Method for Decoding Magnetic Field Signals from Planar Triaxial GMI Magnetic Sensors for Terrestrial Magnetic Surveys and Its Validation
-
摘要: 地磁场在地球内部具有稳定分布，其方向和强度可作为天然参考基准. 地磁探测技术为深地、水下等复杂环境提供了可靠的导航解决方案，尤其在自主性、隐蔽性和抗干扰能力方面优势显著. 地磁导航探测中多采用三轴磁传感器获取空间磁场分布信息，从而反演得到位置信息，因此三轴磁传感器精度是地磁导航探测的关键性能指标之一. 然而，传统三轴磁传感器由于体积大、制备工艺复杂、正交性难以保证，常引入测量误差且不易校正，制约了其精度的提升. 为此，提出了一种基于磁力线变轨和磁力线聚集原理的平面三轴GMI磁传感器设计方案. 该设计将3个磁探头在平面内呈正交排列，通过磁力线变轨结构实现三维磁场的平面化测量，有效避免常规三轴磁传感器正交性难以保证带来的误差. 文中对构建的三轴磁探头进行了仿真分析，解析了各探头信号构成，并推导出相应的信号解算方法. 实验结果表明，该传感器测量范围达±370 µT，X、Y、Z三个方向的输出电压灵敏度分别为1 416 Ⅴ/T、1 424 Ⅴ/T和628.3 Ⅴ/T. 本方案在保障测量精度的同时，实现了三维磁场的平面化集成测量，尤其提升了Z方向的检测精度，为高性能三轴磁传感器的发展提供了新路径.
-
关键词:
- 地磁场探测 /
- 地磁导航 /
- 平面三轴GMI磁传感器 /
- 磁力线变轨 /
- 深度学习
Abstract: The geomagnetic field exhibits a stable distribution within the Earth's interior, with its direction and intensity serving as a natural reference benchmark. Geomagnetic detection technology provides reliable navigation solutions for complex environments such as deep underground and underwater settings, demonstrating particular advantages in autonomy, concealment, and interference resistance. In geomagnetic navigation detection, triaxial magnetometers are commonly used to acquire the spatial distribution information of the magnetic field, thereby inverting position information. Hence, the accuracy of triaxial magnetometers is one of the key performance indicators in geomagnetic navigation detection. However, conventional triaxial magnetic sensors suffer from large size, complex fabrication processes, and difficulty in ensuring orthogonality. These factors frequently introduce measurement errors that are challenging to correct, thereby limiting precision improvements. To address this, this paper proposes a planar triaxial GMI magnetic sensor design based on the principles of magnetic flux line reorientation and magnetic flux line aggregation. This design orthogonally arranges three magnetic probes within a plane. By employing a magnetic flux line deflection structure, it enables planar measurement of three-dimensional magnetic fields, effectively mitigating errors arising from the inherent orthogonality challenges of conventional triaxial sensors. The constructed triaxial magnetic probes underwent simulation analysis, with the signal composition of each probe resolved and corresponding signal calculation methods derived. Experimental results demonstrate a measurement range of ±370 µT, with output voltage sensitivities of 1 416 Ⅴ/T, 1 424 Ⅴ/T, and 628.3 Ⅴ/T for the X, Y, and Z axes respectively. This approach achieves planar integrated measurement of three-dimensional magnetic fields while maintaining measurement accuracy, notably enhancing detection precision in the Z-direction. It thus provides a novel pathway for developing high-performance triaxial magnetic sensors. -
图 1 (a) 平面三轴GMI磁传感器三轴磁探头的模型构建图; (b)网格剖分图
Fig. 1. (a)Model construction diagram for the planar triaxial gmi magnetic sensor triaxial magnetic probe; (b)grid partition diagram
图 2 (a) X方向磁场下各探头敏感材料磁通密度变化; (b)Y方向磁场下各探头敏感材料磁通密度变化; (c)Z方向磁场下各探头敏感材料磁通密度变化
Fig. 2. (a)Variation in magnetic flux density in the sensing materials of each probe subjected to an X-direction magnetic field; (b)Y-direction magnetic field; and (c)Z-direction magnetic field
图 3 平面三轴GMI磁传感器电路结构框图
Fig. 3. Circuit block diagram of a planar triaxial GMI magnetic sensor
图 5 (a) X轴探头输出Ⅴ-H曲线; (b)Y轴探头输出Ⅴ-H曲线; (c)X-Z轴探头输出Ⅴ-H曲线; (d)X轴输出电压噪声谱密度; (e)Y轴输出电压噪声谱密度; (f)X-Z轴输出电压噪声谱密度
Fig. 5. Ⅴ-H curves of the (a)X-axis probe; (b)Y-axis probe; and (c)Z-axis probe; Output voltage noise spectral density of the (d)X-axis probe; (e)Y-axis probe; and(f)Z-axis probe
图 6 (a) X-Z轴探头输出$ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z1}}}} $和$ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z2}}}} $; (b)$ \pm 370 \mu \mathrm{~T} $范围内X-Z轴探头输出$ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z1}}}} $、$ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z2}}}} $的响应曲线及拟合曲线
Fig. 6. (a)Outputs $ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z1}}}} $ and $ {V_{{{\rm{x}}^{\rm{ - }}}{\rm{z2}}}} $ of the X-Z axis probe; (b)Their response and fitting curves within a range of ±370 μT
图 7 有无磁力线变轨结构的X-Z轴探头线圈输出响应曲线及拟合曲线
Fig. 7. Output response curves and fitted curves of X-Z axis probe coils with and without magnetic flux line deflection structures
图 8 X-Z轴探头线圈输出响应测量值与计算值对比曲线
Fig. 8. Comparison curve of measured versus calculated values for X-Z axis probe coil output response
表 1 磁传感器性能参数对比表
Table 1. Magnetic sensor performance parameters comparison table
传感器型号 X, Y方向灵敏度(Ⅴ/T) Z方向灵敏度(Ⅴ/T) 变轨系数 磁噪声水平(nT/√Hz) 本文设计的平面三轴GMI磁传感器 $ {S}_{x}=1\;416 $
$ {S}_{y}=1\;424 $628.3 0.446 X方向噪声1.09
Z方向噪声7.38Lu团队的平面结构磁通门传感器 122.4 11.6 0.094 X方向噪声0.11
Z方向噪声6.29Lai团队的AMR传感器 15~60 0.84 --- 4.7 Trinh团队的平面三轴GMR传感器 108 74 --- 0.10
下载: 导出CSV
-
Duan, J. S., Liang, S. H., Qi, N., et al., 2014. The Development and Application of HD-2010 Proton Precession Magnetometer. World Nuclear Geoscience, 31(2): 115-119(in Chinese with English abstract). Ge, L. L., Ren, Q. Y., Zhao, H., 2017. Design and Performance Test of High-Precision Magnetoresistive Magnetometer for Space Application. Spacecraft Environment Engineering, 34(2): 166-170(in Chinese with English abstract). Jiang, S. H., Li, X. Q., Chen, B., etal., 2025. Wire RopeBroken Wire Detection Method Based on Magnetic Field Gradient and Energy Method. China Measurement & Test, 51(6): 40-48(in Chinese with English abstract). Lai, W. M., Hsu, F. M., Sung, W. L., et al., 2015. Monolithic Integration of Micro Magnetic Pillar Array with Anisotropic Magneto-Resistive (AMR) Structure for Out-of-Plane Magnetic Field Detection. 2015 28th IEEE International Conference on Micro Electro Mechanical Systems (MEMS). January 18-22, 2015, Estoril, Portugal. IEEE: 901-904. https://doi.org/10.1109/MEMSYS.2015.7051105 Li, T., Zhang, J. S., Wang, S. C., et al., 2014. Selection Criterion of Geomagnetic Matching Area Based on Improved Geomagnetic Entropy. Journal of Geodesy and Geodynamics, 34(5): 151-155(in Chinese with English abstract). Li, Y. X., Liu, X. Y., 2021. Paleomagnetic Field Research: Challenges and Opportunities. Acta Geologica Sinica, 95(01): 64-74(in Chinese with English abstract). Lu, C. C., Huang, J., 2015. A 3-Axis Miniature Magnetic Sensor Based on a Planar Fluxgate Magnetometer with an Orthogonal Fluxguide. Sensors, 15(6): 14727-14744. https://doi.org/10.3390/s150614727 Lu, J. Q., Jin, F., Dong, K. F., et al., 2024. Simulation and Experiment of Planar Magnetic Sensor. 2024 Academic Conference of China Instrument and Control Society (ACCIS). July 28-31, 2024, Chengdu, China. IEEE: 497-501. https://doi.org/10.1109/ACCIS62068.2024.10948699 Luong, V. S., Su, Y. H., Lu, C. C., et al., 2018. Planarization, Fabrication, and Characterization of Three-Dimensional Magnetic Field Sensors. IEEE Transactions on Nanotechnology, 17(1): 11-25. https://doi.org/10.1109/TNANO.2017.2660062 Ma, Y. N., Wang, Y. G., 2024. Method for Scalar Magnetic Field Measurement of SERF Magnetometer Based on Pump Light Modulation. Flight Control & Detection, 7(6): 82-88(in Chinese with English abstract). Pei, H. G., Zhang, H. B., Ouyang, J., et al., 2025. Error Compensation Method for Anisotropic Magnetoresistive-Sensors. Ship Electronic Engineering, 45(7): 181-186(in Chinese with English abstract). Pu, X. L., Yang, Y. H., Liu, Y., 2024. A Review of Space Ore Prospecting: a New Direction for Exploring Mineral Resources. Bulletin of Mineralogy, Petrology and Geochemistry, 43(6): 1280-1302. (in Chinese with English abstract). Sun, J. S., Wu, Y. Y., Li, H. Y., et al., 2025. Research on Taylor Polynomial Model Based on Proton Vector Magnetometer Stations in Jiangsu Area. Earthquake, 45(3): 168-179(in Chinese with English abstract). Trinh, X. T., Jeng, J. T., Lu, C. C., et al., 2017. Miniature Tri-Axis Magnetometer with In-Plane GMR Sensors. IEEE Transactions on Magnetics, 53(11): 4004304. https://doi.org/10.1109/TMAG.2017.2696243 Wang, X. Z., Feng, Z. S., Ju, H. H., et al., 2024. The Inductive Magnetometer of the Meridian Project Ⅱ. Reviews of Geophysics and Planetary Physics, 55(1): 31-36(in Chinese with English abstract). Xing, A. C., Li, H. B., Kan, B. X., et al., 2025. Key Technologies and Development Trends of Marine Geomagnetic Navigation. Navigation Positioning and Timing, 12(2): 1-14(in Chinese with English abstract). Zhang, M., Zhao, S. Z., Jia, L., et al., 2020. Application of Polarization Method in Extracting Seismo-Magnetic Anomaly Information. Progress in Geophysics, 35(2): 488-494(in Chinese with English abstract). Zhang, Q. S., Dong, G. W., An, N., et al., 2025. A NewIdea of Integrated Calibration Method for Airborne Magnetic Vector Measurement Device. Geological Review, 71(S1): 243-246(in Chinese with English abstract). Zhang, Q. Z., Zou, S., Zhang, H., 2024. Application and Progress of Residual Magnetism Measurement Based on Electron Paramagnetic Resonance Spectroscopy. Spectroscopy and Spectral Analysis, 44(1): 22-28(in Chinese with English abstract). Zhao, D. H., Liu, Z. J., Zhao, Y. Y., et al., 2025. Measurement of Impact Current Based on Non-Magnetic Ring TMR Sensor. High Voltage Apparatus, 61(8): 120-127(in Chinese with English abstract). Zhao, Y. K., Kong, M., Liu, L., et al., 2025. Research onSpace Magnetic Particle Pose Measurement System and Sensor Calibration. China Measurement & Test, 51(4): 109-115(in Chinese with English abstract). Zheng, Y. F., Guo, Z. T., Jiao, N. Z., et al., 2024. A Holistic Perspective on Earth System Science. Science China Earth Sciences, 67(10): 3013-3040(in Chinese with English abstract). doi: 10.1007/s11430-024-1409-8 段金松, 梁树红, 齐宁, 等, 2014. HD-2010质子旋进磁力仪的研制与应用. 世界核地质科学, 31(2): 115-119. 葛丽丽, 任琼英, 赵华, 2017. 面向空间应用的高精度磁阻磁强计设计及性能测试. 航天器环境工程, 34(2): 166-170. 江胜华, 李潇庆, 陈斌, 等, 2025. 基于磁场梯度和能量法的钢丝绳断丝检测方法. 中国测试, 51(6): 40-48. 李婷, 张金生, 王仕成, 等, 2014. 基于改进地磁熵的地磁适配区选择准则. 大地测量与地球动力学, 34(5): 151-155. 李永祥, 刘欣宇, 2021. 古地磁场研究: 挑战与机遇. 地质学报, 95(1): 64-74. 马彦宁, 王耀国, 2024. 基于抽运光调制的SERF磁强计标量磁场测量方法. 飞控与探测, 7(6): 82-88. 裴华刚, 张海波, 欧阳君, 等, 2025. 各向异性磁阻传感器误差补偿方法. 舰船电子工程, 45(7): 181-186. 蒲秀浪, 杨宇红, 刘耘, 2024. 太空找矿综述: 矿产资源勘探新方向. 矿物岩石地球化学通报, 43(6): 1280-1303. 孙君嵩, 吴迎燕, 李鸿宇, 等, 2025. 基于江苏地区质子矢量磁力仪台站的泰勒多项式模型研究. 地震, 45(3): 168-179. 王喜珍, 冯志生, 居海华, 等, 2024. 子午工程二期感应式磁力仪. 地球与行星物理论评, 55(1): 31-36. 邢奥成, 李海兵, 阚宝玺, 等, 2025. 海洋地磁导航关键技术及发展趋势. 导航定位与授时, 12(2): 1-14. 张敏, 赵石柱, 贾路, 等, 2020. 极化法在提取震磁异常信息方面的应用. 地球物理学进展, 35(2): 488-494. 张青杉, 董根旺, 安娜, 等, 2025. 航空磁矢量测量装置集成检校方法新思路. 地质论评, 71(S1): 243-246. 张全哲, 邹升, 张红, 2024. 基于电子顺磁共振谱的残磁测量应用及进展. 光谱学与光谱分析, 44(1): 22-28. 赵德华, 刘召杰, 赵莹莹, 等, 2025. 基于无磁环TMR传感器的冲击电流测量. 高压电器, 61(8): 120-127. 赵云琨, 孔明, 刘璐, 等, 2025. 空间磁颗粒位姿测量系统与传感器标定研究. 中国测试, 51(4): 109-115. 郑永飞, 郭正堂, 焦念志, 等, 2024. 地球系统科学研究态势. 中国科学: 地球科学, 54(10): 3065-3090. -
