb Age and Hf Isotope Evidence. Gondwana Research, 36: 488-502. https://doi.org/10.1016/j.gr.2015.08.006 Xu, X.S., Yin, F.G., Wan, F., et al., 1999. The Nature of the Chuxiong Basin and Evolution of Sedimentary Sequences. Sedimentary Facies and Palaeogeography, 19(5): 1-11(in Chinese with English abstract). doi: 10.3969/j.issn.1009-3850.1999.05.001 Xu, Y.J., Du, Y.S., Yang, J.H., 2007. Prospects of Sediment Provenance Analysis. Geological Science and Technology Information, 26(3): 26-32(in Chinese with English abstract). doi: 10.3969/j.issn.1000-7849.2007.03.005 Xu, Z.Q., Hou, L.W., Wang, Z.X., et al., 1992. Orogenic Processes of the Songpan-Garze Orogenic Belt of China. Geological Publishing House, Beijing, 199 (in Chinese with English abstract). Yan, Z. K., Dong, S. L., Li, Y., et al., 2019. Detrital Zircon U‐Pb Geochronology of the Triassic Sandstones from the Yanyuan Basin of Southwestern Sichuan, China. Acta Geologica Sinica, 93(6): 1974-1975. https://doi.org/10.1111/1755-6724.13844 Yang, Q.D., Chen, M.C., Mao, S.E., et al., 2017. Important Deep-Buried Geological Discovery and Its' Significance in Chuxiong Basin of Mid-Yunnan Province. Journal of Yunnan University (Natural Sciences Edition), 39(S2): 287-296(in Chinese with English abstract). Zeng, Q.G., Wang, B.D., Xiluo, L.J., et al., 2020. Suture Zones in Tibetan and Tethys Evolution. Earth Science, 45(8): 2735-2763(in Chinese with English abstract). Zhan, Q. Y., Zhu, D. C., Wang, Q., et al., 2018. Constructing the Eastern Margin of the Tibetan Plateau during the Late Triassic. Journal of Geophysical Research: Solid Earth, 123(12): 10449-10459. https://doi.org/10.1029/2018jb016353 Zhong, Y. T., He, B., Mundil, R., et al., 2014. CA-TIMS Zircon U-Pb Dating of Felsic Ignimbrite from the Binchuan Section: Implications for the Termination Age of Emeishan Large Igneous Province. Lithos, 204: 14-19. https://doi.org/10.1016/j.lithos.2014.03.005 Zhou, M., Ma, Y., Yan, D., et al., 2006. The Yanbian Terrane (Southern Sichuan Province, SW China): A Neoproterozoic Arc Assemblage in the Western Margin of the Yangtze Block. Precambrian Research, 144(1-2): 19-38. https://doi.org/10.1016/j.precamres.2005.11.002 Zhu, M., Chen, H. L., Zhou, J., et al., 2017. Provenance Change from the Middle to Late Triassic of the Southwestern Sichuan Basin, Southwest China: Constraints from the Sedimentary Record and Its Tectonic Significance. Tectonophysics, 700/701: 92-107. https://doi.org/10.1016/j.tecto.2017.02.006 陈根文, 吴延之, 1999. 楚雄弧后前陆盆地的形成及演化. 云南地质, 18(4): 392-397. https://www.cnki.com.cn/Article/CJFDTOTAL-YNZD199904002.htm 邓飞, 贾东, 罗良, 等, 2008. 晚三叠世松潘甘孜和川西前陆盆地的物源对比: 构造演化和古地理变迁的线索. 地质论评, 54(4): 561-573. doi: 10.3321/j.issn:0371-5736.2008.04.017 巩小栋, 唐渊, 秦雅东, 等, 2020. 晚三叠世金沙江结合带碰撞作用: 贡觉石英二长岩年代学、地球化学及Hf同位素证据. 地球科学, 45(8): 2905-2919. doi: 10.3799/dqkx.2020.221 郭佩, 李长志, 2013. 楚雄盆地的性质综述. 地下水, 35(5): 194-196. doi: 10.3969/j.issn.1004-1184.2013.05.073 胡修棉, 薛伟伟, 赖文, 等, 2021. 造山带沉积盆地与大陆动力学. 地质学报, 95(1): 139-158. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE202101011.htm 姜磊, 邓宾, 刘树根, 等, 2018. 上扬子盆地新生代差异抬升剥蚀与分异过程. 地球科学, 43(6): 1872-1886. doi: 10.3799/dqkx.2018.597 李宸, 郎兴海, 邓煜霖, 等, 2020. 四川盆地峨眉山雷口坡组底部黏土岩(绿豆岩)的年代学及地球化学特征. 矿物岩石地球化学通报, 39(4): 810-825. https://www.cnki.com.cn/Article/CJFDTOTAL-KYDH202004016.htm 刘建清, 何利, 陈风霖, 等, 2021. 滇东北盐津地区中三叠统关岭组底部绿豆岩年代学及地球化学研究. 岩石学报, 37(7): 2245-2255. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB202107016.htm 谭富文, 尹福光, 许效松, 等, 2004. 楚雄前陆盆地的构造特征与沉积演化. 大地构造与成矿学, 28(3): 345-352. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK200403015.htm 吴根耀, 矢野孝雄, 1993. 滇中地区晚三叠世的重力流沉积及其地质意义. 大地构造与成矿学, 17(4): 305-313. https://www.cnki.com.cn/Article/CJFDTOTAL-DGYK199304001.htm 许效松, 尹福光, 万方, 等, 1999. 楚雄盆地性质与沉积层序演化. 岩相古地理, 19(5): 1-11. https://www.cnki.com.cn/Article/CJFDTOTAL-YXGD199905000.htm 徐亚军, 杜远生, 杨江海, 2007. 沉积物物源分析研究进展. 地质科技情报, 26(3): 26-32. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200703005.htm 许志琴, 侯立玮, 王宗秀, 1992. 中国松潘-甘孜造山带的造山过程. 北京: 地质出版社. 杨庆道, 陈明春, 卯升俄, 等, 2017. 滇中楚雄盆地地腹构造-沉积特征重要发现及地质意义. 云南大学学报(自然科学版), 39(S2): 287-296. https://www.cnki.com.cn/Article/CJFDTOTAL-YNDZ2017S2046.htm 曾庆高, 王保弟, 西洛郎杰, 等, 2020. 西藏的缝合带与特提斯演化. 地球科学, 45(8): 2735-2763. doi: 10.3799/dqkx.2020.152 -
