Fault System and Evolution Process of Hashan Structural Belt in Northwestern Junggar Basin
-
摘要: 准噶尔盆地西北缘哈山构造带的断裂属性仍然存在较大的争议.基于哈山构造带最新地震剖面的精细解析建立地质模型，系统分析其断裂活动性，并通过平衡剖面恢复定量揭示构造演化过程.研究结果表明，哈山构造带是一个经历多期构造演化的复合断裂系统：其中达尔布特断裂体系是具有花状构造特征的走滑断裂体系，而乌尔禾-夏子街断裂体系则是走滑变形向盆地方向传播形成的褶皱冲断带.哈山构造带自二叠纪以来主要经历三期构造变形：二叠纪末期为主变形期，达尔布特走滑断裂体系于此期间成型，三叠纪-侏罗纪是乌尔禾-夏子街断裂体系主要形成时期，白垩纪-新生代表现为斜向抬升.Abstract: The fault property of the Hashan structural belt, located in the southwestern Junggar basin, is still controversial. In this paper it constructs the structural model of the Hashan structural belt by interpreting the latest seismic profile, and analyzes the fault displacements. The evolution process is investigated using balanced cross-section restoration. The results suggest that the Hashan structural belt is a complex fault system undergoing multiple stages of deformation. The Darabut fault system forms a typical flower structure controlled by the basement-involved strike-slip fault, and the Wuerhe-Xiazijie fault system develops a thrust deformation as the compressional stress propagates toward the Junggar basin. The Hashan structural belt has experienced three deformation stages since the Permian. The Darabut fault system predominantly formed in the Late Permian. The Wuerhe-Xiazijie fault system formed during the deformation from the Triassic to the Jurassic, and the Hashan structural belt kept lifting from the Cretaceous to the Cenozoic.
-
Key words:
- earthquake /
- strike-slip fault /
- fault displacement /
- Hashan structural belt /
- Junggar basin /
- tectonics
-
图 1 准噶尔盆地周缘构造简图（a）以及哈山构造带区域地质图（b）
a.准噶尔盆地周缘造山带及主干断裂分布，据Ding et al.（2020）和Zhu et al.（2023）修改；b.研究区周缘地质图以及主要断裂分布示意，据薛雁等（2017）修改
Fig. 1. Tectonic (a) and geological (b) maps of the Hashan area, northwestern margin of the Junggar basin
图 3 哈山构造带中部（a）典型地震剖面及（b）解释模型
Fig. 3. Seismic (a) and interpreted (b) cross-sections in the central zone of the Hashan structural belt
图 4 哈山构造带地质剖面与前陆褶皱冲断带和走滑断裂对比
a.塔西南褶皱冲断带的地质剖面，N1k：克孜洛依组，N1a：安居安组，N1p：帕卡布拉克组，N2a：阿图什组；b.哈山构造带的典型地质剖面，地层名称见图 3；c.汇聚型走滑断裂体系的物理模拟剖面，据McClay and Bonora（2001）；d.荷兰盆地西部花状构造地质剖面，据Racero-Baena and Drake（1996）
Fig. 4. Comparison between the Hashan structural belt, foreland fold-and-thrust belts, and strike-slip faults
图 5 准噶尔盆地西北缘哈山构造带‒谢米斯台山长剖面
据孙自明等（2015）.D.泥盆系；C.石炭系；P1.下二叠统；P2-3.中上二叠统；T.三叠系；J1b.八道湾组；J1s.三工河组；J2x.西山窑组；J2t.头屯河组；K1T.吐谷鲁群；Cz.新生界
Fig. 5. The long cross-section from the Mount Semistai to the Hashan structural belt in the northwestern zone of the Junggar basin
图 6 哈山构造带达尔布特断裂体系逆冲叠瓦构造模型的前展式平衡恢复图
按照前展式变形模式，针对每条断裂进行去断层的恢复，获得断裂运动学模型和断距
Fig. 6. Forward balance restoration for the imbricated thrust system of the Darabut fault system in the Hashan structural belt
图 7 典型前陆冲断带断裂活动与达尔布特断裂体系活动性对比
a.根据Morgan and Bangs（2017）中数值模拟实验结果绘制；b.根据文献Sun et al.（2016）中物理模拟实验绘制
Fig. 7. Comparison of the fault displacement between the foreland fold-and-thrust belt and the Darabut fault system
图 8 哈山构造带典型剖面平衡恢复图
达尔布特断裂体系按照走滑变形模式进行恢复，乌尔禾‒夏子街断裂体系按照逆冲断裂进行恢复
Fig. 8. Balance restoration of the Hashan structural belt
图 9 哈山构造带平面演化与动力学背景示意
a.晚二叠世准噶尔盆地与周缘板块关系简图（据Yi et al.，2015绘制）；b.现今噶尔盆地与周缘板块关系简图（据Yi et al.，2015绘制）；c.哈山构造带二叠纪到三叠纪平面演化示意，主要断裂活动集中在达尔布特断裂体系；d.哈山构造带三叠纪到侏罗纪平面演化示意，受到东准噶尔块体的阻挡，压扭应力向盆地方向传播，形成乌尔禾‒夏子街断裂体系；e.哈山构造带白垩纪‒新生代平面演化示意图.受到欧亚板块碰撞远程效应的影响，达尔布特断裂转为左行走滑断裂，以整体抬升为主，断裂活动不发育
Fig. 9. Simplified tectonic map of the Junggar basin and relevant evolution process of the Hashan structural belt in plain view
-
Chapman, J. B., DeCelles, P. G., 2015. Foreland Basin Stratigraphic Control on Thrust Belt Evolution. Geology, 43(7): 579-582. https://doi.org/10.1130/g36597.1 Chen, S., Guo, Z. J., Qi, J. F., et al., 2016. Three-Stage Strike-Slip Fault Systems at Northwestern Margin of Junggar Basin and Their Implications for Hydrocarbon Exploration. Oil & Gas Geology, 37(3): 322-331 (in Chinese with English abstract). Chen, S., Pe-Piper, G., Piper, D. J. W., et al., 2014. Ophiolitic Mélanges in Crustal-Scale Fault Zones: Implications for the Late Palaeozoic Tectonic Evolution in West Junggar, China: Fault-Zone Ophiolite, West Junggar. Tectonics, 33(12): 2419-2443. https://doi.org/10.1002/2013tc003488 Choulet, F., Chen, Y., Cogné, J. P., et al., 2013. First Triassic Palaeomagnetic Constraints from Junggar (NW China) and Their Implications for the Mesozoic Tectonics in Central Asia. Journal of Asian Earth Sciences, 78: 371-394. https://doi.org/10.1016/j.jseaes.2013.01.023 Davis, D., Suppe, J., Dahlen, F. A., 1983. Mechanics of Fold-and-Thrust Belts and Accretionary Wedges. Journal of Geophysical Research: Solid Earth, 88(B2): 1153-1172. https://doi.org/10.1029/jb088ib02p01153 DeCelles, P. G., Giles, K. A., 1996. Foreland Basin Systems. Basin Research, 8(2): 105-123. https://doi.org/10.1046/j.1365-2117.1996.01491.x Ding, W. C., Li, T. D., Chen, X. H., et al., 2020. Intra-Continental Deformation and Tectonic Evolution of the West Junggar Orogenic Belt, Central Asia: Evidence from Remote Sensing and Structural Geological Analyses. Geoscience Frontiers, 11(2): 651-663. https://doi.org/10.1016/j.gsf.2019.08.001 Dooley, T. P., Schreurs, G., 2012. Analogue Modelling of Intraplate Strike-Slip Tectonics: A Review and New Experimental Results. Tectonophysics, 574/575: 1-71. https://doi.org/10.1016/j.tecto.2012.05.030 Feng, G. M., Chen, S. P., Adam, J., et al., 2024. Effect of Mechanical Stratigraphy on the Structure and Kinematics of Salt-Bearing Fold-and-Thrust Belts: Insights from Scaled Analogue Experiments with Optical Strain Monitoring (Digital Image Correlation). Journal of Structural Geology, 183: 105135. https://doi.org/10.1016/j.jsg.2024.105135 Guan, S. W., Li, B. L., Hou, L. H., et al., 2008. New Hydrocarbon Exploration Areas in Footwall Covered Structures in Northwestern Margin of Junggar Basin. Petroleum Exploration and Development, 35(1): 17-22 (in Chinese with English abstract). doi: 10.1016/S1876-3804(08)60004-X He, D. F., Yin, C., Du, S. K., et al., 2004. Characteristics of Structural Segmentation of Foreland Thrust Belts—A Case Study of the Fault Belts in the Northwestern Margin of Junggar Basin. Earth Science Frontiers, 11(3): 91-101 (in Chinese with English abstract). He, W. G., Yu, Y. X., Luo, Y., et al., 2023. Effects of Friction Properties and Rheological Structures on the Deformation Patterns and Evolution of Fold-and-Thrust Belts; New Insights from Analogue Modelling. Journal of Structural Geology, 173: 104904. https://doi.org/10.1016/j.jsg.2023.104904 Hu, Y., Xia, B., Guo, F., et al., 2012. Tectonic Evolution and Its Influence on Hydrocarbon Accumulation of Heshituoluogai Basin in Northwest Xinjiang. Geology and Resources, 21(4): 380-385 (in Chinese with English abstract). Ji, D. S, Gan, R. Z., Pang, Z. C., et al., 2025. Mesozoic Structure and Its Impact on Cenozoic Deformation in Northern Piedmont of Tianshan Mountain. Earth Science, 50(12): 4685-4696 (in Chinese with English abstract). Jia, C. Z., 2017. Breakthrough and Significance of Unconventional Oil and Gas to Classical Petroleum Geological Theory. Petroleum Exploration and Development, 44(1): 1-11 (in Chinese with English abstract). doi: 10.1016/S1876-3804(17)30002-2 Le Guerroué, E., Cobbold, P. R., 2006. Influence of Erosion and Sedimentation on Strike-Slip Fault Systems: Insights from Analogue Models. Journal of Structural Geology, 28(3): 421-430. https://doi.org/10.1016/j.jsg.2005.11.007 Li, Y. J., Xu, Q., Liu, J., et al., 2016. Redefinition and Geological Significance of Jiamuhe Formation in Hala'alate Mountain of West Junggar, Xinjiang. Earth Science, 41(9): 1479-1488 (in Chinese with English abstract). McClay, K., Bonora, M., 2001. Analog Models of Restraining Stepovers in Strike-Slip Fault Systems. AAPG Bulletin, 85(2): 233-260. https//doi. org/10.1306/8626C7AD-173B-11D7-8645000102C1865D doi: 10.1306/8626C7AD-173B-11D7-8645000102C1865D Morgan, J. K., Bangs, N. L., 2017. Recognizing Seamount-Forearc Collisions at Accretionary Margins: Insights from Discrete Numerical Simulations. Geology, 45(7): 635-638. https://doi.org/10.1130/g38923.1 Racero-Baena, A., Drake, S. J., 1996. Structural Style and Reservoir Development in the West Netherlands Oil Province. Geology of Gas and Oil under the Netherlands. Springer Netherlands, Dordrecht, 211-227. https://doi.org/10.1007/978-94-009-0121-6_18 Shao, Y., Wang, R. F., Zhang, Y. Q., et al., 2011. Strike-Slip Structures and Oil-Gas Exploration in the NW Margin of the Junggar Basin, China. Acta Petrolei Sinica, 32(6): 976-984 (in Chinese with English abstract). Song, Y., Jia, C. Z., Jiang, L., et al., 2024. Connotation and Research Strategy of the Whole Petroleum System. Petroleum Exploration and Development, 51(6): 1199-1210, 1226 (in Chinese with English abstract). Song, Y., Tang, Y., He, W. J., et al., 2024. New Fields, New Types and Exploration Potentials of Oil-Gas Exploration in Junggar Basin. Acta Petrolei Sinica, 45(1): 52-68 (in Chinese with English abstract). doi: 10.1038/s41401-023-01147-x Sun, C., Jia, D., Yin, H. W., et al., 2016. Sandbox Modeling of Evolving Thrust Wedges with Different Preexisting Topographic Relief: Implications for the Longmen Shan Thrust Belt, Eastern Tibet. Journal of Geophysical Research: Solid Earth, 121(6): 4591-4614. https://doi.org/10.1002/2016jb013013 Sun, Z. M., Hong, T. Y., Zhang, T., 2008. Strike-Slip-Thrust Composite Structures and Its Relationships to Hydrocarbon in Hala'alate Mountains, Northern Xinjiang. Chinese Journal of Geology (Scientia Geologica Sinica), 43(2): 309-320 (in Chinese with English abstract). Tian, F. L., He, D. F., Chen, J. J., et al., 2022. Vertical Differential Structural Deformation of the Main Strike-Slip Fault Zones in the Shunbei Area, Central Tarim Basin: Structural Characteristics, Deformation Mechanisms, and Hydrocarbon Accumulation Significance. Acta Geologica Sinica, 96(4): 1415-1431. https://doi.org/10.1111/1755-6724.14973 Xu, Z. P., Yang, G. X., Luo, H. Y., et al., 2024. The Influence Lithologic Differences at Different Depths on the Segmentation between the Eastern and the Western Zones of Kuqa Depression. Earth Science, 49(8): 3029-3042 (in Chinese with English abstract). Xue, Y., Lin, H. X., Zhang, K. H., et al., 2017. Tectonic Characteristics and Genetic Simulation of Hala'alate Mountain Area. Geotectonica et Metallogenia, 41(5): 843-852 (in Chinese with English abstract). Xue, Y., Zhang, K. H., Wang, Y. H., et al., 2015. Techtonic Evolution of Hala'alate Mountain Area and Implications in Petroleum Geology. Xinjiang Petroleum Geology, 36(6): 687-692 (in Chinese with English abstract). Yi, Z. Y., Huang, B. C., Xiao, W. J., et al., 2015. Paleomagnetic Study of Late Paleozoic Rocks in the Tacheng Basin of West Junggar (NW China): Implications for the Tectonic Evolution of the Western Altaids. Gondwana Research, 27(2): 862-877. https://doi.org/10.1016/j.gr.2013.11.006 Yu, H. Z., 2014. Complicated Structure Modeling in Front-Zone of Hala'alate Mountain of Northwestern Margin, Junggar Basin. Natural Gas Geoscience, 25(S1): 91-97 (in Chinese with English abstract). Yu, Y. L., Wang, X., Rao, G., et al., 2016. Mesozoic Reactivated Transpressional Structures and Multi-Stage Tectonic Deformation along the Hong-Che Fault Zone in the Northwestern Junggar Basin, NW China. Tectonophysics, 679: 156-168. https://doi.org/10.1016/j.tecto.2016.04.039 Zhang, Y. Q., Wang, X., Liu, J. S., et al., 2011. Wuerhe-Xiazijie Strike-Slip Structure and Petroleum Exploration Significance in Northwestern Margin of Junggar Basin. Xinjiang Petroleum Geology, 32(5): 447-450 (in Chinese with English abstract). Zheng, Y. F., Chen, Y. X., Chen, R. X., et al., 2022. Tectonic Evolution of Convergent Plate Margin and Its Geological Effect. Science China Earth Sciences, 52(7): 1213-1242 (in Chinese). Zhu, M., Liang, Z. L., Wang, X., et al., 2023. Mesozoic Strike-Slip Fault System at the Margin of the Junggar Basin, NW China. Journal of Structural Geology, 175: 104950. https://doi.org/10.1016/j.jsg.2023.104950 Zhu, Y. F., Chen, B., Xu, X., et al., 2013. A New Geological Map of the Western Junggar, North Xinjiang (NW China): Implications for Paleoenvironmental Reconstruction. Episodes, 36(3): 205-220. https://doi.org/10.18814/epiiugs/2013/v36i3/003 陈石, 郭召杰, 漆家福, 等, 2016. 准噶尔盆地西北缘三期走滑构造及其油气意义. 石油与天然气地质, 37(3): 322-331. 管树巍, 李本亮, 侯连华, 等, 2008. 准噶尔盆地西北缘下盘掩伏构造油气勘探新领域. 石油勘探与开发, 35(1): 17-22. 何登发, 尹成, 杜社宽, 等, 2004. 前陆冲断带构造分段特征: 以准噶尔盆地西北缘断裂构造带为例. 地学前缘, 11(3): 91-101. 胡杨, 夏斌, 郭峰, 等, 2012. 新疆和什托洛盖盆地构造演化特征及其对油气成藏的影响. 地质与资源, 21(4): 380-385. 冀冬生, 甘仁忠, 庞志超, 等, 2025. 天山北麓中生代构造特征及其对新生代变形的意义. 地球科学, 50(12): 4685-4696. doi: 10.3799/dqkx.2025.168 贾承造, 2017. 论非常规油气对经典石油天然气地质学理论的突破及意义. 石油勘探与开发, 44(1): 1-11. 李永军, 徐倩, 刘佳, 等, 2016. 新疆西准噶尔哈山地区佳木河组的重新厘定及地质意义. 地球科学, 41(9): 1479-1488. doi: 10.3799/dqkx.2016.516 邵雨, 汪仁富, 张越迁, 等, 2011. 准噶尔盆地西北缘走滑构造与油气勘探. 石油学报, 32(6): 976-984. 宋岩, 贾承造, 姜林, 等, 2024. 全油气系统内涵与研究思路. 石油勘探与开发, 51(6): 1199-1210, 1226. 宋永, 唐勇, 何文军, 等, 2024. 准噶尔盆地油气勘探新领域、新类型及勘探潜力. 石油学报, 45(1): 52-68. 孙自明, 洪太元, 张涛, 2008. 新疆北部哈拉阿拉特山走滑-冲断复合构造特征与油气勘探方向. 地质科学, 43(2): 309-320. 徐振平, 杨庚兄, 罗浩渝, 等, 2024. 不同深度岩性差异对库车坳陷构造分段特征的影响. 地球科学, 49(8): 3029-3042. doi: 10.3799/dqkx.2022.391 薛雁, 林会喜, 张奎华, 等, 2017. 哈拉阿拉特山地区构造特征及成因机制模拟. 大地构造与成矿学, 41(5): 843-852. 薛雁, 张奎华, 王艺豪, 等, 2015. 哈拉阿拉特山地区构造演化及其石油地质意义. 新疆石油地质, 36(6): 687-692. 于洪洲, 2014. 准噶尔盆地西北缘哈拉阿拉特山前复杂构造带建模技术. 天然气地球科学, 25(S1): 91-97. 张越迁, 汪新, 刘继山, 等, 2011. 准噶尔盆地西北缘乌夏走滑构造及油气勘探意义. 新疆石油地质, 32(5): 447-450. 郑永飞, 陈伊翔, 陈仁旭, 等, 2022. 汇聚板块边缘构造演化及其地质效应. 中国科学: 地球科学, 52(7): 1213-1242. -
