云南预警台网异构波形数据集构建与震相拾取模型性能评估

doi:10.3799/dqkx.2025.287

云南预警台网异构波形数据集构建与震相拾取模型性能评估

doi: 10.3799/dqkx.2025.287

吕帅^1,2,
房立华^3, ,,
彭钰翔¹,
曹颖¹,
夏登科⁴,
范莉苹⁴,
朱杰¹,
郭亚茹¹

1. 云南省地震局, 云南昆明 650224;
2. 中国地质大学(北京), 北京 100083;
3. 中国地震局地震预测研究所, 北京 100036;
4. 中国地震局地球物理研究所, 北京 100081

基金项目:

地震科技星火计划项目(No.XH25033YB)和国家自然科学基金(No.42374081).

详细信息

作者简介:
吕帅(1991-),男,高级工程师,主要从事地震监测和地震信息化工作.E-mail：lv_303494@163.com.

通讯作者:
房立华(1981-),男,博士,研究员,主要从事人工智能地震学研究.E-mail：fanglihua@ief.ac.cn.

中图分类号: P315.61
计量
- 文章访问数: 128
- HTML全文浏览量: 0
- PDF下载量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2025-08-17
- 网络出版日期: 2025-12-29

Development of a Heterogeneous Waveform Dataset and Evaluation of Phase Picking Models for the Yunnan Earthquake Early Warning Network

1. Yunnan Earthquake Agency, Kunming 650224, Yunnan, China;
2. School of Information Engineering, China University of Geosciences (Beijing), Beijing 100083, China;
3. Institute of Earthquake Forecasting, China Earthquake Administration, Beijing 100036, China;
4. Institute of Geophysics, China Earthquake Administration, Beijing 100081, China

摘要

摘要: 近年来,深度学习方法在地震检测和震相拾取中得到广泛的应用.然而,现有模型主要基于高信噪比的速度型波形数据进行训练,缺乏对加速度计与烈度计数据的泛化性评估.为探究现有模型对加速度数据的处理效果及在云南地区的泛化能力,本文基于云南预警台网的最新观测数据,构建了包括速度计、加速度计和烈度计的多源异构高质量波形数据集,且所有震相到时均由人工标注.结合PhaseNet、USTC-Pickers等五种专业模型,以及SeisMoLLM和SeisT等四种大模型,系统评估了不同模型在云南数据集上的震相拾取性能.结果表明：本地迁移优化的USTC-Pickers综合性能最优,其Pg和Sg震相拾取的平均F1值达0.779(到时拾取差异△t≤0.1 s),显著优于其他模型,且在检测加速度计与烈度计数据时,较好解决了震相拾取滞后问题;大模型在Sg拾取等复杂环境中展现出更强的泛化能力.研究还揭示了主流地震检测模型在不同波形长度、震级、震中距条件下的性能变化,强调了本地化训练与模型选取在实际应用中的重要性.研究结果为地震预警系统中的地震检测和震相识别,以及中国地震科学实验场地震观测数据的实时自动处理提供参考.
- 震相拾取 /
- 异构波形数据集 /
- 大模型 /
- 性能评估 /
- 地震预警
Abstract: In recent years, deep learning methods have been widely applied to seismic detection and phase picking. However, existing models are mainly trained on high signal-to-noise ratio (SNR) velocity-type waveform data, with limited evaluation of their generalization to accelerometer and intensity meter data. To investigate the performance of existing models on accelerometer data and their generalization capability in Yunnan, this study constructed a high-quality, multi-source heterogeneous waveform dataset based on the latest observations from the Yunnan Earthquake Early Warning (EEW) network, including velocity meters, accelerometers, and intensity meters, with all phase arrival times manually annotated. We systematically evaluated the phase-picking performance of nine models—five domain-specific models (e.g., PhaseNet, USTC-Pickers) and four large models (e.g., SeisMoLLM, SeisT)—on the Yunnan dataset. The locally fine-tuned USTC-Pickers achieved the best overall performance, with mean F1 scores of 0.779 for Pg and Sg phase picking (Δt≤0.1 s), significantly outperforming other models, and effectively mitigating phase-picking delays for accelerometer and intensity meter data. Large models demonstrated stronger generalization in Sg picking and low-SNR conditions. The study also revealed performance variations of mainstream seismic detection models under different waveform lengths, magnitudes, and epicentral distances, underscoring the importance of localized training and model architecture selection in practical applications. The research findings provide references for seismic detection and phase picking in earthquake early warning systems, as well as for the real-time automatic processing of seismic data at the China Earthquake Science Experiment Site.
- seismic phase picking /
- dataset /
- large language model /
- performance evaluation /
- earthquake early warning

HTML全文

参考文献(32)

An, Y. R., 2024. Introduction to a Recently Released Dataset Entitled CSNCD: A Comprehensive Dataset of Chinese Seismic Network. Earthquake Research Advances, 4(1): 100255. https://doi.org/10.1016/j.eqrea.2023.100255
Bormann, P., Wendt, S., Klinge, K., 2013. Data Analysis and Seismogram Interpretation. New Manual of Seismological Observatory Practice 2 (NMSOP-2), 11: 1-34. https://doi.org/10.2312/GFZ.NMSOP-2_CH11
Bornstein, T., Lange, D., Münchmeyer, J., et al., 2023. PickBlue: Seismic Phase Picking for Ocean Bottom Seismometers with Deep Learning. Earth and Space Science, 11(1): e2023EA003332. https://doi.org/10.1029/2023EA003332
Chai, C. P., Maceira, M., Santos-Villalobos, H. J., et al., 2020. Using a Deep Neural Network and Transfer Learning to Bridge Scales for Seismic Phase Picking. Geophysical Research Letters, 47(16): e2020GL088651. https://doi.org/10.1029/2020GL088651
Du, M. N., He, F. X., Zou, N., et al., 2024. Shortcut Learning of Large Language Models in Natural Language Understanding. Communications of the ACM, 67(1): 110-120. https://doi.org/10.1145/3596490
Fang, L. H., Wu, Z. L., Song, K., 2017. SeismOlympics. Seismological Research Letters, 88(6): 1429-1430. https://doi.org/10.1785/0220170134
Feng, C. Y., Yang, Y., Hu, X., et al., 2023. MSNet: A Seismic Phase Picking Network Applicable to Microseismic Monitoring. IEEE Geoscience and Remote Sensing Letters, 20:1-5. https://doi.org/10.1109/LGRS.2023.3314029
Huangfu, G., 2009. Research on the Seismicity in Yunnan, China (Dissertation). University of Science and Technology of China, Hefei: 2-3(in Chinese with English abstract).
Li, J., Chen, J. Y., Tang, Y. C., et al., 2023. Transforming Medical Imaging with Transformers? A Comparative Review of Key Properties, Current Progresses, and Future Perspectives. Medical Image Analysis, 85: 102762. https://doi.org/10.1016/j.media.2023.102762
Li, S., Yang, X., Cao, A. Y., et al., 2024. SeisT: A Foundational Deep-Learning Model for Earthquake Monitoring Tasks. IEEE Transactions on Geoscience and Remote Sensing, 62: 1-15. https://doi.org/10.1109/TGRS.2024.3371503
Liu, T. L., Münchmeyer, J., Laurenti, L., et al., 2024. SeisLM: a Foundation Model for Seismic Waveforms. arXiv. https://doi.org/10.48550/arXiv.2410.15765
Mousavi, S. M., Beroza, G. C., 2022. Deep-learning Seismology. Science, 377(6607): 4470. https://doi.org/10.1126/science.abm4470
Mousavi, S. M., Ellsworth, W. L., Zhu, W. Q., et al., 2020. Earthquake Transformer—an Attentive Deep-learning Model for Simultaneous Earthquake Detection and Phase Picking. Nature Communications, 11(1): 3952. https://doi.org/10.1038/s41467-020-17591-w
Mousavi, S. M., Sheng, Y. X., Zhu, W. Q., et al., 2019. STanford EArthquake Dataset (STEAD): A Global Data Set of Seismic Signals for AI. IEEE Access, 7: 179464-179476. https://doi.org/10.1109/ACCESS.2019.2947848
Münchmeyer, J., Woollam, J., Rietbrock, A., et al., 2022. Which Picker Fits My Data? A Quantitative Evaluation of Deep Learning Based Seismic Pickers. Journal of Geophysical Research: Solid Earth, 127(1): e2021JB023499. https://doi.org/10.1029/2021JB023499
Niksejel, A., Zhang, M., 2024. OBSTransformer: a Deep-learning Seismic Phase Picker for OBS Data Using Automated Labelling and Transfer Learning. Geophysical Journal International, 237(1): 485-505. https://doi.org/10.1093/gji/ggae049
Pecher, B., Srba, I., Bielikova, M., 2025. Comparing Specialised Small and General Large Language Models on Text Classification: 100 Labelled Samples to Achieve Break-Even Performance. In: Proceedings of the 2025 Conference on Empirical Methods in Natural Language Processing, Association for Computational Linguistics, Suzhou, 165-184. https://10.18653/v1/2025.emnlp-main.9
Peng, C. Y., Jiang, P., Ma, Q., et al., 2022. Chinese Nationwide Earthquake Early Warning System and Its Performance in the 2022 Lushan M6.1 Earthquake. Remote Sensing, 14(17): 4269. https://doi.org/10.3390/rs14174269
Ross, Z. E., Meier, M. A., Hauksson, E., et al., 2018. Generalized Seismic Phase Detection with Deep Learning. Bulletin of the Seismological Society of America, 108(5A): 2894-2901. https://doi.org/10.1785/0120180080
Saad, O. M., Savvaidis, A., Chen, Y. K., 2024. Transfer Learning for Seismic Phase Picking With Significantly Higher Precision in Faraway Seismic Stations. IEEE Transactions on Geoscience and Remote Sensing, 62: 1-12. https://doi.org/10.1109/TGRS.2024.3422612
Si, X., Wu, X. M., Li, Z. F., et al., 2024. An All-in-one Seismic Phase Picking, Location, and Association Network for Multi-task Multi-station Earthquake Monitoring. Communications Earth & Environment, 5(1): 22. https://doi.org/10.1038/s43247-023-01188-4
Wang, X. H., Liu, F., Su, R., et al., 2025. SeisMoLLM: Advancing Seismic Monitoring via Cross-modal Transfer with Pre-trained Large Language Model. arXiv. https://doi.org/10.48550/arXiv.2502.19960
Woollam, J., Münchmeyer, J., Tilmann, F., et al., 2022. SeisBench - A Toolbox for Machine Learning in Seismology. Seismological Research Letters, 93(3):1695-1709. https://doi.org/10.1785/0220210324
Yu, Z. Y., Cai, Y. Q., Wang, W. T., et al., 2024. PRIME-DP: Pre-trained Integrated Model for Earthquake Data Processing. arXiv. https://doi.org/10.48550/arXiv.2408.01919
Yu, Z. Y., Wang, W. T., 2022. LPPN: A Lightweight Network for Fast Phase Picking. Seismological Research Letters, 93(5): 2834-2846. https://doi.org/10.1785/0220210309
Yu, Z. Y., Wang, W. T., Chen, Y. N., 2023. Benchmark on the Accuracy and Efficiency of Several Neural Network Based Phase Pickers Using Datasets from China Seismic Network. Earthquake Science, 36(2): 113-131. https://doi.org/10.1016/j.eqs.2022.10.001
Zhao, M., Xiao, Z. W., Chen, S., et al., 2023. DiTing: A large-scale Chinese Seismic Benchmark Dataset for Artificial Intelligence in Seismology. Earthquake Science, 36(2): 84-94. https://doi.org/10.1016/j.eqs.2022.01.022
Zhu, J., Li, Z. F., Fang, L. H., 2023. USTC-Pickers: a Unified Set of Seismic Phase Pickers Transfer Learned for China. Earthquake Science, 36(2): 95-112. https://doi.org/10.1016/j.eqs.2023.03.001
Zhu, J., Zhong, Y. S., 2025. Evaluation of the Monitoring Capability of the Yunnan Earthquake Early Warning Network. Journal of Seismological Research, 48(3):422-431(in Chinese with English abstract).
Zhu, W. Q., Beroza, G. C., 2019. PhaseNet: A Deep-Neural-Network-Based Seismic Arrival Time Picking Method. Geophysical Journal International, 216(1): 261-273. https://doi.org/10.1093/gji/ggy423
皇甫岗, 2009. 云南地震活动性研究(博士学位论文). 合肥: 中国科学技术大学, 2-3.
朱杰, 钟玉盛, 2025. 云南地震预警站网监测效能评估. 地震研究, 48(3): 422-431.
