Progress and Prospects of Geological Scientific Drilling beneath Antarctic Ice Sheet and in Southern Ocean
-
摘要: 南极冰下及大洋地质样品对于认识南极地质构造演化、南极冰盖稳定性、南大洋对全球气候环境的影响机制等世界前沿科学问题至关重要.科学钻探是获取南极冰下及大洋地质样品的唯一技术手段.近年来，美国研发了系列南极冰下及大洋科学钻探装备与钻具，并实施了大量科学钻探工程.我国虽然也开展了南极冰下基岩取心钻探装备的研发，并成功在南极进行了应用，但与美国相比，仍有较大差距.系统梳理了国内外南极冰下基岩钻探、冰架下地质钻探和南大洋地质钻探所涉及的钻探技术和钻探工程.提出了适合我国国情的南极冰下及大洋地质科学钻探发展建议，主要为发展冰层/冰下基岩快速钻探技术、南极冰架下地质科学钻探技术和南极冰区大洋科学钻探技术，并开展相关钻探工程，以期为我国极地科技规划制订提供参考.Abstract: Geological samples beneath the Antarctic ice and in the Southern Ocean are crucial for understanding the evolution of the Antarctic geology, the stability of the Antarctic ice sheet and the influence mechanisms of the Southern Ocean on global climate and environment. Scientific drilling is the only technical means to obtain such samples. In recent years, the United States has developed a series of scientific drilling equipment and tools for drilling beneath the Antarctic ice and in the Southern Ocean, and has carried out a large number of scientific drilling projects. Although China has also carried out the research and development of drilling equipment for subglacial bedrock coring and successfully applied it in Antarctica, there is still a considerable gap compared with the United States. This paper systematically reviews the drilling technologies and projects at home and abroad involved in drilling beneath the Antarctic ice, beneath the ice shelves, and in the Southern Ocean, and proposes development suggestions for scientific drilling beneath the Antarctic ice and in the Southern Ocean that are suitable for China's national conditions with the aim of providing a reference for the formulation of China's polar science and technology plans.
-
Key words:
- Antarctica /
- subglacial bedrock /
- ice shelve /
- Southern Ocean /
- geological scientific drilling /
- marine geology
-
图 1 近年来南极冰下及大洋地质科学钻探工程位置
Fig. 1. Drilling locations of Antarctic subglacial and Southern Ocean geological drilling projects
图 2 RAID钻机系统原理设计图（李冰等，2021）
Fig. 2. Principle design diagram of RAID drilling rig system
图 3 IBED孔底回转动力式钻机系统结构示意图（张楠等，2020）
Fig. 3. Schematic diagram of IBED bottom rotary power drilling rig system
图 4 Winkie钻机在墨菲山（a）和俄亥俄山脉（b）钻取的冰岩界面样品（Braddock et al.，2024）
Fig. 4. The ice-bedrock interface samples from Mount Murphy (a) and Ohio Range (b) obtained by Winkie drill
图 5 ASIG钻机南极野外钻探现场（Boeckmann et al.，2021）
Fig. 5. ASIG drill in the Antarctica field drilling site
图 6 RAID钻机获得的冰下地质样品（Goodge et al.，2021）
Fig. 6. The subglacial geological samples obtained by RAID drill
图 7 IBED钻机钻取的冰下基岩样品（张楠等，2020；Talalay et al.，2025）
Fig. 7. The subglacial geological samples obtained by IBED drill
图 8 ANDRILL钻机（Naish et al.，2007）
Fig. 8. Schematic diagram showing the main elements of ANDRILL drill
图 9 AIDD钻机使用的海底沉积物取样钻具（Patterson et al.，2022）
Fig. 9. Ocean sediment samples drilling tool used by AIDD drill
图 11 “决心”号钻探船防震水下电视系统（朱芝同等，2020）
Fig. 11. The Seismic-Resistant Underwater TV System of "Jordis Resolution" drilling vessel
图 12 APC钻具结构原理图（Weber et al.，2021b）
Fig. 12. Schematic diagram of APC drilling tool structure
图 13 XCB钻具结构原理图（Weber et al.，2021b）
Fig. 13. Schematic diagram of XCB drilling tool structure
图 14 RCB钻具结构原理图（Weber et al.，2021b）
Fig. 14. Schematic diagram of RCB drilling tool structure
表 1 美国冰下基岩钻探工程主要技术参数（Boeckmann et al.，2021；Goodge et al.，2021；Kuhl et al.，2021；Braddock et al.，2025）
Table 1. Main technical parameters of United States subglacial bedrock drilling projects
冰下基岩钻具名称 应用地点/初始地层/时间 设计钻进深度(m) 最大钻进冰层厚度(m) 基岩取心目标(m) 单孔最大岩心长度(m) 岩心直径(mm) 粒雪层
钻进方式钻井液 钻井液防漏措施 冰层
钻进方式冰岩夹层
钻进方式基岩层
钻进方式Winkie钻 西南极俄亥俄山脉
蓝冰2016/2017120 28.3 1.5 0.67 33.4 无粒雪层 Isopar K 套管+封隔器 Kovacs螺旋钻 聚晶金刚石复合片钻头
地质取心钻头
阶梯型孕镶金刚石钻头地质
取心钻头
孕镶
金刚石
钻头西南极墨菲山
粒雪+冰层2019/202040.9 1.37 Badger-Eclipse钻 Badger-Eclipse钻 西南极哈德逊山脉
粒雪+冰层2022/202349.6 0 Badger-Eclipse钻 Badger-Eclipse钻 西南极恩特普赖斯丘陵蓝冰2022/2023 29.5 0.47 无粒雪层 改进版Kovacs螺旋钻 ASIG钻 西南极皮里特丘陵
粒雪+冰层(2016/2017)700 150 10 5 39 螺旋取
心钻Isopar K 套管+封隔器 全面
钻头聚晶金刚石复合片钻头
阶梯型孕镶金刚石钻头孕镶
金刚石
钻头格陵兰岛冰穹普拉德霍2023 509.4 4 4.4 螺旋取
心钻Isopar K 套管+封隔器 全面
钻头聚晶金刚石复合
片钻头
阶梯型孕镶金刚
石钻头孕镶
金刚石
钻头RAID钻 西南极明纳陡崖
2019/20203 300 680 3 3 38.4 螺旋钻
取心钻ESTISOLTM 140 套管+封隔器 全面
钻头工具钢
取心钻头
聚晶金刚石复合片钻头孕镶
金刚石
钻头
下载: 导出CSV
-
Albert, M. R., Slawny, K., Johnson, J., et al., 2024. Drilling Ice and Subglacial Rock Cores for Scientific Discovery in a Changing Climate. Glaciers—Recent Research, Importance to Humanity and the Effects of Climate Change. IntechOpen, London. https://doi.org/10.14379/iodp.proc.374.101.2019 Boeckmann, G. V., Gibson, C. J., Kuhl, T. W., et al., 2021. Adaptation of the Winkie Drill for Subglacial Bedrock Sampling. Annals of Glaciology, 62(84): 109-117. https://doi.org/10.1017/aog.2020.73 Braddock, S., Venturelli, R. A., Nichols, K., et al., 2025. Lessons Learned from Shallow Subglacial Bedrock Drilling Campaigns in Antarctica. Annals of Glaciology, 65(18): 1-11. https://doi.org/10.1017/aog.2024.12 Falconer, T., Pyne, A., Olney, M., et al., 2007. Operations Overview for the Andrill Mcmurdo Ice Shelf Project, Antarctica. Terra Antartica, 14(3): 131-140. Falconer, T., Pyne, A., Wilson, D., et al., 2008. Operations Overview for the Andrill Southern Mcmurdo Sound Project, Antarctica. Terra Antartica, 15(1): 41-48. Gong, D., 2017. Design and Experimental Study of Self-Synchronous Vibration Sampler for Subglacial Sediments (Dissertation). Jilin University, Changchun (in Chinese with English abstract). Goodge, J. W., Severinghaus, J. P., Johnson, J., et al., 2021. Deep Ice Drilling, Bedrock Coring and Dust Logging with the Rapid Access Ice Drill (RAID) at Minna Bluff, Antarctica. Annals of Glaciology, 62(85-86): 324-339. https://doi.org/10.1017/aog.2021.13 Harwood, D., Levy, R., Cowie, J., et al., 2006. Deep Drilling with the ANDRILLProgram in Antarctica. Scientific Drilling, 3: 43-45. https://doi.org/10.5194/sd-3-43-2006 Hemer, M., Harris, P., 2003. Sediment Core from beneath the Amery Ice Shelf, East Antarctica, Suggests Mid-Holocene Ice-Shelf Retreat. Geology, 31(2): 127-130. https://doi.org/10.1130/0091-7613(2003)031<0127:SCFBTA>2.0.CO;2 doi: 10.1130/0091-7613(2003)031<0127:SCFBTA>2.0.CO;2 Hodgson, D. A., Bentley, M. J., Smith, J. A., et al., 2016. Technologies for Retrieving Sediment Cores in Antarctic Subglacial Settings. Philosophical Transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 374(2059): 20150056. https://doi.org/10.1098/rsta.2015.0056 Huston, M., Gilbert, N., Newman, J., 2006. Final Comprehensive Environmental Evaluation (CEE) for ANDRILL, McMurdo Sound Portfolio. In: Huston, M., Gilbert, N., Newman, J., eds., ANDRILL-McMurdo Sound Portfolio. International Antarctic Centre, Christchurch. Kellogg, D. E., Kellogg, T. B., 1986. Diatom Biostratigraphy of Sediment Cores from beneath the Ross Ice Shelf. Micropaleontology, 32(1): 74-94. https://doi.org/10.2307/1485703 Kuhl, T., Gibson, C., Johnson, J., et al., 2021. Agile Sub-Ice Geological (ASIG) Drill Development and Pirrit Hills Field Project. Annals of Glaciology, 62(84): 53-66. https://doi.org/10.1017/aog.2020.59 Li, B., Han, L. L., Li, Y. Z., et al., 2021. Scientific Objective Analysis and Drilling Technology Progress of Polar Drilling in the United States. Drilling Engineering, 48(9): 10-25 (in Chinese with English abstract). McKay, R. M., De Santis, L., Kulhanek, D. K., et al., 2019. Expedition 374 Summary. In: McKay, R. M., De Santis, L., Kulhanek, D. K., and the Expedition 374 Scientists, Ross Sea West Antarctic Ice Sheet History. Proceedings of the International Ocean Discovery Program, 374: College Station, TX (International Ocean Discovery Program). https://doi.org/10.14379/iodp.proc.382.101.2021 Naish, T. R., Powell, R. D., Levy, R. H., et al., 2007. A Record of Antarctic Climate and Ice Sheet History Recovered. EOS, Transactions American Geophysical Union, 88(50): 557-558. https://doi.org/10.1029/2007eo500001 Niu, X. W., Gao, J. Y., Wu, Z. C., et al., 2016. Lithosphere Anisotropy of Prydz Bay, Antarctica: From Ocean Bottom Seismometer Long Term Observation. Earth Science, 41(11): 1950-1958 (in Chinese with English abstract). Patterson, M. O., Levy, R. H., Kulhanek, D. K., et al., 2022. Sensitivity of the West Antarctic Ice Sheet to +2 ℃ (SWAIS 2C). Scientific Drilling, 30: 101-112. https://doi.org/10.5194/sd-30-101-2022 Talalay, P. G., 2013. Subglacial Till and Bedrock Drilling. Cold Regions Science and Technology, 86: 142-166. https://doi.org/10.1016/j.coldregions.2012.08.009 Talalay, P. G., Leitchenkov, G., Lipenkov, V., et al., 2025. Rare Ice-Base Temperature Measurements in Antarctica Reveal a Cold Base in Contrast with Predictions. Communications Earth & Environment, 6(189): 1-7. https://doi.org/10.1038/s43247-025-02127-1 Talalay, P., Li, X. C., Zhang, N., et al., 2021. Antarctic Subglacial Drilling Rig: Part II. Ice and Bedrock Electromechanical Drill (IBED). Annals of Glaciology, 62(84): 12-22. https://doi.org/10.1017/aog.2020.38 Tuo, S. T., Jian, Z. M., 2016. Scientific Ocean Drilling Vessels: Review and Prospect. Journal of Engineering Studies, 8(2): 155-161 (in Chinese with English abstract). doi: 10.3724/SP.J.1224.2016.00155 Wang, R. J., Xiao, W. S., Zhang, T. L., et al., 2017. Geological Drilling in Polar Regions: Progress and Perspectives. Advances in Earth Science, 32(12): 1236-1244 (in Chinese with English abstract). Weber, M. E., Raymo, M. E., Peck, V. L., et al., 2021a. Expedition 382 Summary. In: Weber, M. E., Raymo, M. E., Peck, V. L., Williams, T., and the Expedition 382 Scientists, Iceberg Alley and Subantarctic Ice and Ocean Dynamics. Proceedings of the International Ocean Discovery Program, 382: College Station, TX (International Ocean Discovery Program). https://doi.org/10.14379/iodp.proc.382.102.2021 Weber, M. E., Raymo, M. E., Peck, V. L., et al., 2021b. Expedition 382 Methods. In: Weber, M. E., Raymo, M. E., Peck, V. L., Williams, T., and the Expedition 382 Scientists, Iceberg Alley and Subantarctic Ice and Ocean Dynamics. Proceedings of the International Ocean Discovery Program, 382: College Station, TX (International Ocean Discovery Program). _ext_link_paichu__ Zhang, N., Wang, L., Talalay, P., et al., 2020. Advances in Research on Key Technology for Ice Drilling in the Polar Regions. Exploration Engineering (Rock & Soil Drilling and Tunneling), 47(2): 1-16 (in Chinese with English abstract). Zhu, Z. T., Liu, X. L., Tian, L. Y., et al., 2020. Development and Application of the Reentry Drilling Technology and System in Ocean Drilling. Exploration Engineering (Rock & Soil Drilling and Tunneling), 47(7): 8-15 (in Chinese with English abstract). 宫达, 2017. 自同步式冰下沉积物振动取样器设计与实验研究(博士学位论文). 长春: 吉林大学. 李冰, 韩丽丽, 李亚洲, 等, 2021. 美国极地钻探科学目标分析与钻探技术进展. 钻探工程, 48(9): 10-25. 牛雄伟, 高金耀, 吴招才, 等, 2016. 南极洲普里兹湾岩石圈各向异性: 海底地震仪观测. 地球科学, 41(11): 1950-1958. doi: 10.3799/dqkx.2016.135 拓守廷, 翦知湣, 2016. 科学大洋钻探船的回顾与展望. 工程研究-跨学科视野中的工程, 8(2): 155-161. 王汝建, 肖文申, 章陶亮, 等, 2017. 极地地质钻探研究进展与展望. 地球科学进展, 32(12): 1236-1244. 张楠, 王亮, Pavel Talalay, 等, 2020. 极地冰钻关键技术研究进展. 探矿工程(岩土钻掘工程), 47(2): 1-16. 朱芝同, 刘晓林, 田烈余, 等, 2020. 大洋钻探重入钻孔技术与系统发展应用. 探矿工程(岩土钻掘工程), 47(7): 8-15. -
