Zhongnan-Liyue Fault Zone Developed at Continental Margins of the South China Sea and Tectonic Movements
-
摘要: 南海南、北陆缘是否发育与目前中央海盆中存在的中南-礼乐断裂有关的S-N向走滑断裂带，一直是从事南海构造演化研究者关注的焦点之一，皆因资料缺乏等原因而没有定论.通过分析南海陆缘残余中生界的分布特征与精细解释最新地质-地球物理资料破解这一难题.南海陆缘发育S-N向延伸的中南-礼乐断裂带，构造属性为大型走滑断裂，初始活动时间始于中生代.新生代南海发生海底扩张之前，发育在南、北陆缘的中南-礼乐断裂带基本相连，长约700 km.该断裂带在不同时期具有不同的构造活动特征.中生代为左旋走滑构造活动，古近纪早、中期具有走滑拉张的活动特征，晚古近纪与早新近纪以走滑活动为主，新近纪中、晚期为走滑挤压活动特征.Abstract: Whether a strike-slip fault zone of S-N trend developed in the centre South China Sea (SCS) has been focused by geologists who study tectonic evolution, but no any conclusion due to lack of data.The difficult issue has been resolved in this paper by studying the distribution of residual Mesozoic strata and interpreting new geological and geophysics data in the SCS. Zhongnan-Liyue (ZL) fault zone, a strike-slip fault zone with S-N trend, developed at both southern and northern continental margins and the initial time of its activity was at least in Mesozoic.Before sea-floor spreading of the SCS, this strike-slip fault zone attains about 700 km at southern and northern continental margins. In different geological times this fault zone was of different characteristics of tectonic movement, that was strike slip of left-rotation in Mesozoic, strike slip and extension in Early-Middle Paleogene, in order to strike slip in Late Paleogene and Early Neogene, last one strike slip accompanying pressure function in Middle-Late Neogene.
-
图 1 根据残余中生界分布所推测的南海陆缘中南-礼乐断裂带分布
Fig. 1. Location of Zhongnan-Liyue (ZL) fault zone revealed by distribution of residual Mesozoic strata at continental margin of the SCS
图 2 北部陆缘地貌特征与测线位置(a); 南部陆缘地貌特征与测线位置(b); 南海陆缘地层系统与年代以及对应的地震反射界面(c)
Fig. 2. Topography and morphology of northern continental margin of the SCS and locations of lines (a); topography and morphology of southern continental margin of the SCS and location of line (b); stratigraphy system and geological ages with corresponding seismic reflectors, continental margins of SCS (c)
图 3 南海北部陆缘空间重力异常特征与推测的中南-礼乐断裂带轨迹(a)；南海北部陆缘磁异常场(ΔT)特征与推测的中南-礼乐断裂带轨迹(b)
空间重力异常和磁异常背景据中国地质调查局广州海洋地质调查局（2015）南海地质地球物理图系（1∶200万）
Fig. 3. Feature of free-air gravity anomaly and speculate location of ZL fault zone at northern continental margin of SCS (a); feature of magnetic anomaly and speculate location of ZL fault zone at northern continental margin of SCS (b)
图 4 南海南部陆缘空间重力异常场与中南-礼乐断裂推测轨迹(a); 南海南部陆缘磁异常场(ΔT)与中南-礼乐断裂带推测轨迹(b)
空间重力异常背景和磁异常背景据中国地质调查局广州海洋地质调查局（2015）南海地质地球物理图系（1∶200万）
Fig. 4. Free-air gravity anomaly and speculate location of ZL fault zone at southern continental margin of SCS (a); magnetic anomaly and location of ZL fault zone at southern continental margin of SCS (b)
图 7 ZtL160剖面示位于南海北部陆坡坡脚处的中南-礼乐断裂带(测线位置2)
Fig. 7. Characteristics of Zhongnan-Liyue fault zone at slope foot of northern SCS on the seismic profile ZtL160 (location of the line in Fig.2a)
图 9 OBS 4号台站示与大型断裂有关的异常震相(a); OBS1号台站~15号台站射线路径图(b)
箭头所指是与断裂有关的射线路径
Fig. 9. Abnormal seismic facies related to major fault on OBS No. 3 (a); Ray-paths OBS No.1—OBS No.15 (b)
图 10 LF-1测线示珠江口盆地中生界反射(a)；CFC测线示台西南盆地中生界反射(b)
Fig. 10. Reflectors of Mesozoic stratigraphy in Pearl River Mouth Basin on line LF-1(a); reflectors of Mesozoic stratigraphy in Taixinan Basin on line CFC(b)
图 11 花岗质糜棱岩中钾长石旋转斑(a)；花岗岩中的“S-C”组构(b)
露头经纬度：a. 118°31′E，24°46′N；b. 118°41′E，24°40′N
Fig. 11. Rotating maculosus of potassium feldspar in granite mylonite (a); fabric "S-C" in granite rock(b)
图 12 南海东部陆缘左行走滑运动形成雁列式构造示意图
Fig. 12. Sketch of strike-slip movement in evolution and goose echelon structure at the eastern continental margin of the SCS
-
Barckhausen, U., Engels, M., Franke, D. et al., 2014. Evolution of the South China Sea: Revised Ages for Breakup and Seafloor Spreading. Marine and Petroleum Geology, 58: 599-611. https://doi.org/10.1016//j.marpetgeo.2014.02.022 Cameselle, A. L., Ranero, C. R., Franke, D., et al., 2017. The Continent-Ocean Transition on the Northwestern South China Sea. Basin Research, 29(S1): 73-95. https://doi.org/10.1111/bre.12137 Cullen, A. B., 2010. Transverse Segmentation of the Baram-Balabac Basin, NW Borneo: Refining the Model of Borneo's Tectonic Evolution. Petroleum Geoscience, 16(1): 3-29. https://doi.org/10.1144/1354-079309-828 Franke, D., 2013. Rifting, Lithosphere Breakup and Volcanism: Comparison of Magma Poor and Volcanic Rifted Magins. Marine and Petroleum Geology, 43: 63-87. https://doi.org/10.1016//j marpetgeo. 2012. 11.003 doi: 10.1016//jmarpetgeo.2012.11.003 Gong, Z. S., Li, S. T., 1997. Continental Margin Basin Analysis and Hydrocarbon Accumulation of the Northern South China Sea. Science Press, Beijing (in Chinese). Hao, H. J., Wang, R. L., Zhang, X. T., et al., 2004. Mesozoic Marine Sediment Identification and Distribution in the Eastern Pearl River Mouth Basin. China Offshore Oil, 16(2): 84-88(in Chinese with English abstract). Hayes, D. E., Nissen, S. S., Buhl, P., et al., 1995. Through Going Crustal Faults along the Northern Margin of the South China Sea and Their Role in Crustal Extension. Journal of Geophysical Research: Solid Earth, 100(B11): 22435-22446. https://doi.org/10.1029/95jb01867 Huang, Q. Y., Yan, Y., Zhao, Q. H., et al., 2012. Cenozoic Stratigraphy of Taiwan: Looking into Rifting, Stratigraphy and Paleoceanography of South China Sea. Chinese Science Bulletin, 57(20): 1842-1862 (in Chinese). doi: 10.1360/csb2012-57-20-1842 Ju, D., Qiu, Y., Huang, W. K., et al., 2022. Activity Characteristics of Main Sag-Controlling Faults and Cenozoic Initial Crustal Rifting in the South China Sea. Marine Geology Frontiers, 38(9): 59-70(in Chinese with English abstract). Kudrass, H. R., Wiedicke, M., Cepek, P., et al., 1986. Mesozoic and Cainozoic Rocks Dredged from the South China Sea (Reed Bank Area) and Sulu Sea and Their Significance for Plate-Tectonic Reconstructions. Marine and Petroleum Geology, 3(1): 19-30. https://doi.org/10.1016/0264-8172(86)90053-X Li, Y. H., Liu, H. L., Zhu, R. W., et al., 2017. Extension of the Zhongnan-Siling Fault Zone in South China Sea and Its Bearing on Seafloor Spreading. Marine Geology & Quaternary Geology, 37(2): 82-98(in Chinese with English abstract). Liu, H. L., Guo, L. Z., Sun, Y., et al., 2002. Study on Fault System in Nansha Block (South China Sea) and the Block's Lithospheric Dynamics. Science Press, Beijing(in Chinese). Liu, H. L., Yang, S. K., Zhou, D., et al., 1998. Basic Characteristics of Extension Structure in Northern Nansha Islands, China, and Its Dynamical Implications. Geological Journal of China Universities, 4(1): 64-72(in Chinese with English abstract). Liu, H. L., Zheng, H. B., Wang, Y. L., et al., 2011. Layer-Block Tectonics, a New Concept of Plate Tectonics: An Example from Nansha Micro-Plate, Southern South China Sea. In: Closson, D., ed., Tectonics. In Tech, Rijeka, Croatia. Qiu, Y., Huang, W. K., Du, W. B., et al., 2021. Analysis on the Formation of the Thin Continental Crust in the South China Sea. Earth Science, 46(3): 899-915(in Chinese with English abstract). Qiu, Y., Sun, G. H., Wang, Y., 2018. Subduction of the Mesozoic Pacific Ocean Plate and Its Bearing on Mesozoic Deposits in the South China Sea. Marine Geology Frontiers, 34(7): 1-8(in Chinese with English abstract). Qiu, Y., Wang L. F., Huang W. K., et al., 2016. Sedimentary Basins in Mesozoic and Cenozoic in the China Seas. Geological Publishing House, Beijing(in Chinese). Qiu, Y., Zeng, W. J., Li, T. G., 2005. Fracture Systems and Their Tectonic Significance in the Central and Southern Parts of the South China Sea. Geotectonica et Metallogenia, 29(2): 166-175(in Chinese with English abstract). Ru, K., Pigott, J. D., 1986. Episodic Rifting and Subsidence in the South China Sea. American Association of Petroleum, Geologists Bulletin, 70(9): 1136-1155. https://doi.org/10.1029/JB091iB10p10513 Ruan, A. G., Wei, X. D., Niu, X. W., et al., 2016. Crustal Structure and Fracture Zone in the Central Basin of the South China Sea from Wide Angle Seismic Experiments Using OBS. Tectonophysics, 688: 1-10. Schlüter, H. U., Hinz, K., Block, M., 1996. Tectono-Stratigraphic Terranes and Detachment Faulting of the South China Sea and Sulu Sea. Marine Geology, 130(1-2): 39-78. https://doi.org/10.1016/0025-3227(95)00137-9 Sibuet, J. C., Yeh, Y. C., Li, C. S., 2016. Geodynamics of South China Sea. Tectonophysics, 692: 98-119. https://doi.org/10.1016//j.tecto. 2016. 09.022 doi: 10.1016//j.tecto.2016.09.022 Taylor, B., Hayes, D. E., 1983. Origin and History of the South China Sea Basin. In: Hayes, D. E., ed., The Tectonic and Geologic Evolution of Southeast Asian Seas and Islands. Geophysical Monograph Series, American Geophysical Union, 27: 23-56. Wang, J., Luan, X. W., He, B. S., et al., 2021. Characteristics and Genesis of Faults in Southwestern Pearl River Mouth Basin, Northern South China Sea. Earth Science, 46(3): 916-928(in Chinese with English abstract). Wang J., Qiu Y., Yan P., et al., 2019. A Joint Investigation Using OBS, Multi-Channel Seismic and Gravity Data Across the Southwest Sub-Basin of the South China Sea. Journal of Tropic Oceanology, 38(4): 81-90 (in Chinese with English abstract). Xie, X. N., Ren, J. Y., Wang, Z. F., et al., 2015. Difference of Tectonic Evolution of Continental Marginal Basins of South China Sea and Relationship with SCS Spreading. Earth Science Frontiers, 22(1): 77-87(in Chinese with English abstract). Xu, H., Sun, H. Q., Li, G., 2003. Geologic Exploration and Development of Cenozoic Oil and Gas in Taixi Basin. Marine Geology Frontiers, 19(8): 27-31(in Chinese with English abstract). Xu, Z. Y., Wang, J., Yao, Y. J., et al., 2021. The Temporal-Spatial Distribution and Deep Structure of the Zhongnan-Liyue Fault Zone in the North of the South China Sea Basin. Earth Science, 46(3): 942-955(in Chinese with English abstract). Yan, P., Wang, Y. L., Liu, H. L., 2008. Topography of Oceanic Basin in South China Sea and NW-Directed Faults. Journal of Tropical Oceanography, 27(3): 30-37(in Chinese with English abstract). Yao, B. C., Zeng, W. J., Taylor, B., et al., 1994. The Geological Memoir of South China Sea Surveyed Jointly by China & USA. China University of Geosciences Press, Wuhan (in Chinese). Yao, B. C., 1995. Characteristics and Tectonic Meaning of Zhongnan-Lile Fault. Research of Eological South China Sea, (7): 1-14(in Chinese). Yin, Y. H., Wen, Z. H., Sun, G. H., et al., 2013. Types, Distribution and Geological Feature of the Main Faults in the Southern China Seas. Marine Geology Frontiers, 29(8): 1-6(in Chinese with English abstract). Zhang, G. C., Wang, P. J., Wu, J. F., et al., 2015. Tectonic Cycle of Marginal Oceanic Basin: A New Evolution Model of the South China Sea. Earth Science Frontiers, 22(3): 27-37(in Chinese with English abstract). Zhong, G. J., Feng, C. M., Wang, Y. L., et al., 2022. Fault-Bounded Models of Oil-Gas and Gas-Hydrate Accumulation in the Chaoshan Depression, the South China Sea. Frontiers in Earth Science, 10: 965898. https://doi.org/10.3389/feart.2022.965898 Zhong, J. Q., Huang, C. L., Zhan, W. H., 1994. Analyses of Cenozoic Tectonic Events in Taixi Basin, Taiwan Strait. Journal of Oceanography in Taiwan Strait, 13(4): 323-341(in Chinese with English abstract). 龚再升, 李思田, 1997. 南海北部大陆边缘盆地分析与油气聚集. 北京: 科学出版社. 郝沪军, 汪瑞良, 张向涛, 等, 2004. 珠江口盆地东部海相中生界识别及分布. 中国海上油气, 16(2): 84-88. 黄奇瑜, 闫义, 赵泉鸿, 等, 2012. 台湾新生代层序: 反映南海张裂, 层序和古海洋变化机制. 科学通报, 57(20): 1842-1862. 鞠东, 邱燕, 黄文凯, 等, 2022. 南海主要控凹断层活动特征与新生代地壳初始张裂. 海洋地质前沿, 38(9): 59-70. 黎雨晗, 刘海龄, 朱荣伟, 等, 2017. 南海中南-司令断裂带的延伸特征及其与南海扩张演化的关系. 海洋地质与第四纪地质, 37(2): 82-98. 刘海龄, 郭令智, 孙岩, 等, 2002. 南沙地块断裂构造系统与岩石圈动力学研究. 北京: 科学出版社. 刘海龄, 杨树康, 周蒂, 等, 1998. 南沙北部伸展构造的基本特征及其动力学意义. 高校地质学报, 4(1): 64-72. 邱燕, 黄文凯, 杜文波, 等, 2021. 南海边缘海减薄陆壳成因剖析. 地球科学, 46(3): 899-915. 邱燕, 孙桂华, 王瑜, 2018. 古太平洋板块中生代俯冲活动与南海中生界. 海洋地质前沿, 34(7): 1-8. 邱燕, 王立飞, 黄文凯, 等, 2016. 中国海域中新生代沉积盆地. 北京: 地质出版社. 邱燕, 曾维军, 李唐根, 2005. 南海中、南部断裂体系及其构造意义. 大地构造与成矿学, 29(2): 166-175. 王嘉, 栾锡武, 何兵寿, 等, 2021. 南海北部珠江口盆地西南段断裂特征与成因讨论. 地球科学, 46(3): 916-928. 汪俊, 邱燕, 阎贫, 等, 2019. 跨西南次海盆OBS、多道地震与重力联合调查. 热带海洋学报, 38(4): 81-90. 解习农, 任建业, 王振峰, 等, 2015. 南海大陆边缘盆地构造演化差异性及其与南海扩张耦合关系. 地学前缘, 22(1): 77-87. 许红, 孙和清, 李刚, 2003. 台西盆地新生界油气地质勘探与开发. 海洋地质动态, 19(8): 27-31. 徐子英, 汪俊, 姚永坚, 等, 2021. 中南-礼乐断裂带在南海海盆北部的时空展布与深部结构. 地球科学, 46(3): 942-955. 阎贫, 王彦林, 刘海龄, 2008. 南海海盆地形与NW向断裂. 热带海洋学报, 27(3): 30-37. 姚伯初, 1995. 中南-礼乐断裂的特征及其构造意义. 南海地质研究, (7): 1-14. 姚伯初, 曾维军, Taylor, B., 等, 1994. 中美合作调研南海地质专报. 武汉: 中国地质大学出版社. 尹延鸿, 温珍河, 孙桂华, 等, 2013. 中国南部海域主要断裂类型、分布及地质特征. 海洋地质前沿, 29(8): 1-6. 张功成, 王璞珺, 吴景富, 等, 2015. 边缘海构造旋回: 南海演化的新模式. 地学前缘, 22(3): 27-37. 钟建强, 黄慈流, 詹文欢, 1994. 台湾海峡台西南盆地新生代构造事件的分析. 台湾海峡, 13(4): 323-341. -
