Design and Application of a Digital Direct-Drive Electro-Hydraulic Control System for Coal Mine Drilling Rigs
-
摘要: 针对常规煤矿钻机电控系统集成度低、现场调试周期长、故障定位效率低等问题，设计一种煤矿钻机用数字直驱式电液控制系统. 采用分布式架构，构建双通道隔离CAN总线通信网络，开发数据服务与边缘计算模块，多源异构数据采集板和基于数字阀的驱动电路；制定专用通信协议，开发总线在线监测、传感器故障诊断、变值触发式控制指令下发算法；融合远程组网与IAP远程升级技术，实现系统远程调试与维护. 将系统应用于多种矿用钻机，与传统电液控制系统相比，平均调试周期缩短约50%，非电源短路情况下的常规电控系统故障识别率达100%，售后服务频次降低约50%. 有效提升了电控钻机数字化水平和系统可维护性，为矿用钻机数字化升级提供了一套可行的方案.Abstract: To address the issues of low integration, lengthy on-site commissioning cycles, and inefficient fault localization in conventional electric control systems for coal mine drilling rigs, a digital direct-drive electro-hydraulic control system for coal mine drilling rigs is designed. A distributed architecture is adopted, and a dual-channel isolated CAN bus communication network is constructed. Data service and edge computing modules, multi-source heterogeneous data acquisition boards, and digital valve-based drive circuits are developed. A dedicated communication protocol is established, along with algorithms for bus online monitoring, sensor fault diagnosis, and variable-triggered control command transmission. Remote networking and IAP remote upgrade technologies are integrated to enable remote system commissioning and maintenance. The system is applied to various types of mine drilling rigs. Compared with traditional electro-hydraulic control systems, the average commissioning cycle is shortened by approximately 50%, the fault identification rate for conventional electric control systems under non-power-short-circuit conditions reaches 100%, and after-sales service frequency is reduced by about 50%. This study effectively enhances the digitalization level and system maintainability of electrically controlled drilling rigs, offering a feasible solution for the digital upgrade of mining drilling rigs.
-
图 1 数字直驱式电液控制系统总体方案
Fig. 1. Overall scheme of the digital direct-drive electro-hydraulic control system
图 3 隔离CAN总线与RS485总线电路原理图
a.RS485总线电路；b.CAN总线电路
Fig. 3. Schematic diagram of the isolated CAN bus and RS485 bus circuits
图 4 Linux核心板外围主要电路接口
Fig. 4. Main peripheral circuit interfaces of the Linux core board
图 5 采集器与控制器三维模型
a. 采集器三维模型（1防水航插，2采集器机芯组件，3门盖密封条，4采集器壳体，5门盖，6按钮，7触摸屏）；b.控制器三维模型（1控制器机芯组件，2电缆引入装置，3防爆壳体，4双路本安电源，5驱动板，6开关电源，7门盖）
Fig. 5. Three-dimensional model of the collector and controller
图 7 变值触发式控制指令下发算法框图
Fig. 7. Algorithm flowchart for variable-value triggered control command issuing algorithm
图 10 ZDY10000LDK型窄体式遥控定向钻机
Fig. 10. ZDY10000LDK narrow-body remote-controlled directional drilling rig
图 11 ZDY10000LDK钻机电液控制系统组成示意图
Fig. 11. Schematic diagram of the ZDY10000LDK drilling rig electro-hydraulic control system composition
图 12 远程组网与现场设备示意图
Fig. 12. Schematic diagram of remote networking and on-site equipment
图 13 搭载不同电液控制系统的钻机调试周期对比
Fig. 13. Comparison of commissioning cycles of drilling rigs with different electro-hydraulic control systems
图 14 搭载不同系统的钻机售后服务频次对比
Fig. 14. Comparison of after-sales service frequency of drilling rigs with different systems
表 1 多源数据采集板接口类型与数量
Table 1. Interface types and quantities for multi-source data acquisition board
接口类型 符号 数量 备注 电流量采集接口 AI 11路 电压量采集接口 UI 11路 可复用为AI或DI 电阻量采集接口 RI 2路 开关量采集接口 DI 8路 CAN总线接口 CAN 2路 隔离设计 RS485总线接口 RS485 1路 隔离设计
下载: 导出CSV
表 2 驱动板接口类型与数量
Table 2. Interface types and quantities of the drive board
接口类型 符号 数量 备注 CAN总线接口 CAN1 1路 本安 CAN总线接口 CAN2 1路 隔爆 PWM输出接口 PWM 6路 隔爆
下载: 导出CSV
表 3 数据采集系统通讯协议
Table 3. Communication protocol of the data acquisition system
CAN ID 数据位 D0 D1 D2 D3 D4 D5 D6 D7 0x200 AI个数 UI个数 RI个数 CAN RS485 0x311 AI1 AI2 AI3 AI4 0x312 AI5 AI6 AI7 AI8 0x313 AI9 AI10 AI11 RI1 0x314 UI1 UI2 UI3 UI4 0x315 UI5 UI6 UI7 UI8 0x316 UI9 UI10 UI11 RI2 0x317 DI SDI1 SDI2 SDI3 0x318 CAN120 CAN121 CAN123 CAN124 0x319 CAN125 CAN126 CAN127 CAN128 0x31A RS485-1 RS485-2 RS485-3 总线传感器故障码 0x31B 电流量短路故障码 电流量断路故障码 电压量短路故障码 电压量断路故障码
下载: 导出CSV
表 4 防爆数字阀CAN总线通信协议
Table 4. CAN bus communication protocol of the explosion-proof digital valve
ID 数据位 帧类型 D0 D1 D2 D3 0x180+ID 0x08 0x00 [-1 000，1 000] 反馈帧 0x200+ID 0x07 0x00 [-1 000，1 000] 指令帧
下载: 导出CSV
表 5 驱动板通讯协议
Table 5. Communication protocol of the drive board
本安CAN1 ID 数据位 隔爆CAN2 D0 D1 D2 D3 D4 D5 D6 D7 接收 0x401 PWM1 PWM2 PWM3 PWM4 PWM5 PWM6 PF 无 发送 0x629 RPWM1 RPWM2 RPWM3 RPWM4 RPWM5 RPWM6 PS 接收 0x201 0x07 0x00 [-1 000，1 000] 无 转发 接收 0x202 0x07 0x00 [-1 000，1 000] 无 转发 接收 …… 0x07 0x00 [-1 000，1 000] 无 转发 转发 0x181 0x08 0x00 [-1 000，1 000] 无 接收 转发 0x182 0x08 0x00 [-1 000，1 000] 无 接收 转发 …… 0x08 0x00 [-1 000，1 000] 无 接收
下载: 导出CSV
表 6 电控系统故障识别诊断统计
Table 6. Statistics of electronic control system fault identification and diagnosis
故障类别 出现次数 识别次数 识别准确率 本安型编码器通信中断 48 48 100% 拉绳位移传感器通信中断 52 52 100% 遥控器通信链路超时 27 27 100% 遥控器电源短路 6 0 0 CAN总线传感器短路 24 24 100% 数字阀离线 26 26 100% 压力传感器断路 38 38 100% 压力传感器短路 16 16 100% 采集板离线 21 21 100% 驱动板离线 16 16 100%
下载: 导出CSV
-
Chen, J., Li, J. M., 2025. FPGA-Based Design of Laser Gyro Signal Acquisition Circuit. Journal of Measurement Science and Instrumentation, 16(1): 107-118. https://doi.org/10.62756/jmsi.1674-8042.2025011 Dang, J., 2024. Research on Electro-Hydraulic System of Rotary-Feed for Drilling Rig Based on Digital Proportional Valve(Dissertation). China Coal Science Research Institute, Beijing(in Chinese with English abstract). Ding D., Peng X., Guo X. F., et al., 2020. Scenario-Driven and Bottom-Up Microservice Decomposition Method for Monolithic Systems. Journal of Software, 31(11): 3461-3480 (in Chinese with English abstract). Ding, Y., Liu, P., Zou, D. D., et al., 2019. Application of IAP Remote Upgrade Technology in Coal Mine Safety Monitoring Substation Based on ARM. Safety in Coal Mines, 50(8): 107-110(in Chinese with English abstract). Dong, H. B., Fan, Q., Li, K., et al., 2022. Development and Application of ZDY4500LFK Full Automatic Drilling Rig. Coal Geology & Exploration, 50(1): 66-71(in Chinese with English abstract). Dong, H. B., Yao, N. P., Ma, B., et al., 2020. Research on Electronically Controlled Automation Technology of Underground Drilling Rig for Coal Mine. Coalfield Geology & Exploration, 48(3): 219-224 (in Chinese with English abstract). . Găitan, N. C., Zagan, I., Găitan, V. G., 2024. Proposed Modbus Extension Protocol and Real-Time Communication Timing Requirements for Distributed Embedded Systems. Technologies, 12(10): 187. doi: 10.3390/technologies12100187 Gao, J., Tian, M. Q., Xu, C. Y., et al., 2020. Research on Electro-Hydraulic Control System of Thin Coal Seam Hydraulic Support Based on Double CAN Bus. Coal Engineering, 52(1): 143-147(in Chinese with English abstract). Guo, Y. F., Xu, P., Li, W., et al., 2025. 3D Perception and Reconstruction of Underground Coal Mine Roadways Based on Multi-Sensor Fusion. Earth Science, 1-15(in Chinese with English abstract). Huang, Z. B., 2022. Design and Implementation of Portable CAN Bus Analyzer in Underground Coal Mine. Safety in Coal Mines, 53(1): 134-138(in Chinese with English abstract). Jianan, L., Abas, A., 2020. Development of Human-Computer Interactive Interface for Intelligent Automotive. International Journal of Artificial Intelligence, 7(2): 13-21. https://doi.org/10.36079/lamintang.ijai-0702.134 Jiang, Z. D., Wei, W., He, J., et al., 2023. Practice of Remote Leakage Test Transformation of Low Voltage Power Equipment in Coal Mine. Automation in Mines and Factories, 49(S2): 142-145(in Chinese with English abstract). Li, K., Ting, R., Yao, Y. F., 2023. Key Technology of Automatic Loading and Unloading System for Dual-Pipe Directional Drilling Rig and Its Application in Soft-Fragmentized Coal Seam. Coalfield Geology & Exploration, 51(4): 179-186(in Chinese with English abstract). Li, T. T., Zhang, Y., Zhang, X., 2026. A Cloud-Edge-End Collaborative Architecture for Intelligent Operation and Maintenance of High-End Drilling Equipment. Earth Science, 1-12(in Chinese with English abstract). Li, X. M., Han, J., Yao, Y. F., 2020. Narrow-Body Directional Crawler Drilling Rig Used in Coal Mine. Safety in Coal Mines, 51(11): 142-145(in Chinese with English abstract). Ma, L., 2020. Power Supply Technology of 5G Equipment in Underground Coal Mine. Coal Mine Safety, 51(5): 111-113(in Chinese with English abstract). Sun, P. L., Liu, X., Zhang, G., et al., 2025. Digital Twin-Driven Remote Operation and Maintenance Method for Electromechanical Equipment. Journal of Xi'an Jiaotong University, 59(8): 20-31(in Chinese with English abstract). Tinetti, F. G., Romero, F. L., Perez, A D., 2018. CAN Bus Experiments of Real-Time Communications. IEEE Latin America Transactions, 16(1): 207-214. Wang, G. F., 2022. New Technological Progress of Coal Mine Intelligence and Its Problems. Coal Science and Technology, 50(1): 1-27(in Chinese with English abstract). Wang, G. F., Xu Y. J., Zhang J. H., et al., 2021. New Development of Intelligent Mining in Coal Mines. Coal Science and Technology, 49(1): 1-10(in Chinese with English abstract). Wang, J. P., Zhang, W. S., Shi, Y. K., et al., 2018. Industrial Big Data Analytics: Challenges, Methodologies and Applications. Journal of Industrial Information Integration, 10: 1-10(in Chinese with English abstract). Wang, Q. F., Chen, H., Zhou, T., 2022. Development History and Prospect of Automatic Drilling Technology and Equipment in Coal Mine. Mining Safety & Environmental Protection, 49(4): 45-50(in Chinese with English abstract). Wang, Q. F., Chen, H., Du, L., et al., 2025. Research Progress of Key Technology of the Intelligent Drilling Field in Coal Mine. Journal of China Coal Society, 1-14(in Chinese with English abstract). Weng, Y. S., Yin, X. S., Zhao, L., 2014. Design of Drilling Parameter Measuring System of Drill Rig in Soft Coal Seam. Coalfield Geology & Exploration, 42(5): 100-103(in Chinese with English abstract). Wu, Q. S., Shi, Z., Liang, H., 2012. Design of Underground Intelligent Controller Based on CAN Bus and Its Application. Industry and Mine Automation, 38(7): 102-104(in Chinese with English abstract). Xu, W. M., 2026. Study on Intelligent Control System and Control Method of Dry Dust Removal Vehicle. Mechanical Science and Technology for Aerospace Engineering, 45(4): 663-674(in Chinese with English abstract). Yang, Y. K., Zhang, M. L., Xu, C. Y, et al., 2023. Fault Detection and Diagnosis Method for Bus Communication in Hydraulic Support Electro-Hydraulic Control System. Automation in Mines and Factories, 49(12): 70-76(in Chinese with English abstract). Yang, Z. S., Zhang, C., Rong, X., 2025. Current Situation and Development Trend of Line Selection Method for Single-Phase Grounding Fault in Mine Power Supply System. Coal Mine Safety, 56(1): 212-219(in Chinese with English abstract). Yuan, L., 2023. Theory and Technology Considerations on High-Quality Development of Coal Main Energy Security in China. Bulletin of the Chinese Academy of Sciences, 38(1): 11-22(in Chinese with English abstract). Yuan, L., Zhang, J., Liang, Z., et al., 2023. EMI Challenges in Modern Power Electronic-Based Converters: Recent Advances and Mitigation Techniques. Frontiers in Electronics, 4: 1274258(in Chinese with English abstract). doi: 10.3389/felec.2023.1274258 Zhang, G., 2021. Fault Monitoring of Electric and Hydraulic Control System of Remote Control Drilling Rig. Safety in Coal Mines, 52(5): 154-157(in Chinese with English abstract). Zhang, X. H., Tian, M. Q., Zhang, M. L., et al., 2023. Design of End Controller for the Electrohydraulic Control System of Intelligent Working Face Hydraulic Support. Automation in Mines and Factories, 49(8): 30-36(in Chinese with English abstract). Zhou, X. Y., Liu, Y. Z., Zhao, Y. J., et al., 2025. Hierarchical Spatial Embedding BiGRU Model for Destination Prediction. Journal of Zhejiang University (Engineering Science), 59(6): 1211-1218(in Chinese with English abstract). 党健, 2024. 基于数字比例阀的钻机回转给进电液系统研究(博士学位论文). 北京: 煤炭科学研究总院. 丁丹, 彭鑫, 郭晓峰, 等, 2020. 场景驱动且自底向上的单体系统微服务拆分方法. 软件学报, 31 (11): 3461-3480. 丁远, 刘鹏, 邹德东, 等, 2019. 基于ARM的煤矿监控分站IAP远程升级技术. 煤矿安全, 50(8): 107-110. 董洪波, 范强, 李坤, 等, 2022. ZDY4500LFK全自动钻机开发与应用. 煤田地质与勘探, 50 (1): 66-71. 董洪波, 姚宁平, 马斌, 等, 2020. 煤矿井下坑道钻机电控自动化技术研究. 煤田地质与勘探, 48(3): 219-224. 高晋, 田慕琴, 许春雨, 等, 2020. 基于双CAN总线的薄煤层液压支架电液控制系统研究. 煤炭工程, 52 (1): 143-147. 郭云飞, 徐鹏, 李伟, 等, 2025. 基于多传感器融合的煤矿井下巷道三维感知与重建方法. 地球科学. 1-15. doi: 10.3799/dqkx.2025.274 黄增波, 2022. 便携式煤矿井下CAN总线分析仪的设计与实现. 煤矿安全, 53 (1): 134-138. 姜占东, 魏巍, 何军, 等, 2023. 煤矿井下低压电力设备远程漏电试验改造实践. 工矿自动化, 49 (S2): 142-145. 厉曈曈, 张毅, 雷彪, 等, 2026. 云边端协同高端钻探装备智能运维体系架构. 地球科学, 1-12. doi: 10.3799/dqkx.2026.024 李坤, TING, R., 姚亚峰, 2023. 碎软煤层双管定向钻具自动加卸系统关键技术与应用. 煤田地质与勘探, 51(4): 179-186. 李晓明, 韩健, 姚亚峰, 2020. 煤矿用窄体小型履带式定向钻机. 煤矿安全, 51 (11): 142-145. 马龙, 2020. 5G设备煤矿井下电源供电技术. 煤矿安全, 51(5): 111-113. 孙培禄, 刘馨, 张耿, 等, 2025. 数字孪生驱动的机电设备远程运维方法. 西安交通大学学报, 59(8): 20-31. 王国法, 2022. 煤矿智能化最新技术进展与问题探讨. 煤炭科学技术, 50(1): 1-27. 王国法, 徐亚军, 张金虎, 等, 2021. 煤矿智能化开采新进展. 煤炭科学技术, 49(1): 1-10. 王清峰, 陈航, 杜雷, 等, 2025. 煤矿智能化钻场关键技术研发进展. 煤炭学报, 1-14. 王清峰, 陈航, 周涛, 2022. 煤矿井下自动化钻进技术及装备的发展历程与展望. 矿业安全与环保, 49 (4): 45-50. 翁寅生, 殷新胜, 赵良. 2014. 松软煤层坑道钻机钻进参数测量系统设计. 煤田地质与勘探, 42 (5): 100-103. 徐文明, 2025. 干式除尘车智能化控制系统及控制方法研究. 机械科学与技术, 1-13. 杨永锴, 张敏龙, 许春雨, 等, 2023. 液压支架电液控制系统总线通信故障检测与诊断方法. 工矿自动化, 49 (12): 70-76. 杨战社, 张程, 荣相, 2025. 矿井供电系统单相接地故障选线方法现状与发展趋势. 煤矿安全, 56 (1): 212-219. 袁亮, 2023. 我国煤炭主体能源安全高质量发展的理论技术思考. 中国科学院院刊, 38(1): 11-22. 吴清收, 史珍, 梁辉, 2012. 井下CAN总线智能控制器的设计及应用. 工矿自动化, 38(7): 102-104. 张刚, 2021. 遥控钻机电液控制系统故障监控. 煤矿安全, 52 (5): 154-157. 张晓海, 田慕琴, 张敏龙, 等, 2023. 智能工作面液压支架电液控制系统端头控制器设计. 工矿自动化, 49 (8): 30-36. 周翔宇, 刘毅志, 赵肄江, 等, 2025. 面向目的地预测的层次化空间嵌入BiGRU模型. 浙江大学学报(工学版), 59 (6): 1211-1218. -
